Reconfiguration Penalty Calculation for Cross-cloud Application

Adaptations

Vasilis-Angelos Stefanidis

, Yiannis Verginadis

, Daniel Bauer

, Tomasz Przezdziek

and Grigoris Mentzas

Institute of Communications and Computer Systems, National Technical University of Athens, Zografou, Greece

Institute of Organization and Management of Information Systems, University of Ulm, Ulm, Germany

CE-Traffic, Warszawa, Poland

Keywords: Cross-cloud Applications, Reconfiguration Penalty, Adaptation.

Abstract: Cloud’s indisputable value for SMEs and enterprises has led to its wide adoption for benefiting from its cost-

effective and on-demand service provisioning. Furthermore, novel systems emerge for aiding the cross-cloud

application deployments that can further reduce costs and increase agility in the everyday business operations.

In such dynamic environments, adequate reconfiguration support is always needed to cope with the fluctuating

and diverse workloads. This paper focuses on one of the critical aspects of optimal decision making when

adapting the cross-cloud applications, by considering time-related penalties. It also contributes a set of recent

measurements that highlight virtualized resources startup times across different public and private clouds.

1 INTRODUCTION

In cloud computing besides the on-demand

provisioning of resources, users are enabled with

features that allow the seamless adaptation of the

allocated resources, used for hosting applications

according to the constantly fluctuating workload

needs. This is achieved by either scaling in or scaling

out the infrastructure in times of lower or higher

demand, respectively. This ability to dynamically

acquire or release computing resources according to

user demand is defined in the computer science as

elasticity (Verma et al., 2011). Providing

infrastructural resources i.e. Virtual Machines (VMs),

becomes very important when these resources can be

ready in time to be used according to the users’

expectations.

Nowadays, modern data-intensive applications

increasingly rely on more than one cloud vendors, a

fact that makes elasticity even more challenging as a

feature (Horn et al., 2019). In order to decide in each

situation, based on a given application topology and

fluctuating workload, several aspects of the

reconfiguration costs should be considered (such as

time cost, data lifecycle cost etc.). In this work, we

present how the time dimension of this cost can be

considered, based on the VM startup times and the

application component deployment times. This cost is

evaluated as a part of a utility function that can reveal

whether a certain reconfiguration action is optimal for

the current cross-cloud application. Specifically, an

algorithm and a software tool are presented, in section

3, for calculating the reconfiguration cost of each

alternative topology that should be examined towards

a cloud application reconfiguration. In section 4, we

highlight the importance of the penalty calculator for

the reconfiguration decision making by using an

illustrative example. Through a set of related startup

measurements of virtualised resources in prominent

vendors, we reveal important findings about VM

provisioning. Last, we conclude this work and discuss

next steps in section 5.

2 RELATED WORK

In this section, we discuss some of the studies

performed that focus on the reconfiguration costs in

the cloud and the multi-cloud environment. Such a

work (Mao and Humphrey, 2012) provides a

systematic study on the cloud VM startup times

across three cloud providers (i.e. Amazon EC2,

Windows Azure and Rackspace). In this study,

measurements were reported, while an analysis of the

relationship among the VM startup time and different

factors, is given for comparing the three cloud

Stefanidis, V., Verginadis, Y., Bauer, D., Przezdziek, T. and Mentzas, G.

Reconﬁguration Penalty Calculation for Cross-cloud Application Adaptations.

DOI: 10.5220/0009410303550362

In Proceedings of the 10th International Conference on Cloud Computing and Services Science (CLOSER 2020), pages 355-362

ISBN: 978-989-758-424-4

355

providers. These factors include the size of OS

instance image, the instance type of the VM, the

number of instances concurrently deployed and the

time within the day that the reconfiguration/startup is

performed. Although this study is valuable the

measurements have been performed back in 2012 and

they need to be updated, while there is a lack of

exploitation of such data in terms of reconfiguration

decision making. In another work (Salfner et al.,

2011) the authors analyse the VM live migration

downtime during the reconfiguration process using

different cloud resources. The results from the

analysis after various experiments, showed that the

total migration time as well as the downtime of the

services running on the migrated VMs are mainly

affected by the memory usage of the VMs used. But

besides the significant findings, there is no described

method on how to take into consideration this time

cost in the reconfiguration process of the cloud

infrastructure in order to minimize its impact. What is

more the multi-cloud case of reconfiguration is not

examined at all. In a different approach, the authors

(Yusoh and Tang, 2012) propose a penalty-based

Grouping Genetic Algorithm for deploying various

Software as a Service (SaaS) composite components

clustered on VMs in different clouds. Their main

objective was to minimize the resources used by the

application and at the same time maintain an adequate

quality of service (QoS), respecting any constraints

defined. Based on the experimental results, their

proposed algorithm always produces a feasible and

cost-effective solution with a quite long computation

time though. In addition, no action is taken in this

study to incorporate in this penalty calculation the

time dimension for provisioning VMs, as a crucial

aspect of the reconfiguration process and the

availability of cloud applications.

Considering time aspects for the reconfiguration

penalty in the multi-cloud environments, it is also

noteworthy to examine cases were resources should

be used for which no prior data is available (e.g. a

custom VM for which no previous measurements are

available). In such cases several approaches exist that

are valuable. Uyanik and Guler (Uyanik and Guler,

2013) analyse in their study whether or not the five

independent variables in the standard model were

significantly predictive of the KPSS score (Kokoszka

and Young, 2015), the dependent variable, based on

ANOVA statistics (Rutherford, 2001). Their primary

objective was to exemplify the multiple linear

regression analysis with its stages. The assumptions,

necessary for this analysis, were examined and the

http://camel-dsl.org/

regression analysis was performed using related data

that were satisfying the assumptions. The standard

model’s prediction degree of the dependent model

was R=0.932, while the variance of the dependent

variable was R2=0.87. The model seems to predict

appropriately the dependent variable, but it is not so

accurate as the ordinary least squares (OLS) Multiple

Linear Regression algorithm (Rutherford, 2001).

Specifically, in the case of OLS algorithm a greater

than 95% value of R2 is achieved which means that

the proportion of the variance in the dependent

variable that is predicted from the independent

variables is greater than 95%. OLS regression

algorithm is one of the major techniques used to

analyse data and specifically to model a single

response variable which has been recorded on at least

an interval. For the above reasons the specified OLS

method is used for the Penalty Calculator Algorithm

described in the section 3.2.

3 PENALTY CALCULATOR

In this paper, an innovative platform which is called

Melodic is used as an automatic DevOps for

managing the life cycle of cross-cloud applications

(Horn et al., 2019), (Horn and Skrzypek, 2018). The

Melodic platform is built around a micro-services

architecture, able to manage container-based

applications and support some of the most prominet

big data frameworks. The main idea of Melodic is

based on models@run.time and states that the

application architecture, its components and the data

to be processed can all be described using a Domain

Specific Language (DSL). The application

description includes the goals of the efficient

deployment (e.g. reduce cost), complies with the

given deployment constraints (e.g. use data centres

located in various locations), and registers the current

state of the application topology, through monitoring,

in order to optimize the deployment of each

application component.

The Melodic platform-as-a-service (PaaS) is

conceptually divided into three main parts: i) the

Melodic interfaces to the end users; ii) the

Upperware; and iii) the Executionware. The first part

comprises tools and interfaces used to model users’

applications and datasets along with interacting with

the PaaS platform. Moreover, the PaaS is using

modelling interfaces that are established through the

CAMEL

modelling language, which provides a rich

set of DSLs with modelling artefacts, spanning both

CLOSER 2020 - 10th International Conference on Cloud Computing and Services Science

356

the design and the runtime of a cloud application as

well as data modelling traits. The second part

(Upperware) is responsible to calculate the optimal

application component deployments and the

appropriate data placements on dynamically acquired

cross-cloud resources.The optimal configuration of

the cross-cloud application topology refers to a utility

function evaluation. The utility function can be

defined as the function, introduced as a measure of

fulfillment for applying reconfiguration for cross-

cloud applications. This utility function requires the

use of a Penalty Calculator (used as a library) which

focuses on the reconfiguration time cost. In this paper

the time reconfiguration cost is mainly examined,

while there can also be other parameters to consider

such as the cost of transferring data. An important

part of this evaluation includes the VMs startup times

along with the expected deployment times of specific

application components that are to be reconfigured.

The Penalty Calculator provides normalized output

values between 0 and 1, where 0 indicates the lowest

possible penalty which indicates the most desired

solution and 1 indicates the highest possible penalty

which is the less desired solution.

For example, a utility function can be defined as

follows:

Solution configuration

UtilityFunction





(1)

Where the C

Solution

is a function of the number of

resources used for deployment. This implies the

satisfaction of certain goals (e.g. minimize the

deployment cost, minimize response time etc.)

expressed as a mathematical function:











_

(2)

While the C

Reconfiguration

is a function of the result

of the Penalty Calculator. This result represents the

value given by the Min-Max normalization method,

applied over the Ordinary Least-Squares Regression

(OLS) algorithm result described in paragraph 3.2:









_

(3)

The third part of Melodic includes the

Executionware which executes the actual cloud

application deployments and reconfigurations by

directly invoking the cloud providers APIs.

3.1 Approach

Penalty Calculator’s objective is to calculate a

normalized reconfiguration penalty value by

https://memcached.org/

comparing the current and the new candidate

configuration, coming from a constraing

programming solver component of the Upperware.

Therefore, the system examines a sequence of

candidate configurations under specific constraints

and optimization goals (e.g. reduce cost and increase

service response time) that will serve according to the

desired QoS the incoming workload. The Penalty

Calculator affects the decision on accepting and

deploying a new candidate cross-cloud application

topology based on its’ function value. The smaller the

penalty function is, the better is for the candidate

solution as it implies a smaller time for materializing

the proposed reconfiguration.

The Penalty Calculator is a part of the Melodic

Upperware and it is used as a library by the Utility

Generator, a component that calculates a single value

for each candidate solution, according to a utility

function that expresses the overall goals of the

application. The Penalty Calculator receives from the

Utility Generator, XMI files describing the

collections of configuration elements for the current

and the new proposed configuration (OS, hardware

and location related information of the virtualised

resources to host certain application components).In

order to use a high-performance, distributed memory

caching system intended to speed up the penalty

function calculations, the VM startup time data are

stored in memory, using the Memcache

solution.

The categorization of various VM startup times

include multiple variables for resources such as the

RAM, CPU cores, Disk, VM types names etc.

Regarding the component deployment times, these

are persisted and retrieved from a time-series

database. The various application components that

are deployed in cross-clouds are constantly measured

with respect to the deployment time needed and based

on the virtualized resource used. By using a time-

series database for this purpose, it allows for a quick

retrieval of the average deployment times. In this

work InfluxDB

was used.

3.2 The Penalty Calculator Algorithm

Based on the feed from the Utility Generator in

Melodic, the Penalty Calculator algorithm is applied

for comparing the old and the new proposed

(candidate) solution, issuing a penalty value, thus

affecting the decision on whether or not a specific

new solution should be deployed. This algorithm uses

measured VM startup times and measured component

deployment times (their average values) for

https://www.influxdata.com/

Reconﬁguration Penalty Calculation for Cross-cloud Application Adaptations

357

calculating the time-related cost for changing from

the current to a new application topology. If there are

no component deployment times from past

measurements, the algorithm takes into consideration

only the VM startup times. In case of new custom

VMs are to be provisioned, the Ordinary Least

Squares Regression Algorithm (Hutcheson, 2011) is

used to estimate the expected startup time by

exploiting the measurements of the available

predefined cloud providers’ flavours. The general

flow of the Penalty Calculator is given in Figure 2.

Figure 2: Penalty Calculator’s Flowchart.

It is very important to note that since the VM

startup times is not a constant property of the VM and

of each cloud provider, but depends on the current

state, load and configuration of each given cloud

infrastructure in conjunction with the chosen VM, the

used startup times values in the algorithm are real

ones and are updated and fetched in real-time from a

time-series database where these are stored.

Regarding the OLS algorithm, a single response

variable is used to model the VM startup time which

has been recorded for a specified range of values. The

specific technique is applied to multiple variables that

have been appropriately coded (i.e. RAM usage, CPU

core number and Disk usage). It’s purpose is to

calculate startup times regarding (custom) VM

flavours for which we do not have mesurements from

previous deployments. The general format of the OLS

model includes the relationship between a continuous

response variable Y and some continuous variables X

by using a line of best-fit, where Y is predicted at least

to some extend by variables X:

112 23 3

***YabX bX bX  

(4)

In equation (4), α indicates the value of Y when all

values of the explanatory variables X are equal to

zero. Each parameter b indicates the average change

in Y that is associated with a unit change in X, whilst

controlling the other explanatory variables in the

model. The Min-Max normalization method is used

as a last step in the Penalty Calculator by considering

the average values of all the VMs (to be used) startup

times of new configuration plus the average value of

the component deployment times.

4 AN ILLUSTRATIVE EXAMPLE

We note that the Penalty Calculator, presented in this

paper has been tested and evaluated in several real-

application scenarios. In this section, we present one of

them as an illustrative example for highlighting the

value of such an approach. We refer to a traffic

simulation application which is used by the company

CE-Traffic for the analysis of traffic and mobility-

related data as a basis for optimization and planning in

major European cities. The initial deployment consists

of five main components instances (also seen in Figure

3): i) traffic evaluation component (single instance); ii)

simulation manager (single instance); and iii)

simulation workers (three instances). The traffic

evaluator component is responsible for the traffic

analysis and sends to the simulation manager

information about the need of executing a simulation.

On the other hand, simulation workers are components

responsible for evaluating traffic simulation settings

received from the simulation manager.

Figure 3: Model of CET Traffic Simulation App.

We consider the following constraints and

requirements described in the data farming

application CAMEL model:

CLOSER 2020 - 10th International Conference on Cloud Computing and Services Science

358

• Single instance of the traffic evaluation

component

• Single instance of the simulation manager

• Between 0 and 10 instances of workers

• At least 2 CPU Cores per worker

• At least 2GB of RAM per worker

As expressed in the CAMEL model of the

application, reconfiguration and later horizontal

scaling of simulation worker instances is supposed to

happen within a limit of 1 to 100 instances. To trigger

this reconfiguration, the simulation manager collects

several metrics:

• TotalCores - the total number of cores

available in workers

• RawExecutionTime - the time of performing

a single task (running a single simulation) by

a worker

• SimulationLeftNumber - the number of tasks

(simulations) which should be still performed

• RemainingSimulationTimeMetric - the

remaining time in which the data farming

experiment should be finished

Values of these metrics are computed and updated

by the simulation manager which sends them to PaaS

platform described in the introduction of section 3. In

this PaaS platform we have implemented a distributed

complex event processing system that is able to

process incoming monitoring data in hierarchical way

(Stefanidis et al., 2018). Based on this processing the

system is able to detect at the appropriate time when

a new reconfiguration should be initiated to cope with

the detected current workload of the application.The

specified system receives values of metrics and

checks whether the data farming experiment is

expected το be finished on time. Finally the

‘MinimumCores’ composite metric is calculated in

order to help for the reconfiguration. In our case

example, 2 new workers are added in order to finish

the traffic simulation that described before. When the

simulations are finished the ‘MinimumCores’

composite metric is equal to zero and in the next

reconfiguration workers are being removed.

Although the above system works fine in the

majority of the cases, there are edge cases where a

reconfiguration might start (based on the scalability

rules) although the remaining simulation time is quite

small. In fact this means that we might observe a

behaviour where our system starts a reconfiguration

cycle which until it is fully implemented, the

application simulation will have been completed.

Therefore the consideration of the time that is needed

for any reconfiguration and as a consequence the time

penalty that our component calculates, is a critical

factor to be considered.

Such cases are resolved succesfully by using a

Penalty Calculator component that receives two

configurations schemas that are provided to it as

input. The new configuration schema presents new

elements (i.e. a new predefined VM flavour) and

some custom VM flavours, not predefined in the used

cloud providers (i.e. t1.microcustom). Specifically,

the predefined VM types in this example come from

2 cloud vendors: Amazon EC2 and Openstack. By

using the normalized value that it is produced from

Penalty Calculator and considered in the Utility

Function (UF) the previous described unecessary

reconfigurations are avoided. Zero is the most desired

output of Penalty Function and if the output is closer

to that value, it implies a smaller time for

materializing the proposed reconfiguration. On the

other hand, if the output of Penalty Calculator is

closer to one, then this is not desired and affects

negatively the UF for a new reconfiguration. In this

way reconfigurations that impose delays

unacceptable according to the current application

context are avoided.

4.1 Experiment Measurement Results

and Analysis

Table 1: Openstack Flavours Used.

Openstack Flavours VCPUs RAM (in MB)

m1.small2 2 1024

m1.medium2 4 4096

m1.large2 8 8192

m1.xlarge 8 16384

Table 2: Amazon EC2 Flavours Used.

EC2 Flavours VCPUs RAM (in MB)

t2.micro 1 1024

t2.small 1 2048

t2.medium 2 4096

t2.large 2 8192

t2.xlarge 4 16384

t2.2xlarge 8 32768

Considering the importance of the VM startup times

in cloud application reconfigurations, we conducted a

performance study that is presented in this section.

Similar to this work (Mao and Humphrey, 2012), we

conducted new measurements across one private and

one public cloud provider, specifically: i) an internal

testbed offered by the university of ULM in Germany

that corresponds to an Openstack installation; and ii)

Amazon AWS. A number of different regions from

the public providers and several VM types were used

in this analysis, which focused on the VM startup

times. More than 2500 measurements were conducted

Reconﬁguration Penalty Calculation for Cross-cloud Application Adaptations

359

that involved the provisioning of different VM

flavours, hosted in different data centre locations and

with an increasing number of VMs instantiated

simultaneously (Table 1, Table 2). For all of these

VMs, the same Ubuntu images were used.

To describe the lifecycle of the cloud VM

instances, cloud providers use a set of status tags to

indicate the states of the provisioned VM instances.

To make the definition of startup time consistent

across the cloud providers that were used in our

measurements, we ignore the status tags and

considered as VM startup time the duration from the

time of issuing a VM provision request to the time

that the acquired instances can be logged in remotely.

Figure 4: Average Startup times by Openstack VM flavour

(including standard deviations).

The first set of measurements across the cloud

providers focused on the relationship between the

VM startup time and the VM flavour used. Each set

of measurements included for each specific VM

flavour the provisioning of 1-20 instances either

sequentially or in parallel (by incrementally

increasing the VMs requested simultaneously). The

threshold of 20 instances per set of measurements was

imposed by the API limitations of the providers.

Figure 5: Average Startup times by Amazon EC2 VM

flavour (including standard deviations).

According to the outcome of these measurements

which can be found in Figures 4-5 the VM startup

time is longer for the private cloud provider than the

public one. Specifically, the Openstack VMs are

provisioned with an average startup time from 81 to

123 seconds depending on the VM flavour, while the

rest startup times are found from 49 to 66 seconds for

EC2 Cloud VMs. This is quite expected if we

consider the wide range of resources that is employed

by big vendors. With respect to the variance of the

conducted measurements, we found that the standard

deviation in Openstack VMs’ startup time is also

significantly higher than those of the public provider.

This implies a much more unstable environment in

the case of the private provider both in terms of

infrastructural resources and scheduling mechanism.

Figure 6: Average Startup times by Amazon EC2

Availability Zones (including standard deviations).

The second set of measurements was focused

around the different data centre locations offered by

the AWS public cloud providers and how this may

impact the startup time of VMs. In Figure 6, we

present the findings of our measurements. It is

important to note that we do not find a significant

fluctuation of the VM startup times as the requests for

VMs provisioning change among regions and

availability zones. The 55 seconds was the average

startup time even for VMs provisioned in US

locations. A slight improvement by 5 seconds was

observed in all VMs provisioned from the data centre

located in Paris, while the standard deviation of these

measurements didn’t exceed the 15 seconds.

In the last set of measurements, we tried to

examine the impact in the VM startup times as we

increased the number of VMs that were requested

simultaneously, reaching up to 20 VMs in parallel

(which is the threshold set by the Cloud providers).

The results are presented in Figures 7-8. In Openstack

VMs, we detected, as expected a much higher

fluctuation in the VM startup times, which is

gradually reduced as the requested VMs increase. In

addition, we found significant fluctuations among the

CLOSER 2020 - 10th International Conference on Cloud Computing and Services Science

360

same number of instances startup that reached even

the amount of 89 seconds when 7 VMs requested in

parallel, a fact that reveals unstable behaviour in case

of the private cloud provider. In the case of the public

provider, we witnessed a much more balanced

behaviour with minor fluctuations in the startup time.

Specifically, we observed average startup times

between 45 (for 10 instances) and 53 seconds (for 11

instances) as different simultaneous VMs startup

requests were submitted. This is quite reasonable as

the scheduling is done online and there are always

enough spare resources to directly schedule the

considerably small amount of resources that we were

requesting. We also note that in the previous similar

work (Mao and Humphrey, 2012), the authors have

measured in 2012 an average startup time in Amazon

EC2 VMs that of 100 seconds while in our recent

measurements we witnessed 48% shorter times. This

fact affirms the significant investments in

infrastructure that public cloud providers have made

over the last years.

Figure 7: Average Startup times in Openstack by the

number of concurrent instances (including standard

deviations).

Figure 8: Average Startup times in Amazon EC2 by the

number of concurrent instances (including standard

deviations).

4.2 Penalty Calculator Results

According to the measured values from the previous

paragraph 4.1, we present the VM startup times stored

in the system (Memcached memory) in order to be

used by the proposed Penalty Calculator for the needs

of our example: t2.micro-56 sec, t2.small-58 sec,

t2.medium-66 sec, t2.large-52 sec, t2.xlarge-50 sec,

t2.2xlarge-49 sec, m1.tiny-55 sec, m1.small-80 sec,

m1.medium-120 sec, m1.large-90 sec, m1.xlarge- 93

sec.

A table is used with the specific values on RAM,

CPU cores, and Disk for each type described in Table

3. This table is also stored in Memcached for fast

retrieval.

Table 3: VM Startup Times mapped to resources.

VM startup

time (sec)

Number of

cores for

vCPU

RAM (GB) Disk (GB)

56 1 0.6 0.5

58 1 1.7 160

66 4 7.5 850

52 8 15 1690

50 7 17.1 420

49 5 2 350

55 1 0.5 0.5

80 1 2.048 10

120 2 4.096 10

90 4 8.192 20

93 8 16.384 40

The values of Table 3 are used to train the

Ordinary Least-Squares Regression algorithm which

is used to help in the prediction of the unknown VM

startup times. By that way, the weights of the OLS

algorithm are adapted. The new custom VM type that

is used in this case is the t1.microcustom with a

predicted startup time of 57 sec.

Moreover, the component deployment times have

to be considered in the penalty calculator as explained

in section 3. The measured component deployment

times that have been stored in the InfluxDB are: Traffic

evaluation compontent - 372.7659902248333 sec,

Simulation manager component -

383.61119407688045 sec and Simulation Worker (per

each of the 3 instances) - 323.87364700952725 sec. By

using the above VM startup times and the component

deployment times the following regression parameters

of the equation (4) are produced:

A=96.69038582442504

B1= -8.070707346640273

B2=1.7404837523622727

B3=7.407279675477281E-4

With a r-Squared parameter: 0.9894791420723722

Reconﬁguration Penalty Calculation for Cross-cloud Application Adaptations

361

Based on these results, this algorithm is quite

accurate and depends on the value of the 3

explanatory variables to 98.95% and 1.7% to the

constant value of a. This is used in order to give an

accurate prediction for any custom VM type that may

be used as part of a new configuration in the new

Cloud infrastructure. Last, by using the Min-Max

normalization method, the system calculates a

Penalty value which is the normalized average value

of the VM startup time and component deployment

time and equals to 0.52197146827194. Based on this

value, the Utility Generator component is able to

decide the most appropriate configuration out of all

the available candidate configurations.

5 CONCLUSIONS

In this paper we focused on one of the critical aspects

for optimal decision making, with respect to

reconfiguration, in the dynamic environment of cross-

cloud applications. Specifically, we presented a

system for calculating time-related penalties when

comparing candidate new solutions that adapt a

current application topology which is unable to serve

an incoming workload spike. The algorithm

implemented considers both VM startup times, across

different providers and application component

deployment times for calculating a normalized

penalty value. This paper also discussed a set of

recent measurements that highlight virtualization

resources startup times across different public and

private providers.

The next steps of this work include the extension

of the VMs startup time measurements across more

providers, regions using additional VM flavours.

Moreover, this work will continue with the

consideration of data management and migration

related times for considering the complete lifecycle

management when calculating reconfiguration (time-

related) penalties.

ACKNOWLEDGMENTS

The research leading to these results has received

funding from the European Union’s Horizon 2020

research and innovation programme under grant

agreement No. 731664. The authors would like to

thank the partners of the MELODIC project

(http://www.melodic.cloud/) for their valuable

advices and comments.

REFERENCES

Baur, D., Domaschka, J., 2016. Experiences from building

a cross-cloud orchestration tool. Proceedings of the 3rd

Workshop on CrossCloud Infrastructures & Platforms.

ACM.

Fox, J., 2002. An R and S-Plus Companion to Applied

Regression, London: Sage Publications. London, UK.

Horn, G., Skrzypek, P., Prusinski, M., Materka, K.,

Stefanidis, V., Verginadis, Y., 2019. MELODIC:

Selection and Integration of Open Source to Build an

Autonomic Cross-Cloud Deployment Platform.

TOOLS 50+1: Technology of Object-Oriented

Languages and Systems Conference, Kazan, Russia.

Horn, G., Skrzypek, P., 2018. MELODIC: Utility Based

Cross Cloud Deployment Optimisation. 32nd

International Conference on Advanced Information

Networking and Applications Workshops (WAINA),

Krakow, pp. 360-3.

Hutcheson, G.D., 2011. Ordinary Least-Squares

Regression In L. Moutinho and G.D. Hutcheson, The

SAGE Dictionary of Quantitative Management

Research. London: Sage Publications, Pages 224-228.

Yusoh, Z., Tang, M., 2012. A penalty-based grouping

genetic algorithm for multiple composite SaaS

components clustering in Cloud. 2012 IEEE

International Conference on Systems, Man, and

Cybernetics (SMC). Seoul, South Korea.

Kokoszka, P., Young, G., 2015. KPSS test for functional

time series, Colorado State University, Colorado, USA,

Tech. Rep.

Mao, M., Humphrey, M., 2012. A Performance Study on

the VM Startup Time in the Cloud. IEEE Fifth

International Conference on Cloud Computing.

Honolulu, HI, USA

Rutherford, A., 2001. Introducing ANOVA and ANCOVA:

a GLM approach, London: Sage Publications. London,

UK, 2nd edition.

Salfner, F., Troger, P., Polze, A., 2011. Downtime Analysis

of Virtual Machine Live Migration. DEPEND 2011:

The Fourth International Conference on Dependability.

French Riviera.

Stefanidis, V., Verginadis, Y., Patiniotakis, I., Mentzas, G.,

2018. Distributed Complex Event Processing in

Multiclouds. 7th IFIP WG 2.14 European Conference,

ESOCC 2018. Como, Italy.

Uyanik, G., Guler, N., 2013. A study on multiple linear

regression analysis. Procedia - Social and Behavioral

Sciences 106, pp 234 – 240.

Verma, A., Kumar, G., Koller, R., Sen, A., 2011.CosMig:

Modeling the Impact of Reconfiguration in a Cloud.

IEEE 19th Annual International Symposium on

Modelling, Analysis, and Simulation of Computer and

Telecommunication Systems, Singapore.

CLOSER 2020 - 10th International Conference on Cloud Computing and Services Science

362
