Continuous and Client-centric Trust Monitoring in Multi-cloud Storage

Dimitri Van Landuyt, Luuk Raaijmakers, Ansar Raﬁque and Wouter Joosen

imec-DistriNet, Dept. of Computer Science, KU Leuven,

B-3001 Heverlee, Belgium

Keywords:

Trust Monitoring, Continuous Monitoring, Black-box Monitoring, Multi-cloud Storage, Federated Cloud

Storage.

Abstract:

Multi-cloud storage is the practice of composing the data tier of an application with heterogeneous cloud

storage technologies, resources and services. In a federated cloud storage architecture which involves multiple

cloud storage providers, both the complexity and the importance of trust management increases drastically. A

trust relation is established between a data owner and a cloud storage provider when the data owner subscribes

to the service and service level agreements (SLAs) are established. In practice, this trust relation is seldom

revised, only when serious infractions are discovered and made public.

In this paper, we evaluate the potential of continuous and client-centric trust monitoring of cloud storage

services. This approach leverages upon the statistical correlations between black-box performance metrics

and reported white-box metrics, and identiﬁes signiﬁcant deviations between both. We evaluate in terms of

(a) the effectiveness of correlating black-box and white-box measurements, and (b) the incurred performance

overhead of the approach to continuously monitor for trust.

1 INTRODUCTION

Cloud storage services provide scalable and on-

demand storage facilities. Due to the heterogene-

ity inherent to the underlying database technologies

(NoSQL), many organizations are adopting a feder-

ated, multi-storage strategy (Bermbach et al., 2011),

in which different storage services from different

cloud storage providers (CSP) are combined.

The requirement of a trust relationship between

service consumers and cloud service providers is a

key impediment to cloud adoption (Rong et al., 2013;

Habib et al., 2012). Lack of physical access to the

storage infrastructure, information asymmetry, and

diverging economical interests are at the foundation

of this lack of trust. Indeed, cloud providers have eco-

nomic incentives to be dishonest, e.g. by deliberately

allocating less CPU or memory resources than agreed

upon to maximize economic beneﬁt (Zhang et al.,

2014), or by not disclosing unexpected service dis-

ruptions to their clientele to avoid reputational harm.

Arguably, the issue of trust in cloud storage ser-

vices is even more stringent, as the cloud storage

paradigm involves entrusting third-party CSPs with

data assets that are of crucial value to the data owner.

One common example is a Software-as-a-Service

(SaaS) offering that is built upon existing cloud stor-

age resources to improve their operational efﬁciency.

To alleviate the information asymmetry, CSPs com-

monly provide access to white-box monitoring ser-

vices, allowing data owners to consult a number of

measurements and performance indicators such as the

delivered uptime and read/write latency. However,

similarly to the scenarios described above, this ap-

proach still requires data owners to have a degree of

trust in the reported values as such measurements are

collected, reported and controlled exclusively by the

CSP. In practice, if there is a discrepancy between

the reported and the delivered service, regardless of

it being deliberate or not, data owners have no sim-

ple way to knowing. CSPs commonly provide mon-

itoring APIs and dashboard to trust between applica-

tion providers/data owners and CSPs. However, since

this is the only source of information, there is from

a client-centric perspective no straightforward way to

verify the correctness of this information.

A number of different approaches have been pro-

posed and investigated to deal with the problem of

limited trust in a cloud computing context. Reputa-

tion and recommender frameworks (Li et al., 2012;

Khan and Hamlen, 2012; Habib et al., 2014; Habib

et al., 2013; Muchahari and Sinha, 2012) collect

positive and negative experiences from many ser-

vice consumers and calculate trust ranks. Broker-

100

Van Landuyt, D., Raaijmakers, L., Raﬁque, A. and Joosen, W.

Continuous and Client-centric Trust Monitoring in Multi-cloud Storage.

DOI: 10.5220/0007713201000110

In Proceedings of the 9th International Conference on Cloud Computing and Services Science (CLOSER 2019), pages 100-110

ISBN: 978-989-758-365-0

based approaches (Uikey and Bhilare, 2013) involve

a trusted-third party reseller of cloud services that as-

sume part of the liability or trust or assume an active

rule, such as third-party auditors (Zhang et al., 2014).

Other approaches rely on standardization and certi-

ﬁcation (Cloud Security Alliance (CSA), 2018) and

periodic audits (Popa et al., 2011). These approaches

essentially rely extensively on trust in external parties.

In this paper, we evaluate the potential of a com-

plementary approach that focuses on the issue ex-

clusively from the point of a single data owner.

This approach is similar to the continuous monitor-

ing and trust assessment solution of Li et al. (Li

and Du, 2013). This approach involves continuously

monitoring both the reported measurements (through

white-box metrics) and delivered service (through

black-box metrics) and attributing trust scores based

on statistically-relevant discrepancies between both.

This approach is based upon leveraging known (and

thus expected) statistical correlations between white-

box and black-box measurements (Schoonjans et al.,

2015). Continuously checking the accuracy and ve-

racity of the reported white-box measurements as

such enables continuously assessing the trustworthi-

ness of the CSP. We focus on functional validation

of this approach and evaluating the performance cost

of continuous monitoring. The results indicate that

the performance overhead is acceptable in a realistic

multi-cloud scenario. Additional results conﬁrm the

expected statistical correlations between both metric

types.

The remainder of this paper is structured as fol-

lows: Section 2 provides a discussion of the back-

ground of this article. Section 3 discusses a prototype

implementation of continuous black-box monitoring

which is evaluated in Section 4. Section 5 discusses

related work and ﬁnally, Section 6 concludes the pa-

per.

2 BACKGROUND

Section 2.1 ﬁrst provides background information on

multi-cloud storage and then Section 2.2 discusses the

notion of trust in this speciﬁc context.

2.1 Multi-cloud Storage

Cloud storage allows data owners and service

providers to acquire storage resources on demand and

store their data in the cloud. Apart from providing

ﬂexible data storage, it also alleviates the burden of

maintaining an expensive in-house storage infrastruc-

ture (Raﬁque et al., 2017). As shown in Table 1, there

is a wide variety of cloud storage providers (CSPs)

and Database-as-a-Service (DBaaS) providers in the

market, each focusing on different SLA guarantees

and with support for different database technologies

(e.g., NoSQL databases) (Raﬁque et al., 2018).

However, the paradigm of online data hosting and

data access introduces serious concerns about data

security, performance (i.e. latency), availability, and

vendor lock-in. In addition, due to the heterogene-

ity inherent in the underlying database technologies,

limited application requirements can be satisﬁed by a

single cloud storage provider.

Therefore, a federated or multi-cloud storage ar-

chitecture in which technologically heterogeneous

storage services and database technologies from mul-

tiple cloud storage providers are combined within the

same application, is becoming an increasingly popu-

lar tactic for service providers (Bermbach et al., 2011;

Raﬁque et al., 2018).

2.2 Trust in Multi-cloud Storage

In the context of cloud storage, data owners have

expectations from CSPs. These are typically codi-

ﬁed and agreed upon in Service Level Agreements

(SLAs). SLAs represent contracts between CSPs

and data owners. In an SLA, guarantees offered by

the CSP are clearly outlined. Next to this, an SLA

also details the expected consequences when these

promises aren’t fulﬁlled. SLAs are an important com-

ponent in the trust relationship between data own-

ers and CSPs. When the CSP refrains from offering

promised agreements of the SLA, this can seriously

hurt the trust relationship.

Table 1 lists (in columns 3-5) the SLA guaran-

tees offered by 10 representative commercial CSPs.

It shows that these SLAs focus mainly on availabil-

ity, while only two CSPs provide explicit perfor-

mance guarantees (in terms of latency and through-

put). However, although all CSPs guarantee some

form of availability, deﬁnitions vary widely and dif-

ferences can be observed regarding the employed cal-

culation method: some CSPs calculate at the basis of

unavailability, others in terms of downtime, and oth-

ers in terms of error rate. Further investigation, how-

ever, indicates that each provider adopts a slightly dif-

ferent interpretation, making SLA promises in gen-

eral rather difﬁcult to compare fairly across providers.

The trust deﬁnition introduced in (EMC, 2011)

equates trust to control and visibility. A certain de-

gree of control and internal visibility or transparency

is needed to establish trust. When outsourcing data to

a CSPs, data owners trade in both in terms of visibil-

ity and trust. Information asymmetry (Akerlof, 1970)

Continuous and Client-centric Trust Monitoring in Multi-cloud Storage

101

Table 1: Illustrative overview of 10 different cloud storage providers (CSPs), the nature of the SLAs, and monitoring metrics

they offer.

CSP

(DB technology)

SLA: Availability SLA: Performance Monitoring API

Pct. Based

Latency Thr-

oughput

Availability Latency Throughput

InstaClustr (Instaclustr,

2017; Instaclustr, 2018)

(Cassandra)

99,9% /

99,95%

Unavai-

lability

- / 99% - nodeStatus clientRequestRead

clientRequest-

Write

reads

writes

ScaleGrid (ScaleGrid, 2016; Mon-

goDB, 2018b; ScaleGrid, 2012)

(MongoDB, Redis)

99,95% Unavai-

lability

- - events.re-

start

Redis Labs (Redis Labs, 2018; Re-

disLabs, 2018) (Redis)

99,95% /

99,99%

/ - - Read latency

Write latency

Reads/sec

Writes/sec

Datastax Managed Cloud (DataS-

tax, 2018) (Cassandra)

99% /

99,9%

Unavai-

lability

- - nodetool

status

nodetool cfstats nodetool

cfstats

Compose (Compose, 2018b; Com-

pose, 2018a)

(MongoDB, Redis)

99,98% / databa-

ses.status

MongoDB Atlas (MongoDB Atlas,

2018; MongoDB, 2018a) (Mon-

goDB)

99,95% Downtime serverStatus

Uptime

serverStatus

OpLatencies

serverStatus

OpLatencies.ops

Google Cloud Storage (Google

Cloud, 2016; Google Cloud, 2018)

99,9% /

99,95%

Error

Rate

- - uptime checks request latency

Microsoft Azure (Microsoft Azure,

2015; Microsoft Azure, 2018)

99,9% /

99,99%

Error

Rate

status &

request

errors

SuccessServerLa-

tency

Amazon EBS (AWS - Amazon Web

Services, 2018b; AWS - Amazon

Web Services, 2018a; AWS - Ama-

zon Web Services, 2018)

99% /

99,99%

Unavai-

lability

- 99% volume status

check

volumeTotalRead-

Time/

volumeReadOps

volumeWriteOps

Oracle Cloud (Oracle Cloud, 2018;

Oracle, 2018)

99,9% Error

Rate

- 90%

gene-

ral.status

performan-

ce.throughput

99,9% of the time.

is a key problem: data owners are only provided with

a subset of the available information about the inter-

nal workings of the storage offering, while CSPs have

full control and visibility. Increasing the amount of

control consequently increases the amount of trust.

For this reason, many CSPs currently offer mon-

itoring service interfaces and extensive data control

dashboards, which are accessible to customers. Hav-

ing an internal view of the system, which can for ex-

ample be achieved by monitoring, increases visibil-

ity and in turn can increase the level of trust. Ta-

ble 1 (ﬁnal column) summarizes the metric types that

can be accessed (programmatically or via these dash-

boards) in 10 investigated commercial cloud storage

offerings. As these metrics are reported by the cloud

providers themselves and are inherently based on the

an internal view of the storage offering, they are in

effect white-box metrics.

Motivation. CSPs retain full control on the infor-

mation they provide. Dishonest CSPs could be delib-

erately selective in the information they provide, tam-

per with or alter the information offered to their cus-

tomers, e.g. to avoid reputational damage in case of

service disruption. Since CSPs are proﬁt-based enti-

ties, they have an economic incentives to be dishonest

because offering data owners less than agreed upon

allows them to support more users and consequently

gain more proﬁt (Zhang et al., 2014).

3 APPROACH AND

IMPLEMENTATION

Many approaches exist to maintain trust in a multi-

cloud context. In this paper, we explore and evalu-

ate a continuous, client-centric monitoring approach.

More speciﬁcally, measurements obtained in a client-

centric, black-box fashion are compared to the white-

box measurements reported by the CSPs. By exploit-

ing knowledge on existing (and thus expected) sta-

tistical correlations (Schoonjans et al., 2015) between

values obtained from both perspectives, trust rankings

of CSPs can be created and continuously revised.

The overall architecture is depicted in Figure 1.

As shown, it is comprised of three major subsys-

tems: (i) an abstraction layer for fetching white-

box measurements from a wide range of CSPs and

storage nodes (White-box metrics abstraction

layer), which includes a scheduler to obtain speciﬁc

white-box measurements according to an application-

speciﬁc monitoring policy (White-box metrics

scheduler), (ii) an instrumentation layer for obtain-

ing black-box measurements (Black-box metrics

CLOSER 2019 - 9th International Conference on Cloud Computing and Services Science

102

<<component>>

Monitoring framework

<<component>>

White-box metrics

abstraction layer

<<component>>

White-box metrics

Scheduler

<<component>>

DB-as-a-Service

provider

<<component>>

<<database>>

StatsD storage

<<component>>

Application

<<component>>

Black-box metrics

instrumentation

<<component>>

Trust veriﬁcation engine

<<component>>

Database mapper

<<artifact>>

White-box

scheduling

policy

<<artifact>>

Black-box

scheduling

policy

<<artifact>>

Storage

conﬁguration

native whitebox API

fetchMetrics

trust boundary

Create/read/update/delete

native create/read/update/delete

store

Create/read/update/delete

read

<<use>>

Figure 1: The overall architecture of the monitoring framework (UML component diagram).

instrumentation) through observation on regular

application calls, and (iii) the Trust verification

engine.

We have implemented a prototype implementation

which is available on-line (Raaijmakers, 2018).

The White-box metrics abstraction layer

component provides built-in abstraction support for

in total 18 white-box provided by PostgreSQL, Redis,

MongoDB, and Cassandra.

The Black-box metrics instrumentation

component builds upon a database mapper frame-

work (also called Object-NoSQL Database Mapper

or ONDM (Cabibbo, 2013; Reniers et al., 2017)) to

collect black-box measurements through instrumenta-

tion of regular application calls. Metrics are recorded

for (i) uptime, (ii) number of read requests, (iii) num-

ber or failed requests (yielding an error or time-out),

(iv) average read latency (10-second interval, 1-hour

interval and 24-hour interval), and (v) average write

latency (10-second interval, 1-hour interval and 24-

hour interval).

The Trust verification engine implements a

number of trust ranking algorithms that essential look

at the discrepancies between the reported white-box

measurements and the black-box metrics obtained

from a client perspective. Many trust ranking mod-

els can be adopted to calculate trust scores, ranging

from very straightforward methods such as calculat-

ing the difference between black-box and white-box

measurements, to more advanced models to calculate

and predict trustworthiness based on the obtained in-

puts (for example, using machine learning-based clas-

siﬁers). The prototype implementation currently pro-

vides the following trust models, but is extensible in

this regard.

• Percentage deviation. The percentage deviation

method calculates the difference between black-

box and white-box measurements as the percent-

age deviation based on the black-box measure-

ment. A black-box measurement of 210 ms and

a white-box measurement of 200 ms results in

a trust score of 95% using the following calcu-

lation: (210 − 200)/200 = 5%, a 5% deviation

means that this measurement is 100% − 5% =

95% trustworthy.

• Mean Square Error (MSE). The MSE of the two

measurements can also be used as a trust score.

Using the example above yields: (210 − 200)

100. The closer the value is to zero, the more

trustworthy the storage node proves to be. This

method results in more extreme values as the de-

viation between the two values increases, due to

the power used in the calculation.

• Threshold. The threshold method treats all devi-

ations equally, regardless of their size, as long as

they are above a certain threshold. This method

can prove to be useful in scenarios where each de-

viation above a certain level has the same severity,

such as mission-critical applications that can not

tolerate any violations.

In the most simple deployment, the monitoring

framework is conﬁgured as application middleware.

In this deployment, the framework runs entirely in

the same execution environment as the application.

For more advanced scenarios, the three main com-

ponents can each be deployed on separate nodes: the

black-box and white-box components are not coupled

to each other, but they store their data on the same data

store which is used by the trust ranking component.

4 EVALUATION

This section evaluates the presented approach in

terms of (i) the effectiveness of correlating black-box

and white-box measurements, and (ii) the additional

performance overhead caused by continuous client-

centric black-box monitoring.

Continuous and Client-centric Trust Monitoring in Multi-cloud Storage

103

4.1 Experiment Setup

The evaluations described in this section are per-

formed on a machine with a 2.6 GHz Intel Core

i7 processor and 16GB 2133 MHz LPDDR3 RAM,

running MacOS 10.13.4. The performance measure-

ments are obtained using the YCSB benchmark sys-

tem

which supports a number of reusable workloads

out of the box. The tests are executed in a con-

ﬁguration that involves a native Cassandra instance

and each of the presented experiments were executed

again over a Redis database to conﬁrm the ﬁndings.

The executed workloads consisted of 1 million in-

sert operations and 1 million read operations, and a

5-second monitoring interval was used to obtain both

white-box and black-box measurements for read and

write latency.

4.2 Veriﬁcation Accuracy

The approach presented in this paper builds upon the

existence of statistical correlations between white-

box measurements and black-box measurements ob-

tained from a client perspective. These have been

shown in earlier work (Schoonjans et al., 2015). In

this ﬁrst set of experiments, we evaluate the accu-

racy of the proposed method, by comparing the ob-

tained black-box measurements with the white-box

measurements.

Table 2 displays the average latencies after each

workload. Column 3 shows the reported white-box

latencies, obtained via the Cassandra client API. Col-

umn 4 presents the black-box latency obtained with

the prototype, whereas the ﬁfth column shows the av-

erage latencies as obtained by YCSB, which are also

measured in a black-box fashion and were included to

have a third perspective on the latencies.

In terms of absolute values, there is a large dis-

crepancy between the white-box and black-box mea-

surements. This is indicated by column 6, showing

the ratio of black-box over white-box latencies. For

insert operations in Cassandra, the black-box laten-

cies (measured from an external perspective and thus

including network latency) are almost 26 times higher

than the self-reported white-box latencies. Compar-

ing the obtained black-box measurements with the

YCSB latencies (in the ﬁnal column), which are also

measured from a black-box perspective, the ratio is

much smaller: between 1.04 and 1.33.

This gives a strong indication that the measured

black-box measures are at least not incorrect: they

follow almost the same ratio as YCSB for each stor-

age technology. As mentioned. the obtained black-

YCSB: https://github.com/brianfrankcooper/YCSB

box values include more operations, e.g. the ad-

ditional latency towards the client, which are not

counted in the white-box latency measurement which

is obtained nearer to the database node. In this ex-

periment, the discrepancy between both measurement

types in terms of absolute values is speciﬁc to the

setup (network latency) and incidental.

Figure 2 shows the detailed write latencies for

Cassandra, during the workload involving 1 million

insert operations, measured every 5 seconds. Despite

the large discrepancy between the two measurements

(factor 26), these graphs illustrate that they both re-

ﬂect the same changes. At times t=13, t=20, t=36

and t=55 small changes in the white-box latency were

observed, which are also reﬂected in the black-box

latencies. These results conﬁrm that this black-box

metric can be used for veriﬁcation, even though the

absolute values do not correspond.

In a realistic deployment setting, these measure-

ments will additionally be impacted by natural varia-

tions in the network latency between the storage ser-

vice and the client. This is most relevant in a multi-

cloud conﬁguration that involves multiple CSPs, and

plays a less signiﬁcant role in a local, on-premise de-

ployment (e.g., in a local data center context) such

as in our evaluations. Trust ranking models that tol-

erate such variations will necessarily involve statisti-

cal prediction models of end-to-end latency (Kim and

Yi, 2010; Yamamoto et al., 2015; Madhyastha et al.,

2006). Integration of such models in the prototype

and further validation of the approach outside of lab

settings are considered part of our future work.

4.3 Performance Overhead of

Black-box Measurements

In this second experiment, identical workloads were

executed on both a native Cassandra instance (the

baseline for comparison) and the prototype imple-

mentation that (i) measures black-box latency and

(ii) stores these measurements in a central database.

The experiment focuses on quantifying the perfor-

mance overhead introduced by instrumenting regular

read and insert requests with support for black-box

monitoring. This is done by systematically comparing

the results of a benchmarking workload of the base-

line with the performance results of the prototype, fo-

cusing on the increase in latency.

For this experiment, we have executed workload

D of YCSB, which is a combined read-write work-

load, with 95% read operations and 5% inserts. Each

workload was executed with N = 1 million opera-

tions, and each experiment was repeated M = 3 times

to ensure fair comparison and remove the inﬂuence of

CLOSER 2019 - 9th International Conference on Cloud Computing and Services Science

104

Table 2: Latency measurements obtained in a black-box and white-box way. The ‘WB’ data series represent white-box

measurements, whereas the ‘BB’ and ‘YCSB’ series represent black-box measurements obtained by respectively the prototype

and YCSB.

Database

read /

insert

(ms)

YCSB

(ms)

ratio

BB/WB

ratio

BB/YCSB

Cassandra insert 0.034 0.874 0.657 25.70 1.33

Redis insert 0.113 0.409 0.359 3.62 1.14

800 1000 1200 1400

Cassandra black-box insert latency

32 33 34 35 36

Cassandra white-box insert latency

Latency (µs)

0 10 20 30 40 50 60

20 25 30 35 40

Ratio black-box over white-box

Time (t)

Ratio

Latency (µs)

Figure 2: Cassandra insert latencies measured in a white-box and black-box way. Horizontal lines at t=13, 20, 36 and 55

indicate changes that are reﬂected in both black-box and white-box measurements.

accidental outliers.

The second row of Table 3 shows the results of

the experiments for Cassandra: compared to the base-

line variant, we observe an increased latency of on av-

erage 141 µs for read operations (corresponding to a

63% increase) and of on average 139 µs for the insert

operations (corresponding to a 44% increase).

To conﬁrm these ﬁndings, the experiment was re-

peated for the Redis database. The third row of Ta-

ble 3 presents a summary overview of these results. It

conﬁrms that (a) the relative differences between la-

tencies using the native APIs compared to the moni-

toring framework are substantial (40% to even 100%)

and (b) no substantial differences can be observed

across databases.

To pinpoint the speciﬁc cause of the extra over-

head, additional experiments were conducted to as-

sess the impact of storing the obtained measurements

to the database. These experiments showed that the

overhead increase is caused by storing the black-box

measurements, which in effect introduces extra I/O

operations for each request, regardless of it being a

read- or insert-request. Figure 5 shows the results of

a variant of the prototype that obtains the black-box

measurements, but does not actually persists them to

disk (the ‘without storing’ data series in Figure 5).

As shown, not actually storing the measurements

has lead to a signiﬁcant improvement in performance,

more precisely latencies that are almost the same as

for the native API. Having as such effectively pin-

pointed the main bottleneck allows to formulate a

number of possible optimizations, such as a batch-

Continuous and Client-centric Trust Monitoring in Multi-cloud Storage

105

Cassandra reads

Latency (µs)

Frequency

0 100 200 300 400 500 600

0 100000 300000 500000

native

LuMon

Cassandra inserts

Latency (µs)

Frequency

0 100 200 300 400 500 600

0 10000 20000 30000 40000 50000

native

LuMon

Figure 3: Cassandra read/insert latencies.

Redis reads

Latency (µs)

Frequency

0 50 100 150

0 200000 400000 600000 800000

native

LuMon

Redis inserts

Latency (µs)

Frequency

0 50 100 150 200 250 300

0 10000 20000 30000 40000 50000

native

LuMon

Figure 4: Redis read/insert latencies.

driven strategy for persisting the black-box measure-

ments.

Furthermore, it is important to put these results in

perspective: these experiments were performed on a

local, single-node setup and thus does not take into

account network latency and additional performance

costs incurred in larger database clusters or complex

inter-CSP federations. In comparison to the laten-

cies of storage operations in more realistic cluster se-

tups (Reniers et al., 2017), the absolute latency in-

creases of 70-140 µs are not altogether that substan-

tial.

5 DISCUSSION AND RELATED

WORK

In a cloud context, the most common approach to trust

involves trusted third parties (T3P) and trust broker-

age. For example, the approach of Zhang et al. (Zhang

et al., 2014) features T3P that audits cloud service

providers in terms of memory usage. Muchahari et

al. (Muchahari and Sinha, 2012) have presented a dy-

namic trust monitor that performs continuous calcula-

tion based on SLA and QoS and reports it to a central

registry (Muchahari and Sinha, 2012). Analogously,

recommender (Li et al., 2012), marketplace (Habib

CLOSER 2019 - 9th International Conference on Cloud Computing and Services Science

106

Table 3: Summary of average latencies.

Database ops P (µs) native (µs) abs diff % diff

Cassandra read 364 223 141 63

insert 453 314 139 44

Redis read 90 45 45 100

insert 190 118 72 61

Cassandra reads

Latency (µs)

Frequency

0 100 200 300 400 500 600

0 100000 300000 500000

native

Mon

Mon (without storing)

Cassandra inserts

Latency (µs)

Frequency

0 200 400 600 800

0 10000 20000 30000 40000 50000

native

Mon

Mon (without storing)

Figure 5: Cassandra read/insert overhead.

et al., 2013; Habib et al., 2014) and reputation sys-

tems (Khan and Hamlen, 2012) rely on a centralized

trusted entity that collects and shares experiences be-

tween data owners and CSPs and facilitates match-

making and service brokerage.

The solution discussed in this article is comple-

mentary, in the sense that it assumes the point of view

of a single data owner and does not build upon the

precondition of a trusted third party.

The industry survey of Lins et al. (Lins et al.,

2016) stresses the necessity of continuous auditing. In

terms of the architectural styles explored in this sur-

vey, the approach presented in this paper is an exam-

ple of the ‘Monitoring and Control Layer’-type sys-

tem, but then from an externalized perspective. Key

arguments against systematic benchmarking of cloud

services (Li et al., 2010) are that these activities com-

monly introduce (i) additional cost, and (ii) may have

side-effects, for example benchmark systems intro-

duce artiﬁcial data which may hinder a production

system. In our approach, the impact on a produc-

tion system is reduced by instrumenting regular ap-

plication operations with the acquisition of black-box

measurements. Similar approaches have been imple-

mented to continuously audit the privacy-preservation

and data security aspects of a CSP, leveraging tech-

niques of trusted computing (Kai et al., 2013). In such

protocols, trust guarantees w.r.t. the correctness of the

reported service levels are constructed by means of

cryptographic proofs. Yang et al. (Yang et al., 2013)

have proposed an architecture that supports these pro-

tocols in a multi-cloud storage architecture.

Increasing trust between data-owners and CSPs

can be done in several ways. Since trust is based on

lack of sufﬁcient information, the solution is to in-

crease the visibility of the system, by gathering and

sharing information. In (Zhang et al., 2014) this

approach is taken. While these approaches increase

the trustworthiness of CSPs, they essentially shift the

trust problem to the T3P.

Quantifying and ranking trust has been an ac-

tive topic of research in reputation systems (Kam-

var et al., 2003). The Cloud Security Alliance

(CSA) (Cloud Security Alliance (CSA), 2018) pro-

posed the CAIQ (Consensus Assessments Initiative

Questionnaire), at the basis of which rankings and

trust information scores can be calculated. This scor-

ing scheme has been used extensively in the context

of trust-based systems, for example in the work of

Habib et al. (Habib et al., 2014; Habib et al., 2013).

Cloud-trust, the security assessment model of Gon-

zalez et al. (Gonzales et al., 2017) involves deﬁning

a reference model for multi-tenant IaaS services that

explicitly offers security controls and trust zones, and

Continuous and Client-centric Trust Monitoring in Multi-cloud Storage

107

derives trust scores from lower-level security-related

metrics. Although we have only worked with initial

and simplistic trust ranking schemes, in future work,

we will investigate more sophisticated trust ranking

models that deal with problems such as hysteresis be-

tween metrics or other causal or temporal relations

that may hamper the accuracy of the proposed trust

models.

Client-centric approaches to benchmark or as-

sess distributed systems have been successfully ap-

plied in the context of system properties for which

a global view is hard to construct, such as consis-

tency (Golab et al., 2014; Bermbach et al., 2014).

Similar approaches have been successfully adopted to

benchmark Infrastructure-as-a-Service (IaaS) cloud

services from an externalized perspective (Folkerts

et al., 2012; Xiong et al., 2013). Wood et al. (Wood

et al., 2007) discuss the efﬁcacy of unobtrusive black-

box performance proﬁling in comparison to gray-

boy performance proﬁling for the purposes of dy-

namic migration of virtual machines. The frame-

work of Sakr et al. (Sakr and Liu, 2012) implements

client-centric monitoring of cloud-hosted databases

for the purpose of adaptive SLA-based provision-

ing and cost management. This framework demon-

strates how adopting a client-centric monitoring per-

spective can improve ﬂexibility and trust. Schoon-

jans et al. (Schoonjans et al., 2015) have shown the

statistical correlations between some black-box and

white-box metrics, showing that these metrics can in-

deed be indicative of actual service delivered. Re-

lated approaches employ black-box metrics predictive

for ﬁnding faults, anomalies, and deviations in perfor-

mance (Nguyen et al., 2013).

The approach evaluated in this paper exploits

these correlations to ﬁnd and monitor for signiﬁcant

deviations between delivered and observed measure-

ments, and attribute a level of trust. The main ben-

eﬁt of adopting a client-centric, black-box approach

is that we effectively measure the end-to-end service

delivered to the customer, including external factors

such as network latency which are not reported in

whitebox measurements.

6 CONCLUSION

In this paper, we have evaluated an approach of con-

tinuous trust monitoring that leverages upon the ex-

isting statistical correlations between black-box met-

rics obtained from a client perspective, and white-

box metrics which are reported by cloud storage

providers. By continuously comparing the delivered

service in terms of key performance and availability

metrics (latency, throughput, uptime), trust rankings

are created and continuously maintained or revised,

allowing data owners to react to service disruptions

or SLA violations in a timely manner.

We have shown the validity and feasibility of the

proposed approach in a prototype which we in turn

evaluated in terms of the incurred performance over-

head.

ACKNOWLEDGEMENTS

This research is partially funded by the Research

Fund KU Leuven (project GOA/14/003 - ADDIS) and

the DeCoMAdS SBO project.

REFERENCES

Akerlof, G. A. (1970). The market for “lemons”: Quality

uncertainty and the market mechanism. The Quarterly

Journal of Economics, 84(3):488–500.

AWS - Amazon Web Services (2018a). Amazon compute

service level agreement. https://aws.amazon.com/ec2/

sla/[Online; accessed March 26, 2018].

AWS - Amazon Web Services (2018b). Amazon

ebs product details. https://aws.amazon.com/ebs/

details/[Online; accessed March 26, 2018].

AWS - Amazon Web Services (2018). Monitoring the

status of your volumes. https://docs.aws.amazon.

com/AWSEC2/latest/UserGuide/monitoring-volume-

status.html. [Online; Accessed April 22, 2018].

Bermbach, D., Klems, M., Tai, S., and Menzel, M. (2011).

Metastorage: A federated cloud storage system to

manage consistency-latency tradeoffs. In Cloud Com-

puting (CLOUD), 2011 IEEE International Confer-

ence on, pages 452–459. IEEE.

Bermbach, D., Zhao, L., and Sakr, S. (2014). Towards

comprehensive measurement of consistency guaran-

tees for cloud-hosted data storage services. In Nam-

biar, R. and Poess, M., editors, Performance Char-

acterization and Benchmarking, pages 32–47, Cham.

Springer International Publishing.

Cabibbo, L. (2013). Ondm: an object-nosql datastore map-

per. Faculty of Engineering, Roma Tre University. Re-

trieved June 15th.

Cloud Security Alliance (CSA) (2018). The cloudtrust pro-

tocol (ctp). https://cloudsecurityalliance.org/group/

cloudtrust-protocol/# overview.

Compose (2018a). Compose scalegrid monitoring.

https://help.compose.com/docs/essentials-compose-

monitoring. [Online; Accessed April 22, 2018].

Compose (2018b). Enhanced sla - compose. https:

//help.compose.com/docs/enhanced-sla[Online; ac-

cessed March 26, 2018].

DataStax (2018). Datastax managed cloud service level

agreement. https://www.datastax.com/dmc-service-

level-agreement[Online; accessed March 26, 2018].

CLOSER 2019 - 9th International Conference on Cloud Computing and Services Science

108

EMC (2011). Proof, not promises: creating the

trusted cloud. http://www.emc.com/collateral/emc-

perspective/11319-tvision-wp-0211-ep.pdf [Online;

accessed December 28, 2017].

Folkerts, E., Alexandrov, A., Sachs, K., Iosup, A., Markl,

V., and Tosun, C. (2012). Benchmarking in the cloud:

What it should, can, and cannot be. In Technology

Conference on Performance Evaluation and Bench-

marking, pages 173–188. Springer.

Golab, W., Rahman, M. R., AuYoung, A., Keeton, K.,

and Gupta, I. (2014). Client-centric benchmarking

of eventual consistency for cloud storage systems. In

Distributed Computing Systems (ICDCS), 2014 IEEE

34th International Conference on, pages 493–502.

IEEE.

Gonzales, D., Kaplan, J. M., Saltzman, E., Winkelman, Z.,

and Woods, D. (2017). Cloud-trust—a security as-

sessment model for infrastructure as a service (iaas)

clouds. IEEE Transactions on Cloud Computing,

5(3):523–536.

Google Cloud (2016). Google cloud storage sla.

https://cloud.google.com/storage/sla[Online; ac-

cessed March 26, 2018].

Google Cloud (2018). Stackdriver monitoring. https:

//cloud.google.com/monitoring/. [Online; Accessed

April 22, 2018].

Habib, S. M., Hauke, S., Ries, S., and M

uhlh

auser, M.

(2012). Trust as a facilitator in cloud computing: a

survey. Journal of Cloud Computing: Advances, Sys-

tems and Applications, 1(1):19.

Habib, S. M., Ries, S., M

uhlh

auser, M., and Varikkattu,

P. (2014). Towards a trust management system for

cloud computing marketplaces: using caiq as a trust

information source. Security and Communication Net-

works, 7(11):2185–2200.

Habib, S. M., Varadharajan, V., and M

uhlh

auser, M. (2013).

A framework for evaluating trust of service providers

in cloud marketplaces. In Proceedings of the 28th An-

nual ACM Symposium on Applied Computing, pages

1963–1965. ACM.

Instaclustr (2017). Service level agreements - cassan-

dra services. https://www.instaclustr.com/company/

policies/service-level-agreements/[Online; accessed

March 26,2018].

Instaclustr (2018). Instaclustr - monitoring

api. https://www.instaclustr.com/support/api-

integrations/api-reference/monitoring-api/. [Online;

Accessed April 22, 2018].

Kai, H., Chuanhe, H., Jinhai, W., Hao, Z., Xi, C., Yilong,

L., Lianzhen, Z., and Bin, W. (2013). An efﬁcient pub-

lic batch auditing protocol for data security in multi-

cloud storage. In ChinaGrid Annual Conference (Chi-

naGrid), 2013 8th, pages 51–56. IEEE.

Kamvar, S. D., Schlosser, M. T., and Garcia-Molina, H.

(2003). The eigentrust algorithm for reputation man-

agement in p2p networks. In Proceedings of the 12th

International Conference on World Wide Web, WWW

’03, pages 640–651, New York, NY, USA. ACM.

Khan, S. M. and Hamlen, K. W. (2012). Hatman: Intra-

cloud trust management for hadoop. In Cloud Com-

puting (CLOUD), 2012 IEEE 5th International Con-

ference on, pages 494–501. IEEE.

Kim, J. and Yi, J. (2010). A pattern-based prediction: An

empirical approach to predict end-to-end network la-

tency. Journal of Systems and Software, 83(11):2317

– 2321. Interplay between Usability Evaluation and

Software Development.

Li, A., Yang, X., Kandula, S., and Zhang, M. (2010). Cloud-

cmp: Comparing public cloud providers. In Proceed-

ings of the 10th ACM SIGCOMM Conference on In-

ternet Measurement, IMC ’10, pages 1–14, New York,

NY, USA. ACM.

Li, W., Ping, L., Qiu, Q., and Zhang, Q. (2012). Research on

trust management strategies in cloud computing envi-

ronment. Journal of Computational Information Sys-

tems, 8(4):1757–1763.

Li, X. and Du, J. (2013). Adaptive and attribute-based trust

model for service-level agreement guarantee in cloud

computing. IET Information Security, 7(1):39–50.

Lins, S., Schneider, S., and Sunyaev, A. (2016). Trust is

good, control is better: Creating secure clouds by con-

tinuous auditing. IEEE Transactions on Cloud Com-

puting.

Madhyastha, H. V., Anderson, T., Krishnamurthy, A.,

Spring, N., and Venkataramani, A. (2006). A struc-

tural approach to latency prediction. In Proceedings of

the 6th ACM SIGCOMM conference on Internet mea-

surement, pages 99–104. ACM.

Microsoft Azure (2015). Sla for storage - azure.

https://azure.microsoft.com/en-us/support/legal/

sla/storage/v1

0/[Online; accessed March 26, 2018].

Microsoft Azure (2018). Overview of metrics in Mi-

crosoft Azure. https://docs.microsoft.com/en-

us/azure/monitoring-and-diagnostics/monitoring-

overview-metrics. [Online; Accessed April 22, 2018].

MongoDB (2018a). Monitoring a cluster. https://docs.atlas.

mongodb.com/monitor-cluster-metrics/. [Online; Ac-

cessed April 22, 2018].

MongoDB (2018b). Using the MMS console. http://

api.mongodb.com/mms/0.8/usage.html. [Online; Ac-

cessed April 22, 2018].

MongoDB Atlas (2018). Sla for mongodb atlas.

https://www.mongodb.com/cloud/atlas/availability-

sla[Online; accessed March 26, 2018].

Muchahari, M. K. and Sinha, S. K. (2012). A new trust

management architecture for cloud computing envi-

ronment. In 2012 International Symposium on Cloud

and Services Computing, pages 136–140.

Nguyen, H., Shen, Z., Tan, Y., and Gu, X. (2013). Fchain:

Toward black-box online fault localization for cloud

systems. In Distributed Computing Systems (ICDCS),

2013 IEEE 33rd International Conference on, pages

21–30. IEEE.

Oracle (2018). Monitoring and tuning the database.

https://docs.oracle.com/cd/B19306 01/server.102/

b14196/montune.htm#ADMQS010. [Online; Ac-

cessed April 22, 2018].

Oracle Cloud (2018). Oracle cloud infrastructure service

level agreement. https://cloud.oracle.com/en US/iaas/

sla[Online; accessed March 26, 2018].

Continuous and Client-centric Trust Monitoring in Multi-cloud Storage

109

Popa, R. A., Lorch, J. R., Molnar, D., Wang, H. J., and

Zhuang, L. (2011). Enabling security in cloud storage

slas with cloudproof. In USENIX Annual Technical

Conference, volume 242, pages 355–368.

Raaijmakers, L. e. a. (2018). Monitoring platform: proto-

type implementation.

Raﬁque, A., Van Landuyt, D., and Joosen, W. (2018). Per-

sist: Policy-based data management middleware for

multi-tenant saas leveraging federated cloud storage.

Journal of Grid Computing.

Raﬁque, A., Van Landuyt, D., Reniers, V., and Joosen, W.

(2017). Towards an adaptive middleware for efﬁcient

multi-cloud data storage. In Crosscloud’17 Proceed-

ings of the 4th Workshop on CrossCloud Infrastruc-

tures & Platforms.

Redis Labs (2018). What is the redis labs service

level agreement? https://redislabs.com/faqs/what-is-

the-redislabs-service-level-agreement-2/[Online; ac-

cessed March 26, 2018].

RedisLabs (2018). Redis enterprise software - operations

and administration guide. https://redislabs.com/redis-

enterprise-documentation/administering/monitoring-

metrics/deﬁnitions/. [Online; Accessed April 22,

2018].

Reniers, V., Raﬁque, A., Van Landuyt, D., and Joosen, W.

(2017). Object-nosql database mappers: a benchmark

study on the performance overhead. Journal of Inter-

net Services and Applications.

Rong, C., Nguyen, S. T., and Jaatun, M. G. (2013). Be-

yond lightning: A survey on security challenges in

cloud computing. Computers & Electrical Engineer-

ing, 39(1):47–54.

Sakr, S. and Liu, A. (2012). Sla-based and consumer-centric

dynamic provisioning for cloud databases. In 2012

IEEE Fifth International Conference on Cloud Com-

puting, pages 360–367.

ScaleGrid (2012). Monitoring mongodb instances us-

ing mongodb monitoring service (MMS). https:

//scalegrid.io/blog/monitoring-mongodb-instances-

using-10gen-mongo-monitoring-service-mms/.

[Online; Accessed April 22, 2018].

ScaleGrid (2016). Master services agreement. https:

//scalegrid.io/msa.html[Online; accessed March 26,

2018].

Schoonjans, A., Van Landuyt, D., Lagaisse, B., and Joosen,

W. (2015). On the suitability of black-box perfor-

mance monitoring for sla-driven cloud provisioning

scenarios. In The 14th Workshop on Adaptive and Re-

ﬂective Middleware. ACM.

Uikey, C. and Bhilare, D. (2013). A broker based trust

model for cloud computing environment. Interna-

tional Journal of Emerging Technology and Advanced

Engineering, 3(11):247–252.

Wood, T., Shenoy, P. J., Venkataramani, A., Yousif, M. S.,

et al. (2007). Black-box and gray-box strategies for

virtual machine migration. In NSDI, volume 7, pages

17–17.

Xiong, P., Pu, C., Zhu, X., and Grifﬁth, R. (2013). vperf-

guard: an automated model-driven framework for ap-

plication performance diagnosis in consolidated cloud

environments. In Proceedings of the 4th ACM/SPEC

International Conference on Performance Engineer-

ing, pages 271–282. ACM.

Yamamoto, H., Ano, S., and Yamazaki, K. (2015).

Modeling of dynamic latency variations using auto-

regressive model and markov regime switching for

mobile network access on trains. Journal of Informa-

tion Processing, 23:420–429.

Yang, K., Jia, X., et al. (2013). An efﬁcient and se-

cure dynamic auditing protocol for data storage in

cloud computing. IEEE Trans. Parallel Distrib. Syst.,

24(9):1717–1726.

Zhang, H., Ye, L., Shi, J., Du, X., and Guizani, M. (2014).

Verifying cloud service-level agreement by a third-

party auditor. Security and Communication Networks,

7(3):492–502.

CLOSER 2019 - 9th International Conference on Cloud Computing and Services Science

110
