Performance of Cluster-based High Availability Database in Cloud

Containers

Raju Shrestha

OsloMet - Oslo Metropolitan University, Oslo, Norway

Keywords:

Performance, High Availability, Database, Cloud, Galera Cluster, Virtual Machine, Container, Docker.

Abstract:

Database is an important component in any software application, which enables efﬁcient data management.

High availability of databases is critical for an uninterruptible service offered by the application. Virtualization

has been a dominant technology behind providing highly available solutions in the cloud including

database, where database servers are provisioned and dynamically scaled based on demands. However,

containerization technology has gained popularity in recent years because of light-weight and portability, and

the technology has seen increased number of enterprises embracing containers as an alternative to heavier and

resource-consuming virtual machines for deploying applications and services. A relatively new cluster-based

synchronous multi-master database solution has gained popularity recently and has seen increased adoption

against the traditional master-slave replication for better data consistency and high availability. This article

evaluates the performance of a cluster-based high availability database deployed in containers and compares

it to the one deployed in virtual machines. A popular cloud software platform, OpenStack, is used for virtual

machines. Docker is used for containers as it is the most popular container technology at the moment. Results

show better performance by HA Galera cluster database setup using Docker containers in most of the Sysbench

benchmark tests compared to a similar setup using OpenStack virtual machines.

1 INTRODUCTION

Most of today’s modern cloud-based applications and

services, in general, are dynamic database-driven

web-based applications. In order to provide

always-on and always-connected service, which is

one of the major goals of cloud computing, it is

vital that the database is highly available. In other

words, a high availability (HA) database is critical

for interrupted service. HA database aims for

reduced downtime as well as for reduced response

time and increased throughput (Hvasshovd et al.,

1995). As the HA database cannot be retroﬁt

into a system, it should be designed in the early

stages of the system architecture design to provide

minimal downtime, optimal throughput and response

time. HA database is realized through redundancy,

where multiple database servers are used and data is

replicated in all the servers.

There are mainly two major replication technolo-

gies that are used for high availability database:

master-slave database replication and cluster-based

database replication. Master-slave (single master,

multiple slaves) database replication (Ladin et al.,

1992; Wiesmann et al., 2000; Earl and Oderov, 2003;

Wiesmann and Schiper, 2005; Curino et al., 2010)

is a solution which is being used traditionally since

long time. A master database server handles data

writes, while multiple slave servers are used to read

data, thus supporting read scalability. Any changes

in the master database are replicated in the slaves

asynchronously (Wiesmann et al., 2000; Elnikety

et al., 2005). Since asynchronous replication doesn’t

guarantee the delay between applying changes on the

master and propagation of changes to the slaves, this

may cause data inconsistencies when something goes

wrong in the master database server in the middle

of a transaction. Thus, master-slave replication

doesn’t guarantee consistency, one among the three

consistency, availability, and partition tolerance in the

Brewer’s CAP theorem (Brewer, 2012).

Multi-master cluster-based database replication

techniques such as MariaDB Galera cluster (MariaDB

Galera, 2019a) and MySQL cluster (MySQL, 2019)

offer effective alternatives to master-slave replication

by addressing its data inconsistency problem through

synchronous replication. A comparative study

between master-slave and cluster-based high avail-

ability database solutions showed that master-slave

replication performs equal or better in terms of

320

Shrestha, R.

Performance of Cluster-based High Availability Database in Cloud Containers.

DOI: 10.5220/0009387103200327

In Proceedings of the 10th International Conference on Cloud Computing and Services Science (CLOSER 2020), pages 320-327

ISBN: 978-989-758-424-4

throughput and response time (Shrestha, 2017).

However, the cluster-based solution is superior when

it comes to high availability, data consistency, and

scalability as it offers instantaneous failover, no loss

of data, and both read and write scalability.

Virtualization is a key enabling technology of

cloud computing. Most HA solutions rely on

redundant hardware, and virtualization technology

enables efﬁcient and effective HA in the cloud

through provisioning and deployment of virtual

machines (VMs) and the whole infrastructure

(IaaS). Virtual machines are then scaled based on

demands (Xing and Zhan, 2012). Since each VM

includes an operating system (OS) and a virtual

copy of all the hardware, virtualization requires

signiﬁcant hardware resources such as CPU, RAM,

and Disk space. Moreover, because of their large size

and resource requirements, moving VMs between

different clouds can be challenging. Container

technology (simply called as a container) addresses

this, whereby an application or service is packaged so

that it can be provisioned and run isolated from other

processes (He et al., 2012; Kang et al., 2016). Unlike

virtual machines, which are separate full-blown

machines with their own OS, containers run on top

of a single OS. As such, there is a lot of overhead

and resource requirement with virtual machines,

whereas containers are more efﬁcient requiring

signiﬁcantly less overhead and resources (MaryJoy,

2015). Because of the container’s lightweight

nature, many containers can be deployed onto a

single server. Studies showed that containers, in

general, take signiﬁcantly less boot time, and use

fewer resources (Seo et al., 2014; MaryJoy, 2015;

Felter et al., 2015; Kozhirbayev and Sinnott, 2017;

Zhang et al., 2018). At the same time, generating,

distributing, and deploying container images is fast

and easy. (Mardan and Kono, 2016) did a comparative

study between KVM based virtualization and Linux

LXC container in terms of disk I/O and isolation

in a database management system, and they found

KVM to perform better than LXC in disk I/O without

violating the isolation. However, this may no longer

be true with the recent development of container

technology and with different virtualization and

container technologies. In the meantime, container

technology has gained popularity in recent years and

enterprises are embracing containers as an alternative

to virtual machines for deploying applications and

services. There are several container software and

platform available such as Docker, Linux container

(lxc), Apache Mesos, and rkt (rocket) (Bernstein,

2014). Among them, Docker is the most popular and

widely used at the time.

Even though some research has been done in

studying performance comparison of the container

with the virtual machine in general, to the

author’s knowledge, not much study being done

regarding the performance of container in the

speciﬁc application domain of database, especially

cluster-based HA database. This paper has made

an attempt in this direction, where the performance

of the container-based HA cluster database setup is

evaluated and compared with a similar setup using

virtual machines. Since MariaDB database is not

only free, and open-source, but also has more cutting

edge features and storage engines, compatible with

MySQL, performs better, and easy to migrate (Seravo,

2015; Nayyar, 2018), and Docker is the most popular

container platform, Galera cluster implementation

using the latest MariaDB database server at the time

(v.10.4) and Docker container are used to implement

cluster-based HA database in cloud.

After this introduction section, Section 2 describes

the cluster-based high availability database. Section 3

describes the experimental setup, tests carried out,

and evaluation metrics used to compare performance.

Section 4 presents and discusses the experimental

results. Finally, Section 5 concludes the paper.

2 CLUSTER-BASED HIGH

AVAILABILITY DATABASE

A typical cluster-based HA database is relatively new,

which uses a multi-master architecture consisting of

a cluster (or group) of servers, called nodes. Any

node within a cluster can respond to both read and

write requests. Any change of data in a node is

replicated across all nodes in the cluster instantly,

thus providing system redundancy and minimizing

the possibility of service downtime. Cluster nodes

can be load-balanced using a database proxy such

as MariaDB MaxScale (MariaDB MaxScale, 2019)

to make the database highly available. Figure 1

illustrates a cluster-based architecture.

Data replication in a cluster-based architecture

is performed synchronously, which unlike asyn-

chronous replication, guarantees that if any change

happens on one node of the cluster, the change is

applied in other nodes as well at the same time.

Therefore, even when a node fails, the other nodes

continue working and hence the failure has no major

consequences. The data gets replicated from the

existing nodes when the failed node joins the cluster

again later. It thus guarantees data consistency.

Performance of Cluster-based High Availability Database in Cloud Containers

321

Master 1

Master 3

Master 2

Figure 1: Cluster-based multi-master architecture for a high

availability database.

The most recent version of the MariaDB database

server and it’s inbuilt Galera cluster is used in

this work for HA database implementation as it

is a community-developed open-source software.

Galera cluster uses a write-set replication (WSREP)

service for synchronous multi-master replication.

Transactions are either applied to every node or not

at all, thus guaranteeing data consistency. Galera is

capable of automatic node provisioning. If one master

fails, the cluster continues so that users can continue

reading and writing on other nodes.

3 EXPERIMENTAL SETUP AND

TESTS

OpenStack-based (OpenStack.org, 2019) cloud setup

at Oslo Metropolitan University (OsloMet), which is

presumably one of the largest cloud environments

in Norwegian higher education, is used to conduct

experiments. Two OpenStack projects, one for the

VM-based HA cluster database setup and one for the

Docker container-based HA cluster database setup

are created. In each case, a Galera cluster of three

database servers is set up as a part of a LAMP

stack (IBM Cloud, 2019) using the latest version of

MariaDB (v10.4) and built-in Galera v4 (MariaDB

Galera, 2019a). Galera clusters are setup by

using the same conﬁguration in all the database

servers in both VM-based and container-based

implementations. rsync is used as the WSREP

snapshot transfer method (wsrep sst method) in the

Galera cluster conﬁguration. Figure 2 shows the

common conﬁguration added within the [mysqld]

section in the MariaDB conﬁguration ﬁle my.cnf.

MariaDB’s MaxScale v2.4, (MariaDB MaxScale,

2019), an intelligent database proxy, is used to load

balance the three database servers on a round-robin

basis. Since all the database servers are the same

speciﬁcation, equal weight is given to each server.

Figure 3 depicts the Galera cluster setup. Figure 4

shows an example listing of running database servers

as obtained with MaxCtrl command in MaxScale in

VM-based HA setup.

Figure 2: MariaDB conﬁguration used to setup Galera

clusters in both VM-based and container-based HA

database implementations.

Figure 3: Experimental setup of Galera cluster-based high

availability database using three MariaDB database server

nodes and MariaDB MaxScale database proxy.

Figure 4: List showing running database servers and their

roles at the time.

The two HA database setups and benchmark tests

carried out, and the metrics used to evaluate their

performance are described below.

Galera Cluster Setup using VMs: All servers

(VMs) including three database servers are created

of small ﬂavor (1VCPU, 2GB RAM, and 20GB

Disk) and deployed in a private network. Necessary

security rules are deﬁned and ports are opened to

allow TCP network communication between them.

Ubuntu 18.04 OS is used in all the servers. MariaDB

database server v10.4 is installed in all three database

servers and they are conﬁgured for the HA Galera

cluster database.

CLOSER 2020 - 10th International Conference on Cloud Computing and Services Science

322

Galera Cluster Setup using Containers: A single

Ubuntu 18.04 VM of extra-large ﬂavor (8VCPU,

16GB RAM and 160GB Disk) is created in

OpenStack and used as a Docker host to provision

all the containerized servers. Galera cluster is

set up with the three database servers using the

standard Docker image mariadb/server:10.4 from

MariaDB. Three separate external storage SSD data

volumes each of 20GB size are attached to the

VM. One data volume is used as a persistent data

storage for a database server, by connecting to

the container using the --volume parameter when

running the container. MariaDB’s MaxScale Docker

image, mariadb/maxscale:latest (v2.4), is used

for setting up the database proxy. Containers are

provisioned in a private network so that they can

communicate with each other.

In Docker, a container has no resource

constraints by default and can use as much of

a given resource as the host’s kernel scheduler

allows. In order to make a fair comparison with

the VM-based setup, the database containers are

enforced to limit the same number of CPUs,

memory, and Disk size as in the database VMs,

which are 1CPU, 2GB, and 20GB respectively.

CPU and memory constraints are deﬁned by

setting the limits to the --cpus and --memory

parameters when running the docker containers.

For limiting the memory in Docker, control group

(cgroup) is enabled in Docker host by adding

GRUB CMDLINE LINUX="cgroup enable=memory

swapaccount=1" in /etc/default/grub and then

updating the grub. The same conﬁguration is set in

all the VMs in the VM-based setup as well.

Benchmark Tests: A mature and widely used

open-source benchmark suite, Sysbench, developed

by Alexy Kopytov (Kopytov, 2014; Kopytov, 2019),

which provides most of the database benchmark tests,

is used to perform various benchmark tests under

intensive loads with common database operations.

The same tests are run in both VM-based HA database

setup and container-based HA database setup using

the same set of parameters in each test. The

latest version of Sysbench (v1.0.19) is installed and

executed from a separate test VM in case of the

VM-based setup, and from the Docker host in case

of the container-based setup. MaxScale proxy server

is used as the database host when running Sysbench

tests so that all the database requests are made to the

Galera cluster via the database proxy.

Five different types of benchmark tests are

performed, namely Readonly, WriteOnly, ReadWrite,

Bulkinsert, and Deleteonly, using OLTP (Online

Transaction Processing) benchmark that comes with

Sysbench. OLTP is used as it is close to

common real-world dynamic database-driven web

applications. Sysbench’s default option ‘special’ for

data distribution and default values for the related

parameters are used as it is quite common in web

applications. Tests are pre-warmed or warmed up,

allowing to warm up the cache and buffer pools in

order to collect regular statistical results and then

run with a time limit of two minutes. As we

wanted to test regular queries, prepared statements

were disabled in all the tests. With the default

settings, Sysbench data preparation shows that it takes

about 375MB disk space for one million rows. In

order to test in-memory workload, the parameters

--tables (number of database tables or table count)

and --table-size (number of rows in a table) are

set to thirty and one hundred respectively to ﬁt well

into innoDB buffer pool.

Five benchmark tests are brieﬂy described and

corresponding Sysbench run commands used are

given below. tblcount, tblsize, and runtime

variables used in the commands are set to 30, 100000,

and 120 respectively.

• Readonly tests performance of the database when it

comes to reading from the database, which consists

of different types of SELECT queries.

sysbench oltp_read_only --db-driver=mysql \

--mysql-host=$maxscalehost \

--mysql-user=root --db-ps-mode=disable \

--events=0 --time=$runtime \

--tables=$tblcount --table-size=$tblsize \

--threads=$thrdcount run

• Writeonly tests performance while doing database

writes, a mix of INSERT, UPDATE, and DELETE

operations.

sysbench oltp_write_only --db-driver=mysql \

--mysql-host=$maxscalehost \

--mysql-user=root --db-ps-mode=disable \

--events=0 --time=$runtime \

--tables=$tabl_count \

--threads=$thrdcount run

• ReadWrite tests performance of the database when

doing both reads and writes. By default, Sysbench

OLTP ReadWrite test consists of 70% read and

30% write operations.

sysbench oltp_read_write --db-driver=mysql \

--mysql-host=$maxscalehost \

--mysql-user=root --db-ps-mode=disable \

--events=0 --time=$runtime \

--tables=$tblcount --table-size=$tblsize \

--threads=$thrdcount run

• Deleteonly test determines the amount of purg-

ing/delete the database setup can handle.

Performance of Cluster-based High Availability Database in Cloud Containers

323

sysbench oltp_delete --db-driver=mysql \

--mysql-host=$maxscalehost \

--mysql-user=root --db-ps-mode=disable \

--events=0 --time=$runtime \

--tables=$tblcount --table-size=$tblsize \

--threads=$thrdcount run

• Bulkinsert test is used to benchmark the ability

of the HA database setup to perform multi-row

inserts. This test helps ﬁnding how fast data can

be inserted given the replication lag kick in.

sysbench bulk_insert --db-driver=mysql \

--mysql-host=$maxscalehost \

--mysql-user=root --db-ps-mode=disable \

--events=0 --time=$runtime \

--threads=$thrdcount run

Tests are run with a different number of threads (in

multiples of 8) to study the performance patterns with

the increasing number of threads. Thread size of 64

is found to reach the limit to communicate and sync

data and break down in Bulkinsert test, in case of VM

setup, and therefore, we stopped there.

Evaluation Metrics: The two most widely used

evaluation metrics, namely throughput, and response

time, are used to evaluate performance of the two HA

database setups.

• Throughput is deﬁned as the number of transac-

tions per second. A database transaction is a unit

of tasks performed within a database, which must

be atomic (all the changes are either committed

or rolled back), consistent, isolated, and durable,

referred to as ACID (Jacobs and Satran, 2018).

• Response time or latency is measured as an average

time (in millisecond) taken to complete a task, an

event in the Sysbench tests.

4 RESULTS AND DISCUSSION

Results from the ﬁve benchmark tests on the two

HA database setups are given in terms of the two

evaluation metrics ,throughput and response time, in

Figure 5. The ﬁgure shows the average metric values

for the different number of threads from 1 to 64 in

multiples of 8. Tests failed with the VM setup when

the number of threads equals 64, hence no result

available in this case.

Results show that throughput increased in all

the tests except Bulkinsert when the number of

threads (or thread count) is increased from 1 to 8.

However, it remains more or less unchanged when

the thread count increased further. This is true

in both HA database setups. The performance is

1 8 16 24 32 40 48 56

Number of threads

15000

20000

25000

30000

35000

1 8 16 24 32 40 48 56

Number of threads

2000

2500

3000

Throughput (tps)

1 8 16 24 32 40 48 56 64

Number of threads

100

200

300

400

500

(a) Throughput (Transactions per second).

(b) Response time or latency.

Figure 5: Performance results of the ﬁve benchmark tests

with the two HA database setups [Solid line - Container

setup, Dashed line - VM setup].

CLOSER 2020 - 10th International Conference on Cloud Computing and Services Science

324

higher in case of container setup compared to VM

setup in Writeonly, ReadWrite, and Deleteonly tests.

However, Readonly and Bulkinsert show the opposite

performance. The difference is small in the Readonly

test but relatively bigger in Bulkinsert test. VMs

ability to work in isolation whereas scheduling of

host’s resources in case of containers could possibly

contribute to this difference. Moreover, Bulkinsert

performance is much higher compared to other tests,

but the performance decreases with the increase in the

number of threads. Higher throughput is explained by

the fact that bulk insertion is more efﬁcient compared

to individual writes when it comes to writing into the

disk. The decrease in throughput with the increase in

thread count is possibly due to internal contention and

rowlocks.

In terms of response time, performance increases

with the increase in the number of threads almost

linearly. This is anticipated as the number of

threads increases, they have to wait for long for

the resources and get hold of them as scheduled

by the OS. Like with throughput, container setup

shows better (lower) response time with Writeonly,

Readewrite, and Deleteonly tests, compared to VM

setup. Likewise, in Readonly and Bulkinsert tests,

performance is reversed, but by a relatively small

margin.

Vadim Tkachenko (Tkachenko, 2012) stated that

using throughput only may not reﬂect the true

performance and highlighted the importance of

response time. He suggested a benchmark test model

where a transaction rate is assumed and given the

rate, 95% or 99% response times are measured. The

benchmark tests done here is based on a stress test

where the rate is not limited as the aim is to push the

database as much as possible. Based on throughput

and response time, choosing the thread count of 16

as an optimal value (see Figure 5), the stability of

response times can be studied from a plot of 95%

response time measured at a regular interval. Figure 6

shows a plot based on a measurement at an interval of

ﬁve milliseconds. The plot shows that response time

in VM setup is pretty unstable, with Writeonly and

ReadWrite tests. In the meantime, the container setup

has reasonably good stability in all the tests. Results

are found to be similar with thread count values of

eight and sixteen as well. Quantitative results of

the performance of the two HA database setups on

different benchmark tests with sixteen thread count is

given in Table 1.

It is to be noted here that the performance

comparison is made based on the OLTP benchmark

tests, which is designed to make it close to common

10 20 30 40 50 60 70 80 90 100 110 120 130 140 150

Time interval [in ms]

500

1000

1500

95% Response time (ms)

Figure 6: 95% response time as measured at every 5-second

interval in the tests with thread counts set to an optimal

value of 16. Response time higher than 1500ms is clipped

in the plot for better visibility in the lower region.

Table 1: Comparative performance results (in terms of

throughput and response time) between the VM-based and

the container-based HA database setups on ﬁve different

benchmark tests when the number of threads is set to 16.

Numbers shown in green indicate better performance over

the corresponding ones shown in red.

Throughput

(tps)

Response me

(ms)

Throughput

(tps)

Response me

(ms)

Readonly 504 15.85 325 24.62

Writeonly 24 336.06 325 24.64

ReadWrite 28 288.65 117 68.27

Deleteonly 391 20.46 2843 2.81

Bulkinsert 33648 0.21 22610 0.35

VM-based HA database

Container-based HA database

Test

web applications. However, it may not truly represent

all kinds of real-world applications. Secondly,

experiments are carried out using small VMs, which

is not necessarily the case in many large applications.

However, we can anticipate a similar pattern (relative

results) irrespective of the VM size.

It has been found that the Galera cluster

Performance of Cluster-based High Availability Database in Cloud Containers

325

provides a highly available database with guaranteed

consistency. However, it’s response time is not as

low as in master-slave replication (Shrestha, 2017).

Therefore, it is possibly not the right solution if one

needs very low latency or even real-time behavior. A

list of other limitations of Galera cluster can be found

in (MariaDB Galera, 2019b).

5 CONCLUSIONS

The paper presented a comparative study of the

performance of highly available Galera cluster-based

database setup in Docker containers and OpenStack

virtual machines. The results from benchmark tests

show that container-based setup performs better in

most of the tests such as ReadWrite, Writeonly

and Deleteonly tests that correspond to real-world

applications that require both reading, writing, and

deleting data in the database. VM setup performs

better in Readonly and Bulkinsert tests. The results,

therefore, support the wider belief that container, in

general, outperforms virtual machines.

REFERENCES

Bernstein, D. (2014). Containers and Cloud: From LXC

to Docker to Kubernetes. IEEE Cloud Computing,

1(3):81–84.

Brewer, E. (2012). Pushing the CAP: Strategies for

Consistency and Availability. Computer, 45(2):23–29.

Curino, C., Jones, E., Zhang, Y., and Madden, S. (2010).

Schism: A workload-driven approach to database

replication and partitioning. Proc. VLDB Endow.,

3(1-2):48–57.

Earl, L. and Oderov, S. (2003). Database replication system.

US Patent App. 10/426,467.

Elnikety, S., Pedone, F., and Zwaenepoel, W. (2005).

Database replication using generalized snapshot

isolation. In 24th IEEE Symposium on Reliable

Distributed Systems (SRDS’05), pages 73–84.

Felter, W., Ferreira, A., Rajamony, R., and Rubio, J.

(2015). An updated performance comparison of

virtual machines and linux containers. In 2015 IEEE

International Symposium on Performance Analysis of

Systems and Software (ISPASS), pages 171–172.

He, S., Guo, L., Guo, Y., Wu, C., Ghanem, M., and

Han, R. (2012). Elastic application container: A

lightweight approach for cloud resource provisioning.

In 2012 IEEE 26th International Conference on

Advanced Information Networking and Applications,

pages 15–22.

Hvasshovd, S. O., Torbjørnsen, O., Bratsberg, S. E., and

Holager, P. (1995). The clustra telecom database:

High availability, high throughput, and real-time

response. In Proceedings of the 21th International

Conference on Very Large Data Bases, VLDB ’95,

pages 469–477, San Francisco, CA, USA. Morgan

Kaufmann Publishers Inc.

IBM Cloud (2019). LAMP stack. https://www.ibm.com/

cloud/learn/lamp-stack-explained. Last access: Feb.

2020.

Jacobs, M. and Satran, M. (2018). What is transaction?

https://docs.microsoft.com/en-us/windows/win32/

ktm/what-is-a-transaction?redirectedfrom=MSDN.

Last access: Feb. 2020.

Kang, H., Le, M., and Tao, S. (2016). Container and

microservice driven design for cloud infrastructure

devops. In 2016 IEEE International Conference on

Cloud Engineering (IC2E), pages 202–211.

Kopytov, A. (2014). Sysbench manual. https://imysql.com/

wp-content/uploads/2014/10/sysbench-manual.pdf.

Last access: Feb. 2020.

Kopytov, A. (2019). Sysbench. https://github.com/

akopytov/sysbench/. Last access: Feb. 2020.

Kozhirbayev, Z. and Sinnott, R. O. (2017). A performance

comparison of container-based technologies for the

cloud. Future Generation Computer Systems, 68:175

– 182.

Ladin, R., Liskov, B., Shrira, L., and Ghemawat, S. (1992).

Providing high availability using lazy replication.

ACM Trans. Comput. Syst., 10(4):360–391.

Mardan, A. A. A. and Kono, K. (2016). Containers

or hypervisors: Which is better for database

consolidation? In 2016 IEEE International

Conference on Cloud Computing Technology and

Science (CloudCom), pages 564–571.

MariaDB Galera (2019a). MariaDB Galera Cluster.

https://mariadb.com/kb/en/library/what-is-mariadb-

galera-cluster/, http://galeracluster.com/. Last access:

Feb. 2020.

MariaDB Galera (2019b). MariaDB Galera Cluster

- Known limitations. https://mariadb.com/kb/en/

mariadb-galera-cluster-known-limitations/. Last

access: Feb. 2020.

MariaDB MaxScale (2019). MariaDB MaxScale. https:

//mariadb.com/kb/en/maxscale/. Last access: Feb.

2020.

MaryJoy, A. (2015). Performance comparison between

linux containers and virtual machines. In 2015

International Conference on Advances in Computer

Engineering and Applications, pages 342–346.

MySQL (2019). MySQL Cluster CGE. https://www.mysql.

com/products/cluster/. Last access: Feb. 2020.

Nayyar, A. (2018). Why mariadb scores over mysql.

https://opensourceforu.com/2018/04/why-mariadb-

scores-over-mysql/. Last access: Feb. 2020.

OpenStack.org (2019). OpenStack. openstack.org. Last

access: Feb. 2020.

CLOSER 2020 - 10th International Conference on Cloud Computing and Services Science

326

Seo, K.-T., Hwang, H.-S., Moon, I.-Y., Kwon, O.-Y.,

and Kim, B.-J. (2014). Performance comparison

analysis of linux container and virtual machine for

building cloud. Networking and Communication,

66(25):105–111.

Seravo (2015). 10 reasons to migrate to Mari-

aDB. https://seravo.ﬁ/2015/10-reasons-to-migrate-

to-mariadb-if-still-using-mysql. Blog, Last access:

Feb. 202.

Shrestha, R. (2017). High availability and performance

of database in the cloud: Traditional Master-slave

replication versus modern Cluster-based solutions. In

Proceedings of the 7th International Conference on

Cloud Computing and Services Science, CLOSER

2017, pages 413–420, Portugal. SCITEPRESS -

Science and Technology Publications, Lda.

Tkachenko, V. (2012). Introducing new type of

benchmark. https://www.percona.com/blog/2012/

02/25/introducing-new-type-of-benchmark/. Last

access: Feb. 2020.

Wiesmann, M., Pedone, F., Schiper, A., Kemme, B., and

Alonso, G. (2000). Database replication techniques: a

three parameter classiﬁcation. In Reliable Distributed

Systems, 2000. SRDS-2000. Proceedings of The 19th

IEEE Symposium on, pages 206–215.

Wiesmann, M. and Schiper, A. (2005). Comparison of

database replication techniques based on total order

broadcast. IEEE Transactions on Knowledge and

Data Engineering, 17(4):551–566.

Xing, Y. and Zhan, Y. (2012). Virtualization and cloud

computing. In Zhang, Y., editor, Future Wireless

Networks and Information Systems, pages 305–312,

Berlin, Heidelberg. Springer Berlin Heidelberg.

Zhang, Q., Liu, L., Pu, C., Dou, Q., Wu, L., and Zhou, W.

(2018). A comparative study of containers and virtual

machines in big data environment. In 2018 IEEE

11th International Conference on Cloud Computing

(CLOUD), pages 178–185.

Performance of Cluster-based High Availability Database in Cloud Containers

327
