Low Cost Big Data Solutions: The Case of Apache Spark on Beowulf

Clusters

Marin Fotache

, Marius-Iulian Cluci

and Valerică Greavu-Șerban

Al. I. Cuza University of Iasi, Romania

Keywords: Big Data, Beowulf Clusters, Apache Spark, Spark SQL, Machine Learning, Distributed Computing, TCP-H.

Abstract: With distributed computing platforms deployed on affordable hardware, Big Data technologies have

democratised the processing of huge volumes of structured and semi-structured data. Still, the costs of

installing and operating even relatively small cluster of commodity servers or the cost of hiring cloud

resources could prove inaccessible for many companies and institutions. This paper builds two predictive

models for estimating the main drivers of the data processing performance for one of the most popular Big

Data system (Apache Spark) deployed on gradually increased number of nodes of a Beowulf cluster. Data

processing performance was estimated by randomly generated SparkSQL queries on TPC-H database schema,

with variable number of joins (including self-joins), predicates, groups, aggregate functions and subqueries

included in FROM clause. Using two machine learning techniques, random forest and extreme gradient

boosting, predictive models tried to estimate the query duration on predictors related to cluster setup and

query structure and also to assess the importance of predictors for the outcome variability. Results were

positive and encouraging for extending the cluster number of nodes and the database scale.

1 INTRODUCTION

Before Big Data advent, massive data processing and

analysis was accessible to only big companies and

institutions. Both Big Data and Cloud Computing

opened the gates for data processing “democracy”.

Cloud computing has provided scalable storage and

processing platforms with prices depending on

consumed or rented resources (Josep et al., 2010;

Yang, 2017). The umbrella of technologies labelled

as Big Data provided, among other options, the

possibility to create data processing infrastructures by

deploying distributed storage and computing on

commodity hardware (Assunção, 2015; Van Dijck,

2014; Hashem et al., 2015).

While dramatically decreasing the cost for

operating private/organisational data centers, the

necessary hardware for deploying private Big Data

systems is far from negligible. Also costs associated

with hiring big data resources in cloud can steeply

increase when data volume and processing

complexity amplify (GCP, 2019).

https://orcid.org/0000-0002-5873-159X

https://orcid.org/0000-0002-8427-5436

https://orcid.org/0000-0003-2619-4598

For many categories of non-critical data

processing and data analysis tasks, deploying big data

clusters on the organisation’s workstations and using

them when they are idle (off the office hours) can be

appealing, especially when building and testing

prototypes, summarise/aggregate data, develop/apply

algorithms etc. (Fotache et. al, 2018b; Cluci et al.,

2019).

This paper tries to assess the data processing

performance of a popular big data platform (Apache

Spark) installed on small, but gradually extended

Beowulf cluster. Data processing performance is

expressed by the duration of a series of various

SparkSQL (Spark’s SQL dialect) queries executed on

different settings of the cluster and different sizes of

the database. In order to ensure data variability and

appropriateness for statistical analysis, queries were

generated randomly, using a module developed by the

authors. Resulted queries varied in terms of length,

number of joins, number of subqueries in FROM

clause, predicates included in WHERE clause,

groups, etc.

Fotache, M., Cluci, M. and Greavu-¸Serban, V.

Low Cost Big Data Solutions: The Case of Apache Spark on Beowulf Clusters.

DOI: 10.5220/0009407903270334

In Proceedings of the 5th International Conference on Internet of Things, Big Data and Security (IoTBDS 2020), pages 327-334

ISBN: 978-989-758-426-8

327

Collected data was subsequently examined. Two

series of predictive models were fitted and assessed

through repeated cross-validation using random

forests and extreme gradient boosting. Models not

only estimated the query duration on various cluster,

database and query parameters, but also assessed the

importance of the predictors in explaining the

variability of the outcome.

2 RELATED WORK

Apache Spark (Spark, 2019) is a unified analytics

engine with excellent performances in large-scale

data processing (Gopalani & Arora, 2015; Armbust et

al., 2018; Lin & Hsu, 2019). SparkSQL module

provides support for running SQL queries on top of

the Spark framework by exploiting the cluster

capabilities and DAG optimizations. It can ingest data

from various sources such as .csv files, Avro, Parquet,

Hive tables, and many NoSQL and SQL data stores.

Ilias (2017) showed that SparkSQL is faster than

Apache Hive (a big data processing contender), since

Spark has a set of techniques to reduce reads and

writes to disk. Moving the core of data processing

from disc to memory makes Spark suitable for

Beowulf clusters since they usually lack impressive

hardware resources.

Similar to other types of computer clusters,

Beowulf clusters share storage and processing among

nodes, but they can be deployed on commodity

hardware. Unfortunately, studies on deploying Spark

on Beowulf clusters are sparse, since this big data

architecture is less glamorous and performs poorer.

Huamaní et al. (2019) deployed an experimental

cluster to test big data features using workstations

similar to the study described in this article. They

assess the cluster performance based on the

calculation of prime numbers. Other research

approached the parallel processing performance of

non-commodity hardware devices, such as Raspberry

Pi (Papakyriakou, et. al., 2018) or were concerned

with low energy consumption (Qureshi & Koubâa,

2019).

We share the idea that the future of parallel

processing technologies is based on cloud

technologies (public, private or hybrid), generally

accepting the costs associated with them. But, as this

study will show, the internal resources of companies

can still be cheaply and efficiently exploited in

creating models for analysing data on small and

medium datasets, or in deploying and testing features

and performance of some big data tools.

3 EXPERIMENTAL DESIGN

The paper’s main objective was to build models for

estimating (predicting) the duration of SparkSQL

queries, controlling for various parameters of the

cluster, database size and query complexity. For three

database sizes (1GB, 10 GB and 100GB) 100 queries

were randomly generated and then executed varying

the cluster manager (Standalone, YARN and Mesos

1), the available RAM on the workstations (4GB,

6GB and 8GB) and the cluster’s number of nodes (3,

6 and 9).

The setup was deployed between January and

June 2019 in a university lab off the class activities,

i.e. from 20:00 PM to 6:00 AM and also during

weekends and holidays. The idea was to use the

systems after the daily schedule, in order to assess

whether this could work in a real-life situation.

Further information about the cluster is displayed in

section 3.1, but the technical proprieties of those

machines fit our design.

Some of the queries were cancelled by the system

due to their complexity (mainly, because of large

numbers of self-joins and subqueries in FROM

clause). For the completed queries the execution time

was collected.

The second objective of the predictive models was

to identify the most important predictors for the

outcome variability. Both objectives were achieved

using two of the most popular Machine Learning

techniques, random forests and extreme gradient

boosting.

3.1 Beowulf Cluster

For this paper the cluster consisted of 10 computers

of which, one was the master and the other 9 worked

as nodes. The computers were equipped with 16GB

of DDR3 RAM, the Intel i5-4590 3.30GHz processor

with 4 cores, 4 threads and 6MB of cache memory;

the hard disk capacity was 500GB; the network was

of type 100Mbps.

Each computer had Windows 8.1 64-bit installed

and run VMs in VirtualBox 5.2.26, which is a

distribution of Linux Ubuntu 18.04 LTS (Bionic

Beaver); Ubuntu was updated with the latest patches

and fixes as of 2 February 2019. Apache Spark 2.4.3

was installed along with Hadoop 3.1.2 for transferring

data (and for its resource manager), Apache Mesos

1.8.0, Scala 2.11.12 and JDK1.8_201. Monitoring

was performed with NMON v6.0 and Ganglia 3.7.2.

The dataset used for testing was provided by TCP-

H 2.4.0, a tool used by so many scholars and

professionals for benchmarking the data processing

IoTBDS 2020 - 5th International Conference on Internet of Things, Big Data and Security

328

performance (Chiba & Onodera, 2016). Three

datasets with the scales of 1 (representing 1 GB of

hard disk space), 10 (10 GB) and 100 (100 GB) were

stored in their raw format.

Data distribution among cluster nodes was

achieved with Hadoop Distributed File System

(HDFS). The block size was set at 256 MB and the

replication factor was the same as the number of

nodes in the test scenario (3, 6 or 9 accordingly).

Depending by the test case, each working node

was configured with either 4GB, 6GB or 8GB of

RAM. We decide not to go over 8GB because some

spare RAM should be reserved for the swap memory,

disk cache/buffer, paging and other OS operation

which could hinder our research, according to the

study made by Chen et al. (2016).

3.2 Apache Spark

SQL queries was processed by the SparkSQL module

which generates directed acyclic graphs (DAG) and

chooses the most efficient execution plan for each

specific query. Thus, there was no need to translate

the queries into Scala in order to run them on the

dataset.

For each query executed, Spark records the time

needed to complete and some other details, such as

how many stages and tasks were completed or used

for intermediate results. The stages and tasks are

created according to the DAG and resembles the steps

required to get the query result; the tasks are

distributed among the nodes for distributed

processing. DAG are also useful for recovering a

resilient distributed dataset (RDD) and instrumental

for Spark’s acknowledged performance and fault

tolerance (Jinbae et al., 2019). Furthermore, the

RDDs can also tweak performance, by using

Parallelized Collections which allow parallel usage of

a chunk (also called slice) from the dataset at the same

time in parallel by avoiding locks (Spark, 2019). All

these features, plus the in-memory computing, make

Apache Spark an excellent solution for Big Data

processing.

Regardless of the how well optimized are the

default algorithms used for scheduling, some

tweaking is still needed for some of the parts in the

ecosystem, such as optimizations to the HDFS

settings, dataset, the cluster manager used and

especially to the JVM (Chiba & Onodera, 2016).

3.3 Data Processing Tasks (Queries)

One the most popular benchmark for assessing the

data processing performance of various systems is

TPC-H (TPC-H, 2018a). The benchmark provides an

8-table database schema, a tool (DBGen) for

generating random data for various scale factors

(TPC-H, 2018b) and a set of 22 pre-defined queries.

Even if the pre-defined queries were designed to

stretch the data processing capabilities of the tested

systems, they lack variability and randomness. Also,

their small number is not particularly suitable for

statistical or machine learning analysis.

Consequently, the tested queries were generated

by a special module (Fotache and Hrubaru, 2016;

Fotache et al., 2018a) which randomly builds valid

TPC-H queries in various SQL dialects. Generated

queries contain various number of tables (to be joined

or self-joined), WHERE predicates, grouping

attributes, simple HAVING predicates and

subqueries included in the FROM clause of the main

query. The values included in the predicates are

extracted (also randomly) from the records populated

with DBGen. The appendix shows a generated query.

4 METHOD, TOOLS

For each database size (scale factor) the 100-query set

was executed varying the cluster manager, the

workstations available RAM and cluster number of

nodes. Query duration of the completed queries was

collected. Next, exploratory data analysis examined

the variable distribution (trough bar plots and

histogram) and correlations among predictors (in

order to identify possible collinearities).

After data exploration, predictive models were

built using two popular machine learning techniques,

random forests and extreme gradient boosting. Model

performance was assessed with repeated cross-

validation. Both techniques also provide predictor

(variable) importance for the outcome variability.

4.1 Variables

The outcome variable of the predictive models is the

duration of each query completion. Variability of the

outcome was examined in relation to various

predictors related to the cluster setting, database size

and the query complexity.

Of the completed queries, 30% were executed on

limited 4GB-RAM workstations, 31% on limited

6GB-RAM and 39% on 8GB-RAM workstations

(predictor available_ram__gb). Grouped by the

Apache Spark cluster manager (variable

cluster_manager), 39% of the completed queries

were executed on Mesos, 35% on YARN and only

26% on Standalone manager. Also, the number of

Low Cost Big Data Solutions: The Case of Apache Spark on Beowulf Clusters

329

cluster nodes (variable n_of_nodes) was gradually

increased and the number of queries completed on

each of three settings (3-node, 6-node and 9-node

cluster) was similar.

The second group of predictors refers to the

database size (db_size__gb) and its relation to the

total memory available on the cluster (db_oversize).

Variable db_oversize signals if, when executing a

query, the database size exceeds or not the summed

cluster RAM. The class imbalance (82% frequency

for value “db < ram” and only 18% for “db >= ram”)

appears since, of the three scale factors, two had the

size smaller than the cluster total memory and only

one exceeded the cluster memory (100GB). Variable

db_size__gb had three values: 1 GB (frequency of

47%), 10GB (35%) and 100GB (18%).

The third series of predictors are related to the

query complexity and describe the structure of

SELECT, FROM, WHERE, GROUP BY, HAVING

and ORDER BY clauses. 81% of the completed

queries contain at least a filter included in WHERE

clause (predictor where_clause) and 32% contain

filters at group level included in HAVING (predictor

having_clause). The main FROM clause includes two

subqueries in 44% of the completed queries, one

subquery in 2% of the queries and no subquery for

54% of the queries (predictor sub_clauses).

Figure 1: Predictors related to query complexity (1).

In figure 1, variable aggr_functions records the

number of aggregation functions (COUNT, SUM,

MIN, MAX, AVG) appearing in the main query and

the subqueries, no matter if they are in conjunction

with GROUP BY or not; inner_joins keeps track of

the number of inner joins included in the query

syntax, whereas order_by and group_by record the

number of attributes used in ORDER BY and

GROUP BY clauses.

Variable and_clause (figure 2) acts as a proxy for

the number of predicates included in WHERE, since

predicates are randomly connected by AND and OR.

Variable in_clause keeps track of the number of

values included in predicates using IN option.

Figure 2: Predictors related to query complexity (2).

A special note on tasks_runned predictor (also in

figure 2): even it is not directly controllable in the

experiment, it acts as an additional proxy for query

complexity, being a consequence of the execution

plan performed by the system. It does not completely

overlap with the number of join and number of

subqueries variables, since any join could be a

“simple” join or a self-join, performed among two

tables or “chain” of tables – see the example in

appendix.

After data exploration, predictive models were

built using two popular machine learning techniques,

random forests and extreme gradient boosting. Model

performance was assessed with repeated cross-

validation. Both techniques also provide predictor

(variable) importance for the outcome variability.

4.2 Tools for Data Exploration and

Predictive Modelling

All the data processing and analysis was performed in

R (R Core Team, 2019). Data processing was

deployed using the tidyverse ecosystem of packages

(Wickham et al., 2019). Graphics were created with

ggplot2 (Wickham, H., 2016) package which is part

of the tidyverse, except the correlation plot in figure

6 generated with corrplot package (Wei & Simko,

2017).

Predictive models were built, assessed and

visualized using the tidymodels (Kuhn and Wickham,

2019) ecosystem, mainly the following packages:

rsample, recipe, parnsip and yardstick. Also, caret

(Kuhn & Johnson, 2013), ranger (Wright & Ziegler,

2017) and xgboost (Chen et al., 2019) packages were

used in model fitting and extracting the variable

importance. Package furrr (Vaughan & Dancho,

2018) helped speeding up the repeated cross-

validation of the models.

41%

39%

20%

14%

17%

12%

41%

43%

11%

25%

37%

17%

inner_joins order_by

aggr_functions group_by

123456789 01234567

0123 012345

500

1000

1500

2000

500

1000

1500

2000

500

1000

1500

2000

300

600

900

frequency

IoTBDS 2020 - 5th International Conference on Internet of Things, Big Data and Security

330

5 RESULTS, DISCUSSION

As pointed out in previous sections, the main variable

of interest for assessing the data processing

performance of Apache Spark deployed on a basic

Beowulf cluster was the interval (in seconds)

necessary for completing every SQL (SparkSQL)

query. Figure 3 displays the density plot of the

outcome limited to [0, 1000] seconds range.

Figure 3: Outcome density plot ([0, 1000] range).

The limitation was imposed for visualization

purposes. Otherwise, the values are scattered on the

[0.013 - 19440] range. Duration median is 15.4

whereas average duration was 225 seconds, which

provides a clear imagine of the extreme distribution

asymmetry.

The imbalance of the values frequency for the

db_size__gb predictor (section 4.1) was a signal of

the decreased number of completed queries when

increasing the database size. Only 18% of the queries

launched on 100GB database were completed and this

is a consequence of having numerous queries

containing subqueries and self-joins.

The asymmetry of query duration also suggests

that, for larger database scale factors, complex

queries, involving larger number of joins, self-joins

and subqueries, queries cannot be finalized and the

number of observations containing large values of the

outcome decreased drastically.

Before proceeding to the building and assessment

of the predictive models, correlations among

predictors was examined – see figure 4. Even if

machine learning techniques are not as sensitive to

collinearity as the parametrical techniques (such as

linear regression), collinearity must be taken into

consideration.

The correlation plot shows no strong collinearity

among predictors. Due to the skewness of the

predictors, non-parametric Spearman correlation

coefficient was preferred. The largest correlation was

recorded for (sub_clause, inner_join) pair of

predictors – 0.76.

Figure 4: Correlation among predictors.

In the next step predictive models were build

using random forest and extreme gradient boosting

techniques. Both random forests and extreme gradient

boosting belong to the tree-based family. Both

techniques growth ensembles of classification or

regression trees (CART).

Random forests combine bagging sampling

approach with the random selection of features so that

it increases the prediction accuracy and reduces the

prediction variance (Breiman, 2001). Random forests

manifest both computational (fast and easy to train,

few tuning parameters, parallelizable, built-in error

estimation, high-dimensional problems handling) and

statistical (measure of variable importance, missing

value imputation, class weighting) strengths (Cutler

et al., 2012).

Extreme gradient boosting (Chen & Guestrin,

2016) is a new, regularized implementation of

gradient boosting framework (Friedman et al., 2000).

Boosting combines the predictions of several "weak"

learners (e.g. one-level trees) using a gradient

learning strategy in order to develop a "strong"

learner. Extreme gradient boosting show sometimes

similar better results than the random forests,

handling complex data with high speed and prediction

accuracy.

Repeated cross validation (n = 5, k = 10) was used

to assess the model performance. Three metrics were

collected for each fold assessment sub-set (the fold’s

assessment data) – the concordance correlation

coefficient (Lin, 1989), mean square error and r-

squared. Figure 5 displays the distribution of

performance metrics across the folds for both families

0.000

0.005

0.010

0.015

0.020

0 250 500 750 1000

duration

density

0.09

0.12

0.02

−0.01

0.06

−0.01

−0.09

0.58

0.01

0.05

0.09

0.14

−0.02

−0.18

0.32

0.48

0.27

−0.03

−0.28

0.11

−0.01

0.06

−0.04

−0.01

−0.02

−0.15

0.04

−0.09

0.03

0.65

−0.01

−0.06

0.43

0.76

0.24

0.51

−0.01

−0.02

−0.01

−0.1

0.19

0.1

0.13

0.15

0.06

0.08

−1

−0.

0.2

0.4

0.6

0.8

n_of_nodes

available_ram__gb

db_size__gb

tasks_runned

inner_joins

in_clause

and_clause

group_by

aggr_functions

sub_clauses

order_by

n_of_nodes

available_ram__gb

db_size__gb

tasks_runned

inner_joins

in_clause

and_clause

group_by

aggr_functions

sub_clauses

order_by

Low Cost Big Data Solutions: The Case of Apache Spark on Beowulf Clusters

331

of models. Average ccc was .90 for random forests

and .88 for xgboost, whereas the average rsq was 0.84

for random forests and 0.80 for xgboost.

Figure 5: Main performance metrics for random forests and

xgboost models.

Since there was not so much variability in the

number of cluster nodes and available RAM, results

can be qualified as good. Also, for the given dataset,

random forests seem to perform better than xgboost.

Figure 6: Variable importance - Random Forests.

Both random forests and xgboost provides the

estimated importance of the predictors for the

outcome variability. Figure 6 shows the variable

importance estimated by the random forests using

permutation (Cutler et al., 2012). The most important

predictor is tasks_runned followed by the database

size. This underlines the importance of query

complexity, compared to the size of the database and

other cluster settings. The lack of importance for

predictors like number of nodes, db_oversize and the

cluster manager came as a surprise, since the quantile

regression model in (Cluci et al., 2019) identified

both the number of nodes and the cluster manager to

be statistically significant in explaining query

duration variability (admittedly, for both predictors

the Epsilon-squared and Freeman’s theta reported

small effect sizes).

Variable importance estimated by the xgboost

model is presented in figure 7. Similar to random

forest, in the xgboost final model the most important

predictor was tasks_runned, followed by

db_size__gb. Also, similar to previous chart, number

of nodes is not significant in the model. Surprisingly,

db_oversize is even less important in the xgboost

model.

Figure 7: Variable importance – xgboost.

Also, the number of joins, the presence of

WHERE and HAVING clauses are less prominent in

the xgboost model.

6 CONCLUSIONS AND

FURTHER RESEARCH

The main objective of the paper was to deploy and

assess the data processing performance (including the

performance drivers) of an Apache Spark distribution

deployed on a simple, affordable Beowulf cluster

ccc rmse rsq

0.75

0.80

0.85

0.90

0.7

0.8

0.9

1.0

1.1

1.2

0.84

0.86

0.88

0.90

0.92

.estimate

cluster_manager

n_of_nodes

db_size__gb

db_oversize

tasks_runned

inner_joins

where_clause

in_clause

and_clause

group_by

having_clause

aggr_functions

sub_clauses

order_by

0123

ortance

variable

tasks_runned

db_size__gb

in_clause

and_clause

inner_joins

group_by

order_by

n_of_nodes

where_clausewhere

aggr_functions

sub_clauses

db_oversizedb > ram

cluster_managerstandalone

cluster_manager yarn

having_clauseno having

0 255075100

ortance

variable

IoTBDS 2020 - 5th International Conference on Internet of Things, Big Data and Security

332

using (mainly off the office hours) a small subset of

modest organisational workstations.

Even if the variability of some predictors (such as

number of cluster nodes) was low, both machine

learning models have good results in predicting the

query duration based on main query and cluster

parameters. Random Forests model performed

slightly better than the xgboost model, with the

concordance correlation coefficient above 90% and

the R

about 85%.

Variable’s importance provided by both models

suggest, as expected, that the query complexity

(approximated the necessary Spark tasks for query

completion and the number of joins) is the main

driver of query performance. Also, the database size

was ranked as an important predictor.

Unexpectedly, predictors such as the cluster

number of nodes, the gap between the cluster memory

and the database size, the tuples grouping and group

filtering, the cluster manager were qualified as less

important (in the outcome variability) by the both

models.

Some further research directions may include:

 Increasing the number of cluster nodes;

 Running the queries on TPC-H databases with

larger sizes;

 Adding Kubernetes as a cluster manager in

order to have a whole image of all the available

resource managers;

 Making optimization to the JVM, the garbage

collection, and OS parameter for accelerating

Spark performance;

 Assess the performance of other Spark features

such as Streaming, Machine Learning and

GraphX in order to see how they perform on a

Beowulf cluster;

 Test with the dataset in other formats not just

the default generated by TCP-H: AVRO,

Parquet, blob storage and AWS S3, to see if

there are any performance gains;

 Diversify the hardware resources and storage

types (e.g. add SSDs or RAID configuration);

 Take into account the hardware bottlenecks

which might occur during the testing, and

quantification their effect on performance;

Run the queries on other Big Data systems (such

as Hive and Pig) to compare the performance;

Overall results suggest that running SQL queries

on Spark using modest Beowulf clusters is a viable

solution, but this need subsequent comparisons with

other Big Data solutions, on disk (e.g. Hive, Pig) or

in-memory (e.g. in-memory features of SQL servers,

MemSQL, VoltDB, Impala).

REFERENCES

Armbrust, M., Das, T., Torres, J., Yavuz, B., Zhu, S., Xin,

R., Ghodsi, A., Stoica, I. & Zaharia, M., 2018.

Structured Streaming: A Declarative API for Real-

Time Applications in Apache Spark, Proc. of the

SIGMOD'18, 601-613.

Assunção, M.D. et al., 2015. Big Data computing and

clouds: Trends and future directions. Journal of

Parallel and Distributed Computing, 2015, 79, 3-15.

Breiman, L., 2001. Random Forests, Machine Learning, 45,

pp.2-32

Chaowei, Y., Huang, Q., Li, Z., Liu, K., Hu, F., 2017. Big

Data and cloud computing: innovation opportunities

and challenges. International Journal of Digital Earth,

10, 13-53.

Chen, Q., Wang, K., Bian, Z., Cremer, I., Xu, G. and Guo,

Y., 2016. Simulating Spark Cluster for Deployment

Planning, Evaluation and Optimization, SIMULTECH

2016, SCITEPRESS, 33-43

Chen, T. & He, T., 2019. xgboost: Extreme Gradient

Boosting. R package version 0.90.0.2.,

https://CRAN.R-project.org/package=xgboost

Chen, T., Guestrin C., 2016. XGboost: a scalable tree

boosting system. Proc. of the 22nd ACM SIG KDD

International conference on Knowledge Discovery and

Data Mining. ACM Press, 785–94.

Chiba, T., Onodera, T., 2016. Workload characterization

and optimization of TPC-H queries on Apache Spark.,

Proc. of the ISPASS 2016, 112-121

Cluci, M.I., Fotache, M., Greavu-Șerban, V., 2019. Data

Processing Performance of Apache Spark on Beowulf

Clusters. An Overview. In Proc. of the 34th IBIMA

Conference

Cutler A., Cutler D.R., Stevens J.R., 2012. Random Forests.

In: Zhang C., Ma Y. (eds) Ensemble Machine Learning.

Springer, Boston, MA

Fotache, M., Hrubaru, I., 2016. Performance Analysis of

Two Big Data Technologies on a Cloud Distributed

Architecture. Results for Non-Aggregate Queries on

Medium-Sized Data. Scientific Annals of Economics

and Business, 63(SI), 21-50

Fotache, M., Tică, A., Hrubaru, I., Spînu, M.T., 2018a. Big

Data Proprietary Platforms. The Case of Oracle

Exadata, Review of Economic and Business Studies, 11

(1), 45-78

Fotache, M., Greavu-Șerban, V., Hrubaru, I., Tică, A.,

2018b. Big Data Technologies on Commodity

Workstations. A Basic Setup for Apache Impala. Proc.

of the 19th International Conference on Computer

Systems and Technologies (CompSysTech'18), ACM

Press

Friedman, J., Hastie, T., Tibshirani, R., 2000. Additive

logistic regression: a statistical view of boosting. The

Annals of Statistics, 28(2), 337–407.

GCP, 2019. Google Cloud Platform blog and

documentation, [Online], [Retrieved September 22,

2019], https://cloud.google.com/blog/products/gcp/.

Gopalani, S., Arora, R.R., 2015. Comparing Apache Spark

and Map Reduce with Performance Analysis using K-

Low Cost Big Data Solutions: The Case of Apache Spark on Beowulf Clusters

333

Means., International Journal of Computer

Applications, 113(1), 8-11.

Hashem, I.. Yaqoob, I., Anuar, N., Mokhtar, S., Gani, A.,

Khan, S., 2015. The rise of “Big Data” on cloud

computing: Review and open research issues.

Information Systems, 47, 98-115.

Huamaní, E. L., Condori, P., Roman-Gonzalez, A., 2019.

Implementation of a Beowulf Cluster and Analysis of

its Performance in Applications with Parallel

Programming. Int. J. Adv. Comput. Sci. Appl, 10(8),

522-527.

Ilias M., Eleni K., 2017. Performance evaluation of cloud-

based log file analysis with Apache Hadoop and

Apache Spark, The Journal of Systems & Software, 125,

133-151

Jinbae, L., Boabe, K. and Jong-Moon, C., 2019. Time

Estimation and Resource Minimization Scheme for

Apache Spark and Hadoop Big Data Systems with

Failures, IEEE Access, 7, 9658 – 9666.

Josep, A. D., Katz, R., Konwinski, A., Gunho, L. E. E.,

Patterson, D., Rabkin, A., 2010. A view of cloud

computing. Communications of the ACM, 53(4).

Kuhn, M., Johnson, K., 2013. Applied Predictive Modeling,

Springer. New York.

Kuhn, M., Wickham, H., 2019. tidymodels: Easily Install

and Load the 'Tidymodels' Packages. R package version

0.0.3. https://CRAN.R-

project.org/package=tidymodels

Lin, G., Hsu, I., 2019. Performance Evaluation of Fuzzy C-

means Associated with Spark based on Virtual Cloud

Computing, Bulletin of Networking, Computing,

Systems and Software, 8(1), 14-18.

Lin, L., 1989. A concordance correlation coefficient to

evaluate reproducibility. Biometrics, 45 (1), 255-268.

Papakyriakou, D., Kottou, D., Kostouros, I., 2018.

Benchmarking Raspberry Pi 2 Beowulf Cluster.

International Journal of Computer Applications, 975,

8887.

Qureshi, B., Koubâa, A., 2019. On Energy Efficiency and

Performance Evaluation of Single Board Computer

Based Clusters: A Hadoop Case Study. Electronics,

8(2), 182.

R Core Team, 2019. R: A Language and Environment for

Statistical Computing. Vienna, Austria: R Foundation

for Statistical Computing, [Retrieved October 12,

2019], https://www.R-project.org/.

Spark, 2019. Official Apache Spark documentation,

[Online], [Retrieved May 12, 2019],

https://spark.apache.org/docs/2.4.1/.

TPC, 2018a. TPC Benchmark H (Decision Support)

Standard Specification Revision 2.18.0,

http://www.tpc.org/tpc_documents_current_versions/p

df/tpc-h_v2.18.0.pdf

TPC, 2018b. TPC Benchmark H Tools,

http://www.tpc.org/TPC_Documents_Current_Version

s/download_programs/

Van Dijck, J., 2014. Datafication, dataism and

dataveillance: Big Data between scientific paradigm

and ideology. Surveillance & Society, 12(2), 197-208.

Vaughan, D., Dancho, M., 2018. furrr: Apply Mapping

Functions in Parallel using Futures. R package version

0.1.0., https://CRAN.R-project.org/package=furrr

Wei, T., Simko, V., 2017. R package "corrplot":

Visualization of a Correlation Matrix (Version 0.84).

Available from https://github.com/taiyun/corrplot

Wickham et al., 2019. Welcome to the tidyverse, Journal of

Open Source Software, 4(43), 1686,

https://doi.org/10.21105/joss.01686

Wickham, H., 2016. ggplot2: Elegant Graphics for Data

Analysis, Springer. New York. 2nd edition.

Wright, M.N., Ziegler, A., 2017. ranger: A Fast

Implementation of Random Forests for High

Dimensional Data in C++ and R. Journal of Statistical

Software, 77(1), 1-17

Yang, C., Huang, Q., Li, Z., Liu, K., Hu, F., 2017. Big Data

and cloud computing: innovation opportunities and

challenges. International Journal of Digital Earth,

10(1), 13-53.

APPENDIX

SELECT t2.s_name, t2.n_name,

SUM(t1.l_quantity * t1.l_extendedprice)

AS expr

FROM ( SELECT * FROM lineitem lineitem1

INNER JOIN partsupp partsupp1 ON

lineitem1.l_partkey =

partsupp1.ps_partkey

and lineitem1.l_suppkey =

partsupp1.ps_suppkey

INNER JOIN supplier supplier1 ON

partsupp1.ps_suppkey =

supplier1.s_suppkey) t1

inner join

( SELECT * FROM supplier supplier2

INNER JOIN nation nation2 ON

supplier2.s_nationkey =

nation2.n_nationkey

) t2 on

t1.s_suppkey = t2.s_suppkey

WHERE t1.s_suppkey < 7150 or

t1.l_commitdate between '1993-09-19' and

'1995-12-16' and t1.ps_availqty <> 2026 or

t2.n_regionkey <> 2 and t2.s_acctbal <=

2029.1

GROUP BY t2.s_name, t2.n_name

HAVING SUM(t1.l_quantity *

t1.l_extendedprice) >= 575085

ORDER B 1 DESC, 3 DESC

IoTBDS 2020 - 5th International Conference on Internet of Things, Big Data and Security

334
