Experiences and Recommendations from Operating a Tor Exit Node

at a University

Michael Sonntag

and René Mayrhofer

Institute of Networks and Security, Johannes Kepler University Linz, Altenbergerstr. 69, 4040 Linz, Austria

Keywords: Anonymisation, Tor Exit Node, Legality, Public Perception, Recommendations.

Abstract: We report on a multi-year operation of a Tor exit node at a public university and provide recommendations

for running other instances. These include legal issues, such as permissions perhaps required in advance, and

where potential pitfalls are, like blocking content/DNS resolution or monitoring/logging requirements. We

also discuss organizational aspects including preparations for inquiries and problem reports, how to avoid

issues with potential legal enforcement, or who should have access to which systems. Technical issues are

discussed in detail, including lessons learnt from DoS attacks both on the university as well as the exit node

in particular. Finally, we provide technical and organizational recommendations on longitudinal data collec-

tion and other research on exit node traffic without compromising anonymity.

1 INTRODUCTION

Our university institute operated a high-bandwidth

Tor (Dingledine et al., 2004) exit node for several

years and performed research – particularly statistical

traffic analysis – on it. Tor is an anonymisation sys-

tems based on routing encrypted traffic across multi-

ple nodes, each of which strips away an encryption

layer. Observers in the Internet (or server operators)

therefore see (only) the IP address of the last (=exit)

node as the system requesting some data, but not the

actual originator. Misuse can be tracked back to the

exit node, but not any further

For reasons detailed below, this has now stopped.

At the beginning, such a project was considered

highly controversial and a big risk by many relevant

stakeholders, but our experiences showed that these

were mostly unfounded, although we were not able to

convince everyone of the relatively low risk of oper-

ating a Tor exit node. Issues that led to the highest

amount of discussions were spread throughout differ-

ent concerns: legal (Is this allowed at all? Is it “con-

tributing to illegal acts” and therefore exposing the

university to potential liability?), organizational

(How to ensure that in case legal problems arise there

is no impact on the rest of the university? How not to

https://orcid.org/0000-0002-2506-2350

https://orcid.org/0000-0003-1566-4646

compromising anonymity and still perform re-

search?), technical (Might we become an attack tar-

get? How does the normal operation – or any attacks

– impact the university network?), and public percep-

tion (What media opinion pieces might this generate?

Does the general public perceive anonymity as posi-

tive or negative?).

In this paper we report on the project and provide

recommendations and lessons learnt from it, so that

others can more easily start and operate a Tor exit

node.

2 LEGAL ISSUES

Operating on solid legal ground is an obvious precon-

dition; therefore, we proactively verified the current

legal situation on multiple fronts: First, we checked

whether it is legal at all to provide such a service in

Austria, and if yes, whether some kind of registra-

tion/permission/etc is needed. We could confirm that

a) it is legal to operate an anonymizing network

packet forwarding service, and b) that no explicit per-

mission or registration is a precondition for such op-

eration (Sonntag, 2015). This may be different in

other jurisdictions, but is probably consistent within

Sonntag, M. and Mayrhofer, R.

Experiences and Recommendations from Operating a Tor Exit Node at a University.

DOI: 10.5220/0010156802830290

In Proceedings of the 7th International Conference on Information Systems Security and Privacy (ICISSP 2021), pages 283-290

ISBN: 978-989-758-491-6

283

the EU. Other typical legal “dangers” are, and should

therefore be answered (in our case negatively):

* Operating a Telecommunication Service: Such a

service transmits third party data from an external

source to an external destination, i.e. it is no endpoint

but a relay – similar to an upstream ISP. This “carrier”

service could be regulated and require registration or

licensing or be subject to oversight etc. The important

part here is, that there is no contractual binding to any

of the communicating parties (additionally, the end-

user is explicitly not known to the service).

Recommendation: No explicit action needed in Aus-

tria, but registration or an operator license may be re-

quired in other jurisdictions.

* Monitoring Obligations: The service might be re-

quired to investigate all or certain traffic for some un-

desirable content. This might be independent of

whether this is possible at all – although the outgoing

traffic of an exit node is “cleartext”, it can still be

HTTPS and therefore encrypted. As we are not the

operator e.g. of a cloud service, respective keys to de-

crypt and investigate are not in our sphere of influ-

ence. Note that aside of a MitM attack no “retention”

and therefore disclosure of cryptographic keys is pos-

sible – this is end-to-end encryption. The type (e.g.

chat, web browsing, or file download) of content

might still be recoverable, e.g. from time and traffic

amount analysis (Lashkari et al., 2017).

A typical example would be blocking pornogra-

phy (e.g. the UK Digital Economy Act, 2017). This is

potentially problematic, as e.g. the UK law applies to

ISPs and “ancillary service providers” (see section 21

5 b) giving access to such content to persons in the

United Kingdom. Depending on jurisdiction, this

could therefore also apply to Tor nodes in other coun-

tries – although these do not know in any way in

which country the end-user who uses the exit node is

located. Also, an exit node probably doesn’t profit

from the mere-conduit-exception of liability in Art 12

of the E-Commerce directive (still optimistic Minarik

and Osula, 2015). The CJEU judgment from

15.9.2016, C-484/14 – Mc Fadden, made clear that it

only applies to services provided for remuneration,

even though these could be “unrelated” (e.g. a restau-

rant providing free Internet access to its paying cus-

tomers). As exit nodes do not have any business re-

garding the unknown end-users – especially if oper-

ated by a publicly funded university – this does not

apply (note that in Austria this exemption was explic-

itly extended to free services: ECG § 19 Abs 2).

Recommendation: For exit node operation no moni-

toring should be required, as resulting logs would be

(mostly) meaningless to usual monitoring cases.

* Content Blocking Requirements: Blocking of cer-

tain content might be required, both from fixed lists

(updated e.g. by courts) as well as ad-hoc (court judg-

ments, information from rights holders etc) in various

ways (Lodder and Polter, 2017). This can also include

the requirement to start ongoing monitoring for iden-

tical or similar content. Note that while a large

amount of exit traffic is encrypted, according to our

experiences this does not cover the entirety (25-35%

remains unencrypted web traffic at the time of this

writing). Additionally, the appropriate infrastructure

might be required anyway (for the possibility that

such a problem may arise in the remaining clear-text

traffic). This could perhaps be reduced/avoided by

limiting traffic to encrypted services only – so that

any kind of inspection and therefore blocking is im-

possible anyway. However, that would significantly

reduce the utility of an exit node at this time, and we

therefore decided to explicitly allow cleartext traffic

to be forwarded. Note that blocking and monitoring

might be combined: blocking “inappropriate” traffic

and simultaneously logging all such requests.

Recommendation: We believe that within the EU no

a priori content blocking needs to be implemented. In

specific cases as ordered by a court of law, blocking

selected targets may become necessary. Avoiding this

may be easiest implemented using a narrow exit pol-

icy disallowing any cleartext traffic (with the obvious

disadvantages for the network).

* DNS Blocking: Blocking might not take place on

the content level, but also on the DNS resolution

level, which is the typical case today for e.g. copy-

right infringements (Geiger and Izyumenko, 2019).

As exit nodes also perform DNS requests for end-us-

ers, “lying” to block specific (web)sites might be nec-

essary. This, like the previous category, could per-

haps be passed to the upstream provider: if it is in the

same country, then all exit node traffic has to go

through their network too. But such obligations might

only apply to them for servicing “end-users” – which

an exit node could be argued not to be (i.e. an ISP

might have to filter traffic of private homes/busi-

nesses, but perhaps not traffic from other ISPs, espe-

cially international ones). Otherwise, implementing

DNS blocking is relatively easy on the technical level

if the exit runs its own DNS resolver as recommended

(Tor-DNS 2019), because DNS resolution can other-

wise be a significant privacy problem (Greschbach et

al., 2017).

Recommendation: We believe that no a-priori DNS

blocking infrastructure needs to be implemented by a

Tor exit node operator, and that relevant legal re-

quests may typically be better addressed by the re-

spective upstream provider if necessary.

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

284

Another aspect is preparation for “legal” inquir-

ies, i.e. if a national law enforcement agency contacts

the service operator because its IP address was found

on a child pornography server, someone distrib-

uted/downloaded/shared a movie, or some offensive

message was sent (mail, forum post, comment…).

These might originate from public officials (police,

courts, administration), but also from private persons.

Recommendation: Prepare an easy-to-understand

(for non-experts) explanation of the Tor system and

why you are technically unable to answer any re-

quests for end-user data, and what their other options

are (if any). This should be readily available, e.g. on

a website. In our experience this was not a problem,

as the few official persons contacting us knew per-

fectly well what Tor is, and lost all interest as soon as

they were informed about this fact. This was similarly

true for the private persons that contacted us, which

either knew what Tor is or were sufficiently informed

to not contact us again by our (automated) response.

2.1 Improving Legal “State of the Art”

Whether something is “state of the art” is an im-

portant concept from the legal point of view: “State

of science” (also called “best available techniques”)

aspects can easily be disregarded and do not have to

be implemented in most areas of business (see

BVerfG, 1978 for the source of this differentiation).

Companies might not have to actually implement all

of the “state of the art” either, but it is mandatory to

“consider” it. This means, if you choose not to follow

recommendations from this level, you need an expla-

nation as to why not (which may typically include “it

is too expensive” or “it would disrupt core business”).

“State of the art” still requires “practically tested” and

“sufficiently proven”, i.e. it must have been used in a

wider area or to a larger extent (not only tested in a

laboratory or a single special instance) and has

worked sufficiently well for a longer span of time

(Weidenhammer and Gundlach, 2018). At least in

Austria, Tor was (because of the world’s first court

proceedings on operating an exit node, where the op-

erator was found guilty) seen as neither: (practically)

nobody operated an exit node (at least not openly),

and its operation (effort required, potential problems

etc; but not that it is technically possible and works as

intended, which was accepted) was not proven either.

In this sense we provided a significant contribu-

tion to the “state of the art” in Austria, and perhaps

even to a wider (e.g. EU) jurisdiction: operating a Tor

exit node was proven to be practically possible for a

long time without significant drawbacks or problems,

neither technical, nor legal, nor organizational.

Through our successful operation and the publicity it

is now proven that it works not only on the computer

science level, but on a practical level too, transition-

ing the operation of a Tor exit node from the concept

of “state of science” to “state of the art”. Conse-

quently, if discussing techniques to improve privacy,

considering the Tor system will now be a mandatory

element that can no longer be ignored. It might not be

used, but then arguments are needed why. These will

usually have to be technical (latency etc), as our ex-

plicit lack of bad experience in terms of legal/organi-

zation aspects renders arguing on those grounds dif-

ficult. Financial reasons are limited too, as the neces-

sary hardware is very cheap (at least for any kind of

business venture), and personnel costs are low be-

cause little work is needed for installation as well as

operation.

Recommendation for Operators: No specific action

is needed, because our successful multi-year project

with very little actual risk or damage has set a prece-

dent that operating a Tor exit node in Austria (and

therefore the EU) is now “state of the art”.

Recommendation for Other Services with Ano-

nymity Needs: Because the Tor system is now “state

of the art”, it needs to be considered as one potential

solution for anonymous communication and service

access, e.g. by providing an Onion service (Goulet et

al., 2013) or relaying client/server connections

through the Tor network.

3 ORGANIZATIONAL ISSUES

From the organizational point of view, several pre-

cautions should be taken for an exit node that are not

necessary for an entrance or middle node. Some of

them might be easier at a university, where personnel

of the same organizational level are more common

than in a company with a strict hierarchy, but these

should still be considered. These recommendations

serve to increase security both in a technical sense as

well as from a legal point of view.

First, the group of persons with access to the hard-

ware should be kept as small as possible: hardware

manipulation can remain undetected electronically,

and most servers have ample space inside to introduce

additional small devices. This requires physical sepa-

ration of the exit node from other systems. This ap-

plies to the whole “system”, i.e. a firewall dedicated

to it, a switch/router, DNS server, the exit node itself,

and any statistical monitoring or other components re-

cording research data. It does not apply to the “gen-

eral” parts, i.e. everything where merely data is trans-

ported but not acted upon – which are identical to the

Experiences and Recommendations from Operating a Tor Exit Node at a University

285

untrusted “public Internet” anyway. Therefore, the

exit node hardware up to and including its boundary

gateway to public systems needs to be secured. In our

case this was a physically separate room, but variants

are of course possible too, like wire cages or locked

racks. This has the additional advantage that in case

of a legal order to confiscate hardware equipment for

analysis the damage can be isolated to only the Tor

exit node components by clearly marking that the rel-

evant IP addresses and data are all handled inside this

single room with no external dependencies. We did

not have to face such a situation during our multi-year

operation, but, based on prior legal action against a

Tor exit node in Austria, were prepared for it. We also

believe that this isolation (=mitigation against risk to

other systems) was a positive factor in gaining initial

permission to run the system within the university.

Recommendation: If possible, we strongly recom-

mend to physically isolate the whole system, either in

a separate room or at least a separate, locked rack.

Should physical and electronic access be sepa-

rated? Anyone with el. access can get at the data, but

this would also produce digital traces. However, sep-

arating access gives an additional person an oppor-

tunity for malicious behaviour (or, of course) simply

mistakes): voluntarily, or through bribes or extortion.

Recommendation: Merge all kinds of access (physi-

cal and digital) in as few persons as possible.

For both electronic and physical access, the four-

eyes-principle should be followed. For physical ac-

cess this results in double locks or in access to the

room separated from access to the rack/cage. Digi-

tally this is much harder, as typical access is via SSH,

which does not readily support this principle. A sim-

ple “circumvention” is to employ multi-factor authen-

tication and give each person only a certain factor,

e.g. one person knows the password, the other con-

trols the token/authenticator app etc. This works for a

simple “two-person” requirement, but not for more

complex “at least two out of N persons”. Unless spe-

cial custom software is used, we therefore recom-

mend this “simple” two-factor authentication to en-

sure that no single person can modify the configura-

tion, introduce additional software, or extract data.

While this might be possible for the exit node itself,

this can be more complicated (or even impossible) on

other devices. Firewalls might support such function-

ality, but for switches/routers it is uncommon. If the

setup is possible without such devices, this should be

preferred. This might not necessarily be easy, as a

webserver (information about Tor/the exit node), a

DNS server (DNS lookups; support for blocking) and

a firewall (protecting these systems) need to be con-

nected. However, modifying the switch/router should

only rarely be necessary, e.g. in case of a firmware

update. Therefore, an option is to forbid any elec-

tronic access and only allow physical access, e.g.

through a serial interface, porting the problem to the

physical four-eyes principle. Note that we did not

strictly enforce the four-eyes principle on the digital

level for all components, but that different adminis-

trative roles were assigned to different people.

Another issue is top-level permission to operate

an exit node. We did perform research on the node

and published the results in several venues, but sim-

ultaneously it was also a service for the public (una-

voidably and intentionally, as we could not produce

realistic traffic ourselves). We therefore obtained

prior, explicit permission from the university, which

turned out to be the biggest problem of all: technical

requirements could be solved easily, legal issues re-

quired some work and research, but posed no real hin-

drance either. This university permission was always

only granted for a single year (which is problematic,

as we had to design an experiment, prepare it and im-

plement it/collect traffic within this timeframe). The

last time, explicit permission was not granted any-

more until the time of this writing; we applied for it,

but, repeatedly, no decision was made. No specific

other data, plans etc were requested (already included

in application), so we couldn’t “remove” the barrier

for a permission. As we found out later, the univer-

sity’s biggest fear was bad publicity (see below).

A contributing factor could have been that we did

not manage to obtain third-party funding for running

the exit node – we did not require any expensive hard-

ware (a 5-year old server that was phased out by the

central IT department was deemed more than suffi-

cient, reducing add. hardware cost to close to zero) or

software. The university also did not have to pay for

the traffic (which was donated by the network pro-

vider, so in a sense we did obtain external funding).

Direct costs involved were trivial and borne by the

institute (no university funding), but no external grant

money was flowing into the university either. The

publications and publicity originating from the oper-

ation were sufficient and useful for researchers and

department – and hopefully the scientific community.

Recommendation: Engage with all stakeholders (IT

services, upstream provider (in our case ACOnet, the

Austrian academic network), legal and public media

outreach departments) and apply for explicit permis-

sion to run an exit node before commencing its setup

and operation. If permission is only granted for a lim-

ited duration, apply early for extensions.

Another recommended precaution is preparing

and testing to block all traffic to/from the exit node

from the outside. While there was a DoS attack

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

286

against the university (different from the one de-

scribed below; this was targeted at the whole univer-

sity, not specifically the Tor node), we were cut off

first: “unnecessary” traffic is shed first if bandwidth

gets limited. Technically, this can be done in various

ways, e.g. shutting down the exit node or unplugging

it. As the persons capable/allowed to do this might not

be available (or as quickly as necessary), interrupting

traffic on routers/firewalls should be prepared. This is

technically easy, but should be tested and guidelines

for when this can/should be done instituted.

Recommendation: Prepare a “crisis situation” plan

to quickly deactivate network access to the whole sys-

tem while the situation is analysed and other steps can

be prepared. Documenting how to turn off central

power or unplug the boundary gateway from the main

network for admin staff is a perfectly valid approach.

3.1 Contact with Public Authorities

Contact with public authorities was very rare. As dis-

cussed above, they seemed to know exactly what Tor

is, and what data we therefore could potentially pro-

vide to them (i.e. nothing useful). This also led to no

additional contacts like physical visits, searches, con-

fiscated hardware, etc. However, this might partially

be caused by being a public university (which does

have a legal department – and a legal faculty, can

reach out to the public, has experience with publica-

tions, and has connections to politics). Experiences of

private person as operators might vary.

Recommendation: A large, publicly funded, and

generally considered trustworthy institution is a per-

fect place to run a Tor exit node. Smaller organiza-

tions may potentially face more pressure.

In terms of an added organizational precaution we

initially implemented, that we don’t know how effec-

tive it was: a separate domain name/IP address range,

with matching WhoIs entries. These included that this

was a “Tor research” project. If our IP address was

found, querying the WhoIs database might be a very

early and quick investigative step. Whether this was

enough to discourage actual inquiries (or they were

still made in spite of a “suspicion” of this being a Tor

exit node), is unknown. Still, we would recommend

doing this, as it could reduce the number of contacts

and doesn’t impose direct cost if separate IP ranges

are available. The only drawback is, that the node

could more easily/quickly end up on a list of “exit

nodes”, which are blocked/delayed/require additional

confirmation etc. But as exit nodes are public anyway

and their IP addresses can trivially be downloaded

(while the WhoIs is more restricted and has no fixed

format for noting such data!), this seems irrelevant.

Recommendation: If organizationally available, as-

sign a distinct IP subnet and reverse lookup domain

to the Tor exit node. Set WhoIs information appropri-

ately (noting in text fields that this is a Tor exit node)

and define an “abuse” email contact separate from the

main IP address range used for the rest of the network.

Recommendation: Use a ticketing system to system-

atically handle incoming abuse/inquiry email re-

quests with an auto-reply explaining that this is a Tor

exit node (e.g. with the template explanation of what

it does) and that there is no personal data available.

The auto-reply could mention that another request (by

replying to this auto-reply) would trigger a manual re-

sponse by the node operator team. Although the total

number of “manual” inquiries was extremely low - so

this might not be significant - we did not every receive

a repeated inquiry from the same institution.

3.2 Continuous Effort Required

Apart from research, continuous effort required to run

the exit node was moderate: the node itself needed lit-

tle attention (e.g. SW updates), but answering every

single abuse report required significant time. This we

promised to do to the university admin., to ensure that

we didn’t run into any problems (and the number/type

of inquiries we received was in scope of our research

topic). But practically all reports were created fully

automatically and we did not ever receive any mean-

ingful replies. This could be because nobody read our

standard replies, or nobody cared because they were

about a Tor exit node, and so they could not pursue

their inquiries anyways. Additionally, nearly all of

them were reports about password tries to SSH serv-

ers. Such attempts are extremely common even on the

normal network - and not really a cause for serious

concern. After we removed port 22 from our exit pol-

icy, such reports, and the associated work, disap-

peared for all practical considerations.

Recommendation: Either not allow port 22, or at

least filter out (and ignore) all reports about this port.

Note that SSH traffic is only a tiny part of the traffic

regarding bandwidth, but produces practically all

complaints. Additionally, contacting a service where

you have to explicitly identify yourself securely is

only rarely useful anonymously (and so the utility of

a Tor exit node is not limited significantly by disal-

lowing SSH traffic): hiding the source IP address or

the fact of using that server/service. Most of these re-

ports originated from fail2ban, which was often mis-

configured too (e.g. no IP address/hostname of the

server included, or no E-Mail address to reply to).

While no effort was expended by the team at the

university, there was an incident where a DoS attack

Experiences and Recommendations from Operating a Tor Exit Node at a University

287

was performed against the exit node. This was de-

tected and averted at the boundary of the Austrian ac-

ademic network (ACOnet). As it was a naïve DoS at-

tack, the effort was probably also small at that insti-

tution – however this is not something that has to be

the case every time (see Jansen et al., 2019 for more

complex attacks on both individual nodes as well as

the whole Tor network). A more sophisticated (or

larger/longer) attack would cause problems or poten-

tially require more effort to reduce it, or even com-

mercial services to help against it. And while this net-

work of all Austrian universities (and other educa-

tional institutions) could come under attack for many

reasons, a Tor exit node could be an additional cause.

The DoS attack was solely directed at the exit

node (no other systems or nearby IP addresses were

attacked) and had a maximum of 15,1 Gbit/s (1,8

Mpps), so was quite large even for a “normal” com-

mercial network, but not internationally significant. It

lasted for 31 minutes and only consisted of UDP

packets targeted at various unprivileged ports. It was

uniquely simple in the sense that approx. 75% of all

traffic originated from only four IP addresses (and

there mostly from two), while the rest was highly dis-

tributed. It also seems that every source IP address

used only a single source port. Moreover, 91% of all

traffic originated in a single AS in Poland. Almost all

traffic was simply UDP packets of 1050-1200 bytes

length; only tiny parts were IP fragmentation or

CLDAP amplification attacks. These properties made

it comparatively easy to protect against at the network

ingress. There was no communication regarding the

attack, i.e. no demand for anything, no “warning” or

anything else: it simply started and soon after ended.

4 TECHNICAL ISSUES

Because of the potential for problems, both legal and

technical, as described above, we recommend a sepa-

ration from other aspects of a company’s organization

(such as the university) as far as possible. This in-

cludes a separate domain name (easy and cheap) and

a separate IP range (difficult and potentially expen-

sive with IPv4, but should not be a problem with

IPv6). Physical separation, or at least very clear mark-

ing, is also recommended to avoid potential collateral

damage. This might be problematic with “shared”

equipment, like a switch or a firewall. We therefore

recommend to employ either completely general sys-

tems (e.g. a firewall for everything, with no special

handling for the exit node), or dedicated systems.

This might be less useful for a switch/router, as there

no meaningful content can be expected, but this de-

pends on the technical expertise of the personnel po-

tentially tasked with investigating/impounding hard-

ware. But operating an exit node as a virtual machine

on a hardware together with other business-critical

VMs is carries high risk – the police might not

know/care and inspect/impound the whole physical

server. To avoid having to set aside a physically sep-

arate firewall, OS built-in firewalls can be used and

configured, and e.g. a direct cable for the communi-

cation with a separate DNS resolver. The easiest ver-

sion to implement is however, if the exit node is phys-

ically the same system as all other elements, either

because everything is a separate service on one OS,

or virtualization is used (i.e. the exit node and

DNS/web/… servers are VMs on a dedicated hard-

ware server). We do not recommend the latter, as it

provides a chance to obtain data from inside the exit

node, without the node itself being able to protect

against. This might also take place inadvertently, e.g.

by virus scanners integrated into the hypervisor and

scanning the content of the virtual machines (and po-

tentially passing it on to cloud services for analysis).

A basic precaution is to ensure that no personal or

content data is stored at all and not longer than neces-

sary, i.e. log files should not be created or stored. This

applies also to security devices like firewalls and can

be problematic as not all products support turning off

all kinds of logging completely.

Recommendation: Explicitly disable all logging and

monitoring not required for the operation of the Tor

exit node or obtaining the research data in scope of

the current experiment. This will lead to a non-stand-

ard configuration on most systems, but mitigates

other legal and organizational risks and effort.

Additionally, while devices dedicated solely to

the exit node can be adapted comparatively easily –

they are after all close by and usually under the same

control – the same might not apply to organization-

wide elements. For instance, all traffic of the univer-

sity has to pass through an IDS system, and turning it

off for the exit node was not possible. This was seen

as acceptable, as it only blocks attacks according to a

list of known attacks or known bad systems (no heu-

ristics). Moreover, it does not log any “normal” traf-

fic, only a few statistics on detected (and blocked) at-

tacks. If such systems exist, it must be closely verified

whether they pose a danger to privacy regarding the

exit node, or whether they can be turned off for this

part of the network – which is typically a policy issue.

Recommendation: If central systems can be influ-

enced as part of operating an exit node, either apply

policies of no monitoring or no specific policies for

the node itself, treating it like all other client systems.

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

288

The most important technical question for running

a Tor exit node is the bandwidth required, which is a

problem for the whole Tor network (Panchenko et al.,

2010). Unlike normal end-user systems (typically

much more download than upload, or in case of up-

loading backups to remote storage exactly the re-

verse) a Tor exit node always produces symmetric

traffic: the amount of data going in is the same as the

outgoing traffic, as it merely acts as a relay (HTTP

requests might be small, but they enter encrypted

from “inside” the Tor system and exit unencrypted to

the Internet, and while web content is large, it enters

in clear from “outside” and exits encrypted inside).

Additionally, as a Tor node should serve a large num-

ber of users to improve anonymity, its bandwidth

should be large. All elements combined, symmetric

traffic of many users with high bandwidth results in a

permanent traffic without interruptions. The amount

of traffic can therefore quickly become significant to

the whole organization, even for institutions with

many employees. According to information we re-

ceived informally, the network traffic of our univer-

sity to/from outside of the Austrian university net-

work (inside, i.e. to other universities, very large data

transfers of various research data seem to take place)

doubled because of our 200 Mbit/s exit node, i.e. pro-

ducing the same “external” traffic as approx. 15,000

students and 6,000 employees. If ACOnet had not

classified the traffic caused by our Tor exit node as

research project traffic, the university would not have

granted permission to run it because of the significant

additional traffic cost. We therefore (again) thank

ACOnet for it support of our multi-year project.

Recommendation: Prior to activating a Tor exit

node, estimate the total traffic bandwidth and volume

and ensure that traffic cost can be covered long-term.

This is the single most important cost factor for the

operation of a Tor exit node.

5 PUBLIC PERCEPTION ISSUES

Public perception of anonymization services is highly

ambivalent. On the one hand, privacy concerns have

become far more significant in the last 2-3 years due

to well-publicized abuses of surveillance and data

collection (Szoldra, 2016; Gibbs, 2015; Collins,

2020; Puig, 2020). On the other hand, some public

media articles have linked anonymization services in

general and Tor in particular to scary-sounding topics

like the “Darknet”, “terrorism”, “child pornography”,

“drug markets”, “illegal weapons”, etc (Power, 2020;

Fariva and Blankstein, 2019). Common (mis-)con-

ceptions of “nothing to hide, nothing to fear”, law en-

forcement “going blind”, or that the Internet should

not become a “lawless place” make decent headline

material but do not generally promote an informed,

nuanced, and helpful public debate. Therefore, public

perception of an organization running a public anon-

ymization service is, for all practical matters, unpre-

dictable and can change quickly – e.g. any local news-

paper could write that the university is actively help-

ing criminals and transporting child pornography.

Permission to continue to operate the Tor exit

node by the university would probably be granted

without a time limit if we could guarantee that this

kind of publicity would never happen. Unfortunately,

this is impossible to guarantee or merely estimate. We

provided a list of reasons, why such an exit node is

important not only for research, but also society, so

that a “response” for a bad-press incident was already

prepared – but this was not considered to be sufficient

to mitigate the publicity risks to the university. After

more than 7 months and multiple tries with additional

arguments in favour of continuing the project, a deci-

sion on the permission to operate the exit node was

again postponed. Even if the request was not declined

or the operation prohibited, no decision is a decision

too, and we therefore shut the project down (the serv-

ers were already deactivated earlier when the last per-

mission ran out). It should be noted that no such bad

publicity did occur during operating the exit node –

the mere fear of such an incident potentially occurring

at some point in time was enough.

We explicitly note that we do not blame the uni-

versity administration for the hesitancy in accepting

the unpredictable risk of public perception, but docu-

ment this reason for discontinuing our project to help

other operators prepare for this issue. In a period of

post-factual (social) media reporting, every organiza-

tion must decide on its own prioritization of how

(pot.) public perception influences its goals, including

research and open debate of controversial topics.

6 SUMMARY

Although we cannot operate the Tor exit node any-

more, there are now several other exit nodes in Aus-

tria, which were started based on our positive experi-

ences. Based on the communication with them and

their informal feedback we deem it very unlikely that

these would have been created without our prece-

dence, and testing the legal and technical operation.

These can serve as an example of moving a technol-

ogy from state of science to state of the art, and to-

wards “normal business”, i.e. something that can be

Experiences and Recommendations from Operating a Tor Exit Node at a University

289

operated without difficulties. This broadens the base

of relays and additionally moves operating an exit

node closer to end-users, which would improve over-

all performance and anonymity (Ngan et al., 2010). If

all end users simultaneously act as exit-nodes with

their excess bandwidth, that would provide plausible

deniability for their own traffic too.

It is also important to note that we only offered an

exit node, i.e. a relay to the public Internet. There was

never any question of hosting hidden services for

third parties, as this would have exposed the univer-

sity to much larger legal dangers as a hosting pro-

vider. Similarly, although we of course participate in

the operation of hidden services as any other Tor

node, we did not provide any directory or list of onion

URLs or similar: while not hosting the content,

providing directions to them would still have required

investigating/checking each of them for legality.

We can therefore conclude that operating a Tor

exit node is easily possible from the technical point of

view, but the biggest problem seems to remain on the

organizational level. Nonetheless, our multi-year pro-

ject successfully established precedent to now make

operation of Tor exit nodes “state of the art” within

Austria and therefore within the EU. Legal ramifica-

tions in terms of having to consider Tor exit nodes as

a viable network anonymization techniques remain a

topic for future research.

REFERENCES

BVerfG 8.8.1978, 2 BvL 8/77 - Kalkar I,

https://dejure.org/dienste/vernetzung/rechtsprechung?

Gericht=BVerfG&Datum=08.08.1978

Collins, K., 2020. US-EU Privacy Shield data-sharing pact

invalidated https://www.cnet.com/news/

us-eu-privacy-shield-data-sharing-pact-invalidated-

over-surveillance-fears/

Dingledine, R., Mathewson, N., Syverson, P., 2004. Tor:

The second-generation onion router. In: Proc. of the

13th USENIX Security Symposium (August 2004)

Puig, A., 2020. Equifax Data Breach Settlement,

https://www.consumer.ftc.gov/blog/2019/07/

equifax-data-breach-settlement-what-you-should-

know

Fariva, C., Blankstein, A., 2019. Feds take down world's

'largest dark web child porn marketplace'

https://www.nbcnews.com/news/crime-courts/

feds-take-down-world-s-largest-dark-web-child-porn-

n1066511

Geiger, C., Izyumenko, E., 2020. Blocking Orders: As-

sessing Tensions with Human Rights, In: Frosio, G.

(Ed.), The Oxford Handbook of Intermediary Liability

Online (OUP, 2020), 566

Gibbs, S., 2015. What is 'safe harbour' and why did the

EUCJ just declare it invalid? https://www.theguard-

ian.com/technology/2015/oct/06/safe-harbour-euro-

pean-court-declare-invalid-data-protection

Goulet, D., Kadianakis, G., Mathewson, N, 2015. Next-

Generation Hidden Services in Tor, https://git-

web.torproject.org/torspec.git/tree/proposals/224-rend-

spec-ng.txt

Greschbach, B., Pulls, T., Roberts, L. M., Winter, P., Feam-

ster, N., 2017. The Effect of DNS on Tor’s Anonymity.

NDSS ’17, Internet Society

Jansen, R., Vaidya, T., Sherr, M., 2019, Point Break: A

Study of Bandwidth DoS Attacks against Tor, Proc. of

the 28th USENIX Security Symp. 2019

Lashkari, A., Gil, G., Mamun, M., Ghorbani, A., 2017.

Characterization of Tor Traffic using Time based Fea-

tures. 3rd Int. Conference on Information Systems Se-

curity and Privacy, 253-262

Lodder, A. R., Polter, P., 2017. ISP blocking and filtering:

on the shallow justification in case law regarding effec-

tiveness of measures, European Journal of Law and

Technology, Vol 8, No 2

Minárik, T., Osula, A.-M., 2016. Tor does not stink: Use

and abuse of the Tor anonymity network from the per-

spective of law, Computer Law & Security Review,

Volume 32, Issue 1, 111-127

Ngan, T.-W., Dingledine, R., Wallach, D.S., 2010. Building

Incentives into Tor, In: Sion R. (Ed.) Financial Cryp-

tography and Data Security. FC 2010. LNCS 6052,

Springer, Berlin

Panchenko, A., Lanze, F., Engel, T., 2012. Improving per-

formance and anonymity in the Tor network, 2012

IEEE 31st International Performance Computing and

Communications Conference (IPCCC), 1-10

Power, M., 2020. Online Drug Markets Are Entering a

'Golden Age', https://www.vice.com/en_us/arti-

cle/dyz3v7/online-drug-markets-are-entering-a-

golden-age

Sonntag, M., 2015. Rechtsfragen im Zusammenhang mit

dem Betrieb eines Anonymisierungsdienstes, JusIT 6,

2015, 215-222 (ISSN 1996-8228)

Szoldra, P., 2016. This is everything Edward Snowden re-

vealed in one year of unprecedented top-secret leaks,

https://www.businessinsider.com/snowden-leaks-time-

line-2016-9

TorRelayGuide, https://trac.torproject.org/pro-

jects/tor/wiki/TorRelayGuide#DNSonExitRelays

Weidenhammer, D., Gundlach, R., 2018. Wer kennt den

„Stand der Technik“? DuD 2/2018, 106-110.

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

290
