Migration of Monolith Applications to Miniservices: A Case Study

from the Telecom Domain

Ümit Kanoğlu

, Ali İmre

and Oumout Chouseinoglou

Türk Telekom, Ankara, Turkey

Department of Industrial Engineering, Hacettepe University, Ankara, Turkey

Keywords: Service Computing, Miniservices, Microservices, Miniservice Migration.

Abstract: More organizations are considering the transformation of their existing monolithic applications to

microservices in order to increase competitiveness and utilize the benefits of new software architectures which

meet their business needs. However, due to detailed and extensive requirements of the microservice

architecture (MSA), organizations either implement microservices at different granularity levels or decide not

to undertake this migration even though the business need is evident. Miniservices have been proposed as an

intermediate alternative between monoliths and microservices, with a larger scope of services and more

relaxed architectural constraints. This paper introduces the concept of miniservice architecture (MnSA) to the

industry domain, proposes a methodology to be implemented for the migration of a monolith application to

MnSA and shows the applicability of this methodology with a detailed case study from the telecom domain.

1 INTRODUCTION

Large enterprises over the years of their operation

generally accumulate a software inventory of large

and elephantine monolithic systems. Continuously

changing business requirements and environments

lead to these monolithic systems getting inevitably

larger and implementing changes while trying to meet

budget and schedule constraints but also satisfying

quality, availability, and reliability levels can be very

challenging (Levcovitz, Terra, & Valente, 2015)

(Dragoni, et al., 2017). One of the newest proposed

alternatives to the monolithic approach is the

microservice architecture (MSA), based on the

service-oriented computing and defined as “an

approach for developing a single application as a suite

of small services, each running in its own process and

communicating with lightweight mechanisms”

(Lewis & Fowler, 2014). Even though MSA has been

proposed as a solution for the inefficiencies and

problems caused by the monolith architecture and a

strong industry interest in migrating legacy systems

to MSA exists (Di Francesco, Lago, & Malavolta,

2019), MSA can also be a high-cost, disruptive, and

https://orcid.org/0000-0001-8245-1355

https://orcid.org/0000-0001-9477-0660

https://orcid.org/0000-0002-8513-351X

often less predictable undertaking for many

enterprises due to the lack of experienced

development teams (Christudas, 2019). As a deficient

implementation of MSA would not fully resolve the

already existing problems of a monolithic application,

the miniservice architecture (MnSA) has been

proposed as an intermediary architectural approach.

MnSA, compared to monolithic architecture

aggregates functionality related to a specific domain,

whereas compared to MSA, MnSA has a larger scope

and more relaxed architectural constraints, and may

or may not use independent data (Christudas, 2019)

(Thomas & Gupta, 2017). In other words, a

miniservice can be described as a structure that may

consist of functionalities which could be decomposed

to more than one microservice and share databases

(DB) with other miniservices, thus allowing a more

relaxed design and development for the organization

with the realization of the advantages of the MSA.

The introduction of the concept of miniservices has a

specific importance as findings from the industry

show that not every implementation of microservices

adheres to the characteristics of “pure microservices”,

and service granularity is one of the characteristics

390

Kano

glu, Ü.,

Imre, A. and Chouseinoglou, O.

Migration of Monolith Applications to Miniservices: A Case Study from the Telecom Domain.

DOI: 10.5220/0009408103900397

In Proceedings of the 15th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2020), pages 390-397

ISBN: 978-989-758-421-3

not followed in many microservice applications

(Bogner, Fritzsch, Wagner, & Zimmermann, 2019).

As in the case of microservices (Baresi, Garriga,

& De Renzis, 2017), when planning a migration of a

monolith system to an MnSA or when designing an

application from scratch considering an MnSA,

discovering the level of granularity and cohesiveness

that would be adequate for the miniservices is an

important problem that needs to be addressed by the

people responsible for the migration. To the best of

our knowledge, this is the first paper that proposes a

methodology for the migration of an existing

monolithic application to an MnSA, and displays the

applicability of the proposed approach with a case

study. However, it should be noted that the proposed

methodology is not a technical decomposition but a

high-level design and analysis, based on the business

needs of the organization evaluating the migration to

miniservices. The contributions of this research are

therefore threefold; we introduce the alternative of

MnSA as proposed by Christudas (2019) and Gartner

Research report (Thomas & Gupta, 2017) for

organizations that want to migrate to MSA but cannot

handle the detailed and extensive requirements of

microservices, we propose a migration methodology

to MnSA and finally evaluate its applicability with a

case study.

The aforementioned case study was conducted on

an enterprise application in Türk Telekom, one of the

largest telecommunication companies and the first

integrated telecommunication operator in Turkey,

with a history of 178 years. As of September 2019,

Türk Telekom provides telecommunication services

to 14.6 million land line, 11.3 million broadband, 3.6

million TV and 22.8 million mobile subscribers. In

this paper, the Customer Problem Management

(CPM) (TMForum Frameworx, 2019) application

from the enterprise application inventory of Türk

Telekom that serves all the aforementioned customers

has been selected, and the migration of CPM to

MnSA is examined and documented as a case study,

with a specific focus on the lessons learned

throughout the project management of this migration

process. The CPM application was developed initially

as a monolithic system with the aim of centralizing in

an end-to-end way numerous different service failure

management processes running on different systems

at Türk Telekom. CPM is providing the Service

Failure Management Product which facilitates the

failure management in different broadband services

of Türk Telekom (e.g. xDSL, PSTN, IPTV, Data,

P2P, etc.), allows reception of failures from different

channels, manages the sending and receiving of

failure notifications, stores and monitors end-to-end

records of failures, facilitates problem management,

provides inter-team workflows, and has the capability

of generating executive reports that may support

future investment decisions and further decisions at

strategic level. As CPM manages the failures

submitted by customers, its accessibility level is

required to be at the highest. Moreover, as a result of

the continuously introduced new products and

services, and rapidly changing legislations and

technology in the telecom domain, CPM is required

to meet the changing functional requirements of both

internal and external customers. However, as CPM is

a monolithic application, the deployment of any

changes to the live environment is only possible by

stopping the whole CPM and all associated services.

The rest of this paper is organized as follows:

Section 2 provides a brief literature review of related

studies and approaches from the microservices

domain, Section 3 describes the proposed

methodology, Section 4 summarizes the migration of

the CPM application to an MnSA as a case study, and

finally Section 5 concludes the findings, gives the

evaluation of the proposed approach by a team of

developers, summarizes the lessons learned and refers

to the planned future work.

2 LITERATURE REVIEW

The migration literature on MnSA is almost non-

existent as the concept of miniservices is considerably

new compared to microservices. Similarly, no case

studies documenting the success of migration to an

MnSA exist. However, a number of studies have

addressed the problem of decomposing an already

existing monolithic application to microservices or

documented case studies of migration from

monolithic applications to MSA. Even though there

are notable differences between the concept of MSA

and MnSA, we believe that similar studies in the

domain of microservices would shed light to better

understanding the implementation of miniservices.

Several software products exist that have been

developed as solution to the problem of microservice

identification, such as Service Cutter (Service Cutter;

Gysel, Kölbener, Giersche, & Zimmermann, 2016) or

graph based analysis by using Neo4J GraphGist

(Bastani, 2015). A systematic mapping study by Di

Francesco, Lago and Malavolta (2019) by examining

103 studies regarding microservices displays the

current trends in the microservices research and the

gap between academy and industry in this domain.

Baresi, Garriga and De Renzis (2017), by utilizing

a clustering approach, propose a solution to the

Migration of Monolith Applications to Miniservices: A Case Study from the Telecom Domain

391

problem of identifying microservice granularity

based on the semantic similarity between predicted

and available functionality of the application, with a

success rate of 80% in correct identification of

microservices. Levcovitz, Terra and Valente (2015)

propose a six-step technique to identify microservices

on existing monolithic systems and successfully

display the applicability of their proposed approach

on a 750KLOC real-world monolithic banking

system. Their proposed approach has as initial step

the evaluation and classification of the DB tables of

the monolith system into business subsystems, thus

not being entirely applicable to a miniservice

viewpoint where the organization may not require the

decomposition of the DB. Use cases or user interfaces

have also been proposed (Richardson, 2014) to be

used for the decomposition of monolithic applications

to microservices. Fritzch et al. (2019), by examining

the MSA migration of 14 systems from different

business domains, identify as an important drawback

the fact that most organizations preferred to rewrite

their codebase instead of splitting it as they had highly

complex legacy systems. The authors argue that in

some cases this was because of the absence of a

suitable decomposition approach, and therefore a

major technical challenge was finding the right

service cut. Mazzara et al. (2018) present a real-world

case study regarding the migration to MSA of a

mission critical system from the banking industry.

The authors identify and propose a repeatable

migration process that can be used to convert a

monolithic application coming from the financial

domain (with the characteristics of legacy systems

and batch-based processing on heterogeneous data

sources) into an MSA.

3 PROPOSED METHODOLOGY

As part of this study, a methodology to assess the

feasibility to migrate an existing monolithic

application to an MnSA is proposed. This migration

methodology is not a technical decomposition but

instead a high-level design and analysis, to be utilized

based on the business needs of the organization when

evaluating the migration to miniservices, and is in

accordance with the ITIL framework (What is ITIL,

2019).

The steps followed in the migration process are

given in a generic fashion and in the most general

form in Figure 1. In the first step of the migration

process a development team that is knowledgeable

about MSA and the application to be migrated is

formed and the application is logically decomposed

to miniservices. During this decomposition process

the mission and aims of the application, code isolation

in an MnSA basis, the integration of the application

with other applications, a viewpoint supportive of

continuous integration, delivery and development

(Microsoft, 2019) and the DB structure are

considered. Following this step, all updates done in

the previous year regarding the application in

question are collected from the respective change logs

and they are assigned to each proposed miniservice.

For each update an effort is estimated based on the

components of the miniservice that they are assigned

to and the historical effort data of this update. In the

third step the previous year’s updates are evaluated

based on the changes they resulted on the DB DDL.

If the updates have resulted in too many DB changes,

the decomposition of the DB at a miniservice level is

evaluated and discussed. At the fourth step the

proposed

miniservices are examined with respect to

Figure 1: Steps of the followed migration process.

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

392

the number of updates that they have been assigned

and if there are miniservices with excessive number

of updates, a new logical MnSA decomposition is

reconsidered. In the next step, the integration of the

miniservices with external applications is examined:

if the impact of the external applications concentrates

on a single miniservice the decomposition process is

executed again to form a new MnSA decomposition.

In the final step, if the decomposition of the

application to the proposed miniservices is acceptable

with respect to the aforementioned steps by the team,

the project management process within the

organization is initiated.

It should be noted that further steps may be added

to the proposed approach with respect to the specific

characteristics of the application being evaluated and

the overall requirements of the organization. The

main aim, however, should be realization of the

architectural and technological advantages of the

MnSA through the migration of the application to this

new architecture.

4 CASE STUDY

4.1 Current Architecture (AS-IS)

In this section, the migration process from monolith

to MnSA of CPM (TMForum Frameworx, 2019), an

enterprise application that resides in the Customer

domain of Türk Telekom as specified by the

TMForum Application Framework (Application

Framework - TAM, 2019) is documented. The

existing version of CPM was developed according to

monolithic architecture; that is development was

conducted on a single codebase in Java and the

application runs with a single DB. The monolith CPM

application consists of approximately 200 KLOC,

2,681 Java classes and 305 DB tables, and has

approximately 3,000 active users who execute an

average of 30,000 transactions per day. This version

of the CPM is being used for the last five years (2014-

2019) and has accumulated a DB size of

approximately 20 TB. When the planned and realized

application updates are examined it is observed that

during the last year of operations, 85 update requests

that required a total of 1,377 person/day effort were

realized and put to live, resulting to 22 planned

shutdowns of the live system that lasted

approximately a total of 35 hours. Figure 2, in order

to better describe the importance of the CPM

application, displays the enterprise applications

within Türk Telekom that CPM is related to and

works in an integrated fashion. As CPM is a monolith,

Figure 2: Relationship of CPM with other enterprise

applications in the organization.

even a single update or change in the code requires

the update of the whole application. Due to the

predefined enterprise application update policies,

during planned updates all servers and access to CPM

are shutdown. Moreover, in case of a problem in the

implemented update the application in all servers

needs to be rolled back.

4.2 Proposed Architecture (To-Be)

Considering the problems existing with the monolith

CPM, a migration of the application to MSA was

initially evaluated. With the employment of an MSA

approach it was intended to deploy updates more

rapidly and in a more flexibly fashion, decrease the

downtimes resulting from updates, and eliminate the

rollback process complexity in case of problems after

the deployment of updates. According to the MSA

principles each microservice is required to be able to

execute independently, needs to be associated with a

single functionality or task and data independence is

mandatory. However, as a result of the evaluation it

was decided that an MnSA approach would be more

appropriate for the migration from the monolith

architecture, and the migration methodology

described in Section 3 was followed.

The miniservices were identified by a migration

team of five software professionals, consisting of one

project manager, one solution architect, one

operations manager and two software developers. The

migration team have decomposed the monolith CPM

to miniservices by considering the existing codebase,

their experiences with the functionality of CPM and

the requirements of the organization by this

migration. One of the most important requirements

considered was the minimization of the downtimes

resulting from application updates. Following the

steps identified in Figure 1, the technical components

of the application were grouped and the miniservices

Migration of Monolith Applications to Miniservices: A Case Study from the Telecom Domain

393

were decomposed logically in such a way to support

continuous integration (CI) and continuous

deployment (CD). Following these steps, two major

MnSA versions were obtained, namely MnSA-1 and

MnSA-2, respectively shown in Figure 3 and 4.

Figure 3: Proposed MnSA-1.

In order to evaluate the efficiency of the proposed

MnSA’s, the updates realized during the last one year

were associated with the miniservices proposed in

each MnSA alternative. Table 1 and Table 2 show

how each one of the 85 updates and their actual effort

is associated with the MnSA alternatives developed

by the migration team. This miniservice and update

association was realized by evaluating the update

details by examining the update logs, the

functionalities that an update was related to, how

these functionalities were distributed to each

miniservice and by using the expert knowledge of the

team on how the update effort would be distributed to

the detailed components of each update.

Table 1: Analysis of the Proposed MnSA-1.

Changes Number %

Effort as

Person/

Day %

Total CPM + DB

Changes 59 69 1058 77

Only BPM Changes 3 4 16 1

Only LOV Changes 6 7 20 1

Only GUI Changes 5 6 65 5

Only NPM Changes 1 1 13 1

Multiple Changes

except CPM 11 13 205 15

Total Changes except

CPM + DB 26 31 319 23

Total Changes 85 100 1377 100

When MnSA-1 in Figure 3 is examined, it is

observed that 69% of the updates and 77% of the

realized effort is associated with the Customer

Problem Management miniservice that deals with the

problems transferred by other enterprise applications

and users to CPM. The migration team evaluated

these update and effort numbers to be too high, the

methodology given in Figure 1 was repeated taking

into account this observation. As a result, the

Customer Problem Management miniservice of

MnSA-1 was further decomposed to two

miniservices, proposing Customer Problem Entry

(CPE), a new miniservice that deals with the external

integrated enterprise applications. The new MnSA is

shown in Figure 4. When Table 2 is examined, it is

observed that with MnSA-2, 62% of all updates can

be realized without shutting down the CPE

miniservice which is vital for the reception of

problems communicated by other enterprise

applications and users.

According to the MnSA-2 proposal, the

monolithic CPM is decomposed consequently to

seven miniservices: CPE encompasses the web

services that receive user problem notifications by

other enterprise applications, Customer Problem

Management miniservice manages the overall

customer problems process, Network Problem

Management (NPM) miniservice are the web services

that allow the receipt of problems sent from other

enterprise applications regarding the problems in

network devices, Business Process Management

(BPM) miniservice manages the business processes,

List of Values (LOV) miniservice encompasses web

services that allow the query of a list of values that

exist in the problem management process and define

complaint types and problem causes by the external

WFM enterprise application, GUI miniservice is the

interface of the CPM application, and finally the DB

miniservice.

Figure 4: Proposed MnSA-2.

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

394

Table 2: Analysis of the Proposed New MnSA-2.

Changes Number %

Effort as

Person/

Day %

Total CPE + DB

Changes 32 38 565 41

Only CPM Changes 13 15 133 10

Only BPM Changes 3 4 16 1

Only LOV Changes 6 7 20 1

Only GUI Changes 5 6 65 5

Only NPM Changes 1 1 13 1

Multiple Changes

except CPE 25 29 565 41

Total Changes except

CPE + DB 53 62 812 59

Total Changes 85 100 1377 100

As the data integrity has been evaluated by the

migration team to be of high importance and the

percentage of updates that have affected the DB

during the last year have been identified as only 12%,

it was decided that there is no necessity of

decomposing the DB at the miniservice level, thus

justifying the reasoning of using an MnSA approach

instead of MSA. Figure 4 also shows the number of

Java classes that are associated with each proposed

miniservice.

4.3 MnSA Migration Process

In order to migrate to the proposed MnSA-2, the

codebase of the monolithic CPM is required to be

decomposed with respect to the proposed

miniservices. At this point, it was assessed by the

migration team that there is no need for changing the

tools and techniques used by the development team

for the realization of this migration, but it would

suffice to manage the development, compile and

deploy steps of each miniservice separately.

However, if the application servers are migrated to a

container structure then the development tools should

be updated to alternatives that would be compatible

with the container structure. It is proposed that in the

ideal case, similar to the MSA, the communication

between miniservices should be realized with

messages, however, it is argued that if required this

communication can be done through RESTful web

services. Moreover, a separate miniservice

development team may be formed for each

miniservice according to the MnSA approach. In the

current case study, it was decided by the migration

team that a single development team would manage

all proposed miniservices, and that as the

organizational experience regarding MnSA increases

and the teams mature on the migration and

management of miniservices future migration efforts

may be undertaken with the specialization of separate

teams at the miniservice level.

4.4 MnSA Operational Processes

As required by different legislations, the change

management processes in Türk Telekom are being

governed by the ITIL framework (What is ITIL,

2019). A foreseen further gain of the MnSA

migration, from the operational viewpoint, is making

the change management process more agile. Due to

the services that will be designed in a distributed

fashion on a cluster structure, it will be possible to

make deployments related to the CPM services

without affecting the operation of other enterprise

applications integrated to the CPM. Moreover, with

the use of the automatic test run tools placed on top

of CI and CD pipeline it is expected that defects will

be resolved more rapidly and new updates will be

deployed to the live system in a timelier manner.

However, together with the gains at the

operational level, it is expected that the use of new

tools and techniques with the novel MnSA would

result in experiencing several difficulties at the

operational processes, in accordance with the findings

of Fritzch et al. (2019). These difficulties are foreseen

to be related to the configuration and use of new tools

for server management (e.g. Kubernetes), intra-

service communication (e.g. Kafka and Zookeeper),

and log management (e.g. Elasticsearch, Graphana,

Prometheus) by the operational users at the starting

level. Moreover, code management of miniservices

that have been decomposed with some predefined

logic by the migration team and are built on top of a

container structure is expected to be more difficult

compared to the monolithic architecture alternative.

Finally, as the DB in the proposed MnSA is still

designed in a relational way, no changes at the

operational are expected with respect to this

miniservice.

5 CONCLUSION

This paper introduces the possibility of migrating

monolith applications to MnSA at the industrial

setting, consequently proposes a methodology for the

migration of monolithic enterprise application

software to an MnSA, and applies and documents the

implementation of this methodology on a monolithic

enterprise application at Türk Telekom to display its

applicability at the organisational domain.

Migration of Monolith Applications to Miniservices: A Case Study from the Telecom Domain

395

As the case study of the proposed methodology,

the CPM, an enterprise application of five operation

years from the Türk Telekom application inventory is

selected. A migration team consisting of five software

professionals with experience at both microservices

and the CPM application was formed. In order to

decompose the monolith application to miniservices,

as a first step the codebase of the existing application

is investigated. By following the steps of the proposed

methodology and taking the codebase structure into

account, the basic functions and the processes of the

application, together with the experience and

knowledge of the migration team on microservices,

the first architecture, that is MnSA-1, is proposed.

The development of MnSA-1 required a 16

person/hour effort by the migration team. To evaluate

the efficiency of the proposed MnSA, the

implemented updates of the last year on the CPM

application were collected from the change logs of the

organization and each update was allocated by the

migration team to a miniservice in the proposed

MnSA, the effect and effort of each update on each

miniservice was estimated. The migration team spent

a 24 person/hour effort for this allocation process.

Having evaluated the findings of this allocation it was

decided that the proposed MnSA can be improved as

specific miniservices are overloaded, thus with an

extra effort of 24 person/hours the second architecture

was decomposed, that is MnSA-2. A project plan was

developed and was submitted to the Project

Management Office of Türk Telekom together with

the feasibility analysis and expected gains of this

migration. The migration of CPM to MnSA according

to the proposed MnSA-2 has been accepted to the

2020 Master Plan and will be evaluated with respect

to the overall Türk Telekom budget and priority

requirements.

In order to assess the effectiveness and the

possible gains of migrating CPM to MnSA as

proposed by migration team, an internal questionnaire

was prepared and distributed to the software team of

CPM. The development team consists of 16

individuals with an average of professional

experience in software development being 12 years

and an average experience at the organization being 9

years. The respondents are all university graduates

(10 bachelors, 6 graduate level), with 12 of them

having a diploma in Computer Science or Computer

Engineering. The development team members were

asked six questions based on the proposed benefits of

microservice migration in the literature and especially

selected from the work of Taibi, Lenarduzzi and Pahl

(2017), and the responses are given in Table 3.

The questions were specifically adapted to the

concept of miniservices. When the responses are

examined, even though the proposed architecture by

the migration team is not a pure MSA but instead an

MnSA, it is evident that the developers believe the

application will benefit from this transformation in all

six areas, namely agility, deployment risk, distributed

development, technology flexibility, server

scalability and increased resiliency.

Table 3: Responses of Development Team members

regarding the benefits of migrating to MnSA.

Question:

“Migration to this MnSA would…

No idea

Some

Very

Extremely

…increase the agility of the

application”

1 1 1 10 3

…decrease the risks associated

with deployment”

2 1 1 10 2

…would facilitate distributed

development”

3 0 1 6 6

…would allow technology

flexibility”

1 0 1 8 6

…would increase server

scalability”

3 0 0 8 5

…would increase server

resiliency”

5 2 0 7 2

In the documented case study, the MnSA was

developed with the use of approaches and techniques

introduced for microservices and MSA, as it is

apparent that these approaches may be used for

miniservices and migration to MnSA. Moreover, the

proposed MnSA is based to the requirements of the

organization and a logical decomposition of services.

Subsequent to this decomposition, the application

itself was decomposed to separate codebases.

Considering the requirement of data integrity, a DB

decomposition was not proposed as each miniservice

will be working with separate parts of the single DB

and moreover historical updates that were examined

show that DB updates are rare. Each proposed

miniservice may be deployed as a separate

application or can be managed accordingly with a

migration to a container structure. With the migration

to this structure the aim was to flexibly manage the

integration dependencies between applications,

decrease the service shutdowns and associated risks

during deployments, and thus adding agility to the

development process. Moreover, it is argued that with

a container server structure, improvements in

availability and scalability are realized. The most

evident gain of the proposed MnSA is that CPE, one

of the basic miniservices of the proposed MnSA and

which is associated with 62% of all updates realized

during the last year, can now be updated and deployed

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

396

without stopping the operation of other services

within the CPM application. This would significantly

decrease the downtime of the overall CPM

application, which was recorded to be 35 hours during

the operations of previous year.

The development of the methodology presented

in this paper has contributed to the existing

organizational know-how on microservice migration

and MSA/MnSA transformation. Moreover, the

proposed methodology was presented and

communicated with different IT units of Türk

Telekom to disseminate the microservice and

miniservice migration awareness. As a result of the

conducted presentations the Enterprise Architecture

Unit is considering the addition of the developed

methodology to the already existing two-phase

migration framework as a third and final step to be

implemented in future MSA/MnSA transformation

processes within Türk Telekom.

Depending on the success and organizational

reception of the proposed MnSA migration of the

CPM application, further enterprise applications from

the application inventory of Türk Telekom are

considered to be transformed following the proposed

methodology. As a future study, the applicability of

the MnSA migration methodology on applications

with different characteristics and requirements, and

the findings of these migration processes may be

documented and presented to provide a deeper insight

on the topic of miniservice migration. Moreover, we

are planning to investigate and model a methodology

for the required transformation of server

infrastructure, business processes and organizational

processes to meet the migration to an MnSA.

REFERENCES

Application Framework - TAM. (2019). Retrieved 12 10,

2019, from TMForum: https://www.tmforum.org/

application-framework/

Baresi, L., Garriga, M., & De Renzis, A. (2017).

Microservices identification through interface analysis.

European Conference on Service-Oriented and Cloud

Computing. Cham: Springer.

Bastani, K. (2015). Using Graph Analysis to Decompose

Monoliths into Microservices with Neo4j. Retrieved 12

24, 2019, from Kenny Bastani: https://

www.kennybastani.com/2015/05/graph-analysis-

microservice-neo4j.html

Bogner, J., Fritzsch, J., Wagner, S., & Zimmermann, A.

(2019). Microservices in Industry: Insights into

Technologies, Characteristics, and Software Quality.

2019 IEEE International Conference on Software

Architecture Companion (ICSA-C) (pp. 187-195).

IEEE.

Christudas, B. (2019). Practical Microservices

Architectural Patterns: Event-Based Java

Microservices with Spring Boot and Spring Cloud.

Springer.

Di Francesco, P., Lago, P., & Malavolta, I. (2019).

Architecting with microservices: A systematic mapping

study. Journal of Systems and Software, 150, 77-97.

Dragoni, N., Giallorenzo, S., Lafuente, A., Mazzara, M.,

Montesi, F., Mustafin, R., & Safina, L. (2017).

Microservices: yesterday, today, and tomorrow. In

Present and ulterior software engineering (pp. 195-

216). Cham: Springer.

Fritzsch, J., Bogner, J., Wagner, S., & Zimmermann, A.

(2019). Microservices Migration in Industry:

Intentions, Strategies, and Challenges. arXiv preprint

arXiv:1906.04702.

Gysel, M., Kölbener, L., Giersche, W., & Zimmermann, O.

(2016). Service Cutter: A Systematic Approach to

Service Decomposition. European Conference on

Service-Oriented and Cloud Computing (pp. 185-200).

Cham: Springer.

Levcovitz, A., Terra, R., & Valente, M. (2015). Towards a

technique. III Workshop de Visualização, Evolução e

Manutenção de Software (VEM), (pp. 97-104).

Lewis, J., & Fowler, M. (2014). Microservices: a definition

of this new architectural term. Retrieved 12 24, 2019,

from martinfowler.com: https://martinfowler.com/

articles/microservices.html

Mazzara, M., Dragoni, N., Bucchiarone, A., Giaretta, A.,

Larsen, S., & Dustdar, S. (2018). Microservices:

Migration of a mission critical system. IEEE

Transactions on Services Computing.

Microsoft. (2019). CI/CD for microservices architectures.

Retrieved 12 1, 2019, from Microsoft Azure:

https://docs.microsoft.com/en-

us/azure/architecture/microservices/ci-cd

Richardson, C. (2014). Microservices: Decomposing

Applications for Deployability and Scalability.

Retrieved 12 24, 2019, from InfoQ: https://

www.infoq.com/articles/microservices-intro/

Service Cutter. (2019). Retrieved 12 24, 2019, from Service

Cutter: https://servicecutter.github.io/

Taibi, D., Lenarduzzi, V., & Pahl, C. (2017). Processes,

motivations, and issues for migrating to microservices

architectures: An empirical investigation. IEEE Cloud

Computing, 4

(5), 22-32.

Thomas, A., & Gupta, A. (2017). Innovation Insight for

Miniservices. Retrieved 12 10, 2019, from Gartner

Research: https://www.gartner.com/en/documents/

3615120

TMForum Frameworx. (2019). Retrieved 11 12, 2019, from

ILSA: http://www.ilsa.kz/etom/main/

tamapplication2.htm

What is ITIL. (2019). Retrieved 12 16, 2019, from ITIL:

https://www.axelos.com/best-practice-solutions/itil/

what-is-itil

Migration of Monolith Applications to Miniservices: A Case Study from the Telecom Domain

397
