Review of VANET (Vehicular Ad Hoc Network) and Countermeasure

against DOS Attack

Muhammad Ananda Fauzan

, Selo Sulistyo

and I Wayan Mustika

Department of Electrical Engineering and Information Technology, Universitas Gadjah Mada, Yogyakarta, Indonesia

Keywords:

VANET, MANET, Security, Node, Communication, Autonomous Vehicles, ITS.

Abstract:

VANET technology is a sub-domain of MANET that being used in vehicles. This technology able to improve

the security for drivers because it provides communication features between vehicles. Vehicles will act as a

nodes and supporting infrastructure. VANET is susceptible to various types of attacks such as Denial of Ser-

vice (DoS) because it is still on the development phase, increasing security for this technology will guarantee

the implementation on actual conditions. Various attacks that occurs will be classiﬁed and determined which

ones gives the heaviest impact and disrupt the performance of VANET. The use of VANET technology will

help to create trafﬁc that are able to improve the security and comforting users on the road. Thus, applied the

Intelligent Transport System (ITS) can ensuring a friendly environment for safety trafﬁc.

1 INTRODUCTION

Vehicular Ad hoc Network (VANET) is a develop-

ment of Mobile Ad Hoc Network (MANET), VANET

is a combination of vehicles equipped with wireless

devices. Communication occurs on the highway be-

tween vehicles with other vehicles, vehicles with in-

frastructure, namely the Road Side Unit (RSU). Com-

munication between vehicles and RSU is referred to

as the Intelligent Transport System (ITS). The aim of

VANET is to help people avoid vehicle accidents, ac-

cording to the US Department of Transportation (US-

DOT). ITS is intended to describe how vehicles can be

connected to overcome some problems such as safety

and the environment.

VANET has several possible attacks, Sybil at-

tacks, timing attacks, replay attacks, routing attacks,

DOS attacks are a few examples. This can be seen

from the motives of the perpetrators, as well as the

use of security holes in accordance with the security

requirements that are targeted.

2 DATA COLLECTION

Literature process begins with ﬁnding reference pa-

per from several sources like IEEE and Scopus jounal

database. Filtering selection of the paper that will be

reviewed in this study based on the date the paper was

published (range of years: from 2010-2018) and the

quality of journal based on the number of citations.

The data used in this review related to the technology,

and research journals on computer science and engi-

neering, IEEE Review in Engineering.

Keywords that are being used to ﬁnd an appropri-

ate paper such as ”Autonomous Vehicles”, “VANET”,

and ”DOS Attack”. The main focus in the analysis

of a paper is in the parts of the method and discus-

sion. The obtained information from the sources pa-

per then recorded and will present on discussion and

ﬁnding part. We will discuss the objectives and meth-

ods that being used on each paper. In total, there are

11 reference paper related with attack on VANET that

obtained by ﬁltering process.

3 RESULTS

3.1 VANET Architecture

The architecture of VANET consists of: On Board

Unit (OBU), Application Unit (AU) which is part of

the OBU, RSU and network access.

a. On Board Unit (OBU): in the form of a Global Po-

sitioning System (GPS) module, wireless commu-

nication module, Central Control Module (CCM),

and user interface. CCM acts as a serial port pro-

cessor, memory, and transceiver data. Supporting

Dedicated Short range Communication (DSRC)

Fauzan, M., Sulistyo, S. and Mustika, I.

Review of VANET (Vehicular Ad Hoc Network) and Countermeasure against DoS Attack.

DOI: 10.5220/0009865901270132

In Proceedings of the International Conference on Creative Economics, Tourism and Information Management (ICCETIM 2019) - Creativity and Innovation Developments for Global

Competitiveness and Sustainability, pages 127-132

ISBN: 978-989-758-451-0

127

Figure 1: Literature process.

is also a function of OBU. DSRC regulates the

sender of security and status between vehicles

within a certain range (Kumar et al., 2017).

b. Application Unit (AU): additional components in

the OBU to facilitate communication using the

program, in the form of a physical component

connected to the OBU. AU only deals with net-

works through OBU and performs tasks related to

safety applications related to vehicle mobility and

network functions (Krishna, 2017).

c. Road Side Unit (RSU): network support devices,

usually physical and permanent, are placed at

the end of the road or around the intersection,

supporting devices that are equated with trafﬁc

lights, serve to increase signal coverage and inter-

OBU data distribution and communication be-

tween RSU to reach OBU in the other region (Ku-

mar et al., 2017).

Figure 2: VANET architecture

3.2 Security Requirements and

Potential Attack

Authentication, ensuring that messages sent by vehi-

cles are authentic and genuine, those messages com-

ing from clients that have been recognized and regis-

tered on the network are used to prevent the spread

of messages that are not authentic and aim to dis-

rupt the network and affect user safety. Integrity, the

message sent is not changed by the sender to the re-

cipient. Non- repudiation, the transmission of mes-

sages that have been sent cannot be denied by the

sender. Availability, the system must always be avail-

able and accessible under any circumstances. Conﬁ-

dentiality, guarantees that message transmission can

only be accessed by users who have been authenti-

cated and closely related to user privacy, if it comes

from another user who is not authenticated then the

message can be ignored (Sumra et al., 2011)(Luck-

shetty et al., 2016).

Some examples of threat attacks that can occur in

accordance with security requirements:

Table 1: Security Requirements and Potential Attack

Security Require-

ments

Potential Attack

Availability DoS, DDoS, black

hole, spamming mal-

ware

Conﬁdentiality Timing attack, home

attack, man-in-the-

middle attack, trafﬁc

Analysis, brute

force attack, bogus

information, ID

closure

Authentication and

Integrity

Node impersonation,

replay attack, tun-

neling, GPS spoof-

ing, message sup-

pression, sybil attack

3.3 Type of Attacker

Determining the attacker’s motives for carrying out

attacks on VANET is difﬁcult because it is unpre-

dictable. In order to prevent and help anticipate this,

the motives and reasons for the attackers are grouped

into several types.

Some of these types are insider, active, extended,

and malicious, independent, dependent, outsider, pas-

sive, local, and rational, intentional, and uninten-

tional. This is done to better understand the habits

ICCETIM 2019 - International Conference on Creative Economics, Tourism Information Management

128

of attackers so that attacks can be more easily antici-

pated. These types are also used as markers and pri-

ority giving (Sumra et al., 2013).

a. Insider & Outsider: Insider is a network user who

has been authenticated and has access to the net-

work. Outsiders are individuals or groups of at-

tackers whose capacity to attack is limited.

b. Malicious & rational: malicious is an attacker

type that only has the motive to damage and dis-

rupt the functions of network services. Nationally,

attackers who have a goal to gain proﬁts, in prac-

tice, are more predictable.

c. Active & Passive: active attacks with the aim of

changing content, signals, and packages. Passive

attacks that aim to analyze information on the net-

work.

d. Independent: the attacker has an independent na-

ture of the network, so it does not depend on other

things in the attack process.

e. Intentional: is the personal purpose of an attacker

who intentionally interferes with the work of the

network in order to create problems for the user

when accessing the network.

f. Dependent: is a group of attackers that are inter-

dependent with one another intentionally carrying

out speciﬁc attacks. Coordinate in groups when

carrying out attacks.

g. Unintentional: accidentally involved in network

damage that occurs and causes various network

problems to users. Usually occurs in the process

of operation and transmission on the network.

(Malla and Sahu, 2013) the types of attacks that

can be carried out are grouped into ﬁve attack classes.

This types of attack determine which one gives most

impact based on their classes.

3.3.1 1st Class Network Attack

Directly affects communication whether the media is

used such as infrastructure or other vehicles, some ex-

amples of attacks are as follows :

a. Denial of Service (DOS Attack)

Attacks carried out on communication media

cause interference to the node in accessing the

network. Blocking nodes (vehicles) that have au-

thentication to access network services, as well

as infrastructure in the form of RSU (as access

points). There are three level of DoS Attack the

attacker use to disrupt communication (Pathre,

2013)(Rampaul et al., 2016):

(1) Overwhelm the node resources

This level attacker focuses on nodes to disrupt

communication, to overwhelm the resources

so nodes become busy, by sending unique

messages continuously so they are not able to

do their job in verifying messages to be sent or

received. Make the victim unable to access the

network.

In other cases the attacker attacks the RSU,

causing a busy condition when verifying the

message from the attacker so that other nodes

will not be able to get reply from the RSU,

resulting in the service becoming unavailable.

Figure 3: Overwhelm the resources node and infrastructure.

(2) Jamming the channel

At this level the attack is carried out by di-

rectly jamming the channel, make the users

unable to access the network. The attacker

sends frequencies to a particular domain, so

that the domain and its surroundings cannot ac-

cess the network, users can re-use the service

when leaving the domain.

In other cases the attacker attacks using certain

frequencies to jam the infrastructure. At this

stage sending and receiving messages from and

or to other nodes is not possible because it make

the network inacessible.

(3) Distributed Denial of Service (DDoS)

Execute DoS attacks from various locations.

The attack will take place at different times, the

attacker’s habits will be different for each ob-

ject of attack (vehicle). The purpose of an at-

tack is the same as DoS, but it is done at dif-

ferent locations and times on the same target.

The attack can also be done on V2I Communi-

cation.

b. Node Impersonation

On VANET each vehicle has its own unique

identity that is used to verify the message sent,

in a critical case such as an accident the message

sent will be crucial make this unique identity is

needed so that the wrong message is not sent

Review of VANET (Vehicular Ad Hoc Network) and Countermeasure against DoS Attack

129

to other users. This attack aims to change the

message from the original node by modifying the

attacker’s identity and when received by other

users it remains detected as a message from the

original sender.

Figure 4: Node impersonation

c. Sybil Attack

This type of attack manipulates the attacker’s

vehicle, creating the identity of the attacker’s

vehicle to have the same identity as the others,

each vehicle seeing the attacker at a different

location at the same time. In Figure 5 Vehicle

A duplicates its identity so that it is detected to

ﬁll the road. The main goal of an attacker is

the ability to control the direction of the other

vehicle’s (Pathre, 2013).

Figure 5: Sybil attack

3.3.2 2nd class Application Attack

The attacker’s main motive for this attack is to change

the content on the application (safety and non-safety)

that is used for its own purposes. Types of safety ap-

plications such as warning information on the road,

the attacker will change the warning content into false

info that can result in an accident.

Figure 6: Safety application attack

In non-safety applications the information pro-

vided is in the form of conditions outside the trafﬁc

so that if changed it will not cause dangerous condi-

tions.

3.3.3 3rd Class Timing Attack

Gives delay to the message / information sent, so the

message will be late until it enters the expiration time.

Figure 7: Non-safety application attack

The ﬁrst information (1) is conveyed to the closest

vehicle that is to the attacker’s vehicle, then because

the information was not delivered on time there was

a second accident (2) involving the vehicle behind it.

In the safety application, time is the most crucial thing

because the message must be received directly at that

time if not the main function of the application will

be lost.

Figure 8: Timing attack

3.3.4 4th Class Social Attack

An attack intended to inﬂuence the emotions of the

user. Through the messages aiming to generate angry

behavior from the user when the message is received

by the user.

3.3.5 5th Class Monitoring Attack

The attacker will monitor the communication that oc-

curs on V2I and V2V, when the information needed

has been obtained it will be channeled to the other at-

tackers who need it.

3.4 Solution to Prevent Attack

In its application there are several models to prevent

certain types of attacks that can occur on the VANET.

(Hasbullah et al., 2010). This ﬁrst model relies on

the OBU’s ability in each vehicle to make a decision

to block DoS attacks, in its application the process-

ing unit is able to recommend OBU to select antici-

pation, according to the type of attack OBU has 4 op-

tions that can be done; Channel switching, Technol-

ogy switching, Frequency hopping spread spectrum

(FHSS), Multiple Radio Transceiver. New informa-

tion can be received and forwarded to users by OBU

after going through the process and selecting the most

appropriate technology.

ICCETIM 2019 - International Conference on Creative Economics, Tourism Information Management

130

Figure 9: Model of OBU features

(VIPIN and Chhillar, 2018). The Group Con-

trolled Analysis Model is analyzing the types of nodes

that are dangerous and harmless based on several pa-

rameters compared namely the direction, position,

and speed of the vehicle. As shown on Table 2 is the

result of the model.

Table 2: Result of the method

Measure Per-

formance

Existing

Technique

Proposed

Model

Throughput 517.48 743.47

PDR 83.16 87.27

Communication

Loss

4.87 0.83

The results of the analysis of these parameters de-

tect communication carried out by nodes that do no

harm to produce communication that does not affect

delay, response time, and communication loss. It is an

observation of communication problems at an early

stage. Being able to ensure communication occurs

more effectively to the small scope of the vehicle, in

blocking the occurrence of DDoS attacks.

(Kolandaisamy et al., 2018). Multivariant Stream

Analysis, MVSA consists of several stages in detect-

ing DDoS attacks on the network. There are 3 algo-

rithms used in detecting the attack of the ﬁrst algo-

rithm for classiﬁcation, the second algorithm is a set

of rules generated from calculations, algorithm 3 will

give the ﬁnal result.

a. Preprocessing Stage

Begin the classiﬁcation phase of safety and non-

safety applications in trafﬁc by collecting logs on

packages containing information.

b. Multivariant Stream Weight Stage

The algorithm is used at this stage to calculate

weights to detect DDoS attacks.

MASV =

Ap f

Ahc

Attl

(1)

The payload value (Ap), is the value of bandwidth

that is affected by the frequency of the package

(Apf). hop count (Ahc) depends on TTL (Attl).

As shown in equations (1).

Masw = Σ

MASV

(2)

Time divided by number of time windows (24) as

per hour count into one time window assume this

calculation to detect in one day make it 24 time

windows. As shown in equations (2).

c. DDoS Mitigation Stage

It is the ﬁnal stage of the MVSA method, doing

a trace on the ﬁrst node then preprocessing it in

the log, the preprocessing stage generates a rule /

standard and produces a value / weight that will

be used to detect the problematic packet. Using

algorithm 3, the detection results from the pack-

age will be known.

MASM =

Dist(Ri.Pl, P.Pl)

ΣpacketrecievedinTix

Dist(Ri.hc,P.hc)

P.ttl

(3)

The value calculated for the package received

must be of a certain size (σ) at a certain time win-

dow (Ti). The algorithm must calculate the dis-

tance (Dist) between the rules and features (Ri)

extracted for the packet received. The value calcu-

lated for the package received must be of a certain

size (σ) at a certain time window (Ti). The algo-

rithm must calculate the distance (Dist) between

the rules and features (Ri) extracted for the packet

received. As shown in equation (3).

IFMASM < MASW&&MASM <> Ri.Features

(4)

Comparison between MASM and (MASW and

MASM) is the end result in computational algo-

rithms to detect DDoS attacks.

After observing the communication in trafﬁc

against various different situations such as net-

work trace, payload, the amount of data generated

by the packet, then hop count (a number of mes-

sages from the node that must be sent to reach the

destination), time to live (duration of data trans-

mission on the network). Four (4) features are

calculated to produce a rule and weight which can

classify an authentic or dangerous a package is.

The result show that MVSA outperform the other

3 methods (H-IDS, Multi Filter, Trilateral trust) in

term of throughput, detection accuracy, detection

time, delivery ratio, packet delay, packet drop ra-

tio. Figure 11 shows result on delivery ratio.

Review of VANET (Vehicular Ad Hoc Network) and Countermeasure against DoS Attack

131

Figure 10: Delivery ratio

4 CONCLUSIONS

From the research that has been done, it can be con-

cluded that based on the security requirements and

types of attacks that can occur in vanet, network avail-

ability is the ﬁrst and most important thing because it

is related to network services, if not available, users

will lose the beneﬁts of safety and non-safety appli-

cations.

In order to be used properly, network services

must be available at all times, but attacks on DoS

that are carried out can result in availability being dis-

rupted. This attack is categorized as the ﬁrst class be-

cause it diverts services from the start and prevents

sending information between nodes and infrastruc-

ture.

In this paper, we describe the vanet architecture,

attack type, type of attack, several methods and mod-

els to cancel and reduce the risk of attacks, not only

DoS also includes DDoS. The most important thing

is to maintain availability on the network, messages

generated by VANET services must be guaranteed

and provide beneﬁts to users.

REFERENCES

Hasbullah, H., Soomro, I. A., et al. (2010). Denial of ser-

vice (dos) attack and its possible solutions in vanet.

International Journal of Electronics and Communica-

tion Engineering, 4(5):813–817.

Kolandaisamy, R., Md Noor, R., Ahmedy, I., Ahmad, I.,

Reza Z’aba, M., Imran, M., and Alnuem, M. (2018).

A multivariant stream analysis approach to detect

and mitigate ddos attacks in vehicular ad hoc net-

works. Wireless Communications and Mobile Com-

puting, 2018.

Krishna, B. H. (2017). Study of ad hoc network with ref-

erence to manet vanet fanet. International Journal

of Advanced Research in Computer Science and Soft-

ware Engineering, 7(7):390–394.

Kumar, A., Bansal, M., et al. (2017). A review on vanet se-

curity attacks and their countermeasure. In 2017 4th

International Conference on Signal Processing, Com-

puting and Control (ISPCC), pages 580–585. IEEE.

Luckshetty, A., Dontal, S., Tangade, S., and Manvi, S. S.

(2016). A survey: comparative study of applications,

attacks, security and privacy in vanets. In 2016 In-

ternational Conference on Communication and Signal

Processing (ICCSP), pages 1594–1598. IEEE.

Malla, A. M. and Sahu, R. K. (2013). Security attacks with

an effective solution for dos attacks in vanet. Interna-

tional Journal of Computer Applications, 66(22).

Pathre, A. (2013). Identiﬁcation of malicious vehicle in

vanet environment from ddos attack. Journal of

Global Research in Computer Science, 4(6):30–34.

Rampaul, D., Patial, R. K., and Kumar, D. (2016). Detec-

tion of dos attack in vanets. Indian Journal of Science

and Technology, 9(47).

Sumra, I. A., Ahmad, I., Hasbullah, H., et al. (2011). Be-

havior of attacker and some new possible attacks in

vehicular ad hoc network (vanet). In 2011 3rd Inter-

national Congress on Ultra Modern Telecommunica-

tions and Control Systems and Workshops (ICUMT),

pages 1–8. IEEE.

Sumra, I. A., Hasbullah, H. B., Ahmad, I., Alghazzawi,

D. M., et al. (2013). Classiﬁcation of attacks in ve-

hicular ad hoc network (vanet). International Infor-

mation Institute (Tokyo). Information, 16(5):2995.

VIPIN, D. and Chhillar, R. S. (2018). The ddos attack de-

tection and prevention in vanet by group controlled

analysis model.

ICCETIM 2019 - International Conference on Creative Economics, Tourism Information Management

132
