Accommodating Negation in an Efﬁcient Event-based Natural Language

Query Interface to the Semantic Web

Shane Peelar

and Richard A. Frost

School of Computer Science, University of Windsor, 401 Sunset Avenue, Windsor, Ontario, Canada

Keywords:

Semantic Web, Compositional Semantics, Event-based Triplestores, Natural Language Processing, Natural

Language Query Interfaces, Quantiﬁcation.

Abstract:

Although The Semantic Web was built with the Open World Assumption in mind, there are many cases where

the Closed World Assumption would be a better ﬁt. This is unfortunate because the OWA prevents rich queries

involving negation from taking place, even in contexts where it would be appropriate. In this paper we present

an English Natural Language Query Interface to event-based triplestores based on Compositional Semantics

that can support both open and closed world semantics with “drop-in” denotations for “no”, “not”, “non”,

and “the least”. Where closed world semantics are not appropriate, omitting these denotations is sufﬁcient

to restore the OWA. The result is a highly expressive compositional semantics supporting complex linguistic

constructs such as chained prepositional phrases, n-ary transitive verbs, superlative phrases, and negation,

suitable for expert systems and knowledge bases.

1 INTRODUCTION

The Semantic Web consists of a collection of triple-

stores accessible via endpoints that process queries

using various query languages. Widely used methods

for querying triplestores include using SPARQL (Har-

ris et al., 2013) and Linked Data Fragments (LDF)

(Verborgh et al., 2014). These query languages, while

powerful, are not designed with end-users in mind,

with their primary use cases aimed towards databases

rather than user-facing applications. An alternative

approach to using a database querying language di-

rectly is to use a Natural Language Query Interface

(NLQI). NLQIs have a number of beneﬁts including

being accessible through both text and speech modal-

ities.

There are two main approaches used by NLQIs.

Machine Learning (ML) can be used to attempt to de-

termine the user’s intent and retrieve corresponding

relevant information. This has the advantage of be-

ing able to support a wide variety of queries, with the

risk that returned information may not truly satisfy the

user’s intent. The second type of approach is to use a

Compositional Semantics (CS) to directly answer the

query with regards to a knowledge base. CS is pred-

https://orcid.org/0000-0001-7391-0951

https://orcid.org/0000-0001-7083-5060

icated on the notion that the meaning of a sentence

can be derived from the meaning of its parts (Dowty

et al., 1981). This has the advantage that the answer to

a query is as correct as the information in the knowl-

edge base itself. As a result, CS-based NLQIs are

able to express highly sophisticated “narrow” queries

using complex linguistic constructs including superla-

tives and chained prepositional phrases. For example,

it is possible for the NLQI presented in this paper to

evaluate, with respect to a knowledge base consisting

of facts about the solar system, the query:

which vacuumous moon that orbits the

planet that is orbited by the most moons

was discovered by nicholson or pickering

with a telescope in 1898 at not mt wilson

or not mt hopkins

However, CS approaches have drawn a lot of criti-

cism. They have been characterized as being rigid,

and therefore not sufﬁciently able to handle complex

queries in real world applications. Recent work has

addressed a number of these issues, including ac-

commodating chained complex prepositional phrases

(Peelar, 2016), n-ary transitive verbs (Peelar and

Frost, 2020b) and superlative phrases (Frost and Pee-

lar, 2019). It has also been shown that CS can be

memoized for efﬁcient evaluation (Peelar and Frost,

2020a), which also enables ofﬂine pre-computation of

query results.

Peelar, S. and Frost, R.

Accommodating Negation in an Efﬁcient Event-based Natural Language Query Interface to the Semantic Web.

DOI: 10.5220/0010148500830092

In Proceedings of the 16th International Conference on Web Information Systems and Technologies (WEBIST 2020), pages 83-92

ISBN: 978-989-758-478-7

One criticism of our previous approaches was that

they relied on the Open World Assumption (OWA)

and hence could not support negation in queries.

While the Resource Description Framework (RDF)

((W3C), 2014) underlying the Semantic Web itself is

predicated on the OWA, there exist triplestores where

the Closed World Assumption (CWA) holds, particu-

larly in knowledge bases for expert systems. It would

be ideal to support negation in queries to these triple-

stores.

In this paper, we show that it is possible to ac-

commodate negation in an English NLQI to an event-

based triplestore where the CWA holds. In particu-

lar, we describe an English NLQI to an event-based

triplestore using a CS that supports arbitrary quan-

tiﬁcation including negation, complex linguistic con-

structs including chained prepositional phrases with

superlatives and n-ary transitive verbs. The approach

is an extension of Montague’s approach (Dowty et al.,

1981). Readers are directed towards (Frost and Pee-

lar, 2019) and (Peelar and Frost, 2020a) for an intro-

duction to the work that this paper builds on.

In Section 2 we describe previous work on NLQIs

to the Semantic Web that support negation. In Sec-

tion 3 we describe how to access a live demonstration

of our NLQI that can accommodate the queries pre-

sented in this paper along with some other example

queries. In Section 4 we describe our event-based se-

mantics and in Section 5 we describe how to accom-

modate negation where the CWA holds. In Section 6

we provide a list of examples queries and explain how

they are processed. Finally, we conclude in Section 7

and Section 8.

2 PREVIOUS WORK

In 2002, Frost and Boulos introduced the notion of

“complementary sets” as a way of accommodating

negation in FLMS, a set-theoretic version of Mon-

tague Semantics (Frost and Boulos, 2002). Their ap-

proach has two drawbacks: ﬁrst, that a separate deno-

tation for transitive verbs had to be created for han-

dling queries such as “discover no moon”. In prac-

tice, this meant that 4 denotations of transitive verbs

were required: for active and passive tense verbs,

and a corresponding “no” query (as in “discover no

moon” or “discovered by no person”). The ap-

proach presented in this paper requires only one deno-

tation for transitive verbs for all cases, including with

the presence of chained prepositional phrases and su-

perlatives. Second, their approach required that the

cardinality of the set of entities in the database be a

known constant. The denotations presented in this pa-

per receive the cardinality of the set of entities as an

argument instead. A query is made to the triplestore

itself to retrieve the cardinality of the set of entities,

removing the need for computing it locally.

Champollion showed that that negation in event-

based CS can be accommodated using “negative

events” (Champollion, 2011). These appear to be

similar to the ideas expressed in (Frost and Boulos,

2002), although both approaches were developed in-

dependently. Where Frost and Boulos discuss repre-

senting the result of a “negative” query by implic-

itly enumerating the complement of a set of enti-

ties, Champollion describes events that preclude other

events from occurring. This gives some conﬁdence

about the nature of the approach taken towards ac-

commodating negation in CS. Our own approach to

negation in this paper is based in part on (Frost and

Boulos, 2002), but is event-based rather than entity-

based and therefore suitable for event-based triple-

stores.

SQUALL (Ferre, 2012) has limited support for

negation in queries, mapping negation onto the

“NOT EXISTS” construct of SPARQL. In particular,

SQUALL has a denotation for the adverb “not”,

where its presence removes triples from the result

set. This implies closed-world semantics for the query

(Darari et al., 2014), although this is not discussed

by the authors. SQUALL is unable to accommo-

date negation in noun-phrases (such as “which non-

moon spins”). SQUALL is also unable to negate

termphrases (for example “not Hall or not Galileo”).

The reading of SQUALL queries is also not as nat-

ural as our semantics. The example given in (Ferr

2014), “Which author of Paper42 has not afﬁliation

Salford University?” could be expressed in the se-

mantics of this paper as “Which author of Paper42 is

not afﬁliated with Salford University?” Also, where

SQUALL depends strictly on translation to SPARQL,

the approach described in this paper is not tied to any

particular database query language or interface and

could readily be adapted to relational databases.

3 HOW TO ACCESS OUR NLQI

A live demonstration of our NLQI is accessible via

the following URL:

https://speechweb2.cs.uwindsor.ca/solarman4/

demo sparql.html

In addition to accepting textual input, it also can be

interacted with speech on browsers that support the

WebSpeech API (W3C et al., 2018). Currently, this

includes Google Chrome-based browsers and Firefox.

WEBIST 2020 - 16th International Conference on Web Information Systems and Technologies

3.1 System Overview

The approach presented in this paper is based on

Richard Montague’s denotational semantics (Dowty

et al., 1981). In particular, our system derives the

meaning of a query from the meaning of its parts.

A query is evaluated with respect to a triplestore as

though it were a formal mathematical expression us-

ing an Executable Attribute Grammar (Haﬁz, 2011).

For example, the query “ganymede discovered no

moons” is evaluated as the expression:

kphobosk (kdiscoveredk (knok kmoonsk))

where kxk represents the denotation (meaning) of x.

3.2 Supported Features

The following are a list of example queries that

demonstrate features supported by the interface.

n-ary Transitive verbs:

who used a telescope to discover a moon

Quantiﬁcation:

who used two telescopes to discover one

moon ⇒ science team 2

Chained prepositional phrases:

which telescope was used by a person in

1877 ⇒ refractor telescope 1

Superlatives:

hall discovered the most moons that

orbit mars ⇒ True

Negated noun-phrases:

a non-planet was discovered ⇒ True

Negated verb-phrases:

allen did not discover anything ⇒ True

Negated term-phrases, including conjunction:

not hall and galileo discovered phobos

⇒ False

Adjectives:

enceladus is a vacuumous moon ⇒ True

The above features can be combined arbitrarily to

form rich queries. For example, adjectives can be

combined with negation:

mars is a non-blue planet ⇒ True

In all cases, the query processor returns the syntax

tree of the query to help the user understand how the

query was evaluated (Peelar and Frost, 2020b). A list

of example queries and a discussion of how they are

evaluated can be found in Section 6.

4 EVENT-BASED

DENOTATIONAL SEMANTICS

The approach described in this paper builds upon

FLMS (Frost and Launchbury, 1989), EV-FLMS

(Frost et al., 2014), UEV-FLMS (Peelar, 2016), and

most recently Memoized UEV-FLMS (Peelar and

Frost, 2020a). Notably, our semantics are event-based

rather than entity-based. The fundamental data struc-

ture underlying our semantics is called the Function

deﬁned by a Relation, or FDBR, described in Sec-

tion 4.2. This data structure has been shown to be

useful in answering a wide variety of Natural Lan-

guage queries (Frost and Peelar, 2019). In this pa-

per, we show how the FDBR can be used to answer

queries involving negation in event-based databases

where the CWA holds.

4.1 Event-based Triplestores

A conventional triplestore is a database of triples that

have the form (Subject, Predicate, Object). An event-

based triplestore is a triplestore where the Subject of a

triple denotes an event (Frost et al., 2013)(Frost et al.,

2014). The main advantage event-based triplestores

offer is that it is straightforward to add additional in-

formation to an event by simply adding more triples

referencing that event. It is less straightforward to do

the same in a triplestore where the Subject denotes an

entity. Such an approach in a conventional triplestore

requires reiﬁcation and involves using ontological in-

formation to link multiple triples together.

As an example, consider a triple that describes the

statement “Jane bought a pencil”:

<ent:Jane> <act:purchase> <ent:pencil_1> .

Without reiﬁcation, there is no way to add other in-

formation about the purchase to the triplestore, such

as the price, or the time or location that the transac-

tion took place. In an event-based triplestore, this is

straightforward:

<event:1> <type> <type:purchase_ev> .

<event:1> <subject> <ent:Jane> .

<event:1> <object> <ent:pencil_1> .

Since the triples directly reference the event itself,

adding more information about the event simply in-

volves adding more triples to the triplestore with the

Subject matching the event.

4.2 The Function Deﬁned by a Relation

(FDBR)

The notion of a Function deﬁned by a Relation

(FDBR) was ﬁrst described in (Peelar, 2016) as use-

Accommodating Negation in an Efﬁcient Event-based Natural Language Query Interface to the Semantic Web

ful datastructure for accommodating chained preposi-

tional phrases in Natural Language Queries. It was

shown that the word “by”, as in “discovered by”,

could be treated as a “virtual preposition” under this

approach. In (Frost and Peelar, 2019) it was shown

that the FDBR can be used to answer many kinds

of NL queries including superlatives (including those

that occur in a prepositional phrase), and as a use-

ful datastructure for memoizing the results of queries

performed in the denotations. This vastly improved

query execution time and opened the door for ofﬂine

computation of results. The deﬁnition of the FDBR is

as follows:

FDBR(rel) = {(x, image

) | (∃e) (x, e) ∈ rel

& image

= {y | (x, y) ∈ rel}}

Where rel is the name of a binary relation. The FDBR

has been shown to be useful for the denotation of

transitive verbs. Consider the denotation for the ac-

tive voice of “discover” given in (Peelar and Frost,

2020b), for example:

kdiscoverk =

λt {(s, relevs) | (s, evs) ∈ FDBR(discover rel)

& (t obj fdbr(evs) 6=

& relevs = gather(obj fdbr(evs))}

where obj fdbr(evs) is the FDBR from the objects in

the events of the set evs to the events they participate

in within evs. “discover phobos”, where phobos is

a proper noun, results in the FDBR:

{(e

hall

, {ev

1045

, ev

1046

})}

The FDBR can be readily extended to n-ary rela-

tions (and hence n-ary transitive verbs) (Peelar and

Frost, 2020b). In this paper we show that with some

small modiﬁcations, the FDBR can be used to answer

NL queries with negation as well, in cases where the

CWA holds.

5 ACCOMMODATING

NEGATION

Negation in NL queries is only possible if the CWA

holds for a database. We modify the semantics pre-

sented in (Frost and Peelar, 2019), (Frost and Peelar,

2018) and (Peelar and Frost, 2020b) such that the re-

sults of denotations may return the complement of an

FDBR in addition to an FDBR, adopting a similar ap-

proach to (Frost and Boulos, 2002). We deﬁne this

type as follows:

type Result = FDBR fdbr | ComplementFDBR fdbr

We then deﬁne the intersection of two Result

types as follows:

intersect_result (FDBR a) (FDBR b)

= FDBR $ intersect_fdbr a b

intersect_result (FDBR a) (ComplementFDBR b)

= FDBR $ difference_fdbr a b

intersect_result (ComplementFDBR a) (FDBR b)

= FDBR $ difference_fdbr b a

intersect_result (ComplementFDBR a)

(ComplementFDBR b)

= ComplementFDBR $ union_fdbr a b

Where intersect fdbr operates as it did previously,

and a new function difference fdbr is introduced

as follows:

difference fdbr = λmλs.{(e

, evs

) | (e

, evs

) ∈ m

& ∀(e

, evs

) ((e

, evs

) ∈ s ⇒ e

6= e

)}

That is, difference fdbr removes all entities found in

the left column of the second FDBR from the ﬁrst

FDBR. This is a key function for performing nega-

tion, and plays a similar role to the NOT EXISTS op-

erator in SPARQL. A function is introduced for com-

puting the union of Results as well:

union_result (FDBR a) (FDBR b)

= FDBR $ union_fdbr a b

union_result (FDBR a) (ComplementFDBR b)

= ComplementFDBR $ b ‘difference_fdbr‘ a

union_result (ComplementFDBR a) (FDBR b)

= ComplementFDBR $ a ‘difference_fdbr‘ b

union_result (ComplementFDBR a)

(ComplementFDBR b)

= ComplementFDBR $ a ‘intersect_fdbr‘ b

This is used in the denotation of “and” and “or” as

used with termphrases. Next, we introduce a function

to obtain the cardinality of a Result:

cardinality _ (FDBR np) = List.length np

cardinality (Just num_ents) (ComplementFDBR np)

= num_ents - length np

The ﬁrst argument to this function is passed in from

the query pipeline described in (Peelar and Frost,

2020a), and is either Nothing or Just num ents,

where num ents is the cardinality of the set of enti-

ties in the triplestore. It will only be retrieved if the

query has any denotations involving negation in it.

Our approach maintains leftmost-outermost scop-

ing of quantiﬁers including negation, which enables a

natural reading of the query.

5.1 Quantiﬁers

We modify the denotations of all quantiﬁers to be

characterized in terms of the cardinality:

WEBIST 2020 - 16th International Conference on Web Information Systems and Technologies

a’ = intersect_result

every’’ cardinality nph vbph =

if cardinality result == cardinality nph

then result else FDBR []

one’’ cardinality nph vbph =

if cardinality result == 1

then result

else FDBR []

two’’ cardinality nph vbph =

if cardinality result == 2

then result

else FDBR []

most’’ cardinality nph vbph =

if n_nph /= 0 && (n_nph_v / n_nph) > 0.5

then result else FDBR []

where

n_nph = fromIntegral $ cardinality nph

n_nph_v = fromIntegral $ cardinality res

where in the above denotations, result =

intersect result’’ nph vbph. Curiously,

the function cardinality appears as the ﬁrst

argument to these quantiﬁers, giving them three

arguments in total. This function is passed in from

the caller as a function that can be used to obtain the

cardinality of a FDBR. A function, “apply card” is

used to automatically apply the cardinality function

to the denotations. For example:

every’ = applyCard every’’

>|< GettsIntersect GI_Every

every = wrapS2 every’

The >|< operator is described in more detail in (Peelar

and Frost, 2020a). It is used to assign a unique name

to the denotations according to the syntax tree of the

query. This is useful for memoization and query opti-

mization. “no” is denoted as follows:

no’’ cardinality nph (FDBR []) =

ComplementFDBR []

no’’ cardinality nph vbph =

if cardinality result == 0 then vbph

else FDBR []

where in the above denotations, result =

intersect result’’ nph vbph. This is a de-

parture from the denotation of “no” given in (Frost

and Boulos, 2002). Namely, the complement of the

empty FDBR (denoting “everything”) is returned

when an empty FDBR is passed as the second

argument to “no”. This is critical in handling “no” in

the denotation of transitive verbs as discussed later in

Section 5.4.

5.2 Negating Noun- and Verb-Phrases

We denote “not”, when applied to a verb-phrase

(such as “not spins”) as follows:

not (FDBR vbph) = ComplementFDBR vbph

not (ComplementFDBR vbph) = FDBR vbph

“non” plays a similar role as a preﬁx to a noun-phrase,

and can be denoted as:

non = not

5.3 Negating Term-Phrases

One aspect missing from both (Ferr

e, 2014) and

(Frost and Boulos, 2002) is the notion of negat-

ing termphrases, such as “hall”, “a moon”, “one

moon”, and “no moon”, which exhibits double nega-

tion. Negating termphrases provides more ﬂexibility

to the query interface, making it possible to express

the query:

who discovered in 1877 not one moon that

orbits mars

Where “one” denotes “exactly one”. This query ex-

plicitly is excluding any discoverers that discovered

exactly one moon that orbits mars. It results in hall,

because hall discovered two moons that orbit mars

in 1877. “not” when applied to a term-phrase, such

as “hall” or “a moon” is denoted as follows:

termnot tmph vbph

= intersect_result (not (tmph vbph)) vbph

Therefore not hall spins is evaluated as follows:

(not hall) spins

=> intersect_result (not (hall spins)) spins

=> intersect_result (not (FDBR [])) spins

=> intersect_result (ComplementFDBR []) spins

=> spins

=> True (because spins is not empty)

Negating term-phrases was not discussed in (Frost

and Boulos, 2002), and it offers more ﬂexibility in

the nature of queries that can be performed (see Sec-

tion 6)

5.4 A Denotation for Transitive Verbs

That Accommodates Superlatives,

Prepositional Phrases, and Negation

Transitive verbs are less straightforward to accommo-

date with negation. Consider the following query:

ganymede discovered no moons

This query should evaluate to True, as ganymede, a

moon, was not the subject of any discovery events –

however, ganymede is not the subject of any events

of type discover. Therefore, it is missing from

FDBR(discover rel).

A denotation is given in (Frost and Boulos, 2002)

that accommodates this usage of transitive verbs;

however it requires syntactic disambiguation at the

grammar level to apply correctly. The approach also

Accommodating Negation in an Efﬁcient Event-based Natural Language Query Interface to the Semantic Web

does not scale well when other linguistic constructs

are introduced, such as chained prepositional phrases

and superlatives, requiring a new denotation to sup-

port each usage. The examples given in that paper

required 4 denotations for transitive verb depending

on the context.

The denotation we introduce expands on the deno-

tation introduced in (Frost and Peelar, 2019), where

we described how superlative phrases can also be

accommodated. This new denotation evaluates the

list of prepositional phrases (including superlatives)

in leftmost-outermost order, which is consistent with

other work in the area (Champollion, 2010), (Ferr

2014). For example, the query “discovered a

moon in 1877 with a telescope” would be eval-

uated with scoping as though it were as fol-

lows: “discovered (a moon (in 1877 (with a

telescope))) – that is, “with a telescope” takes

precedence over ”in 1877, which in turn takes prece-

dence over a moon”.

Only one denotation for transitive verbs is re-

quired for all cases (rather than 4 as in (Frost and

Boulos, 2002)). In particular, the word “no” can be

handled compositionally rather than syntactically in

the query.

We modify the denotation for transitive verbs

given in (Peelar and Frost, 2020a) to evaluate the list

of prepositional phrases in leftmost-outermost order.

The filter ev function, described in (Peelar, 2016),

is modiﬁed to operate on one prepositional phrase at

a time: a new FDBR is computed for each preposi-

tional phrase applied. This allows superlatives to be

neatly evaluated in the order they appear rather than in

a separate stage after the prepositions are evaluated as

denoted in (Frost and Peelar, 2019). filter ev also

is modiﬁed to account for negation in the query: ﬁrst,

the current prepositional phrase is evaluated against

the empty FDBR (FDBR[]). If the result is not an

FDBR, then it is a no termphrase:

in no place (FDBR [])

=> ComplementFDBR []

This is owing to the denotation of no used in Sec-

tion 5.1. Indeed, the only way to obtain a non-empty

FDBR from applying an empty FDBR is through

negation. When this is the case, filter ev returns

a complement in the same fashion as (Frost and Bou-

los, 2002).

Since filter ev can also receive the complement

of an FDBR, as in the case when negation is present

in the query, applying term-phrases can be difﬁcult.

The complement operation is reversed by taking the

FDBR of the transitive verb itself and performing the

intersection of it with the complement passed into

filter ev. Whether negation is present in the cur-

rent prepositional phrase or not, this FDBR is passed

in to the termphrase of that preposition. If no nega-

tion is present in the current preposition, the result is

returned as-is, unless it contains a superlative. Oth-

erwise, if negation is present, then if a complement

of an FDBR was passed into filter ev, the FDBR

used in the denotation of the transitive verb itself

is used to compute the complement, otherwise the

FDBR passed into filter ev is used directly. This

allows for discover no moon in 1948 to work as

expected. This can neatly handle the following cases:

discover no moons in no places with no

telescopes

The result is the complement of the FDBR of those

that discovered a moon in a place with a telescope

discover no moons in 1877

The result is the complement of the FDBR of those

that discovered a moon in 1877

discover a moon in 1877

The result is the FDBR of the people that discovered

a moon in 1877.

5.5 Obtaining the Cardinality of the

Entities of the Triplestore

In systems where the Open World Assumption holds,

obtaining the cardinality of the set of entities may not

be possible, as the cardinality of that set may be inﬁ-

nite. Attempting to obtain that set at all may not be

practical. Even in systems where the CWA holds, ob-

taining the set of all entities in the database may not be

feasible. Fortunately, only the cardinality is required

to start answering queries.

A new querying primitive is introduced from (Pee-

lar and Frost, 2020a) that queries the remote triple-

store itself for the cardinality of the set of entities in

the triplestore:

getts_cardinality_allents ev_data props

Here, ev data represents the URL of the triple-

store itself (in the case of SPARQL, a SPARQL end-

point URL), and props is the set of properties of

the events contained in the triplestore whose enti-

ties should be counted towards the cardinality. In

the example queries given in this paper, the prop-

erties listed for cardinality are subject, object,

location, and implement. We exclude the year

property as all entities must exist both physically and

temporally ((W3C), 2014). This function, like the

other getts* family functions described in (Frost and

Peelar, 2019), can be specialized for different types of

databases, including relational triplestores.

This alleviates having to send the full set of enti-

ties to the semantics in order to answer a query that

WEBIST 2020 - 16th International Conference on Web Information Systems and Technologies

uses negation. Note that the cardinality of the set

of entities of the triplestore is only ever required in

queries that have negation present. Using the memo-

ization and triplestore querying framework described

in (Peelar and Frost, 2020a), a guarantee is made that

if no negation is present in the query, the cardinality

query will never be performed. Therefore, our denota-

tions for negation in queries, including “not”, “non”,

“no” and “the least”, are drop-in enhancements to

NLQIs built using our framework: if the CWA holds

for the application, all one needs to do is add these de-

notations in. Otherwise, the NLQI will operate with

the open world semantics described in (Frost and Pee-

lar, 2019).

In some cases, the user may want to force evalu-

ation of the complement. It is possible to introduce

a special denotation, “force eval”, will obtain all

triples and force retrieval of all entities. This may be

cached on the interface to alleviate the load against the

remote triplestore using the memoization framework

in (Frost and Peelar, 2019). It may be appropriate

to evaluate the complement if its cardinality is under

a certain threshold as well, triggering “force eval”

automatically – this could be customized on a per-

application basis.

5.6 Accommodating “The Least”

In (Frost and Peelar, 2019) we described how to ac-

commodate superlative phrases compositionally by

delegating their evaluation to the transitive verb they

are arguments of. This allows them to appear in

chained prepositional phrases.

One problem described with that approach was

answering queries with superlatives such as “the

least” or “the lowest number of”. The main reason

for this was owing to the OWA underlying the

semantics. Under that approach, “which planets

are orbited by the least number of moons”

would return earth, despite both venus and mercury

having a lower number of moons than Earth. The

semantics had no concept of zero and could only

report about what was observable. Since there were

no events explicitly stating that venus and mercury

had no moons, it could not assume that it was not the

case.

We propose an alternative approach in this paper,

where “the least” is handled similarly to the word

“no”. The denotation for “the least” ﬁrst checks

that the complement of the FDBR is non-empty. If so,

“the least” returns the complement of that FDBR

– this allows for “venus” and “mercury” to appear in

the result set while removing all non-candidates. If

the complement of the FDBR is empty, however, then

it performs the same cardinality partitioning that the

“the most” does (Frost and Peelar, 2019), except it

chooses the lowest object cardinality entities to form

the result rather than the greatest.

6 EXAMPLE QUERIES

The following are some example queries that can be

handled by our NLQI. With each query we explain the

result and how it was evaluated.

no people spin ⇒ True

The intersection of the people and spins FDBRs is

empty, therefore no returns spin, which is non-empty

and therefore True.

a non person exists ⇒ True

“non person” is the complement of the person set,

and the intersection of this complement with the

exists set (which is the complement of the empty

set) is the same as the complement of the union of the

person set with the empty set. The answer is charac-

terized in terms of the cardinality, which for the com-

plement of an FDBR is deﬁned as the cardinality of

the number of set of entities in the triplestore minus

the cardinality of the FDBR itself. This is greater than

0, and therefore there is at least one entity that is both

a non-person and exists.

a person does not exist ⇒ False

This computes the intersection of the person FDBR

with the complement of the exists FDBR, which is

just the empty FDBR. Therefore, the result is empty,

and the result is False.

what discovered no moon in 1877 ⇒

everything except: hall

This sentence is treated similarly to what did not

discover a moon in 1877. The result is the com-

plement of the set of entities that discovered a moon

in 1877, in this case, hall.

what discovered a non moon ⇒ nothing.

This query is speciﬁcally asking about entities that

discovered non-moons – the entities that did not dis-

cover anything are not included in this set and there-

fore an FDBR is returned. Since that FDBR is empty,

the result is that nothing in our triplestore discovered

any non-moons.

allen discovered no moon at no places

⇒ True

The result of “discovered no moon at no

places” is the complement of the FDBR returned

from “discovered a moon at a place”. This

includes entities that either discovered a moon at

no known location, or discovered a non-moon at a

known location. Since allen does not appear in

Accommodating Negation in an Efﬁcient Event-based Natural Language Query Interface to the Semantic Web

the FDBR returned by “discovered a moon at a

place”, the result is True.

what discovered the most moons using no

telescopes ⇒ voyager science team

This query combines both a superlative phrase with

negation. The query is asking “out of the events where

entities discovered something without using a tele-

scope, which ones discovered the most moons”. Since

voyager science team used no telescopes at all to

discover 22 moons, more than any other entities that

discovered using no telescopes, they are in the result

set.

what was discovered by no team in 1877

⇒ everything.

This query is handled the same as “what was not

discovered by a team in 1877”, which returns

the complement of the empty FDBR, since no teams

discovered anything in 1877.

how was something discovered using no

telescope ⇒ I can’t perform this query

because I would need to enumerate the

entire triplestore.

This query is asking about which implements that

are not telescopes were used in a discovery event.

However, something is deﬁned as the complement

of the empty FDBR, and discovered using no

telescope is the complement of the FDBR of

discovered using a telescope. Since the inter-

section of the two complements is itself a comple-

ment, how receives the complement of an FDBR

and is unable to enumerate the events to retrieve

implements from directly. Although it is possi-

ble to answer the query by fully evaluating the

complement, we have not implemented this be-

haviour in our NLQI at this time. However, a sim-

ilar query, “which non telescope was used to

discover something” is able to yield the result

“cassini, voyager 1, voyager 2”.

not hall discovered ganymede ⇒ True

“not hall” is a negated term-phrase. The result is True

because galileo discovered ganymede, not hall.

which person that does not spin

discovered no planet in 1877 using

a telescope and is a discoverer ⇒

bernard, bond, cassini, christy, dollfus,

galileo, hall, herschel, holman, huygens,

karkoschka, kowal, kuiper, lassell,

melotte, nicholson, perrine, pickering,

sheppard, showalter

The result is all of the people that are discoverers,

since none of the members of person spin, and

none of them discovered a planet in 1877 using a

telescope. It may be helpful to examine the scoping

of this query:

which (person ‘that‘ (does not spin))

((discovered (no planet) [in 1877, using

(a telescope)]) and (is a discoverer))

nothing exists ⇒ False

This is False because the intersection of thing and

exists is non-empty.

everything exists ⇒ True

This is True because thing and exists are both the

complement of the empty FDBR, and the intersection

of those results in the same. Therefore “thing” is a

subset of “exists”.

what was not discovered by hall

⇒ everything except: deimos, phobos

This is the complement of the FDBR “discovered by

hall”. The answer is the set of all things excluding

those that hall discovered.

phobos and deimos were not discovered

by not hall ⇒ True

This query features double negation and is equiva-

lent to asking “phobos and deimos were discovered

by hall”. The result is True.

not not kuiper discovered not not

nereid

This query also features double negation on the

termphrases kuiper and nereid. This is equivalent

to the query kuiper discovered nereid.

which non vacuumous moon that orbits

most planets that spin was not discovered

by kuiper at two places using the most

telescopes in 1942 ⇒ none.

This query features a variety of complex lin-

guistic constructs, including nested n-ary transi-

tive verbs, adjectives, negation, chained preposi-

tional phrases, quantiﬁcation and superlative phrases.

The result is “none” because “non vacuumous moon

that orbits most planets that spin” returns

the empty FDBR, and the intersection of the empty

FDBR with any set is also the empty FDBR.

not no moon orbits mars ⇒ True

This query features a negated termphrase, which it-

self consists of the word “no” (entailing negation it-

self). “orbits mars” is the FDBR from the enti-

ties phobos and deimos to their orbit events, and

“not no moon orbits mars” evaluates to “orbits

mars” with the entities of “no moon orbits mars”

removed. Since “no moon orbits mars” is False, it

returns the empty FDBR, which is then removed from

“orbits mars”, giving a non-empty result. There-

fore, the query returns True. This provides evidence

that our NLQI correctly handles negation as a compo-

sitional construct.

who discovered no moons at no places ⇒

allen, baum, buie, burns ...(full results

omitted here)... weaver, young e f,

WEBIST 2020 - 16th International Conference on Web Information Systems and Technologies

young l a

The result is everyone that is not known to have dis-

covered a moon at a place. This includes the discov-

erers that discovered a moon at no known location, or

whose location property is not listed in the event, or

discoverers that discovered a non moon at a known

location.

7 FUTURE WORK

Our next efforts will be focused on creating an NLQI

to DBPedia using the approaches described here and

in (Peelar and Frost, 2020a). Speciﬁcally, we plan

to use Timbr.ai (Timbr, 2020) to provide a relational

view of DBPedia, targeting SQL as the query lan-

guage. Once this is done, we plan to test our NLQI

using well-known benchmarks such as QALD (Us-

beck et al., 2018).

We also plan to explore interfacing with non-event

based triplestores in general. ML approaches may be

useful in contexts where ontological information is

not available for reiﬁcation.

8 CONCLUSIONS

We have shown that it is possible to accommodate

negation in our event-based CS efﬁciently. We have

shown that our approach to negation is powerful, able

to be applied to noun-phrases, verb-phrases, and term-

phrases. We presented a denotation for “no” that en-

ables it to be treated as a quantiﬁer that can be compo-

sitionally used in conjunction with transitive verbs, ei-

ther as an argument to the verb or as a preposition. We

improved on (Frost and Boulos, 2002) by maintain-

ing only one denotation for transitive verbs through-

out the semantics rather than requiring different de-

notations depending on the context. Notably, our ap-

proach to negation seems to be consistent with other

work in event semantics (Champollion, 2011). We

improved on (Ferr

e, 2013) by enabling the negation

of term-phrases, and also enabling our approach to be

used with other query languages than SPARQL. We

discussed the necessity of the Closed World Assump-

tion for queries involving negation and described how

to extend the CS in (Frost and Peelar, 2019) to ac-

commodate negation in queries. Where the CWA is

not appropriate, leaving out the denotations for “not”,

“non”, and “the least” is sufﬁcient to restore the

Open World Assumption in the semantics. Our ap-

proach also ﬁts within the memoization framework in

(Frost and Peelar, 2019). We also discussed exam-

ple queries that are supported with our NLQI and ex-

plained how the results are formed. We believe now

that our semantics is ready to be benchmarked directly

against other systems on large knowledge bases using,

for example, QALD-9 (Usbeck et al., 2018).

ACKNOWLEDGEMENTS

This research was supported by NSERC of Canada.

REFERENCES

Champollion, L. (2010). Quantiﬁcation in event semantics.

In Talk given at the 6th int. symp. of cogn., Logic and

commun.

Champollion, L. (2011). Quantiﬁcation and negation in

event semantics.

Darari, F., Razniewski, S., and Nutt, W. (2014). Bridging

the semantic gap between RDF and SPARQL using

completeness statements [extended version]. CoRR,

abs/1408.6395.

Dowty, D., Wall, R., and Peters, S. (1981). Introduction to

Montague Semantics. D. Reidel Publishing Company,

Dordrecht, Boston, Lancaster, Tokyo.

Ferre, S. (2012). Squall: A controlled natural language for

querying and updating rdf graphs. In proc. of CNL

2012, pages 11–25. LNCS 7427.

Ferr

e, S. (2013). Squall: a controlled natural language as

expressive as sparql 1.1. In International Conference

on Application of Natural Language to Information

Systems, pages 114–125. Springer.

Ferr

e, S. (2014). Squall: The expressiveness of sparql 1.1

made available as a controlled natural language. Data

& Knowledge Engineering, 94:163–188.

Frost, R. and Launchbury, J. (1989). Constructing natu-

ral language interpreters in a lazy functional language.

The Computer Journal, 32(2):108–121.

Frost, R. A., Amour, B. S., and Fortier, R. (2013). An

event based denotational semantics for natural lan-

guage queries to data represented in triple stores. In

ICSC, 2013 IEEE Seventh International Conference

on Semantic Computing, pages 142–145. IEEE.

Frost, R. A. and Boulos, P. (2002). An efﬁcient composi-

tional semantics for natural-language database queries

with arbitrarily-nested quantiﬁcation and negation. In

Cohen, R. and Spencer, B., editors, Advances in Ar-

tiﬁcial Intelligence, 15th Conference of the Canadian

Society for Computational Studies of Intelligence, AI

2002, Calgary, Canada, May 27-29, 2002, Proceed-

ings, volume 2338 of Lecture Notes in Computer Sci-

ence, pages 252–267. Springer.

Frost, R. A., Donais, J., Matthews, E., and Agboola, W.

(2014). A demonstration of a natural language query

interface to an event-based semantic web triplestore.

In ESWC, pages 343–348. Springer LNCS Volume

8798.

Accommodating Negation in an Efﬁcient Event-based Natural Language Query Interface to the Semantic Web

Frost, R. A. and Peelar, S. M. (2018). An extensible natural-

language query interface to an event-based semantic

web triplestore. In Choi, K., Anke, L. E., Declerck,

T., Gromann, D., Kim, J., Ngomo, A. N., Saleem,

M., and Usbeck, R., editors, Joint proceedings of the

4th Workshop on Semantic Deep Learning (SemDeep-

4) and NLIWoD4: Natural Language Interfaces for

the Web of Data (NLIWOD-4) and 9th Question An-

swering over Linked Data challenge (QALD-9) co-

located with 17th International Semantic Web Con-

ference (ISWC 2018), Monterey, California, United

States of America, October 8th - 9th, 2018, volume

2241 of CEUR Workshop Proceedings, pages 1–16.

CEUR-WS.org.

Frost, R. A. and Peelar, S. M. (2019). A new data structure

for processing natural language database queries. In

Proceedings of the 15th International Conference on

Web Information Systems and Technologies, WEBIST

2019, Vienna, Austria, September 18-20, 2019, pages

80–87.

Haﬁz, R. (2011). Executable attribute grammars for modu-

lar and efﬁcient natural language processing.

Haﬁz, R., Frost, R., Peelar, S., Callaghan, P., and Matthews,

E. (2020). The xsaiga package.

Harris, S., Seaborne, A., and Prud’hommeaux, E. (2013).

Sparql 1.1 query language. W3C recommendation,

21(10).

Peelar, S. (2016). Accommodating prepositional phrases in

a highly modular natural language query interface to

semantic web triplestores using a novel event-based

denotational semantics for english and a set of func-

tional parser combinators. Master’s thesis, University

of Windsor (Canada).

Peelar, S. and Frost, R. A. (2020a). A new approach

for processing natural-language queries to semantic

web triplestores. In 15th International Conference

on Web Information Systems and Technologies, WE-

BIST 2019, Vienna, Austria, September 18-20, 2019,

Revised Selected Papers, Lecture Notes in Business

Information Processing. Springer.

Peelar, S. M. and Frost, R. A. (2020b). A compositional se-

mantics for a wide-coverage natural-language query

interface to a semantic web triplestore. In IEEE

14th International Conference on Semantic Comput-

ing, ICSC 2020, San Diego, CA, USA, February 3-5,

2020, pages 257–262. IEEE.

Timbr (2020). Timbr.io. https://wiki.dbpedia.org/timbr.

Usbeck, R., Gusmita, R. H., Ngomo, A.-C. N., and Saleem,

M. (2018). 9th challenge on question answering over

linked data (qald-9). In Semdeep/NLIWoD@ ISWC,

pages 58–64.

Verborgh, R., Vander Sande, M., Colpaert, P., Coppens, S.,

Mannens, E., and Van de Walle, R. (2014). Web-scale

querying through linked data fragments. In LDOW.

Citeseer.

W3C et al. (2018). Web speech api. Retrieved from World

Wide Web Consortium: https://w3c. github. io/speech-

api.

(W3C), T. W. W. W. C. (2014). RDF 1.1 Semantics. https:

//www.w3.org/TR/rdf11-mt/. [Online; accessed 06-

September-2016].

APPENDIX

The complete source code for the demonstration, in-

cluding the semantics and parsing framework, can be

found online at the Hackage Haskell package reposi-

tory under the XSaiga project (Haﬁz et al., 2020):

https://hackage.haskell.org/package/XSaiga

WEBIST 2020 - 16th International Conference on Web Information Systems and Technologies
