Droppix: Towards More Realistic Video Fingerprinting

∗

Przemysław Bła

skiewicz

1,2

, Marek Klonowski

1,2

and Piotr Syga

1,2

Wrocław University of Science and Technology, Poland

Vestigit sp.z o.o., Poland

Keywords:

Watermarking, Video, Copyright Management, Intellectual Property Protection.

Abstract:

We present preliminary results for a way of video ﬁngerprinting that is different from typical methods based

on paradigms from watermarking of still images. Our approach is based on modifying some fragments of the

clip in a carefully chosen manner. We show the robustness of our approach against a number of typical of

attacks. The marks introduced by our modiﬁcations are almost imperceptible to the viewer and their impact

can be adjusted. Finally, our protocol is computationally light and can be combined with others schemes as an

extra security layer.

1 INTRODUCTION

With a rapid growth of multimedia market, the need

for preventing piracy is stronger than ever before. An

illegal redistribution of copyrighted content causes

signiﬁcant losses to its producers and providers. This

is the main motivation for constructing more and

more advanced audio and video ﬁngerprinting tech-

niques, that introduce individual marks into each copy

of a clip. Such mark (ﬁngerprint) can be then linked

with a legitimate receiver. If a video is illegally circu-

lated, e.g. retransmitted, the copy can attributed to its

associated legitimate user.

One of the ﬁngerprinting techniques for multi-

media is watermarking which leverages the fact that

bandwidth of digital video/image signals is much

higher that the amount of information available to

the human eye. The idea is to embed in each copy

of a movie or picture marks that are invisible to the

viewer, however can be easily detected by the copy-

right owner.

Designing methods of ﬁngerprinting one needs to

take into account that the watermarked content can

be subject to various attacks aimed at removing them

without signiﬁcant degradation of quality. That is, an

attacker aims at destroying the embedded message,

yet preserving the commercial value of the original

data. There are many transformations that could be

∗

This Work Is Partially Supported by the National

Centre for Research and Development (Ncbir) Project

POIR.01.01.01-00-1032/18 and Polish National Science

Centre – Project UMO-2018/29/B/ST6/02969.

viewed as an attack on the watermark, including rota-

tions, ﬂipping along the vertical axis or using various

ﬁlters (see e.g. (Asikuzzaman and Pickering, 2018)

for a list of possible attacks). In principle, an ade-

quate ﬁngerprinting method needs to provide at least

two features The ﬁrst is transparency – quality of

the image with embedded ﬁngerprinting information

cannot be signiﬁcantly worse than that of the origi-

nal. Ideally, the watermarked content is indistinguish-

able from the original one. Second fundamental issue

is robustness – it is expected that the ﬁngerprinting

method should be immune to all attacks that preserve

reasonable quality of the output. That is, the adver-

sary could be capable of removing the characteristic

mark only if the video or image is changed to such

an extent that it becomes useless for commercial pur-

poses.

While ﬁngerprinting methods designed for static

pictures seem to be very mature, there is still many

problems with securing video content. Many papers

treat video material as a sequence of static pictures

and a typical attempt to ﬁngerprint a video is to re-

place one such picture with any efﬁcient “static” wa-

termark. Even though such approach is theoretically

efﬁcient, it usually does not work in practice. The

majority of today’s video content is represented as

a GoP structure (ISO/IEC 23009-1, 2012; ISO/IEC

14496-12, 2011), with carefully chosen key frames

(IFrames) and vast majority of ﬁnally displayed im-

ages is represented as difference between the frames

(PFrames or BFrames). While it allows dropping re-

dundant data, an efﬁcient embedding a picture into a

468

Bła

skiewicz, P., Klonowski, M. and Syga, P.

Droppix: Towards More Realistic Video Fingerprinting.

DOI: 10.5220/0009876104680476

In Proceedings of the 17th International Joint Conference on e-Business and Telecommunications (ICETE 2020) - SECRYPT, pages 468-476

ISBN: 978-989-758-446-6

video can be impossible, since fragile changes can be

immediately removed by the encoder before ﬁnger-

printing marks are detected.

Our Contribution. In this paper we test an ap-

proach to video ﬁngerprinting that is more suitable

for real-life video content. The basic idea is to care-

fully modify some fragments of the video in a way

that is characteristic for each copy of a given ﬁlm.

Deletion is however not realised by removing frames

but rather fading out some short fragments. This ap-

proach preserves the quality of the original video in

a much better way and is almost imperceptible to the

viewers if implemented properly. In our method the

copy of a ﬁlm can be detected even by cam-coding

a ﬁlm displayed on a wide classes of devices. Our

protocol does not require any heavy computations for

embedding or detection, unlike some new and very

promising watermarking protocols based on machine

learning (rather for still images than video material).

To the best of our knowledge, the only similar ap-

proach to video ﬁngerprinting is presented in (Lee

et al., 2006) wherein the authors present a nice idea

of removing single frames from a movie. Note that

in contrast to the paper, we discuss the impracticality

of removing frames (cf. Sect. 3) and instead we mod-

ify their luminance. Moreover, we investigate a wider

spectrum of attacks than Lee et al. (cf. Sect 4).

2 PREVIOUS AND RELATED

WORK

Methods for Static Pictures. Methods of robust

ﬁngerprinting of digital content have been studied for

a long time. Majority of commonly used techniques

can be found in survey (Potdar et al., 2005). The

earliest methods of utilising transparent watermarks

relied on negligible modiﬁcations made to the spa-

tial domain of the image (e.g. modifying least sig-

niﬁcant bits (LSB) of the colour intensity (Fridrich,

1998) followed by (Tjokorda Agung B.W et al., 2012)

that enables RLE compression or statistical testing of

the mean intensity of the marked pixels (Nikolaidis

and Pitas, 1998)). Due to the robustness requirement,

coping with the effects of compression was of partic-

ular interest (Sebé et al., 2000). Often, when the in-

tensity modiﬁcation was made in the spatial-domain,

the authors resort to converting colour space (e.g., to

YCbCr (Patvardhan et al., 2018)), that allows more

signiﬁcant (i.e., more robust) modiﬁcations without

signiﬁcant visible changes. Note that transparency is

not always required; the authors in (Ping Wah Wong

and Memon, 2001) allowed a parameter that is re-

sponsible for visibility or the transparency of the wa-

termark, depending on the embedder’s intentions. In

order to allow more robust and transparent modiﬁca-

tions, many researchers turned to frequency-domain

alterations. Due to the nature of popular compression

algorithms, Discrete Cosine Transform was a primar-

ily investigated method (Hwang et al., 2003; Chang

and Tsan, 2005). In (Kingsbury, 2000), the author

introduced a concept of utilising Dual-tree complex

wavelet transform. This approach was followed ex-

tensively by (Mabtoul et al., 2007; Alkhathami et al.,

2013; Bhatnagar and Wu, 2013; Zebbiche et al., 2018)

among others. Another widely used technique is Sin-

gular Value Decomposition (SVD) (Gupta and Raval,

2012; Makbol and Khoo, 2013; Makbol and Khoo,

2014). Hybrid approaches, mixing the basic space-

domain methods like LSB with frequency-domain ap-

proaches were presented e.g., in (Sheth and Nath,

2016), watermarking in frequency-domain with utili-

sation of SVD (Gaur and Srivastava, 2017) or utilising

Hadamard transform with Schur decomposition (Li

et al., 2018). A new approach to watermarking was

introduced with the advent of neural networks and

deep learning. The authors of (Tsai and Liu, 2011)

combine the idea of wavelet transforms with utilis-

ing neural networks. In (Zhu et al., 2018) a novel

framework for end-to-end approach utilising an en-

coder and decoder with nosier layers was introduced.

The authors of (Wen and Aydore, 2019) presented the

notion of adversarial training, whereas (Zhong and

Shih, 2019) proposed a fully automated system for

images captured directly from the camera. An addi-

tional neural network was used in (Luo et al., 2020)

so that distortions improving robustness were added.

Methods for Motion Pictures. Majority of algo-

rithms for marking video material are based on a di-

rect application of methods constructed for still pic-

tures. The main ﬂaw of direct mapping of the static

image watermarking algorithms to motion pictures is

that the time-domain compression results, quite of-

ten, in deletion or distortion of the embedded water-

mark. Nevertheless, the authors of many watermarks

designed for videos followed the way paved by static

images, e.g. DCT (Sun et al., ), DT-CWT (Coria et al.,

2008), 3D Discrete Fourier Transform (Deguillaume

et al., 1999). In (Noorkami and Mersereau, 2005)

main focus was watermarking in H.264 compressed

domain and the authors of (Xu et al., 2011) use DCT

in order to gain robustness against H.264/AVC com-

pression. Somewhat different, and quite similar to

the one described in this paper (cf. 3) approach was

presented by (Lee et al., 2006), where certain frames

Droppix: Towards More Realistic Video Fingerprinting

469

from a movie are removed so that the pattern of

missing frames allows unique user identiﬁcation. An

object-based watermarking was introduced in (Swan-

son et al., 1997) and extended to scene in (Swanson

et al., 1998), whereas in (Lee and Seo, ) an adaptive

modulation is used. A robust, visual watermarking

has been proposed in (Zhang et al., 2007). More in-

formation on the techniques used in video watermark-

ing may be found in (Doerr and Dugelay, 2003; Bhat-

tacharya et al., 2006; Chang et al., 2011; Asikuzza-

man and Pickering, 2018).

3 DESCRIPTION OF THE

ALGORITHM

The general intent while working on the algorithm

was to embed a unique sequence into the movie, so

that the numbers retrieved from the sequence uniquely

identify the user leaking the movie. Such approach is

fundamentally different to the approach of adapting

static image watermarking to embed entire informa-

tion in a single frame. A natural idea to embed such

watermark is to add some mark on selected frames

and the number of the frames create a unique se-

quence. In order to cope with compression (both of

a single frame and time-domain) and provide some

level of robustness against attacks, one can go to the

extreme and remove certain frames (Lee et al., 2006).

Such approach has two major downsides: it is difﬁ-

cult to implement in a compressed movie (e.g. AVC

or HEVC) and often frame removal is simulated by

replacing it with a black one, which allows easy lo-

calisation by the adversary and “ﬁlling up the hole” if

they have access to another copy of the movie. Alter-

natively, the attacker can black-out few more frames

in order to mislead the decoder. To ﬁx it we can en-

sure that each copy not only has a sequence of frames

that are “missing” (either blacked-out or removed) but

also there is a frame that is not removed in only this

single copy. However, the second issue arises with the

ﬁx – such idea does not scale well with the number

of users. An average feature movie lasts around 100

minutes, which results in roughly 144000 frames. If

there needs to be a single frame that is unique to a

given user, the watermarking for only 100000 possi-

ble users requires removing the majority of the movie

for all the users. Due to the problems described above

and speciﬁc challenges presented by AVC or HEVC

compression when trying to remove a frame (espe-

cially problematic are the cases when two consecu-

tive frames in a single GOP are removed), instead of

removing the frames, replacing them with a black one

or leaving some visual macroartifact, we decided to

test if modiﬁcation of the luminance of a frame would

provide adequate marking capabilities.

Droppix. We start our algorithm with generating

S , a sequence of the frames to be watermarked. It

uniquely identiﬁes a user and is generated as a code-

word of their unique number. In the ﬁnal version

of the algorithm Reed-Solomon codes or Levenshtein

distance may be used to extend S to provide sufﬁcient

correcting power for cases when original frames from

S have not all been detected by the decoder or ad-

ditional ones have been falsely identiﬁed. Next, we

decode the movie in order to obtain a sequence of

frames. For each frame s ∈ S we perform the same

operations (Alg. 8). We start by converting the frame

into CIELAB colour space. Next, we multiply the L

component (lightness) of each pixel by a predeﬁned

constant α. Our test showed that in order for a ro-

bust, yet transparent watermark, the values between

0.92 and 0.97 can be used. We proceed with convert-

ing the frame back to BGR colour space and replacing

the resulting frame instead of s. When all frames in S

were modiﬁed, we code the movie back to the original

container using compression algorithm.

Data: M – movie to be watermarked, k – user

key (e.g. device ID), α – watermark

strength parameter

Result: M – watermarked movie

1 S ←SequenceGen(k);

, f

, . . . , f

←Decode(M);

3 for i ∈

{

1, 2, . . . , n

}

4 if i ∈ S then

f ←BGR2LAB( f

);

←

· α;

7 f

←LAB2BGR(

f );

8 M ←Encode(

, f

, . . . , f

);

Algorithm 1: Droppix: watermark embedding.

In order to decode the watermark, we need also

the original movie and the set of parameters used by

the embedding algorithm. We start by decoding both

movies to obtain respective sequences of frames. We

proceed by comparing pairs of corresponding frames

using structural similarity (Zhou Wang et al., 2004)

of their grayscale versions. Next, we calculate the

mean square error of the similarity distances for each

frame-pair in an array mse. In order to retrieve the

information on the frames that were watermarked we

establish a threshold of considered values and local-

ising the peaks of the normalised errors. The indexes

of the peaks are then subject to the reverse S generat-

ing algorithm in order to correct possible mistakes in

SECRYPT 2020 - 17th International Conference on Security and Cryptography

470

retrieving the information and to recover the user ID

of the leaker. The idea of the decoding procedure is

shown in Algorithm 2.

Data: M – original movie,

M – copy of the

movie with potential watermark, K –

set of user keys, t – acceptance

threshold

Result: k – user ID

1 SEtab←[];

, f

, . . . , f

←Decode(M);



, . . . ,



←Decode(

M);

4 for i ∈

{

1, 2, . . . , n

}

5 g ←RGB2GRAY( f

);

6 ˆg ←RGB2GRAY(

);

7 if StructuralSimilarity(g, ˆg)<t

then

8 mse ←MSE(g, ˆg);

9 SEtab.append(mse);

10 median←median(SEtab);

11 ∆ ←SEtab−median;

12 P←findPeakIndexes(∆);

13 k←SequenceGen

−1

(P);

Algorithm 2: Droppix: watermark decoding.

4 EXPERIMENTAL RESULTS

Corpus. In order to test our solution we gathered

a corpus of clips from various commercial television

broadcasts to be our testing body. They all were

H.264 encoded HD quality 120 seconds long frag-

ments. In each of those samples a watermark was em-

bedded using our method, and for each such marking

the numbers of frames that we used for watermarking

were stored.

Watermarking. Next, we checked how our water-

marking procedure changes values of mean square er-

ror (MSE), structural similarity (SS) and peak signal-

to-noise ratio (PSNR) calculated with respect to non-

watermarked clips. Fig. 1, shows the inﬂuence of

droppix parameter α on those indicators for an exem-

plary clip. One can tell that as α approaches 1, there

is smaller inﬂuence of the watermark on the parame-

ters, and hence detection success rate can be expected

to drop. More importantly, the watermarking leaves

a clear peak in all three values, a property we want

to maintain when the clip undergoes a modiﬁcation

attack.

Visual inspection of the inﬂuence of α resulted

in the following observations. For value 0.9 the

0

20

40

60

80

100

120

140

160

180

0 5 10 15 20 25 30 35 40 45

MSE

Framenumber

0.90

0.92

0.95

(a) MSE

24

26

28

30

32

34

36

38

40

42

0 5 10 15 20 25 30 35 40 45

PSNR

Framenumber

0.90

0.92

0.95

(b) PSNR

0.95

0.955

0.96

0.965

0.97

0.975

0.98

0.985

0 5 10 15 20 25 30 35 40 45

Structuralsimilarity

Framenumber

0.90

0.92

0.95

Figure 1: Inﬂuence of watermarking on MSE, PSNR and

SS values for different α.

modiﬁed frame can be slightly noted as ﬂicker, with

0.95 a (subjective) perception is marginal and de-

pends heavily on the particular scene the frame be-

longs to. On the other hand, as discussed below, for

values above 0.95 the success rate of detection dete-

riorates rapidly. Example original and watermarked

frames (for α = 0.92) and their difference are shown

in Fig. 2. Note that difference between “clean” and

watermarked frame is a uniquely almost-black rectan-

Droppix: Towards More Realistic Video Fingerprinting

471

(a) Original frame

(b) Watermarked frame

Figure 2: Example frame from testing clip.

gle, since the luminance of all pixels has been reduced

by the same (small) amount.

Attacks. The aim of the attack in our scenario is to

change PSNR, MSE and SS characteristics of the clip,

so that ﬁnding the frames used for watermarking be-

comes impossible.

From many possible attacks possible we chose six

to give a general idea about the performance of our

scheme. These attacks are easy to perform and as

such are more available to less experienced attackers,

and there might be more leaked content modiﬁed by

such simple means. The attacks we chose are in the

list below, and for each we provide a short rationale

for choosing it. All attacks kept other characteristics

(resolution, framerate, etc.) of the movie unchanged.

1. Transcoding from H.264 to MPEG-2 format and

downsampling to SD. Both these formats are pop-

ular and can provide good quality video. Due

to different methods of compression, transcod-

ing can effectively erase pixel-level modiﬁcations

used in other watermarking techniques. Since our

approach modiﬁes lightness (also a visual prop-

erty), we checked how different compression al-

gorithm inﬂuences detection.

2. Vertical ﬂip. This method is frequently applied to

counter watermarking techniques relying on spa-

tial information within a frame. Importantly, ver-

tical ﬂip can be visually acceptable for the viewer

as little content is lost and there are many exam-

ples of such content on the internet.

3. Globally increasing brightness. Since lightness of

a frame is our embedding technique, such attack

might limit our detection capability.

4. Slight rotation (1 degree). Similar to the vertical

ﬂip above, this attack yields visually acceptable

results to the viewer, yet is able to mis-lead wa-

termarking schemes utilising spacial information

of a frame. Because we utilise structural similar-

ity between frames as one of the decision factors,

we wanted to verify how such slight change might

affect detection.

5. Blurring. This is one of the common attacks

against watermarks embedded in pixel structure

of the frame. To test our approach with this at-

tack, we selected (subjectively) maximal parame-

ters for blurring both chrominance and luminance

channels so that the result was still acceptable to

the viewer as HD content.

6. Frame averaging. This is another popular tech-

nique of attack against watermarking. Essentially,

it is a low-pass ﬁlter applied to the movie so that

fast/sharp movement, which the human eye is not

capable of identifying is smoothed out. In our

tests we transformed each frame to be the average

of two consecutive frames, yielding still accept-

able results to the viewer.

All attacks were performed using ffmpeg in ver-

sion 4.2.2 and the implementation of the watermark-

ing and detection algorithms was done in Python with

OpenCV ver. 4.2.0 bindings and SciKit ver. 0.16.2

Testing Framework. Each clip from the corpus

was ﬁrst watermarked. Next, the content was modi-

ﬁed according to the attack scenario. Finally, both the

original clip and the watermarked and modiﬁed con-

tent were passed to watermark detection. In that pro-

cess, the PSNR, structural similarity and mean-square

error (MSE) for each pair of frames was calculated.

Next, frame numbers suspected as ones encoding the

watermark were selected. Finally, the chosen frame

numbers were matched against those stored for par-

ticular clip at the moment of watermark insertion. If

SECRYPT 2020 - 17th International Conference on Security and Cryptography

472

all frames have been found and no other – the trial was

deemed success. Any additional frames except those

determined by watermarking yielded a false-positive.

And ﬁnally, when not all watermarked frames were

found, the trial was considered failed.

Results. For the sake of presentation, the results are

shown for clips where watermark was embedded us-

ing frames number 10, 15, 20 and 22, which allows vi-

sual inspection of obtained data. There were 28 such

clips. Data presented in Fig. 1, 3, 4 and 5 correspond

to the same clip, so that relative change between non-

attacked and attacked/modiﬁed video can be traced.

Overall results are shown in Tab. 1. Columns

“success” and “FP” show the number of clips where

the watermark was identiﬁed, and where additional

frames were also selected, respectively. The column

“extra” presents the mean number of extra frames de-

tected and the column “σ” shows its standard devia-

tion.

It can be seen that the watermark embedding is

little inﬂuenced by brightness modiﬁcation, and much

less still by transcoding and down-sampling. Rotation

by a small degree makes the scheme more prone to

false-positives as well as limits the success rate. Ver-

tical ﬂip attack seems to be most effective against our

method, however, on closer inspection it was revealed

that MSE values calculated in this case were smaller

then average for frames used for watermarking than

for regular ones. This is exactly the opposite from

what has been observed for other attacks and conse-

quently our decoding algorithm was not able to detect

those negative peaks. This is illustrated in Fig. 3.

-600

-500

-400

-300

-200

-100

0

100

200

300

400

0 5 10 15 20 25 30 35 40 45

Deviation

Framenumber

vﬂip

brightness

mpeg2

rotate

blur

averaging

Figure 3: MSE deviation from average per frame for dif-

ferent attacks on the same movie. Watermark is inserted in

frames 10, 15, 20 and 22.

In general, the ﬂipping attack has the same impact

on PSNR and structural similarity indicators in that it

produces opposite orientation of peaks as compared

to other studied attacks (Figs. 4 and 5). Therefore, for

10

15

20

25

30

35

40

0 5 10 15 20 25 30 35 40 45

PSNR

Framenumber

vﬂip

brightness

mpeg2

rotate

blur

averaging

Figure 4: PSNR of frames for different attacks on the same

movie. Watermark is inserted in frames 10, 15, 20 and 22.

0.4

0.5

0.6

0.7

0.8

0.9

1

0 5 10 15 20 25 30 35 40 45

Structuralsimilarity

Framenumber

vﬂip

brightness

mpeg2

rotate

blur

averaging

Figure 5: Structural similarity of attacked frames to origi-

nals for different attacks on the same movie. Watermark is

inserted in frames 10, 15, 20 and 22.

this particular attacks our detection algorithm must be

adequately adjusted.

Interpretation of Results. Our preliminary results

on the proposed method for watermarking suggest

that it is immune against some popular and common

attacks on video content. While some aspects of the

detection method require a more evolved approach,

the tests support our claim about potential of this

method, particularly as a one-of-many methods used

concurrently on the same video content.

Building a fully functional detector requires more

samples and wider range of attack cases, or employ-

ing ANN as a decision maker based on a sequence of

tuples of the form (PSNR, MSE, SS) for each frame.

Different clips have different thresholds by which to

decide whether a given frame pertains to the water-

mark or not. As a consequence, the detector should

determine acceptance/rejection parameters on the ﬂy

and for particular clip, with only some initial startup.

Because our research was about testing the idea,

our testing scenario did not use redundancy codes

Droppix: Towards More Realistic Video Fingerprinting

473

Table 1: General detection results for 28 clips.

α 0.9 0.92 0.95

Attack success FP extra σ success FP extra σ success FP extra σ

brightness 28 0 – 28 0 – 28 9 5.88 1.36

vﬂip 0 27 3.22 2.79 0 25 3.25 2.81 0 27 3.28 2.71

mpeg2 + SD 28 3 1 0 28 3 1 0 28 2 1 0

rotate 23 28 4.14 2.42 20 27 3.96 2.8 16 27 4.07 2.22

blur 27 8 8 5.07 26 12 8.58 4.31 24 18 8.78 4.37

averaging 26 5 2.4 1.36 25 7 4.14 3 23 11 6.36 3.08

nor did we use any correlation between numbers

of frames used for embedding. The use of Reed-

Solomon codes and the like would allow rising α =

0.94 even higher (since 0.98 produced more failed at-

tempts due to not all frames being detected). And

because in our tests not detecting all frames used

for embedding was considered failure, some standard

method of recovering missing information would fur-

ther rise the success rate.

As we mentioned above, a broader framework can

be devised where there is another scheme, that co-

exists in the movie and is resistant to other attacks,

for which our scheme is susceptible.

5 CONCLUSION

In our paper we presented an approach to ﬁnger-

printing of video materials that diverges from a usual

paradigm. The proposed protocol provides immu-

nity against some common attacks and is adequate

for contemporary multimedia format. Moreover, the

transparency of our scheme is acceptable enough to

be commercially acceptable and can be traded off

for better detection rates. The presented protocol

is somehow “orthogonal” to and independent from

many other methods of typical ﬁngerprinting. There-

fore we believe that our approach can also be used

as an extra security layer together with other, classi-

cal protocols. The synergy of such combination can

lead to a very strong immunity against various attacks.

One path of experimentation is that of immunizing

the scheme against attack using a certain number of

copies of the movie.

Additionally, as a future work we leave out

enhancing the method so that it allows blind-

identiﬁcation. The only reason the original footage is

required is for estimation of MSE between the frames,

however as one of every few IFrames is watermarked

by increasing its luminance channel, it will be an out-

lier among frames describing the same scene. Locali-

sation of the outliers in a sliding window would allow

identiﬁcation of the marked frames without a refer-

ence clip, and due to its signiﬁcant robustness against

averaging it is feasible to adjust the parameters so that

blind detection is possible without signiﬁcant loss in

accuracy.

REFERENCES

Alkhathami, M., Han, F., and Van Schyndel, R. (2013). Fin-

gerprint image watermarking approach using dtcwt

without corrupting minutiae. In 2013 6th Inter-

national Congress on Image and Signal Processing

(CISP), volume 03, pages 1717–1723.

Asikuzzaman, M. and Pickering, M. R. (2018). An

overview of digital video watermarking. IEEE Trans-

actions on Circuits and Systems for Video Technology.

Bhatnagar, G. and Wu, Q. J. (2013). Biometrics inspired

watermarking based on a fractional dual tree com-

plex wavelet transform. Future Generation Computer

Systems, 29(1):182 – 195. Including Special section:

AIRCC-NetCoM 2009 and Special section: Clouds

and Service-Oriented Architectures.

Bhattacharya, S., Chattopadhyay, T., and Pal, A. (2006).

A survey on different video watermarking techniques

and comparative analysis with reference to h.264/avc.

In 2006 IEEE Int. Symposium on Consumer Electron-

ics.

Chang, H. T. and Tsan, C. L. (2005). Image watermarking

by use of digital holography embedded in the discrete-

cosine-transform domain. Appl. Opt., 44.

Chang, X., Wang, W., Zhao, J., and Zhang, L. (2011). A

survey of digital video watermarking. In 2011 Sev-

enth International Conference on Natural Computa-

tion, volume 1, pages 61–65.

Coria, L. E., Pickering, M. R., Nasiopoulos, P., and Ward,

R. K. (2008). A video watermarking scheme based on

the dual-tree complex wavelet transform. IEEE Trans-

actions on Information Forensics and Security, 3.

Deguillaume, F., Csurka, G., O’Ruanaidh, J. J., and Pun,

T. (1999). Robust 3D DFT video watermarking. In

Security and Watermarking of Multimedia Contents,

volume 3657. Int. Society for Optics and Photonics.

Doerr, G. and Dugelay, J.-L. (2003). A guide tour of video

watermarking. Signal Processing: Image Communi-

cation, 18(4):263 – 282. Special Issue on Technolo-

gies for Image Security.

SECRYPT 2020 - 17th International Conference on Security and Cryptography

474

Fridrich, J. (1998). Image watermarking for tamper detec-

tion. In Proceedings 1998 International Conference

on Image Processing. ICIP98 (Cat. No.98CB36269),

volume 2, pages 404–408 vol.2.

Gaur, S. and Srivastava, V. K. (2017). A hybrid rdwt-dct and

svd based digital image watermarking scheme using

arnold transform. In 2017 4th Int. Conf. on Signal

Processing and Integrated Networks (SPIN).

Gupta, A. K. and Raval, M. S. (2012). A robust and se-

cure watermarking scheme based on singular values

replacement. Sadhana, 37(4):425–440.

Hwang, D.-C., Bae, K.-H., Lee, M.-H., and Kim, E.-S.

(2003). Real-time stereo image watermarking using

discrete cosine transform and adaptive disparity maps.

In Tescher, A. G., Vasudev, B., Jr., V. M. B., and Di-

vakaran, A., editors, Multimedia Systems and Applica-

tions VI, volume 5241, pages 233 – 242. International

Society for Optics and Photonics, SPIE.

ISO/IEC 14496-12 (2011). Information technology – Cod-

ing of audio-visual objects. Standard, International

Organization for Standardization, Geneva, CH.

ISO/IEC 23009-1 (2012). Information technology – Dy-

namic adaptive streaming over HTTP (DASH). Stan-

dard, International Organization for Standardization,

Geneva, CH.

Kingsbury, N. (2000). A dual-tree complex wavelet

transform with improved orthogonality and symmetry

properties. In Proceedings 2000 Int. Conf. on Image

Processing, volume 2.

Lee, S.-W. and Seo, D.-I. Novel robust video watermarking

algorithm based on adaptive modulation.

Lee, Y., Kim, C., and Lee, S. (2006). Video ﬁngerprinting

based on frame skipping. In Proceedings of the Inter-

national Conference on Image Processing, ICIP 2006,

October 8-11, Atlanta, Georgia, USA. IEEE.

Li, J., Yu, C., Gupta, B. B., and Ren, X. (2018). Color image

watermarking scheme based on quaternion hadamard

transform and schur decomposition. Multimedia Tools

and Applications, 77(4):4545–4561.

Luo, X., Zhan, R., Chang, H., Yang, F., and Milanfar,

P. (2020). Distortion Agnostic Deep Watermarking.

arXiv e-prints, page arXiv:2001.04580.

Mabtoul, S., Hassan, E., Elhaj, I., and Aboutajdine, D.

(2007). Robust color image watermarking based on

singular value decomposition and dual tree complex

wavelet transform. In 2007 14th IEEE International

Conference on Electronics, Circuits and Systems.

Makbol, N. M. and Khoo, B. E. (2013). Robust blind im-

age watermarking scheme based on redundant discrete

wavelet transform and singular value decomposition.

AEU-International Journal of Electronics and Com-

munications, 67(2):102–112.

Makbol, N. M. and Khoo, B. E. (2014). A new robust and

secure digital image watermarking scheme based on

the integer wavelet transform and singular value de-

composition. Digital Signal Processing, 33:134–147.

Nikolaidis, N. and Pitas, I. (1998). Robust image water-

marking in the spatial domain. Signal Processing, 66.

Noorkami, M. and Mersereau, R. M. (2005). Compressed-

domain video watermarking for h.264. In IEEE Int.

Conf. on Image Processing 2005.

Patvardhan, C., Kumar, P., and Vasantha Lakshmi, C.

(2018). Effective color image watermarking scheme

using ycbcr color space and qr code. Multimedia Tools

and Applications, 77(10):12655–12677.

Ping Wah Wong and Memon, N. (2001). Secret and public

key image watermarking schemes for image authenti-

cation and ownership veriﬁcation. IEEE Transactions

on Image Processing, 10(10):1593–1601.

Potdar, V. M., Han, S., and Chang, E. (2005). A survey of

digital image watermarking techniques. In INDIN ’05.

2005 3rd IEEE International Conference on Industrial

Informatics, 2005., pages 709–716.

Sebé, F., Domingo-Ferrer, J., and Herrera, J. (2000).

Spatial-domain image watermarking robust against

compression, ﬁltering, cropping, and scaling. In Goos,

G., Hartmanis, J., van Leeuwen, J., Pieprzyk, J., Se-

berry, J., and Okamoto, E., editors, Information Secu-

rity, pages 44–53. Springer Berlin Heidelberg.

Sheth, R. K. and Nath, V. V. (2016). Secured digital image

watermarking with discrete cosine transform and dis-

crete wavelet transform method. In 2016 International

Conference on Advances in Computing, Communica-

tion, Automation (ICACCA) (Spring), pages 1–5.

Sun, J., Yang, N., Liu, J., Yang, X., Li, X., and Zhang, L.

Video watermarking scheme based on spatial relation-

ship of dct coefﬁcients.

Swanson, M. D., Bin Zhu, and Tewﬁk, A. H. (1998).

Multiresolution scene-based video watermarking us-

ing perceptual models. IEEE Journal on Selected Ar-

eas in Communications, 16(4):540–550.

Swanson, M. D., Zhu, B., Chau, B., and Tewﬁk, A. H.

(1997). Object-based transparent video watermark-

ing. In Proceedings of First Signal Processing Society

Workshop on Multimedia Signal Processing.

Tjokorda Agung B.W, Adiwijaya, and Permana, F. P.

(2012). Medical image watermarking with tamper

detection and recovery using reversible watermarking

with lsb modiﬁcation and run length encoding (rle)

compression. In 2012 IEEE Int. Conf. on Commu-

nication, Networks and Satellite (ComNetSat).

Tsai, H.-H. and Liu, C.-C. (2011). Wavelet-based image

watermarking with visibility range estimation based

on hvs and neural networks. Pattern Recognition, 44.

Wen, B. and Aydore, S. (2019). ROMark: A Robust Wa-

termarking System Using Adversarial Training. arXiv

e-prints, page arXiv:1910.01221.

Xu, D., Wang, R., and Wang, J. (2011). A novel watermark-

ing scheme for h.264/avc video authentication. Signal

Processing: Image Communication, 26(6):267 – 279.

Zebbiche, K., Kheliﬁ, F., and Loukhaoukha, K. (2018). Ro-

bust additive watermarking in the dtcwt domain based

on perceptual masking. Multimedia Tools and Appli-

cations, 77(16):21281–21304.

Zhang, J., Ho, A. T. S., Qiu, G., and Marziliano, P.

(2007). Robust video watermarking of h.264/avc.

IEEE Transactions on Circuits and Systems II: Ex-

press Briefs, 54(2):205–209.

Droppix: Towards More Realistic Video Fingerprinting

475

Zhong, X. and Shih, F. Y. (2019). A Robust Image Wa-

termarking System Based on Deep Neural Networks.

arXiv e-prints, page arXiv:1908.11331.

Zhou Wang, Bovik, A. C., Sheikh, H. R., and Simoncelli,

E. P. (2004). Image quality assessment: from error

visibility to structural similarity. IEEE Transactions

on Image Processing, 13(4):600–612.

Zhu, J., Kaplan, R., Johnson, J., and Fei-Fei, L. (2018).

HiDDeN: Hiding Data with Deep Networks. In The

European Conference on Computer Vision (ECCV).

SECRYPT 2020 - 17th International Conference on Security and Cryptography

476
