Towards a Natural Language Dialog System for Mobility Service

Platforms

David Thulke

1,∗

, Felix Schwinger

1,2

and Karl-Heinz Krempels

1,2

Information Systems, RWTH Aachen University, Aachen, Germany

Fraunhofer Institute for Applied Information Technology FIT, St. Augustin, Germany

Keywords:

Mobility Service Platforms, Natural Language Processing, Dialog Systems.

Abstract:

Due to a rise in novel mobility modes, urban transportation systems have become more heterogeneous and

complicated in recent years. Mobility Service Platforms integrate different mobility services to offer integrated

travel information, booking, and travel assistance, regardless of mobility provider or mode. Traditionally, users

access these information systems through graphical user interfaces. Especially for the older population, such a

sophisticated information system for a complex problem is problematic. Therefore, in this paper, we propose

an approach and a prototype for a natural language interface for Mobility Service Platforms. The natural

language interface allows access to the Mobility Service Platforms’ information systems and integrates other

domains, such as event and place information into natural language queries. To this end, we introduce a

simple uniﬁed data model for travel, event, and Point of Interest domain and design an interaction model for

the natural language interface. We evaluate the prototype in a case study with potential users. The evaluation

shows that most users are more comfortable interacting with a mobility service platform using natural language

instead of using different graphical user interfaces providing similar functionality.

1 INTRODUCTION

Finding optimal itineraries in urban transportation

networks is becoming increasingly complex. Mo-

torized private transport causes challenges like con-

gestions, air pollution, scarcity of parking spaces, and

greenhouse gas emissions. Simultaneously, alterna-

tive mobility services like car-, bike-, or ride-sharing

are emerging and gaining popularity. These alterna-

tive mobility services may help to alleviate the ﬁrst-

mile/last-mile problem. This problem occurs with

public transportation. People have trouble managing

their ﬁrst mile to a public transit station and from their

last-mile from destination stop to their ﬁnal destina-

tion. Hence, alternative mobility services are also

of great political importance to provide sustainable

transportation means by allowing people to access

public transportation more efﬁciently.

An increasing amount of real-time data on traf-

ﬁc ﬂow and delays in public transport networks be-

came available in recent years for all these mobility

modes. For travelers, it becomes increasingly difﬁ-

* David Thulke is now afﬁliated with the Chair of Human

Language Technology and Pattern Recognition, RWTH

Aachen University, Aachen, Germany

cult to ﬁnd their preferred journeys in such heteroge-

neous information systems. Furthermore, due to mo-

bility modes’ heterogeneity, the shortest time, price,

weather conditions, reliability, and sustainability are

critical factors to consider for travelers when choos-

ing their itinerary. Manually comparing different pos-

sibilities is becoming a challenging task since the nec-

essary information is often only available in special-

ized applications. Optimal itineraries may even be in-

termodal, i.e., they consist of a mix of multiple dif-

ferent modes of transportation during a single trip. In

this case, reserving and booking legs requires deal-

ing with different pricing schemes and booking pro-

cesses. Additionally, travelers have to check each leg

for delays individually manually and are accountable

if they miss their connection due to a prior delay. One

approach to solve these issues are Mobility Service

Platforms (MSPs) (Beutel et al., 2018) which imple-

ment the concept of Mobility-as-a-Service.

MSPs try to integrate different transportation

modes to provide travelers with a uniﬁed interface for

routing, booking, and travel assistance. Mobility-as-

a-Service describes the notion that people stop rely-

ing on private vehicles for their mobility needs, but

rather turn to service providers. To make this feasible,

706

Thulke, D., Schwinger, F. and Krempels, K.

Towards a Natural Language Dialog System for Mobility Service Platforms.

DOI: 10.5220/0010526507060713

In Proceedings of the 7th International Conference on Vehicle Technology and Intelligent Transport Systems (VEHITS 2021), pages 706-713

ISBN: 978-989-758-513-5

standardization of interfaces and business processes

between different stakeholders is necessary. Even

though MSPs attempt to ease the complexity of com-

bining multiple transportation modes, new users may

easily be overwhelmed by the sheer amount of dif-

ferent options available to them (Schulz et al., 2020).

One of the political goals of MSPs are to enable more

people to use sustainable mobility modes for their

daily mobility needs, i.e., allowing a switch from pri-

vate transportation to public and shared transporta-

tion. Therefore, people require information on how to

realize their mobility needs with the available modes

without being drowned in the mass of heterogeneous

information.

Users primarily interact with these systems using

Graphical User Interfaces (GUIs), like web pages or

smartphone apps. An alternative to these are Natu-

ral Language Interfaces (NLIs). They allow users to

interact with a system using natural speech or text.

There is a distinction between question-answering

and dialog systems. The former only replies to a

single user utterance, whereas, in contrast, the lat-

ter takes the previous conversation into account when

answering user queries. This kind of interaction has

some advantages for travel information systems com-

pared to GUIs. Using speech for the interaction

makes the system accessible in situations where a

screen can or should not be used, e.g., while driving or

walking or even for users who have difﬁculties oper-

ating GUIs due to disabilities (Pradhan et al., 2018).

Additionally, interacting with the system using nat-

ural language may make it more accessible to users

with low system knowledge or inexperienced users

with limited knowledge about interacting with com-

puters at all (Dodd et al., 2017). It is easier to for-

mulate a complex query using a single sentence than

selecting the options in a GUI. Another advantage of

dialog systems is that it is easy to switch domains or

interact with the system across multiple areas. For

example, users could ask for a restaurant recommen-

dation and then plan an itinerary for the selected re-

sult. On the other hand, NLIs make it harder to dis-

cover functionalities, may not meet the language un-

derstanding capabilities expected by users, and often

result in privacy concerns due to off-device process-

ing of language and data annotation requirements.

This work aims to do the ﬁrst step towards a dia-

log system for an MSP to lower its usage complexity

in Mobility-as-a-Service scenarios. For this, we con-

tribute in the following way:

Domain Data Model: To allow users seamless inter-

action between the domains travel, point of inter-

est, and events, we designed a corresponding data

model. The connection of these domains helps

travelers to ﬁnd itineraries suitable to their needs.

Interaction Model: For the NLI, we designed a pro-

totype interaction model capturing intents belong

to the three domains of the data model. The user

can query information in a distinct domain and

formulate queries that mix information from dif-

ferent domains.

Context Model: In a cross-domain scenario, it is

complex to handle the context of a conversation

as utterances may refer to a multitude of different

entities. For this, we developed a cross-domain

context model that captures relevant context in-

formation in the different domains.

With these contributions, we attempt to ease the usage

of an MSP and address the problem of the ﬂood of

information for new users.

Section 2 gives a brief overview of related work.

In Section 3, we elicit general requirements, propose

a system architecture, and design an initial prototype

for such a system. Based on this, Section 4 presents a

simple prototype of the system. The case study, where

potential users used and rated the general concept and

an initial prototype, is discussed in Section 5. Finally,

Section 6 concludes the paper and gives an outlook on

future work.

2 RELATED WORK

This section introduces and discusses related work

and state-of-the-art travel information systems and

natural language dialog systems. Already in 1995,

Aust et al. developed a spoken dialog system for train

timetable information in Germany. The system was

restricted to this single domain but allowed users to

correct and update their queries. It was callable via

the telephone network and used stochastic context-

free grammars for speech understanding. Turunen et

al. (2005), Raux et al. (2005), Du

sek et al. (2014) de-

veloped similar systems.

The Deep Map project (Malaka and Zipf, 2000)

was to build a tourist guide for the City of Heidel-

berg. Users could query information like sights, ho-

tels, restaurants, and ﬁnding itineraries through a nat-

ural language interface. The SpaceBook project (Bar-

tie et al., 2018) developed a similar system for the

City of Edinburgh. In contrast to the system proposed

in this paper, they focused on supporting tourists dur-

ing their trip.

Braun et al. (2018) developed a system integrat-

ing different mobility services accessible via a nat-

ural language interface. It enables intermodal rout-

ing by building a meta-model for different mobility

Towards a Natural Language Dialog System for Mobility Service Platforms

707

services. In contrast to other approaches, they only

use the publicly available APIs of the mobility ser-

vices and do not rely on their cooperation. Other ser-

vices of a mobility service platform, such as reserving

or booking itineraries, are currently not supported by

their approach. In contrast to the system developed in

this service, their interface is limited to travel infor-

mation.

In the NLMaps project (Lawrence and Riezler,

2016), the goal was to develop a question-answering

system for the OpenStreetMap (OSM) database. The

system translates user utterances to queries to the

database. Besides the system, the authors present the

corresponding NLmaps corpus in (Haas and Riezler,

2016) containing 2,380 natural language questions in

German and English paired with queries to OSM in

the custom query language.

3 SYSTEM DESIGN

For the requirements engineering and implementation

process, we followed a user-centered approach (Low-

dermilk, 2013). To guide the system’s design, we

start by deﬁning multiple scenarios as user stories that

we have also validated in a Wizard-of-Oz experiment

(Dahlb

ack et al., 1993). In a Wizard-of-Oz experi-

ment, users interact with a system without knowing

that a person operates the system. These user sto-

ries outlined how potential users may interact with the

system. We used these scenarios to derive require-

ments and to guide the design and development of

our approach. Next, a common data model for the

individual domains covered by the system is deﬁned.

Based on this, an interaction model is developed, de-

scribing the interaction between users and the system.

Next, a context model is discussed, which the system

has to consider during a dialog. Finally, we give an

overview of the architecture of the whole system.

3.1 Domain Data Model

The proposed system should combine data from dif-

ferent sources. A data model of the relevant domains

has to be speciﬁed to give reasonable responses.

The main objects in the domain are shown in Fig-

ure 1 and are POIs, events, and itineraries. A POI is

a subclass of a Place, which is a generic description

of an object on a map. A Place has a Geography and

may have an Address. The former is an abstract type

representing a geographical shape and may be a Co-

ordinate, a Line, like a street, or an Area, like a city.

An Event has a start date and may have a speciﬁc

end date or no deﬁned end. It has a name and a de-

Place

-country

-city

-postcode

-street

-housenumber

Address

Geography

start

end

location

has

0..*

consists of

1..*

{ordered}

-id

User

homeLocation

workLocation

currentLocation

departures

-name

-type

-startDateTime

-endDateTime

-description

Event

Itinerary

-name {optional}

-type

POI

-number

-vehicleType

-direction

JourneyLeg

-track

PTStop

-cuisine

Restaurant

-startDateTime

-endDateTime

-mode

Leg

Figure 1: Data Model of the individual domains. The ob-

jects in the travel domain are in green, in the Point of Inter-

est (POI) domain in blue and in the event domain in red.

scription and is located at a particular Place. Finally,

an Itinerary is a possible trip between two places. It

has an ordered non-empty list of Legs. Each Leg rep-

resents one part of the trip and has a speciﬁc start and

end place and a start and end date. Finally, each User

has a home, work, and current location, which are ref-

erences to a speciﬁc place.

3.2 Interaction Model

As a next step in the system design, we deﬁne the in-

teraction model between the user and the system. The

interaction model consists of the set of dialog acts,

i.e., the intents and their corresponding entities, the

system can understand. Intents are classes of user ut-

terances describing their intention or goal.

We gathered an initial corpus of possible dialogs

and user utterances to deﬁne the set of intents and en-

tities systematically. For this, we ﬁrstly generated a

corpus by hand consisting of manually generated ut-

terances based on the results of a small Wizard-of-Oz

experiment (Dahlb

ack et al., 1993), and secondly, in-

corporated the NLMaps corpus.

Thereby the following main intents were identi-

ﬁed:

• get pois: utterances that search for POIs.

• get events: utterances that search for events.

• get departures: utterances asking for depar-

tures at public transport stops.

• find itineraries: utterances that ask for an

itinerary.

VEHITS 2021 - 7th International Conference on Vehicle Technology and Intelligent Transport Systems

708

Another set of utterances are those where users

want to change or correct a previous request (e.g., “I

meant near A”) or respond to a clariﬁcation request of

the system (e.g., “What is your destination?”). These

were classiﬁed under the intent update slot. The

purpose of some entities depends on the context of the

utterance. A reference to a place could be a source,

destination, or direction entity. A time could be

a start time or an arrival time. The time in the

utterance “I meant at 2 pm” could either be a depar-

ture or arrival time depending on which one of them

the user speciﬁed in a previous utterance (e.g., “I want

to depart at 3 pm” or “I want to arrive at 3 pm”).

For references to places or dates, the user context

can be used (e.g., the home location). Users might

want to query the current state of the context (e.g.,

“Where am I?” or “Where do I work?”) or might

want to update this state (e.g., “I work in the com-

puter science center.”). For these utterances, the in-

tents get * location and update * location were

added. Similar intents for dates could be added in the

future.

3.3 Context Model

To adequately reply to a request, it is often not suf-

ﬁcient to understand the user utterance, but the addi-

tional context must be considered. Bunt (1999) de-

ﬁnes context as “factors relevant to the understanding

of communicative behavior”. He categorizes context

into dialog, user, and world context.

The dialog context consists of the relevant infor-

mation of the current dialog with the user. This in-

cludes the history and the current goal of the dialog.

These are used in the dialog manager to decide on the

next action of the system. Users may refer to objects

mentioned in earlier utterances (e.g. “How do I get

there?”). This co-reference has to be resolved from

the dialog history.

The user context contains information on the user,

which is relevant to the dialog. This work includes the

current, home, and work location of the user. Besides,

this can include personal information like the user’s

preferences.

Finally, the world context includes information in-

dependent of the current dialog and user but could still

inﬂuence the dialog.

3.4 System Architecture

Figure 2 gives an overview of the individual compo-

nents of the proposed system. The user interacts with

the User Interface (UI). This interaction could either

be via speech or text. In the former case, an Au-

NLU

NLG

Dialog

Manager

Task

Manager

Text

Text Dialog Act

Context

Update

Dialog Act

Action +

Context

Update

Figure 2: Abstract overview of the system architecture and

the interaction of the individual components.

tomatic Speech Recognition (ASR) component tran-

scribes the user utterance. The Natural Language Un-

derstanding (NLU) component receives the user ut-

terances as text. Its task is to transform the text into

a dialog act consisting of an intent and corresponding

entities deﬁned in the context model. Based on this

dialog act and the current context, the dialog man-

ager’s task is to predict the system’s following action.

Actions are either system dialog acts or forwarded to

the task manager. An example of the latter is to ﬁnd

an itinerary. Based on the action and the current con-

text, the task manager creates a query to the MSP.

Its response is passed back to the dialog manager to

update the current context. A system dialog act is

transformed into text by the Natural Language Gen-

eration (NLG) component. This text is then displayed

or spoken to the user via the UI. Besides, the UI may

send additional context updates, e.g., the current user

location, directly to the dialog manager.

4 IMPLEMENTATION

This section gives an overview of the implementa-

tion of the individual components discussed in Sec-

tion 3.4. Even though the system currently only sup-

ports German, examples are given in English or trans-

lated into English if there is a difference between

them. The individual components are containerized

using Docker. This segmentation increases the porta-

bility of the system by facilitating deployment to a

new environment.

4.1 Natural Language Understanding

Extracting dialog acts from user utterances, as de-

scribed in the interaction model, can be divided into

the sub-tasks of intent classiﬁcation and slot ﬁlling.

For both tasks, we used the default implementation,

pipelines, and models provided by the Rasa NLU

Towards a Natural Language Dialog System for Mobility Service Platforms

709

framework

. As a ﬁrst step, the user utterance is tok-

enized and converted to a sequence of GloVe embed-

ding vectors (Pennington et al., 2014). These vectors

are averaged to create a representation of the complete

utterance. Then support vector machines (SVMs) are

used to classify the intent based on this representation.

For the slot ﬁlling task, a feature-based conditional

random ﬁeld (CRF) model (Lafferty et al., 2001) is

used. Bocklisch et al. (2017) discuss this approach in

detail.

Even though these approaches do not achieve

state-of-the-art performance on the respective tasks,

they are very efﬁcient to train and work reasonably

with low amounts of training data, making them suit-

able to bootstrap the system.

The next step was to collect and annotate the nec-

essary training data. As freely available utterances

for NLI for the travel information domain is sparse,

we trained the system initially with the data from

the NLMaps corpus (about 1.500 utterances). As no

open corpus exists for cross-domain NLI we extended

this corpus with further data. For this, we performed

a Wizard-of-Oz experiment (Dahlb

ack et al., 1993)

and included about 150 relevant utterances. Next,

we manually ﬁne-tuned the corpus and included 400

more possible utterances. This ﬁne-tuning included,

among others, replacing words with synonyms or

similar utterances with slightly different nuances. Fi-

nally, we augmented the corpus’s utterances by re-

placing entities with different values to increase the

corpus size further.

Afterward, we needed to annotate the utterances

for each intent in the corpus. For this, we manually

annotated about 5 to 20 utterances per intent for a to-

tal number of 56 intents. To annotate the remaining

utterances, we trained an initial version of the natural

language understanding system with the initial data.

Then the system was used to classify and recognize

the next chunk of utterances automatically. As not all

utterances were correctly classiﬁed, we manually cor-

rected the system’s classiﬁcation errors, and then we

added the data to the training corpus. We repeated this

process until all utterances were correctly labeled.

4.2 Dialog Manager

The Rasa Core

module, which is based on Hybrid

Code Networks (Williams et al., 2017), is the basis

for the dialog manager. Its task is to handle the current

dialog state. On a high level, the dialog manager con-

sists of a state tracker, a policy, and a set of actions.

http://legacy-docs-v1.rasa.com/nlu/about/

http://legacy-docs-v1.rasa.com/core/about/

The tracker stores the latest messages as a list of in-

tents and the current dialog state. The dialog state is

represented as a key-value store. Depending on their

type, values are converted to features to be used in the

prediction. The values can either be entities extracted

from user utterances, added by actions (e.g., the re-

sults of a routing request) or added externally (e.g.,

the user’s current or home location). Based on the

state of the tracker, the policy predicts the next action,

which should be executed. A set of sample dialogs

has to be provided to train the model of the policy.

These consist of a list of user dialog acts, i.e., the in-

tent and corresponding entities, the system’s actions,

and relevant dialog state updates. We generated sam-

ple dialogues directly from user utterances based on

the Wizard-of-Oz experiments transcripts and manu-

ally interacted with the system. This way, we gathered

user utterances on how they would interact with the

system and then added these utterances to our corpus.

4.3 Task Manager

The role of the task manager is to execute actions or

tasks triggered by the dialog manager. Incoming re-

quests from the Rasa Core module are processed and

handed to the corresponding action handler. Each ac-

tion handler performs the following steps: The ﬁrst

step is to parse entities and resolve references. This

parsing includes analyzing dates given in natural lan-

guage, resolving places to their geography, and re-

solving references to the dialog history. The dialog

state is validated, and a query to an external system is

built using these parsed entities. Next, the task man-

ager executes this query. The result is either a suc-

cessful query, a check back, or an error. Afterward,

the dialog state is updated accordingly. For parsing

and queries, the task manager may call external ser-

vices that provide the data integration.

4.4 Data Integration

The previously introduced task manager’s role is also

the data integration. Typically, all required informa-

tion should be provided by an actual MSP. As no sys-

tem with such interfaces exists to our best knowledge,

we mocked it using a set of external services provid-

ing the system’s functionality. The task manager may

either query external web services or query an internal

Postgres database for information retrieval.

The Postgres database with the spatial extension

PostGIS implements the point of interest and event

part of the data model introduced in Figure 1. For

event information, the system scraped the database of

a local magazine publishing local event information.

VEHITS 2021 - 7th International Conference on Vehicle Technology and Intelligent Transport Systems

710

For POI information, we queried the Overpass API

of the OSM project to store relevant POIs in the lo-

cal database. The geocoding of locations mentioned

by the user in a query was translated into coordinates

by the open-source geocoders Nominatim and Pho-

ton. Travel information is retrieved by querying an

external web service provided by the local transport

provider. Travel information is time-dependent and

may change over time. It is not stored in the database

but rather recalculated every time the user requests

travel information.

4.5 Natural Language Generation

The system uses a template-based approach for NLG.

Thereby, the system differentiates between predeﬁned

and generated responses. The former are simple tem-

plates that can include placeholders that the system

can ﬁll with slot values. Rasa Core handles them and

is either invoked directly by the dialog manager (as an

utter action) or triggered by the task manager. Exam-

ples for these are responses to small talk utterances or

check backs like “What is your destination?”.

Generated responses are more complex responses

(e.g., a list of objects or an itinerary description). It

takes as input the system dialog act and the current

context.

5 EVALUATION

Potential users evaluated the approach and the imple-

mented prototype to assess whether it matches our

requirements and the described scenario. The eval-

uation is still a work-in-progress and only provides

initial non-representative feedback for a cross-domain

NLI. We ﬁrst present our methodology and then intro-

duce the most relevant results.

5.1 Methodology

We evaluated the system with an online survey, struc-

tured into ﬁve distinct parts. The ﬁrst one inquired

about general demographic data from the participants.

In the second part, the survey inquired participants

about their previous experience with NLIs. It asked

them whether they are using NLIs and, if so, which

systems they use, in which domains, and in which ar-

eas they think, NLIs are useful. The third part pre-

sented participants with the concept of a dialog sys-

tem for an MSP, covering all phases of a trip, includ-

ing related domains. It asked the participants whether

they think that such a system would be useful and

whether they would use it. This approach allowed

"Musikbunker Aachen" in the street "Goffartstraße 39"

I have found the following locations in the "Frankenberger Viertel":

Is there a nightclub in the

Frankenberger Viertel?

Please enter a message...

Hello

Hello. How can I help you? I can answer questions related to public

transit, points of interest, or events in Aachen.

Figure 3: Translated screenshot of the chat interface of the

prototype application.

gathering feedback on the system’s actual goal with-

out inﬂuencing participants by letting them already

use the current prototype. In the fourth part, partic-

ipants should use the system via a chat interface. A

screenshot of the chat interface is shown in Figure 3.

First, the survey explained the functionality for

participants to get familiar with the system. The next

three pages of the survey asked participants to com-

plete the three different scenarios using the system

and the systems they usually use in these domains.

The following three scenarios were used:

1. Participants were asked to search for a nightclub

in a given neighborhood in Aachen. After ﬁnd-

ing a suitable one, they should search for events

at this place on the following weekend and ask for

an itinerary to get to one of these events on time.

2. Participants should plan an itinerary by bus from

one location to another for the following day.

3. Participants should plan a trip with their children

during the next week. Therefore, they should ﬁnd

events during the next week which are suitable for

children. After picking one of the events, they

should ﬁnd a suitable parking space nearby.

These scenarios and similar ones were also part of the

Wizard-of-Oz experiments to gather system require-

ments and utterances. As the scenarios are based in

the vicinity of the city of Aachen, the knowledge of

the participants of the area is also important.

For each scenario, users were asked with which

system it was easier to complete the task, faster to

complete the task, and which system they preferred

overall. Additionally, they were asked whether any

errors occurred while using the system.

The ﬁnal part of the survey asked participants

to evaluate the usability of the prototype. There-

fore, the framework for questionnaires by the In-

ternational Telecommunication Union presented in

Towards a Natural Language Dialog System for Mobility Service Platforms

711

oller, 2003) was used. M

oller mainly intended the

survey for spoken dialog systems used over the tele-

phone network. We translated the survey question-

naire into German and omitted questions speciﬁc to

the spoken interaction.

After the survey, we lastly asked the participants

for qualitative feedback on what they liked the most

and least on the system and whether they have any

proposals for change or improvement. No systems

with similar scope, i.e., NLI across the three differ-

ent domains and on a focus on Mobility Service Plat-

forms, exists to our knowledge, Therefore, we de-

cided not to compare the model directly to other ap-

proaches but to focus on the described user-centered

evaluation and compare the integrated NLI approach

to multiple GUI approaches. In future work, the pro-

totype will be compared to state-of-the-art solutions.

5.2 Results

The survey was conducted in the environment of the

university and thus the participants were not demo-

graphically representative. In total 25 participants

completed the survey (10 female, 14 male, and 1 non-

binary participants). Most participants were between

20 and 29 years old, but most other age groups were

represented. Most participants considered themselves

as rather tech-savvy. Two-thirds of the participants

(16 out of 25) stated that they have local knowledge

of the City of Aachen.

About half of the participants are actively using

NLIs, like Google Assistant, Apple Siri, and Amazon

Alexa. Though more than 80% of these participants

stated that they think that NLIs are useful in the do-

mains of travel information, POIs, and local events,

less than 30% are using NLIs in one of these do-

mains. For travel information, most participants are

currently using the apps of regional or national trans-

port providers. For POIs most participants are using

Google Maps, and for local events, participants men-

tioned Google Search, Social Media, and Print Adver-

tising most frequently. The concept of an NLI for an

MSP was rated positively. About half of the partici-

pants stated that they would use such a system, while

the other half was unsure.

After completing each scenario with the system

and the applications they usually use, they were asked

which of them were more comfortable to use, faster

to get a result and which one they preferred over-

all. Most users preferred and thought that the pro-

totype was more comfortable to use in all scenarios

and faster to use than the other application in the sec-

ond and third scenarios. Only in the ﬁrst scenario, a

majority stated that the other applications were faster

to use.

Participants were asked whether error or unex-

pected behavior occurred while using the prototype.

For the ﬁrst scenario, about half of the users afﬁrmed

this. For the other scenarios, about one-third of the

participants answered yes to this question. This high-

error rate could explain why most users could com-

plete the ﬁrst scenario faster using other applications.

Next, participants were asked to ﬁll out the usabil-

ity questionnaire (M

oller, 2003). Only half of the par-

ticipants stated that the system understood them per-

fectly or rater perfectly, which could be explained by

the sometimes limited performance of the NLU sys-

tem. 9 participants stated that the system sometimes

did not behave as they expected and that the system

made errors either frequently or frequently. Most par-

ticipants stated that the system reacted ﬂexibly, and

they were able to control the dialog as desired. 15

participants were satisﬁed or somewhat satisﬁed with

the system. In contrast, one participant was unsatis-

ﬁed, and four somewhat unsatisﬁed.

Finally, participants were asked for qualitative

feedback. The most stated positive points were that

the system allows for easy and quick access to infor-

mation, integrates different domains, and allows re-

ferring to previous utterances, either to correct a query

or when changing the domain. The negative feed-

back included that some utterances were not under-

stood correctly. Some participants disliked the tex-

tual representation of itineraries and would prefer a

more structured one. The system requires too much

typing. Consequently, one of the suggested improve-

ments was to allow speech as an input and output

modality. Participants suggested using additional vi-

sualizations like maps to display location or pictures

for events or POIs. Some participants asked for in-

struction on how to use the system. They were un-

sure which kind of queries the system is capable of

handling. The system partly caused this by mapping

unsupported utterances to one of the intents with rel-

atively high conﬁdence.

6 CONCLUSION

This paper presented our current progress towards

a natural language interface for a Mobility Service

Platform. MSPs give travelers more options on

how to reach their destination, ideally resulting in

cheaper, faster, more reliable, and more comfortable

itineraries. Globally this can result in better resource

usage, fewer trafﬁc congestions, and more sustain-

able mobility behavior. Accessing these platforms us-

ing NLIs can increase the ease of use and make them

VEHITS 2021 - 7th International Conference on Vehicle Technology and Intelligent Transport Systems

712

more accessible. An NLI may signiﬁcantly help peo-

ple not accustomed to using public or shared trans-

portation. With the NLI and the integration of fur-

ther information domains, we attempted to increase

the beneﬁt of the information systems, particularly for

infrequent users.

We proposed a data model integrating different

data resources in the individual domains. Further-

more, we designed an interaction model covering the

interaction in a limited subdomain. The prototype,

which is still a work-in-progress, was implemented

based on existing open source components and evalu-

ated by potential users. One of the challenges was to

acquire a sufﬁcient amount of training data that would

be required to improve the NLU component. Never-

theless, the system was rated already rather positively

by users in a preliminary test. Participants empha-

sized the seamless integration of related domains.

Besides improving the performance by using more

training data and more sophisticated models, the sys-

tem’s domain should be extended to cover more ser-

vices provided by MSPs. The interaction’s usabil-

ity can be improved by offering additional input and

output modalities, like speech or visualizations. Fi-

nally, we plan to perform a broader evaluation with

a larger group of people from different backgrounds,

thus making the evaluation representative.

ACKNOWLEDGEMENTS

This work has, in part, been funded by the Fed-

eral Ministry of Transport and Digital Infrastruc-

ture (BMVI) within the funding guideline ”Auto-

mated and Connected Driving” under the grant num-

ber 16AVF2134B.

REFERENCES

Bartie, P., Mackaness, W., Lemon, O., Dalmas, T., Ja-

narthanam, S., Hill, R. L., Dickinson, A., and Liu,

X. (2018). A Dialogue Based Mobile Virtual Assis-

tant for Tourists: The SpaceBook Project. Computers,

Environment and Urban Systems, 67:110–123.

Beutel, M. C., G

okay, S., Ohler, F., Kohl, W., Krempels,

K.-H., Rose, T., Samsel, C., Schwinger, F., and Ter-

welp, C. (2018). Mobility Service Platforms - Cross-

Company Cooperation for Transportation Service In-

teroperability. In Proceedings of the 20th Interna-

tional Conference on Enterprise Information Systems,

pages 151–161.

Bocklisch, T., Faulkner, J., Pawlowski, N., and Nichol, A.

(2017). Rasa: Open Source Language Understanding

and Dialogue Management. Technical report, Rasa.

Dahlb

ack, N., J

onsson, A., and Ahrenberg, L. (1993). Wiz-

ard of Oz studies—why and how. Knowledge-based

systems, 6(4):258–266.

Dodd, C., Athauda, R., and Adam, M. T. (2017). Designing

User Interfaces for the Elderly: A Systematic Litera-

ture Review. In Australasian Conference on Informa-

tion Systems, pages 1–11, Hobart, Australia.

Haas, C. and Riezler, S. (2016). A Corpus and Semantic

Parser for Multilingual Natural Language Querying of

OpenStreetMap. In Proceedings of the 2016 Confer-

ence of the North American Chapter of the Associa-

tion for Computational Linguistics: Human Language

Technologies, pages 740–750, Stroudsburg, PA, USA.

Association for Computational Linguistics.

Lafferty, J., Mccallum, A., and Pereira, F. (2001). Condi-

tional Random Fields: Probabilistic Models for Seg-

menting and Labeling Sequence Data. In Proceed-

ings of the 18th International Conference on Machine

Learning, pages 282–289.

Lawrence, C. and Riezler, S. (2016). NLmaps: A Natu-

ral Language Interface to Query OpenStreetMap. In

Proceedings of the International Conference on Com-

putational Linguistics (COLING), pages 6–10, Osaka,

Japan.

Lowdermilk, T. (2013). User-centered design: a devel-

oper’s guide to building user-friendly applications. ”

O’Reilly Media, Inc.”.

Malaka, R. and Zipf, A. (2000). DEEP MAP Challenging

IT research in the framework of a tourist information

system. In Information and communication technolo-

gies in tourism, pages 15—-27. Springer.

oller, S. (2003). Subjective Quality Evaluation of Tele-

phone Services Based on Spoken Dialogue Systems.

Technical report, International Telecommunication

Union.

Pennington, J., Socher, R., and Manning, C. (2014). GloVe:

Global Vectors for Word Representation. In Proceed-

ings of the 2014 Conference on Empirical Methods in

Natural Language Processing (EMNLP), pages 1532–

1543, Stroudsburg, PA, USA. Association for Compu-

tational Linguistics.

Pradhan, A., Mehta, K., and Findlater, L. (2018). Acces-

sibility Came by Accident: Use of Voice-Controlled

Intelligent Personal Assistants by People with Disabil-

ities. In Proceedings of the 2018 CHI Conference on

Human Factors in Computing Systems, page 459.

Schulz, T., B

ohm, M., Gewald, H., and Krcmar, H. (2020).

Smart mobility–an analysis of potential customers’

preference structures. Electronic Markets, pages 1–

20.

Williams, J. D., Asadi, K., and Zweig, G. (2017). Hybrid

Code Networks: practical and efﬁcient end-to-end di-

alog control with supervised and reinforcement learn-

ing. In Proceedings of the 55th Annual Meeting of

the Association for Computational Linguistics, pages

665—-677, Vancouver, Canada. Association for Com-

putational Linguistics.

Towards a Natural Language Dialog System for Mobility Service Platforms

713
