npm Packages as Ingredients: A Recipe-based Approach

Kyriakos C. Chatzidimitriou, Michail D. Papamichail, Themistoklis Diamantopoulos,

Napoleon-Christos Oikonomou and Andreas L. Symeonidis

Electrical and Computer Engineering Dept., Aristotle University of Thessaloniki, Thessaloniki, Greece

Keywords:

Dependency Networks, Software Reuse, JavaScript, npm, Node.

Abstract:

The sharing and growth of open source software packages in the npm JavaScript (JS) ecosystem has been

exponential, not only in numbers but also in terms of interconnectivity, to the extend that often the size of de-

pendencies has become more than the size of the written code. This reuse-oriented paradigm, often attributed

to the lack of a standard library in node and/or in the micropackaging culture of the ecosystem, yields interest-

ing insights on the way developers build their packages. In this work we view the dependency network of the

npm ecosystem from a “culinary” perspective. We assume that dependencies are the ingredients in a recipe,

which corresponds to the produced software package. We employ network analysis and information retrieval

techniques in order to capture the dependencies that tend to co-occur in the development of npm packages and

identify the communities that have been evolved as the main drivers for npm’s exponential growth.

1 INTRODUCTION

The popularity of JS is constantly increasing, and

along is increasing the popularity of frameworks for

building server (e.g. Node.js), web (e.g. React, Vue.js,

Angular, etc.), desktop (e.g. Electron) or mobile ap-

plications (e.g. React Native, NativeScript, etc.), even

IoT solutions (e.g. Node-RED). A common denom-

inator to this explosive growth has been the launch

of the npm registry (i.e. the package manager of JS)

in 2010. The npm ecosystem is often seen as one of

the JS revolutions

that have transformed JavaScript

from “a language that was adding programming ca-

pabilities to HTML” into a full-blown ecosystem. In

fact, the growth is so rapid that terms like “JS frame-

work fatigue” have become common among develop-

ers. Indicatively, the June 2018 Redmonk survey

the GitHub status report

, and the 2018 Stack Over-

ﬂow survey

position JS as the most popular program-

ming language, while Module Counts

depicts an ex-

ponential growth of npm modules against repositories

of other languages.

Given that dependencies and reusability have be-

https://youtu.be/L-fx2xXSVso

https://redmonk.com/sogrady/2018/08/10/language-

rankings-6-18/

https://octoverse.github.com/

https://insights.stackoverﬂow.com/survey/2018/

http://www.modulecounts.com/

come very important in today’s software develop-

ment process, npm registry has become a “must”

place for developers to share packages, deﬁning code

reuse as a state-of-the-practice development paradigm

(Chatzidimitriou et al., 2018). A white paper by Con-

trast Security (Williams and Dabirsiaghi, 2014) men-

tions that up to 80% of the code in today’s software

applications comes from libraries and frameworks.

This is evident in the npm ecosystem, where the num-

ber of dependencies for a package has been shown to

grow with time (Wittern et al., 2016). There are even

extreme cases, where one-liner libraries have more

than 70 dependencies (Haney, 2016). Such extreme

reusability is usually attributed to the lack of a stan-

dard library in node.js and to the micropackaging cul-

ture of the npm ecosystem.

Against this background, in this work we extract

the collective knowledge and preferences when creat-

ing JavaScript (node.js) packages through mining the

most proliferate module repository, the npm registry.

Inspired by (Teng et al., 2012), we treat packages as

recipes and dependencies as ingredients. Just like a

recipe comprises a list of ingredients along with a pro-

cess on how to combine them, one can consider an

npm package as a recipe: a list of core dependencies

and a list of development dependencies, also known

as devDependencies in the npm lingo, that are com-

bined together with some code that uses them. And

just like online recipes receive reviews and comments,

544

Chatzidimitriou, K., Papamichail, M., Diamantopoulos, T., Oikonomou, N. and Symeonidis, A.

npm Packages as Ingredients: A Recipe-based Approach.

DOI: 10.5220/0007966805440551

In Proceedings of the 14th International Conference on Software Technologies (ICSOFT 2019), pages 544-551

ISBN: 978-989-758-379-7

npm packages have repository stars, forks, watchers

and package downloads, GitHub issues, Stack Over-

ﬂow posts, and so on. This type of information can

provide insights not only about package popularity or

quality but also about user preferences, development

tendencies, and which dependencies go well with oth-

ers. We focus on the following research questions:

• RQ

: Are there any interesting communities (clus-

ters) developed by dependencies that tend to co-

occur together in “recipes”?

• RQ

: Is the same true for devDependencies?

• RQ

: Can we identify the scope these communi-

ties are used for?

• RQ

: What are the similarities or differences be-

tween package recipes (node.js packages of the

npm registry) and application recipes (node.js ap-

plications that are not part of the npm registry)?

By providing answers to these questions we aim to get

a better understanding of how packages work when

used together as dependencies. We can also answer

questions as to which packages mix well together and

for what purpose.

2 BACKGROUND

The npm registry

is the largest and fastest growing

module (or packages in the JS terminology) reposi-

tory of all programming languages. At the moment of

writing it includes more than 800K packages, while

more than 500 are added every day. Packages pub-

lished to the registry must contain a package.json

ﬁle. The main goals of the package.json

ﬁle are:

1. to list the packages that the project depends on.

2. to allow specifying the versions of a package that

the project can use via semantic versioning rules.

3. to make one’s build reproducible, and therefore

much easier to share with other developers.

Among other things, this ﬁle holds information, such

as the package name and version, its description, the

authors, keywords, license, repository, and more.

Besides the dependencies, the package.json ﬁle

contains a devDependencies list that accounts for

packages used while developing the software project

and not included in the “production” build of the

product. Most often, the npm packages are associated

with a GitHub repository, which contains the source

https://www.npmjs.com/

https://docs.npmjs.com/getting-started/using-a-

package.json

code under development and other information (is-

sues, commits, stars, forks, watchers etc.). All the

above hold true for node.js applications as well. That

is, end-user applications that too have dependencies

and devDependencies and allow us to see package us-

age from an application developer viewpoint.

3 METHODOLOGY

The target of our methodology is to distill the knowl-

edge found in the package.json ﬁles of the npm reg-

istry, with respect to their declared dependencies. To

do so, we parse them and extract the dependencies and

devDependencies, the description and keywords that

denote their functionality, along with certain meta-

data regarding package popularity.

We construct four networks in order to capture

developers’ practices about how they combine them:

one that reﬂects the relationships between dependen-

cies and one for devDependencies. This is performed

twice one for npm packages and one for node.js ap-

plications. Upon creating the networks, we employ

cluster detection algorithms in order to ﬁnd communi-

ties of packages that are often used together and apply

information retrieval techniques to the keywords and

description ﬁelds in order to assign keywords of func-

tionality to the communities. Last but not least, we try

to identify if employing frequently used dependencies

has any impact to the popularity of the produced pack-

age in terms of GitHub stars or package downloads.

3.1 The Dataset

In such big open databases like npm, the quality and

usefulness of the packages usually follows a Power

Law

or the Pareto Principle

. So in order to mine

useful, quality packages, we augmented each pack-

age with its monthly download count gathered from

npms.io

and the GitHub stars from the repository

mentioned in the package.json ﬁle.

Using popularity thresholds of 5, 000 monthly

downloads and 70 GitHub stars, we extracted 8, 732

packages. The aforementioned thresholds were not

arbitrarily selected, but were investigated using the

elbow method based on the number of packages that

satisfy them. This number is exponentially increasing

when we further decrease those thresholds. For each

package (recipe) we kept the name, its dependencies

(ingredients), its devDependencies (another type of

https://en.wikipedia.org/wiki/Power law

https://en.wikipedia.org/wiki/Pareto principle

https://api-docs.npms.io/

npm Packages as Ingredients: A Recipe-based Approach

545

ingredients), the keywords and the description ﬁelds

found in the package.json ﬁle, augmented with its

monthly downloads and the GitHub stars of the repos-

itory declared in its package.json ﬁle. We only kept

the name of the package and the names of its de-

pendencies and didn’t consider any declared semantic

version. As for the applications, by crawling GitHub,

we downloaded package.json ﬁles that were con-

tained in the root folder of repositories with more

than 70 stars and their package names did not exist

in the npm registry. Upon applying the aforemen-

tioned methodology, we gathered 13, 884 application

package.json ﬁles. The value of the threshold in

the number of stars was chosen again using the elbow

methods as shown in Figure 1

Figure 1: Choosing the star threshold visually.

We then generated a list sorted by frequency of

dependency occurrence in packages, and selected the

top 1000 most frequent dependencies as our ﬁnal de-

pendency list. In Figure 2 one can see the top 10 most

frequent dependencies, with lodash making an ap-

pearance in 8.1% of the 8686 packages. These de-

pendencies also accounted for 16.8% of dependency

entries in the dataset. For devDependencies, depen-

dency mocha appeared in 2558 packages (29.4%).

Figure 2: Top dependencies of high quality packages.

The dataset with the package.json information

of the retrieved packages and applications can be

found in https://github.com/AuthEceSoftEng/icsoft-2019-

npm-recipes.

3.2 Package Dependencies Complement

Network

We constructed a dependency complement network

based on the Pointwise Mutual Information (PMI) cri-

terion, deﬁned on pairs of dependencies (a, b) as fol-

lows:

PMI(a, b) = log

p(a, b)

p(a)p(b)

(1)

where p(a) and p(b) denote the frequency of pack-

ages containing a and b, respectively, and p(a, b) de-

notes the frequency of packages where a and b co-

occur. More speciﬁcally:

p(a, b) =

# o f packages containing a and b

# o f packages

(2)

p(a) =

# o f packages containing a

# o f packages

(3)

p(b) =

# o f packages containing b

# o f packages

(4)

The PMI is the probability that two dependencies

occur together against the probability that the same

two dependencies occur separately. A high PMI ex-

pects dependencies to occur together far more often

than by chance. After calculating PMI for the top

1000 dependencies in the dataset, we kept only de-

pendencies with high PMI, i.e. a value of more than

6 (maximum PMI was 10.77 between d and es5-ext

and minimum PMI was −3.76 between prop-types

and mkdirp packages). Figure 3 depicts the depen-

dency complementary network

Upon examining Figure 3 without the comple-

mentary colors, it is obvious that the communities are

not clearly visible through plain visualization. In or-

der to make our approach systematic, we have em-

ployed the Girvan-Newman network clustering al-

gorithm (Girvan and Newman, 2002), a hierarchical

method used to detect communities, by progressively

removing edges from the original network. The top-7

in size (number of packages belonging to a commu-

nity), distinct communities are colored in Figure 3.

Each one of them represents a population of more

than 2% of the nodes.

We use the members of the formulated commu-

nities in order to extract their domain of use. To-

wards this direction, we apply information retrieval

techniques on the meta-data of package.json ﬁles.

Graph visualizations and network analyses were per-

formed using the Gephi open source graph visualization

platform (Bastian et al., 2009).

ICSOFT 2019 - 14th International Conference on Software Technologies

546

Figure 3: Dependencies complementary network. Larger

nodes correspond to nodes with higher degree (nodes with

more connections to other nodes).

In speciﬁc, we use the tf–idf (term frequency − in-

verse document frequency) algorithm, which quanti-

ﬁes how important a word is to a document in a corpus

(Salton and Buckley, 1988).

Every cluster corresponds to a corpus, while

its members (packages) correspond to documents.

Each document contains the name (split in keywords

on dashes and slashes), description and keywords

of a package.json ﬁle. Upon removing all stop

words and the keywords npm, node, js, javascript,

package, plugin, we employ tf-idf for each clus-

ter and compute the signiﬁcance of each word as the

average of the corresponding values included in the

term-document matrix. Finally, we apply the elbow

method on the calculated signiﬁcance values to ex-

tract the top keywords that describe the domain. Fig-

ure 4 visualizes the elbow method towards deriving

the top 5 keywords for one of the communities, while

Table 1 depicts the keywords for each community.

The main communities that accounted for more

than 2% of ingredients are those of: general node.js

packages related to webpack and babel (C1), pack-

Table 1: Keywords of function of complement dependency

communities with more than 2% support.

Com. Keywords

C1 webpack, babel, loader, css, module

C2 http, methods, content, parse, utility

C3 stack, line, string, cli, ansi

C4 opcua, sdk, iot, internet, module

C5 lodash, exported, method, module

modularized

C6 simple, authentication, session, web, zip

C7 d3, time, format, module, data

Figure 4: Decision boundary for the keywords to keep.

ages related to web development (C2), cli related

recipes that involve string manipulation (C3), a spe-

cialized community revolving around a node.js IoT

framework, opcua (C4), the lodash community (C5),

the community of tools about web plugins for authen-

tication of session manipulation (C6) and the commu-

nity around d3 development (C7).

In addition, for each package, we calculated the

minimum, average and maximum pairwise PMI be-

tween dependencies, in order to check if complemen-

tary dependencies would yield a better downloads

count or GitHub star count. We have only found

statistically signiﬁcant correlation (statistical signif-

icance 0.043 with a p-value of 0.003) between the

monthly downloads count and the minimum PMI.

This may suggest that having at least two complemen-

tary dependencies could boost the package’s popular-

ity prospects. On the other hand, uncommon depen-

dencies used together do not cause any harm.

3.3 Package Development Dependencies

Complement Network

We repeated the procedure for development de-

pendencies of packages. Again, after calculating

the PMI for the top 1000 devDependencies, we

kept only dependencies with a PMI of 6. The

maximum PMI = 9.92 was found between the

@babel/plugin-proposal-do-expressions and

the @babel/plugin-proposal-logical-assign-

ment-operators packages, while the min-

imum PMI = −5.34 was found between the

@babel/preset-env and the babel-cli packages).

A high PMI value accounts for packages that proba-

bly have been are separated to increase modularity.

Figure 5 shows the devDependencies complementary

network for packages. Table 2 presents the keywords

for the top-10 development dependency communities

identiﬁed.

As for statistical correlations, minimum PMI was

found positively correlated with downloads, maxi-

mum PMI was found positively correlated with stars

and negatively correlated with downloads, while av-

npm Packages as Ingredients: A Recipe-based Approach

547

Figure 5: DevDependencies complementary network.

erage PMI was found positively correlated with stars.

Table 2: Keywords of function of complement development

dependency communities with more than 5% support.

Com. Keywords

C1 loader, vue, webpack, css, eslint

C2 eslint, babel, ﬂow, cli, react

C3 gulp, gulpplugin, stream, git, coverage

C4 grunt, gruntplugin, karma, css, ﬁles

C5 typescript, karma, loader, reporter, copy

C6 ember, cli, addon, eslint, sass

C7 tslint, react, prettier, rules, ﬁle

In devDependencies the communities seem eas-

ier to distinguish, both in terms of the visualization

and in terms of keywords: the vue development re-

lated dependencies (C1), the react ones (C2), the

gulp automation ecosystem (C3), the grunt automa-

tion ecosystem (C4), development packages related to

typescript (C5), the ember web development platform

ecosystem (C6), and a community related to type-

script, linting and react (C7). This is probably due to

the fact that devDependencies are usually added for

the same reasons: task automation, transpiling, com-

piling, bundling, testing, linting etc., whereas produc-

tion dependencies follow the application domain of

the developed package.

3.4 Application Complement Networks

We repeated the same procedure for dependen-

cies found in node.js applications that too have a

package.json ﬁle, although not uploaded in the

npm registry. We crawled 13822 package.json

ﬁles using the GitHub search API. Dependency

react was the top package in appearances found in

2414 applications and eslint was the top appearing

package in devDependencies found in 3141 applica-

tions. Furthermore, the top PMI for dependencies

was achieved by pair grunt-sails-linker and

include-all with 9.67, and pair @babel/plugin-

proposal - nullish - coalescing - operator and

@babel / plugin - proposal - pipeline - operator

with 9.36 for devDependencies. Top pairs exhibit

the micropackaging approach, where developers

split features into smaller and smaller packages

performing simpler and simpler tasks. The lowest

PMI were achieved by the pairs angular-forms-

react-dom with −5.72 for dependencies and

eslint-plugin - import-grunt-contrib - jshint

with −6.32 for devDependencies. These values are

explainable as one would use angular or react for

web development, and eslint of jshint for linting.

Figure 6 and Figure 7 depict the complementary

networks for node.js application dependencies and

devDependencies, respectively. From the ﬁgures one

can observe that communities are easier to distinguish

in applications than in package complementary net-

works, since applications are usually developed for a

speciﬁc sector and use speciﬁc plugins, while pack-

ages are as broadly applicable as possible in order for

the to be as reusable as possible.

Figure 6: Dependencies complementary network for appli-

cations.

Table 3 depicts the 7 largest communities iden-

tiﬁed for application dependencies and Table 4 for

application devDependencies. For the ﬁrst case we

have: general web development utilities like webpack

ICSOFT 2019 - 14th International Conference on Software Technologies

548

Figure 7: DevDependencies complementary network for

applications.

and babel (C1), react-ethereum applications (C2), re-

act web applications with graphql (C3), desktop ap-

plications developed with electron (C4), grunt au-

tomation ecosystem dependencies (C5), gulp automa-

tion ecosystem dependencies (C6) and mobile appli-

cations developed with the cordova framework (C7).

For the devDependencies case we have: ember re-

lated application development (C1), grunt automation

for angular development (C2), babel helper packages

(C3), react development utilities (C4), gulp automa-

tion (C5), angular related application development

(C6) and even more application development utilities

for loading modules dynamically (C7).

Table 3: Function keywords of application dependencies

communities with more than 5% support.

Com. Keywords

C1 webpack, loader, babel, css, eslint

C2 react, ethereum, component, library, utility

C3 react, graphql, apollo, json, link

C4 electron, ﬁle, windows, module, app

C5 gruntplugin, contrib, ﬁles, grunt, express

C6 gulp, browserify, gulpplugin, require

transform

C7 cordova, android, animations, whitelist

ionic

Table 4: Function keywords of application devDependen-

cies communities with more than 4% support.

Com. Keywords

C1 ember, cli, addon, loader, eslint

C2 karma, grunt, angularjs, gruntplugin

angular

C3 babel, es2015, preset, eslint, markdown

C4 react, create, webpack, fetch, preset

C5 bower, html, gulp, gulpplugin, inject

C6 zones, angular (absence of more keywords)

C7 static, css, module, systemjs, build

3.5 Graph Analysis

Last but not least, in an effort to further validate our

results we also examine the networks from a pure

graph analysis perspective. Towards this direction,

we compute the degree, the closeness centrality and

the betweenness centrality metrics.

The closeness centrality quantiﬁes the degree to

which a node is able to spread information through

a graph, while betweenness centrality measures the

importance of nodes in terms of maintaining the in-

tegrity of the formulated network. From a software

engineering perspective, the nodes (packages) that ex-

hibit high closeness centrality are the ones that despite

being direct dependencies of a small number of pack-

ages, these packages appear to be of great importance

and thus indirectly inﬂuence a large number of pack-

ages/applications. As for the betweenness centrality,

the packages that exhibit high values can be consid-

ered the ones that are integral for certain combina-

tion of operations. For instance, the high betweenness

centrality in a middleware package that is required for

back-end testing denotes that whenever a developer

wants to test the back-end of an application, it is vital

to use that certain package. The graph metrics regard-

ing the degree and the betweenness centrality for all

four networks are presented in Table 5. The presented

values refer to the 3 packages with the highest val-

ues for each case. Given that the values for closeness

centrality are normalized, the top packages in all four

networks have a value of 1 and as a result they are not

included.

Upon examining the packages that have the high-

est values regarding both degree and betweenness

centrality, the results that occur are reasonable and

expected from a software engineering perspective.

For instance, in the case of the package dependen-

cies, the package object.values appears to exhibit

the highest betweenness centrality. This is expected

as this package provides an ES2017 spec-compliant

Object.values shim (code that enables two not en-

tirely matching components to work together) and

thus is used by major leading packages. This is also

evident by its number of monthly downloads, which is

more than 15 million. The same applies for the ﬁnd-

ings based on the degree of packages in all four net-

works. In the case of package dependencies, the pack-

ages webpack-dev-server and react-hot-loader

appear to have the highest degree, which is reasonable

as those two packages provide functionality that is vi-

tal in web development such as live reloading and real

time changes in components. Consequently, given the

aforementioned results, the ﬁndings based on graph

analysis metrics come in harmony with the ones ex-

npm Packages as Ingredients: A Recipe-based Approach

549

Table 5: Packages with high valued graph analysis metrics.

Package Degree Package Betweeness

Package dependencies

webpack-dev-server 115 object.values 22865.477

react-hot-loader 115 http-proxy-middleware 8864.721

raw-loader 112 react-hot-loader 7513.229

Package devDependencies

ember-cli-blueprint-test-helpers 43 karma-phantomjs-shim 12521.219

ember-load-initializers 41 karma-ng-html2js-preprocessor 11042.628

ember-resolver 41 jasmine-jquery 10723.319

Application dependencies

gatsby-plugin-google-analytics 37 resize-observer-polyﬁll 32193.66

gatsby-plugin-catch-links 36 babel-plugin-add-module-exports 29276.75

gatsby-plugin-feed 36 @fortawesome/free-brands-svg-icons 25307.09

Application devDependencies

broccoli-assert-rev 29 detect-port 124.16

ember-cli-dependency-checker 29 ﬁlesize 104.85

ember-cli-htmlbars-inline-precompile 29 karma-ng-scenario 95.13

pected from a software engineering perspective.

4 RELATED WORK

There are several works that mine dependency net-

works of different languages and development plat-

forms to understand their properties and evolution.

However, as different ecosystems do not share the

same properties (Decan et al., 2016) and since our fo-

cus is on the npm registry, we review here the related

work only on the npm dependency network.

Wittern et al. (2016) analyzed the evolution of

packages in the npm registry, their dependencies,

their popularity, and the creation and adoption of new

packages. What was particularly interesting and con-

nects to our case is that at that time, 81% of the

packages depended on at least one dependency, while

32.5% of them depended on 6 or more packages with

a steady increase. For our snapshot, at the time of

writing, we found that 61% depended on at least one

dependency and 14% on 6 or more. These may be

fewer packages in terms of percentages but far more

in terms of absolute numbers.

In (Abdalkareem et al., 2017), authors analyzed

the use of trivial npm packages (less that 35 lines of

code and less than 10 McCabe’s cyclomatic complex-

ity) as dependencies in packages and applications.

They found that trivial packages are increasing, while

using them as dependencies is not considered a bad

practice by the majority of developers, especially if

they are well implemented and increase productivity.

Decan et al. (2016) try to identify the differ-

ences in software package ecosystems (CRAN, PyPI,

NPM), though package dependency graphs. Based on

their results, NPM is the one ecosystem that supports

the extreme re-usability and micropackaging culture

by following the single-responsibility principle to the

package level. In (Kikas et al., 2017) authors exhib-

ited that indeed the JS ecosystem is the fastest grow-

ing and has high inter-connectivity between packages.

Finally, Bogart et al. (2016) identiﬁed through inter-

views that developers, in order to make sure their

packages do not break and since they are not al-

ways aware of the status of their dependencies, try to

limit their exposure to them and adopt “best-practice”

packages.

In the context of our work, we view network anal-

ysis of npm dependencies from a completely different

perspective, that of being ingredients to recipes (other

packages). Moreover, our work focuses on identify-

ing packages that work well together as dependencies

in popular packages and thus can help package main-

tainers make their choices, through “trusted ingredi-

ents”.

5 CONCLUSIONS

In this work, we have analyzed dependencies as in-

gredients and packages/applications as recipes, which

is not far from the truth considering the high uti-

ICSOFT 2019 - 14th International Conference on Software Technologies

550

lization of software reuse in npm packages, and the

trivial packaging phenomenon. For each dependency

complement network we have identiﬁed 7 big clusters

used for various purposes. Moreover, we have found

that using development dependencies with high aver-

age complementarity has a positive correlation (0.06)

with the popularity in star counts of npm packages as

a statement of “you know what you are doing”.

From the applications’ analysis, one can observe

as main communities those of web development, mo-

bile development and desktop development. In addi-

tion, no community with respect to data science and

data processing projects was identiﬁed as those are

mainly supported by the Python and R ecosystems.

Other applications of such an approach could be use-

ful in recommender software systems, for instance:

• Through information retrieval techniques devel-

opers can identify packages that work well to-

gether in a domain (for example in linting or test-

ing) using keywords in a search engine.

• If a developer saves packageA as a dependency in

the package.json ﬁle, the system could suggest

to “use packageB along with packageA”.

• We could use the complementary networks to cal-

culate a metric of how well-together our depen-

dencies ﬁt together by summing up the PMI of all

combinations between our “ingredients”.

Last but not least, a common question among devel-

oper forums is which development platform to use,

for example for web application development (e.g.

React?, Vue?, Angular? Ember?). Such an analy-

sis could reveal which platforms are more popular or

the ones that create a closed community that can only

use platform-speciﬁc packages, or even ones that are

more open to connections with third-party libraries.

An idea for future work would be to mine Stack Over-

ﬂow in order to ﬁnd packages that can substitute other

packages and build package substitute networks.

ACKNOWLEDGEMENTS

This research has been co-ﬁnanced by the European

Regional Development Fund of the European Union

and Greek national funds through the Operational

Program Competitiveness, Entrepreneurship and In-

novation, under the call RESEARCH – CREATE –

INNOVATE (project code: T1EDK-02347).

REFERENCES

Abdalkareem, R., Nourry, O., Wehaibi, S., Mujahid, S.,

and Shihab, E. (2017). Why do developers use trivial

packages? an empirical case study on npm. In Proc.

of the 11th Joint Meeting on Foundations of Software

Engineering, pages 385–395, NY, USA. ACM.

Bastian, M., Heymann, S., and Jacomy, M. (2009). Gephi:

An Open Source Software for Exploring and Ma-

nipulating Networks. In Proc. of the Third Interna-

tional AAAI Conference on Weblogs and Social Me-

dia, ICWSM 2009, pages 361–362, Menlo Park, CA,

USA. AAAI Press.

Bogart, C., K

astner, C., Herbsleb, J., and Thung, F. (2016).

How to break an api: Cost negotiation and community

values in three software ecosystems. In Proceedings

of the 2016 24th ACM SIGSOFT International Sym-

posium on Foundations of Software Engineering, FSE

2016, pages 109–120, New York, NY, USA. ACM.

Chatzidimitriou, K. C., Papamichail, M. D., Diamantopou-

los, T., Tsapanos, M., and Symeonidis, A. L. (2018).

Npm-miner: An infrastructure for measuring the qual-

ity of the npm registry. In Proc. of the 15th Interna-

tional Conference on Mining Software Repositories,

MSR ’18, pages 42–45, New York, NY, USA. ACM.

Decan, A., Mens, T., and Claes, M. (2016). On the topology

of package dependency networks: A comparison of

three programming language ecosystems. In Procced-

ings of the 10th European Conference on Software Ar-

chitecture Workshops, ECSAW ’16, pages 21:1–21:4,

New York, NY, USA. ACM.

Girvan, M. and Newman, M. E. J. (2002). Com-

munity structure in social and biological networks.

Proceedings of the National Academy of Sciences,

99(12):7821–7826.

Haney, D. (2016). NPM & left-pad: Have we forgotten how

to program? https://www.davidhaney.io/npm-left-

pad-have-we-forgotten-how-to-program/. Accessed:

2019-01-16.

Kikas, R., Gousios, G., Dumas, M., and Pfahl, D. (2017).

Structure and evolution of package dependency net-

works. In Proceedings of the 14th International Con-

ference on Mining Software Repositories, MSR ’17,

pages 102–112, Piscataway, NJ, USA. IEEE Press.

Salton, G. and Buckley, C. (1988). Term-weighting ap-

proaches in automatic text retrieval. Information pro-

cessing & management, 24(5):513–523.

Teng, C.-Y., Lin, Y.-R., and Adamic, L. A. (2012). Recipe

recommendation using ingredient networks. In Pro-

ceedings of the 4th Annual ACM Web Science Con-

ference, WebSci ’12, pages 298–307, New York, NY,

USA. ACM.

Williams, J. and Dabirsiaghi, A. (2014). The unfortunate

reality of insecure libraries. Technical report, Contrast

Security.

Wittern, E., Suter, P., and Rajagopalan, S. (2016). A look at

the dynamics of the javascript package ecosystem. In

Proceedings of the 13th International Conference on

Mining Software Repositories, MSR ’16, pages 351–

361, New York, NY, USA. ACM.

npm Packages as Ingredients: A Recipe-based Approach

551
