Class Clown: Data Redaction in

Machine Unlearning at Enterprise Scale*

Daniel L. Felps

, Amelia D. Schwickerath

, Joyce D. Williams

, Trung N. Vuong

Alan Briggs

, Matthew Hunt

, Evan Sakmar

, David D. Saranchak

and Tyler Shumaker

National Geospatial-Intelligence Agency, 7500 GEOINT Drive, Springfield, VA, U.S.A.

Concurrent Technologies Corporation, 100 CTC Drive, Johnstown, PA, U.S.A.

{briggsa, huntm, sakmarev, saranchd, shumaket}@ctc.com

Keywords: Machine Unlearning, Data Redaction, Membership Inference Attack, Data Poisoning Attack.

Abstract: Individuals are gaining more control of their personal data through recent data privacy laws such the General

Data Protection Regulation and the California Consumer Privacy Act. One aspect of these laws is the ability

to request a business to delete private information, the so called “right to be forgotten” or “right to erasure”.

These laws have serious financial implications for companies and organizations that train large, highly

accurate deep neural networks (DNNs) using these valuable consumer data sets. However, a received

redaction request poses complex technical challenges on how to comply with the law while fulfilling core

business operations. We introduce a DNN model lifecycle maintenance process that establishes how to handle

specific data redaction requests and minimize the need to completely retrain the model. Our process is based

upon the membership inference attack as a compliance tool for every point in the training set. These attack

models quantify the privacy risk of all training data points and form the basis of follow-on data redaction from

an accurate deployed model; excision is implemented through incorrect label assignment within incremental

model updates.

1 INTRODUCTION

The ability of deep neural network (DNN) machine

learning (ML) models to achieve human or above-

human task performance is the direct result of recent

advances in compute infrastructure capabilities and

the availability of vast amounts of data. The

collection of relevant and unique large data sets

remains vital to DNN training and has become a

differentiator in the marketplace. As organizations

dedicate expensive resources to data acquisition, the

data must be treated as sensitive proprietary

information. This is often expressed as “data is the

new oil” or “data is the new source code”.

Recent research has demonstrated several ML

privacy vulnerabilities where an adversary can

reverse engineer information about the sensitive

training data, particularly in computer vision

applications. In one of these attacks, the membership

inference attack (Shokri et al., 2017), it is possible for

*Approved for public release, NGA #21-141.

an adversary to predict whether a record was in the

model’s training set.

The strength of these attacks has been increasing

and it is now possible to efficiently generate point-

specific attacks against every point in a known

training data set (Felps et al., 2020). This has large

ramifications for ML privacy, security, and usability.

In addition, laws are emerging that provide people

more control over how organizations use their data in

technology such as machine learning models. This

has resulted in the possible need to retrain a model to

achieve the same accuracy, but without using certain

data points. However, doing so from scratch is not

guaranteed to converge and, even if it does, it could

require significant time and compute resources to do

so. As redaction requests begin to occur on a more

frequent basis when the laws come into effect, it is

infeasible to expect complete retraining alone to be a

viable solution.

Felps, D., Schwickerath, A., Williams, J., Vuong, T., Briggs, A., Hunt, M., Sakmar, E., Saranchak, D. and Shumaker, T.

Class Clown: Data Redaction in Machine Unlearning at Enterprise Scale.

DOI: 10.5220/0010419600070014

In Proceedings of the 10th International Conference on Operations Research and Enterprise Systems (ICORES 2021), pages 7-14

ISBN: 978-989-758-485-5

1.1 Machine Unlearning

The concept of making a ML system forget

information that it has learned about data without the

need for complete retraining is known as machine

unlearning (Cao and Yang, 2015). Cao designed a

model training framework that relied upon

intermediate features, of which each data sample was

only in a small number. When it was necessary to

remove data from the ML algorithm, only the related

features needed to be updated and the model updated

rather than completely retained.

While applicable to a wide range of scenarios,

their approach did not extend to more general and

complex models such as the non-linear models deep

neural networks that have dominated the field since

2015. Bourtoule (Bourtoule et al., 2019) addresses

deep neural networks with a machine unlearning

framework designed to have maximal impact upon

algorithms using the stochastic gradient descent

(SGD). By strategically sharding, isolating, slicing

and aggregating (SISA) training data, they can limit

each point’s overall influence and reduce the burden

of retraining in a similar way to Cao’s concept. Model

components are ensembled together to create an

overall model.

When redaction is required, only those ML

components trained with that specific data need to be

retrained. These components are smaller models that

require less time and resources to completely retrain.

Furthermore, they introduce a data partitioning

technique that incorporates a-priori knowledge on the

likelihood of reaction requests, allowing them to

decrease the number of ML models that are expected

to be retrained from scratch.

The perspective taken offers a guarantee that the

point is no longer in the ML training data set, which is

both easy to understand and useful. This ease of

understanding is true not only for those requesting the

redaction, but also to compliance officials that can

enforce newer regulations by imposing severe financial

penalties. The solution is useful in cases where the

technique is designed and applied at train time.

More recently, Baumhauer (Baumhauer et al.,

2020) has considered the setting where an entire class

needs to be removed from the model, for instance in

biometric applications where the entire class

represents an individual.

In this research, we present a solution that could

be combined with SISA, but removes the need to

retrain models from scratch, possibly because the

original data set does not exist in its original form.

This technique follows an unlearning mechanism

whereby

a trained model is iteratively updated to

another model that, conceptually, behaves as if the

sensitive data point was not used but maintains task

performance. Updates are performed without the need

to use the original training data set. See Figure 1.

Figure 1: DNN Machine Unlearning.

Our new redaction technique, which we call Class

Clown, leverages two common machine learning

attacks in the model updates, the membership

inference and poisoning attacks. See Figure 2 for an

overall process depiction.

Figure 2: The Class Clown Redaction Process.

In their Bootstrap Aggregating Generalized

Membership Inference Attack paper (Felps et al.,

2020), they show that the vulnerable points of a

model can vary greatly between different training

instances. Thus, finding and removing vulnerable

points, say the top 10%, and then retraining will not

eliminate new points from being vulnerable in the

retrained model. In the same paper, they also offer an

efficient mechanism for understanding which points

are most vulnerable for a deployed target model. The

Class Clown redaction process described here offers

a mechanism to reduce the vulnerability of these

points through a redaction process that does not rely

on removing sensitive points and retraining

completely.

1.2 Membership Inference Attack as a

Compliance Tool

With the need to comply to local and international

regulations, but without the ability to viably perform

ICORES 2021 - 10th International Conference on Operations Research and Enterprise Systems

model retraining without specific data points, several

ideas have emerged on how to legally demonstrate

that the information has been removed from the DNN.

The strongest guarantees come from the

mathematical field of differential privacy (DP). These

techniques apply and track noise during the training

process. This noise both restricts the amount of

information the model learns from any single point

while also acting as a regularization optimization

term, allowing it to generalize better to new data. This

DP process is applied to every training point and the

model can often suffer significant loss in

performance, making it no longer useful.

Lui (Lui and Tsaftaris, 2020) introduces the

concept of applying statistical distributional tests

after model training to determine if a model has

forgotten information related to a set of points. It

hinges on having enough new data to train another

model to a similar task accuracy, from which

similarity measures between output distributions can

be utilized. Such a test would be used by an

independent auditor to assess compliance. While

effective, it more directly assesses whether data has

not been used in model training.

Chen (Chen et al., 2020) introduces explicitly

leveraging the MI attack to directly measure how

much privacy information has been degraded. Chen

also introduces two privacy metrics that measure the

difference of the membership inference confidence

levels of a target point between two models.

We agree with this approach; however, they again

use model retaining and shadow models to compute

this statistic. In our work, we advance their approach

in a key way that will support operational

deployments of large, distributed DNNs. Our

approach leverages incremental retraining of a target

model. It does not rely on full retraining of either the

deployed model or a new model for statistical

comparisons. With this redaction technique, data

owners can evolve a model and alter a point’s attack

confidence to a desired level within a ranked listed of

possible training points. It is also possible to make it

appear with high confidence that the point was not

used to train the deployed model, when evaluated

against many other membership inference attack

models.

Note that we don’t use the MI attack models other

than as a compliance mechanism. That is, we don’t

use loss or other information of the attack models

during our re-training optimization. The advantage of

this is that it makes the redactions less dependent

upon the specific attack model and resilient to other

types of attacks.

Also, we only train evaluation attack models to

determine the effectiveness of the Class Clown

technique. Our results show that reducing attack

confidence in one attack model reduces confidence in

all attack models. However, such a step is not

necessary within operational spaces.

2 CLASS CLOWN: SURGICAL

DATA EXCISION THROUGH

LABEL POISONING DURING

INCREMENTAL RETRAINING

It is an open question as to how exactly deep neural

networks are storing and leaking privacy information

on specific data points. However, all of the attacks

rely upon observing shifts in the output based upon

known the shifts in the input. For the vast majority of

attacks, this means exploiting shifts in the output

confidence vectors. The easiest attack is the case

where there is no overlap between training data

output and new data output, for instance, a highly

overfit model, as these can be readily differentiated.

Even Shokri’s original paper indicated that

restricting the model output to the label is not enough

to prevent this attack. Mislabelled predictions and the

differences of these misclassifications can be

exploited as well. This is highlighted in a recent label-

only attack (Choquette Choo et al., 2020).

These shifts in output are the result of many

aggregated computations across the network’s layers

that ultimately define the class decision boundary in

the embedded loss space. However, in the vicinity of

a point, there is a relationship between model

confidence and the distance to its decision boundary.

We leverage this and seek to alter the embedded

loss space of the target model only in the vicinity of

the points that we need to redact. By altering the

point’s local decision boundary, we can shift the

target model confidence outputs, thereby tricking any

membership inference attack model into believing

that the point was not used in training. We use a

mechanism that does so gently without largely

affecting the accuracy or network weights.

We achieve this in an incremental manner starting

from the existing deployed (target) model. For

simplicity, we hone the technique in the context of a

single point, and then extend to multiple redaction

points via an arrival queue representing irregular data

redaction requests.

2.1 Class Label Poisoning

In our approach, we intentionally poison the label of

the point to be redacted in ensuing retraining epochs.

In our experiments, we randomly chose the label to

poison with once, and then use that in every epoch.

Intuitively, this mislabelling decreases the

Class Clown: Data Redaction in Machine Unlearning at Enterprise Scale

model’s belief in the correct class during new training

epochs. This impacts the epsilon-ball neighbourhood

of the redacted point near the decision boundary by

altering it from the correct class to an incorrect pre-

existing class.

This infinitesimal change in the embedded space

alters the output confidences for the redaction data

point in ways that are unexpected for attack models.

These changes will result in an output vector

distribution that is different than those used to train

the membership inference attack models. However,

they will not be so different as to produce an incorrect

or low confidence model prediction.

Model updates occur similarly to how the original

model was trained, namely via the SGD algorithm in

epochs with minibatches. Here, the influence of the

poisoned gradient must be balanced with a small

number of true data from the class. If the poisoned

gradient is too large, the global decision boundary

may be altered too greatly, with ensuing significant

impacts upon model accuracy. Likewise, if too many

true points are used, the influence of the poisoned

point will not contribute to the overall gradient,

resulting in minimal changes to the local loss space.

Our process uses only data from the true class of the

redaction point.

Figure 3: Label Poisoning of the Redaction Point.

In our experiments, we first identify the correct

ratio of true-to-poisoned data in the batch. For each

class, we employ a small number of redaction points

and demonstrate that this configuration can be applied

to arbitrary redaction points.

After establishing the correct single point

configuration, we extend this to the sequential

redaction of multiple points from any class by

simulating a queue of redaction requests.

2.2 Post Redaction Accuracy Recovery

If, after a successful redaction, we observe that the

task accuracy has fallen below operational

requirements, we may choose to perform a small

amount of training epochs with either new or original

training data. For the case of sequential redaction of

multiple points, this step becomes necessary after a

number of redactions. In either event, care is taken to

ensure that redacted points remain redacted after new

valid training epochs.

3 EXPERIMENTAL

CONFIGURATION

3.1 Dataset

In this research, we focus on the CIFAR10 dataset

(Krizhevsky, 2009). This set is comprised of 50,000

training points across 10 classes. The baseline

scenario for practitioners evaluating MI attacks and

defences assumes that the model attacker knows

which data set was used for training and that only half

of the data set was used in the training. The task of

the attacker is to identify which half was used.

As such, all models are trained with 50% of the

data to support evaluations of the membership

inference attack before and after redaction. Data is

sampled with replacement from the original

CIFAR10 training set.

3.2 Model Architectures and

Configurations

For all trained models, use a convolutional neutral

network with an architecture that has 0.27M trainable

parameters and consists of two sequential blocks of

[CONV2 -> RELU -> BN -> CONV2 -> RELU ->

BN -> maxPool], followed by a dense layer with

ReLu activation and a Softmax layer.

Training is performed using a batch size of 128,

Adam optimizer, and for 25 epochs without data

augmentation. This achieves a baseline task accuracy

of 65.2%

From the training data set of the Target model, we

randomly sample a large number of data points

equally amongst the 10 classes. With this

configuration and data set, we train and attack three

different model types. The first is a “Target Model”

trained with all of the selected training data. The

second is a model trained with all of the selected data,

but with a single point removed; the “Remove

Model”. The last is the model obtained via Class

Clown redaction from the Target Model. New

Remove and Redact models are generated for every

data point to be redacted. Refer to Figure 4 below for

a depiction.

ICORES 2021 - 10th International Conference on Operations Research and Enterprise Systems

Figure 4: The "Remove", "Target", and "Redact" Models.

3.3 MI Attack Model for Redaction

In the Class Clown process, an attack model is used

to determine the confidence of the prediction for that

redaction data point. This MI attack is conducted

using an independently trained model using class-

based approaches similar to Shroki. Here, the entire

data set is split into two, one for training of a target

model and another for the training of a single shadow

model. These form the basis of the “In/Out” training

of an attack model. We choose a logistic regression

attack model.

After each retraining epoch, the MI attack is

conducted against the redaction point and the MI

confidence observed and compared to the original MI

attack confidence(s). Retraining ceases if the attack

confidence decreases below zero for the redaction

point. The model obtained is called the Redact Model.

3.4 Redaction Evaluation

For redaction evaluation purposes, we also construct

100 new attack models, trained in a way that matches

the redaction attack model above. The associated

training datasets are generated by randomly splitting

the 50,000 records into two datasets of the same size,

each serving as a training set for a target model and

an associated shadow model. We repeat this process

for 50 times and train a total of 100 target models.

From these models, 100 attack models are

subsequently constructed.

These 100 attack models are used against the

Target Model, and the Remove and Redact Models

associated with each of the randomly selected

redaction points. The output MI confidence is

recorded for each of the 100 attacks or each of the

selected points. For the Target Model, we expect that

the majority of attack models will correctly detect the

point as “In” the training data set. For the Remove and

Redact Models, we expect that the majority of attack

models will correctly detect the point as “Out” the

training data set. Furthermore, we compare the

distribution of confidences amongst these model

outputs to compare redaction strategies. For redaction

compliance, all attack models should predict “Out”

for the selected redaction points.

4 RESULTS AND ANALYSIS

4.1 Optimal Class Clown Redaction

Batch Size

We train the baseline CNN using a random half of the

data for 25 epochs, achieving an accuracy of 65.2%.

We then randomly selected 20 training points from

each class that were both in the target model’s

training set and have a positive MI confidence of

inclusion. In total, this gives us 200 points with which

to perform Class Clown redaction.

For each of these points, we perform retraining

epochs from the initial checkpointed trained target

model. The poisoned point and several true data

points for the same class are used to form a batch. No

other points are used in these retraining epochs.

We investigated several different batch sizes

across the trials. Retraining was stopped either once

the MI confidence fell below zero or a maximum

number of epochs was achieved. In these

experiments, the maximum retrain permitted was 25

epochs to match the number used in training. Upon

conclusion of redaction epochs, the accuracy of the

redacted model was recorded, along with the number

of retraining epochs and the MI attack confidence. A

Table 1: Optimal Single Point Redaction Batch Size.

True points in batch 0 1 5 10 15 25 50 75 100

Average redact MI

confidence

0.568 -1.589 -1.62 -1.82 -1.66 -1.53 -1.20 -1.141 -0.896

Average redact

accuracy

0.652 0.662 0.662 0.661 0.66 0.658 0.649 0.637 0.628

Average epoch of MI

change

N/A

(25.0)

2.17 1.84 1.784 1.84 1.97 2.7 3.88 4.87

Class Clown: Data Redaction in Machine Unlearning at Enterprise Scale

mean average across all classes was computed for of

each of these metrics.

Table 1 lists the results from trials using several

different batch sizes for a single point redaction. From

this, we observe that the use of 10 additional points in

the batch produces the most successful redaction (the

largest negative confidence) while preserving task

accuracy and completing in the shortest number of

epochs. In follow-on experiments, we set the number

of true extra points in the redaction epochs to 10.

4.2 Class Clown Redaction Efficacy

To validate the efficacy of the Class Clown redaction

technique, we performed an experiment to determine

how many points could be successfully redacted.

From a target model’s training data set, we selected

the top 100 most vulnerable points for each class

when attacked with the single MI attack model. We

trained a Remove Model by removing these 1,000

points and retraining. We also trained 1,000 Redact

Models from the Target model by employing Class

Clown Redaction with each of the 1,000 selected data

points.

Figure 5: Redaction Evaluation Boxplots.

The 100 membership inference attack evaluation

models were used to attack each of the 1,000 data

points. MI attack results were observed for each of the

Target, Remove and Redact models. Results are

plotted in Figure 5.

For the Target Model, we observed that all 100

attack models could detect the correct membership

status of 993 points. The other 7 points are outliers in

this boxplot, but only 3 of these points are incorrectly

detected as “Out” by a majority of the attack models.

For the Remove Model, we observed that all 100

attack models could detect the correct membership

status of 989 points. The other 11 points are outliers

in this boxplot, but only 6 of these points are

incorrectly detected as “In” by a majority vote of the

attack models.

For the Redact Models, we observed that every

redact point was detected as “Out” but attack model.

There were no outliers.

Based upon these results, we determine that the

Class Clown redaction technique effectively removes

the ability to detect the membership of a redacted

point.

4.3 Class Clown Redaction Time

In consideration of whether to perform Class Clown

redaction or to create a Remove model, we perform

an experiment to investigate the timing behaviour of

both options. We selected a random 200 points

equally across the classes. For each point, we train a

new Remove Model for 25 epochs and observe how

long it takes to train. We also perform Class Clown

redaction and observe how long it takes to

successfully redact using a single independent attack

model. Across all 200 models, we compute the

average train time. The results of these trails are in

Table 2.

Table 2: Remove and Class Clown Training Time.

Technique Average Train Time (s)

Remove 116.32

Class Clown 13.52

The results in Table 2 indicate that Class Clown

redaction is roughly 10 times faster than removing the

data point and retraining. For models trained on more

data or for more training epochs, the relative speed

improvement from Class Clown redaction would be

even greater, as retraining would take longer, but

Class Clown redaction would not be affected.

4.4 Sequential Class Clown Redaction

In enterprise operations, redaction requests will arrive

in an unordered fashion across the classes and with

interarrival times that depend upon application

specifics. One option is to batch these requests and

retrain from scratch after an acceptable amount have

been received, see Figure 6. The SISA approach takes

this perspective and may be advantageous if the

number of redactions requests is so voluminous that

it is faster to retrain from scratch.

However, depending upon the frequency of

redaction requests and the compliance mandated time

to fulfil them, our Class Clown technique may be a

viable option.

ICORES 2021 - 10th International Conference on Operations Research and Enterprise Systems

Figure 6: Batch Removal.

To investigate this scenario, we randomly select

20 training points from training data set for redaction.

We sequentially process each with Class Clown and

track the task accuracy. After all redactions, we

confirm that the attack model predicts all 20 as “Out”.

The results are depicted in Figure 7.

Figure 7: Sequential Class Clown Accuracy.

We observe an overall task accuracy decreased

from 75% to 67%, but that each individual successful

redaction can either decrease or increase task

accuracy.

The acceptable accuracy threshold for

deployment is application specific, and we

recommend performing a small amount of recovery

retraining with new data when Class Clown redaction

falls below it, as described in Section 2.2. Such

incremental online retaining is common practice

already, and this would complement such a strategy

to maintaining model performance.

5 FUTURE RESEARCH

The design of the Class Clown redaction technique is

only the begging of a compliance effort and there are

several research avenues to advance the technique

and operational scenarios against which to fine-tune

it. In this work, we chose the poisoning class

randomly. However, there may be a better strategy in

selecting this class to optimize across the various

metrics (fewest Class Clown epochs or quickest time,

smallest impact on accuracy, etc.)

We also redacted a single point at a time.

However, it is possible to simultaneously redact

multiple points from the same class at a time, but we

did not fully investigate this mechanism.

Alternatively, with multiple sequential single point

redaction, is there an optimal ordering or strategy to

redacting these points? Additionally, it may be

possible to redact multiple points from difference

classes.

Lastly, we focused on the CIFAR10 data set and

CNN architectures. Extending beyond these would

determine the general applicability of the technique.

6 CONCLUSIONS

In this research, we have presented a new data

redaction mechanism via machine unlearning through

the innovative application of the membership

inference and label poisoning attacks. Our process is

based upon the membership inference attack as a

compliance tool for every point in the training set.

Redaction is implemented through incorrect label

assignment within incremental model updates with

the aid of a membership inference attack model.

Through experiments, we verified that our

technique was successful for any and every point

attempted. Successful redaction occurs, on average,

within 5 or less retraining epochs, with minimal

impact to the task accuracy, i.e. a decrease of 5% or

less.

We observed in our experiments that this process

could be performed sequentially and for any data

point in the training data set. Based upon this

observation, we designed a DNN model lifecycle

maintenance process that establishes how to handle

data redaction requests and minimize the need to

completely retraining the model.

We propose, based upon the observed behaviours

of our new process, that it can be used to demonstrate

compliance with emerging data privacy regulations

while still allowing performance metrics to be

fulfilled in operational spaces.

REFERENCES

Baumhauer, T.; Schöttle, P.; Zeppelzauer M. 2020.

Machine Unlearning: Linear Filtration for Logit-based

Classifiers. arXiv preprint. arXiv: 2002.02730v1

[cs.LG]. Ithaca, NY: Cornell University Library.

Bourtoule, L.; Chandrasekaran, V.; Choquette-Choo, C.A.;

Jia, H.; Travers, A.; Zhang, B.; Lie, D.; and Papernot,

N. 2019. Machine Unlearning. arXiv preprint. arXiv:

1912.03817 [cs.CR]. Ithaca, NY: Cornell University

Library.

Class Clown: Data Redaction in Machine Unlearning at Enterprise Scale

Chen, M.; Zhang, Z.; Wang, T.; Backes, M.; Humbert, M.;

Zhang, Y. 2020. When Machine Unlearning

Jeopardizes Privacy. arXiv preprint. arXiv: 2005.02205

[cs.CR]. Ithaca, NY: Cornell University Library.

Choquette Choo, C.A.; Tramer, F.; Carlini, N.; Papernot, N.

2020. Label-Only Membership Inference Attacks. arxiv

pre-print. arXiv: 2007.14321v1 [cs.CR] Ithaca, NY:

Cornell University Library.

Felps, D.; Schwickerath, A. Williams, J.; Vuong, T.;

Briggs, A.; Hunt, Matt; Sakmar, E.; Saranchak, D.; and

Shumaker, T. 2020. Bootstrap Aggregation for Point-

based Generalized Membership Inference Attacks.

arxiv pre-print. arXiv: 2011.08738 [cs.CR]. Ithaca, NY:

Cornell University Library.

Krizhevsky, A. 2009. Learning Multiple Layers of Features

from Tiny Images. Master’s Thesis, University of

Toronto.

Liu, X.; and Tsaftaris, S. 2020. Have you forgotten? A

method to assess if machine learning models have

forgotten data. arxiv pre-print. arXiv: 2004.10129

[cs.CV]. Ithaca, NY: Cornell University Library.

Shokri, R.; Stronati, M.; Song, C.; and Shmatikov, V. 2017.

Membership inference attacks against machine learning

models. IEEE Symposium on Security and Privacy, 3-18.

ICORES 2021 - 10th International Conference on Operations Research and Enterprise Systems
