Trust Profile based Trust Negotiation for the FHIR Standard

Eugene Sanzi and Steven A. Demurjian

Department of Computer Science & Engineering, University of Connecticut, 371 Fairfield Way, Storrs, U.S.A.

Keywords: Trust Negotiation, Trust Profile, FHIR, Authorization, Healthcare.

Abstract: Sensitive healthcare data within Electronic Healthcare Records (EHRs) is traditionally protected through an

authentication and authorization process. The user is authenticated based on a username/password

combination which requires a pre-registration process. Trust profile based trust negotiation replaces the

required human intervention during the traditional pre-registration process with an automated approach of

verifying that the user owns the trust profile with digital signatures. To accomplish this, the negotiation

process gradually exchanges the credentials within the trust profile to build trust and automatically assign

authorization rules to previously unknown users. In this paper, we propose a new model for attaching trust

profile authorization data to Fast Healthcare Interoperability Resources (FHIR), a standard created by HL7,

in order to integrate the process of trust profile based trust negotiation into FHIR.

1 INTRODUCTION

The healthcare industry is increasingly adopting new

techniques for sharing secure healthcare data through

Health Information Exchange (HIE) (De Pietro &

Francetic, 2018). While integration between

electronic healthcare records (EHRs) stored at

multiple providers has been hampered due to the

difficulty in implementing interoperability standards,

the exchange of patient healthcare data between

providers is shown to positively affect patient

treatment and patient satisfaction (Yasnoff, 2015).

However, the authorization to healthcare data

between healthcare providers is still attached to the

slow username/password combination authentication

process which requires explicit pre-registration. This

pre-registration slows the dissemination of

potentially time-critical sensitive healthcare data by

requiring a system administrator to remotely

determine a potential user’s identity and explicitly

assign authorization to the user.

Despite the difficulties in coordinating the

exchange of health data, healthcare providers are

adopting new technologies that facilitate its

exchange. The Fast Healthcare Interoperability

Resources (FHIR) (HL7 International, 2020) is a

healthcare interoperability standard whose goal is to

facilitate the retrieval of healthcare data by providing

a common API to locate and exchange healthcare

records. FHIR’s data exchange structure is built on

the concept of a resource, which provides a

meaningful set of healthcare related data for transfer.

FHIR provides over 125 different resources for:

patients, observations, medications, patient consent,

etc. Requests for a specific resource are available

through a REST API that supports instance level

interactions such as: read, vread (version read),

update, patch (update a portion of a resource), delete,

and history interactions. FHIR has emerged as a

popular choice (Posnack & Barker, 2018) for

supporting HIE. Microsoft has an azure API for FHIR

(https://azure.microsoft.com/en-us/services/azure-

api-for-fhir/), and Google has created a cloud

healthcare API using FHIR (https://cloud.google.

com/healthcare). Large EHR providers such as Epic

(Epic Systems Corporation, 2020) and Cerner

(Cerner, 2020) have leveraged FHIR to facilitate HIE

for patient use.

Trust negotiation (Winsborough et al., 2000) was

introduced as a method of building trust between two

parties whose identities were previously unknown to

each other. In this context, trust is defined as the

ability to ascertain that the other party is authorized

to obtain the requested sensitive data and will handle

the data appropriately. During trust negotiation, each

participant possesses a set of credentials capable of

describing whether the other participant should

consider them trustworthy. The credentials are

exchanged between participants throughout several

rounds of trust negotiation until there is a

242

Sanzi, E. and Demurjian, S.

Trust Proﬁle based Trust Negotiation for the FHIR Standard.

DOI: 10.5220/0009830502420251

In Proceedings of the 9th International Conference on Data Science, Technology and Applications (DATA 2020), pages 242-251

ISBN: 978-989-758-440-4

determination that: each participant possesses the set

of credentials necessary to obtain trust; or, at least one

participant does not possess a trustworthy set of

credentials meaning trust cannot be established. One

effort (Ryutov et al., 2005) extended trust negotiation

by creating an adaptive framework, allowing online

business to determine customer trustworthiness based

on past purchase value. This adaptive framework has

been expanded to include our controller’s adaptation

to the requestor’s role and the specific resource being

accessed. In (Vawdrey et al., 2003), trust negotiation

was adapted to healthcare by describing a trust

negotiation process for obtaining a patient’s EHR, but

provides only a healthcare license as a credential. In

(Elkhodr et al., 2011), a three step trust negotiation

process is used for determining the authenticity of a

request for healthcare data, but still requires that the

identity of the requestor is previously known.

Our prior work proposed and defined a trust

profile (Sanzi et al., November 2016) as an extension

to trust negotiation that defines a set of credentials

based on the trust profile owner’s history of

successful access to sensitive data via trust

negotiation. A trust profile is a collection of access

history credentials that describe a particular user (the

owner) and are digitally signed by a controller, an

entity responsible for the secure dissemination of

sensitive data. Trust profiles utilize X.509 identity

certificates (Cooper et al., 2008), attribute certificates

(Farrell & Housley, 2002), and certificate chaining to

build trust between controllers in the credentials they

have digitally signed (Sanzi & Demurjian, May

2016). The users send a request for data with a subset

of their personal trust profile to a controller, which

then reads the access history provided, determines

whether the credentials are sufficient to establish

trust, and releases the data if sufficient trust has been

established (Sanzi et al., 2017). If trust negotiation is

successful, the controller creates new credentials

detailing the new access to sensitive data and sends

them to the user with the requested data. These new

credentials are then added to the user’s personal trust

profile to be presented to other controllers during

future trust negotiation attempts. This improves upon

previous works by providing a standardized set of

credentials describing an entire access history,

allowing complex requirements to be formulated on

the controller side, and new credentials to be obtained

during the course of a user’s career.

Our work in this paper is part of an ongoing effort

to integrate trust profile based trust negotiation into

the authorization process of modern EHRs across all

of the healthcare stakeholders (e.g., physicians,

nurses, insurance billing agents, patients, patient

families, etc.). The decentralization of healthcare

information has spread across multiple EHRs as

patients increasingly are being treated by teams of

healthcare specialists in geographically separated

locations. Our new proposed method of authorization

for the release of sensitive healthcare data is required

and replaces the time intensive pre-registration

process. The FHIR security model is enhanced by

integrating a new capability that incorporates the

option for trust profile based trust negotiation during

a resource request if the requestor is unknown to the

healthcare organization providing FHIR based HIE.

In support of this work, we propose a new model that:

details trust profile metadata integrated into FHIR

resources; and, describes the trust profile credentials

needed to obtain access utilizing a combination of

role-based access control (RBAC) (Ferraiolo et al.,

2001) and mandatory access control (MAC) (Bell &

La Padula, 1976). Successful access to FHIR data

results in requestors obtaining needed healthcare data

quickly and includes dynamic additions to their trust

profiles detailing access to the requested resources

that can be presented to other FHIR systems during

future trust negotiation attempts.

The remainder of this paper is organized into five

sections. Section 2 presents background on FHIR,

access control models, trust negotiation, trust profiles,

and the process of obtaining authorization via trust

negotiation supported by trust profiles. Section 3

introduces extensions to our existing trust profile

model (Sanzi et al., 2017) for intercepting resource

requests to provide trust profile based authorization

by annotating FHIR concepts and resource objects

with trust profile data, and resolving authorization to

the requested resources. Section 4 presents an

example of the model applied to the healthcare

domain. Section 5 has a conclusion for the paper.

2 BACKGROUND

2.1 Access Control

The Role-based access control (RBAC) (Ferraiolo et

al., 2001) model binds a set of permissions to operate

on data (create, read, update, delete) to roles (e.g.,

physician, nurse, front desk secretary, etc.). These

roles are then assigned to users. When a user is

assigned a role, the user may perform any action

allowed in that role’s permission set. RBAC is a

popular access control model in healthcare as a result

of its ability to simplify the assignment of complex

permissions through role assignment, allowing

consistent permissions across each type of job.

Trust Proﬁle based Trust Negotiation for the FHIR Standard

243

During trust negotiation, the user’s assumed role

allows our controller to map a set of required trust

profile credentials to the specific resource requested.

The Mandatory access control (MAC) (Bell & La

Padula, 1976) model defines a set of sensitivity levels

on subjects (users) and objects (data) and allows

access to the data if the user meets the required

sensitivity level. MAC is generally modeled with

levels: top secret (TS) < secret (S) < classified (C) <

unclassified (U). If a user wishes to read data, they

must meet or exceed the sensitivity level assigned to

the data they wish to access. MAC in healthcare can

be implemented as a method where the sensitivity

level of the data corresponds with the potential for

damage if released.

2.2 Trust Profiles

To facilitate the discussion of trust profile concepts,

Fig. 1 displays a generalized overview of trust

negotiation extended with trust negotiation. The

medical authority in the upper left corner establishes

trust between HIT Systems A, B, and C below by

digitally signing its CA certificates, allowing each of

them to trust any certificates signed by the other two.

A user’s trust profile, consisting of the identity and

attribute certificates appearing on the left side of Fig.

1, is endorsed through the digital signatures provided

by HIT Systems A, B, and C. A user constructs a

digital wallet, which is sent to the controller of an HIT

system. The controller utilizes the four Sec objects to

be introduced in Section 3 to build a credential

expression that describes the entries in the trust

profile necessary to release the FHIR resources that

they protect.

In Fig. 1, a trust profile is a complete collection

of a user’s entire history of access to sensitive data. In

the healthcare field, a trust profile would describe

each successful access a healthcare professional is

granted to sensitive healthcare data. A trust profile is

encoded in a series of X.509 encoded identity

(Cooper et al., 2008) and attribute certificates (Farrell

& Housley, 2002). Healthcare controllers issue one

identity certificate per user the first time a user

successfully accesses healthcare data from the

controller. The accesses are described in sets of

attribute certificates attached to the identity

certificates. An attribute certificate is attached to an

identity certificate by including the identity

certificate’s serial number and issuer, which is a

combination that must be unique to that identity

certificate. The attribute certificate is digitally signed

by the controller to prevent subsequent modification.

The identity certificates describe a user’s public

key, and the user proves ownership of the trust profile

data by proving ownership of the private key

associated with the public key listed in the identity

certificates. This also allows the user to claim

ownership of any attribute certificate attached to the

identity certificate. A healthcare provider must obtain

his/her own certificate to allow a controller to act as a

certificate authority (CA), allowing them to digitally

sign trust profile certificates. The trust profile

certificates digitally signed by a healthcare provider

are only trusted by another provider during trust

negotiation if: the other provider has decided to trust

the controller’s certificate by adding it directly to a

local trust store; or, the other provider trusts the entity

that signed the controller’s certificate by adding the

entity’s certificate to a local trust store. A healthcare

organization promotes trust by performing as a

trusted entity signing the requestor’s trust profile

entries.

Figure 1: Overview of trust profile based trust negotiation.

Each user may obtain multiple identity

certificates (left side of Fig. 1), one from each

controller that has granted sensitive data access. Each

identity certificate may have one or more attached

attribute certificates and the access described within

the attribute certificate must refer to data accessed

from the controller that signed the attached identity

certificate. A controller may only describe accesses

that occurred within the EHR it controls. When a user

with a trust profile discovers healthcare data, the user

first initiates a request for trust negotiation by

specifying: the resource being requested, the role the

user possesses, and an initial subset of the trust profile

referred to as a digital wallet (bottom portion of Fig.

1). The controller receives the request, retrieves

security metadata for the resource, and builds a

credential expression (ψ) during trust negotiation

located at the bottom of HIT System A’s purple box

(right side of Fig. 1). The credential expression

represents credentials that must be present in the

digital wallet to grant the requestor access to the

DATA 2020 - 9th International Conference on Data Science, Technology and Applications

244

resource. The controller retrieves the four Sec objects

(inner box of HIT System A) that describe the

security constraints on the FHIR resource being

requested (top of HIT System A). The controller may

generate a set of release actions that depend on the

credentials the requestor presents, such as: redacting

sensitive data if the credentials are insufficient to

release more sensitive data, logging the transaction in

different severity logs, or dispatching audit

notifications to the local system administrator.

If the credentials passed to the controller within

the digital wallet are insufficient, the controller builds

a server governance policy (SGP) (Winsborough et

al., 2000) that describes the missing requirements.

Trust negotiation may occur over several rounds, as

the requestor and controller negotiate the release of

potentially sensitive trust profile credentials. If the

presented credentials are insufficient, negotiation

fails and the connection is terminated. If the requestor

has presented sufficient credentials to obtain access to

the resource, the controller generates new certificates

to describe the current data access and sends the

certificates and health data back to the requestor. If a

new identity certificate is required, the controller asks

the requestor for a new public key for the new identity

certificate. The controller then performs its release

actions depending on the credentials matched to the

credential expression and terminates the connection.

The requestor receives the healthcare data and trust

profile certificates and adds the new certificates to the

trust profile. These new certificates may be used

during trust negotiation with any controller.

Trust negotiation failures may be caused by a lack

of required credentials or by deadlock during the trust

negotiation process, where both the requestor and

controller require a credential from the other before

their own required credential can be released. Our

integration of release actions improves the success

rate by allowing controllers to relax requirements on

the requestor in exchange for a lower rated trust

transaction, which may result in data redaction or

notes for manual auditing. Oblivious attribute

certificates (Li & Li, 2006) can be used to eliminate

deadlock by creating certificates that can only be read

if the receiver possesses the attributes necessary to

read them. With oblivious attribute certificates, data

can be exchanged without the possibility of it being

readable if the receiver is not authorized to view it.

2.3 FHIR

Fast Healthcare Interoperability Resources (FHIR)

(HL7 International, 2020) provides structures for

sharing EHR data between healthcare providers. Data

is accessed through resources. Resources are

accessed utilizing a location URL as part of a REST

API in conjunction with a logical ID. This allows data

that resources describe to sync between separate

FHIR systems.

FHIR resources are organized in categories:

foundation resources, base resources, clinical

resources, financial resources, and specialized

resources. We highlight only a subset relevant for the

paper. The base resources describe: patients,

practitioners, and family relationships; organizations,

services, appointments, and encounters. The clinical

resources are for a patient’s health history, including:

diagnostic data, medications, care provision, and

request/response communication. HAPI FHIR

(HAPI FHIR, 2020) is a Java implementation of the

FHIR resources Patient, FamilyMemberHistory,

Condition, Observation, Diagnostic Report,

Medication, Immunization, AllergyIntolerance,

Coverage, EligibilityRequest, Claim,

PaymentNotice, etc. The resources are available

through the FHIR standard's REST API.

3 TRUST PROFILE AND FHIR

INTEGRATION

In this section, we describe our method for integrating

FHIR with a trust profile based trust negotiation

approach for dynamic and automatic authorization to

requested FHIR resources that extends our prior work

on a trust profile model (Sanzi et al., 2017) that

encodes several different properties of access to a

healthcare system within four types of attribute

certificates. The remainder has seven subsections.

Section 3.1 explores the interaction between the data

encoded in trust profile attribute certificates and a

description of the type of security metadata tracked

within four different types of Sec objects. Each of the

four different types of Sec object metadata is

elaborated on in Sections 3.2, 3.3, 3.4, and 3.5

respectively. Section 3.6 describes the internal

structure of the security objects. Section 3.7 describes

the way that the security constraints of each of the

four Sec objects are combined to resolve a request.

3.1 Sec Object Interaction

The trust profile’s attribute certificate types track: the

associated identity certificate, the attribute certificate

issuer, and a timestamp. The attribute certificate types

are: affiliation certificates (AC

Affiliation

), data resource

access certificates (AC

DataResourceAccess

), data resource

Trust Proﬁle based Trust Negotiation for the FHIR Standard

245

confidentiality certificates (AC

DataResourceConfidentiality

and system confidentiality certificates

(AC

SystemConfidentiality

). Affiliation certificates denote

current employment with a trusted healthcare

provider and signify a thorough manual background

check as part of the pre-employment process. Data

resource access certificates provide metadata on the

role the user possessed during the access, FHIR

resource ID, and the system ID representing the FHIR

server that serviced the originating request. The data

resource confidentiality certificate provides: the

confidentiality level of the resource accessed, the

FHIR resource ID, and the system ID. The system

confidentiality certificate describes the highest level

of confidentiality that the certificate subject has

accessed on the FHIR server and the system’s ID.

In support of trust profile integration, we have

modified the HAPI FHIR implementation to enable

the creation of a credential expression whose access

rules are created based on a configuration. This

metadata describes the properties needed in the

requestor’s trust profile to gain authorization to the

resource. The modifications support the creation of

multiple credential expressions based on any set of

properties specified within the trust profile.

Security metadata for our extension is divided

into one of four levels, whose various access rules are

combined utilizing the process described in this

section to form one credential expression for the

entire trust negotiation process. These four levels are:

 system security refers to the requirements that

the controller must observe in the requestor’s

trust profile to gain access to any resources

 resource type security refers to the

protections of an individual type of resource

 resource security refers to the actual

protection of an individual resource instance

on the FHIR server and data within the object

 patient consent refers to the ability of a

patient to describe which healthcare

providers may access each resource, at either

the resource type or individual resource level

3.2 System Security Metadata

System security (Sec

System

) refers to the requirements

the controller must observe in the requestor’s trust

profile to gain access to any resources. This may

include a valid affiliation certificate denoting current

employment at a trusted healthcare provider and at

least one data resource access certificate describing

access to a resource under the role requested for the

current trust negotiation. System security also

encompasses the overall highest security clearance

the user has been granted on a specific system. As

specified in the trust profile model, an identity

certificate in a trust profile may have a system

confidentiality attribute certificate attached to it that

records the highest security clearance previously

granted to the trust profile owner by the specific

healthcare system that signed it. This certificate is

replaced with a newer certificate listing a higher

clearance in the event that the controller grants the

requestor access to a resource with a higher listed

security clearance than the clearance listed in the

requestor’s system confidentiality attribute

certificate. The requestor may be assigned higher

security clearances by the FHIR server depending on

which trust profile entries the requestor sends to

satisfy the generated credential expression. An

SystemConfidentiality

certificate previously digitally

signed by the controller may be provided during

negotiation to claim a previous confidentiality level

assigned by the controller. A system confidentiality

level may be assigned based on the perceived damage

caused by a potential unauthorized leak of the

requested data, and a requestor that meets the

confidentiality requirements for portions of the

requested resource, but not the entire resource, may

result in a release action (RA) (Sanzi et al., 2017) that

causes the controller to filter data of higher sensitivity

from the resource before sending it to the requestor.

3.3 Resource Type Security Metadata

Resource type security (Sec

Type

) refers to the

protection of all of the resources of a given type.

Resource types are further divided into base, clinical,

and financial resource types (HL7 International,

2019). Each resource type possesses an associated

security object that describes the credentials that must

be presented by the requestor for the controller to

release a resource of the given type. The required

credentials are described by a series of Access History

Properties (AHP), each describes a single property of

access to a sensitive FHIR resource. These credentials

are also organized within the security object by the

role the requestor assumes for the given trust

negotiation transaction. Recall that (Sanzi et al.,

2017) specifies that in the initial request for trust

profile based trust negotiation, the requestor specifies

the role (e.g., family physician, emergency room

physician, nurse, billing agent, front desk secretary,

etc…) to be assumed for the purposes of negotiation.

The controller filters the resources a requestor of a

given role accesses based on the perceived needs of a

DATA 2020 - 9th International Conference on Data Science, Technology and Applications

246

role. For example, a physician role will be allowed to

access clinical resources (e.g., summary, diagnostics,

medications, care provisions, request and responses)

whereas a front desk secretary may be limited to the

patient resource (describing the patient’s

demographic data) under the base category. The role

specified by the requestor will also affect the proof

the controller requests for assurance of the requestor’s

membership of the specified role. A family physician

requesting a patient’s clinical resources may be asked

to provide credentials from the trust profile indicating

a historical access to the patient’s clinical resources

whereas a front desk secretary may only have to

provide proof of employment (affiliation) via a desk

secretary role to access a patient’s demographic data.

3.4 Resource Security Metadata

Resource security (Sec

Resource

) protects an individual

resource object on the FHIR server and the data

within the object. The resource Sec

Resource

provides

security data for is identified within the Sec

Resource

a matching identifier. Sec

Resource

is similar to Sec

Type

with the exception that it protects an individual

resource instance as contrasted to an entire collection

of resources of a certain type, increasing the

granularity with which a resource is protected. When

the request for a FHIR object through trust

negotiation is first received, the Sec

Resource

object

attached to the requested FHIR object is retrieved by

matching the FHIR ID.

3.5 Patient Consent Security Metadata

Patient consent security (Sec

Consent

) allows the patient

described by the FHIR object to provide input as to

which healthcare providers may access each resource,

at either the resource type or individual resource

level. Our Sec

Consent

security object is based on the

principles of patient consent (The Office of the

National Coordinator for Health Information

Technology, 2019) outlined by The Office of the

National Coordinator for Health Information

Technology (ONC). Patient consent methods allow

patients to consent to HIE among multiple healthcare

providers by allowing patients to note when and how

their health data is shared whether their health data is

shared for treatment, bill payment, or general

healthcare operations. Our patient consent object

overrides other security objects when present,

allowing the patient to have final authority over the

disclosure of the health record. The Sec

Consent

object is

built by the patient and attached to the patient’s

records within a FHIR system, allowing the patient to

provide input as to which trust profile credentials are

necessary during trust negotiation for the release of

different types of FHIR data and FHIR resources.

The patient interacts with the Sec

Consent

object via

a patient portal provided by the healthcare

organization maintaining the FHIR server. The

patient portal follows the ONC’s meaningful consent

guidelines (The Office of the National Coordinator

for Health Information Technology, 2018) and

describes the patient’s choices as well as the

implication of their options regarding what data will

be released to which types of providers under

different circumstances. The patient portal interface

provided by the healthcare organization presents

multiple options that cover different use cases along

with descriptions for which healthcare providers have

access to the patient’s FHIR resources depending on

the options chosen. This simplifies the selection

process for a patient, allowing the patient to fully

comprehend the implications of each choice without

needing a deep understanding of trust profiles or trust

negotiation. At the healthcare provider’s discretion,

more granular interfaces can be made available to the

patient should the patient have the knowledge to

construct more detailed Sec

Consent

objects. The

Sec

Consent

object contains the same format as the

Sec

Resource

and Sec

Type

objects with the restriction that

a Sec

Consent

object is only attached to a FHIR resource

via ID if the resource ID’s patient identifier matches

the identifier of the patient creating the Sec

Consent

object. Additionally, the patient may include multiple

instances of a healthcare professional’s public key

from a trust profile identity certificate. This allows the

patient to identify a healthcare professional as being

able to access a portion of the patient’s healthcare

records if the patient has a pre-existing relationship.

If a public key is listed as a potential credential to gain

access to a FHIR resource, the healthcare professional

attempting to access the resource proves ownership of

the public key by proving ownership of the associated

private key. This is done by digitally signing a

message with the private key during trust negotiation

in accordance with public key infrastructure.

3.6 Security Object Structure

Each Sec object contains a tree structure as illustrated

with the Sec

Type

example in Fig. 2 detailing the

specific credentials that must be presented to the

controller on a per role basis, as well as release

actions required for the release of the resource based

on which parts of the credential expression are

satisfied. A Sec object is organized into a tree

structure. The root of the tree contains an identifier

Trust Proﬁle based Trust Negotiation for the FHIR Standard

247

that defines the type of Sec object. The Sec

System

Sec

Type

, Sec

Resource

, and Sec

Consent

objects also provide

the system ID, resource type ID, resource ID, or

patient ID, respectively, that they are responsible for

protecting. The next level of the tree represented by

the top branch in Fig. 2, which provides a supported

list of roles capable of retrieving data of the requested

Sec object. For example, a Sec

System

object contains a

complete listing of all of the roles that are able to

access any sensitive data protected by the controller,

whereas Sec

Type

for an Observation will only contain

the roles that are capable of accessing an Observation.

Each role contains subtrees representing the AHPs

that the controller must request from the requestor’s

trust profile to grant access if the requestor is

assuming that role. An AHP is noted as required, in

which case its absence in the credentials during trust

negotiation causes trust negotiation to fail; or

optional, which allows the FHIR object to be released

even if not present. The existence of required or

optional AHPs allows more flexibility in the ability to

build trust between the requestor and controller by

requesting the presence of an AHP without requiring

it, while still providing a baseline for AHPs that must

be present for the controller to trust the requestor with

the release of the requested FHIR object.

Figure 2: An example Sec object structure.

Each AHP has an optional set of release actions,

RAs, attached to it that describes ancillary actions the

controller must take to approve the satisfaction of the

AHP requirement by a credential in the requestor’s

trust profile. The RA for an AHP optionally has:

potential additions, modifications, or redactions of

the resource before release to the requestor; or

specifies side effect actions such as noting the release

of the resource at certain risk levels in a multi-level

audit log and dispatching audit notifications to the

healthcare organization’s local security auditor for

immediate review. Additions to the resource include

contextual data not requested but necessary to

understand the resource, e.g., a program for reading

X-Ray scans. Modifications to the resource include

changes such as translating embedded data into a

standard format. Redactions may occur if the

requestor’s credentials meet a trust level sufficient to

access parts of a resource, but not the entire resource.

In this case, the sensitive data is redacted, allowing

the requestor to obtain the subset of useful data that

the requestor is authorized to access. Integrating an

RA into a resource is a method that the controller uses

to increase the rate of trust negotiation success and

disseminate requested PHI without compromising

patient security.

Conceptually, each AHP listed in a Sec object

represents an entry in the requestor’s trust profile that

proves successful, secure handling of the type of Sec

object by the role. The healthcare organization that

shares the PHI is responsible for determining the

AHPs necessary as to whether a requestor is

trustworthy. A requestor making a request under a

family physician role for their patient’s EHR data

located at a remote healthcare organization could

result in the following requested AHPs and RAs:

 Sec

System

: Affiliation with any healthcare

provider (RA: log as high risk)

 Sec

Type

: Past access to a resource of the same

type within the last year (RA: reduce log level

to medium risk, redact resource data with

sensitivity: S or higher)

 Sec

Resource

: Optional: Past access to a resource

belonging to the patient within the last two

years (RA: reduce log level to low risk, audit

notification not required, no redaction

required)

 Sec

Consent

: Affiliation with a listed healthcare

provider (RA: notify patient of access

through a healthcare portal)

3.7 Request Resolution

When a request for trust negotiation is initially

received, the controller first retrieves each of the four

Sec objects that will be associated with the request:

the system object for the FHIR installation as a whole,

the type object for the type of resource being

requested, the resource object for the individual

FHIR resource by ID, and, the consent object

associated with the patient. Each Sec object must be

satisfied by one or more credentials sent by the

requestor to determine the requestor’s

trustworthiness. When the controller receives a

requestor’s trust profile credential and has finished

verifying the credentials authenticity, an attempt is

DATA 2020 - 9th International Conference on Data Science, Technology and Applications

248

made to match it against the AHPs in each of the four

retrieved Sec objects. The controller records which of

the AHPs has been satisfied, and creates an SGP

based on which AHPs remain unsatisfied to send back

to the requestor. All of the four Sec objects must be

satisfied for the trust negotiation to be successful. A

Sec object may specify that a particular AHP is

optional, thereby increasing trust in the requestor and

modifying the release actions accordingly.

Additionally, the Sec object may define a set of AHPs

as optional, but require that at least one be met for the

Sec object to be satisfied. A single trust profile

credential is potentially capable of satisfying multiple

AHPs across multiple Sec objects. During credential

exchange, the controller is continually checking the

requestor’s credentials and matching them to the Sec

objects until all of the AHPs are satisfied or the

requestor chooses not to send another credential. If

the requestor chooses not to send another credential,

the controller checks whether all of the four Sec

objects are satisfied, executes the release actions, and

provides the resource and new trust profile

credentials. The controller’s final set of release

actions are resolved hierarchically from Sec

System

Sec

Resource

by beginning with the Sec

System

’s set of

release actions and combining with Sec

Type

’s release

actions, then Sec

Resource

’s release actions. When two

RAs conflict at different levels, the RA at the lowest

level (closest to the individual resource) takes

precedence. The Sec

Consent

’s release actions are

separated from the other three Sec objects and are

always executed as specified by the patient. The

consent object concerns patient notifications but may

also filter access to the patient’s resources more

strictly or release resources more freely to specific

healthcare providers and thus override the other three

Sec objects. Within a single Sec object, each AHP

contains a ranking, with higher ranking determining

which RA is executed if there is a conflict between

two RAs in two satisfied AHPs.

4 HEALTHCARE EXAMPLE

In this section, we demonstrate the operation of a trust

profile enhanced FHIR installation by providing an

example of an implementation in a healthcare setting

in Greater Hartford, Connecticut. Jane is a physician

working at Family Medicine Center (FMC) as a

family physician. Fig. 3 shows the different

interactions of Dr. Jane as she proceeds through the

trust profiling process to request permission to access

a new FHIR resource at another location that she has

not been authorized to. During her career, she has

gradually built a trust profile containing an access

history that describes access to sensitive data from

both her local EHR as displayed in the lower left of

Fig. 3 and remote access to EHRs maintained by other

healthcare providers in the area. While retrieving her

patient’s EHR, she discovers that the patient has

recently been seen at Hartford Hospital (HH) and a

new healthcare record of the FHIR Observation

resource was generated, represented by the Patient

Observation in the top middle of Fig 3. Dr. Jane is

unknown to HH and HH has no record of her, but

maintains a FHIR installation that supports trust

profile based trust negotiation.

Dr. Jane begins by initiating a request for trust

negotiation to HH under her family physician role for

the patient’s FHIR resource, which includes a trust

profile credential indicating current affiliation with

FMC, and sends it to HH. Dr. Jane is now the

requestor. The controller at HH receives the request

for trust negotiation, identifies the resource being

requested, and extracts the trust profile credentials.

The controller must now build the credential

expression that defines which trust profile credentials

are necessary to release the requested resource to Dr.

Jane and the release actions it must perform. The

controller identifies the four Sec objects represented

with ovals along the right side and upper left corner

of Fig. 3 that describe the credentials Dr. Jane will

need to present. These objects are: HH’s Sec

System

object that describes the credentials necessary to

access any FHIR resource from HH, the Sec

Type

object

that describes the credentials necessary to access any

Observation resource, the Sec

Resource

object that

describes the credentials necessary to access the

specific Observation, and, the Sec

Consent

object that

describes the credentials the patient requires to access

a resource they own. The Sec objects, AHPs, and RAs

represented to the right of Fig. 3 retrieved are:

 Sec

System

: Current affiliation with any

healthcare provider (RA: log as high risk,

send audit notification to local auditor)

 Sec

Type

: Past access to a resource of the same

type within the last year (RA: log as medium

risk, redact resource data with sensitivity: S

or higher)

 Sec

Resource

: Optional: Past access to a resource

belonging to the patient within the last two

years (RA: log as low risk, audit notification

not required, no redaction required)

 Sec

Consent

: Current affiliation (RA: patient

notification) or optionally: affiliation with a

listed healthcare provider

Trust Proﬁle based Trust Negotiation for the FHIR Standard

249

The controller matches the initial trust profile

credential, affiliation with FMC, against each of the

four Sec objects (green ovals in Fig. 3). The credential

satisfies both the Sec

System

object and the optional

Sec

Consent

requirement since the patient regularly sees

Dr. Jane at FMC. Since not all of the objects are fully

satisfied, the controller sends a server governance

policy (SGP) to Dr. Jane listing the missing AHPs.

Dr. Jane receives the request and sends a trust profile

entry describing access to one of the patient’s

Observation resources at FMC occurring three

months in the past. The controller receives this

request and matches it against each of the four Sec

objects. This new credential satisfies both the Sec

Type

and optional Sec

Resource

since the access to the

Observation resource matches both the Sec

Type

requirement of access to an Observation resource and

the Sec

Resource

requirement of access to an Observation

resource belonging to the patient, identified by a

patient ID. Having satisfied all of the credentials, the

controller processes the release actions of each Sec

object starting with Sec

System

and ending with

Sec

Consent

. Sec

Resource

’s log requirements override the

Sec

System

and Sec

Type

log requirements, logging the

access as low risk, no redaction being performed, and

overriding the audit notification requirement. The

affiliation with a listed healthcare provider AHP of

the Sec

Consent

object was the AHP that was satisfied

and carries no release action. The controller notifies

Dr. Jane that the trust negotiation was successful,

retrieves the requested Observation resource, and

generates new trust profile credentials describing Dr.

Jane’s access to the resource. The requested resource

and new credentials are sent to Dr. Jane, who can now

examine the patient’s observations from HH and add

the new credentials to her trust profile.

Figure 3: Trust negotiation example.

5 CONCLUSION AND ONGOING

RESEARCH

In this paper, we have outlined a methodology for

integrating trust profile based trust negotiation into

the FHIR environment supported by an example of its

operation in a real world healthcare scenario that

extends our prior work on trust profiles (Sanzi et al.,

2017). The methodology involves applying security

constraints for the specific resource requested by the

requestor. The security objects request access history

properties to allow access at the system level,

resource type level, individual resource level, and the

patient consent level. The trust profile credentials are

composed into a single credential expression by the

controller utilizing the requirements listed at each

level to provide a complete list of trust profile

requirements and to describe release actions for the

controller to execute to ensure a valid, secure

transaction. Combining the security objects allows

the healthcare organization operating a FHIR

installation to provide granular permissions for

accessing sensitive health data while acknowledging

the patient’s right to provide guidance towards the

dissemination of the patient’s EHR. Release actions

provide alternatives for trust profile requirements,

allowing for proper release of PHI when required.

This increased ability to share healthcare data among

providers increases patient recovery and satisfaction.

In support of our trust profile effort, we have

modified a mobile health application created in

support of a Connecticut bill (Connecticut General

Assembly, 2015) that is used for concussion

management of students in grades kindergarten

through high school by school nurses, athletic

trainers, parents, etc., to include the integrated trust

profile process as described in Section 3 with FHIR.

This mobile health application for concussion

management is integrated through the HAPI FHIR

server to the OpenEMR electronic medical record

(https://www.open-emr.org/) with the ability to take

information out of OpenEMR using its PHP API and

return observation and patient objects for the students

that have concussions. Our current research is

transitioning our model ideas in Section 3 in order to

fully realize the ability to access FHIR resources for

doing the trust management as described in Section 3

and illustrated in the healthcare example in Section 4.

DATA 2020 - 9th International Conference on Data Science, Technology and Applications

250

REFERENCES

Bell, D. E., & La Padula, L. J. (1976). Secure Computer

Systems: Unified Exposition and Multics

Interpretation. Bedford, Mass.: MITRE Corp.

Cerner. (2020, January 4). Home. Retrieved from

https://www.cerner.com/

Connecticut General Assembly. (2015). Substitute for

Raised H.B. No. 6722. Retrieved from https://www.

cga.ct.gov/asp/cgabillstatus/cgabillstatus.asp?selBillTy

pe=Bill&which_year=2015&bill_num=6722

Cooper et al. (2008, May). Internet X.509 Public Key

Infrastructure Certificate. Retrieved from

https://tools.ietf.org/html/rfc5280

De Pietro, C., & Francetic, I. (2018). E-health in

Switzerland: The laborious adoption of the federal law

on electronic health records (EHR) and health

information exchange (HIE) networks. Health Policy,

122(2), 69-74. doi:10.1016/j.healthpol.2017.11.005

Elkhodr et al. (2011). Enhancing the security of mobile

health monitoring systems through trust negotiations.

Local Computer Networks (LCN), 2011 IEEE 36th

Converence on (pp. 754-757). Bonn: IEEE.

Epic Systems Corporation. (2020, January 4). Epic.

Retrieved from https://www.epic.com/

Farrell, S., & Housley, R. (2002, April). An Internet

Attribute Certificate Profile for Authorization.

Retrieved from The Internet Engineering Task Force

(IETF®): https://www.ietf.org/rfc/rfc3281.txt

Ferraiolo et al. (2001). Proposed NIST standard for role-

based access control. ACM Transactions on Informa-

tion and System Security (TISSEC), 4(3), 224–274.

HAPI FHIR. (2016). Server Interceptors. Retrieved

January 10 2020, from https://web.archive.org/web/

20190512185820/http://hapifhir.io/doc_rest_server_int

erceptor.html

HAPI FHIR. (2020). HAPI FHIR - The Open Source FHIR

API for Java. Retrieved January 10, 2020, from

https://hapifhir.io/

Health Level 7 International. (2013). Confidentiality.

Retrieved January 19, 2020, from http://www.

hl7.org/documentcenter/public/standards/vocabulary/v

ocabulary_tables/infrastructure/vocabulary/Confidenti

ality.html

Health Level Seven International. (2013). Unique ID, R1 -

3. HCS Guide Final 2013 0322 JMD.pdf. Retrieved

January 16, 2020, from https://www.hl7.org/document

center/public/wg/secure/3.%20HCS%20Guide%20Fin

al%202013%200322%20JMD.pdf

HL7 International. (2019, January 4). Health Level Seven

International. Retrieved from https://www.hl7.org/

HL7 International. (2019, November 1). Resourcelist -

FHIR v4.0.1. Retrieved January 19, 2020, from

https://www.hl7.org/fhir/resourcelist.html

HL7 International. (2020). Index - FHIR v4.0.1. Retrieved

January 10, 2020, from http://hl7.org/fhir/

Li, J., & Li, N. (2006, Oct.-Dec.). OACerts: Oblivious

Attribute Certificates. IEEE Transactions on

Dependable and Secure Computing, 3(4), 340-352.

Posnack, S., & Barker, W. (2018, October 1). Health IT

Buzz. Retrieved January 4, 2019, from https://www.

healthit.gov/buzz-blog/interoperability/heat-wave-the-

u-s-is-poised-to-catch-fhir-in-2019

Ryutov et al. (2005). Adaptive Trust Negotiation and

Access Control. SACMAT '05 Proceedings of the tenth

ACM symposium on Access control models and

technologies (pp. 139-146). New York City: ACM New

Sanzi et al. (2017). Integrating Trust Profiles, Trust

Negotiation, and Attribute Based Access Control. 2017

5th IEEE International Conference on Mobile Cloud

Computing, Services, and Engineering (MobileCloud)

(pp. 177-184). San Francisco: IEEE. doi:10.1109/

MobileCloud.2017.30

Sanzi et al. (November 2016). Trust Profiling to Enable

Adaptive Trust Negotiation in Mobile Devices. In S.

Mukherja (Ed.), Mobile Application Development,

Usability, and Security (pp. 95-116). IGI Global.

Sanzi, E., & Demurjian, S. (May 2016). Identification and

Adaptive Trust Negotiation in Interconnected Systems.

In A. Malik, A. Anjum, & B. Raza (Eds.), Innovative

Solutions for Access Control Management (pp. 33-65).

IGI Global.

The Office of the National Coordinator for Health

Information Technology. (2018, September 19).

Meaningful Consent Overview | HealthIT.gov.

Retrieved January 24, 2020, from https://www.

healthit.gov/topic/meaningful-consent-overview

The Office of the National Coordinator for Health

Information Technology. (2019, April 17). Patient

Consent for Electronic Health Information Exchange |

HealthIT.gov. Retrieved January 24, 2020, from

https://www.healthit.gov/topic/patient-consent-

electronic-health-information-exchange

U.S. Department of Veterans Affairs - Office of Public and

Intergovernmental Affairs. (2019, July 29). VA

achieves critical milestone in its Electronic Health

Record Modernization Program. Retrieved January 4,

2020, from https://www.va.gov/opa/pressrel/press

release.cfm?id=5286

Vawdrey et al. (2003). Trust Negotiation for Authentication

and Authorization in Healthcare Information Systems.

Engineering in Medicine and Biology Society, 2003.

Proceedings of the 25th Annual International

Conference of the IEEE (pp. 1406-1409). IEEE.

Winsborough et al. (2000). Automated trust negotiation.

DARPA Information Survivability Conference and

Exposition, 2000. DISCEX '00. Proceedings. 1, pp. 88

- 102. Hilton Head, SC: IEEE. doi:10.1109/

DISCEX.2000.824965

Yasnoff, W. A. (2015). A Feasible and Sustainable

Approach to Health Information Infrastructure Via

Mobile Devices. Retrieved Oct. 23, 2015, from

http://mediasite.uchc.edu/mediasite41/Play/b409b6fea

70b4ec5b3fc34355340ac521d

Trust Proﬁle based Trust Negotiation for the FHIR Standard

251
