Paradigm of Post-quantum Cryptography and Crypto-agility:

Strategy Approach of Quantum-safe Techniques

Olaf Grote

, Andreas Ahrens

and C

esar Benavente-Peces

ETS de Ingenier

ıa y Sistemas de Telecomunicaci

on, University Polit

ecnica de Madrid,

Campus Sur, Ctra. Valencia, 28031 Madrid, Spain

Hochschule Wismar, University of Applied Sciences - Technology, Business and Design,

Philipp-M

uller-Straße 14, 23966 Wismar, Germany

ETS de Ingenier

ıa y Sistemas de Telecomunicaci

on, University Polit

ecnica de Madrid,

Campus Sur, Ctra. Valencia, 28031 Madrid, Spain

Keywords:

Post-quantum Cryptography, Crypto-agility, Quantum-safe, Quantum Algorithms, Quantum Computer

Science.

Abstract:

Current security protocols use cryptographic methods based on asymmetric and symmetric schemes. These

are used for encrypted communication of information or for general data encryption. The security of these

methods is based on well researched methods and known mathematical problems. These have been developed

for common computing resources and with the certainty that they cannot be broken at a determinable runtime

with ﬁnite resources. This excludes novel attack vectors such as those of a quantum computer using quantum

algorithms. These cryptographic methods, especially the asymmetric schemes, are not prepared against quan-

tum attacks and not considered quantum safe. Even the security of current quantum safe symmetric schemes

is not based on proven security against quantum attacks. In order to effectively counter this threat, a new and

effective strategy is necessary. One point of this strategy is the post-quantum cryptography to evaluate new

quantum-safe cryptographic principles. The second point is to research security protocols which are quantum

safe and resistible against quantum attacks. This paper describes the strategy of post-quantum cryptography

and crypto-agility.

1 INTRODUCTION

Current cryptographic schemes must be evaluated to

see how they are still effective against quantum at-

tacks. This affects encrypted communication (data

in transit) and encrypted data that is not continu-

ously changed (data at rest). However, from the

perspective of a quantum computer the symmetric

scheme is considered quantum safe and the asym-

metric as be broken. In order to make this scheme

quantum safe, quantum computer resistant public key

derivatives are sought because this method is cur-

rently needed. The novel contribution of this article

is the review and presentation, which holistic con-

cept is necessary to ward off possible attacks on es-

tablished security mechanisms with quantum algo-

rithms. The paper focusing is on the established cryp-

tographic methods and how current security protocols

can be adapted against quantum attacks. They are two

variants to be resilient against quantum attacks. On

the one hand, research and investigation of quantum

computer-resistant cryptography primitives for post-

quantum cryptography (PQC) is needed to ﬁnd poten-

tial candidates. On the other hand is the cryptographic

agility (crypto-agility) of security protocols to ex-

change, modify or parameterize public-key cryptog-

raphy algorithms with new cryptographic primitives

which from the perspective of quantum computing

are resilient against quantum attacks. The remaining

parts of this paper are structured as follows: Section

2 shows the state of the art established cryptography

in context of the new approach. Section 3 introduce

the need for use to deﬁne a concept and paradigm of

post-quantum cryptography and crypto-agility. The

main section 4 describes the paradigm. Thus section

describes in the ﬁrst part the new mathematical primi-

tives and cryptographic schemes candidates and in the

second part describes the crypto-agility how it is pos-

sible to integrate this schemes and the way to modify

established security protocol quantum-safe. The re-

sults of this study are presented in section 5. Finally,

section 6 provides some concluding remarks.

Grote, O., Ahrens, A. and Benavente-Peces, C.

Paradigm of Post-quantum Cryptography and Crypto-agility: Strategy Approach of Quantum-safe Techniques.

DOI: 10.5220/0008162800910098

In Proceedings of the 9th International Conference on Pervasive and Embedded Computing and Communication Systems (PECCS 2019), pages 91-98

ISBN: 978-989-758-385-8

2 STATE OF THE ART

In general, the functionality of an algorithm is a

unique, time dedicated, executable sequence of in-

structions with deﬁned length. Such algorithms scale

against the input value exponential. Computer-based

programs deliver the quantiﬁed results of this algo-

rithm. The estimated runtime and the efﬁciency of

cryptographic algorithms are estimated relatively dis-

advantageously. Based on complexity theory, each al-

gorithm is runtime efﬁcient of class P, where P con-

tains all decision problems when the input polyno-

mial is determined and the result is computer-capable

with a polynomial effort runtime. For example, the

following algorithms belong to class P, which have

a constant, logarithmic, linear and quadratic runtime.

Nevertheless, all algorithms that are correctly recog-

nized for the solution of a problem in polynomial

time by means of a non-deterministic Turing machine,

but require an exponential computing time in case

of a wrong solution, are called runtime inefﬁcient of

the class NP, where NP deﬁne the non-deterministic

polynomial time. Current cryptographic methods

are based on these complexity-theoretical statements,

since P 6= NP is currently assumed to be mathemati-

cal, but has not yet been proven (Eckert, 2014). Thus,

if the complexity class of a problem depends on the

algorithm or is determined by the required resources

such as computing power and memory, quantum al-

gorithms can perform these tasks with optimized run-

times. In contrast to the algorithms that make all prob-

lems in complexity class P decidable to a polynomial

runtime on a deterministic Turing machine, quantum

algorithms include functions rather on questions like

searching in a database, recognizing a global prop-

erty of a function, e.g. period, mean value. Further-

more, quantum algorithms solve runtime-optimized

problems on a non-deterministic Turing machine such

as the number-theoretical problem or the calculation

of the gradient in n−dimensions. Two quantum algo-

rithms have received quite a bit of notice: Shor’s al-

gorithm for factoring integers in polynomial time on

a quantum computer (Shor, 1994) and Grover’s algo-

rithm for searching a unsorted database of x elements

with efﬁcient runtime (Grover, 1996). The advantage

and main reason of the high efﬁciency of quantum

algorithms is the calculation of the periodicity of a

function, which is available as a global property after

the ﬁrst operation in the quantum register of a quan-

tum computer. With this method, which provides for a

concrete parallelism, the periodic and recurring com-

ponents within a bit sequence can be efﬁciently ﬁl-

tered and useful for a quantum attack.

3 QUANTUM ATTACK

APPROACHES

Quantum mechanics describes in simpliﬁed terms the

microscopic properties of a physical object where the

speciﬁc state of this object temporal and physical

space only be determined vaguely. This object (e.g.

atoms, electrons, photons) particle has the same en-

ergetic order of magnitude as the object with which

it is to be measured. This also means that the orig-

inal particle is demonstrably changed after a mea-

surement (Brands, 2011). Quantum computer follow

the laws of quantum physics and performs operations

with three states ”0” or ”1” or ”0 and 1”. This new

computer capability solve mathematical problems of

the complexity class NP in a polynomial time so that

P = NP. Shor’s algorithm (1) which performed on a

quantum computer breaks in polynomial time cryp-

tographic primitives and schemes that based on inte-

ger factorization and discrete logarithms (Shor, 1997).

This algorithm delivers to one natural number N a

nontrivial factor which are deﬁned as:

O((logN)

) (1)

All public-key cryptography that use those algebraic

structure are affected like Rivest, Shamir, Adleman

method (RSA), Elliptic Curve Cryptography (ECC)

and Difﬁe-Hellman (DH). Grover’s algorithm (2) is a

runtime optimized quantum search algorithm to use

brute-force attacking that checks all possible cipher

key by determined time and resources (3) (Grover,

1999), where n is the number of bits that are searched

(see Table 1):

√

n) (2)

O(logn) (3)

This enables the quantum computer to use the square-

root factor and halved the exponent of time complex-

ity in opposite to a linear search algorithm O(n). The

Table 1 shows the runtime and cost effort for each

algorithm and for the symmetric cryptography Ad-

vanced Encryption Standard (AES).

Table 1: Runtime and cost efforts per algorithm.

n O(n) O(

√

n) O(

√

128 bit 128 bit 64 bit 42,66

192 bit 192 bit 96 bit 64

256 bit 256 bit 128 bit 85,33

Furthermore, the Grover’s algorithm is useful for at-

tacking the established secure hash algorithm (SHA)

to ﬁnd preimages (Amy et al., 2017) and hash col-

lisions by modifying the algorithm with a cube-root

factor (Brassard et al., 1998). In general Grover algo-

rithm is a probabilistic algorithm and tries to achieve a

PECCS 2019 - 9th International Conference on Pervasive and Embedded Computing and Communication Systems

good or approximately correct average result. To ﬁnd

the right key it makes sense to use this randomized

algorithm again on the previous result.

4 PARADIGM OF

POST-QUANTUM

CRYPTOGRAPHY AND

CRYPTO-AGILITY

In terms of special requirements, future-proof cryp-

tography is characterized by the ability to adapt to

new technologies and challenges. Today’s cryptog-

raphy achieves this ideal through post-quantum cryp-

tography and crypto-agility. That includes research

new cryptographic primitives and ensuring common

mechanisms to stable current system environment and

the idea to modify security protocols. This will be

necessary because the development of quantum com-

puters is an active ﬁeld of research. Technical guide-

lines and recommendations for quantum computer re-

sistant cryptographic methods are currently reaching

a stage of development, but no standardization yet.

According to the current state of research, one can

classify symmetric encryption as a quantum computer

resistant. The turn-based method (4), as well as the

key length (5) of one of its key phrases |K|, allows

this assumption:

|K| = 10/128,12/192,14/256 (4)

|K| = 2

128

192

256

(5)

These properties make the symmetric scheme resis-

tant to brute-force attacks by a quantum computer. A

complete analysis of the keyspace is considered inef-

fective. An attacker could scan the ciphertext about 4

times faster and break it if he has little plaintext to the

ciphertext than to perform an analysis of the keyspace

(Bogdanov et al., 2011). Furthermore, the higher the

key, the fewer steps are required for decryption. For

example, a ciphertext created with AES-192 requires





steps for decryption and only 

,

steps for AES-

256 (Biryukov and Khovratovich, 2009). Neverthe-

less, in brute-force attacks of quantum computers on

the key space of AES thanks to turn-based methodol-

ogy and the key length as a quantum-safe. As an alter-

native to AES, the Camellia procedure recommended

by the European ENISA can be used. Both methods

are based on block encryption with the same block

cipher. Camellia is slower in direct comparison to

AES, but uses a block cipher directly of 128 bits for

more laps (/,/,/). For stream ci-

phers, the method Salsa20 (Snufﬂe 2005) with a 256

bit key length could be used. The standard version

Salsa20/20 uses an encryption of 20 rounds. The al-

gorithm is extremely efﬁcient and resistant to possible

side channel attacks. The Salsa20/12 and Salsa20/8

variants can be used for time-critical as well as jitter-

and latency-relevant applications. In contrast to sym-

metric methods, the asymmetric method is consid-

ered non-quantum-safe. Nevertheless, this scheme

still needs to be used for key exchange. With asyn-

chronous encryption algorithms, it makes sense to use

a RSA key length of ≥ 3000 bits to achieve a secu-

rity level that can react to possible attacks from quan-

tum computers. In order to attack a ≥ 3000 RSA

key a quantum computer must have a few thousand

logical Qubits for the mathematical operation. Fur-

thermore, correction or cache Qubits are necessary,

which hold intermediate results. To compare, state-

of-the-art fully controlled quantum computer operates

of 20 Qubits with entangled states (Friis et al., 2018).

But it makes sense to search for other public-key al-

ternatives to replace this asymmetric methods. The

McEliece method can be used as an RSA alternative,

since no quantum algorithm has yet been found that

can effectively break this cryptographic method but

use of the large matrices for this method is rarely used

in practice. Quantum Key Distribution (QKD) is a

possible solution for the key exchange. The QKD

belongs to quantum cryptography and is a method

for secure key exchange. The method guarantees its

security with the physical fact of quantum mechan-

ics. This method is not suitable as an encryption

method for messages, but for the secure exchange of

keys. A man in the middle attacker would have to

actively measure the quantum particles. This gener-

ates high error rates and measurement inaccuracies

on the quantum channel. Furthermore, the charge

of the quantum particles would collapse. This gives

you physical evidence of safety. With this method

even very long symmetric keys can be transmitted in

a relatively short time. An application of the Ver-

nam’s One Time Pad (OTP) method, which is con-

sidered quantum-safe, would be conceivable. ECC

equivalents like Elliptic Curve Digital Signature Al-

gorithm (ECDSA) and Elliptic Curve Difﬁe-Hellman

(ECDH) must be considered broken and not useful

for the PQC. Nevertheless, one can provide secu-

rity protocols with a hybrid procedure. The Super-

singular Isogeny Difﬁe-Hellman (SIDH) is deﬁned

as quantum computer resistant and could be a can-

didate for hybride implementation of ECC with e.g.

Montgomery and Twisted Edwards Curves (Boureanu

et al., 2014). For digital signature procedures, new

such hash-based eXtended Merkle Signature Scheme

(XMSS) and SPHINCS can be used for PQC. This

hash methods are high-security post-quantum state-

Paradigm of Post-quantum Cryptography and Crypto-agility: Strategy Approach of Quantum-safe Techniques

less hash-based signature schemes. The established

secure hash algorithm SHA-2/-3 is currently believed

secure and quantum computer resistant but not to be

resilient and proved. However, the ≥ 384 hash value

(bit) should already be used for long-term storage. Ta-

ble 2 illustrates the recommended key length for the

cryptographic scheme.

Table 2: Recommended key length and method.

Scheme Recommendation

AES 256 bit

Camellia 192 bit

Salsa20 256 bit stream chiffre

RSA ≥ 3000 bit

McEliece method 128 bit

SIDH 128 / 192 bit

SHA-2 /-3 256 / 384 Hash value (bit)

XMSS/ SPHINCS SHA-256 / AES-128

4.1 Post-quantum Cryptography

Increase of the key space alone is not enough to be

quantum-safe. For example, If the symmetrical en-

cryption AES was attacked by the Grover quantum

algorithm, the key strength would still be 50%. An

attack via Shor quantum algorithm on asymmetric al-

gorithms such as RSA or ECC could no longer nearly

guarantee the same security that an asymmetric en-

cryption would provide. Even increasing the size of

the key space would not be an adequate measure and

would also make the cryptographic process inefﬁcient

(Fumy, 2017). Table 3 shows the effectively capacity

of the key size and key data and deﬁne the efﬁcient

properties of the established not quantum-safe public-

key schemes.

Table 3: Key properties of no quantum-safe schemes.

Key-Length (bit) Size (bytes) Data (bytes)

RSA-2048 256 256

RSA-3072 384 384

RSA-4096 512 512

ECC-256 32 32

ECC-512 64 64

The Table 4 shows schemes which are believed

quantum-safe and proofed secure level for public-key

and key exchange method. This methods operates

with a transmitted data capacity that is signiﬁcant

larger then established methods e.g. public-key sig-

natures XMSS (Butin, 2017), SPHINCS (Bernstein

et al., 2015) and HFE* (Petzoldt et al., 2015). The

same situation with the public-key encryption e.g.

the coding-based scheme McEliece (Bernstein et al.,

2008) and grid-based scheme NTRU (IEEE, 2008),

and the key exchange as well like NewHope (Alkim

et al., 2015) and SIDH (Costello et al., 2016).

Table 4: Key properties of quantum-safe schemes.

Key-Length (bit) Size (bytes) Data (bytes)

HFE*/PMI* = 500,000

NTRU = 1,500 = 1,500

McEliece = 800,000 = 180

SIDH n/a = 500

XMSS 64 = 2,000

SPHINCS = 1,000 = 40,000

However, the challenge is to update the established se-

curity protocols and cryptographic methods in a man-

ner that is useful and beware against possible quan-

tum attacks. Here are ﬁve potential candidates of

quantum-safe primitives.

4.1.1 Multivariate Cryptography

The multivariate cryptography is mathematically

based on a quadratic polynomial equation. The func-

tionality is based on the idea that ﬁgures on sets of n

quadratic polynomials p

,..., p

over ﬁnite elements

with more then n variables χ

,...,χ

can be repre-

sented in different ways. For function P, this results

in:

→ K

(6)

(χ

,...,χ

) → (p

(χ

,...,χ

,..., p

)(χ

,...,χ

)) (7)

and P(x) can therefore be calculated if x ∈ K

applies.

The inverse way for a y ∈K

, thus a x ∈ K

with func-

tion P(x) = y by means of a quadratic equation sys-

tem. The difﬁculty of this variant and at the same

time the safety of the procedure is to solve the equa-

tion system, as the following applies:

(χ

,...,χ

) −y

= 0 (8)

(χ

,...,χ

) −y

= 0 (9)

For encryption the evaluation is performed by a poly-

nomial. Decryption, on the other hand, is performed

by the inverse polynomial mapping using knowledge

of a mapping structure. The weakness of this pro-

Table 5: Character of Multivariate cryptography.

Property Speciﬁcation

based on quadratic equations

methods HFE, HFEv, HFEv-, PMI+

beneﬁts efﬁcient, ready for use

disadvantages mathematically not proven

cedure lies in the mathematical veriﬁability as to

whether the function P is a one-way function, and to

ensure that it is not effectively reversible. But secu-

rity in cryptographic processes is based on this. Table

5 shows the properties of this method.

PECCS 2019 - 9th International Conference on Pervasive and Embedded Computing and Communication Systems

4.1.2 Grid-based Cryptography

The mathematical approach of grid-based cryptogra-

phy is based on creating a grid as a discrete subset

of a n−dimensional real vector space. It is thus di-

vided in a n−dimensional space like a grid and di-

vided into a deﬁned number of cells. Each cell con-

tains objects with statistical values such as number,

average, deviations, min./max. values. The advantage

results from the low complexity, since a runtime does

not depend on the contained objects, but only on the

cells to be considered. The values for these are saved

as soon as the data has been loaded into the cells.

Grid-based cryptographic methods are rather limited

to solving mathematical problems in such grids e.g.

shortest vector problem, close vector problem, Ring-

Learning With Errors (Ring-LWE). Thus, for exam-

ple, the sum of two grid points again results in a grid

point in the grid where no other grid point exists. Fur-

thermore, the runtime of the algorithm is exponen-

tially, the more granular the more accurate the number

of dimensions of the grid. This generally means that

problems on standard grids will cause a strong safety

proof but run slower. Problems in ideal grids are used

for encryption and decryption at the expense of a low

safety proof of runtime efﬁciency. Table 6 shows the

general properties of the common grid-based method.

The methods BLISS and Tesla are mentioned as grid-

based methods but not presented.

Table 6: Character of Grid-based cryptography.

Property Speciﬁcation

based on Grid calculation

methods New Hope, Frodo, Kyber, NTRU

beneﬁts Runtime efﬁcient

disadvantages No experience by cryptanalysis

A possible compromise would be a procedure based

on module grids. However, the proven speed over

RSA encryption can be noticed. Furthermore, there

are some implementation of security protocols with

New Hope that based on grid-based cryptography

(Alkim et al., 2015). The NTRU algorithm which

is based on the principles of the Ring-LWE prob-

lem, requires a runtime of O(N



) for an encryp-

tion/decryption operation of a message of length N,

while a conventional RSA method requires a run-

time of O(N



) (Hoffstein et al., 1998). NTRU algo-

rithm is thus depending on the three integer param-

eters N, p, q and four polynomials p

,..., p

with a

degree of N − and an integer coefﬁcient. The pa-

rameters p, q not necessarily need be prime numbers,

where gcd(p,q) =  and q > p apply. Thus, the ring

R is calculated as follows if Z is the quantity of the

total Numbers:

R = Z[X]/(X

−1) (10)

4.1.3 Coding-based Cryptography

The coding-based cryptography is the oldest approach

towards quantum computer resistant public-key meth-

ods and is based on the difﬁculty to decode gen-

eral error correcting codes efﬁciently. The binary

Goppa code is preferred for this, on which the meth-

ods McEliece and Niederreiter are based on. The

property of error correction codes is that the decoding

algorithm can correct a maximum of errors r, which

is encoded and/or transmitted in a ciphertext c:

y = c + e (11)

If thus e is regarded as error vector to r, one can

conclude from y to c. An attacker could not deter-

mine c from y in an acceptable time. The basis for

the security of the procedure is the secrecy of the de-

coding matrix. Only the coding matrix from which

no conclusions about the decoding matrix can be de-

rived may be published. The Goppa code forms such

a large class of algebraic error correcting codes to en-

sure the security of this procedure. The Goppa code

Γ(L,g(z)) is represented by the Goppa polynomial

g(z) having a degree t deﬁned over a ﬁnite body hav-

ing a ﬁnite number GF(q

) in conjunction with a gen-

erated matrix G and vector parameters. Based on the

Goppa code, the McEliece and Niederreiter methods

are used. Table 7 shows the character of this method.

Table 7: Character of Coding-based cryptography.

Property Speciﬁcation

based on Efﬁcient decoding

methods McEliece, McBits, Niederreiter

beneﬁts McEliece method well studied

disadvantages Large public-key, low power

4.1.4 Isogeny-based Cryptography

The isogeny-based cryptography based on the alge-

braic geometry and describes the state of two groups

that produce a structure-preserving image when cer-

tain variety properties of a homogeneity are fulﬁlled.

Restricted to cryptography, the elliptic curves form

over an algebraically closed body. Thus a morphism

of elliptic curves is considered to be isogenic if fol-

lowing is valid:

Φ :E



→ E



(12)

Φ(O) = O (13)

Paradigm of Post-quantum Cryptography and Crypto-agility: Strategy Approach of Quantum-safe Techniques

If such a Φ exists, then E ∩E is called iso-

genic. Thus, mathematical mappings between el-

liptical curves are generated, which can be used as

a basis for the Difﬁe–Hellman key exchange (DH).

The difﬁculty lies in ﬁnding this isogenies between

the elliptic curves. Current implementations of DH

are based on isogenies between supersingular elliptic

curves such as the Montgomery curves. For exam-

ple the Supersingular Isogeny Difﬁe Hellman key ex-

change (SIDH) is a possible method. Table 8 shows

the character of this method.

Table 8: Character of Isogeny-based cryptography.

Property Speciﬁcation

based on Elliptic curves principles

methods SIDH

beneﬁts Elliptic curves well-researched

disadvantages Less researched

4.1.5 Hash-based Cryptography

Cryptographic hash procedures or one-way hash

functions are based on the difﬁculty of calculating

hash collisions. Digital signatures are to be issued us-

ing collision-resistant hash algorithms such as XMSS

(Buchmann et al., 2011) and SPHINCS (Bernstein

et al., 2015). Since 2018, a ﬁrst draft of the IETF stan-

dard has been available (Arrow et al., 2018). XMSS

procedure is well developed and standardized and of-

fers an efﬁcient calculation runtime, since the signa-

ture length and the veriﬁcation time are linear to the

message length and independent of the number of sig-

natures - in contrast to algorithms of signature chains,

whose runtime is linear to the number of signatures on

the signature length and veriﬁcation time. The XMSS

procedure is based on a stateful hash-based signature

scheme, which is mapped on a single or multi tree

(hash tree) and is based on the W-OTS+ variant. With

the pure OTS procedure, only one message can be

digitally signed with a key. With the extended W-

OTS+ variant, a limited number of digital signatures

can be generated for a XMSS public-key. Thus the

secret key must be updated after each signing and the

key pair is limited with regard to the signature pro-

cess. The number of messages m to be signed and

veriﬁed in a key pair is mathematically dependent on

the height H of the hash tree. Thus, the number of 

messages applies if:

H ∈ N (14)

H =  (15)

Furthermore, the limiting factor of 

can be the

signature-generating device or a guideline. There is

currently no quantum algorithm that allows ﬁnding a

hash collision in polynomial time, so they are consid-

ered to be resistant to quantum computers.

4.2 Crypto-agility

Crypto-agility describes the ability to continue us-

ing existing cryptographic methods and security pro-

tocols with adapting for PQC. Non quantum resis-

tant cryptographic algorithms will be replaced PQC

proved algorithms. Furthermore, there is the need to

achieve an afﬁnity to modifying cryptographic sys-

tems by manufacturers. Proactive adapting and con-

tinuous improvement of the cryptographic methods

and security protocols are the effectively countered

against the quantum attacks. Three examples with

X.509v3, Secure / Multipurpose Internet Mail Exten-

sions (S/MIME) and Secure Shell (SSH) show a pos-

sible approach of crypto-agility.

4.2.1 Modifying X.509v3 Certiﬁcate

The X.509v3 certiﬁcate is a compilation of gen-

erally valid data formats and algorithms and not

a native security protocol. The integral compo-

nents of the X.509v3 certiﬁcate are Secure Socket

Layer/Transport Layer Security (SSL/TLS), S/MIME

and Extensible Markup Language (XML) Digital Sig-

natures. Based on the format description and the

data structure of the X.509v3 certiﬁcate a Public-Key-

Infrastructure (PKI) speciﬁcation can be deﬁned to

access digital certiﬁcates with quantum resistant al-

gorithm. There is no need to adapt the RFC compli-

ant standards. However, further adjustments must be

made at the security protocol level, such as upgrading

the TLS version to version 1.3 to ensure a hybrid ap-

proach. Furthermore, the very large key room for the

public-key must be reckoned to realized the protec-

tion against quantum attack (Campagna et al., 2015).

4.2.2 Modifying S/MIME Protocol

The S/MIME protocol is used via the PKI procedure

to ensure that digital signatures guarantee authentica-

tion, data integrity, binding nature and secure e-mail

encryption. A similar scheme and protocol is Open

Pretty Good Privacy (OpenPGP), which is based on

Web of Trust (WOB). To generate and verify a key

pair, a digital signature is required for S/MIME ver-

sion 3.2, which requires an asymmetric key of at least

1024 bits. The asymmetric algorithms Digital Sig-

nature Algorithm (DSA), RSA and RSA Probabilis-

tic Signature Scheme (RSA-PSS) with SHA-256 each

are available. The content of the message is exe-

cuted with the symmetric algorithm AES. Thus the

content is secure against quantum algorithms with

PECCS 2019 - 9th International Conference on Pervasive and Embedded Computing and Communication Systems

AES encryption, but the key exchange is not quan-

tum computer resistant. Note that the S/MIME proto-

col supports extended key sizes and encryption meth-

ods. Thus, the signature and key generation of the

S/MIME protocol can be updated with quantum com-

puter resistant algorithms. Therefore, the S/MIME

protocol supports elliptic curve algorithms for Cryp-

tographic Message Syntax (CMS), which is compat-

ible with the Public Key Cryptography Standards#7

(PKCS#7) certiﬁcate regarding to data format. The

implementation of CMS is possible for most applica-

tions. The strength of the security comes from the

encapsulation. Furthermore, many security features

are based on the parameters of CMS, which allow

the modiﬁcation and selection of algorithms. Some

S/MIME versions prior to version 3.2 may only use

RSA (Campagna et al., 2015).

4.2.3 Modifying SSH Protocol

The SSH architecture consists of TLS, a user au-

thentication protocol and a connection protocol, each

of which uses its own algorithm in different net-

work layers. The TLS protocol ensures the protec-

tion goals of conﬁdentiality, authentication and in-

tegrity and can be designed to be quantum-safe by a

parameterized adaptation. In contrast, the user au-

thentication and connection protocol with its cryp-

tographic primitives such as RSA, Digital Signature

Algorithm (DSA), ECDSA is not quantum secure.

Fundamentally, however, the SSH protocol is cryp-

tographically agile, since the SSH TLS protocol ne-

gotiates the ﬁrst algorithm for key exchange between

client and server when a connection is to be estab-

lished. Thus, a quantum-safe algorithm can be used

for key exchange, if the protocol ﬂexible enough to

cover the properties and requirements of PFS. Fur-

thermore, the use of the non-quantum-safe signature

algorithms DSA, ECDSA and RSA Probabilistic Sig-

nature Scheme (RSASSA-PSS) for the authentication

of the host can be replaced by quantum-safe digital

signatures. Thus, the standard as speciﬁed in RFC

4253 does not need to be fundamentally changed

when making the appropriate modiﬁcations to the

SSH protocol and its underlying layers (Campagna

et al., 2015). The adapting already existing encryp-

tion methods is a common way to be quantum-safe.

5 RESULTS

It generally applies: Without any proof that a crypto-

graphic algorithm via quantum algorithm is vulnera-

ble or to broken by a quantum attack, a cryptographic

method could be with sufﬁcient research presumed to

be quantum attack resistant. Furthermore, every cryp-

tographic algorithm that based of mathematical com-

plexities like factorization and discrete logarithms are

believed as broken from the perspective of quantum

computer. This applies also to all security protocols

that use thus cryptographic algorithm. Typical asym-

metric encryptions such as RSA, ECC, public key

methods and their security protocols are not consid-

ered PQC ready. The asymmetric method can only re-

act to potential quantum attacks by increasing the size

of the key. Furthermore, the security of the method

and the key length can be guaranteed until the next

quantum attack and is dependent on the next higher

quantum computer generation. However, a large RSA

or ECC key affects the transfer of the key. Cryptosys-

tems which based on symmetric encryption like AES

are considered quantum resistant because the method

is turn-based and the key size can be increased. The

common security protocols, cryptosystems and appli-

cations use public-key method for the key exchange

and symmetric key for the data payload. In order

to be quantum-safe the public-key method must be

adapted by PQC approved cryptographic algorithm

and method. Furthermore, it must be ensure that all

security protocols are easy to substituted and be cryp-

tographic agility. The research for new cryptographic

primitives compliment the strategy of crypto-agility

and post-quantum cryptography.

6 CONCLUSIONS

At present, no quantum computers can break estab-

lished encryption. Furthermore, the perception of the

feasibility of a quantum computer is becoming more

concrete and this is the reason why it is comprehensi-

ble that quantum computer has such an enormous im-

pact on all areas of our society. The further develop-

ment of quantum algorithms are no longer just a topic

for universities or institutions of research and teach-

ing. Especially larger IT companies such as Google,

IBM, Microsoft, etc. are investing a great deal of time

and effort in creating a powerful quantum computer.

Just because we are currently still secure with our es-

tablished encryption mechanisms does not mean that

we do not have the cryptographic future to plan. It

must rather be accompanied by the timely and par-

allel development of the quantum computer and the

same procurement of resources.

Paradigm of Post-quantum Cryptography and Crypto-agility: Strategy Approach of Quantum-safe Techniques

REFERENCES

Alkim, E., Ducas, L., P

oppelmann, T., and Schwabe, P.

(2015). Post-quantum key exchange - a new hope.

Cryptology ePrint Archive, Report 2015/1092.

Amy, M., Di Matteo, O., Gheorghiu, V., Mosca, M., Parent,

A., and Schanck, J. (2017). Estimating the cost of

generic quantum pre-image attacks on sha-2 and sha-

3. In Avanzi, R. and Heys, H., editors, Selected Areas

in Cryptography – SAC 2016, pages 317–337, Cham.

Springer International Publishing.

Arrow, A., Butin, D., Gazdag, S., Rijneveld, J., and Mo-

haisen, A. (2018). Xmss: extended merkle signature

scheme. Request for Comments rfc8391, Corporation

of TU Darmstadt, Radboud University, University of

Central Florida, genua GmbH.

Bernstein, D. J., Hopwood, D., H

ulsing, A., Lange, T.,

Niederhagen, R., Papachristodoulou, L., Schneider,

M., Schwabe, P., and Wilcox-O’Hearn, Z. (2015).

Sphincs: Practical stateless hash-based signatures. In

Oswald, E. and Fischlin, M., editors, Advances in

Cryptology – EUROCRYPT 2015, pages 368–397,

Berlin, Heidelberg. Springer Berlin Heidelberg.

Bernstein, D. J., Lange, T., and Peters, C. (2008). Attacking

and defending the mceliece cryptosystem. In Buch-

mann, J. and Ding, J., editors, Post-Quantum Cryp-

tography, pages 31–46, Berlin, Heidelberg. Springer

Berlin Heidelberg.

Biryukov, A. and Khovratovich, D. (2009). Related-key

cryptanalysis of the full aes-192 and aes-256. In

Proceedings of the 15th International Conference on

the Theory and Application of Cryptology and In-

formation Security: Advances in Cryptology, ASI-

ACRYPT ’09, pages 1–18, Berlin, Heidelberg, Ger-

many. Springer-Verlag.

Bogdanov, A., Khovratovich, D., and Rechberger, C.

(2011). Biclique cryptanalysis of the full aes. In

Proceedings of the 17th International Conference on

The Theory and Application of Cryptology and In-

formation Security, ASIACRYPT’11, pages 344–371,

Berlin, Heidelberg, Germany. Springer-Verlag.

Boureanu, I., Owesarski, P., and Vaudenay, S., editors

(2014). Applied Cryptography and Network Security

- 12th International Conference, ACNS 2014, Lau-

sanne, Switzerland, June 10-13, 2014. Proceedings,

volume 8479 of Lecture Notes in Computer Science,

Berlin, Heidelberg, Germany. Springer.

Brands, G. (2011). Einf

uhrung in die quanteninformatik.

In Quantenkryptograﬁe, Teleportation und Quanten-

computing, pages 17–18, Berlin, Heidelberg. Springer

Berlin Heidelberg.

Brassard, G., HØyer, P., and Tapp, A. (1998). Quantum

cryptanalysis of hash and claw-free functions. In Luc-

chesi, C. L. and Moura, A. V., editors, LATIN’98:

Theoretical Informatics, pages 163–169, Berlin, Hei-

delberg. Springer Berlin Heidelberg.

Buchmann, J., Dahmen, E., and H

ulsing, A. (2011). Xmss -

a practical forward secure signature scheme based on

minimal security assumptions. In Yang, B.-Y., editor,

Post-Quantum Cryptography, pages 117–129, Berlin,

Heidelberg. Springer Berlin Heidelberg.

Butin, D. (2017). Hash-based signatures: State of play.

IEEE Security Privacy, 15(4):37–43.

Campagna, M., Chen, L., Dagdelen,

O., Ding, J., Fer-

nick, J. K., Gisin, N., Hayford, D., Jennewein, T.,

utkenhaus, N., Mosca, M., Neill, B., Pecen, M., Perl-

ner, R., Ribordy, G., Schanck, J. M., Stebila, D., Wa-

lenta, N., Whyte, W., and Zhang, Z. (2015). Quantum

safe cryptography and security: An introduction, ben-

eﬁts, enablers and challengers. Technical report, ETSI

(European Telecommunications Standards Institute).

Costello, C., Longa, P., and Naehrig, M. (2016). Efﬁcient

algorithms for supersingular isogeny difﬁe-hellman.

In Robshaw, M. and Katz, J., editors, Advances in

Cryptology – CRYPTO 2016, pages 572–601, Berlin,

Heidelberg. Springer Berlin Heidelberg.

Eckert, C. (2014). IT-Sicherheit: Konzepte - Verfahren -

Protokolle. De Gruyter Oldenbourg, Munich, 9nd edi-

tion.

Friis, N., Marty, O., Maier, C., Hempel, C., Holz

apfel, M.,

Jurcevic, P., Plenio, M. B., Huber, M., Roos, C., Blatt,

R., and Lanyon, B. (2018). Observation of entangled

states of a fully controlled 20-qubit system. Phys. Rev.

X, 8:021012.

Fumy, W. (2017). Quantencomputer und die zukunft

der kryptographie. Datenschutz und Datensicherheit,

41(1):13–16.

Grover, L. K. (1996). A fast quantum mechanical algorithm

for database search. In Proceedings of the Twenty-

eighth Annual ACM Symposium on Theory of Com-

puting, STOC ’96, pages 212–219, New York, NY,

USA. ACM.

Grover, L. K. (1999). Quantum computing. The Sciences,

39(4):24–30.

Hoffstein, J., Pipher, J., and Silverman, J. H. (1998). Ntru:

A ring-based public key cryptosystem. In Buhler, J. P.,

editor, Algorithmic Number Theory, pages 267–288,

Berlin, Heidelberg. Springer Berlin Heidelberg.

IEEE (2008). Ieee draft standard speciﬁcation for public-

key cryptographic techniques based on hard prob-

lems over lattices. IEEE Unapproved Draft Std

P1363.1/D12, Oct 2008.

Petzoldt, A., Chen, M.-S., Yang, B.-Y., Tao, C., and Ding,

J. (2015). Design principles for hfev- based multivari-

ate signature schemes. In Iwata, T. and Cheon, J. H.,

editors, Advances in Cryptology – ASIACRYPT 2015,

pages 311–334, Berlin, Heidelberg. Springer Berlin

Heidelberg.

Shor, P. W. (1994). Algorithms for quantum computation:

discrete logarithms and factoring. In Proceedings 35th

Annual Symposium on Foundations of Computer Sci-

ence, pages 124–134.

Shor, P. W. (1997). Polynomial-time algorithms for prime

factorization and discrete logarithms on a quantum

computer. SIAM J. Comput., 26(5):1484–1509.

PECCS 2019 - 9th International Conference on Pervasive and Embedded Computing and Communication Systems
