Twin-GAN for Neural Machine Translation

Jiaxu Zhao

, Li Huang

, Ruixuan Sun

, Liao Bing

and Hong Qu

University of Electronic Science and Technology of China, Chengdu 610054, China

Yelp Inc., U.S.A.

Chengdu Dajiangtong Technology Co., Ltd, China

Keywords:

Neural Machine Translation, Exposure Bias, GAN.

Abstract:

In recent years, Neural Machine Translation (NMT) has achieved great success, but we can not ignore two

important problems. One is the exposure bias caused by the different strategies between training and infer-

ence, and the other is that the NMT model generates the best candidate word for the current step yet a bad

element of the whole sentence. The popular methods to solve these two problems are Schedule Sampling and

Generative Adversarial Networks (GANs) respectively, and both achieved some success. In this paper, we

proposed a more precise approach called “similarity selection” combining a new GAN structure called twin-

GAN to solve the above two problems. There are two generators and two discriminators in the twin-GAN.

One generator uses the “similarity selection” and the other one uses the same way as inference (simulate the

inference process). One discriminator guides generators at the sentence level, and the other discriminator

forces these two generators to have similar distributions. Moreover, we performed a lot of experiments on the

IWSLT 2014 German→English (De→En) and the WMT’17 Chinese→English (Zh→En) and the result shows

that we improved the performance compared to some other strong baseline models which based on recurrent

architecture.

1 INTRODUCTION

Thanks to recent advances in deep learning, many ap-

proaches have emerged to implement Neural Machine

Translation (NMT). Because the translation task is

a sequential problem, most of those approaches are

based on Seq2Seq models (Kalchbrenner and Blun-

som, 2013) (Sutskever et al., 2014) (Cho et al., 2014).

The Seq2Seq models generally consist of two sub

neural networks called encoder and decoder. The en-

coder is to extract a representation of the input source

sequence; the decoder is to transfer the representation

to the target sequence. Generally, the decoder’s in-

put is a target-side sequence during training (teacher

forcing mode) and the input is generated by itself dur-

ing the inference phase (recurrent mode). This strat-

egy brings a discrepancy called exposure bias (Ran-

zato et al., 2015) causing a gap between the training

and the inference. That is, the words accepted by the

decoder in training is the ground-truth sentence, but

in testing, it accepts the output of its previous unit

as the input of this unit. The inconsistency between

these two settings will lead to error accumulation at

test time. Schedule Sampling (Bengio et al., 2015) is

one of the most common solutions to this problem.

This method is only used in the training and it works

like this: in the early stages of training, the method

mainly uses the target-side sequence as the decoder’s

input, which can quickly guide the model from a ran-

domly initialized state to a reasonable state. As the

training progresses, the method will gradually use the

generated words as the decoder’s input. The proba-

bility of using the generated word as input in Sched-

ule Sampling changes with the training time, which is

reasonable. But we think that the probability should

change with the performance of the model, that is, the

better the model performs, the higher the probability

should be. In this paper, we use the similarity of gen-

erated words and labels to indicate the performance

of the model, which we call “similarity selection”.

Like Schedule Sampling, it still does not completely

solve the problem of inconsistent data distribution

during training and generation (Husz

ar, 2015). In-

spired by (Lamb et al., 2016), we introduced Genera-

tive Adversarial Networks (GANs)(Goodfellow et al.,

2014) (Goodfellow, 2016) in combination with “sim-

ilarity selection” to solve the problem. GAN is a deep

learning model and one of the most popular meth-

ods for unsupervised learning on complex distribu-

tions in recent years. It consists of two modules (Gen-

Zhao, J., Huang, L., Sun, R., Bing, L. and Qu, H.

Twin-GAN for Neural Machine Translation.

DOI: 10.5220/0010217300870096

In Proceedings of the 13th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2021) - Volume 2, pages 87-96

ISBN: 978-989-758-484-8

erative Network and Discriminative Network) and it

produces fairly good output through the mutual game

learning of the two modules. Since GAN has achieved

remarkable success in image generation since it was

proposed, some works (Lamb et al., 2016) (Zhang

et al., 2016) introduced GAN to NLP. In this paper,

we design two generators, one using “similarity selec-

tion” to generate sequences, the other using recurrent

mode to generate sequences. And we use a discrimi-

nator to make the latter generator close to the forward

one to solve the problem of inconsistent data distribu-

tion.

Most of the NMT models are learned only under

the guidance of the ground-truth translations. Models

are generally optimized by maximizing the likelihood

estimation of the target-side sequence at each step at

training time. This optimization strategy just guar-

antees that the model can generate the best word at

every single step but ignore the coherence and natu-

ralness of the whole sentence. To address this issue,

there are some works (Shen et al., 2015) (Bahdanau

et al., 2016) trying to optimize the model in sentence

level not just in word level. Those works aim to avoid

the limitation of maximum likelihood estimation by

directly optimizing the evaluation (BLEU) (Papineni

et al., 2002) and the results show that they have im-

proved the quality of translation a little. Some re-

searchers also use the idea of GAN to solve the prob-

lem: the discriminator learns to distinguish whether

a given sentence is a ground-truth sentence or not,

which can be regarded as a guide of the generator

in sentence level. The generator can be the ordinary

neural machine translation networks, which learns

by generating sentences more similar to ground-truth

translations. However, applying the traditional GANs

directly to sequence generation like neural machine

translation is not appropriate. Traditional GANs gen-

erating an image is a real-valued data mapping trans-

formation, which is a continuous process. There-

fore, the discriminator’s gradient can be propagated

back to the generator. But for NMT, in the process

of decoding and generating text, the model genera-

tion is actually the process of selecting words in the

vocabulary, which is a discrete and non-differential

process (Husz

ar, 2015). Therefore, the gradient of

the discriminator can not be propagated back to the

generator, and the parameters of generator can not

be updated (Goodfellow, 2016). To address the is-

sue and guarantee those two sub-modules in GANs

are effectively optimized when the data is discrete,

(Kusner and Hern

andez-Lobato, 2016) proposed the

Gumbel-softmax distribution, which is a continuous

approximation to a polynomial distribution based on

the so f tmax function. Inspired by (Yang et al., 2017)

(Wu et al., 2017), in this work, we use the idea of

the policy gradient method (Williams, 1992), widely

used in reinforcement learning (Sutton et al., 1998),

to make the gradient of the discriminator can be prop-

agated back to the generator. Therefore, we pro-

pose another discriminator that identiﬁes the coher-

ence and naturalness of the generated sentences and

feeds the value back to the generator using the recur-

rent mode through the policy gradient.

Our work provides the following contributions:

• We propose a novel generative adversarial net-

work model for NMT. As our best knowledge, this

is the ﬁrst work that leverages two generators and

two discriminators in GAN. One generator gener-

ates sentences with “similarity selection” and the

other generates with ordinary recurrent mode as

in the test. One discriminator closes the distance

between the two generators, the other guides the

generator to generate more natural and ﬂuent sen-

tences in sentence level.

• We design a more precise method named “similar-

ity selection” as opposed to the “Scheduled Sam-

pling”. We believe that selecting a word as input

should depend on the quality of the generated data

rather than the training time.

• We carried out extensive experiments on

German→English and Chinese→English trans-

lation tasks. We compared some strong basic

recurrent structure models with twin-GAN and

the result of the twin-GAN signiﬁcantly outper-

forms the RNNsearch (Bahdanau et al., 2015)

by +4.20 BLEU points on IWSLT 2014 De-En

data set. Comparing with the related model, our

model further achieved a signiﬁcant improvement

by about +1.09 BLEU points.

2 RELATED WORK

2.1 Neural Machine Translation

Neural Machine Translation (NMT) is a Machine

Translation method that applies neural networks to

predict the likelihood of a sequence of words. Since

Sequence to Sequence (Seq2Seq) architecture (Kalch-

brenner and Blunsom, 2013) (Sutskever et al., 2014)

(Cho et al., 2014) was proposed, the most popular

structures of NMT are based on it, such as (Wu et al.,

2016) (Tan et al., 2019) (Artetxe et al., 2017) (Lam-

ple et al., 2017) (Lample et al., 2018) (He et al.,

2018) (Song et al., 2018). The architecture of the

Seq2Seq comprises of two processes, the encoder

process and decoder process. And these two parts are

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

very ﬂexible. Researchers started with RNN in these

two processes and later gradually introduced Long

Short-Term Memory (LSTM) units (Hochreiter and

Schmidhuber, 1997) and Gate Recurrent Unit (GRU)

(Cho et al., 2014) to in place of RNN units. Con-

volutional Neural Network (CNN) is the most com-

monly used neural network for analyzing visual im-

ages. As witnessed the great success of CNN in com-

puter vision, some researchers introduced it to NLP.

And some works (Lamb and Xie, 2016) (Kalchbren-

ner et al., 2016)(Gehring et al., 2017) used CNN for

machine translation with success. The two processes

in Seq2Seq are relatively independent and not closely

related. To this end, (Luong et al., 2015) proposed

the attention mechanism, which greatly improved the

performance of Seq2Seq through making these two

parts more closely. (Vaswani et al., 2017) proposed

a fully-connected attention-based model called trans-

former, which discards the CNN and RNN. And trans-

former became popular in natural language process-

ing applications, notably machine translation and lan-

guage modeling. Since the Generative Adversarial

Networks (GAN) (Goodfellow et al., 2014) was pro-

posed, it was widely used in unsupervised learning in

the ﬁeld of computer vision and had a good perfor-

mance. Therefore, some researchers (Yu et al., 2017)

(Lamb et al., 2016) (Goodfellow, 2016) (Zhang et al.,

2016) introduced GAN into NLP. For NMT, (Yang

et al., 2017) and (Wu et al., 2017) achieved competi-

tive performance through GAN.

2.2 Exposure Bias

As described above, the Seq2Seq model (Sutskever

et al., 2014) has been popular in Neural Machine

Translation recently. The decoder of Seq2Seq re-

quires the target sequence as it’s input at training time,

but the output of the previous time step is used to in-

stead at test time. The difference between training

and inference causes the exposure bias (Ranzato et al.,

2015). (Venkatraman et al., 2015) proposed a method

to alleviate the impact of errors in the current time

step on posterior steps by reusing the training data

which serves as a “demonstrator” by providing cor-

rections for the errors. Based on this method, (Ben-

gio et al., 2015) proposed another one called “Sched-

ule Sampling”. That is, the input used in the train-

ing phase uses the ground-truth with a probability of

p, and uses the output of the previous word with a

probability of 1-p. And this probability p increases

as training progress. And (Zhang et al., 2019) has a

more precise formula to get the probability p. Unlike

those works that use a simple function to calculate a

probability, we use the similarity of label and output

to guide the probability p.

Another direction of trying to solve exposure bias

is to borrow the idea of GANs, like (Lamb et al.,

2016), (Yang et al., 2017) and (Wu et al., 2017). How-

ever, they still use “teacher forcing” mode (Williams

and Zipser, 1989) in the generator at training time.

Unlike them, we use the “similarity selection” to re-

place the “teacher forcing” mode. Furthermore, We

also have another generator, which generates sen-

tences in the same way as in the test. And we use

a discriminator to force the distribution of the latter

generator to be close to the previous one. In the ﬁ-

nal test, we only use the latter generator, whose data

distribution is the same for testing and training.

2.3 Sentence Level Strategy

To make the generated sequence closest to the

ground-truth sequence, maximizing the likelihood es-

timation (MLE) of the ground-truth sequence at each

time step is the most commonly used optimization

method. This method optimizes model in word level

because that MLE forces model to generate a word

that corresponded to the target word at the current

step. In this work, we use a discriminator that is simi-

lar to (Yang et al., 2017) and (Wu et al., 2017), which

optimizes generator in sentence level by discriminat-

ing the sentence is generated by machine or written

by humans. Therefore, in order to “cheat” the dis-

criminator, the generator will generate more natural

and coherent sentences like those written by humans.

But there is a limitation when generating sequences

of discrete tokens because it’s difﬁcult to pass the gra-

dient update from the discriminator to the generator.

Same as (Yu et al., 2017), we borrowed a idea of re-

inforcement learning called policy gradient to make it

differentiable in this discrete process. We use the re-

sult of the discriminator as a reward and feed it back

to the generator.

The remainder of this paper is organized as fol-

lows. Section 3 provides the background of Neural

Machine Translation, including its commonly used

architecture and the application of GAN in NMT. Our

proposed twin-GAN is introduced in Section 4. We

discuss our experiments in Section 5, including data

sets, speciﬁc model settings and results analysis. Sec-

tion 6 concludes the paper.

Twin-GAN for Neural Machine Translation

3 BACKGROUND

3.1 Encoder-Decoder with Attention

The translation task is to transfer one sequence into

another sequence. In Neural Machine Translation,

Encoder-Decoder is the most popular and empirically

effective structure. Encoder and decoder can be any

model like RNN based and CNN based. Assume the

source sequence and target sequence are X = {x

... ,x

} and Y = {y

, ... ,y

} respectively. Note the

E = {e

, ... ,e

} is employed to represent the em-

bedding matrix of the source sentence X. When y

,i∈

1,2...,m is generated, the model assigns attention to

different words in source sequence for the i-th decode

step. According to different attention, E is encoded as

intermediate context representation c

,i∈ 1,2...,m that

varies based on the current word generated. And then

input the combination of context vector c

and pre-

vious output into the decoder. Finally, the decoder

outputs y

,i∈ 1,2...,m.

3.2 Generative Adversarial Network in

NMT

(Goodfellow et al., 2014) proposed Generative Ad-

versarial Networks (GANs) and it got great success

in computer vision. The GANs is a new framework

that optimizes the generative model through the ad-

versarial process. The idea of GANs is a two-player

game that is played between a generative model and

a discriminative model. The training strategies of its

two sub-models are as follows: the training process

of the generator G is to maximize the probability of

the discriminator making mistakes, that is, the dis-

criminator mistakenly believes that the data are real

samples rather than the fake samples generated by the

generator. The training process of the discriminator

D is to maximize the probability of making a correct

judgment on the input data. Generally, the discrimi-

nator is a classiﬁcation model or scoring model like

multilayer perceptron (MLP). GANs are ﬁrst applied

to generate realistic pictures with random noise. It

works well in generating images since the image is

continuous data, and small changes can be reﬂected

on the pixels. But if the generated data is based on

discrete tokens, the information given by D is often

meaningless. Small changes to tokens are invalid due

to there may not be corresponding tokens in the vo-

cabulary space.

In neural machine translation, sentences are com-

posed of a series of discrete tokens. Because the gen-

erator G needs to be trained using the gradient ob-

tained from the discriminator D, and both G and D

need to be completely differentiable. Problems arise

when there are discrete variables, where Back Prop-

agation (BP) (Rumelhart et al., 1986) cannot pro-

vide the training gradient form D for G. There are

two main approaches to solve this problem, Gumbel-

softmax (Kusner and Hern

andez-Lobato, 2016) and

policy gradient (PG) method (Williams, 1992). In

this paper, we use the latter which is a common op-

timization method in reinforcement learning. Differ-

ent from original back-propagation, PG does not back

propagate by error but directly carries out back prop-

agation by selecting a behavior through observation

information. It does not have errors, but uses rewards

to directly enhance and diminish the likelihood of a

chosen action, Therefore, good actions increase the

probability of being selected next time, while bad ac-

tions decrease the probability of being selected next

time.

(Wu et al., 2017) is a recent work that applied

GANs and the idea of policy gradient to NMT, which

replaces the previous method. It improves the trans-

lation quality of model by minimizing the difference

between human translation and the translation given

by the NMT model. This work proposed a Convo-

lutional Neural Network that can accurately capture

high-level abstract correspondence of concatenation

of source sequence and target sequence. First, they

join the output sequence

Y of the NMT model or the

human translation output sequence Y with the source

language sentence X to form a two-dimensional ma-

trix and then measure the similarity between Y (or

Y )

and X through the convolution neural network. The

output label is 0(irrelevant) or 1(relevant). Speciﬁ-

cally, they join the word embedding corresponding to

the i-th word x

in the source sequence and the j-th

word y

in the target sequence follow z

i, j

= [x

, y

]

to gain a three-dimensional tensor representation Z.

Then through the convolution layers and max-pooling

layers to get more abstract feature expressions. The

obtained feature expressions are then fed to a multi-

layer perceptron, and the sigmoid activation function

of the last layer outputs a 2-class probability distri-

bution. And generative network update parameters

by the policy gradient. The loss of the discriminative

network is used as a reward to the generative network,

which makes the gradient of discriminator can propa-

gate to the generator.

4 MODEL

Part of our model is based on (Wu et al., 2017), and

we have another generator and discriminator in our

model. We use the “similarity selection” we designed

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

to train generator

and use the policy gradient to

train generator

. Two discriminators are called “sen-

tence discriminator” and “hidden state discriminator”,

which are represented by D

and D

respectively. D

is used to distinguishing whether the sentence is gen-

erated by our generators or written by human. And

its result is used as a reward to generator

; and D

used to reduce the difference between generator

and

generator

. The framework of the model is shown

in the Figure.1. We introduce our model in three

parts:(1) “similarity selection”, (2) Generators and (3)

Discriminators.

4.1 Similarity Selection

The Encoder-Decoder framework has achieved great

success and has been widely used in many natural lan-

guage processing tasks. And Recurrent Neural Net-

work (Mikolov et al., 2010) is the most commonly

used model in the two sub-modules of Encoder-

Decoder when it comes to machine translation task.

In the structure of RNN, dealing with the timing prob-

lem like sentences is to recurrent input and output one

by one. Assume X = {x

, ... ,x

} are the input units

and Y = {y

, ... ,y

} is the label. RNNs also con-

tain hidden units that marked as {s

, ... ,s

} and

express them as vector form S. s

is the state at the t-

th time step of the hidden layer, which is the memory

unit of the network. s

is calculated based on the cur-

rent input x

and the previous state of the hidden layer

t−1

= f (U ∗ x

+W ∗ s

t−1

) (1)

in which f is a non-linear activation function like

ReLU. U and W are model’s weights. When calcu-

lating s

, that is, the hidden state of the ﬁrst word, s

can be 0 vector. The output process of RNNs as blew:

= V ∗ s

(2)

where o

is the output at time step t, that is, the vec-

tor representation of the next word. And V is the

learnable weights. In the decoding process, these hid-

den units complete the most important work but the

way to get s

will cause exposure bias (Ranzato et al.,

2015). To address it, we proposed a new and effec-

tive method called “similarity selection”. As the name

suggests, it uses the previous output or the label as in-

put based on the similarity between the output and the

label. When the output of the previous time step and

label have high similarity, we use the output of pre-

vious step as the current input, otherwise, we use the

current label to input. Inspired by (Li and Han, 2013),

(Muﬂikhah and Baharudin, 2009) and (Nguyen and

Bai, 2010), the similarity of these two vectors is cal-

culated by Eq.3:

similarity(A, B) =

A · B

k A kk B k

∑

i=1

× B

∑

i=1

)

∑

i=1

)

(3)

where A and B represent two word embeddings, and

n is the dimension of the word embedding. The sim-

ilarity of the two vectors ranges from 1 to -1, and

the angle between them increases as the similarity de-

creases. The smaller the value is from 1, the closer

these two vectors are. When the similarity is 0, the

two vectors are vertical. When the similarity is less

than 0, it means that the vectors are more dissimilar.

So we treat the vectors with a similarity of 0 to -1 as

the vectors with a similarity of 0. In this work, We

ﬁrst calculate the similarity of the output of the pre-

vious time step and the label of the current time step.

Then we input the similarity into ReLU function and

get a result from 0 to 1. And then we take this result

as the probability of using the output instead of the

label. It means that the more similar these two word

vectors are, the more likely we are to use the output

from the previous step to input.

4.2 Generators

We have two generators named generator

and

generator

in our work. generator

uses “similar-

ity selection” and generator

uses policy gradient.

These two generators are both based on the encoder-

decoder framework and share parameters. We use

Long Short-Term Memory (LSTM) network (Hochre-

iter and Schmidhuber, 1997) in encoder and decoder:

= σ(W

· [h

t−1

, x

] + b

) (4)

= σ(W

· [h

t−1

, x

] + b

) (5)

= tanh(W

· [h

t−1

, x

] + b

) (6)

= σ(W

t−1

, x

] + b

) (7)

= f

∗C

t−1

+ i

∗

(8)

= o

∗tanh(C

) (9)

where W

, W

and b

, b

are matrices

of learnable weights and biases. Eq.4 is input gate;

Eq.5 and Eq.6 is forget gate; Eq.7 is output gate; Eq.8

and Eq.9 are represent long term memory and short

term memory respectively. h

is the hidden state of

the network at time step t and x

is the input unit at the

current step t. Different from other works, here x

the current label or the previous step output selected

by the “similarity selection” in generator

. And we

Twin-GAN for Neural Machine Translation

generator

encoder

word embedding

output

hidden states

decoder

encoder

word embedding

output

hidden states

decoder

weights

Figure 1: Model framework: The top of the framework is generator

, and the bottom is generator

. The D

represents the

“hidden state discriminator”, whose input is the hidden states of the generator’s decoder. The D

represents the “sentence

discriminator”. The generator’s outputs are input to D

and its output is fed back to generator

as a reward.

also add attention mechanism (Bahdanau et al., 2015)

into the connection between encoder and decoder:

|X|

∑

i=1

(10)

exp(F(s

, h

t−1

))

∑

|X|

j=1

exp(F(s

, h

t−1

))

(11)

F(s

, h

t−1

) = h

t−1

· s

(12)

where |X| represents the length of the source sen-

tence. c

is the result of the attention mechanism

for decoder at time step t. h

and s

represent the i-

th hidden state of encoder and decoder respectively.

We use Eq.12 (dot-multiply) to calculate the attention

score. Eq.11 is the so f tmax function and it obtains

, which is the ﬁnal attention score of the encoder

hidden states for the t-th time step decoder. The itera-

tive optimization scheme of generator

is:

minimizing : −

|Y |

∑

j=1

logP

] (13)

where | Y | indicates the length of the ground-truth

sentence, P

refers to the predicted probability distri-

bution at the j-th step, y

is the token generated by

generator

at the j-th step.

In generator

, we train it in the same way as the

inference (recurrent mode), that is, we use the previ-

ous step output as the current input to train it recur-

rently. This strategy during training makes it more

like an inference process to achieve the purpose of

alleviating the discrepancy between training and in-

ference. We apply the idea of policy gradient to

generator

. We use the result of the D

as the reward

to this generator. With the notations for generator

model G(θ

) and sentence discriminator model D

the iterative optimization scheme of generator

is:

minimizing : −E

X∼P

data

(X),

Y ∼G(θ

,X)

log(1 − D

(X,

Y ))

(14)

where X is the data sampled from source sentences,

is parameters of generator

and

Y is the target sen-

tences generated by generator

We use a discriminator D

(introduced in the Sec-

tion 4.3 ) to force generator

to close generator

, and

ﬁnally make their data distribution close. At the end,

we use generator

to test.

4.3 Discriminators

In this paper, we proposed two discriminators in one

GAN innovatively. And one is to discriminate be-

tween the results of the generators and ground-truth

translations, and the other is to discriminate against

the data distributions of these two generators.

One discriminative network, called D

for short,

is inspired by (Wu et al., 2017). We use it to di-

rectly reduce the difference between sentences gen-

erated by generators and written by human to train

these two generators at the same time. And we use the

results of D

as a reward feed to generator

. There-

fore, generator

is updated by its own error and the

reward received from D

. We ﬁrst concatenate the

source sentence (X) and synthetic sentence (

Y ) gener-

ated by our generators or the target ground-truth sen-

tence (Y) to form a matrix

Z or Z, which also helps

to measure the translative matching degree of source

sentence and target sentence. Then the

Z and Z are

fed to D

and outputs a probability that

Z and Z is

from ground-truth data. The structure of D

is based

on CNNs which ignores some overly detailed features

of input sequences to capture the overall features and

the relevance of these two sequences.

For the other discriminator, called D

for short,

it is used to make the model distributions of these

two generators more similar through discriminating

the hidden states of them. It is based on a bidirec-

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

tional recurrent neural network (Bi-RNN) that con-

sists of two RNNs. One runs forward in time on the

input hidden states sequence, and the other runs back-

ward in time with the same input sequence. The hid-

den states of the two RNNs are connected at each time

step to form a new hidden state which is continuing to

feed the next layers. The output of Bi-RNN is fed to

the Multilayer Perceptron (MLP) and the output layer

consists of an afﬁne transformation and a sigmoid.

Finally, D

outputs a result indicating the probabil-

ity that the input hidden state sequence is the hidden

states of generator

. We re-train the D

as:

minimizing : −E

X∼P

data

(X),h

∼G(θ

,X)

log(D

))

−E

X∼P

data

(X),h

∼G(θ

,X)

log(1 − D

))

(15)

in which h

and h

are the hidden states of generator

and generator

respectively.

5 EXPERIMENTS

5.1 Dataset

We carry out experiments on the IWSLT 2014 (Cet-

tolo et al., 2014) German→English (De→En) and the

WMT’17 Chinese→English (Zh→En) respectively.

IWSLT 2014: This data set is bilingual corpus

pairs of German and English, consisting of a train-

ing set, a validation set and a test set, with 153k, 7k

and 6.5k pairs of sentences respectively. And we set

the maximum sentence length to 50. Our dictionary

keeps the ﬁrst 22,822 high-frequency English words

and 32,009 German words, and the remaining words

not in the vocabulary are replaced by “<UNK>”.

WMT’17: In this dataset, in order to obtain Chi-

nese word segmentation, we use jieba

to process Chi-

nese corpus. We use the newsdev2017 as the dev set

and newstest2017 as the test set. And we use byte

pair encoding (BPE) (Sennrich et al., 2015) approach

to preprocess the Chinese and English corpus, gener-

ating Chinese and English vocabularies with 37,516

and 25,524 types, respectively.

5.2 System

For the whole model, the dimension of the word em-

bedding is set as 512; We initialized the learning rate

of both discriminators and generators at 0.001. Since

discriminators are simpler and easier to train than

generators, we trained them at different frequencies.

https://github.com/fxsjy/jieba

We trained discriminators only once every ten times

the generators are trained. The source code is avail-

able at GitHub

Generators: both two generators share the same

encoder-decoder structure as described in Section 4.2,

and these two generators share weights. The details

of generators are as follow: 2-layers LSTM networks

act as encoder and decoder employ 2-layers LSTM

and an attention. We set the hidden units for both

encoders and decoders as 1000. We initialized the pa-

rameters of LSTM networks following the Uniform

distribution U(-1, 1). The attention mechanism we

used in the decoder is the same as (Bahdanau et al.,

2015). And we also applied dropout(=0.3) for train-

ing the generators. During testing, we used a beam

search with a beam size of 5 and the length penalty

is not applied. In the forward process, we used the

“similarity selection” method and the inference way

in generator

and generator

respectively to train

them. And we set ﬁfty percent probability to train

generator

, and another ﬁfty percent probability to

train generator

Discriminators: for “sentence discriminator”

), we used two CNN layers and each layer is fol-

lowed by a max-pooling layer, with 3×3 convolution

kernel size and 2×2 pooling window size. And then

fed the output of the CNN layer to a MLP network

which has two full connection layers and each layer

with a ReLU activation function. Finally, we mapped

it into a score through a sigmoid function. For hid-

den state discriminator(D

), it is based on a bidirec-

tional recurrent neural network, which consists of two

RNNs (two GRU networks (Cho et al., 2014)), The

hidden states of these two RNNs are fed to an MLP

network. That MLP has three layers, each consist of

an afﬁne transformation and a ReLU activation func-

tion. Finally, the output layer comprises an afﬁne

transformation and a sigmoid.

5.3 Results

The translation results of our experiments are eval-

uated by BLEU (Papineni et al., 2002) score

. As

shown in table Table 1 which compares the results of

our twin-GAN model with some strong basic mod-

els on the IWSLT 2014 De→En data set. (Bahdanau

et al., 2016) uses an approach to train model to gen-

erate sequences through using actor-critic approach

from reinforcement learning (RL) to replace the uni-

versal log-likelihood training approach. (Bahdanau

et al., 2015) allows a basic encoder–decoder model to

https://github.com/zhao1402072392/twin-GAN

https://github.com/moses-smt/mosesdecoder/blob/

master/scripts/generic/multi-bleu.perl

Twin-GAN for Neural Machine Translation

automatically search for parts of a source sequence re-

lated to the predicted target word to improve the per-

formance of it. And we carried out experiments with

our twin-GAN model at different learning rates and

the different ratios of times of training generators and

discriminators. And the result shows that this BLUE

score of this work (with learning rate=1e-3, update

G/10 times update D) on the IWSLT 2014 De→En

data set is 1.09 points higher than that of the related

model (Wu et al., 2017).

Table 1: Comparisons of different competitive NMT sys-

tems on IWSLT 2014 De→En data set.

Systems BLEU

CNN + actor-critic 22.45

RNN Search 23.87

Adversarial NMT 26.98

twin-GAN

update/5 times, lr=1e-3 27.73

update/10 times, lr= 5e-4 27.81

update/10 times lr=1e-3 28.07

†

reported in (Bahdanau et al., 2016)

reported in (Wiseman and Rush, 2016)

reported in (Wu et al., 2017)

†

the best performance of our twin-GAN model

We also train twin-GAN with other strategies in

generator

, instead of “similarity selection”, we use

“teacher forcing” and schedule sampling respectively,

in order to verify that it was important to use this more

reasonable method “similarity selection” on the twin-

GAN model.

Table 2: Comparisons of different training strategies on

twin-GAN based on IWSLT 2014 De→En data set.

Strategies BLEU

twin-GAN with “teacher forcing” 27.10

twin-GAN with schedule sampling 27.74

twin-GAN with “similarity selection” 28.07

†

the best performance of twin-GAN model with dif-

ferent strategies in generator

In addition, we evaluate different models, based on

WMT’17 Zh→En corpus. The results are shown in

Table 3, where “RNN Enc-Dec Att” represents the

encoder and decoder of the model are the same RNN

architecture(2 layers LSTM network here) with an at-

tention mechanism. We also compared the result of

our work with Adversarial NMT (Wu et al., 2017).

The result shows that our method improved the per-

formance of those recurrent architecture model.

Table 3: Comparisons of different competitive NMT sys-

tems on WMT’17 Zh→En data set.

Systems BLEU

RNN Enc-Dec Attn 18.06

Adversarial NMT 19.90

twin-GAN

update/5 times, lr=1e-3 20.86

update/10 times, lr= 5e-4 20.32

update/10 times lr=1e-3 21.06

†

the best performance of our twin-GAN model

6 CONCLUSIONS

The end-to-end model is very popular and effective

in Neural Machine Translation. But this process of

generating translations word by word is different dur-

ing training and inference, which can cause exposure

bias. Many researchers tried to use Generative Adver-

sarial Networks to address this problem and they in-

deed had some success, but there is still room for im-

provement. We introduce the ﬁrst GAN with two gen-

erators and two discriminators for NMT. We not only

make the training phase and test phase similar in data

distribution, but also make them similar in model dis-

tribution to solve the exposure bias problem through

one of the discriminators. In addition, the proposed

“similarity selection” method in generator

can more

accurately make the data distributions of the model

similar at training and test. The results clearly show

that after using this new model, it does improve the

performance of the basic recurrent model. The twin-

GAN also has enhanced the Adversarial NMT model

after adding an extra “hidden state discriminator” and

applying “similarity selection” method, achieving the

competitive results on recurrent models.

ACKNOWLEDGEMENTS

This work was supported by National Key R&D Pro-

gram of China under Grant 2018AAA0100202, and

in part by the National Science Foundation of China

under Grant 61976043.

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

REFERENCES

Artetxe, M., Labaka, G., Agirre, E., and Cho, K. (2017).

Unsupervised neural machine translation. CoRR.

Bahdanau, D., Brakel, P., Xu, K., Goyal, A., Lowe, R.,

Pineau, J., Courville, A., and Bengio, Y. (2016). An

actor-critic algorithm for sequence prediction. arXiv

preprint arXiv:1607.07086.

Bahdanau, D., Cho, K., and Bengio, Y. (2015). Neural ma-

chine translation by jointly learning to align and trans-

late. ICLR.

Bengio, S., Vinyals, O., Jaitly, N., and Shazeer, N. (2015).

Scheduled sampling for sequence prediction with re-

current neural networks. In Advances in Neural Infor-

mation Processing Systems, pages 1171–1179.

Cettolo, M., Niehues, J., St

uker, S., Bentivogli, L., and Fed-

erico, M. (2014). Report on the 11th iwslt evaluation

campaign, iwslt 2014. In Proceedings of the Inter-

national Workshop on Spoken Language Translation,

Hanoi, Vietnam, volume 57.

Cho, K., Van Merri

enboer, B., Gulcehre, C., Bahdanau, D.,

Bougares, F., Schwenk, H., and Bengio, Y. (2014).

Learning phrase representations using rnn encoder-

decoder for statistical machine translation. Empirical

Methods in Natural Language Processing (EMNLP).

Gehring, J., Auli, M., Grangier, D., Yarats, D., and

Dauphin, Y. N. (2017). Convolutional sequence to se-

quence learning. In Proceedings of the 34th Interna-

tional Conference on Machine Learning-Volume 70,

pages 1243–1252. JMLR. org.

Goodfellow, I. (2016). Generative adversarial networks.

Conference and Workshop on Neural Information

Processing Systems(NIPS), page 2672–2680.

Goodfellow, I., Pouget-Abadie, J., Mirza, M., Xu, B.,

Warde-Farley, D., Ozair, S., Courville, A., and Ben-

gio, Y. (2014). Generative adversarial nets. In

Advances in neural information processing systems,

pages 2672–2680.

He, T., Tan, X., Xia, Y., He, D., Qin, T., Chen, Z., and Liu,

T.-Y. (2018). Layer-wise coordination between en-

coder and decoder for neural machine translation. In

Advances in Neural Information Processing Systems,

pages 7944–7954.

Hochreiter, S. and Schmidhuber, J. (1997). Long short-term

memory. Neural computation, 9(8):1735–1780.

Husz

ar, F. (2015). How (not) to train your generative model:

Scheduled sampling, likelihood, adversary? arXiv

preprint arXiv:1511.05101.

Kalchbrenner, N. and Blunsom, P. (2013). Recurrent con-

tinuous translation models. In Proceedings of the 2013

Conference on Empirical Methods in Natural Lan-

guage Processing, pages 1700–1709.

Kalchbrenner, N., Espeholt, L., Simonyan, K., Oord, A.

v. d., Graves, A., and Kavukcuoglu, K. (2016). Neu-

ral machine translation in linear time. arXiv preprint

arXiv:1610.10099.

Kusner, M. J. and Hern

andez-Lobato, J. M. (2016).

Gans for sequences of discrete elements with

the gumbel-softmax distribution. arXiv preprint

arXiv:1611.04051.

Lamb, A. and Xie, M. (2016). Convolutional encoders for

neural machine translation. WEB download.

Lamb, A. M., Goyal, A. G. A. P., Zhang, Y., Zhang, S.,

Courville, A. C., and Bengio, Y. (2016). Professor

forcing: A new algorithm for training recurrent net-

works. In Advances In Neural Information Processing

Systems, pages 4601–4609.

Lample, G., Conneau, A., Denoyer, L., and Ranzato,

M. (2017). Unsupervised machine translation using

monolingual corpora only. CoRR.

Lample, G., Ott, M., Conneau, A., Denoyer, L., and Ran-

zato, M. (2018). Phrase-based & neural unsupervised

machine translation. In EMNLP, pp. 5039–5049.

Li, B. and Han, L. (2013). Distance weighted cosine simi-

larity measure for text classiﬁcation. In International

Conference on Intelligent Data Engineering and Au-

tomated Learning, pages 611–618. Springer.

Luong, M.-T., Pham, H., and Manning, C. D. (2015). Ef-

fective approaches to attention-based neural machine

translation. arXiv preprint arXiv:1508.04025.

Mikolov, T., Karaﬁ

at, M., Burget, L.,

Cernock

y, J., and

Khudanpur, S. (2010). Recurrent neural network

based language model. In Eleventh annual confer-

ence of the international speech communication as-

sociation.

Muﬂikhah, L. and Baharudin, B. (2009). Document clus-

tering using concept space and cosine similarity mea-

surement. In 2009 International Conference on Com-

puter Technology and Development, volume 1, pages

58–62. IEEE.

Nguyen, H. V. and Bai, L. (2010). Cosine similarity metric

learning for face veriﬁcation. In Asian conference on

computer vision, pages 709–720. Springer.

Papineni, K., Roukos, S., Ward, T., and Zhu, W.-J. (2002).

Bleu: a method for automatic evaluation of machine

translation. In Proceedings of the 40th annual meeting

on association for computational linguistics, pages

311–318. Association for Computational Linguistics.

Ranzato, M., Chopra, S., Auli, M., and Zaremba, W. (2015).

Sequence level training with recurrent neural net-

works. arXiv preprint arXiv:1511.06732.

Rumelhart, D. E., Hinton, G. E., and Williams, R. J. (1986).

Learning representations by back-propagating errors.

nature, 323(6088):533–536.

Sennrich, R., Haddow, B., and Birch, A. (2015). Neural

machine translation of rare words with subword units.

arXiv preprint arXiv:1508.07909.

Shen, S., Cheng, Y., He, Z., He, W., Wu, H., Sun, M., and

Liu, Y. (2015). Minimum risk training for neural ma-

chine translation. The Association for Computational

Linguistics(ACL).

Song, K., Tan, X., He, D., Lu, J., Qin, T., and Liu, T.-Y.

(2018). Double path networks for sequence to se-

quence learning. In Proceedings of the 27th Interna-

tional Conference on Computational Linguistics, pp.

3064–3074.

Sutskever, I., Vinyals, O., and Le, Q. V. (2014). Se-

quence to sequence learning with neural networks. In

Advances in neural information processing systems,

pages 3104–3112.

Twin-GAN for Neural Machine Translation

Sutton, R. S., Barto, A. G., et al. (1998). Introduction to

reinforcement learning, volume 135. MIT press Cam-

bridge.

Tan, X., Ren, Y., He, D., Qin, T., Zhao, Z., and Liu, T.-Y.

(2019). Multilingual neural machine translation with

knowledge distillation. ICLR.

Vaswani, A., Shazeer, N., Parmar, N., Uszkoreit, J., Jones,

L., Gomez, A. N., Kaiser, Ł., and Polosukhin, I.

(2017). Attention is all you need. In Advances in

neural information processing systems, pages 5998–

6008.

Venkatraman, A., Hebert, M., and Bagnell, J. A. (2015).

Improving multi-step prediction of learned time series

models. In Twenty-Ninth AAAI Conference on Artiﬁ-

cial Intelligence.

Williams, R. J. (1992). Simple statistical gradient-following

algorithms for connectionist reinforcement learning.

Machine learning, 8(3-4):229–256.

Williams, R. J. and Zipser, D. (1989). A learning algo-

rithm for continually running fully recurrent neural

networks. Neural computation, 1(2):270–280.

Wiseman, S. and Rush, A. M. (2016). Sequence-to-

sequence learning as beam-search optimization. arXiv

preprint arXiv:1606.02960.

Wu, L., Xia, Y., Zhao, L., Tian, F., Qin, T., Lai, J., and Liu,

T.-Y. (2017). Adversarial neural machine translation.

arXiv preprint arXiv:1704.06933.

Wu, Y., Schuster, M., Chen, Z., Le, Q. V., Norouzi,

M., Macherey, W., Krikun, M., Cao, Y., Gao, Q.,

Macherey, K., et al. (2016). Google’s neural machine

translation system: Bridging the gap between human

and machine translation. CoRR, abs/1609.08144.

Yang, Z., Chen, W., Wang, F., and Xu, B. (2017). Im-

proving neural machine translation with conditional

sequence generative adversarial nets. arXiv preprint

arXiv:1703.04887.

Yu, L., Zhang, W., Wang, J., and Yu, Y. (2017). Seqgan:

Sequence generative adversarial nets with policy gra-

dient. In Thirty-First AAAI Conference on Artiﬁcial

Intelligence.

Zhang, W., Feng, Y., Meng, F., You, D., and Liu, Q. (2019).

Bridging the gap between training and inference for

neural machine translation. The Association for Com-

putational Linguistics(ACL).

Zhang, Y., Gan, Z., and Carin, L. (2016). Generating text

via adversarial training. In NIPS workshop on Adver-

sarial Training, volume 21.

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence
