Protecting Privacy during a Pandemic Outbreak

Karsten Martiny

, Linda Briesemeister

, Grit Denker

, Mark St. John

and Ron Moore

SRI International, 333 Ravenswood Ave, Menlo Park CA 94025, U.S.A.

Pacific Science & Engineering, 9180 Brown Deer Rd, San Diego CA 92121, U.S.A.

Keywords: Privacy, Access Control, Data Sharing, Policies, Reasoning.

Abstract: Respecting privacy is a major challenge when sharing data among enterprises. Because of the high stakes and

complexity, enterprises need expressive and clear methods for defining tailored data sharing so that they can

share the right information with the right partners with confidence. This paper describes a privacy-oriented

declarative policy framework together with an intuitive user interface to manage data sharing policies. It

introduces a use case about a pandemic outbreak, in which the system can be used to share relevant

information with partners to ensure that help can be coordinated quickly and effectively, while at the same

time ensuring that the privacy of individuals remains protected and not sharing overly widely. A set of privacy

policies is introduced to describe how the policy system can meet these requirements.

1 INTRODUCTION

Respecting privacy is a major challenge when sharing

data among enterprises. Enterprises, including law

enforcement, hospitals, financial institutions, and

military organizations cooperating on missions or

disaster relief share large amounts of data. Much of

these data are sensitive and private. Sharing sensitive,

private data with the wrong enterprise partners could

result in adversarial exploitation and serious harm to

the enterprise and subjects of the data and potential

civil and criminal liability. On the other hand,

withholding the data necessary for a cooperative

mission could hamper the execution of the mission,

preempt its success, and incur irreparable damage to

the joint goals that brought the cooperative partners

together.

Additionally, the policies set in place by

enterprises, regarding which data to share with whom,

are often complex. Enterprises may have thousands

of data types and hundreds of partners. Enterprise

policies are likely to contain varying scopes and

levels, such as broad baseline policies as well as

detailed exceptions that tailor data sharing for specific

objectives. Further, because enterprises typically

have multiple objectives, policies may overlap and

interact. Creating and managing enterprise policies,

therefore, is likely to be challenging.

Because of the high stakes and complexity,

enterprises need expressive and clear methods for

defining tailored data sharing so that they can share

the right information with the right partners with

confidence. Building on an existing privacy-oriented

declarative policy framework (Martiny, Elenius, &

Denker, 2018) together with an intuitive user

interface (St. John, Moore, Martin, Gustafson,

Jaramillo, Denker, Martiny, & Briesemeister, 2018,

Briesemeister, Gustafson, Denker, Martin, Martiny,

Moore, Pavlovic, & St. John, 2019), this paper

describes a use case about a pandemic outbreak, in

which privacy policies are used to share relevant

information with partners to ensure that help can be

coordinated quickly and effectively, while at the same

time ensuring that the privacy of individuals remains

protected and not sharing overly widely. Based on

this use case, the paper analyses how a declarative

policy framework provides useful capabilities to aid

in modeling complex data sharing scenarios through

simple policy specifications. The framework focuses

on reasoning about data sharing decisions based on a

common, implementation-agnostic data model. This

allows for an easy integration of various data retrieval

operations in existing systems, e.g., SQL queries,

MongoDB queries, HTTP Rest calls, etc.

Demonstration videos of using our system for this

and other use cases can be found at

https://sunflower.csl.sri.com/index.php/projects-

sponsors/prisms/.

The remainder of the paper is structured as

follows. We conclude this section with a brief

discussion of related work. A more comprehensive

308

Martiny, K., Briesemeister, L., Denker, G., John, M. and Moore, R.

Protecting Privacy during a Pandemic Outbreak.

DOI: 10.5220/0010186603080318

In Proceedings of the 7th International Conference on Information Systems Security and Privacy (ICISSP 2021), pages 308-318

ISBN: 978-989-758-491-6

 2021 by SCITEPRESS – Science and Technology Publications, Lda. All rights reser ved

comparison of our framework with existing

approaches can be found in (Martiny et al, 2018).

Then, Section 2 describes the key components of the

data sharing system relevant for managing policies

and making policy-based data sharing decisions. In

Section 3 we describe in detail a use case in which the

data sharing system can be used to manage sensitive

data during a pandemic outbreak, including a

characterization of the use case’s objectives and

explanations how implemented policies achieve these

objectives. Afterwards, Section 4 provides an

analysis of our experiences and results from

developing and implementing this use case. Finally,

the paper concludes with Section 5.

A number of machine-readable privacy policy

languages exist to protect access to sensitive

information. Most notable are Ponder (Damianou,

Dulay, Lupu, & Sloman, 2001) EPAL (Ashley, Hafa,

Karjoth, Powers, & Schunter, 2003), Rei (Kagal,

Finin, & Joshi, 2003), KAoS (Uszok, Bradshaw, &

Jeffers, 2004) AIR (Kagal, Hanson, & Weitzner,

2008), SecPAL (Becker, Fournet, & Gordon, 2010)

XACML (OASIS XACML Standard, 2013) and

PRISMS (Martiny et al, 2018). A common feature of

all of these languages is that they provide some means

of privacy protection through role-based access

control policies. Based on their specification of

affected data, these contributions can be categorized

into different approaches: In XACML, SecPAL, and

Ponder the unique resources targeted by policies need

to be explicitly specified, and requested objects need

to exactly match a specified policy object in order to

trigger a policy decision. If several related resources

are to be shared in these systems, dedicated policies

have to be specified for each resource, leading to a

large number of very similar policies. Other

approaches such as EPAL specify policies based on

category labels (such as “location data”). This

approach significantly reduces the number of

required policies to share a set of similar records.

However, it only provides very coarse ways of

characterizing data, and thus does not allow for fine-

grained tailoring of access policies. KAoS, Rei, and

AIR on the other hand are expressive enough to

represent rich relationships between targeted

resources. They achieve their power by essentially

exposing a complete logic language to the policy

author, who is left to define the precise semantics of

each policy from scratch. This makes the process of

specifying policies much more challenging and much

less accessible to non-experts.

In PRISMS, policy authors use a use case specific

data model together with a general, use case

independent shareability theory. This allows the

policy framework to generalize to a high degree,

which in turn enables the author to specify expressive

policies in a concise way, capturing their intent

through intuitive graphical interfaces without

requiring extensive knowledge of the underlying

specification formalism. We adopt the PRISMS

framework for our pandemic use case.

2 SYSTEM COMPONENTS

The overall information system architecture is

depicted in Figure 1. Similar to the architecture of

XACML, our high-level architecture is separated into

a policy administration point (PAP) where policies

are authored, policy decision point (PDP) where data

requests are evaluated against policy, and a policy

Figure 1: The overall system architecture: 1. Data requesters send requests for data to the Policy Enforcement Point (PEP).

2. Upon receiving a request for specific data, the PEP will ask the Policy Decision Point (PDP) for a decision with respect to

the currently defined policies. 3. The PDP will return a result, which consists of an allow or deny decision and optionally

additional constraints for this decision. 4. The PEP will use the result from the PDP to rewrite the request into a policy-safe

database query and send this query to the actual database. 5. After receiving results from the data base, the PEP potentially

applies additional post-processing steps and then 6. returns the final result back to the requester. The Policy Administration

Point (PAP) provides a UI that transforms machine-readable policies into human-readable policies that can be managed by

the policies’ author, here after called the policy authority.

DataRequester

PolicyAuthority

PEP

PDP PAP

1.requestfordata

2.requestfor

policydecision

3.returndecision(yes/no),

potentiallyconstrained

4.policy‐safequery

5.queryresult

6.policy‐saferesponse

manage(human‐

readable)policies

manage(machine‐

readable)policies

data‐dependent

operations

data‐independent

operations

Protecting Privacy during a Pandemic Outbreak

309

enforcement point (PEP) where those decisions are

enforced. This architecture supports the separation of

enforcement from decision making, which is

particularly relevant for the integration of additional

privacy-preserving technologies, as described below.

2.1 The Common Data Model

Our architecture uses a Common Data Model (CDM)

as an intermediate representation of the type and

organization of data managed by the system. This

data model is used as the basis of communication

between different components of our architecture. To

illustrate the concepts of the CDM, Figure 2 depicts a

very simple example: The main building block of the

data model are classes that represent certain types of

data, for example, Figure 2 contains two classes

Community and Person. Classes can have data

properties such as name for the Community class,

and lastName, firstName, birthdate, and

gender for the Person class. These data properties

are the representations of information that could

actually be shared with requesters.

The CDM also models connecting properties such

as the resident property shown in Figure 2. This

property expresses that the class Community has a

property resident which points to the class

Person, i.e., it provides a connection between these

two classes. We use the convention of denoting class

names with capital letters and property names with

lower-case letters to easily distinguish these concepts.

We also use a dot notation to denote properties of a

certain class, e.g., Community.name refers to the

name property of the Community class. This

notation can also be used to express paths through the

CDM, e.g., Community.resident.lastName

represents the last names of communities’ residents.

A lot of times connecting properties have

counterparts to express the inverse relatio nship, e.g.,

in Figure 2 the Person class has a property

Figure 2: A very simple CDM: The classes are

Community and Person, with data properties name, and

lastName, firstName, birthDate, and gender,

respectively. The classes are connected through

Community's connecting property resident, and its

corresponding inverse property residence (belonging to

the class Person).

residence pointing to Community, i.e.,

Person.residence is the inverse of

Community.resident. Thus, consequently,

Person.residence.name represents

community names where people reside.

Another feature of the CDM is the ability to

express class hierarchies. This feature is not shown

here, but it is used in the pandemic use case and

shown in Figure 4. This allows the specification of

taxonomies of objects, for example, we can have data

requesters, and epidemiologists as a more specific

subclass of data requesters.

Based on the CDM, Joined Data Sets (JDS) can

be defined to specify the data addressed by policy

specifications. For instance, an (informally

represented) JDS {Community.name,

Community.resident.lastName} specifies

that a policy addresses the joined release of

community names together with the last names of the

communities’ residents.

2.2 The Policy Decision Point

The Policy Decision Point (PDP) is the central

component for making sharing decisions for

incoming requests. It receives access requests from

the Policy Enforcement Point (PEP) consisting of

information for the who, what, and when of a request,

that is, it specifies a requester, the requested data

(represented as a JDS), and the time of the request.

The PDP then infers a sharing decision for this

request in two steps: First, it checks for each of the

existing policies whether they match the given

request specification and collects the corresponding

decisions. Second, if multiple decisions are collected,

it evaluates the interplay of different policies by

analyzing defined overriding criteria to derive a final

sharing decision which is sent back to the PEP.

To determine whether the requested data matches

the data specifications of a given policy, the PDP uses

a shareability theory that models generic relations

between different, but related JDSs: For instance, our

shareability theory states that if a policy allows

sharing of a certain JDS, then it also allows all

requests for subsets of this JDS. For example, if a

policy allows sharing of above JDS combining

persons’ last names and their community of

residence, this also allows a request for just persons’

last names as this is a subset of the allowed data

specification. Conversely, if a policy specifies that

access to a certain JDS is forbidden, this

automatically also applies to all supersets of the

specified JDS. For example, if a policy denied access

to above JDS, it would also deny requests for any

Person

lastName

firstName

birthdate

gender

Community

name

residence

resident

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

310

Figure 3: A view of the semantic data model via the CDM explorer tool. The user has navigated to the Community class

and selected the name data property. Furthermore, the user has linked to residents of the community via the resident

connecting property of Community. Residents are persons and the user has chosen two data properties to share:

firstName and lastName. The user has also selected the link to the person’s Medical Information to share the data

property diseaseStatus. In summary, the graphical tool allows the Policy Authority to specify the JDS of

{Community.name, Community.resident.firstName, Community.resident.lastName,

Community.resident.medicalInformation.diseaseStatus}.

superset such as requesting persons’ last names, their

community of residence, and their medical status.

Moreover, the shareability theory also characterizes

additional matching relations between the requested

and the specified JDSs; (a) if the request is for a

subclass of a class that is specified in the policy’s

JDS, and (b) if the request is for the inverse of a

relation that is specified in the policy’s JDS. For

example, if a policy allows sharing of information

about “communities and their residents,” it will also

permit the equivalent request for “persons and their

residence community,” because the properties

“residents” and “residence” are inverse properties of

each other. This quality allows the use of a single,

concise specification of a policy’s data, while at the

same time ensuring that this specification matches a

large variety of related requests.

If multiple policies match a given request, the

PDP uses a set of defined overriding criteria to

determine the final decision. Overriding criteria can

be flexibly defined according to the use cases’ needs.

In the use case that we introduce below, we illustrate

two commonly used criteria: precedence-based

overrides allow one policy authority to specify

multiple policies with different priorities, so that in

case of conflicts the policy with the highest priority is

chosen. Additionally, hierarchy-based overrides can

be used to model chain of authority relations and give

superior policy authorities the ability to override

decisions from subordinate authorities.

Next to issuing allow/deny decisions, the PDP is

also able to attach constraints to issued decisions.

Constraints can be of two different types: Filter

constraints specify criteria that must be met by

returned data, and action constraints specify post-

processing actions to be performed on the retrieved

data before returning it to the requester.

We will illustrate all of these aspects in detail in

Sections 3 and 4.

2.3 The Policy Administration Point

The policy administration point (PAP) provides a user

interface for the policy authority to create, edit, and

review the effects of their data sharing policies. A

policy manager component displays a list of policies,

including their names, a short description and their

precedence level (higher precedence policies override

lower precedence policies). The policy manager

allows policy authorities to create new policies, edit

or delete existing policies, or enable or disable

existing policies. Disabled policies remain in the

system, but they are not used to compute data sharing

decisions.

Creating or editing a policy uses a four-step

software wizard. In step one, the policy is given a title

and a short description. The policy can also be given

a timeframe for when it enables and disables. Finally,

the policy designates whether to share or deny sharing

data. In step two, data requesters for the policy are

selected. Data requesters are specified based on

attributes. The UI automatically offers choices for all

attributes defined in a given use case. In our

Pandemic use case, data requesters have attributes for

their affiliation (community or nation), and their role

(response coordinators, care providers, and

epidemiologists). Policy authorities can also define

“supergroups” based on specific attributes, such as a

set of response coordinators from certain nations

responding to a disaster. If a policy references a

supergroup whose membership changes, then the

policy automatically shares or denies sharing with the

updated membership.

In step three of the wizard, the policy authority can

select the data shared or denied by the policy. Data

may be specified as simply all data available in the

system or using semantic properties of the data, such

as a JDS from a common data model. We developed

the CDM explorer tool to support the selection of

Protecting Privacy during a Pandemic Outbreak

311

JDSs. In addition to JDSs, policies may also refer to

documents, map layers, or other data formats,

depending on what data formats are available in the

system.

The CDM explorer (see Figure 3) is a graphical tool

for navigating through a data model, such as a

semantic network. Policy authorities start exploring

the semantic network by choosing a root class and

then traverse through classes via connecting

properties (e.g., Community.resident as the

first edge). While visiting class nodes, the policy

authority can select data properties (e.g.,

Person.lastName) available on each class and

thus creates a connected set of paths through the

network to define a JDS. In addition to stepping

through connecting properties, policy authorities can

navigate through class and subclass hierarchies, for

example, both Epidemiologist and Response

Coordinator are subclasses of the

DataRequester class. They can also define

constraints on selected data, such as requiring the date

of birth to be prior to a certain date or requiring the

community of residence to equal a particular

community.

Finally, in step four of the wizard, the policy is

given a precedence level, and there is a final review

of the policy specification.

3 THE PANDEMIC USE CASE

The Pandemic use case was developed to provide a

context for researching, engineering, and

demonstrating privacy-preserving technologies and

user-facing interfaces. The Pandemic use case

involves monitoring a disease outbreak in which a

number of communities share data about their citizens

and their citizens’ disease status, governed by policies

that a number of policy authorities have defined, and

a number of different types of users requesting data

relevant to their roles in this use case. Specific data

sharing policies are enforced to demonstrate a range

of policies and technologies. This use case serves as

a good representative of real-world data sharing tasks

among multiple nations and organizations that

happen on a regular basis. It exhibits privacy

challenges on various levels regarding the privacy of

individuals’ data, as well as inter- and intra-

organizational data exchanges.

Within our pandemic scenario, a typhoon has

caused extensive damage across a set of countries in

the Pacific and relief (food, medicine, water, shelter,

etc.) is needed in a number of communities. Adding

to the complexity of the situation is the outbreak of a

deadly and highly infectious disease that begins

working its way through the populace.

The operational objective in this use case is to

predict the progression of a major disease outbreak

through the impacted communities and to take steps

to counter it. This thread introduces the challenge of

protecting personally identifying information (PII)

within medical records of individuals in the impacted

communities while providing access sufficient to

enable accurate characterization of the disease and its

spread.

3.1 Actors

Actors in this use case belong to one of three different

fictional island nations: Cebu, Bohol, and Siquijor.

Each nation is comprised of different communities,

e.g., Cebu City is one of Cebu’s communities. Every

nation and every community has its own policy

authority, thus enabling data sharing on both the

communal and national level. Moreover, this

situation induces a hierarchy of authorities, where a

(superior) nation policy could potentially override

decisions of associated (subordinate) community

policies.

Requesters are categorized into three different

roles: response coordinators, care providers, and

epidemiologists. While care providers need detailed

medical information about individuals, response

coordinators and epidemiologists need larger-grained

data such as counts of infected persons in each

community and nation. Requesters are also associated

with a specific nation or community. In our use case

we model one nation-level response coordinator and

one care provider for each of the defined nations, and

one community-level response coordinator and care

provider, respectively, for each of the defined

communities. Moreover, each nation has an

epidemiologist to analyze the outbreak and evolution

of the pandemic based on SIRD (Susceptible-

Infected-Recovered-Dead) data.

3.2 Data

The data relevant for this pandemic use case is

depicted in the Common Data Model (CDM) diagram

shown in Figure 4. It is focused on residents’ personal

information (name, birth date, gender) together with

their medical information. Moreover, persons’

relations to communities and nations are modeled

through their resident and citizenship relations,

respectively. Every community belongs to one nation,

and both communities and nations have policy

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

312

Figure 4: The Common Data Model used in the pandemic use case: Classes names are represented in boldface and start with

capital letters; class property names are represented in regular face and start with lowercase letters. Data is centered around

nations, their communities, and persons. Persons are citizens of a country, residents of a community, and have medical

information. Policy authorities (PAs) are categorized into nation and community PAs, and each nation and each community

has a corresponding PA. Nation PAs have authority over their subordinate community PAs. Data requesters are associated

either with a nation or with a community and are categorized into epidemiologists, care providers, and response coordinators.

authorities associated with them. One important

property of this data model is that there is a transitive

residence relation between persons and nations that

traverses through community, i.e., if a person is a

resident of a community, she is also a resident of the

country that the community belongs to. However, the

target relation of this transitive residence relation is

not necessarily the same nation as the target of the

person’s citizenship relation. This is a crucial

difference for the policies discussed below.

Next to the data being shared, the data model also

models data requesters, which can be categorized into

epidemiologists, care providers, and response

coordinators. Data requesters are either associated

with a specific nation or with a specific community,

represented by the corresponding properties. Again,

for data requesters associated with communities, the

associated nation can be determined via a transitive

relationship, but no data requester has simultaneously

defined properties for associated nation and

associated community, thus these relations are

marked as optional in Figure 4.

3.3 Policies

A set of data sharing policies was created for this

pandemic use case to showcase how data can be

shared efficiently with different requesters. The

formal policy specifications are machine readable and

are used by the policy engine, they are not meant for

humans to read. User interactions are performed

through the intuitive interface for policy creation,

management and review (St. John et al, 2018,

Briesemeister et al, 2019). Because of space

limitations, we will not provide formal specifications

for policies, but rather highlight the main features of

our framework by example. Technical details for the

formal policy specifications can be found in (Martiny

et al, 2018).

For descriptive purposes, the policies of this use

case are broken into three vignettes:

Vignette 1. The goal of Vignette 1 is to define

policies that share aggregate information (counts of

people per disease status: S - susceptible, I - infected,

R - recovered, and D - deceased). These counts are

being shared aggregated at the nation level with all

response coordinators and aggregated at each

community level only with the response coordinators

of the corresponding nation. The policies of Vignette

1 make use of various aspects of our powerful policy

language and semantics: (a) the ability to define

exactly what data to share (or not to share) through

JDS path specifications (in particular, in CDMs with

many relations between data, there are many

subtleties that need to be addressed. The related work

cited above does not address these subtleties), and (b)

the ability of detailed tailoring with whom data is

shared. Vignette 1 contains the following policies:

NationPolicyAuthority

CommunityPolicyAuthority

Person

lastName

firstName

birthdate

gender

Community

name

Nation

name

MedicalInformation

diseaseStatus

PolicyAuthority

is‐a

hasAuth‐

orityOver

authority

community

authority

nation

community

nation

citizen

citizenship

residence

resident

person

medicalInformation

Epidemiologist CareProvider

ResponseCoordinator

DataRequester

is‐a

associatedCommunity

associatedNation

relation

optionalrelation

subclassrelation

Protecting Privacy during a Pandemic Outbreak

313

 Policy 1: All Nations Allow Sharing of

Nation-level Aggregated Disease State

Information of their Residents with

Response Coordinators.

This policy specifies that all members of the class

NationPolicyAuthority allow sharing

of data with all members of the class

ResponseCoordinator, i.e., response

coordinators of any level are allowed to see data that

is released on a national level. The data addressed by

this policy can be informally represented

as the joined set of paths (cf. Figure 4)

{NationPolicyAuthority.nation.name,

NationPolicyAuthority.nation.commun

ity.person.medicalInformation.disea

seStatus}, i.e., it allows to jointly release the

names of nations together with the disease state of its

residents.

There are several important aspects to note about

this data specification which distinguish the discussed

approach from previous work on access control: First,

there are different paths through the common data

model to connect nations with medical information of

persons, namely by traversing through nations’

communities and their residents (as this policy does),

or alternatively through nations’ citizens. The former

specification represents all residents of a nation,

while the latter represents all its citizens. It is worth

noting that neither of these concepts subsumes the

other. In particular, this policy does not allow to share

data of a nation’s citizens that reside in another

country.

Second, even though the specified path traverses

through communities, it does not allow to share any

information about communities. Consequently, even

though the community class is part of the part

specification, information about community

associations will not be released to requesters, and

thus response coordinators will only get information

on the national level.

Lastly, this policy intends to release only

aggregate count information about disease states.

Usually, this would require the specification of action

constraints to make sure that only aggregate-level

information is released. However, since the released

data only contains categorical information (SIRD), it

is not necessary to require additional constraints in

this case – the non-aggregated data means that for

each of the four categories (SIRD) there will be

multiple entries. If one were to count the number of

entries per category, one gets the aggregate count. In

other words, this policy allows to release a less

compact representation of count information (not yet

the final count, but lists of entries), but in the end it

does not reveal any more information than the final

count.

 Policy 2: All Nations Allow Sharing of

Community-level Aggregated Disease State

Information of their Residents with Own

Response Coordinators.

The intent of this policy is for each nation to

provide its own response coordinator with more fine-

grained information about the distribution of disease

states. Since this information is mainly required to

coordinate aid on an intra-nation level, it is not shared

on an inter-national level.

To accomplish this sharing goal, a slightly

modified version of the previous policy is used: First,

instead of allowing access for all response

coordinators, a restriction is added that the data

requester’s property associatedNation.name

must be equal to the policy authorities

nation.name property.

Second, one more shared property is

added to the joined data set:

{NationPolicyAuthority.nation.name,

NationPolicyAuthority.nation.commun

ity.person.medicalInformation.disea

seStatus,

NationPolicyAuthority.nation.commun

ity.name}, i.e., the path between nations and

persons is still the same as in the previous policy, but

this policy additionally allows to share the names of

the communities that serve as the intermediate nodes.

Consequently, each released disease status can now

be associated with a specific community and thus

enables the intended community-level aggregation.

Vignette 2. The goal of of Vignette 2 is to define

policies that will generally prohibit sharing of

personal data, but carve out a specific exception,

namely, to share personal data about adults with one’s

own national response coordinator and one’s own

community’s care provider. To simplify the

discussion, this vignette focuses on one particular

community (Cebu City) and its associated nation

(Cebu). The policies of Vignette 2 make use of

various aspects of our powerful policy language and

semantics: (a) ability to override policies based on

different overriding criteria, (b) shareability theory

and superset/subset semantics of decisions to

succinctly capture several equivalent data

representations, and (c) using constraints to exactly

specify what data is made available. Vignette 2

contains the following policies:

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

314

 Policy 3: Cebu City Denies Sharing

Personal Data of Residents with Anyone,

Precedence = 0.

Policy 3 is a baseline policy that locks down data

sharing for all requesters. By choosing the class

DataRequester to specify to whom this policy

applies, and since that is the root or super class of all

data requester classes, this policy applies to all data

requesters in the data model. To express that no

personal data is shared, the policy is a deny policy that

defines {Community.resident} as the data that

will not be shared. Looking at the CDM,

Community.resident points to the Person

class. Even though this is a very succinct description,

it does exactly what is intended, namely not sharing

any personal data of residents. Because of the

shareability theory that underlies our framework, not

only the resident property, but also its reverse

property Person.community is addressed with

this policy and, secondly, because of the semantics

that for a deny policy, all supersets of the specific data

are also denied. Since we deny access to Person in

general with this policy, we also deny access to any

property of persons, making it impossible to share any

meaningful personal data.

 Policy 4: Cebu City Allows Sharing of

Personal Identifiable Information (PII) and

Medical Status of Older Residents (over 14

Years Old) with Cebu Nation Response

Coordinators and Cebu City Care

Providers, Precedence = 1, Specifically the

Shared Joined Data Set is Nation, First

Name, Last Name, and Medical Status, Plus

a Filter Constraint to only Share Persons

Whose Date of Birth is Prior to 2006.

To facilitate effective coordination of a response

to the disease, Cebu City decides to make an

exception to its default policy of not sharing any

personal data: it now creates a policy to share all

relevant information (name, gender, birthdate,

disease status). Policy 4 has a higher precedence than

Policy 3 and overrides it, but note that Policy 4 does

not replace Policy 3. The overriding mechanism

described in Section 2.2 ensures that the policy with

the highest priority is selected if there exist multiple

policies with opposing decisions from a single policy

authority. But there might still be many other records

related to residents (not shown in our CDM) and in

these cases the newly defined policy to release

This is simplified for presentation purposed, technically

the constrained would be expressed as a constraint on the

difference between the current date and the birth date.

medical information does not apply and thus the

default deny policy (Policy 3) would still ensure that

this information is appropriately protected.

As the data shared by Policy 4 contains personal

identifiable information (PII), the requesters are

further limited to the national response coordinator.

Thus, Policy 4 only shares these data with specific

requesters rather than all requesters (i.e., the requester

that is a member of the ResponseCoordinator

class and has the property

associatedNation(Cebu) and to the own

community care providers, i.e., the requesters that are

members of CareProvider and have the property

associatedCommunity(CebuCity)).

Due to the sensitive nature of this data, Cebu City

decides to protect the privacy of children even

stronger and thus only shares data of persons that are

over 14 years old. Our framework supports policies

that tailor sharing in sophisticated ways, such as

defining constraints to identify exactly which data are

shared. This is an example of a filter constraint: the

decisions issued by the PDP now have an additional

constraint “allow if age > 14.”

Note that the PDP

itself does not have access to the actual data (cf.

Figure 1), but attaches this constraint to the decision

so that the PEP can filter the retrieved data

accordingly before returning results to the requester.

 Policy 5: Cebu Nation Allows Sharing

Medical Status of All of Cebu City’s

Residents with Cebu City Care Providers,

Precedence = 0.

Policy 5 demonstrates another override. Due to

the dire situation, Cebu Nation, a national policy

authority with higher rank than Cebu City policy

authority, has written a policy to share all Cebu City

residents’ medical status. Even though this policy has

low precedence, the higher rank of policy authority

prevails. Thus, the effect of this additional policy is

that the targeted requesters will now be allowed to

receive medical PII of all residents including

children.

The policy specification is similar to the previous

one, the differences are: (a) this policy is specified by

the Cebu nation PA (instead of the Cebu City

Community PA), (b) the targeted requesters are

limited to Cebu City’s care provides (now excluding

the national response coordinator), and (c) there are

no constraints on the persons’ age.

Protecting Privacy during a Pandemic Outbreak

315

Vignette 3. The goal of Vignette 3 is to share not

accurate, but differentially private disease state

counts at community level. Differentially private

counts mean that not exact aggregates are shared, but

rather approximate aggregate counts. This provides

more privacy while still providing enough benefit to

the consumers of such data (e.g., care providers). For

example, in order to know how many resources need

to be provided at a certain location, approximate

counts of sick people are usually sufficient. On the

other hand, exact counts (together with auxiliary

information) could reveal individual private data

(Sweeney, 2000). Thus, being able to integrate

privacy-preserving technologies with the policy

framework is very attractive to policy authorities as

an additional means for fine-grained control and

protection of privacy. The policy of Vignette 3 makes

use of the ability to integrate our policy framework

with privacy-preserving technologies and illustrates

how data sharing policies can be written to use those.

 Policy 6: Share Differentially Private

Disease State Community-level Counts

with Epidemiologists. Precedence = 1,

Specifically the Shared Joined Data Set is

Nation, First Name, Last Name, and

Medical Status, Plus An Action Constraint

To Fuzz up the Counts using Differentially

Private Technologies.

The intention of this policy is to provide helpful

information to epidemiologists researching the

pandemic outbreak. Disease state information on a

community level could be very helpful for

epidemiologists across the globe to better understand

how the virus spreads and how the infections proceed.

However, sharing data globally with epidemiologists

significantly opens up the potential audience (and

thus significantly lowers the trust the released data

will not be exploited). Even if only community-level

count aggregates of diseases status are released, this

still bears the danger of potentially allowing for the

re-identification of specific individuals. To ensure

that personal information of individuals is sufficiently

protected, the released data should be protected with

differential privacy. This is specified through an

action constraint: Opposed to filtering constraints,

these types of constraints don’t restrict the records to

be released, but instead they prescribe necessary post-

processing actions to be applied to the data before it

is returned to the requester. In this particular policy,

it specifies that differential privacy must be applied to

the disease status counts before they are released to

epidemiologists. This ensures that epidemiologists

receive useful data for research purposes while at the

same time protecting the privacy of affected

individuals.

The policy demonstrates the incorporation of

differential privacy technology into the system. For

large data sets, it would be very difficult for anyone

to guess the medical status of an individual based on

the counts. However, sharing aggregate status counts

over much smaller data sets, creates the possibility

that requesters could begin to infer the status of

individual residents. Similar sensitivities have been

demonstrated in the current COVID-19 pandemic.

Positive cases are typically reported for whole cities

or sometimes whole zip codes, but finer aggregates,

or the status of individuals, are rarely if ever reported.

To combat this concern, differential privacy can

be used to add enough noise to the shared counts to

guarantee that individual status cannot be guessed to

a desired low probability. In this way, differential

privacy can be used to encourage more data sharing

by reducing fears that sensitive data may be guessed

from shared statistics.

4 RESULTS

The use case described in the previous section shows

how a fairly small set of policies can be used to

facilitate sophisticated data sharing that is tailored to

multiple simultaneous requirements. This capability

is enabled by making use of several key features of

the described system:

1. Using Joined Data Sets to concisely specify not

only which data attributes are shared, but also how

they are connected provides an easy method to

have fine-grained control over exactly what is

shared. This is well-illustrated by the policies in

Vignette 1: The goal is to share information that

connects nation names with medical information

about persons. However, without explicitly

specifying how these attributes are to be

connected, the policies’ intention cannot be fully

captured: if both properties are shared in isolation,

the result is barely useful because the connections

between person names and medical status is lost.

Allowing any combination of these two attributes

on the other hand would result in oversharing,

because it would not only allow the (intended)

sharing of nations’ residents’ information, but also

the (unintended) sharing of nations’ citizens’

information. Moreover, Policy 2 shows that the

detail level of the data (aggregation on nation-level

vs. community-level) can be changed easily by

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

316

allowing for additional joined attributes in the

shared data.

2. Defining policies based upon a shareability theory

allows the separation of general-purpose

specifications of data relations (such as subsets,

inverse properties, etc.) from situation-specific

policies. This approach significantly eases policy

specifications and reduces potential errors because

the policy authority can focus on the variable parts

and does not have to think through “common

sense” implications of policy specifications. For

instance, the shareability theory specifies that if the

sharing of some data set is allowed, then sharing of

all corresponding subsets of data is also allowed.

For example, if a response coordinator is allowed

to see community-aggregated data due to Policy 2,

this response coordinator is also allowed to see

nation-level aggregated data, even if the nation-

aggregated policy were disabled. Moreover,

considering inverse properties provides the ability

to address multiple different but equivalent

requests in a single policy. For instance, if a policy

allows sharing of information about “communities

and their residents”, it will also permit the

equivalent request for “persons and their residence

community.”

3. Addressing requesters in terms of attributes allows

for a very flexible and scalable way of tailoring

decisions to a wide variety of potential requester

types. Essentially, every element in the CDM that

can be connected to the requester class can be used

to address targeted requesters. For instance, both

policies in Vignette 1 specify that members of the

ResponseCoordinator class are allowed to see

data, but the second policy additionally requires

that the value of the requester’s associatedNation

property matches the PA’s nation. As a result, if

response coordinators request community-level

aggregated medical data, they will get a positive

decision only from their own nation, while a

request for nation-level aggregated data will result

in positive decisions from all nation PAs.

4. Making use of the overriding feature allows

sophisticated interactions between policies. This

ability facilitates specifying a succinct set of

policies that can yield a variety of different

decisions in different circumstances and also

allows flexibility in defining exceptions to policies

without requiring any changes to existing policies.

For instance, Policy 3 in Vignette 2 specifies that

no personal data of residents should be shared with

anyone. Next, Policy 4 defines that an exception

should be made under very specific circumstances,

i.e., specific personal medical information of

residents over the age of 14 may be shared with the

nation’s own response coordinators and care

providers.

Furthermore, hierarchy-based overrides show

how existing authority hierarchies can be used to

achieve centrally coordinated decisions within a

chain of authority. This ability is shown by Policy

5, where the Cebu Nation policy defines another

policy that removes the restriction from Cebu

City’s sharing policy for specific requesters

without disabling Cebu City’s policy. As a result,

all three policies in Vignette 2 are still valid and

serve requests from different requesters.

5. Two different types of constraints allow policy

authorities to further restrict access to and thereby

protect the privacy of the accessed data. Filter

constraints, such as requiring the date of birth to be

prior to some date, enable the release of only

subsets of the requested data that meet that

constraint. The age restriction used in Policy 4

ensures that the (more sensitive) data of young

children is filtered out in corresponding requests.

Action constraints on the other hand prescribe

additional post-processing actions that need to be

performed at the PEP before data is returned to the

requester. An example of an action constraint is the

requirement in Policy 6 to apply differential

privacy before data is released to the requester. A

noteworthy property of this constraint mechanism

is that neither type of constraint is evaluated at the

PDP, but instead, data sharing decisions containing

constraints are computed on an abstract level

without requiring access to actual data, and then

passed to the policy enforcement point. This

approach to constraints makes the architecture

particularly well-suited to privacy-protecting

technologies: first, the PDP can operate

completely without access to actual data, which

reduces the risk surface of potential privacy

violations. Second, and more importantly, this

approach enables the integration of privacy-

enhanced, encrypted data bases that are able to

perform query operations on the encrypted data

and only the final result gets decrypted, e.g., the

data of children in Vignette 1 or the non-noisy data

in Vignette 2 will never be decrypted. That is, a

constraint computed at the PDP becomes a part of

the encrypted query to the encrypted database, and

the constrained data never needs to be unencrypted

by any part of the system.

These sophisticated sharing policy features are

combined with an easily accessible user interface (St.

John et al, 2018, Briesemeister et al, 2019) to make

Protecting Privacy during a Pandemic Outbreak

317

policy specifications available to lay users. This

intuitive user interface allows policy authority users

to make use of the entire arsenal of policy features

without requiring detailed knowledge about the inner

workings of the policy decision point nor any specific

technical specification skills.

5 CONCLUSION

Enterprises need to share a wide variety of

information with their partners to pursue their

objectives. Their dilemma is that these data are often

sensitive, and protecting privacy is important. One

importance piece for resolving this dilemma is to

provide fine-grained specifications of exactly which

data to share with which partners so that only needed

data is shared. The methods for specifying data

sharing need to be expressive both for specifying the

data and specifying the requesters who may access

the data. Furthermore, the methods need to be clear

and easy to use by non-experts so that errors are rare

and easy to catch and using the methods does not

require specialized training.

Our methods meet both criteria. Here, we

described these methods in the context of a pandemic

use case. Policy authorities define data sharing

policies that specify which persons’ medical data, or

counts of those data, are shared with different classes

of data requesters.

Our methods include a sophisticated JDS

specification of which data types to share and what

constraints to apply, a shareability theory-based

approach to processing requests for subsets,

supersets, and inversely specified requests, an

expressive role-based specification of data requesters,

and a decision process that incorporates both

precedence-based and policy authority hierarchy-

based overrides. Importantly, this policy decision

point requires no access to the data contents in order

to makes these policy-based sharing decisions.

Enterprises using these methods may come to

share more data and thereby realize more objectives

because they can be confident that they can precisely

control which data are shared with who and how and

which data remain private from all others. This

enhanced sharing should be useful in a wide variety

of context, and vital in global emergences, such as

pandemics, where the appropriate, tailored sharing of

sensitive information is crucial.

Distribution Statement "A" (Approved for Public

Release, Distribution Unlimited).

REFERENCES

Martiny, K., Elenius, D., Denker, G., 2018. Protecting

Privacy with a Declarative Policy Framework. In 12th

IEEE International Conference on Semantic

Computing (ICSC), Laguna Hills, California, USA

St. John, M., Moore, R., Martin, A., Gustafson, W.,

Jaramillo, M., Denker, G., Martiny, K., Briesemeister,

L., 2018. Enterprise-Level Private Data Sharing:

Framework and User Interface Concepts. In 9th

International Conference on Applied Human Factors

and Ergonomics (AHFE) Orlando, Florida, USA.

Briesemeister, L., Gustafson, W., Denker, G., Martin, A.,

Martiny, K., Moore, R., Pavlovic, D., and St. John, M,

2019: Policy Creation for Enterprise-level Data

Sharing. In 21st International Conference on Human-

Computer Interaction (HCI), Orlando, Florida, USA.

Myers, K., Ellis, T., Lepoint, T., Moore, R., Archer, D.,

Denker, G., Lu, S., Magill, S., Ostrovsky, R., 2017.

Privacy Technologies for Controlled Information

Sharing in Coalition Operations. In 9th International

Conference on Knowledge Systems for Coalition

Operations, Los Angeles, California, USA

OASIS XACML Standard, Version 3.0, 2013

http://docs.oasis-open.org/xacml/3.0/xacml-3.0-core-

spec-os-en.html, last accessed 2020/06/12

Damianou, N., Dulay, N., Lupu, E., Sloman, M., 2001.The

Ponder Specification Language. In Policy 01:

Workshop on Policies for Distributed Systems and

Networks.

Ashley, P., Hafa, S., Karjoth, G., Powers, C., Schunter, M.:

Enterprise Policy Authorization Language,

http://www.w3.org/Submission/2003/SUBM-EPAL-

20031110/, last accessed 2020/06/15

Kagal, L., Finin, T., Joshi, A., 2003. A Policy Language for

a pervasive Computing Environment. In Policy 03: 4th

International Workshop on Policies for Distributed

Systems and Networks.

Uszok, A., Bradshaw, J., Jeffers, R., 2004. KAoS: A policy

and domain services framework for grid computing and

semantic web services. In: iTrust 2004, Second

International Conference on Trust Management.

Kagal, L., Hanson, C., Weitzner, D., 2008. Using

dependency tracking to provide explanations for policy

management. In 2008 IEEE Workshop on Policies for

Distributed Systems and Networks, pp. 54–61.

Becker, M., Fournet, C., Gordon, A., 2010. SecPAL:

Design and semantics of a decentralized authorization

language. In: Journal of Computer Security, vol. 18/4,

pp. 619–665.

Sweeney, L., 2000. Simple Demographics Often Identify

People Uniquely. In Data Privacy Working Paper 3.

Pittsburgh.

St. John, M. F., Pankova, A., Denker, G., Laud, P., Martiny,

K. & Pavlovic, D., 2020. Decision Support for Sharing

Data Using Differential Privacy. Manuscript/Under Re-

view.

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

318
