A Data-centered Usage Governance: Providing Life-long Protection

to Data Exchanged in Virtual Enterprises

Jingya Yuan

, Frédérique Biennier

and Nabila Benharkat

University of Lyon, CNRS, INSA-Lyon, LIRIS UMR 5205, Lyon, France

Keywords: Collaborative Networked Organisation, Usage based Access Control, Distributed Usage Governance,

Blockchain.

Abstract: Since the early definition of the Virtual Enterprise concept in the 90s, efficient information sharing and trust

have been pointed out as major challenges to support the enactment of collaborative organisations. By now,

traditional Collaborative Business support systems have been designed to interconnect corporate Business

Processes and different well-known information systems, whereas trust is mostly managed thanks to inter-

personal relationships. Unfortunately, this well-perimetrized vision of a Collaborative Network Organization

does not fit the large scale, opened and evolving context due to the fast adoption of Industry 4.0 and sharing

economy models which rely on the large scale adoption of Social Mobile Analytics Cloud Internet of Things

technologies (later called SMACIT for short) and semi-opened information systems. This involves rethinking

the way information, services and applications are organized, deployed, shared and protected, moving from

the traditional perimetrized system protection to data and service life-long usage control. To this end, we

propose a data-driven security organization which uses a multi-layer architecture to describe on one hand the

logical organisation of the information system, i.e. the data assets and the business services needed to

implement the collaborative business processes and on the other hand the multiple copies exchanged with

different service providers. Based on this Information System meta-model, our system integrates a

blockchain-based usage manager to govern the way information are exchanged and processed.

1 INTRODUCTION

Whereas Collaborative Networked Organisations

(later called CNO for short) have been studied for

decades since the earliest virtual enterprise definition

in the 90s(Browne et al. 1995), the fast development

of digital and sharing economy coupled to the wild

adoption of SMACIT technologies renew these CNO

models to large scale and semi-opened “on demand”

CNO enactment. As pointed out in earlier studies,

trust and reputation are key elements to identify

potential partnerships (Baroudi et Lucas 1994),

(Jøsang et al. 2007). Whereas different Business

related models and criteria (such a cost, delay,

product / service quality…) have been used to

evaluate trust and reputation (Hendrikx et al. 2015),

security and privacy related criteria must also be

considered as information sharing with potential

https://orcid.org/0000-0002-9853-7118

https://orcid.org/0000-0001-6908-6103

https://orcid.org/0000-0002-1911-5524

competitors can be a major threat (Panahifar et

al.2018).

Protecting traditional information systems

(including physical systems, processes and the

information they use) relies on methods to identify

precisely threats and vulnerabilities, prioritize them

and mitigate the main risks by deploying adapted

technical countermeasures. For example, data

replication provides availability, data encryption and

access control increase confidentiality level whereas

hashing techniques (used to “sign” critical data value)

and log registrations are used to fit integrity

requirements. Nevertheless, these protection

strategies are designed for a well-pereimetrised

environment and well-known information system

organisation whereas the semi-opened collaborative

environment involved by SMACIT and sharing

economy requires controlling Business Process

Yuan, J., Biennier, F. and Benharkat, N.

A Data-centered Usage Governance: Providing Life-long Protection to Data Exchanged in Virtual Enterprises.

DOI: 10.5220/0009349501770184

In Proceedings of the 22nd International Conference on Enterprise Information Systems (ICEIS 2020) - Volume 2, pages 177-184

ISBN: 978-989-758-423-7

177

(Weber et al.2018) as they can be seen as potential

threats.

To define and manage consistently assets

protection in opened environments, we propose a

data-driven protection architecture. By integrating

business usage purpose, a finer-grained

contextualized protection is set. Then, we use a

governance loop to collect the service real quality of

protection, including the trust level associated to the

service provider. This architecture allows a consistent

evaluation of the current protection of assets and a

finer-grained control on the real usages.

After presenting the related works, we describe

our distributed data-driven protection architecture

before comparing it with other works (section 4).

2 RELATED WORKS

As SMACIT and CNO integrate different actors (such

as service providers, hosting platform managers…),

they can be deployed world-wide, leading to integrate

different legal regulations constraints. Such complex

distributed organisation makes protecting (personal)

data harder as different parties may exchange and

share these data in a non-protected way. According to

a societal point of view, this can appear as “unfair”

practices but service consumers / end users have only

few ways to manage their security / data privacy

preferences: they can accept or refuse the security /

privacy conditions of the service provider, select

providers depending on a subjective trust level…

Access control has been seen as a fine-grained

trust model. It may be used to restrict access to well-

identified trusted users, using the simplest Access

Control List to name them or Role based Access

Control (RBAC) (Sandhu, R. S et al. 1996) to

integrate basic organisational knowledge to identify

the in a more generic way. Extra organisational

knowledge described in Organizational Based Access

control OrBAC (Autrel, F et al. 2008) or contextual

information identified in Attribute Based Access

Control (Wang et al. 2004) can be used to precise the

usage context. Lastly, Usage CONtrol (UCON) (Park,

J., Sandhu, R 2004) enriches the ‘Attribute-based

access control’ model with “Rights” and “obligation”

parts thanks to dedicated languages such as

Obligation Specification Language (OSL) (Hilty, M

et al. 2007) or Rights Expression Languages (RELs)

(ISO et IEC. 2004) from the DRM area (Open Mobile

Alliance 2008). Other features fitting the distributed

environment challenges can also be added, such as

- Tracking data flows to enforce usage control

requirements at all relevant systems layers

(Pretschner et al. 2011) or for different data copies

in distributed systems (Kelbert, F., et Pretschner,

A 2013).

- Providing extended usage policy language to

implement the server-side usage control

architecture (Pretschner et al. 2006) or to integrate

social networks conditions (Kumari et al. 2011).

Despite their interest, these access control features

do not protect data against unpredictable and “unfair”

usage such as uncontrolled copies of data stored in

social networks or analytics processes extracting new

data and knowledge to serve different business goals

leading to privacy breaches.

To face this risk, GDPR empowers users with

their personal data protection, requiring service

providers to state and prove usages they have for a

particular data. This involves managing user consents

accordingly and reporting any security breach to the

data owner. To fit these legal obligations, several

works have been developed either (i) to identify both

information and processing categories in traditional

Enterprise Architecture models in order to simplify

the data usage control (Burmeister et al.2019) or (ii)

to manage data collection and tracking data flows

between stakeholders (Cha, S. C., et Yeh, K. H 2018)

… Focusing on the way “fair and accepted usage” can

be proved, several works have focused on the

blockchain immutability property: (i) to manage

access control function such as (Di Francesco Maesa.

et al. 2017) which uses smart contracts to embed

access control rules, (ii) to manage data encryption

key used to protect data access (Wirth, C., et Kolain,

M. 2018), (iii) to manage user consents(Truong, N. B.

et al. 2019) or (iv) to track data accountability and

provenance (Choi, C et al.2014) as well as usage

operation thanks to smart contracts generated

according to the data usage policy (Neisse, R. et

al.2017).

Despite this rich background, several challenges

remain. First, data usage does not integrate business

purpose. It means that policies are defined for well-

identified processes, whereas the opened

environment involves considering more generic risks.

Second, as data protection is designed for a “stand-

alone” information system, this may lead to security

breaches for both data owner and data consumers

when inconsistent usage are granted for the different

copies dispatched in several information systems.

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

178

3 DATA-DRIVEN

COLLABORATIVE USAGE

CONTROL ARCHITECTURE

To provide a consistent protection for data in opened

collaborative environments, we propose a data-driven

protection architecture plugged on the information

system thanks to a dedicated Information System

Interface component. First, the protection persistency

layer relies on an information system meta-model,

describing the information system organisation and

its interactions with its environment. This meta-

model allows identifying assets logically and defining

their Requirements of Protection (RoP) depending on

their assets’ value. These RoP are propagated to the

assets’ multiple copies. Second, the asset protection

layer extends the traditional protection features and

usage-based access control models to integrate

organisational knowledge and process purpose so that

Terms of Usage (ToU for short) are defined more

precisely, restricting potential business usage and

identifying the necessary protection features. Third,

the usage governance layer relies on a blockchain-

based registration of data exchange and usage to

evaluate any violation of the approved ToU.

3.1 Protection Persistency Model

To support a consistent protection on the multiple

copies of a logical assets, we design a multi-layer

meta-model integrating:

•The Data Collaborative Ecosystem

Description, defines (i) who (human being or

organization entity) owns the data, processes it,

stores it…, (ii) contracts, including Terms of

Service and security agreements, between

stakeholders and even (iii) trust relationships

between stakeholders

•The Logical Information System Meta-model,

includes the description of (i) the data assets and

their requirements of protection depending on the

data value and sensitivity and (ii) the way they are

used, i.e. a description of abstract business

services including their business purpose)

•The Description of the Different Physical

Copies of a Logical Data (called later containers)

and the real concrete service (IT or manual)

processes acceding to these data.

Thanks to this multilayer meta-model,

relationships between logical assets (data or business

services) and their physical instances (copies or

concrete services) are used to manage a consistent

protection, propagating requirements to the “physical

instances” and tracking real usage to “rebuilt” the

current protection in a life-long protection vision.

3.2 Usage-based Asset Protection

Taking advantage of previous works as UCON (Park,

J., et Sandhu, R. 2004) and of the service-oriented

security architecture, we propose a policy ontology

(see fig 1) integrating both asset sensitivity and usage

to define Requirements of Protection (RoP) related to

logical data and Quality of Protection (QoP) related

to Business Service that will “consume” a data

container.

• The Asset Classification defines the data

visibility (private / public or restricted) depending

on its sensitivity. An Explicit identifier / quasi-

identifier qualification is added to fit some risks

involved by the analytics / mining process in order

to consider anonymization/obfuscation

requirements.

• The Usage Ontology is used to describe the

different actions. It includes classical operations

such as Read, Write, Send, Receive, Execute,

Delete, Modify, Track, Create. It is enriched with

usages dedicated to Social media, Mobile and

Analytics context, including Share/Post, Follow,

Interact, Tag, Record, Log record (authentication

and authorization), Collect, Preserve, Search,

Transfer, Visualization, Associate, Analyse,

Extract, Store, Mine (Deduce) for the Mobile,

Social and Analytics part. Lastly, we also

integrate business purpose description (defining

“why”) to provide business-based usage

description.

• The Security Mechanism Ontology integrates

security services (confidentiality, integrity,

availability, non-repudiation) and security

mechanisms such as cryptography, authentication

protocols, secure communication protocols,

filtering mechanisms (firewall…) …

• Context Information defines different usage-

control criteria such as When (operation time and

duration), From Where (refers to the machine type

(personal / shared / professional), the

geographical location (at home / business / given

state), the access network (Mobile / wired /

Wifi…), the “organisational location” (i.e. the

organisation department, Marketing, Supply

management, Manufacturing, Maintenance)),

Why is associated to the usage objective (refers to

both the generic purpose which includes business

usage (statistics, treatment, analyse…) coupled

with the business purpose and organisation

knowledge) and Who (refers to the subject

A Data-centered Usage Governance: Providing Life-long Protection to Data Exchanged in Virtual Enterprises

179

definition (unknown, trusted group, precise

actor)).

• Security and Usage Tracking Maturity states

if and how real usage or security breaches are

reported. It refers to a “report maturity” indicator:

“no” means that no data is available, “logged”

means that actions are stored, “managed” means

that the tracking part is identified and “proved”

means that the tracking part is certified and

published.

Figure 1: Policy assertion ontology.

3.3 Protection Governance

To provide the life-long asset protection, our policy

assertion ontology is in charge of defining the way a

data asset can be used by a business service before

providing a copy of the data asset to this service and

tracking the real usage of this asset copy. These

requirements involve that the data driven protection

architecture is distributed on both data owner and data

consumer side.

Designed in a loosely coupled strategy, our

system is built on a Protection Management

component, managing our Information System meta-

model. This component uses the Information System

Interface Manager component to capture service

invocation, required information identification by

analysing the meta-data included in the web pages

DOM…. This interface is in charge of invoking the

protection management component.

The protection management component interacts

with the protection persistency component, in charge

of establishing our meta-model to interact with Terms

of Usage management component to manage the

Requirements of Protection and Terms of Service

associated to logical assets and Business services. It

consists in an Asset Manager, associated to the logical

asset and related business services, a Service

Manager, associated to logical asset and related

abstract services, and in an Operation Manager in

charge of physical containers and concrete services.

It generates and manages physical containers storing

the copy of the asset used by a given Business

Service. Paying attention to the data consumer side,

the origin of each container can be tracked and each

container is associated to its Terms of Usage, defining

the way it can be used and processed. Focusing on the

Data owner side, this allows building a consistent

Asset protection dashboard, aggregating the different

copies’ ToU, so that due and undue usage can be

identified.

The Terms of Usage management component

(ToU manager for short) is designed to negotiate the

protection and control contracts between the data

owner and data consumer (see figure 2). It is launched

each time a Business Service requests a data. ToU is

evaluated according to both Data Owner RoP and

Data Consumer Terms of Service, including the

description of usages and protection. To this end, the

Security Manager starts on the data consumer side, by

identifying the asset description (i.e. the associated

meta-data) and the associated Terms of Service (ToS

for short). The ToS is generated by aggregating sub-

services QoP and ToS protection, using a lax

aggregation rule (i.e. keeping the less protecting level

for each protection assertion). Once this ToS policy is

generated, the protection manager sends it to the Data

Owner Protection Manager to evaluate this proposal

as a potential Terms of Usage via the Exchange

interface. On the data owner side, the Protection

Manager sends it to the Asset Manager to identify the

corresponding assets and their associated

Requirements of Protection. Then, the Security

Manager, on the Data Owner side, aggregates the

requested assets RoP, using a strict aggregation rule

(i.e. the more protecting and more reduced usage

authorisation strategy). This consolidated RoP is then

compared to the proposed Usage management

protection policy and a ToU restricting the initial

protection to RoP conditions is set. Of course, if the

proposed protection does not fit the aggregated RoP,

the Data Owner can be notified and may decide to

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

180

modify the RoP accordingly. Then the Data Owner

signs this ToU and sends it for approval to the Data

Consumer Usage manager. This negotiation phase is

concluded when the Data Owner Usage Manager

generates the exchange smart contract (see figure 3)

allowing authenticating both Data Owner (to certify

the container origin) and Data Consumer while

managing the container encryption accordingly. A

token associated to the approved ToU is stored in the

Blockchain to prove the consent.

Figure 2: ToU negotiation process.

Figure 3: Exchange smart contract.

If the ToU mentioned that usage will be at least

reported, the Usage monitoring process is launched

on the Data Owner side as soon as the exchange smart

contract is invoked (see figure 4). To this end, the

Usage Monitoring component notifies the Global

Tracking Agent on the Data Consumer side that it will

follow operations on the container. In a symmetric

way, on the Data consumer side, once the exchange

smart contract is invoked, its Usage manager

generates Usage smart contracts (see figure 5)

monitoring by the Complex tracking agent. Similarly,

the Operation manager, in charge of the logical access

operations on containers, generates physical smart

contracts (see figure 6), coupling the physical

operation on the container to an event, registering it

on a log file and a tracking smart contract is generated

to implement the on-line log file elementary actions

tracking (see figure 7). By this way, elementary

tracking agents report basic operations on the data

container to the Complex Tracking Agent that

consolidates them according to the precise negotiated

usage, so that the Global Tracking Agent generates a

global report including logfile tokens associated to

usage operations for the Data Owner.

Figure 4: Usage monitoring process.

Figure 5: Usage smart contract.

Figure 6: Physical smart contract.

Figure 7: Tracking smart contract.

4 EVALUATION

To evaluate our distributed data driven protection

architecture, we use a simple use case to compare our

system with the existing works. OnlineShopping is a

market place selling different products. Its main

business purpose is product exhibition and sales with

Social interaction usage. Its collaborative ecosystem

integrates different parties:

A Data-centered Usage Governance: Providing Life-long Protection to Data Exchanged in Virtual Enterprises

181

- Company A is a manufacturer that uses Online-

shopping to propose spare parts for its after-

sales service as well as a customized “printable”

product design service. Its main business

purpose is product manufacturing with Cloud

Computing SaaS My3Dprinter operation usage.

- Different companies such as Company B

owning one of the My3D printers offer a

certified “product printing service and

delivery”, allowing to produce the requested

part from a product “ready to print” file as close

as possible to the client to improve the delivery

process. Its main business purpose is semi-

product manufacturing and delivery with Cloud

Computing SaaS operation usage and delivery

feedback with Mobile visualization usage.

- MyPayment company provides a secure

payment and fund transfer service. Its main

business purpose is payment transaction with

Cloud Computing PaaS operation usage.

- MyAnalytic company provides analysis for

marketing services based on its

recommendation engine. Its main business

purpose is activity-based profiling thanks to

mining service.

different business services provided by the parties:

OnlineShopping collects browsing activity traces and

exchanges them with MyAnalytics to get adapted

recommendations for its clients. It also exchanges

payment information (amount and refunding

company Id) and tokens with MyPayment company.

Regarding the ordering service, product information

and client delivery information are exchanged with its

manufacturing partners.

Alice uses the OnlineShopping application which

will generate different transactions with many

suppliers using our system or not. First, Alice

browses the marketplace and buys product X by

interacting with OnlineShopping to exchange

information such as name, delivery address, payment

related information etc.

Alice uses our system and sets her requirements

of protection to the data required by OnlineShopping:

- Web browsing activity: sensitivity level:

medium, should be kept less than 30 days.

This means that Alice accepts that this

activity serves for undefined business

purpose but the deletion should be tracked to

show that the storing delay is respected.

- Personal Information with explicit

identification (i.e. name, phone number) and

quasi-explicit identification is highly

sensitive. It should be kept and processes

only for ordering and delivery purpose. This

means that access should be reduced to actors

and services in charge of processing the

product order and product delivery, regarding

Alice’s address and that payment information

should be kept to fit legal constraints.

Based on these requirements, we first evaluate our

Terms of Usage ontology by comparing it with others.

To this end, we identify 3 main comparison criteria:

- subject attribute defines the attributes of the

party requiring the access,

- control objective defines the attributes which

are used to describe ‘Rights’, ‘Obligation’

and ‘Condition’.

- countermeasure scope includes infrastructure

security, communication security, data

storage and access control,

As far as the subject attribute is concerned, (Hu,

Y. J et al.2008), (Nejdl et al. 2005), (Liu, C. L 2014),

(Garcia et al. 2005) define generic roles. This can fit

partly Alice’s needs as they can be used to identify

actors belonging to the convenient organisation

department but they do not integrate usage-related

role (such as data owner, data consumer), making

harder the definition of who can be authorized to

share Alice’s data with Company A. Although

(Chaari et al. 2008) extends these criteria to

reputation and (Tsai et Shao 2011) integrates social

relationships, they only allow managing (trusted)

links between actors. Our ToU ontology extends the

subject description to manage both individual and

organizational entities. It also couples with usage-

related roles and real subject identity. By this way, it

can be used to identify exactly the actors allowed to

decide to share Alice’s address with company A,

integrating business knowledge from the ordering

process.

Focusing on the control objective, (Choi, C et

al.2014), (Liu, C. L 2014) and (Garcia, D.et al.2009)

consider either the service or the trust level associated

to the stakeholder the asset while (Masoumzadeh, A.,

et Joshi, J. 2010), (Kim, A et al. 2005) and (Wang, L

et al. 2004) propose rules associated to the semantic

value of the asset. These ontologies do not support a

synthetic definition of the business context, making

harder to restrict data usage according to business

purpose (in our example, Alice’s address can be used

for ordering and delivery processes). Our ToU

ontology designed according to our multi-layer model

extends the control object to define precisely

contextual usage information associated to logical

data and physical copies, including archival keeping,

data portability, data sharing, CRUD operations….

This allows propagating the “restricted to delivery

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

182

purpose” usage condition on the address when a copy

of it is shared with company A.

Focusing on countermeasure scope, (Nejdl et al.

2005) et al. 2005) and (Tsai, W. T., et Shao, Q. 2011)

focuses on access control whereas (Kim, A et al.

2005) even integrates infrastructure condition with

access control, allowing integrating the secured

exchange channel constraint. Our ToU ontology

integrates infrastructure, communication, data-

protection and access control means by extending

access control and operational service to “business

purpose”, i.e. generic operations fitting a business

goal and “collaboration operations”. By this way, the

deletion constraints can be taken into account as other

protection means (storing encrypted payment token,

exchanging data through SSL-based channels…).

Compared to other ontologies, our ToU integrates

all the necessary elements to describe usage and

protection features, including data sharing and usage

delegation. By this way, constraints on life-long

usage control and protection features can be described

using a single ontology. Moreover, the usage-related

roles allow integrating the collaborative context (i.e.

the relationships between stakeholders) in the fine-

grained policy rules.

Then, we evaluate our Life-long Data Centric

Protection system (LDCP) with other works

integrating GDPR requirements, such as consent

management, usage scope definition, operation

tracking and life-long protection.

First, we identify that only (Burmeister et al.

2019) integrates the usage scope, i.e. business

purpose. (Kaaniche, N., et Laurent, M 2017) and

(Wirth, C., et Kolain, M. 2018) refer to traditional

consent management which doesn’t consider usage

scope and is only managed by the subject. (Truong,

N. B et al. 2019) retrieves the consent “signature”

from a blockchain. (Neisse, R et al. 2017) and (Di

Francesco Maesa, D et al. 2017) do not integrate data

origin to manage consent forwarding. Our system not

only manages stand-alone consents, it also integrates

consents provided in a collaborative context (i.e.

when information is shared by different parties). Our

Usage Governance architecture, allows monitoring

and evaluating the real operations on the containers,

paying attention to the business purpose. Based on the

different assertions, our system stores the approved

ToU in a Blockchain, proving Alice’s consent shared

with Online Shopping as well as the approved ToU

related to data sharing between Online Shopping and

company A. By this way, the consent origin can be

tracked. Moreover, the exchange smart contract

allows certifying the data origin on the data consumer

side.

Focusing on tracking abilities, (Wirth, C., et

Kolain, M. 2018) controls data encryption keys to

track data access and usage whereas (Neisse, R et al.

2017) tracks data forwarding and (Di Francesco

Maesa, D et al. 2017) tracks right transfer. Thanks to

our governance architecture, our system tracks real

operations on containers (i.e. copies of the logical

data) thanks to its “double approved” monitoring

agents and their associated smart contracts. As our

system manages the rights delegation, the monitoring

feature is also extended to other stakeholders getting

a copy of a data. By this way, our system controls

both data usage operation achieved by Online

Shopping, Company A and Company B as secondary

tracking agents are generated once the data is shared.

By this way, the life-long usage-based protection can

be tracked and each party can prove that it has

fulfilled its obligations.

5 CONCLUSION

In this paper we present a distributed usage

governance architecture, relying on an information

system meta-model and on Blockchain-based Terms

of Service negotiation and usage tracking.

To this end, we have extended usage and security

ontologies to define data protection requirements and

potential usages as precisely as possible. Further

works will focus on the way Information System

interface components can be implemented more

efficiently.

REFERENCES

Autrel, F., Cuppens, F., Cuppens-Boulahia, N., & Coma, C.

(2008). MotOrBAC 2: a security policy tool. In 3rd

Conference on Security in Network Architectures and

Information Systems, 273-288.

Baroudi, J., & Lucas Jr, H. C. (1994). The role of

information technology in organization design. Journal

of Management Information Systems, 10(4), 9-23.

Browne, J., Sackett, P. J., & Wortmann, J. C. (1995). Future

manufacturing systems—towards the extended

enterprise. Computers in industry, 25(3), 235-254.

Burmeister, F., Drews, P., & Schirmer, I. (2019). A

Privacy-driven Enterprise Architecture Meta-Model for

Supporting Compliance with the General Data

Protection Regulation. In Proceedings of the 52nd

Hawaii International Conference on System Sciences.

Cha, S. C., & Yeh, K. H. (2018). A data-driven security risk

assessment scheme for personal data protection. IEEE

Access, 50510-50517.

A Data-centered Usage Governance: Providing Life-long Protection to Data Exchanged in Virtual Enterprises

183

Chaari, S., Badr, Y., & Biennier, F. (2008). Enhancing web

service selection by QoS-based ontology and WS-

policy. In Proceedings of the 2008 ACM symposium on

Applied computing, 2426-2431.

Choi, C., Choi, J., & Kim, P. (2014). Ontology-based access

control model for security policy reasoning in cloud

computing. The Journal of Supercomputing, 67(3),

711-722.

Di Francesco Maesa, D., Mori, P., & Ricci, L. (2017).

Distributed access control through blockchain

technology,31-32.

Garcia, D., Toledo, M. B. F., Capretz, M. A., Allison, D. S.,

Blair, G. S., Grace, P., & Flores, C. (2009). Towards a

base ontology for privacy protection in service-oriented

architecture. In 2009 IEEE International Conference on

Service-Oriented Computing and Applications

(SOCA),1-8.

Hendrikx, F., Bubendorfer, K., & Chard, R. (2015).

Reputation systems: A survey and taxonomy. Journal

of Parallel and Distributed Computing, 75, 184-197.

Hilty, M., Pretschner, A., Basin, D., Schaefer, C., & Walter,

T. (2007). A policy language for distributed usage

control. In European Symposium on Research in

Computer Security, 531-546.

Hu, Y. J., Guo, H. Y., & Lin, G. D. (2008). Semantic

enforcement of privacy protection policies via the

combination of ontologies and rules. In 2008 IEEE

International Conference on Sensor Networks,

Ubiquitous, and Trustworthy Computing, 400-407.

ISO, IEC. (2004). information technology–multimedia

framework (MPEG-21) Part 5: Rights Expression

Language. International Organization for

standardization.

Jøsang, A., Ismail, R., & Boyd, C. (2007). A survey of trust

and reputation systems for online service provision.

Decision support systems, 43(2), 618-644.

Kaaniche, N., & Laurent, M. (2017). A blockchain-based

data usage auditing architecture with enhanced privacy

and availability. In 2017 IEEE 16th International

Symposium on Network Computing and Applications

(NCA), 1-5.

Kelbert, F., & Pretschner, A. (2013). Data usage control

enforcement in distributed systems. In Proceedings of

the third ACM conference on Data and application

security and privacy, 71-82.

Kim, A., Luo, J., & Kang, M. (2005). Security ontology for

annotating resources. In OTM Confederated

International Conferences" On the Move to Meaningful

Internet Systems",1483-1499.

Kumari, P., Pretschner, A., Peschla, J., & Kuhn, J. M.

(2011). Distributed data usage control for web

applications: a social network implementation. In

Proceedings of the first ACM conference on Data and

application security and privacy,85-96.

Liu, C. L. (2014). Cloud service access control system

based on ontologies. Advances in Engineering

Software, 69, 26-36.

Masoumzadeh, A., & Joshi, J. (2010). Osnac: An ontology-

based access control model for social networking

systems. In 2010 IEEE Second International

Conference on Social Computing, 751-759.

Neisse, R., Steri, G., & Nai-Fovino, I. (2017). A

blockchain-based approach for data accountability and

provenance tracking. In Proceedings of the 12th

International Conference on Availability, Reliability

and Security 1-10

Nejdl, W., Olmedilla, D., Winslett, M., & Zhang, C. C.

(2005). Ontology-based policy specification and

management. In European Semantic Web Conference,

290-302.

Open Mobile Alliance. (2008.) DRM Rights Expression

Language V2.1. http://www.openmobilealliance.org/

release/DRM/V2_1-20080805-C/OMA-TS-DRM_RE

L-V2_120080805-C.pdf,1-68.

Panahifar, F., Byrne, P. J., Salam, M. A., & Heavey, C.

(2018). Supply chain collaboration and firm’s

performance. Journal of Enterprise Information

Management, 31(3), 358-379.

Park, J., & Sandhu, R. (2004). The UCONABC usage

control model. ACM Transactions on Information and

System Security, 7(1), 128-174.

Pretschner, A., Hilty, M., & Basin, D. (2006). Distributed

usage control. Communications of the ACM, 49(9), 39-

44.

Pretschner, A., Lovat, E., & Büchler, M. (2011).

Representation-independent data usage control. In Data

Privacy Management and Autonomous Spontaneus

Security,122-140.

Sandhu, R. S., Coyne, E. J., Feinstein, H. L., & Youman, C.

E. (1996). Role-based access control models.

Computer, 29(2), 38-47.

Truong, N. B., Sun, K., Lee, G. M., & Guo, Y. (2019).

GDPR-compliant personal data management: A

blockchain-based solution. arXiv preprint

arXiv:1904.03038.

Tsai, W. T., & Shao, Q. (2011). Role-based access-control

using reference ontology in clouds. In 2011 Tenth

International Symposium on Autonomous

Decentralized Systems, 121-128.

Wang, L., Wijesekera, D., & Jajodia, S. (2004). A logic-

based framework for attribute-based access control. In

Proceedings of the 2004 ACM workshop on Formal

methods in security engineering 45-55.

Weber, I., Xu, X., Riveret, R., Governatori, G., Ponomarev,

A., & Mendling, J. (2016). Untrusted business process

monitoring and execution using blockchain. In

International Conference on Business Process

Management 329-347.

Wirth, C., & Kolain, M. (2018). Privacy by blockchain

design: a blockchain-enabled GDPR-compliant

approach for handling personal data. In Proceedings of

1st ERCIM Blockchain Workshop 2018. European

Society for Socially Embedded Technologies

(EUSSET).

Zhang, X., Park, J., Parisi-Presicce, F., & Sandhu, R.

(2004). A logical specification for usage control. In

Proceedings of the ninth ACM symposium on Access

control models and technologies, 1-10.

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

184
