HoT: Unleash Web Views with Higher-order Templates

Fernando Miguel Carvalho

and Luis Duarte

ADEETC, ISEL, Polytechnic Institute of Lisbon, Portugal

Keywords: Template View, Big Data, Front-end, Web Application, HTML.

Abstract:

Over the past decades, templates views have been the most used approach to build dynamic HTML pages.

Simply put, a template engine (such as JSP, Handlebars, Thymleaf, and others) generates HTML by merging

templates with given data models. Yet, this process may turn impractical for large data sets that postpone the

HTML resolution until all data become available to the engine. This behavior results in poor user experience

preventing the browser to render the end user-interface. In this paper we introduced the concept of higher-

order templates (HoT) provided in Java implementation of HtmlFlow, which allows HTML to be resolved on

demand as data becomes available. This lets the user-interface to be rendered incrementally by the browser in

line with the availability of the data. Finally we also show some advantages of HtmlFlow over state of the art

front-end frameworks such as ReactJS.

1 INTRODUCTION

Contrary to static HTML pages, which do not change

from request to request, dynamic Web pages may take

results from a data source, like database or web ser-

vice, and embed them into the HTML. Dynamic Web

pages share a similar structure to static HTML but

they also include markers that can be resolved into

calls to gather dynamic information. Since the static

part of the page acts as a template, this pattern is

known as template view (Fowler, 2002) or template-

based view strategy (Alur et al., 2001). When the tem-

plate view is used to service a request, the markers

are replaced by the results of corresponding computa-

tions. The parsing and replacement process (i.e. res-

olution) is the main role of the template engine (Parr,

2004).

Template engines distinguish themselves by the

idiom and subset of available markers to control the

dynamic content. Generally, all engines provide a

specialized tag for iteration, which can be used for

example to generate a dynamic list such that one pre-

sented in Listing 1 expressed in the Handlebars id-

iom (an extension to the Mustache templating lan-

guage (Lerner, 2011)).

In this example, the template receives a context

object with a tracks property and generates a li

element with the track’s name for each item in the

tracks list. The process of resolving the template

https://orcid.org/0000-0002-4281-3195

and producing HTML is blocking and it only ﬁnishes

when all template markers have been replaced with

data from the context object. In the case of an itera-

tion tag (i.e. #each of Listing 1) it must traverse the

entire list (i.e. tracks) to complete the template reso-

lution. The larger the data (i.e. tracks.size()), the

longer the engine takes to ﬁnish the resolution. While

the engine is resolving the view, the browser is pre-

senting a blank page to the end user giving him an

unresponsive behavior.

Listing 1: Handlebars template view for a dynamic un-

ordered list.

<ul>

</ul>

Visualization is one of the major concerns in big

data (Agrawal et al., 2015; Storey and Song, 2017).

Also, people tend to prefer web based applications

as their favorite visualization support for data anal-

ysis (Yaqoob et al., 2016). Yet, even using data re-

duction strategies (Liu et al., 2013; ur Rehman et al.,

2016) the resulting data sets are large enough to make

unfeasible the use of template views. This problem

arises in both, server-side or client-side (i.e. front-

end) web application development. In the former

case, the view resolution process prevents the server

to send the response and in the latter, the number of

DOM nodes (Hors et al., 2004) increases with the size

118

Carvalho, F. and Duarte, L.

HoT: Unleash Web Views with Higher-order Templates.

DOI: 10.5220/0008167701180129

In Proceedings of the 15th International Conference on Web Information Systems and Technologies (WEBIST 2019), pages 118-129

ISBN: 978-989-758-386-5

of dynamic data, incurring in additional performance

overhead for the browser. For these reasons tradi-

tional ways of presenting data in web applications is

inadequate to handle big data (Agrawal et al., 2015).

In this work, we propose a new approach based on

higher-order templates (HoT), which aims to achieve

a similar methodology to the server side template

view pattern, but useful even on the presence of big

data. Brieﬂy, our goal is to establish data-centric

push-style approach (Jin et al., 2015) and push the

resulting HTML to the response stream as its content

is being resolved. Rather than pulling data from a

source and fully complete markers of a template view,

we propose to react to data and push the resulting

HTML as it is being resolved. This follows the idea

of (Meijer, 2012) that states that the Velocity axis of

big data ranges from pulling data from the source to

pushing data to the clients.

This solution is implemented in HtmlFlow Java

library, which implements a domain speciﬁc lan-

guage (DSL (Mernik et al., 2005)) for HTML. Brieﬂy,

HtmlFlow implementation is based on the following

key ideas:

1. do not block the template resolution until its com-

pletion (Meijer, 2012);

2. discard textual template ﬁles;

3. use HTTP chunked transfer encoding (Fielding

and Reschke, 2014);

4. deﬁne views as ﬁrst-class functions.

For the remainder of this paper we present in the

next section state of the art solutions that deal with

web presentation of large data sets. Then in Sec-

tion 3 we present our proposal of higher-order tem-

plates. After that in Section 4, we present the Java

library HtmlFlow, which provides a domain-speciﬁc

language for HTML. In Section 5, we discuss re-

lated work in the HtmlFlow ﬁeld. In Section 6, we

present an experimental evaluation of developing a

web application–topgenius.eu

–that presents the top

tracks ranking for a given country. This application

uses data from Last.fm RESTful API and dynamically

builds a list with hundreds of thousands of records.

Here we compare three different technological ap-

proaches: 1) server-side template view, 2) ReactJS

and 3) HtmlFlow. Finally, in Section 7 we conclude

and discuss some future work.

Source code is available at github.com/xmlet/topgenius

2 STATE OF THE ART

Dealing with large data sets on web applications usu-

ally leads the browser to present an unresponsive be-

havior due to the template view resolution process.

One way of dealing with this problem is to reduce big

data into manageable size (Feldman et al., 2013). Yet,

even using reduction techniques the resulting subset

may still be large enough to turn impractical the use

of a template engine.

Web applications usually mitigate this problem

with two possible solutions (but not limited to): 1)

numbered pagination, 2) inﬁnite scrolling. Numbered

pagination was one of the ﬁrst solutions adopted to

deal with the web presentation of big data, such as

the results retrieved by web search engines. Later the

MSN search’s image search was the ﬁrst one to in-

troduce the inﬁnite scrolling technique with a single

page of results, which you can scroll to automatically

load more images (Farago et al., 2007). Both options

reduce latency and turn the browser responsive, but

both also have some drawbacks.

Numbered pagination forbids, for example, the

end user to use the browser to ﬁnd something among

all resulting pages. On the other hand, inﬁnite

scrolling uses AJAX to fetch data (Kesteren et al.,

2006) and DOM (Hors et al., 2004) to update the

user-interface as data results become available. This

approach is usually known as front-end web develop-

ment (Smith, 2012). But, manipulating large collec-

tions of DOM nodes is slow and increases browser

processing overhead. Moreover we lose the overall

structure of the template view that now is mixed in

with DOM manipulation logic.

Regarding the example of Listing 1 and its use

with a front-end technology, then the template would

be only the ul element with a unique identiﬁer (e.g.

listOfTracks) such as:

In turn, the li elements would be manipulated

programmatically through DOM.

Keeping a view deﬁnition with whole HTML

structure similar to a template was one of the moti-

vations for the appearance of front-end frameworks,

such as Angular or ReactJs. This kind of frameworks

allow the deﬁnition of a view based on a context ob-

ject that is latter bound to the view by the framework

through DOM.

Yet, these frameworks do not solve the perfor-

mance issues and do not let end users to get page

source code in an inﬁnite scroll scenario. For example

in ReactJs, the page source of resulting HTML will

HoT: Unleash Web Views with Higher-order Templates

119

only display <div id="root"></div> correspond-

ing to the div element where the framework places

HTML elements from DOM manipulation.

Brieﬂy, web front-end development approaches

circumscribe the server-side templates problems by

moving the HTML resolution from the server to web

agents (i.e. browser). This let the browser to update

the user-interface as data becomes available. Yet, this

approach also have the following drawbacks:

1. proliferation of the web development heterogene-

ity, which adds the use of DOM and AJAX;

2. loose the chance of getting the page source of the

resulting HTML;

3. the number of DOM nodes are proportional to the

size of dynamic data and big data sets may kill the

browser performance.

3 HoT: HIGHER-ORDER

TEMPLATES

A higher-order template (HoT) is an advanced tech-

nique for resolving a template view progressively as

data from its context object is being available, rather

than waiting for whole data and resolve the entire

template. A higher-order template (HoT) deﬁnes a

template view as a function and its context object as

other function received by argument. Also, a higher-

order template can receive other templates as param-

eters. In this case, these parameters play the role of

partial views. Like a higher-order function may take

one or more functions as arguments, a higher-order

template may take one or more templates views as ar-

guments. This compositional nature enables reusing

template logic.

Templates in HtmlFlow are speciﬁed through Java

functions, which can be deﬁned as named or anony-

mous functions (i.e. lambdas) For example, the tem-

plate of Listing 1 can be expressed in HtmlFlow with

the tracksTpl function of Listing 2.

Listing 2: HtmlFlow template function for a division ele-

ment with a dynamic unordered list.

HtmlTemplate < S t rea m < Trac k >> tr a ck sT pl =

( vie w , t r a c k s ) -> vi ew

. d i v ()

. ul ()

. of ( ul -> tr a c k s . f o r Ea c h ( item - > ul

. li (). text ( i t e m . get N a m e ()). __ () // li

))

. __ () // ul

. __ (); // div

The tracksTpl function receives two parameters:

an HtmlFlow view and a context object (e.g. tracks).

The view parameter provides the HTML ﬂuent in-

terface (Fowler, 2010) with methods corresponding

to the name of HTML elements and an additional

() method to close an HTML element tag. The

tracks parameter acts like the model in the model-

view-controller pattern (E. Krasner and Pope, 1988).

Here the tracks is a Java Stream, which is an ab-

straction over a lazy sequence of objects (i.e. in-

stances of Track). In this case, the tracks ob-

ject is traversed in the forEach method call (i.e.

tracks.forEach(...)) chained within the template

deﬁnition.

Also, an HtmlFlow template can receive other

templates as parameters. In this case, these param-

eters play the role of partial views. Regarding a tem-

plate view with partials then the corresponding func-

tion should receive a further argument for each partial

view. For example, considering that the tracksTpl

function takes an additional footer argument, then

it can include this partial view through the method

addPartial. We can chain the call to addPartial

in the template deﬁnition as depicted in the example

of the Listing 3, that adds the footer after the deﬁni-

tion of the unordered list.

Listing 3: HtmlFlow template with a partial view footer.

HtmlTemplate < S t rea m < Trac k >> tr a ck sT pl =

(v , trks , f o o t e r ) -> v

. d i v ()

.. . // adds ul and an li for each track

. of ( d iv -> div . addP a r t i al ( footer ));

. __ () // div

If a partial view has no context object and does

not require model binding, then we can discard the

template function and directly create that view from

an expression, through the view() factory method of

the class StaticHtml. For example, we may deﬁne

a billboard division (i.e. bbView) as depicted in the

following view deﬁnition:

HtmlView bbView = StaticHtml

.view().div().text("Dummy billboard"). ();

Another advantage of using views as ﬁrst-class

functions is to allow views composition. For exam-

ple, if want to deﬁne a partial view (e.g. footerView)

with a placeholder for another partial view (e.g.

banner), then we may deﬁne a footerView method

that takes an HtmlView as the banner parameter and

returns a new HtmlView as depicted in Listing 4.

WEBIST 2019 - 15th International Conference on Web Information Systems and Technologies

120

Listing 4: Partial view deﬁnition of a footer that takes an-

other banner view as parameter.

HtmlV i e w foo t e r V i ew ( Html V i e w b an n e r ) {

return Stat i c H t m l . vi e w ()

. d i v ()

. of ( d iv -> div . addP a r t i al ( banner ))

.p () . te x t ( " C r e a t ed wi t h H t m Fl o w " ). __ () // p

. __ (); // div

}

Thus, we may ﬁnally compose the tracksTpl

template of Listing 3 with the footerView, which

in turn will be ﬁlled with the bbView. This creates

the following pipeline: tracksTpl <- footerView <-

bbView.

Given the tracksTpl function we may create the

corresponding view (i.e. tracksView) through the

view() factory method of the class DynamicHtml

as depicted in line 2 of Listing 5. Finally, we may

compose all the parts of the tracksView through

the render method of HtmlView. For example,

given a tracks stream, the footerView and the

bbView we may resolve the tracksView as de-

picted in line 3 of Listing 5. Here we can observe

the pipeline: tracksView <- footerView <- bbView,

where tracksView takes the footerView as argu-

ment, which in turn receives the bbView as argument.

Listing 5: Composing and resolving the tracksView.

St ream < Trac k > tracks = ...

va r t r a cksVi e w = Dy na micH t m l . v i ew ( tra c k s T p l );

String htm l = tr a ck sView

. render ( t r ack s , fo o terVi e w ( b b V i e w )) ;

Having all the compositional parts of a template

view deﬁned as ﬁrst-class functions (the template it-

self, the context object and partial views) is a key fea-

ture to achieve the HtmlFlow compositional nature.

4 HtmlFlow

HtmlFlow is a Java library DSL for HTML. HtmlFlow

is type-safe and conforms with HTML 5 schema. In

the following subsection we present the HtmlFlow de-

sign and its core types. After that, we distinguish be-

tween the pull and push output approaches provided

by HtmlFlow. Finally in subsection 4.3 we show some

implementation details of HtmlFlow.

4.1 Design

In addition to the HTML ﬂuent interface, the

HtmlView class encapsulates the logic of what

to do on each HTML element visit. To that

end, the HtmlView delegates to an implementa-

tion of the ElementVisitor interface, the re-

sponsibility of deﬁning what to do on each in-

vocation to the HtmlFlow ﬂuent interface (e.g.

.div(), .ul(), etc). This feature enables the

integration with different kind of visitors such

as collecting the resulting HTML into a string

buffer (i.e. HtmlVisitorStringBuilder) or

emitting the HTML to an output stream (i.e.

HtmlVisitorPrintStream), as depicted in the class

diagram of Figure 1. Note that every HTML element

is an implementation of the Element interface and

also the HtmlView itself.

Figure 1: Class diagram of HtmlFlow core types.

In turn, the type HtmlView has two different sub-

types: StaticHtml and DynamicHtml. The former

does not support model binding and can be useful to

deﬁne and reuse partial views in different kinds of

template views (e.g. footerView and bbView). The

latter is intended for templates with a context object

that require model binding on their resolution.

Thus a DynamicHtml view depends of an imple-

mentation of the HtmlTemplate, such as the lambda:

(view, tracks, footer) -> ... of the Listing 3.

This lambda is conforming the following deﬁnition of

the interface HtmlTemplate:

public interface Html Te mp la te <T > {

void reso lv e (

Htm lVi ew <T > view ,

T mo del ,

Htm lVi ew <T >.. . p art ia ls );

}

Note that both view and partials are of type

HtmlView allowing the composition between any

kind of views.

4.2 Output Approaches

HtmlFlow provides two ways of resolving a view:

pull or push approach. In the pull approach we get the

resulting HTML from the render() method call, as

shown in line 3 of the example of Listing 5 and then

we may proceed to do whatever we want with that

HoT: Unleash Web Views with Higher-order Templates

121

HTML. On the other hand, with the push approach,

we set the HtmlFlow with a PrintStream and let

the resolution process push the resulting HTML to

that stream. The equivalent push resolution of the

tracksView of Listing 5 would be:

tr ack sV i ew

. se t Pr i nt S tr e am (...)

. w ri te ( tracks , f oo ter Vi e w ( b bV ie w )) ;

According to the requirements stated in Section 1

of a web application, we want to push the resulting

HTML to the output stream as the template view is

being resolved. To that end we should use a visitor

that writes the resulting HTML to the HTTP response

stream. This allows the HTML to be sent to the end-

user agent (e.g. browser) as tracks are being iter-

ated through the forEach loop. HtmlFlow does not

need to wait for tracksTpl completion to start send-

ing the HTML. As HTML elements are visited the

HTML is generated and emitted immediately to the

output channel allowing the browser to progressively

render the user-interface.

For a web application purpose we should wrap

the HTTP response stream into a PrintStream

object and assign it to the HtmlView. In Listing 6 we

show the usage of a HttpResponsePrinter object

that wraps an instance of HttpServerResponse

representing an HTTP response in a VertX

web application (Fox, 2001). First we take

the HttpServerResponse object from the

RoutingContext and set the content-type as

text/html (lines 2 and 3). After that, we set the

output stream of the view (line 5) and then we pass

to it the model object (line 6) that will be internally

bound to the template. Finally, we close the HTTP

response stream (line 7).

Listing 6: Setting an HtmlView to the HTTP response

stream.

<T > void h a n d l e r (

Ro u t i n gCo n t e x t ctx ,

Ht m l View < T > vie w ,

T model )

{

Ht t p S erv e r R esp o n se resp = ct x . re s p o n s e ();

re s p . p u t H e ad er (" co n tent - type " , " tex t / html " );

vi e w

. se t P r int S t r e am (new H t t pRe s p ons e P r int e r ( r e sp ))

. wr i t e ( m o del );

re s p . en d () ;

}

The handler method of Listing 6 can be used

to send the result of tracksView resolution to the

HTTP response stream. Every time the tracksView

resolution emits HTML to its PrintStream, the

Listing 7: A naif implementation of PrintStream that for-

wards data to a HttpServerResponse.

class Ht t pRe s po n seP r in t er

extends Pr in t St r ea m

{

final Ht t pS e r ve r Re s pon s e r esp ;

public Ht t pRe s po n seP r in t er (.. . re sp ) {

super(new Ou tpu tS t re a m () {

@O ve r ri de

public void wr it e (int b ) {

char c = (char) b ;

res p . writ e ( S tr in g . v al ueOf ( c ));

}

});

this. resp = r esp ;

}

HttpResponsePrinter may push that data to the

HTTP response stream. In Listing 7 we show a naif

implementation of the HttpResponsePrinter that

writes every received byte immediately to the HTTP

response stream.

A more effective approach may buffer those bytes

into an internal buffer and ﬂush that buffer to the out-

put stream only when a certain threshold is achieved.

4.3 HtmlFlow Internals

There is a primary goal in the HtmlFlow design:

the HTML ﬂuent interface should be easily naviga-

ble. This is crucial to provide a good user experi-

ence while creating templates through the HtmlFlow

API. There are two main aspects, the ﬂuent interface

should be easily navigable and always implement the

concrete language restrictions. We tackle this issue

through the use of type parameters, which allow us

to keep track of the tree structure of the elements that

are being created and keep adding elements, or mov-

ing up in the tree structure without loosing the type

information of the parent. In Listing 8 we can observe

how we can take advantage of the type arguments.

Listing 8: Explicit use of type arguments in the subtypes of

Element.

Html < Element > ht ml = new Html < >();

Body < Html < El eme nt > > bo dy = html . bo dy ();

P < H eader < Body < Html < El eme nt > >>> p1 =

bod y . h ea de r (). p ( );

P < Div < Body < Html < E leme nt > > >> p2 =

bod y . div (). p ();

Header < Body < Html < E leme nt > > > hea de r =

p1 . __ () ;

Div < Body < Html < El emen t >>> div = p2 . __ ();

When we create the Html element we should in-

dicate that it has a parent, for consistency. Then, as

WEBIST 2019 - 15th International Conference on Web Information Systems and Technologies

122

Listing 9: Example of the implicit use of type arguments in

HtmlFlow API.

Html < Element > ht ml = new Html < >()

. b ody ()

. h ea de r ()

.p (). __ ()

. __ () // header

. di v ()

.p (). __ ();

. __ () // div

. __ (); // body

we add elements, such as Body, we automatically re-

turn the recently created Body element, but with par-

ent information that indicates that this Body instance

is descendant of an Html element. After that, we cre-

ate two distinct P elements, p1, which has an Header

parent, and p2, which has a Div parent. This informa-

tion is reﬂected in the type of both variables. Lastly,

we can invoke the () method,which returns the cur-

rent element parent, and observe that each P instance

returns its respective parent object, with the correct

type.

In the example presented in Listing 8 the usage of

the ﬂuent interface might seem to be excessive ver-

bose to deﬁne a simple HTML document. Yet, for

most common purposes we can suppress the auxil-

iary variables and simplify its usage chaining method

calls as we show in Listing 9, which is an equivalent

deﬁnition to the previous template of Listing 8. The

type arguments are still important and inferred by the

methods chain usage to validate and provide the cor-

rect available API to the next element. Therefore, typ-

ing for example p().div() is disallowed because it

goes against the content allowed by a P element ac-

cording to HTML5.

All the implementations of the Element interface

corresponding to all kind of HTML elements avail-

able in HTML 5 are automatically built from the XSD

deﬁnition of the HTML 5. These implementations

are part of the HtmlApi auxiliary library used by the

HtmlFlow. The HtmlApi is built with the support of

ASM (Binder et al., 2007) a bytecode instrumentation

tool. Thus HtmlFlow depends of a build process or-

ganized in three different components that are part of

xmlet

framework depicted in Figure 2.

Each component of Figure 2 has the following

role:

1. XsdParser – parses all the external rules deﬁned

by the XSD document into a tree of objects.

2. XsdAsm – deals with the generation of bytecodes

that make up the types of the Java ﬂuent interface.

This project should translate as many rules of the

https://github.com/xmlet/

XsdParser

XsdAsm

HtmlApi

Objects Tree

Java Types

</>

XSD

HtmlFlow

Figure 2: xmlet framework build process and its organiza-

tion in three main components: XsdParser, XsdAsm and

HtmlApi.

parsed language deﬁnition, its XSD ﬁle, into the

Java language in order to make the resulting ﬂu-

ent interface as similar as possible to the language

deﬁnition.

3. HtmlApi – it is a concrete client of the XsdAsm

project, it will use the HTML5 language deﬁni-

tion ﬁle in order to request a strongly typed ﬂuent

interface, named HtmlApi. This is used by the

HtmlFlow library to manipulate the HTML lan-

guage and write well formed documents.

To support the foundations of the XSD language

there is a common infrastructure in every ﬂuent in-

terface generated by this project. This infrastruc-

ture is composed by the following main interfaces:

Element and Attribute, which are implemented

by every generated class for each xsd:element or

xsd:attribute deﬁned in the XSD.

This solution focus on how the code is organized

rather than making complex code. All the meth-

ods present in the generated classes have very low

complexity, mainly adding information to the ele-

ment children or to the attribute list. To reduce code

repetition we created many interfaces with default

methods implementations so that different classes

can extend them and reuse the code. The complex-

ity of the generated code is mostly present in the

AbstractElement class, which implements most of

the Element interface methods. Another very impor-

tant aspect of the generated classes is the extensive

use of type arguments, also known as generics, which

allows the navigation in the element tree while keep-

ing type information, which is essential to ensure the

speciﬁc language restrictions.

The client of the HtmlApi (i.e. HtmlFlow) is

responsible for establishing what to do on Htm-

lApi methods calls. To that end the HtmlApi fol-

lows the Visitor design pattern. Thus, on every el-

ement or attribute instantiation we directly invoke

the ElementVisitor visit method. Since the

ElementVisitor instance is shared by all elements

HoT: Unleash Web Views with Higher-order Templates

123

then we can invoke the visit method in the con-

structor of the classes generated based on a XSD

<xsd:element>. In Listing 10 we show a simpliﬁed

example of the generated Html class.

Listing 10: Html Class Generated by XsdAsm.

final class Html < Z extends Element > {

protected final Z p ar ent ;

protected final E l em e nt V is i to r vi si to r ;

public Ht ml ( Z par en t ) {

this. pare nt = pa re nt ;

this. v is it or = pa re nt . g et Vis it o r () ;

this. v is it or . v i si t El e me n tHt ml (this);

}

...

public Body <T > bo dy () {

return new Bo dy (this);

}

public Head <T > he ad () {

return new He ad (this);

}

Since adding elements results in the creation of

new objects, such as Body and Head, it results in the

invocation of their respective visit method due to the

visit method being called on each class constructor.

The attributes have a very similar behavior, although

they do not create instances on their methods invo-

cation. On the other hand, their restrictions are vali-

dated through the invocation of static validate meth-

ods present on each attribute class.

5 RELATED WORK

HtmlFlow distinguish from competition in three main

features: 1) composability provided by higher-order

templates (HoT), 2) HTML validation and 3) perfor-

mance. In this section we analyze these characteris-

tics and related work for each of these ﬁelds.

HTML view engines deal with data models as

their inputs to produce HTML as output (Fowler,

2002). Martin Fowler distinguishes between two pos-

sible approaches followed by view engines: 1) tem-

plate view and 2) transform view. The former is

HTML centric and thus oriented to the output. In this

case, the view is written in the structure of the HTML

document and embed markers to indicate where data

model properties need to go. Since the seminal tech-

nologies JSP, ASP and PHP appeared with the tem-

plate view pattern, many other alternatives emerged

along the last two decades

, turning this pattern into

wikipedia.org/Comparison of web template engines

one of the most used approaches in web applications

development.

On the other hand, the transform view is oriented

to the input and how each part of the input is directly

transformed into HTML. XSLT is maybe one of the

most well-known programming languages to specify

transformations around XML data. In this case the

XML data takes the place of the input that is trans-

formed by the XSLT to another format (e.g. HTML).

Also, the functional nature of the transform view pat-

tern enables its composition in a pipeline of transfor-

mations where each stage takes the result of the previ-

ous transformation as input and produces a new out-

put that is passed to the next transformation. For ex-

ample, the Cocoon Java library (?) provides a frame-

work for building pipelines of XML transformations

steps speciﬁed in XSLT.

The transform view pattern has similarities with

the higher-order templates approach of HtmlFlow

where a view is a ﬁrst-class function that takes an ob-

ject model as parameter and applies transformations

over its properties. The object model has the role of

the input (e.g. XML data) and the HTML domain-

speciﬁc language is the idiom used to transform the

model into HTML.

The j2html (Ase, 2015) is an alternative Java DSL

for HTML. The major handicap of j2html in com-

parison to HtmlFlow is the lack of validation of the

HTML language rules either at compile time or at

runtime. Hence, is does not ensure that the resulting

HTML is conforming a valid HTML document.

The KotlinX.Html (Mashkov, 2015) is another

popular DSL for HTML and it has been written in

Kotlin programming language. Kotlin may run on top

of the Java Virtual Machine (JVM) and provide inter-

operability between Java, Android, and browser en-

vironments. Like HtmlFlow, the HTML ﬂuent inter-

face for KotlinX.Html is automatically built from the

XSD deﬁnition of the HTML 5 language. Thus, the

generated DSL ensures that each element only con-

tains the elements and attributes stated in the HTML5

XSD document. This is achieved through type infer-

ence and the Kotlin compiler. Yet, unlike HtmlFlow,

the KotlinX.Html does not validate attributes and ac-

cepts any kind of values.

HtmlFlow has two main advantages over com-

petition: 1) shows better performance in several

benchmarks including the spring benchmark (Reijn,

2015), and 2) ﬂexible output approach with sup-

port to the visitor design pattern integration (Gamma

et al., 1995). This latter feature allows the integra-

tion of an output stream that pushes the resulting

HTML to the HTTP response stream as the view is

being resolved. The push-based style is proposed by

WEBIST 2019 - 15th International Conference on Web Information Systems and Technologies

124

Erik Meijer (Meijer, 2012) as an alternative to the

usual pull-based collections through the iterator pat-

tern (Gamma et al., 1995) in the context of the veloc-

ity dimension of big data.

6 EXPERIMENTAL EVALUATION

To evaluate our proposal of HtmlFlow higher-order

templates, we compare it with two different alterna-

tive approaches: a state of the art server side tem-

plate engine (Handlebars) and a front-end framework

(ReactJS). We used these three different technologies

to build a VertX web application (Fox, 2001) that

presents a listing resulting from a large data set pro-

vided by Last.fm API. This API provides a social mu-

sic playground that allows anyone to build their own

programs including web applications.

In our experimental evaluation we built a Java web

application deployed in Heroku with the domain top-

genius.eu. The topgenius.eu provides the most popu-

lar tracks on Last.fm last week for a given country. To

that end we consume data from the geo.getTopTracks

service of Last.fm API.

In the following subsection we present the high-

level architecture of the topgenius.eu web applica-

tion. Next in the subsection 4.2 we explain the do-

main model. Finally in subsection 4.3 we describe

the testing approach and the results of the experimen-

tal evaluation.

6.1 TopGenius Architecture

The topgenius.eu provides 3 different pages with ex-

act same functionality, but built with 3 three different

technologies: Handlebars, HtmlFlow and ReactJS. At

the index we can ﬁnd the corresponding links to these

pages, each one presenting a similar user-interface to

that one of Figure 3.

The web page of Figure 3 also includes an input

for the limit, which speciﬁes the maximum number

of tracks that should be returned by topgenius web

server. To avoid useless roundtrips to Last.fm we keep

an internal per user cache in topgenius web server

with data gathered from the geo.getTopTracks service.

On the ﬁrst request for a given country the topgenius

will dispatch a sequence of fetch operations to gather

that country’s data from the Last.fm. These fetch op-

erations are performed asynchronously and topgenius

does not need to wait for their completion. For ex-

ample, if the end user asks for the top hundred tracks

from Australia, then the topgenius will fetch all avail-

able tracks from Australia on Last.fm, but it will con-

clude the response as the ﬁrst 100 tracks are available.

Later, the same request to topgenius may already get

all available tracks from its cache with a low latency.

Also, as presented in Figure 3 we provide a clear

cache feature that allows users to recycle the cache for

a given country and let them take the user experience

of fetching data from the Last.fm data source with a

high latency.

The topgenius web server provides three routes for

each of the view engines: /handlebars, /htmlflow

and /react, as depicted in Figure 4. In addition, it

also includes a fourth route /api/toptracks used by

the ReactJS application to get a country top tracks.

While the geo.getTopTracks service of Last.fm

API provides paginated results with 50 records

per page, the /api/toptracks route serves those

same pages in a single data stream. This al-

lows the ReactJS application to get whole required

data with a single fetch operation, similar to what

happens for Handlebars and HtmlFlow approaches,

where the browser gets the resulting HTML doc-

ument in a single HTTP GET request. To that

end the /api/toptracks route uses the media type

application/stream+json (Snell, 2012) to trans-

mit JSON objects in newline-delimited JSON for-

mat (NDJSON). In Figure 4 we use a distinct dashed

arrow to represent data emitted by /htmlflow and

/api/toptracks routes regarding the chunked trans-

fer encoding (Fielding and Reschke, 2014) used in

both cases to stream data. On the other hand,

the /handlebars route compromises a well-known

Content-Length, which shows that topgenius server

starts to send the resulting response only when the

entire HTML document is completed. This pre-

vents the browser from presenting the response of

the /handlebars route while the server has not con-

clude the template view resolution. Rather than us-

ing this all-or-nothing basis, the /htmlflow route

starts streaming the end HTML as the resolution pro-

ceeds, sending the ﬁnal data in a series of chunks

with unknown size. This same streaming behavior

applies to the /api/toptracks route. Thus in both

cases the browser will render content progressively:

1) as HTML is received from the /htmlflow route,

or 2) as JSON is received from the /api/toptracks

route and the ReactJS component dynamically up-

dates HTML through DOM manipulation.

6.2 TopGenius Domain Model

In the topgenius Java application the class

LastfmWebApi provides methods to access the

Last.fm API. In this case, the access to the geo.get-

TopTracks service is provided by the method

countryTopTracks with the following signature:

HoT: Unleash Web Views with Higher-order Templates

125

Figure 3: Topgenius.eu user-interface to present the most popular tracks on Last.fm last week for a given country.

Figure 4: Topgenius architecture and interactions with Last.fm RESTful API and the browser.

Track[] countryTopTracks(String country,

int page)

To gather the ﬁrst 100 thousand tracks of Australia

Last.fm top tracks into a single Stream of Track ob-

jects we may perform the following query:

Listing 11: Stream query pipeline to gather the ﬁrst 100

thousand tracks from Australia.

Stream < Track > tr ac ks = Int St re a m

. ra n ge Clo se d (1 , 100 00 0)

. ma pT oO b j ( p ->

co u nt r yTo p Tr a ck s ( " Aus tr al i a " , p ))

. fl at Ma p ( S tr ea m :: of )

The resulting Stream<Track> is the model (i.e.

context object) for the templates built with Handle-

bars and HtmlFlow. But notice that tracks stream is

a lazy sequence, meaning that its elements are pro-

cessed only on demand, when they are fetched by

a terminal operation such as a for each loop. In

the case of HtmlFlow we can provide this tracks

stream as it is to the template which consumes

its elements trough the chained operation of( ->

tracks.forEach...) as denoted in the example

of Listing 2. Yet, for the Handlebars template, we

have to ﬁrst collect the entire tracks stream into a

List<Stream> before passing it to the template. This

prefetch of the stream incurs in useless memory over-

head and higher latency in HTTP server response.

Thus for limits over 10 thousands of tracks the Han-

dlebars HTTP handler may violate the Heroku plat-

form requirements and responds with a internal server

error status code.

In ReactJS a React.Component represents a tem-

plate view and its state property is equivalent to the

model in MVC or the context object in a template.

The main characteristic of ReactJS is that whenever

the state changes, the component automatically re-

renders. The React component setState() method

schedules an update to a component’s state object that

results in its rendering.

Thus, in the ReactJS approach rather than gather-

ing all the top tracks pages in a single stream we con-

catenate the resulting arrays in the component state

array and let React do the job and re-render the com-

ponent. The geographicTopTracks method of List-

ing 12 uses the native Javascript fetch function to

perform an HTTP request to /api/toptracks and a

WEBIST 2019 - 15th International Conference on Web Information Systems and Technologies

126

ndjson parser to deliver pages through the Javascript

async iterable protocol. Note that the concat() oper-

ation does not change the existing arrays, but instead

returns a new array that is set as the new state of the

React component.

Listing 12: ReactJS geographicTopTracks method that

recursively parses each page retrieved from /api/toptracks

route.

ge o gra p hi c Top T ra c ks ( ur l ) {

fetch ( url )

. t hen ( res p => {

const re ad er =

nd js on ( res p . bo dy . ge t Re ad er () )

re ad er . nex t (). th en (

fu nc tio n cons ({ va lue , do ne }) {

if ( don e ) return

const tr ac ks = this

. s ta te

. t ra ck s

. c on ca t ( v al ue . tr ac ks . tr ac k )

thi s

. se tS ta t e ({

’ trac ks ’: t ra ck s

})

re ad er

. n ext ()

. t hen ( con s )

})

}

6.3 Performance Evaluation

To measure and compare the performance of differ-

ent approaches we used JMeter with Selenium Web-

Driver. To that end we built a Selenium script for

each approach that opens the topgenius correspond-

ing url, fetches the top tracks of Australia and when

the browser ﬁnishes receiving and rendering all con-

tent, then it scrolls to the end of the page. In List-

ing 13 we depict the script used to test Handlebars.

For HtmlFlow it only changes the url, but for Reac-

tJS we need an additional wait condition to detect the

rendering completion. Note that for ReactJS the page

body is empty and all content is loaded dynamically

through DOM.

Listing 13: Selenium script to evaluate the performance in

JMeter.

WDS

. br ow se r

. ge t ( " / ha ndl eb a rs ? c ou nt ry =... " )

WDS

. br ow se r

. ex e cu t eS c ri p t ( sc ro llT o (

do cu men t . body . s cr o ll He i gh t )

)

All tests were executed on a single machine with

the JVM version 11, SE Runtime Environment 18.9

(build 11+28). During the measurements there were

no other workloads running. To discard the network

overheads we run both topgenius web server and the

browser in the same machine. And, before starting the

measurement we ensured that all required data was al-

ready collected and available in the topgenius internal

cache.

The results of Figure 5 were taken with 3 different

workloads for a limit of 1000, 5000 and 10000 tracks.

These results show that for small data sets there are

no signiﬁcant differences, yet for larger data sets the

HtmlFlow gets an improvement of up to 4-fold in per-

formance in comparison to ReactJS.

Despite we are including here the Handlebars re-

sults, they only have meaning within this benchmark

ecosystem. On presence of a realistic data source such

as Last.fm with high latency, Handlebars it is not able

to show any preliminary results until all records were

fetched, which is not an acceptable user experience.

We can observe this behavior in topgenius.eu if we do

not use cache.

7 CONCLUSIONS AND FUTURE

WORK

In this paper we propose a new approach of higher-

order templates implemented in HtmlFlow solution.

HtmlFlow assembles all the homogeneity and sim-

plicity of server-side Web development, enabling its

usage even with large data sets. HtmlFlow is a Java

DSL library for HTML that replaces textual template

ﬁles by templates deﬁned as ﬁrst-class functions. This

library not only competes in performance with state of

the art alternatives(Reijn, 2015), but it also provides a

full set of safety features not met together in any other

library individually, such as:

• Well-formed documents;

• Fulﬁllment of all HTML rules regarding elements

and attributes;

• Fully support of the HTML5 speciﬁcation.

HtmlFlow started as an academic use case of a ﬂu-

ent interface for HTML, which was not released nor

disseminated, but still attracted the attention of some

developers. This community was looking for a Java li-

brary that helps them to dynamically produce papers,

reports, emails and other kind of HTML documents

in complex Java applications where classic templates

engines do not ﬁt all the requirements. For exam-

ple, textual templates are not properly suited for com-

plex programming tasks involving the dynamic build

HoT: Unleash Web Views with Higher-order Templates

127

Figure 5: Performance results in milliseconds taken with JMeter for three view engines: Handlebars, HtmlFlow and ReactJs.

of user-interface components, which may depend on

runtime introspection data (e.g. reﬂection).

The increasing attention around HtmlFlow raised

the idea of developing a mechanism that automati-

cally generates a ﬂuent interface based on the HTML

language speciﬁcation, speciﬁed in a XSD ﬁle, which

gave rise to the xmlet platform.

Having templates views deﬁned as ﬁrst-class

functions suppress the limitations of textual templates

for server-side views specially in the presence of large

data sets. Thus HtmlFlow keeps template views sim-

ple with focus on domain-driven design and avoiding

auxiliary decorations such as numbered pagination or

inﬁnite scrolling via DOM manipulation techniques.

One of our goals for a future release of HtmlFlow

is to include an automatic translation tool that allows

to convert an HTML document in its equivalent deﬁ-

nition in HtmlFlow idiom. This is an essential module

to spread the HtmlFlow in mainstream use allowing

web designers to easily convert their web themes to

integrate a main HtmlFlow project.

More interesting and the next evolution of

HtmlFlow will be the support of asynchronous mod-

els with particular focus in Java reactive streams. Our

goal is to deal with the Observable or Publisher as

a result of the transformation provided by a higher-

order template that can be asynchronously processed

to emit the resulting HTML to the HTTP response

stream.

ACKNOWLEDGEMENTS

We express our gratitude to Antonio Rito Silva from

INESC-ID, Professor at University of Lisbon for

many suggestions and improvements of our work. We

would like to thank Pedro Felix for all feedback and

help to enhance our work.

REFERENCES

Agrawal, R., Kadadi, A., Dai, X., and Andres, F. (2015).

Challenges and opportunities with big data visualiza-

tion. In Proceedings of the 7th International Confer-

ence on Management of Computational and Collec-

tive intElligence in Digital EcoSystems, MEDES ’15,

pages 169–173, New York, NY, USA. ACM.

Alur, D., Malks, D., and Crupi, J. (2001). Core J2EE Pat-

terns: Best Practices and Design Strategies. Prentice

Hall PTR, Upper Saddle River, NJ, USA.

Ase, D. (2015). Kotlin dsl for html. Technical report,

https://j2html.com/.

Binder, W., Hulaas, J., and Moret, P. (2007). Advanced java

bytecode instrumentation. In Proceedings of the 5th

International Symposium on Principles and Practice

of Programming in Java, PPPJ ’07, pages 135–144,

New York, NY, USA. ACM.

E. Krasner, G. and Pope, S. (1988). A description of the

model-view-controller user interface paradigm in the

smalltalk80 system. Journal of Object-oriented Pro-

gramming - JOOP, 1:26–49.

Farago, J. H., Williams, H. E., Walsh, J. E., Whyte, N. A.,

Goel, K. J., Fung, P., Lazier, A. J., Moss, K. A., and

Ray, E. N. (2007). Object search ui and dragging ob-

ject results.

Feldman, D., Schmidt, M., and Sohler, C. (2013). Turn-

ing big data into tiny data: Constant-size coresets for

k-means, pca and projective clustering. In Proceed-

ings of the Twenty-fourth Annual ACM-SIAM Sympo-

sium on Discrete Algorithms, SODA ’13, pages 1434–

1453, Philadelphia, PA, USA. Society for Industrial

and Applied Mathematics.

Fielding, R. and Reschke, J. (2014). Chunked transfer cod-

ing. Rfc, https://tools.ietf.org/html/rfc7230#section-

4.1.

Fowler, M. (2002). Patterns of Enterprise Application Ar-

chitecture. Addison-Wesley Longman Publishing Co.,

Inc., Boston, MA, USA.

Fowler, M. (2010). Domain Speciﬁc Languages. Addison-

Wesley Professional, 1st edition.

Fox, T. (2001). Eclipse vert.x tool-kit for building re-

active applications on the jvm. Technical report,

https://vertx.io/.

Gamma, E., Helm, R., Johnson, R., and Vlissides, J.

(1995). Design Patterns: Elements of Reusable

Object-oriented Software. Addison-Wesley Longman

Publishing Co., Inc., Boston, MA, USA.

Hors, A. L., H

egaret, P. L., Wood, L., Nicol, G., Robie, J.,

Champion, M., Arbortext, and Byrne, S. (2004). Doc-

ument object model (dom) level 3 core speciﬁcation.

Technical report, https://www.w3.org/TR/2004/REC-

DOM-Level-3-Core-20040407/.

Jin, X., Wah, B. W., Cheng, X., and Wang, Y. (2015). Sig-

WEBIST 2019 - 15th International Conference on Web Information Systems and Technologies

128

niﬁcance and challenges of big data research. Big

Data Res., 2(2):59–64.

Kesteren, A. V., Aubourg, J., Song, J., and Steen, H. R. M.

(2006). Xmlhttprequest speciﬁcation. Technical re-

port, https://www.w3.org/TR/XMLHttpRequest/.

Lerner, R. M. (2011). At the forge: Mustache.js. Linux J.,

2011(210).

Liu, Z., Jiang, B., and Heer, J. (2013). immens: Real-time

visual querying of big data. In Proceedings of the

15th Eurographics Conference on Visualization, Eu-

roVis ’13, pages 421–430, Chichester, UK. The Eu-

rographs Association & John Wiley & Sons,

Ltd.

Mashkov, S. (2015). Kotlin dsl for html. Technical report,

https://github.com/Kotlin/kotlinx.html.

Meijer, E. (2012). Your mouse is a database. Queue,

10(3):20:20–20:33.

Mernik, M., Heering, J., and Sloane, A. M. (2005). When

and how to develop domain-speciﬁc languages. ACM

Comput. Surv., 37(4):316–344.

Parr, T. J. (2004). Enforcing strict model-view separation

in template engines. In Proceedings of the 13th Inter-

national Conference on World Wide Web, WWW ’04,

pages 224–233, New York, NY, USA. ACM.

Reijn, J. (2015). Demo project to show different java

templating engines in combination with spring mvc.

Technical report, https://github.com/jreijn/spring-

comparing-template-engines.

Smith, P. (2012). Professional Website Performance: Opti-

mizing the Front-End and Back-End. Wrox Press Ltd.,

Birmingham, UK, UK, 1st edition.

Snell, J. M. (2012). The application/stream+json media

type. Internet-draft.

Storey, V. C. and Song, I.-Y. (2017). Big data technologies

and management. Data Knowl. Eng., 108(C):50–67.

ur Rehman, M. H., Liew, C. S., Abbas, A., Jayaraman, P. P.,

Wah, T. Y., and Khan, S. U. (2016). Big data reduction

methods: A survey. Data Science and Engineering,

1(4):265–284.

Yaqoob, I., Hashem, I. A. T., Gani, A., Mokhtar, S., Ahmed,

E., Anuar, N. B., and Vasilakos, A. V. (2016). Big

data: From beginning to future. International Jour-

nal of Information Management, 36(6, Part B):1231 –

1247.

HoT: Unleash Web Views with Higher-order Templates

129
