On the Energy Consumption of Quantum-resistant Cryptographic

Software Implementations Suitable for Wireless Sensor Networks

Michael Heigl

1, 2

, Laurin Doerr

1, 2

, Martin Schramm

and Dalibor Fiala

Department of Computer Science and Engineering, University of West Bohemia, Pilsen 301 00, Czech Republic

Institute ProtectIT, Deggendorf Institute of Technology, 94469 Deggendorf, Germany

Keywords: Wireless Sensor Networks, Post-quantum Cryptography, Energy Consumption.

Abstract:

For an effective protection of the communication in Wireless Sensor Networks (WSN) facing e.g. threats

by quantum computers in the near future, it is necessary to examine the applicability of quantum-resistant

mechanisms in this ﬁeld. It is the aim of this article to survey possible candidate schemes utilizable on sensor

nodes and to compare the energy consumption of a selection of freely-available software implementations

using a WSN-ready Texas Instruments CC1350 LaunchPad ARM® Cortex®-M3 microcontroller board.

1 INTRODUCTION

The set consisting of base stations and multiple tiny

autonomous devices interconnected via an ad-hoc

communication is called WSN. Nowadays, they have

permeated many technological areas mainly driven by

the Internet of Things (IoT). The sensor nodes are

composed of a microcontroller, a radio transceiver,

a power supply (typically battery-powered), memory

and one or more sensors to collect data from the im-

mediate environment and transmit it wirelessly. Ap-

plication areas are boosted by the IoT ranging from

simple measurements of environmental data such as

temperature or smoke towards IoT-enabled Smart

Cars (Bartolomeu et al., 2018).

The ever-increasing and more advanced attack

capabilities and strategies pose an enormous chal-

lenge and demand IT-security for WSN in the near

future. The sophistication of attacks utilizing dis-

tributed, cloud or even quantum computation (Sen,

2013) forces classical IT-security to change into sus-

tainable cyber resilience. However, the application of

viable cryptographic schemes vital for holistic secu-

rity solutions are often seen as an undesirable over-

head cost and therefore neglected in the design of

WSN. Due to the inherent resource limitations in

terms of memory size, processing speed as well as

energy consumption, attacks towards WSN are man-

ifold (Costa et al., 2017). Because of the open com-

munication nature of the wireless radio channel, at-

tackers can easily eavesdrop on, intercept, inject and

forge the exchanged information. Especially when

it comes to the transmission of conﬁdential informa-

tion, for instance measurements in the medical or mil-

itary area, cryptographic schemes are inevitable to

preserve the protection goals conﬁdentiality, integrity

and authenticity. The application of these schemes on

the other side still imposes several limitations since

the known resource issues and other constraints pre-

sented in (Sen, 2013) inhibit the deployment in WSN.

Furthermore, with the advent of quantum comput-

ers, quantum computation will have a tremendous im-

pact on a major ﬁeld of cryptography not only erupt-

ing WSN-security. It has the potential to break or

weaken asymmetric schemes including the Elliptic-

Curve Difﬁe-Hellman (ECDH) key exchange often

applied in the embedded domain.

Thus, in this work possible state-of-the-art cryp-

tographic schemes are proposed which are resistant

to the power of quantum computers. A selection of

freely-available software implementation candidates

are integrated on a WSN-ready microcontroller board

and evaluated in terms of their applicability in WSN.

The remainder of this paper is structured as follows:

Section 2 discusses the threats from quantum comput-

ers towards cryptographic schemes. A state-of-the-art

review on cryptographic mechanisms with regard to

quantum-resistance for WSN is provided in Section 3.

Details on the measurement setup and integration of a

selection of freely-available software implementation

candidates on the Texas Instruments CC1350 Launch-

Pad microcontroller board are presented in Section 4.

The evaluation in Section 5 deals with energy con-

sumption measurements with respect to fundamental

cryptographic components and discusses their com-

putational and communication cost. A short conclu-

sion and a glance at the future work of the ongoing

research work ﬁnalizes the article in Section 6.

Heigl, M., Doerr, L., Schramm, M. and Fiala, D.

On the Energy Consumption of Quantum-resistant Cryptographic Software Implementations Suitable for Wireless Sensor Networks.

DOI: 10.5220/0007835600720083

In Proceedings of the 16th International Joint Conference on e-Business and Telecommunications (ICETE 2019), pages 72-83

ISBN: 978-989-758-378-0

2 QUANTUM NERVOUSNESS

Quantum computing is founded on the microscopic

physical phenomena of quantum mechanics. Instead

of using bits with observed states 0 and 1 on contem-

porary computers, quantum computers are based on

quantum bits (qubits). Qubits are particles that can

exist in both states simultaneously, by the effect of

superposition, and are able to exploit true parallelism

due to quantum entanglement (Jozsa, 1997). In the

era of having ﬁrst viable quantum computers, the so-

called quantum nervousness begins and represents a

new type of threat for cryptography in general.

Shor’s algorithm (Shor, 1997) makes use of the

quantum Fourier transform to extract the required in-

formation from the superposition of quantum states

which allows to break all contemporary asymmet-

ric cryptography such as RSA, DSA or Elliptic-

Curve Cryptography (ECC) based schemes. Espe-

cially ECC is widely deployed in IoT-environments

due to the more efﬁcient arithmetic, low memory

usage, shorter key sizes and lower CPU consump-

tion compared to RSA or DSA (Mani and Nishamol,

2013). Even if asymmetric cryptography with ade-

quate key sizes (BSI, 2018) is considered very safe

today, the underlying mathematical problems such as

efﬁcient integer factorization e.g. in RSA or the cal-

culation of the discrete logarithm e.g. in ECC can be

solved with Shor’s algorithm in a reasonable amount

of time if a powerful quantum computer can be uti-

lized. Even if such efﬁcient machines are currently

far from being practically feasible, the NIST states

that a quantum computer capable of breaking RSA-

2048 or ECC-256 in a matter of hours could be built

by 2030 (NIST, 2016).

A breakthrough has recently been announced by

Google regarding its 72-qubit capable Bristlecone

paving the way for large scale quantum comput-

ers (Kelly, 2018). Those will also affect symmet-

ric cryptography such as AES. Even if Grover’s al-

gorithm (Grover, 1996) has been initially intended to

search unsorted databases, it can be applied to crack

symmetric ciphers. However, the impact is far less

than with Shor’s algorithm since currently it is as-

sumed that doubling the key length mitigates its harm.

According to the authors of (Amy et al., 2016), cryp-

tographic hash functions are not affected by quan-

tum computers. They state that both SHA-256 and

SHA3-256 need around 2166 logical qubit cycles to

be cracked and even if the quantum correction is han-

dled by hardware, running at a few million hashes

per second, Grover’s algorithm would still need about

1032 years.

3 CRYPTOGRAPHY FOR WSN

The protection of communicated data in WSN to

achieve the stated security goals is mainly founded on

hash functions, symmetric-key and asymmetric-key

algorithms composed of the following crucial com-

ponents: message authentication, message encryption

/ decryption, key exchange, digital signature. Es-

pecially with the threat of quantum computers to-

wards asymmetric cryptography, practical alternatives

for contemporary schemes in WSN such as ECDH or

DSA must be researched.

Post-quantum cryptography (PQC) refers to cryp-

tographic schemes that can function on classical

non-quantum machines but promise to withstand

the impact of Shor’s or Grover’s algorithm run-

ning on quantum-accelerated computers. Several

different families of PQC are presented in (Bern-

stein et al., 2009) including hash-based, code-

based, lattice-based, multivariate-quadratic-equations

and secret-key cryptography. Supersingular elliptic-

curve isogeny cryptography is much closer to classi-

cal ECDH-schemes, but it is very young and not well

researched (Bogomolec and Gerhard, 2018).

Recommendations for cryptographic schemes to

be used in the quantum-era, not intended for embed-

ded domains, are provided by (PQCRYPTO, 2015).

Even if some PQC software implementations aimed

for low-cost devices exist (Xu et al., 2018), a major

demerit is the poor resource-efﬁciency especially in

terms of communication overhead of most of the post-

quantum schemes compared to contemporary cryp-

tography which makes them hardly applicable on

resource-constrained devices. Another uncertainty

with PQC is that there could be a currently unknown

algorithm that breaks even such schemes in the near

future. Thus, a combination with contemporarily used

mechanisms could be a possible tradeoff. An exam-

ple is Google’s CECPQ1 which is a key exchange that

concatenates the results of an X25519 and NewHope

key exchange. X25519 is a Difﬁe-Hellman-based key

exchange applying Curve25519.

The following sections discuss the cryptographic

key components with respect to the application in

WSN by stating contemporary applied schemes and

possible PQC-alternatives. With respect to the secu-

rity level, schemes providing 128-bit will be consid-

ered, since the 112-bit security level should be phased

out by 2031 (NIST, 2016). For each key component

respective candidate software implementations appli-

cable on resource-constrained devices are identiﬁed,

later compared and evaluated.

On the Energy Consumption of Quantum-resistant Cryptographic Software Implementations Suitable for Wireless Sensor Networks

3.1 Message Authentication

Message Authentication Codes (MAC) are used to

achieve message integrity and authentication. MACs

are used to identify unauthorized and corrupted mes-

sages and can be either deﬁned over symmetric ci-

phers as modes of operation or, more commonly, on

one-way hash functions such as HMACs. Regarding

the threat of quantum computers, HMAC is demon-

strably resistant (to 128-bit security level) even if

an adversary can obtain the MAC of chosen mes-

sages, under weak hypothesis for SHA-256 (Bellare,

2015). Alternatives for assembly-optimized HMACs

targeted for WSN environments are for instance

the lightweight MAC Chaskey proposed in (Mouha

et al., 2014), the LMAC of (Chowdhury and Das-

Bit, 2015), the LightMAC (Luykx et al., 2016) or an

assembly-optimized Poly1305. Recommended by the

PQCRYPTO project are the GCM mode of AES us-

ing a 96-bit nonce and an 128-bit authenticator and

Poly1305 (PQCRYPTO, 2015).

3.2 Message Encryption / Decryption

Symmetric cipher schemes are mainly used for mes-

sage encryption / decryption and can be gener-

ally divided into block ciphers (e.g. AES, RC5,

RC6, Skip Jack, HIGHT, BSPN) and stream ci-

phers (RC4, Sosemanuk, HC-128, Dragon, LEX or

Salsa20/ChaCha20) (Karuppiah and Rajaram, 2012;

Zhang et al., 2012; Meiser et al., 2008). The re-

quirements of symmetric schemes with respect to

WSN are energy consumption, program memory

(storage), temporary memory (RAM) and execution

time (Karuppiah and Rajaram, 2012). In (Meiser

et al., 2008) various schemes have been implemented

in assembler and ported to an 8-bit AVR microcon-

troller. Considering the encryption speed, all stream

ciphers except Salsa20 outperformed AES and, in

terms of memory needs, Salsa20 and LEX are al-

most as compact as AES. For high throughput re-

quirements, Sosamuk turned out to be the most suit-

able cipher if its considerable higher memory needs

can be tolerated. The authors of (Zhang et al., 2012)

compared different block and stream ciphers in soft-

ware and suggest that utilizing AES achieves bet-

ter performance for a wide range of channel qual-

ities and provides signiﬁcant improvement in en-

ergy efﬁciency compared to other schemes. The

PQCRYPTO project recommends the AES-256 and

Salsa20 with a 256-bit key. Assembly-optimized

Salsa20 or the assembly-supported AES as shown

in (Schwabe and Ko, 2017) seem to be promising

candidates for quantum-resistant WSN-devices. Both

providing a 256-bit security level which guarantees

sufﬁcient security for encryption / decryption even in

the presence of moderate quantum computers.

3.3 Key Exchange

Key management in WSN is a systematic process

consisting of the key deployment/pre-distribution, the

key agreement as an authenticated key exchange,

the member/node addition, the member/node evic-

tion and the key revocation (Kumaran et al., 2016).

The obtained shared secret can then be used to de-

rive a symmetric message encryption key. Protocols

for key management in WSN are discussed in (Sen,

2013) and for key agreements in (Kumaran et al.,

2016). Those comprise methods using symmetric-

keys, asymmetric-key agreements as well as ones uti-

lizing a trusted third party. Symmetric schemes re-

quire less computing power but suffer from the issue

of an initial key exchange over an insecure channel.

In addition to this, the problem occurs when the num-

ber of nodes in a WSN changes dynamically. Using a

trusted third party is also unattractive since large sen-

sor networks are characterized by multi-hop commu-

nication and demand more energy compared to asym-

metric solutions. Most widely deployed in WSN are

ECDH variants which allow two parties, each having

an elliptic-curve key pair, to establish a shared secret

over an insecure channel. However, many implemen-

tations, e.g. (Mani and Nishamol, 2013), are based on

curves such as secp160r1. According to the SEC 2

(Certicom Research, 2000) standard they do not guar-

antee adequate security and referring to the German

BSI (BSI, 2018), the use of mechanisms that achieve

a security level of at least 120 bits is recommended

for the prediction period beyond the end of 2022.

PQC key exchange mechanisms, in the following

including key encapsulation mechanisms, based on

lattices, e.g. Frodo, Kyber, Round5, some of them im-

plemented in the Open Quantum Safe project (Open

Quantum Safe Project, 2018), are not optimized for

the usage in WSN (ETSI, 2017). For SIDH or

SIKE currently only an implementation for the ARM

Cortex-A15 and Cortex-A8 has been optimized uti-

lizing the NEON instruction set (Jalali et al., 2018;

Seo et al., 2018). Even if a prominent PQC-ready ex-

ample, NTRU, could be used for a key exchange as

proposed in (Lei and Liao, 2013), it is associated not

only with a large computational cost but also with a

high communication overhead due to large key sizes.

Meanwhile an implementation of the NTRUEncrypt

public-key cryptographic scheme exists, which can

be used for a NTRU key exchange, optimized for

a Cortex-M0 microcontroller, but no source code is

SECRYPT 2019 - 16th International Conference on Security and Cryptography

publicly available (Guillen et al., 2017). It is not

only suitable for use in battery-operated devices but

also patents on the cryptosystem expired in 2017 or

will expire in 2021 respectively. With various generic

and platform-speciﬁc optimization, promising candi-

dates for an IoT-enabled post-quantum key exchange

guaranteeing 128-bits of post-quantum security are

NewHope (Xu et al., 2018) or Saber which both have

been ported to ARM Cortex-M architectures (Alkim

et al., 2016; Karmakar et al., 2018). In addition,

NewHope and Saber are among the 17 second-round

candidates for key exchange algorithms of NIST’s

PQC standardization process (NIST, 2019). Even if

according to (Alkim et al., 2016) NewHope outper-

forms ECDH implementations in terms of execution

time, the large number of bytes to be exchanged in

both algorithms must be considered in terms of tim-

ing and energy consumption.

3.4 Digital Signature

Digital signatures based on public key cryptography

are necessary in order to authenticate for instance

the key exchange process. In contrast to message

authentication and encryption / decryption schemes,

the requirements regarding memory or execution time

are smaller since signing and verifying messages in

WSN is often only used for partner identiﬁcation

during the initial key exchange or key renewal pro-

cess. Mainly applied in WSN are ECDSA variants

due to their efﬁciency (Ateniese et al., 2017). How-

ever, since also belonging to asymmetric schemes

founded on the discrete logarithm problem, the men-

tioned approaches provide no protection in the era

of quantum computers. Possible PQC schemes with

regard to (NIST, 2019) based on lattices are Fal-

con, Dilithium and qTesla. Multivariate-based signa-

ture schemes are GeMSS, LUOV, MQDSS or Rain-

bow. However, recent work shows the vulnerabil-

ity of lattice-based signature schemes to differential

fault attacks (Bruinderink and Pessl, 2018). Tar-

geted to WSN, the PQM4 library provides candidate

implementations for the Cortex-M4 (PQM4, 2019)

and (G

uneysu et al., 2018) focuses on implementa-

tions of GLP, BLISS and Dilithium for the M4 which

do not claim protection against side-channel attacks.

The work in (Margi et al., 2017) compares differ-

ent post-quantum signature schemes on a 128-bit se-

curity level. The most prominent ones are either

based on lattices such as NTRUSign (Driessen, 2007),

BLISS (Howe et al., 2015) or on hash functions such

as extended Merkle’s signature scheme (XMSS) with

similar approaches for IoT-environments (Pereira

et al., 2016) or ARMed SPHINCS (H

ulsing et al.,

2016). Compared for instance to lattice-based PQC-

schemes, hash-based signatures are well understood

and the security relies on the underlying and thus

very well studied security of hash functions. XMSS

and SPHINCS are recommended by the PQCRYPTO

project. Especially ARMed SPHINCS based on

SPHINCS-256 is a promising implementation for the

use on embedded systems. It is a high-security

post-quantum stateless hash-based signature scheme

and provides an effective replacement for signa-

tures by combining XMSS and other techniques to

overcome the drawback of statefulness of XMSS.

SPHINCS+ is furthermore among the 9 second-

round candidates for digital signatures of NIST’s PQC

standardization process (NIST, 2019). Even if the

most advanced approaches for practical hash-based

signatures SPHINCS-256 and the multi-tree variant

XMSS

are well studied hash-based schemes, re-

cent work shows different attacks on them (Kannwis-

cher et al., 2018).

4 MEASUREMENT SETUP

The evaluation of various freely-available crypto-

graphic software implementations is performed us-

ing LaunchPad boards equipped with a 32-bit ARM

Cortex-M3 processor. The scope of the evaluation

are measurements regarding the energy consumption

such that a statement on the applicability of quantum-

resistant schemes for WSN can be made. Thus, in the

case of asymmetric schemes, especially threatened by

Shor’s algorithm, a comparison with contemporary

mechanisms in terms of computational and communi-

cation cost is conducted. For programming the boards

via the onboard debugger, the Code Composer Stu-

dio in Version 8.0.0.00016 has been used. As basis

projects, rfEasyLinkEchoTx and rfEasyLinkEchoRx

are used from the Texas Instruments TI Resource Ex-

plorer which demonstrate the usage of the EasyLink

API. A DC voltage source providing V

= 3.3 V is

used to source one board with an interconnected low-

side shunt resistor of R = 10 Ω. A 1 GHz oscillo-

scope with a maximum of 20 GS/s is used together

with a passive probe to measure the voltage drop over

the shunt in order to compute the energy consump-

tion. The oscilloscope settings are DC coupling with

1 MΩ, an ERES noise ﬁlter +3bits, a sinx/x interpola-

tion, a trigger slope with rising edge and time settings

with maximum sample points of 500 kS/s with real-

time sampling and a delay of 1.6 s. In order to only

measure the energy consumption of the CC1350, the

onboard debugger needs to be disconnected.

The reference project was extended with the rel-

On the Energy Consumption of Quantum-resistant Cryptographic Software Implementations Suitable for Wireless Sensor Networks

evant source ﬁles of each cryptographic software im-

plementation. The task functionality for transmitting

and receiving was disabled for the following mea-

surements since these where easier without the power

management of TI-RTOS. Therefore, for each library,

a dedicated test function is executed after initializa-

tion performing the relevant cryptographic algorithm.

Each oscilloscope diagram shows two curves. For

signal C1, a voltage drop at the beginning based on

the switching off of an onboard LED signals the start

of the respective cryptographic functions. After the

start and between each relevant function some delays

of simple nop-commands in assembler are introduced

in order to measure each cryptographic component in

the zoomed curve Z1 of signal C1. During the idle

phases, a voltage of approximately 76 mV is mea-

sured resulting in a current of 7.6 mA.

5 EVALUATION

The following candidates of freely-available soft-

ware implementations have been selected for eval-

uation on the candidate WSN board with respect

to the cryptographic key components of Section 3.

Even if ARM Cortex-M0 and M4 microcontrollers

are very popular for realizing IoT-applications (Kar-

makar et al., 2018), the evaluation using a Cortex-M3

whose instruction set is only downwards compatible

excludes the utilization of M4-optimized implemen-

tations to be more restrictive in terms of resources

for WSN. For the sake of comparison, even if not

quantum-resistant, some ECC-based implementations

for asymmetric schemes have been chosen. For eval-

uating different MAC candidates, the LightMAC

im-

plementation based on the publication (Luykx et al.,

2016), Chaskey

and HMAC as well as Poly1305 both

taken from the embedded-optimized cifra

library do-

nated as HMAC SHA-256

cifra

and Poly1305

cifra

have

been utilized. Comparative energy consumption re-

sults on different processor architectures can be found

in (Chowdhury and DasBit, 2015). For symmetric

message encryption / decryption, the tiny AES

, the

assembly-supported AES on ARM Cortex-M3/M4

aes-armcortexm

library from the paper (Schwabe

and Ko, 2017), the Salsa20

cifra

taken from the cifra

library and the assembly-optimized chacha20

ARM

https://github.com/SebMertz/LightMAC

https://mouha.be/chaskey/

https://github.com/ctz/cifra

https://github.com/bricke/tiny-AES-C

https://github.com/Ko-/aes-armcortexm

https://gitlab.science.ru.nl/mneikes/arm-chacha20/

tree/master

library of the cipher ChaCha20 have been tested.

For comparing with implementations on a 133

MHz StrongARM processor refer to the results

of (Großsch

adl et al., 2007). For evaluating a

software-based key exchange process between two

boards, the SafeCurve (Bernstein and Lange, 2014)

implementation of an X25519 curve25519-donna

ANSI C, the assembly-supported ECDH

micro-ecc

li-

brary having an ECDH function and the post-quantum

algorithms Saber

ARM

and NewHope

ARM

optimized

for ARM Cortex-M0 have been selected. Com-

parative results on the energy consumption utiliz-

ing different processor architectures can be found

in (Moon et al., 2016; Großsch

adl et al., 2007;

Bianchi et al., 2010). For the testing of signature

generation and veriﬁcation, the assembly-supported

ECDSA

micro-ecc

library having an ECDSA function,

the C implementation lamport-OTS

of the crypto-

graphic Lamport-style One-Time-Signatures (OTS),

the implementation SPHINCS

Port.

with the aim to

port ARMed SPHINCS on a Cortex-M3 based on the

source code of the paper (H

ulsing et al., 2016) and

the Shorter Merkle Signatures

implementation of

the paper (Pereira et al., 2016) have been chosen.

For comparing with implementations on other proces-

sor architectures refer to the results of (Rehana et al.,

2010; Rehana et al., 2012; Ateniese et al., 2017).

5.1 Message Authentication

For each message authentication evaluation 64 bytes

of input data have been used. In Figure 1 an exem-

plary plot of the oscilloscope output for the HMAC

SHA-256

cifra

implementation is shown. The upper

curve (signal C1) of Figure 1 shows the measured

voltage of one MAC computation on a single board

and signal Z1 the zoomed square wave of the MAC

signal in more detail. The average amplitude of the

signal for only message authentication is approxi-

mately 528 µA and the duration 3.52 ms. Thus, the

energy consumption only for message authentication

is approximately 6.13 µJ. For the sake of comparison

with the symmetric ciphers, the 64 byte results are

converted to 16 bytes resulting in a message authen-

tication taking approximately 880 µs and consuming

https://github.com/agl/curve25519-donna

https://github.com/kmackay/micro-ecc

https://github.com/KULeuven-COSIC/SABER/tree/

master/SABER ARM

https://github.com/newhopearm/newhopearm

https://github.com/m0jo/lamport-OTS

https://github.com/AymericGenet/SPHINCS-

arduinodue

https://github.com/puodzius/shorter-hash-signatures

SECRYPT 2019 - 16th International Conference on Security and Cryptography

about 1.53 µJ. Including the board energy consump-

tion for the execution of the message authentication

this results in approximately 23.6 µJ.

Figure 1: Measurement of HMAC SHA-256

cifra

message

authentication.

Table 1 summarizes the measurements for the

MAC implementations. Information is represented in

Table 1 as follows. The column labelled “Library”

gives the name of the used message authentication

library. The total time the message authentication

takes for 64 bytes is provided with column “Time”.

The column “Energy” provides information about the

energy consumption only of the message authentica-

tion without considering the total board energy con-

sumption. Thus, column “Total” of Table 1 provides

the total energy consumption of the tested schemes

on the CC1350 board for an idle current of 7.6 mA

computed for the execution time of each algorithm

excluding delays. For the sake of comparison with

the symmetric cipher schemes, the column “Total

”

lists the naively computed values for the total board

energy consumption of generating message authenti-

cation codes from 16 bytes input data. The imple-

mentations of the widely accepted SHA-256 HMAC

and Poly1305 of the cifra library perform quite sim-

ilar in terms of energy consumption and execution

time. The lightweight implementations Chaskey and

LightMAC, however, outperform the others. Espe-

cially LightMAC is a good candidate to be applied

for WSN in terms of energy consumption.

5.2 Message Encryption / Decryption

For AES-based libraries, AES-256 has been cho-

sen since, if a moderate quantum computer utilizing

Grover’s algorithm is realized, it seems prudent to

move away from 128-bit keys (Grassla et al., 2016).

In Figure 2 an exemplary plot for the Salsa20

cifra

mea-

surement is shown. The upper curve (signal C1) of

Figure 2 shows the measured voltage of one encryp-

tion and decryption. The key setup and initialization

vector setting function had no inﬂuence on the mea-

sured signal and thus has been neglected. Signal Z1

shows the zoomed square wave of the encryption /

decryption signal in more detail. The average am-

plitude of the signal is approximately 460 µA and

the duration 22.6 ms. Thus, the computed values for

16 bytes referring to one block in AES is approxi-

mately 88.28 µs. The energy consumption for the en-

cryption of one block only is approximately 134 nJ.

Figure 2: Measurement of Salsa20

cifra

encryption / decryp-

tion.

Table 2 summarizes the measurements for the

symmetric cipher schemes. For AES schemes, the

column “Type” names the used AES bit sizes and the

respective applied modes. In the column “Time” the

total time for encryption (enc) and decryption (dec)

is provided. It is clear that the aes-armcortexm li-

brary greatly outperforms tiny AES since it is an

assembly-supported library presented in (Schwabe

and Ko, 2017) for the ARM Cortex-M3 and M4.

However, in terms of energy consumption tiny AES

is competitive to the weaker AES-128 implementa-

tion presented in (Großsch

adl et al., 2007) whose en-

cryption and decryption for one 128-bit block requires

approximately 13.9 µJ. In contrast energy costs for

both tiny AES modes are less than 10 µJ. However,

in terms of execution time tiny AES is inferior. The

ChaCha20 stream cipher achieves good performance

which is almost competitive to the aes-armcortexm

block cipher and slightly better than the Salsa20 im-

plementation. In terms of energy cost both schemes

outperform the implementation of (Großsch

adl et al.,

2007) by a factor greater than 70 (for chacha20

ARM

)

and 150 (for aes-armcortexm). It must be noted that

the chacha20

ARM

library is optimized for the Cortex-

M0 whereas the aes-armcortexm library is aimed at

the more powerful Cortex-M3 and M4, thus, a direct

comparison is not possible with the used libraries.

5.3 Key Exchange

In Figure 3 an exemplary plot for the practical

ARM Cortex-M0 ported NewHope implementation

is shown. The upper curve (signal C1) of Figure 3

shows the measured voltage of the relevant key encap-

sulation computations on a single board. The random

byte generation at the beginning of the algorithm has

been neglected. Signal Z1 shows the zoomed square

wave of the key exchange components in more detail.

Those are not equal in terms of amplitude and dura-

tion as it is the case with other libraries. The average

On the Energy Consumption of Quantum-resistant Cryptographic Software Implementations Suitable for Wireless Sensor Networks

Table 1: Summary of the measurements regarding the message authentication schemes.

Library Time (ms) Energy (µJ) Total (µJ) Total

(µJ)

HMAC SHA-256

cifra

3.52 6.13 94.40 23.6

Poly1305

cifra

3.55 5.93 94.96 23.74

Chaskey 2.24 2.63 58.81 14.7

LightMAC 0.65 0.47 16.77 4.19

Table 2: Summary of the measurements regarding the symmetric cipher schemes.

Library Type Time (µs) enc/dec Energy (nJ) Total (µJ)

tiny AES AES-256 CBC 1290/8000 1610/3990 33.96/204.6

Salsa20

cifra

Salsa20 88.28/88.28 134/134 2.35/2.35

chacha20

ARM

ChaCha20 50.78/50.78 92.95/92.95 1.37/1.37

aes-armcortexm AES-256 CTR 25.98/29.96 20.73/24.50 0.67/0.76

amplitude of the signal executing the key generation

is approximately 465 µA and the duration 35.7 ms.

The average amplitude of the signal executing one

partners’ shared secret is approximately 515 µA and

the length 54.8 ms. The average amplitude of the sig-

nal executing the other partners’ shared secret is ap-

proximately 294 µA and the duration 9.5 ms. The

key exchange excluding the introduced delays and

transmitting as well as receiving operations between

two parties takes approximately 100 ms. The energy

consumed by the key exchange yields approximately

0.15 mJ.

Figure 3: Measurement of NewHope

ARM

key exchange.

It must be noted that in contrast to NewHope’s

three relevant key exchange computations necessary

for the key encapsulation mechanism (key gener-

ation, encapsulation and decapsulation), ephemeral

ECDH-based key exchange protocols are composed

of four computationally expensive scalar multiplica-

tions. The security strength of the used key exchange

schemes must be comparable. For this reason, to com-

pare the elliptic curve based implementations with the

PQC ones, elliptic curves offering 128 bit security

were chosen. Thus, for the ECDH

micro-ecc

library the

curve secp256r1 was utilized. Apart from the chosen

elliptic curves from the SEC 2 standard, Curve25519

offers 128 bits of security as well and in contrast to

the other libraries is a representative of a safe elliptic

curve (Bernstein and Lange, 2014). Table 3 summa-

rizes the measurements for the key exchange libraries

each having a security strength of 128 bit. “Curve”

names the used curves for the ECC-based libraries.

Curve25519 is not only considered a safe curve

but also signiﬁcantly faster for the use in ECDH oper-

ations. The plain execution time of a key exchange on

a single board takes approximately 1.48 s. For this li-

brary the power consumption is the highest of all eval-

uated ones, but the energy and total consumption is

moderate. It must be noted that the curve25519-donna

library is not using any assembly and is comparable to

the assembly-optimized ones. The key exchange with

the secp256r1 curve of ECDH

micro-ecc

for instance

takes approximately 1.2 s and is slightly more efﬁ-

cient in terms of power and energy consumption than

Curve25519. NewHope

ARM

outperforms the succes-

sive libraries in all metrics. It is optimized in all

performance-critical routines for constrained devices

in ARM assembly. Because of this optimization,

the key exchange lasts only approximately 100 ms

and is more efﬁcient than ECDH

micro-ecc

by a fac-

tor of 10. Saber is comparable to ECDH

micro-ecc

but

inferior to NewHope’s results. However, Saber

ARM

is CCA-secure in contrast to NewHope

ARM

. A

good and secure competitor to NewHope would

be an assembly-supported curve25519-donna library.

In (D

ull et al., 2015) curve operations in assembly are

presented for different microcontroller architectures,

which would signiﬁcantly speed up the curve25519-

donna library. However, according to a comparison

mentioned in (Alkim et al., 2016), the NewHope im-

plementation still outperforms Curve25519 of (D

ull

et al., 2015) by more than a factor of two. Following

the example of CECPQ1, a combination of an assem-

bly CCA-secure NewHope with an optimized X25519

would be a reliable solution for WSN.

SECRYPT 2019 - 16th International Conference on Security and Cryptography

Table 3: Summary of the measurements regarding the key exchange schemes.

Library Curve Time (s) Energy (mJ) Total (mJ)

curve25519-donna Curve25519 1.48 (4 x 370 ms) 4.05 41.17

ECDH

micro-ecc

secp256r1 1.20 (4 x 300 ms) 1.78 31.88

Saber

ARM

- 1.15 (292 ms / 390 ms / 472 ms) 1.51 30.44

NewHope

ARM

- 0.10 (35.7 ms / 54.8 ms / 9.5 ms) 0.15 2.66

5.4 Digital Signature

In this evaluation some of the less publicly avail-

able implementations for digitally signing and veri-

fying on embedded devices are tested. In Figure 4

an exemplary plot for the ECDSA implementation

of the micro-ecc library is shown. ECDSA

micro-ecc

was tested for signature generation and veriﬁcation

of 32 bytes based on ECC curve secp256r1 on the

CC1350 board. The upper curve (signal C1) of Fig-

ure 4 shows the measured voltage of the key gen-

eration, signature generation and signature veriﬁca-

tion. Signal Z1 shows the zoomed square waves of the

components in more detail. The average amplitude of

the signals is approximately 415 µA. The execution

time for key generation is about 313 ms, for signature

generation about 364 ms and for signature veriﬁcation

about 340 ms. Thus, the energy consumption is ap-

proximately 429 µJ, 498 µJ and 466 µJ. Including the

board energy consumption the cost is approximately

8.3 mJ, 9.6 mJ and 9.0 mJ.

Figure 4: Measurement of ECDSA

micro-ecc

digital signa-

ture.

The most promising implementation targeted for

an ARM Cortex-M3 is ARMed SPHINCS presented

in (H

ulsing et al., 2016). However, the provided

source code is not directly applicable for the CC1350

since it is optimized for the STM32L1 sensor node.

The portation SPHINCS

Port.

for the Arduino Duo

board was used for the evaluation with the provided

parameter set. Unfortunately, the veriﬁcation func-

tion has not been ported so far and the library cur-

rently does only implement the plain SPHINCS-256

without any optimization. It must further be noted

that SPHINCS has many parameters to adjust because

of the composition of other schemes which makes it

quite complex for a practical usage. The lamport-OTS

implementation is for educational use and was tested

for signature generation and veriﬁcation of 32 bit.

The weak hash function in the reference code has

been replaced by the cryptographically secure SHA-

256 implementation

. The Shorter Merkle Signature

implementation of the scheme presented in (Pereira

et al., 2016) was tested for signature generation and

veriﬁcation of 32 bytes on the CC1350 board. Pa-

rameters have been adjusted because otherwise the

execution would take too long. Those include the

tree height with value 5, the MSS K with value 3

of the treehash algorithm BDS being used and the

W INT ERNIT Z W parameter with value 2 for a sig-

nature size speed tradeoff. The parameter set allows

the generation of 32 signatures and the ﬁrst signature

was used for signing and verifying. If the n-th signa-

ture is used, the process will take longer for larger n.

The key generation process with larger parameter set-

tings to create more signatures takes quite long but the

signature generation and veriﬁcation is signiﬁcantly

faster in comparison (minutes vs. seconds). Thus, it

might be possible to perform the key generation and

distribution to sensor nodes a priori.

Table 4 summarizes the measurements for signa-

ture generation and veriﬁcation schemes. The total

time the key generation, signature generation and ver-

iﬁcation takes is provided with the columns “Time”

(key/sig/ver). The easiest form on which hash-based

signatures are founded on are OTS whose key pair can

only be used once. To sign multiple messages, Merkle

trees composed of many OTS are proposed. The im-

plementation lamport-OTS outperforms the other im-

plementations but has severe drawbacks which makes

it unpractical. Not only the one-time usage of a key

pair is a problem but also if multiple keys are gen-

erated in advance, one must keep track of a large

number of signatures. Therefore, the Shorter Merkle

Signatures and the ARMed SPHINCS portation have

been proposed. Due to the high timing cost for sign-

ing of about 200 s, SPHINCS

Port.

is not practically ap-

plicable. Even if the timing aspect for the public key

authentication process is not critical, since it does not

happen often, the signing time in the original paper of

approximately 18.41 s is still too much. The reason

behind the signiﬁcant lack in performance lies in the

cost for eliminating the state which makes SPHINCS

https://github.com/B-Con/crypto-algorithms

On the Energy Consumption of Quantum-resistant Cryptographic Software Implementations Suitable for Wireless Sensor Networks

Table 4: Summary of the measurements regarding the digital signature schemes.

Library Time (s) key/sig/ver Energy (mJ) key/sig/ver Total (mJ) key/sig/ver

ECDSA

micro-ecc

0.31/0.36/0.34 0.43/0.5/0.47 8.3/9.6/9

lamport-OTS 0.021/0.011/0.00032 0.043/0.0221/0.00065 0.57/0.29/0.0087

SPHINCS

Port.

7.5/200/- 11/295/- 199/5311/-

Shorter Merkle Sig. 4.1/2.9/0.098 4.1/0.2/0.06 107/5.14/1.57

to a stateless scheme. In contrast the stateful XMSS-

based implementation Shorter Merkle Signatures of

the paper (Pereira et al., 2016) is practically feasible.

However, the key generation process for a larger num-

ber of signatures would take signiﬁcantly longer and

should be performed in advance.

5.5 Transceiving Messages

The energy efﬁciency for secure data transmission

does not only rely on the computational cost of the

used cryptographic algorithms but also on the com-

munication cost. The latter can be split into the energy

necessary not only for transmitting but also for receiv-

ing. This energy depends on the radio transmit power

level, the distance between sending and receiving

node and the time required for sending the message

which is proportional to the message length. Even if

the energy decomposition presented in (Bianchi et al.,

2010) is mainly dominated by asymmetric cryptogra-

phy, the main inﬂuence on the energy consumption

over the battery lifetime is for transmitting and receiv-

ing in combination with the decryption of messages

and/or the computation of MACs.

The rfEasyLinkEchoTx and rfEasyLinkEchoRx

reference projects without the TI-RTOS have been

modiﬁed in order to evaluate the communication cost

on the CC1350 board. The curve of Figure 5 (sig-

nal Z1) shows the zoomed square wave of the trans-

mitting (peak) and receiving (square wave) signal

for 10 bytes transferred in detail. The used Phy

setting is EasyLink

Phy Custom. However, other

Phy settings for instance EasyLink Phy 50 kbps2gfsk

(Sub1G 50kbps data rate, IEEE 802.15.4g GFSK)

yielded quite similar results in terms of energy con-

sumption and transmitting as well as receiving time.

Figure 5: Current measurement of transmitting and receiv-

ing 10 bytes.

In various measurements the transmit and receive

time duration as well as the respective energy cost for

different payload sizes has been determined. It must

be noted that the payload size includes 1 byte for the

length ﬁeld and 1 byte for the destination address.

Even if the maximum packet length supported by the

TI 15.4 stack is 2047 bytes, the maximum payload

size for transmitting and receiving on the CC1350

board using the reference projects is limited to only

125 bytes.

5.6 Key Exchange Overhead Costs

For the examined curve25519-donna based key ex-

change, with a public key size of 32 bytes, the

resulting communication overhead is approximately

2×320 µJ for the transmission and 2×380 µJ for the

reception. This results in a total of approximately

58 mJ for the key exchange regarding the computa-

tion and communication overhead including the board

energy consumption. With the ECDH

micro-ecc

hav-

ing a public key size of 64 bytes, the resulting over-

head yields approximately 34 mJ. Some of the PQC-

schemes are according to (Margi et al., 2017) unsuit-

able for environments such as WSN since for instance

transmitting a code-based public key would require

about 1900 messages when applying IEEE 802.15.4

standard with a frame size of 127-byte. Something

similar applies to the Saber/NewHope key exchange

since one partner needs to transfer 992/1824 bytes

and 1088/2048 bytes must be sent back. However,

since this only applies to ideal conditions, it is sug-

gested to not transmit packets of this size. Other-

wise, it can lead to an increased power consumption

in the case of retries when consuming a large air time

slot. Thus, for an easy comparison based on the data

from the message transmission and reception mea-

surements, the packets for Saber and NewHope are

fragmented using messages of up to 100 bytes. This

yields a total board energy consumption for Saber of

approximately 59 mJ and for NewHope of 56 mJ.

Table 5 summarizes the key exchange measurements

considering both the computational and the communi-

cation energy cost including the board consumption.

“Comp. Time” names the duration the computation

of the key exchange takes. The total time the commu-

nication of the key exchange takes is provided with

SECRYPT 2019 - 16th International Conference on Security and Cryptography

column “Comm. Time”. The columns “Total

Comp.

”

and “Total

Comm.

” provide information about the total

energy consumption of the computation and commu-

nication of each key exchange algorithm including the

total energy consumption of the CC1350 board.

Even if the NewHope implementation is outper-

forming the other libraries in terms of computational

cost, the communicative overhead with the large

amount of bytes to be transferred for a single key ex-

change is dominating the energy consumption and the

execution time. It must be noted that the compari-

son is based on the calculation of fragmented mes-

sages. Increasing the message size could signiﬁcantly

reduce the communication overhead but, in contrast,

makes the transmission more error prone. Consider-

ing both, the computational and communication en-

ergy consumption, the quantum-resistant implemen-

tations for Saber and NewHope show reasonable re-

sults compared to the ECC-based ones. Compara-

tive work investigating energy cost and communica-

tion overhead of cryptographic protocols on different

processor architectures is given in (Großsch

adl et al.,

2007; Meulenaer et al., 2008).

6 CONCLUSION AND FUTURE

WORK

This work compares various freely-available software

implementations of cryptographic schemes including

post-quantum applicability targeted to the usage in

WSN. Security goals are stated and the emerging

attack vector by quantum computers are discussed.

Cryptographic mechanisms including message au-

thentication, symmetric encryption / decryption, key

exchange and digital signature are reviewed and rec-

ommendations of candidates for WSN are provided.

The evaluation mainly deals with measurements of

the energy consumption including the discussion of

computational and communication cost for candidate

schemes on a dedicated WSN-ready reference plat-

form. Chaskey and LightMAC seem to be promising

candidates for message authentication in WSN. How-

ever, message authentication is more computationally

complex than symmetric ciphers such that in a com-

bined authenticated encryption an ARM assembly-

optimized AES-256-GCM or ChaCha-Poly1305 im-

plementation is desirable. For symmetric encryp-

tion / decryption the aes-armcortexm implementation

with highly optimized ARM Cortex-M3 assembly uti-

lizing AES-256-CTR provides the best results fol-

lowed by the Cortex-M0 optimized ChaCha20 imple-

mentation. The greatest threat of quantum comput-

ers is targeted to asymmetric cryptography. Thus,

from the key exchange perspective, the NewHope

for ARM seems a promising candidate which has

been efﬁciently implemented on ARM architectures.

Drawbacks on the other side are the missing protec-

tion against CCA which Saber’s ARM implementa-

tion provides and the large amount of bytes to be

transferred for NewHope which constitutes the main

part of the energy consumption. Including the total

computation and communication overhead NewHope

and Saber seem applicable candidates for WSN com-

pared to ECDH

micro-ecc

or curve25519-donna imple-

mentations providing the same pre-quantum security

strength. The impact of the generation of random

numbers on the energy consumption has been ne-

glected in this article, but with respect to a real-world

application, this must be considered in a future work.

The evaluated PQC signature implementations

based on the research of (Pereira et al., 2016) and

SPHINCS-256 are hash-based and neither seem ap-

plicable in real environments since XMSS schemes

are stateful and SPHINCS-256 has a too high timing

cost. Other schemes are currently either not feasible

for the embedded use or still face threats by various

attacks. Thus, more research in PQC-schemes is nec-

essary in the future. With NIST’s announcement on

round 2 PQC candidates very recently only a lim-

ited number of optimized software implementations

are available which still are mainly targeted for the

Cortex-M4 architecture. Also shown with NewHope,

dedicated assembly implementations for the Cortex-

M families are necessary for the embedded domain

since often additional hardware acceleration is not

feasible due to ﬁnancial reasons. Even if the Cortex-

M family is backward compatible meaning that a M0

optimized assembly code is able to run on a M3 or

M4, the instruction set capability is larger the more

performant the processor resulting in a lower energy

consumption. Various versions of implementations

are desired aimed for the manifold existing embedded

architectures. Porting or evaluating M4-optimized

implementations, e.g. SIKE, Round5, Frodo, qTesla

or Dilithium (PQM4, 2019) for less-powerful micro-

controllers is part of future work. Similar to clas-

sical ECC, supersingular isogeny-based ECC seems

a promising approach in terms of smaller key sizes

and moderate signature sizes compared to other PQC-

schemes for the application in WSN. More research

must be done regarding this ﬁeld since e.g. SIDH

is according to the authors of (Bogomolec and Ger-

hard, 2018) very young and not well trusted. How-

ever, the large number of recent publications and Mi-

crosoft Research projects (referring to (Jalali et al.,

2018)) actively working on these algorithms underpin

their importance in the future.

On the Energy Consumption of Quantum-resistant Cryptographic Software Implementations Suitable for Wireless Sensor Networks

Table 5: Summary of the computational and communication energy cost of the tested key exchange schemes.

Library Comp. Time (s) Comm. Time (s) Total

Comp.

(mJ) Total

Comm.

(mJ)

curve25519-donna 1.48 0.11 41.17 1.40

ECDH

micro-ecc

1.20 0.14 31.88 2.16

Saber

ARM

1.15 1.68 30.44 28.45

NewHope

ARM

0.10 3.15 2.66 53.59

ACKNOWLEDGEMENTS

This research work has been supported by the projects

no. 16KIS0539 and 13FH645IB6 of the German Fed-

eral Ministry of Education and Research and the Min-

istry of Education, Youth and Sports of the Czech Re-

public under grant no. LO1506.

REFERENCES

Alkim, E., Jakubeit, P., and Schwabe, P. (2016). Newhope

on arm cortex-m. In International Conference on Se-

curity, Privacy, and Applied Cryptography Engineer-

ing, pages 332–349.

Amy, M., Matteo, O. D., Gheorghiu, V., Mosca, M., Parent,

A., and Schanck, J. (2016). Estimating the cost of

generic quantum pre-image attacks on sha-2 and sha-

3. Cryptology ePrint Archive, Report 2016/992.

Ateniese, G., Bianchi, G., Capossele, A. T., Petrioli, C.,

and Spenza, D. (2017). Low-cost standard signa-

tures for energy-harvesting wireless sensor networks.

ACM Transactions on Embedded Computing Systems

(TECS), 16(3), 64.

Bartolomeu, P. C., Vieira, E., and Ferreira, J. (2018). IOTA

feasibility and perspectives for enabling vehicular ap-

plications. CoRR, abs/1808.10069.

Bellare, M. (2015). New proofs for NMAC and HMAC:

Security without collision resistance. Journal of Cryp-

tology, Volume 28, Issue 4:844–878.

Bernstein, D. and Lange, T. (2014). Safecurves: choosing

safe curves for elliptic-curve cryptography. https://

safecurves.cr.yp.to, Online; accessed 26-Feb-2019.

Bernstein, D. J., Buchmann, J., and Dahmen, E. (2009).

Post-quantum cryptography. Springer, Berlin, ISBN

978-3-540-88701-0.

Bianchi, G., Capossele, A., Mei, A., and Petrioli, C. (2010).

Flexible key exchange negotiation for wireless sensor

networks. In Proceedings of the ﬁfth ACM interna-

tional workshop on Wireless network testbeds, experi-

mental evaluation and characterization, pages 55–62.

Bogomolec, X. and Gerhard, J. (2018). Post-

quantum secure cryptographic algorithms. CoRR,

abs/1809.00371.

Bruinderink, L. G. and Pessl, P. (2018). Differential fault at-

tacks on deterministic lattice signatures. IACR Trans-

actions on Cryptographic Hardware and Embedded

Systems, pages 21–43.

BSI (2018). Cryptographic mechanisms: Recommenda-

tions and key lengths. BSI - Technical Guideline BSI

TR-02102-1.

Certicom Research (2000). Sec 2: Recommended ellip-

tic curve domain parameters. Standards for Efﬁ-

cient Cryptography, http://www.secg.org/SEC2-Ver-

1.0.pdf.

Chowdhury, A. R. and DasBit, S. (2015). LMAC: A

lightweight message authentication code for wireless

sensor network. 2015 IEEE Global Communications

Conference (GLOBECOM).

Costa, D. G., Figuer

edo, S., and Oliveira, G. (2017). Cryp-

tography in wireless multimedia sensor networks: A

survey and research directions. Cryptography, 1(1).

Driessen, B. (2007). Efﬁcient embedded implementations

of security solutions for ad-hoc networks. Diploma

Thesis, Ruhr-University Bochum.

ull, M., Haase, B., Hinterw

alder, G., Hutter, M., Paar,

C., S

anchez, A. H., and Schwabe, P. (2015). High-

speed curve25519 on 8-bit, 16-bit and 32-bit micro-

controllers. Design, Codes and Cryptography, https:

//cryptojedi.org/papers/#mu25519.

ETSI (2017). Cyber; quantum-safe key ex-

changes. ETSI TR 103 570 - Technical Report,

https://www.etsi.org/deliver/etsi tr/103500 103599/

103570/01.01.01 60/tr 103570v010101p.pdf.

Grassla, M., Langenberg, B., R

otteler, M., and Steinwandt,

R. (2016). Applying grover’s algorithm to aes: quan-

tum resource estimates. In International Workshop on

Post-Quantum Cryptography, Springer, pages 29–43.

Großsch

adl, J., Szekely, A., and Tillich, S. (2007). The en-

ergy cost of cryptographic key establishment in wire-

less sensor networks. Proceedings of the 2Nd ACM

Symposium on Information, Computer and Communi-

cations Security.

Grover, L. (1996). A fast quantum mechanical algorithm

for database search. 28th Annual ACM Symposium on

the Theory of Computing, page 212.

Guillen, O. M., P

oppelmann, T., Mera, J. M. B., Bonge-

naar, E. F., Sigl, G., and Sepulveda, J. (2017). To-

wards post-quantum security for iot endpoints with

ntru. DATE.

uneysu, T., Krausz, M., Oder, T., and Speith, J. (2018).

Evaluation of lattice-based signature schemes in em-

bedded systems. In 2018 25th IEEE International

Conference on Electronics, Circuits and Systems

(ICECS), pages 385–388.

Howe, J., P

oppelmann, T., O’neill, T., O’sullivan, M., and

Gueneysu, T. (2015). Practical lattice-based digital

SECRYPT 2019 - 16th International Conference on Security and Cryptography

signature schemes. ACM Transactions on Embedded

Computing Systems (TECS), 4(3), 41.

ulsing, A., Rijneveld, J., and Schwabe, P. (2016).

Armed sphincs. Public-Key Cryptography–PKC

2016, Springer, Berlin, Heidelberg, pages 446–470.

Jalali, A., Azarderakhsh, R., and Mozaffari-Kermani, M.

(2018). NEON SIKE: Supersingular isogeny key en-

capsulation on armv7. In International Conference

on Security, Privacy, and Applied Cryptography En-

gineering, Springer, Cham:37–51.

Jozsa, R. (1997). Entanglement and quantum computation.

Geometric Issues in the Foundations of Science, Ox-

ford University Press, ed. S. Huggett et. al.

Kannwischer, M. J., Genet, A., Butin, D., Kr

amer, J., and

Buchmann, J. (2018). Differential power analysis of

xmss and sphincs. Cryptology ePrint Archive, Report

2018/673.

Karmakar, A., Mera, J. M. B., Roy, S., and Verbauwhede,

I. (2018). Saber on arm. IACR Transactions on Cryp-

tographic Hardware and Embedded Systems, pages

243–266.

Karuppiah, A. B. and Rajaram, S. (2012). Energy ef-

ﬁcient encryption algorithm for wireless sensor net-

work. International Journal of Engineering & Tech-

nology (IJERT), Volume 1, Issue 3.

Kelly, J. (2018). A preview of bristlecone, google’s new

quantum processor. https:// ai.googleblog.com/2018/

03/a-preview-of-bristlecone-googles-new.html, On-

line; accessed 26-Feb-2019.

Kumaran, U. S., Nallakaruppan, M. K., and Kumar, M. S.

(2016). Review of asymmetric key cryptography in

wireless sensor networks. International Journal of

Engineering and Technology (IJET), 8:859–862.

Lei, X. and Liao, X. (2013). Ntru-ke: A lattice-based pub-

lic key exchange protocol. IACR Cryptology ePrint

Archive, 718.

Luykx, A., Preneel, B., Tischhauser, E., and Yasuda, K.

(2016). A mac mode for lightweight block ciphers.

In International Conference on Fast Software Encryp-

tion, pages 43–59.

Mani, D. M. and Nishamol, P. H. (2013). A comparison

between rsa and ecc in wireless sensor networks. In-

ternational Journal of Engineering Research & Tech-

nology (IJERT), Vol. 2 Issue 3.

Margi, C. B., Alves, R. C. A., and Sepulveda, J. (2017).

Sensing as a service: Secure wireless sensor network

infrastructure sharing for the internet of things. Open

Journal of Internet of Things (OJIOT), Volume 3, Is-

sue 1.

Meiser, G., Eisenbarth, T., Lemke-Rust, K., and Paar, C.

(2008). Efﬁcient implementation of estream ciphers

on 8-bit avr microcontrollers. In 2008 International

Symposium on Industrial Embedded Systems.

Meulenaer, G. D., Gosset, F., Standaert, F. X., and

Pereira, O. (2008). On the energy cost of com-

munication and cryptography in wireless sensor net-

works. IEEE International Conference on Wireless

and Mobile Computing WIMOB’08, In Networking

and Communications:580–585.

Moon, A. H., Iqbal, U., and Bhat, G. M. (2016). Authen-

ticated key exchange protocol for wireless sensor net-

works. International Journal of Applied Engineering

Research, Volume 11.

Mouha, N., Mennink, B., Herrewege, A. V., Watanabe, D.,

Preneel, B., and Verbauwhede, I. (2014). Chaskey: An

efﬁcient mac algorithm for 32-bit microcontrollers. In

International Workshop on Selected Areas in Cryptog-

raphy, pages 306–323.

NIST (2016). Report on post-quantum cryptography.

NIST Report NISTIR 8105, https://nvlpubs.nist.gov/

nistpubs/ir/2016/NIST.IR.8105.pdf.

NIST (2019). PQC standardization process: Second round

candidate announcement. https:// www.nist.gov/ news-

events/news/2019/01/pqc-standardization-process-

second-round-candidate-announcement, Online;

accessed 26-Feb-2019.

Open Quantum Safe Project (2018). Software for pro-

totyping quantum-resistant cryptography. https:

//openquantumsafe.org/, Online; accessed 26-Feb-

2019.

Pereira, G., Puodzius, C., and Barreto, P. (2016). Shorter

hash-based signatures. Journal of Systems and Soft-

ware, Volume 116:95–100.

PQCRYPTO (2015). Initial recommendations of long-

term secure post-quantum systems. Horizon

2020 ICT-645622, http://pqcrypto.eu.org/docs/initial-

recommendations.pdf.

PQM4 (2019). Post-quantum crypto library for the arm

cortex-m4. https:// github.com/mupq/ pqm4, Online;

accessed 26-Feb-2019.

Rehana, Y., Ritter, E., and Wang, G. (2010). An authenti-

cation framework for wireless sensor networks using

identity-based signatures. 10th International Confer-

ence on Computer and Information Technology.

Rehana, Y., Ritter, E., and Wang, G. (2012). An authenti-

cation framework for wireless sensor networks using

identity-based signatures: implementation and evalu-

ation. IEICE TRANSACTIONS on Information and

Systems, 95.1:126–133.

Schwabe, P. and Ko, S. (2017). All the aes you need on

cortex-m3 and m4. In International Conference on

Selected Areas in Cryptography, pages 180–194.

Sen, J. (2013). Security in wireless sensor networks. CoRR,

abs/1301.5065.

Seo, H., Liu, Z., Longa, P., and Hu, Z. (2018). SIDH on

arm: Faster modular multiplications for faster post-

quantum supersingular isogeny key exchange. Cryp-

tology ePrint Archive, Report 2018/700.

Shor, P. (1997). Polynomial-time algorithms for prime fac-

torization and discrete logarithms on a quantum com-

puter. SIAM J. Comput., 26(5):1484–1509.

Xu, R., Cheng, C., Qin, Y., and Jiang, T. (2018). Lighting

the way to a smart world: Lattice-based cryptography

for internet of things. CoRR, abs/1805.04880.

Zhang, X., Heys, H. M., and Li, C. (2012). Energy efﬁ-

ciency of encryption schemes applied to wireless sen-

sor networks. Sec. and Commun. Netw., 5(7):789–

808.

On the Energy Consumption of Quantum-resistant Cryptographic Software Implementations Suitable for Wireless Sensor Networks
