On Incorporating Security Parameters in
Service Level Agreements
Aida
ˇ
Cau
ˇ
sevi
´
c, Elena Lisova, Mohammad Ashjaei and Syed Usman Ashgar
M
¨
alardalen University,V
¨
aster
˚
as, Sweden
Keywords:
Service Level Agreement, Security, SLAC, Security Process, Cloud Computing, Run-time Monitoring.
Abstract:
With development of cloud computing new ways for easy, on-demand, Internet-based access to computing
resources have emerged. In such context a Service Level Agreement (SLA) enables contractual agreements
between service providers and users. Given an SLA, service users are able to establish trust in that the service
outcome corresponds to what they have demanded during the service negotiation process. However, an SLA
provides a limited support outside of basic Quality of Service (QoS) parameters, especially when it comes to
security. We find security as an important factor to be included in adjusting an SLA according to user defined
objectives. Incorporating it in an SLA is challenging due to difficulty to provide complete and quantifiable
metrics, thus we propose to focus on a systematic way of addressing security using the security process.
In this paper we investigate ways in which security might be incorporated already in the service negotiation
process and captured in an SLA. We propose a corresponding process to develop and maintain an SLA that
considers both design-, and run-time. To demonstrate the approach we built upon the existing SLAC language
and extend its syntax to support security. An example of a service being provided with security guarantees
illustrates the concept.
1 INTRODUCTION
Cloud computing paradigm has provided new oppor-
tunities for resource sharing and increase of interop-
erability between different service providers. Given
this, many organizations have noticed benefits with
increased service efficiency, dynamic resource allo-
cation and the cost decrease related to the system de-
velopment and maintenance. However, such a busi-
ness model with outsourcing as the key principle, in-
troduces possible risks with regard to system security
that is one of the vital attributes to be fulfilled in any
system connected to the Internet.
Currently, to overcome security risks related to the
cloud services, service users have to rely on a Ser-
vice Level Agreements (SLA), a contractual agree-
ment between a service provider and a service user
established through the negotiation process, in order
to assess service provider reliability, security policies
and make an objective comparisons between different
services offered. Beside cost and terms of use for ev-
ery service, an SLA carries information regarding ser-
vice attributes such as performance, availability, reli-
ability. In most cases, service providers include into
SLAs only those service attributes that is possible to
measure and express using numeric values.
In the current practice, a cloud SLA focuses on
a limited number of attributes, in most cases not in-
cluding security, i.e., SLAs usually focus on perfor-
mance with objectives related to availability (Jaatun
et al., 2012). For the very few cases where security
is taken into consideration, the way it has been ad-
dressed might be difficult to understand by service
users (da Silva and de Geus, 2014; Casola et al.,
2016a). Additionally, provided security guarantees
are uniform for all provided services and users, re-
gardless of particular service characteristics or spe-
cific user needs, in most cases boiling down to the
availability attribute only. Also, security is still a non-
negotiable attribute, meaning that there is no possibil-
ity to acquire a service with specific security charac-
teristics (Petcu, 2014).
Many critical systems and applications are start-
ing to introduce cloud solutions, as for such systems
it is important to take security into account from the
very beginning, clearly described security require-
ments combined with existing practice guidelines al-
ready at the design phase might lead to implementing
48
ˇ
Cauševi
´
c, A., Lisova, E., Ashjaei, M. and Ashgar, S.
On Incorporating Security Parameters in Service Level Agreements.
DOI: 10.5220/0007658000480057
In Proceedings of the 9th International Conference on Cloud Computing and Services Science (CLOSER 2019), pages 48-57
ISBN: 978-989-758-365-0
Copyright
c
 2019 by SCITEPRESS – Science and Technology Publications, Lda. All rights reserved

the system with proper security in place. However,
the actual level of system security in this case will also
depend on the cloud services being involved. Addi-
tionally, to enable a way to deal with possible threats
and risks that an adversary may impose, a security
monitoring mechanism is required. Security monitor-
ing in the cloud is a dynamic recurrent process which
draws in the viable and dedicated administration of
cloud segments to recognize and react to risks and
threats on its services. One of the challenge regard-
ing such monitoring is identification of relevant and
effective parameters. However, once they are iden-
tified, based on the monitoring information service
providers might require to refine provided guarantees
and offer an updated or completely new SLA.
To address such challenges in this paper we focus
on security considerations in SLAs with accounting
for Confidentiality, Integrity, Availability (CIA) triad,
where we first propose a process to develop an SLA
taking into account security as one of the important
properties to be considered. In our process we also
address a run-time monitoring of services and effects
of changes on existing SLA guarantees and possible
re-negotiation process. Moreover, we extend the syn-
tax of one of the existing SLA language, namely SLA
language for Cloud Computing (SLAC), and provide
an example that takes into account the proposed ex-
tensions.
The paper is organized as follows. Section 2
presents necessary background relevant for under-
standing the concepts of services, SLAs, SLA lan-
guages and security. Next, in Section 3 we present
our approach on incorporation of security in an SLA
where we describe the design-, and run-time process
related to development and maintenance of an SLA
along with the proposed extension of SLAC that en-
ables the approach formalization. Furthermore, in
Section 4 we present an example illustrating the ap-
proach via the extended version of SLAC. Relevant
related work is described in Section 5, whereas con-
clusions with future work directions are presented in
Section 6.
2 BACKGROUND
In the following we present preliminaries needed for
understanding of proposed approach.
2.1 Services Terminology
A software service is a set of functions provided by
a server software or system to a client software or
system, usually accessible through an application pro-
gramming interface (Broy et al., 2007). It can be cre-
ated, invoked, composed and destroyed on demand.
Services are developed to be platform independent
and suitable for heterogeneous applications. Compos-
ite services can be built from the atomic ones with
the main goal of a reusable functionality being pro-
vided by existing services in a low cost and rapid de-
velopment process on demand. A composition can
be achieved either through orchestration or choreog-
raphy. The first assumes the existence of a central
controller responsible for scheduling service execu-
tion according to the user demands, while the second
assumes a mechanism of message exchange between
participants in the composition, without requiring a
central coordinator. A service interface provides in-
formation about specific service properties such as
service type, capacity, time-to-serve, etc., visible to
service users and used to find and invoke services
most suitable for their needs. On the other hand,
functionality representation is hidden from the service
user and available only to service developers. Such a
system development may be seen as a cost-efficient
development by reusing functionality from available
services. Also, a service becomes a single point of
maintenance for a common functionality.
2.2 Service Level Agreements
One of the main challenges of using cloud technolo-
gies is that the quality of services cannot be controlled
by cloud users. Therefore, the service qualities are ne-
gotiated and defined by both service users and service
provider in an agreement, known as a Service Level
Agreement (SLA) (Kyriazis, 2013). Given an SLA,
service users are able to establish trust in that the ser-
vice outcome is what they have demanded during the
service negotiation process. An SLA contains a de-
scription of a service that carries information about
various attributes, such as performance, availability
ratio, reliability, etc. In most cases, an SLA includes
only those attributes that can be expressed in terms of
numerical values. On the other hand, security aspects
of services cannot be presented as measurable num-
ber that makes them more difficult to be included and
negotiated about. SLAs also contain a set of penalties
that specify the regulations when the provider fails at
delivering services at the agreed level of quality.
2.3 SLA Languages
In order to ease preparation and negotiation of
an SLA several specialized languages are devel-
oped. SLA languages facilitate automating SLA
On Incorporating Security Parameters in Service Level Agreements
49

Table 1: An SLA example using SLAC.
term group:
Small VM:
prv → cons:cCpu in [1,2] #
prv → cons:RAM in [1,1] gb
Cluster:
prv → cons:RT delay in
[0.0,0.6] ms
[2,2] of Small VM
terms:
[1,1] of Cluster
prv → cons:replication is True
negotiations and automatically creating SLA terms
with their compositions. Among various SLA lan-
guages, the common ones include: Web SLA Lan-
guage (WSLA) (Keller and Ludwig, 2003), Cloud
SLA Language (CSLA) (Kouki and Ledoux, 2012),
and a formal SLA language for Cloud Computing
(SLAC) (Uriarte et al., 2014). A review of SLA spec-
ification languages has been done in (Maarouf et al.,
2015), where the authors highlight the requirements,
strengths and weaknesses of each language compared
to each other. According to this work, all reviewed
languages have formal syntax, however only CSLA
and SLAC support formal semantics and formal veri-
fication. Moreover, SLAC provides support for incor-
porating brokers (by defining various parties), thus for
this work we consider SLAC. In the following we ex-
plain the SLAC language syntax and structure in more
details.
The core elements of the SLAC language include
contract terms and definition of guarantees for terms.
The contract terms specify the characteristics of a ser-
vice given by a provider. Each agreement requires at
least one term, which can be a metric or a group of
terms. Further, a metric can be categorized by Numer-
icMetric, which defines a range of values, Boolean-
Metric, which defines a 2-level value, and ListMetric
that defines a list of values for a service. The SLAC
language allows to define a set of terms in a group to
be reused for several services. In this case the services
should be clustered, e.g., a cluster of virtual machines
with the same characteristics. In contrast to the terms,
guarantees are not mandatory in an agreement. If a
guarantee is defined in an SLA, in case of violation
a penalty will be enforced to the service provider. A
guarantee can be referred to a particular term or to any
term in the agreement. When a violation occurs a set
of conditions is evaluated and a set of actions can be
taken. In such case, the conditionAction and actions
should be defined in the SLA. The full semantics of
the language can be found in (Uriarte et al., 2014).
Table 1 illustrates an example of an SLA using
the SLAC language adopted from (Uriarte, 2015).
Assets
System
Vulnerabilities
Threat 1
Threat 2
Threat N
...
...
Threat k
Figure 1: Security terminology.
In the assumed example, prv is a service provider,
while cons is a service user. A virtual machine
(VM) is defined in the agreement with two CPUs and
1 Gb RAM, which are defined by cons:cCput and
cons:RAM respectively. Then, two of the VMs are
clustered with a specific term on response time de-
lay RT delay within [0.0, 0.6]ms. Finally, a term is
defined for the cluster, which means it applies on all
VMs in the cluster, that enables the replication. Note
that in SLAC any term is defined in a range and the
unit after the range, e.g., [1,1] gb means 1 Gb, while
[1,2] # means between 1 and 2 units.
2.4 Security Terminology
Security can be defined as a system property that
allows the system “to perform its mission or criti-
cal functions despite risks posed by threats” (Kissel,
2013), where a threat is defined as “the potential
source of an adverse event” (Kissel, 2013).
In every system there is a set of assets, i.e., val-
ues that need to be protected against a malicious ad-
versary. A vulnerability is described as a flaw in
the system that enables a threat targeting one of the
system assets. An attack is realization of a threat
by exploiting a vulnerability in an attempt to break
a system asset as it is demonstrated in Figure 1.
Countermeasures are “actions, devices, procedures,
or techniques that meet or oppose (i.e., counters) a
threat, a vulnerability, or an attack by eliminating
or preventing it” (Kissel, 2013). One can classify
them as (i) preventive, e.g., encryption, (ii) detective,
e.g., intrusion detection systems, (iii) responsive, e.g.,
blacklisting of a detected attack source (Miede et al.,
2010). Countermeasures support security objectives,
e.g., confidentiality and authentication.
Security process is a continuous process and it
can be split into following steps (Kizza, 2017): (i)
system security policy formulation, (ii) a security re-
quirements elicitation, (iii) a threat identification, (iv)
a threat analysis, (v) a vulnerability identification and
assessment, (vi) a security certification, (vii) a secu-
rity monitoring and auditing. A security policy can be
defined as a set of policies and procedures that regu-
CLOSER 2019 - 9th International Conference on Cloud Computing and Services Science
50

lates actions of people and systems within the infor-
mation system security domain (Lopes et al., 2017).
A policy can be evaluated for violations and enforced
by mechanisms, it states how a high level security
goal is achieved. Applied to a system level, two main
groups of policies can be identified (McDaniel, 2005):
(i) provisioning policies that prescribe a configuration
meeting system requirements; (ii) authorization poli-
cies that map entities and resources into allowable ac-
tions. The latter is split into authentication policies
responsible for stating how an identity of an entity
can be established, and access control policies map-
ping the established identity to a set of corresponding
rights.
3 SECURITY CONSIDERATIONS
IN SLAs
SLAs include a set of attributes and guarantees on
them, all of which are negotiated between a service
provider and a user. These attributes can be quan-
tifiable, e.g., a bandwidth, availability in terms of a
guaranteed up-time, and non-quantifiable, e.g., safety,
security. For the first group, it is straightforward to
provide guarantees in terms of numbers, i.e., define
ranges and conditions under which the attribute is
guaranteed to be kept. However, providing guarantees
for the second group is more challenging. This work
is focused on a non-quantifiable attribute, namely se-
curity, that cannot be straightforwardly assessed by a
number or by the fact that a security mechanism is
being in place.
Security has to be addressed systematically, where
particular solutions support corresponding security
objectives. For example, an encryption protocol un-
der assumptions about adequacy of its implementa-
tion and adequate usage, supports data confidentiality.
However, the fact that encryption is correctly imple-
mented and used, does not say anything about system
security or even data confidentiality, as key handling
and how data is stored at a server, have to be consid-
ered as well for assessing the security level. Given the
complexity of assessing a service security level, it is a
challenge to present it in a comprehensive, structured
and clear way to a service user. Hence, we propose
to divide assessment of the security process required
for the further service negotiation into two parts: (i)
assessment by a third independent party focused on
a systematic side of the process, adequacy of analy-
ses conducted, solutions, policies; (ii) assessment by
a user, who trusts in the assessment conducted by the
third parties and assess, i.e., negotiates, only particu-
lar security solutions, as they may contribute to dif-
ferent levels of security and imply different costs.
In the following we describe the process of incor-
porating security during design-time, and monitoring
and maintaining it at run-time.
3.1 Security process for SLAs
In this work we consider security being incorporated
in an SLA already at the design-time as it is one of
the most important attributes to be considered in sys-
tems being connected to the Internet (i.e., left-hand
side in Figure 2). Moreover, as security is dynamic
by its nature, we consider run-time monitoring of ser-
vices and effects of changes on existing SLA guaran-
tees and possible re-negotiation process, as well (i.e.,
right-hand side in Figure 2).
Figure 2 presents the adopted security pro-
cess (Kizza, 2017) embedded in the SLA develop-
ment process divided into steps from 1 to 10. The
combination of process allows to address security in
a systematic way and develop an SLA for a service
security level. Block 1 includes specification of a ser-
vice, e.g., its functional specification, definition of re-
quired resources and connections. Block 2 contains
application assumptions capturing possible instantia-
tions of service functionalities for the assumed appli-
cation and possible user requirements. Once the ser-
vice and its specification are available, in Block 3 a
security analysis of the service is performed, i.e., rel-
evant security goals are specified, threat and vulnera-
bilities analyses are conducted.
Based on the analysis results security goals are
translated into corresponding requirements. We skip
the implicit step of requirements elicitation and in-
stead, as more relevant for guarantees, present secu-
rity policies and security mechanisms to be imple-
mented, in Block 4 and Block 5 correspondingly. The
term security policy is defined in Section 2.4. We
choose to separate policies and mechanisms in two
blocks as we want to make sure that the detailed tech-
nical specification of a particular mechanism men-
tioned in policies is captured in the right way, and
both further are connected to guarantees.
The security process presented in Blocks 1-5 is
supported by argumentation over adequacy of secu-
rity level of the service. Further, mechanisms and
policies are translated into guarantees, see Block 6,
which contains assertions of what is guaranteed, un-
der which conditions and with which possible follow-
ing actions (e.g., to update, patch, maintain (Russo,
2018)). These guarantees later on are formalized by
an SLA language into SLAs in Block 7. We assume
Blocks 1-7 to present the design phase of the ser-
vice and thus SLAs developed at this stage are the
On Incorporating Security Parameters in Service Level Agreements
51

Security
Analysis
Service
Specification
Application
Assumptions
Security
Mechanisms
Security
Policies
service design/development service operation
Run-Time
Monitoring
Run-Time
Assessment
Refinement
SLA
Guarantees
1
10
2
3
4
5
6
7
8
9
Figure 2: Process of development and maintaining an SLA for a service security level.
ones used for negotiation before the service being pro-
vided.
The rest of blocks (in bold) are used at run-time,
i.e., during the service operation. Security mecha-
nisms have to be monitored at run-time, see Block 10,
to maintain an acceptable confidence level in their ad-
equacy. Security policies also have to be assessed at
run-time, marked as Block 9. These two are separated
in different activities as monitoring implies checking
values of particular parameters, e.g., a real-time check
of consumed bandwidth, while assessment in our case
implies non-quantifiable check, e.g., that policies are
followed. Both blocks provide input to Block 6, as
guarantees has to be checked at run-time, as well, for
identification of possible violations. Once there are
violations or possible changes leading to future vio-
lations, Block 6 sends this information to Block 8,
where a refinement is performed. Block 8 maps the
occurred change to a required refinement of an SLA
and sends this information to Block 7, where the re-
finement is applied, i.e., the required corresponding
action is triggered.
Above we described the development of an SLA
starting at the service design, upon detection at run-
time a violation or a change leading to future viola-
tions, two ways of addressing it are possible. The first
one includes an update of the SLA, i.e., the SLA stays
with the same terms. The second option is that due to
a significant change we have to renegotiate the SLA,
thus basically we develop at run-time a new SLA,
building on top of the existing one.
As mentioned, we propose to divide assessment
of an SLA development process and an SLA itself
between an independent trusted third party and the
service user. Blocks 1-3 represent a part of the se-
curity process and can better be assessed by a secu-
rity expert. Similarly, the quality of design and im-
plementation of Blocks 9 and 10 can be more effec-
tively assessed by a security expert. Users in their
turn, can assess results of Blocks 4-6 captured with
a specific language in SLAs formulated in Block 7.
Note, that SLAs also capture what is monitored and
assessed and provided guarantees, without assuming
that a user can effectively assess the quality of moni-
toring, assessment mechanisms, and their implemen-
tation.
3.2 SLAC Extension
In this subsection we present how guarantees from
Block 6 in Figure 2 are transformed into the cor-
responding SLAs in Block 7. The formalization is
done using the SLAC language, which is briefly de-
scribed in Section 2.3. However, the defined lan-
guage does not support constructs to incorporate se-
curity into it, thus, we built upon the already defined
syntax in SLAC and extend it further to introduce se-
curity considerations within the development process
presented in Figure 2.
The first step towards extending SLAC to cover
security considerations is to add the term objective.
We propose to include possible security objectives in
the syntax, e.g., Confidentiality, Integrity. The objec-
tive can further have various categorization, similar
to the metrics as explained in the language syntax.
For our purpose, we consider to enrich BooleanOb-
jective to include security mechanisms, such as Ac-
cess Control, Encryption, Log, Key Management, In-
tegrity Check. We consider presence of those mech-
anisms and correctness via a binary scale without an
intermediate step reflecting low confidence in the cor-
rectness of an operating mechanism. Thus, we pro-
pose to set the access confidence level in this parame-
ters as Boolean, i.e., it is either correctly implemented
and used or not. Finally, ManagementAction includes
Patch, Update and Maintain, where Patch and Update
enforce a notification to the user about the action be-
ing taken.
As it was described in Section 3 incorporation of
security requires applying the systematic security pro-
cess and an independent assessment provided by a
third party of its results and the process itself. How-
CLOSER 2019 - 9th International Conference on Cloud Computing and Services Science
52

ever, a service user has an opportunity to grasp a high-
light of the process by assessing security policies that
complement security mechanisms. Thus, we propose
to introduce a construct enabling a policy hierarchy
and an indication which policies pool it is a part of,
namely belong. Policies are abstract and formulated
on a high level of details, thus they are often decom-
posed further into (sub)policies associated with a par-
ticular objectives.
4 EXAMPLE
To demonstrate how security considerations can be in-
cluded in an SLA, we extend the example described
in Section 2.3. The provided service is the same, i.e.,
computational resources via a virtual machine, how-
ever now we enrich the system description with re-
lated security requirements. For example, considering
data confidentiality and integrity we can formulate the
following requirements: Requirement 1 – communi-
cation between Cluster and a user is adequately se-
cure, and Requirement 2 – access to Cluster is ade-
quately secure. In both cases the term adequate can
be defined, e.g. according to ISO/IEC 27017 (ISO,
2015).
Considering related policies, there are two main
groups. The first one reflects that systematic part of
the process has to be reviewed independently, thus it
can be formulated via the following non-use case spe-
cific policies: Policy 1 – a security case is built in par-
allel with service development, where security case
is defined as in (Weinstock et al., 2014) and Policy 2
– the security assurance case is assessed by a third
party. The second group of policies is more service
specific and relates to security mechanisms. In this
work we do not consider all required policies but fo-
cus only on those that support data confidentiality and
integrity, namely Policy 3 – the authorization policy,
which includes how authentication and access control
are addressed.
Table 2 describes how the considered exam-
ple can be expressed by means of the pro-
posed extension of the SLAC language in Sec-
tion 3.2. In order to capture relevant security mech-
anisms, Small VM properties (cCpu, RAM) are com-
plimented by authorization which is further pre-
sented by authorization:authentication and
authorization:accessControl. Note, these two
objectives are defined via different types, i.e., authen-
tication just needs to be in place (boolean), as there
is no related (sub)policy, only a mechanism that can
be associated, and accessControl has a corresponding
policy that belongs to the pool of authorizationPol-
Table 2: The SLA example illustrating the proposed lan-
guage extension.
term group:
Small VM:
prv → cons:cCpu in [1,2] #
prv → cons:RAM in [1,1] gb
prv → cons:authorization:
authentication is True
prv → cons:authorization:
accessControl belong to
authorizationPolicy
prv → cons:password has
{Char[8]}, {INT, SYMB}
Cluster:
prv → cons:RTdelay in
[0.0,0.6] ms
prv → cons:encryptionAES
in [128, 256] b
[2,2] of Small VM
terms:
[1,1] of Cluster
prv → cons:replication is True
prv → cons:encryption is True
prv → cons:authorization is
True
icy. This policy defines which rights are granted to
a particular authenticated user and might depend on
e.g., a user, current service status, time of the day,
location from where access is requested. Addition-
ally, Small VM has an objective regarding a possible
stored password, as the point of the example is just
to illustrate the approach, we consider a simple pass-
word structure and do not consider a key management
and distribution. Above we consider authorization for
a particular virtual machine, additionally at the Clus-
ter level we have an objective supporting secure data
transmission, namely encryptionAES, i.e., support
for data encryption by means of the Advanced En-
cryption Standard (AES) algorithm. Finally, in terms
we specify that the encryption and authorization
may be included in the contract and their inclusion
is a part of negotiation. Note, that the assessment of
the algorithm’s implementation, done by a third party,
depends on an assessor and evidences provided in the
corresponding security case, while negotiation is done
only upon including or not including those security
mechanisms.
Moreover, one can specify guarantees to define
actions given that a violation for an existing SLA
occurs. Within guarantees one have a possibility to
enforce quality of the service or an action will be
taken in case of violations. In Table 3 we choose
to put guarantees on encryption being in place
and accessControl defined based on policies in
authorisationPolicy. In case of violation of such
On Incorporating Security Parameters in Service Level Agreements
53

Table 3: Guarantees for the SLA example in Table 2.
guarantees:
On violation of any:
IF encryption FALSE
OR accessControl NOT belong to
authorisationPolicy
update in 24 hour AND negotiate
ELSE
update in 24 hour AND bonus:
1 hour of ([1,1] of Cluster)
guarantees a provider is obliged to provide an update
action within specified time and renegotiate with user
(update in 24 hour AND negotiate). In case of
such agreement between provider and user, one could
choose to charge penalties in terms of bonus (bonus:
1 hour of ([1,1] of Cluster)).
Making service provision more flexible especially
with regard to security related violations, one can look
into different degrees of violations. It may help to
provide means to distinguish and correspondingly re-
spond differently to e.g., regular patching in a mainte-
nance manner and a specific attack. Considering han-
dling of new vulnerabilities, one can look into a vul-
nerabilities classification, e.g., a Common Vulnerabil-
ities Scoring System (CVSS) (Mell et al., 2006), and
provide responses correspondingly. In this work we
do not go further in fine tuning guarantees in regards
to different degrees of violation, as we only illustrate
the main concept of incorporating security.
5 RELATED WORK
Addressing elicitation of security requirements for
SLAs, in cloud services domain, is still in evolving
stages. Luna et al. (Luna Garcia et al., 2012) justify
the need of cloud administration architectures which
depend on security requirements in an SLA. To iden-
tify the security parameters, there are distinct interna-
tional standardization and rules, which help in spec-
ifying a common classification of security controls
with both specialized and non-specialized features of
security, i.e., the ISO27002 standard (ISO/IEC 27002,
2013), the NIST Security Control Framework (NIST
SP-800-53, 2013), and the Cloud Control Matrix -
CCM – from Cloud Security Alliance (Cloud Security
Alliance, 2013). An SLA alone does not ensure that
the predetermined characteristics are met, but rather
it characterizes the necessary monitoring mechanisms
and actions following up identified events. Service
level monitoring and support for its run-time adapta-
tion are as imperative as the specification of an SLA.
Different commercial cloud service providers usu-
ally have their own solution for service monitoring.
Microsoft Azure Suite (Microsoft Corporation, 2010)
provides Azure Fabric Controller, which observes
and oversees the servers, and also assigns resources
for applications. The Amazon AWS platform offers
CloudWatch (Amazon Web Services, 2006), where an
observing framework has been offered for the control
of resources and application administration. Google
App Engine (Google, 2008) offers different monitor-
ing solutions, e.g., CloudStatus (Hyperic, 2008) by
utilizing a different set of APIs. All above mentioned
providers do not offer SLAs with specific security
guarantees, yet. Currently, a user cannot customize
security features required for an application as docu-
ments that describe security in general are available.
Thus, a user is lacking a possibility to specify a re-
quired security level and assess the satisfaction of the
requirements from the provider’s side.
Petcu et al. (Petcu, 2014) have investigated moni-
toring types, monitoring behavior and a level of mon-
itoring in the cloud services context. Based on their
findings, security monitoring can be executed: on-
premises, on monitored Infrastructure as a Service
(IaaS) or via Software as a Service (SaaS). Security
Information and Event Management (SIEM) systems
are used in the first two cases. In the first case, a SIEM
system uses specific APIs to collect logs from servers,
whereas in the second case, a SIEM system can be
loaded directly into an IaaS. In the last case, a partic-
ular information from the cloud services is gathered
(if accessible) and handed over to a security service
provider. Mu
˜
noz et al. (Mu
˜
noz et al., 2012) have iden-
tified two types of approaches for monitoring soft-
ware assets that provide assurance of the behaviors
of software elements, static and dynamic. Static ap-
proaches focus on checking the security at develop-
ment time, usually in simulated environments, while
the dynamic approaches such as monitoring, surveil-
lance and other forms of runtime analyses focus on
the observation of the run-time software behavior.
Based on work of Aceto et al.˙(Aceto et al., 2013),
one can distinguish between high and low level mon-
itoring. The former relates to information on the
status of the virtual platform that is collected at the
middleware, application and user layers by providers
or users through platforms and services operated by
themselves or by third parties. The latter relates to
information collected by the providers and usually
not exposed to the users, with focus on the status of
the physical infrastructure of the whole cloud (e.g.
servers and storage areas). Security monitoring can
be considered within high-level monitoring, while in
low-level monitoring, specific utilities for collecting
information about security might be related to the
CLOSER 2019 - 9th International Conference on Cloud Computing and Services Science
54

hardware layer, workload, voltage, temperature, to the
operating system, software vulnerabilities and bugs,
etc.
Kaaniche et al. (Kaaniche et al., 2017) present
an SLA monitoring system based on the rSLA
framework for the security properties in cloud ser-
vices. Their work also describes the whole life-
cycle of an SLA along with addressed security issues.
Emeakaroha et al. (Emeakaroha et al., 2012b), present
the DeSVi architecture used to detect an SLA viola-
tion via resource monitoring. The fundamental seg-
ments of the architecture are the automatic VM de-
ployer, in charge of the distribution of resources and
for mapping of assignments; application deployer, in
charge of the execution of client applications; and
LoM2HiS framework that screens the execution of the
applications and makes an interpretation of low-level
metrics into high-level SLAs. In their work they fo-
cus on monitoring and detecting an SLA violation at
cloud infrastructure level only, but do not consider the
application layer. In the other work, Emeakaroha et
al. (Emeakaroha et al., 2012a) propose an architecture
for monitoring, SLA violation identification at the ap-
plication provisioning layer in Clouds, named Cloud
Application SLA Infringement Detection (CASViD).
The focus is on the application-level monitor, which is
equipped for monitoring application measurements at
runtime to decide their asset utilization practices and
execution. Casola et al. (Casola et al., 2016b) provide
a methodology to guide development of catalog of se-
curity services. Using such a methodology a user can
negotiate and monitor the security adequacy of secu-
rity services. The use of this system is the premise
to empower the automatic enforcement of Security-
as-a-Service. Moreover, the authors have proposed
an approach to tackle this issue by introducing a per-
service SLA model, which entails the use of a “tai-
lored” SLA for each service. Rojas et al. (Rojas et al.,
2016) propose a framework that provides a manage-
ment of cloud services using the information about
security requirements defined by the SLA, automati-
cally, during its entire lifecycle. Moreover, proposed
mechanisms offer support of all the phases of the SLA
lifecycle. The framework comprises two sides: the
user side that provides the interface to communicate
with the provider, and the provider side that contains
the proposed framework and their reconciliation with
the cloud services infrastructure.
Silva et al. (da Silva and de Geus, 2014) propose
a methodology to support the concept where a user
may choose security metrics of required services with
continuous monitoring provided by the environment.
Authors focus on automatic creation of an SLA with
security metrics defined and the depiction of the mon-
itoring process for the cloud service infrastructure.
They monitor security through a range of values (0
– 4) and focus on the problem of managing intangible
and unmeasurable numbers. Moreover, they provide
a way to manage security levels (top-down view) that
considers values for each security metric with its re-
spective risk, Quality of Service (QoS) and impact.
When compared to our approach, most of the
above described contributions do not consider the spe-
cific security metrics being in place, i.e., encryption,
authentication, authorization, etc., thus ways how se-
curity is expressed is limited. The closest work to
ours is the one presented by Mu
˜
noz et al. (Mu
˜
noz
et al., 2012). However, compared to that work we go
one step further and in the process assume an external
third-part security assessor to maintain the quality of
the SLA design.
6 CONCLUSIONS
The current state of the art limits SLAs to consider
only those service quality attributes that are possible
to be expressed using quantifiable metrics, such as
performance, reliability, etc. However, given the de-
velopment of cloud computing and new ways services
are provided to their users, we find it as an important
task to enable non-quantifiable qualities, such as secu-
rity and safety to be included in SLAs, as well. There
are some works that have already put some effort in
defining ways to include security into an SLA (Mu
˜
noz
et al., 2012; Casola et al., 2016b; Kaaniche et al.,
2017), mostly focusing on expressing security levels
or security in terms of availability. However, we tar-
get to provide an SLA that includes a larger set of
security objectives (i.e., in context of CIA triad) dur-
ing the design-time such that user gets guarantees on
what is provided with respect to security. Moreover,
we need to enable an SLA monitoring, maintenance,
and renegotiation in case a provider fails at providing
the guaranteed level of security.
To enable this, we have first propose a process of
SLA development and maintenance in order to be able
to capture security-relevant information and provide
guarantees on top of it. Secondly, we extend syntax of
an already existing SLA language, SLAC, to include
security objectives. Additionally, an example of a ser-
vice being provided with security guarantees captured
within an SLA is used to illustrate the concept.
In the future work, we aim at implementing the
constructs into the existing tools. Moreover, we plan
to investigate how to address a confidence level in
security SLA and possible degrees of violations and
their consequences.
On Incorporating Security Parameters in Service Level Agreements
55

ACKNOWLEDGEMENTS
This work is supported by the Serendipity project
funded by SSF, the SAFSEC-CPS project funded by
The Knowledge Foundation, the FiC project funded
by SSF, and within the context of the XPRES frame-
work.
REFERENCES
Aceto, G., Botta, A., de Donato, W., and Pescap
`
e, A.
(2013). Cloud monitoring: A survey. Computer Net-
works, 57(9):2093 – 2115.
Amazon Web Services (2006). Inc. amazon cloudwatch.
http://aws.amazon.com/cloudwatch.
Broy, M., Kr
¨
uger, I. H., and Meisinger, M. (2007). A formal
model of services. ACM Trans. Softw. Eng. Methodol.
Casola, V., Benedictis, A. D., Modic, J., Rak, M., and Vil-
lano, U. (2016a). Per-service security sla: A new
model for security management in clouds. In IEEE
25th International Conference on Enabling Technolo-
gies: Infrastructure for Collaborative Enterprises,
pages 83–88.
Casola, V., d. Benedictis, A., Eras¸cu, M., Rak, M., and
Villano, U. (2016b). A security sla-driven method-
ology to set-up security capabilities on top of cloud
services. In 2016 10th International Conference on
Complex, Intelligent, and Software Intensive Systems,
pages 549–554.
Cloud Security Alliance (2013). Cloud control matrix v3.0.
da Silva, C. A. and de Geus, P. L. (2014). An approach to
security-sla in cloud computing environment. In IEEE
Latin-America Conference on Communications, pages
1–6.
Emeakaroha, V. C., Ferreto, T. C., Netto, M. A. S., Brandic,
I., and Rose, C. A. F. D. (2012a). Casvid: Application
level monitoring for sla violation detection in clouds.
In 2012 IEEE 36th Annual Computer Software and
Applications Conference, pages 499–508.
Emeakaroha, V. C., Netto, M. A., Calheiros, R. N., Brandic,
I., Buyya, R., and Rose, C. A. D. (2012b). To-
wards autonomic detection of sla violations in cloud
infrastructures. Future Generation Computer Systems,
28(7):1017 – 1029. Special section: Quality of Ser-
vice in Grid and Cloud Computing.
Google (2008). Inc. google app engine. https://developers.
google.com/appengine/.
Hyperic (2008). Cloud status. http://www.hyperic.com/
products/cloud-status-monitoring.
ISO (2015). ISO/IEC 27017: Information technology – Se-
curity techniques – Code of practice for information
security controls based on ISO/IEC 27002 for cloud
services.
ISO/IEC 27002 (2013). Information technology, security
techniques, code of practice for information security
management. International Organization for Stan-
dardization.
Jaatun, M. G., Bernsmed, K., and Undheim, A. (2012). Se-
curity slas – an idea whose time has come? In Quirch-
mayr, G., Basl, J., You, I., Xu, L., and Weippl, E.,
editors, Multidisciplinary Research and Practice for
Information Systems, pages 123–130, Berlin, Heidel-
berg. Springer Berlin Heidelberg.
Kaaniche, N., Mohamed, M., Laurent, M., and Ludwig, H.
(2017). Security SLA Based Monitoring in Clouds. In
2017 IEEE International Conference on Edge Com-
puting, pages 90–97.
Keller, A. and Ludwig, H. (2003). The wsla framework:
Specifying and monitoring service level agreements
for web services. Journal of Network and Systems
Management, 11(1):57–81.
Kissel, R. (2013). Glossary of key information security
terms, Revision 2. U.S. Dept. of Commerce, National
Institute of Standards and Technology.
Kizza, J. M. (2017). Security Assessment, Analysis, and
Assurance. Springer.
Kouki, Y. and Ledoux, T. (2012). CSLA : a Language
for improving Cloud SLA Management. In Interna-
tional Conference on Cloud Computing and Services
Science.
Kyriazis, E. D. (2013). Cloud computing service level
agreements - exploitation of research results. Euro-
pean Commission Directorate General Communica-
tions Networks, Content and Technology Unit E2 –
Software and Services, Cloud.
Lopes, I. M., Pereira, J. P., and Oliveira, P. (2017). Def-
inition of information systems security policies. In
Rocha,
´
A., Correia, A. M., Adeli, H., Reis, L. P.,
and Costanzo, S., editors, Recent Advances in In-
formation Systems and Technologies, pages 225–234,
Cham. Springer International Publishing.
Luna Garcia, J., Langenberg, R., and Suri, N. (2012).
Benchmarking cloud security level agreements using
quantitative policy trees. In Proceedings of the ACM
Workshop on Cloud Computing Security Workshop,
pages 103–112, New York, NY, USA. ACM.
Maarouf, A., Marzouk, A., and Haqiq, A. (2015). A review
of sla specification languages in the cloud computing.
In 10th International Conference on Intelligent Sys-
tems: Theories and Applications.
McDaniel, P. (2005). Policy, pages 461–464. Springer US,
Boston, MA.
Mell, P., Scarfone, K., and Romanosky, S. (2006). Common
vulnerability scoring system. IEEE Security Privacy,
4(6):85–89.
Microsoft Corporation (2010). Microsoft azure. http:
//www.windowsazure.com.
Miede, A., Nedyalkov, N., Gottron, C., K
¨
onig, A., Repp, N.,
and Steinmetz, R. (2010). A Generic Metamodel for
IT Security Attack Modeling for Distributed Systems.
In International Conference on Availability, Reliabil-
ity and Security.
Mu
˜
noz, A., Gonzalez, J., and Ma
˜
na, A. (2012). A
performance-oriented monitoring system for security
properties in cloud computing applications. Comput.
J., 55(8):979–994.
CLOSER 2019 - 9th International Conference on Cloud Computing and Services Science
56

NIST SP-800-53 (2013). Nist sp-800-53: Recommended
security controls for federal information systems. Na-
tional Institute of Standards and Technology.
Petcu, D. (2014). SLA-Based Cloud Security Monitor-
ing: Challenges, Barriers, Models and Methods. In
Lopes, L.,
ˇ
Zilinskas, J., Costan, A., Cascella, R. G.,
Kecskemeti, G., Jeannot, E., Cannataro, M., Ricci, L.,
Benkner, S., Petit, S., Scarano, V., Gracia, J., Hunold,
S., Scott, S. L., Lankes, S., Lengauer, C., Carretero,
J., Breitbart, J., and Alexander, M., editors, Euro-
Par 2014: Parallel Processing Workshops, pages 359–
370, Cham. Springer International Publishing.
Rojas, M. A. T., Gonzalez, N. M., Sbampato, F. V.,
Red
´
ıgolo, F. F., Carvalho, T., Ullah, K. W., N
¨
aslund,
M., and Ahmed, A. S. (2016). A framework to or-
chestrate security sla lifecycle in cloud computing. In
2016 11th Iberian Conference on Information Systems
and Technologies, pages 1–7.
Russo, M. A. (2018). STEP1: The Cloud Service Level
Agreement (CSLA). Cyber Risk LLC.
Uriarte, R. B. (2015). Supporting Autonomic Management
of Clouds: Service-Level-Agreement, Cloud Monitor-
ing and Similarity Learning. PhD thesis, IMT Institute
for Advanced Studies.
Uriarte, R. B., Tiezzi, F., and Nicola, R. D. (2014). Slac:
A formal service-level-agreement language for cloud
computing. In 2014 IEEE/ACM 7th International
Conference on Utility and Cloud Computing, pages
419–426.
Weinstock, C. B., Lipson, H. F., and Goodenough, J. (2014).
Arguing security – creating security assurance cases.
On Incorporating Security Parameters in Service Level Agreements
57
