Applying Variability Management in the Development of a Complex

SaaS System: Real Experience and Findings

Leticia González Folgueira, Oscar Pedreira, Ángeles Saavedra Places and Fernando Silva-Coira

Facultade de Informática, Universidade da Coruña, Campus de Elviña s/n, A Coruña, Spain

Keywords: Variability, SaaS, Home Care System.

Abstract: In this work, we present the complex problem of the variability that has a SaaS application for Home Care

System that we have developed. We detail how was the management of this variability that was increasing as

the number of clients grew (currently more than 130 companies use our application of Home Care Service in

different municipalities). Thanks to the fact that the different needs of these companies and municipalities

were managed from the beginning as points of variability, we were able to undertake the development of

variations in the functionalities of the developed software. We also present the variability management tool

that we have developed to give autonomy to the platform's marketing team. Finally, we highlight the lessons

learned and present an approach to evaluating the cost of managing variability.

1 INTRODUCTION AND

MOTIVATION

Delivering software as a service (SaaS) has become a

major trend in the last years. This approach allows the

customers to forget about aspects such as complex

software deployments, maintenance, and managing

and maintaining a hardware and network

infrastructure for their information systems. This

approach has also many advantages for the developer

companies, such as a greater control on the software

and more flexible licensing schemas. However, it also

presents some challenges.

Typically most customers share a large set of

features, but they must be able also to customize the

software in some way, for example, adding or

removing functionalities, or parametrizing the

software so its behavior changes to adapt to the

particular customer needs. This usually results in a

complex parametrization of the software that must be

handled carefully. A promising approach for dealing

with variability analysis and modeling in these

environments is that of feature-oriented analysis

(Apel, 2013; Siegmund, 2017; Galster, 2016). This

approach has already been considered in previous

work, such as (Moens, 2012; Lizhen, 2010; Mietznet,

2009; Weiping, 2009).

In this paper, we present a real experience in using

variability modeling and management to analyze and

model the variability of a complex web system

delivered as a service, more specifically, a system for

managing home care services for dependent people.

In addition to present the system and the result of the

variability modeling, we also present results on the

real use of the system and the different variability

points we have identified and developed.

This project has been developed in Spain, where

all city councils have the obligation to present a home

care service to dependent people. These people are

evaluated according to their medical and economic

situation by the municipal technicians, who finally

assign them a number of weekly hours of attention

and a price to pay for them (which can range from 0€

to a growing percentage of the real cost according to

their economic situation).

However, city councils, in general, do not provide

this service directly, but they subcontract it to

specialized companies. These companies are the ones

that really provide the service and the city council

gives indications and monitors the work of that

service. This subcontracting is done through public

bidding and the subcontracted companies compete in

the hourly price that they will charge for the service.

The management of this service is extremely

complex for both companies and city councils. On the

one hand, the hourly price of the service the

municipality pays to each company depends on the

conditions of the contract and can also specify a price

for different days (weekdays, weekends, holidays,

Folgueira, L., Pedreira, O., Places, Á. and Silva-Coira, F.

Applying Variability Management in the Development of a Complex SaaS System: Real Experience and Findings.

DOI: 10.5220/0007234103910397

In Proceedings of the 14th International Conference on Web Information Systems and Technologies (WEBIST 2018), pages 391-397

ISBN: 978-989-758-324-7

391

nights, etc). On the other, companies have to pay full

salaries to their assistants (not for the hours they

worked, which makes it critical for them to plan the

service that minimizes the displacement of assistants

between homes). In addition, each user pays the hours

of service actually received each month with a

percentage of their cost. The cost varies from user to

user according to their economic situation.

In addition to charging and billing, the service

organization itself is complex because there are

dependents who should always receive the service

(they depend on it to eat, get out of bed or to have a

minimum hygiene). On the other hand the auxiliaries

have the right to vacations, days off and sick leave,

however, replacing them is complex as it sometimes

requires increasing the number of work hours of other

colleagues, which is only possible within certain legal

limits. Besides, dependents have periods of

hospitalization or travel to their family home which

means interrupting the service (and stop paying) but

the company must continue to pay the salary to their

assistants and always minimize periods without work

or of displacement between users since they do not

charge for them.

Finally, municipalities want to be informed of

everything at any time, especially the hours of arrival

and departure of each assistant to each domicile and

when a dependent changes his assistant, as frequent

changes mean a low quality of service.

In order to solve this complex problem, we

developed an application that is being marketed as

SaaS and is currently in use in more than 130 Spanish

city councils, especially in Galicia. This application

offers a company profile and a city council profile to

access the data of each municipality, so that the

application itself serves as a means of communication

between them. The check-in in each domicile is

achieved by calls from the number of the domicile to

a special phone number of a digital switchboard and

is reflected in the database available to the city

council and company. On the other hand, a

mechanism is offered so that the company can

efficiently plan the organization of the service and the

scheduling of its assistants. The city council can also

access this planning and see which assistant provides

service to each user each day.

Although the mechanics of work are similar in all

companies and municipalities, the reality is that

points of variability began to emerge from the

beginning. This is due to the fact that different

companies and city councils have different protocols

of action and, logically, they wanted the management

application to support their way of working.

Aware that the variability management is in

general a preferable option to the development of

independent versions that are installed independently

to each client, we assumed from the beginning that

each variant in a point of variability should be

implemented in the code as an alternative to the flow

of execution, dependent on a control parameter of that

point of variability. These parameters are inserted in

the database associated to each client. Thanks to

making this design decision from the beginning, we

have been able to undertake the growing development

of new functionalities that have been bringing new

points of variability as described in Section 3.

The rest of the paper is organized as follows.

Section 2 describes some aspects of the Home Help

Service management necessary to understand the

points of variability. Section 3 describes the different

points of variability integrated in our application,

both for the city council and the company. Section 4

presents an empirical analysis of the real deployment

of the system and how the different variability points

are being used. Finally, Section 5 presents the

conclusions of the paper.

2 PROBLEMATIC OF THE

VARIABILITY OF THE HOME

CARE SERVICE

A fundamental concept in the management of the

home care service is that of a “bag of hours”, that is,

the number of hours that each assistant works in a

given period. Managing these data for each assistant

allows the company of a home care service to

automatically have up-to-date and detailed

information about the hours hired and worked by their

employees, in addition to other data of interest.

Calculations of the bag of hours are held weekly at

the end of each week. The bag of hours is shown as a

table where its main columns are:

● Nº of hired hours: Number of hours assigned

to the employee for his current contract.

● Nº of worked hours: Number of hours

actually worked by the employee. For this,

the hours of the services carried out in a

period of time are added. Certain factors are

also taken into account, such as absences or

services canceled at the request of a user.

● Nº of complementary hours: Number of

overtime hours worked beyond the time

hired and paid separately.

● Nº of permission hours: Number of paid

hours (permission, holidays, public

APMDWE 2018 - 3rd International Special Session on Advanced practices in Model-Driven Web Engineering

392

holidays, sick leave, etc) and unpaid

permissions.

● Balance of hours: Difference between hours

contracted and hours actually worked and

paid permits.

In the generation of these data, in addition to the

information of the services worked by each

employee, a multitude of parameters are involved.

Further, each city council and company calculate the

bag of hours differently, taking into account certain

factors of interest. Therefore, the bag of hours is a

challenge due to its high complexity and variability.

Another complex part of the system is the billing

of services. The company and the city council

generate invoices for the services in a certain period

of time. Therefore, it is necessary to generate both the

invoice that the company charges the city council for

providing the service and the invoice that users must

pay to the city council, although in some cases

companies are allowed to directly bill users.

3 POINTS OF VARIABILITY

The points of variability of this system follow a

specific hierarchy. The parameters that allow the

different users to adapt the behavior of the software

to their needs can be grouped in parameters for city

council (those that affect the city council and the

companies), parameters for the company (those that

affect the company and, if it is the case, each auxiliary

of the company) and parameters for each auxiliary

assistant of a company (each auxiliary can have a

different value for these parameters).

Secondly, there are several kind of variability

points according to the possible values that can be

selected. They can be classified into three types:

option Yes/No, option of a list of values and

configurable value.

3.1 Parameters for a City Council

The following parameters can be configured by each

city council:

. Cohabitation Unit: it allows to include if

other members of the cohabitation unit are also

beneficiaries of the Home Care Service. Possible

values are Yes/No.

. Visualize the Planning of the Assistants of

Other Companies Providing the Same City

Council. In certain city councils, they contract

several companies for the home care service. In order

to improve the coordination between them, this

parameter allows a company to visualize the

planification of the assistants of the other companies.

Possible values are Yes/No.

. Report Template: Template to be used in

all communications generated automatically between

the city council and the company and vice versa. In

this case, the application offers a generic template for

all communication or one template for each type.

Communications are an essential part of the home

care service and it is necessary to notify certain events

that occur during the provision of the service by the

company.

. Document Language: Languages of

documents generated in PDF format. Currently, the

supported languages are Spanish, Galician and

Catalan. Being a public service, municipalities

require you to use any of their official languages. For

example, all councils in the region of Galicia must be

able to use Galician and Spanish.

. Companies Invoice Users: Users must pay

part of the service received. Such services are billed

by the city council or directly by the company. It

indicates whether companies will bill the users or it is

a responsibility of the city council. The possible

values are Yes/No.

. Type of Billing to Users: It indicates how

the hours to bill each user are counted. There are

different values that can be selected:

● By carried out service.

● By maximum of assigned hours.

● By assigned hours.

● By assigned hours (excess borrowed).

. Computation for the Billing of Public

Holidays to Users: It indicates that public holidays

are billed (if service is available that day). Usually,

services on holidays are charged as special services

and have a different price than one business day.

Options are: “Only public holidays”, “Only Sundays,

Saturdays and Sundays”, “ Public holidays and

Sundays” and “Saturday afternoons, Sundays and

public holidays” (in the last case is necessary to

indicate the start time of the holiday on Saturday

afternoon).

. Rounding of Total Hours Invoiced to

Users: In monthly invoicing, indicate whether

fractions of hours are invoiced or rounded to a integer

number. Possible values are Yes/No.

3.2 Parameters for a Company

The following parameters can be configured by each

company:

Applying Variability Management in the Development of a Complex SaaS System: Real Experience and Findings

393

. Telephonic Check-in: It allows assistants to

check-in and check-out their service by making a call

to a virtual phone number. With this information the

city council and the company can know the absences

of their assistants, or if an assistant has arrived late (or

has left before) an domicile, for example. It is also

used by the application to generate invoices. Possible

values are Yes/No.

. Calculation for Displacement Time:

Assistants attend several users in the same day, so

they have to move from one domicile to another

during their workday and several times. During the

planning process this time is taken into account when

assigning services to assistants and it is also shown in

the bag of hours. This parameter allows to indicate the

means of transport that is used for the displacement.

This option has two values; driving and walking.

. Computation for Public Holidays for Bag

of Hours: It indicates that public holidays are

computed for generation of the hours bag. Options are

“Only public holidays”, “Only Sundays”, “Saturdays

and Sundays”, “Public holidays and Sundays” or

“Saturday afternoons, Sundays and public holidays”

(in the last option is necessary to indicate the start

time of the public holiday on Saturday afternoon).

. Time to Bill in Each Service: The list of

options are:

● Always schedule time: The planned duration

is invoiced for each service.

● Carried out time (only if it is lower than

schedule time): The actual duration is

invoiced for each service, in case the

duration is less than the planned duration,

for example, a service of 60 minutes is

finally billed 55 minutes. Otherwise the

planned duration is invoiced, for example if

the 60-minute service was finally completed

in 65 minutes, the 60 planned minutes will

be billed.

● Always carried out time: The actual duration

is always billed, regardless of whether it is

lower or greater than the planned time.

. Margin Minutes: In the billing types

"Carried out time (only if it is lower than schedule

time)" and "Always carried out time" a margin is

established from which the time carried out is counted

and not the planned time. For example, if for a 60-

minute scheduled service, 59 minutes are finally

performed, it will probably be interesting to invoice

the 60's as well. However, if 50 minutes are done, it

is already interesting to invoice 50. This margin could

be any positive integer.

. Field to Include in the Schedule Report

for Each Assistant: Assistants receive a report from

the company with their current planning. It shows the

work schedules and the users that must be attended.

Report can included the following fields for each user

who attends, which actually have been modelled as

four different boolean points of variability:

● Name and surname (VP

14·1

)

● Telephone number (VP

14·2

)

● Register number (VP

14·3

)

● Total number of kilometers between

services (VP

14·4

)

. Type of Billing to City Council: It

indicates how the hours to bill each city council are

counted. There are different values that can be

selected:

● By carried out service.

● By maximum of assigned hours.

● By assigned hours.

● By assigned hours (excess borrowed).

. Computation for the Billing of Public

Holidays to City Council: It indicates that public

holidays are billed (if service is available that day).

Options are: “Only public holidays”, “only Sundays,

Saturdays and Sundays”, “ Public holidays and

Sundays” and “Saturday afternoons, Sundays and

public holidays” (in the last case is necessary to

indicate the start time of the holiday on Saturday

afternoon).

. Rounding of Total Hours Invoiced to

City Council: In monthly invoicing, it indicates

whether fractions of hours are invoiced or rounded to

a integer number. Possible values are Yes/No.

. Time Control in the Scheduler: It

indicates whether prevents confirm plans that do not

meet exactly the scheduled time of the intervention

plan. Possible values are Yes/No.

3.3 Parameters for an Assistant

. Calculation of Hours Worked on Public

Holidays: It indicates if the hours worked on holidays

will compute double for that assistant. Possible values

are Yes/No.

. Calculation of Hours in the Last Week of

the Month: It indicates how to reflect in the bag of

weekly hours the division of a week in two months

(end of a month and beginning of the next). There are

two possible values:

● Real: Hours worked, permits and others

account for the part of the week in which

they actually take place.

APMDWE 2018 - 3rd International Special Session on Advanced practices in Model-Driven Web Engineering

394

● Proportional: A proportional distribution is

made in the two parts of the week in which

the calculation is divided.

. Calculation of Rest Time after 6

Continuous Hours of Work: It indicates whether a

rest time will be counted in the bag of hours as time

worked. Possible values are Yes/No.

. Minutes of Rest Time to Compute: In the

case of computing a rest period in the bag of hours,

this parameter indicates the number of minutes to be

computed. The value is a positive integer value.

4 EMPIRICAL ANALYSIS

In this section we present an analysis of the

deployment of the software for different customers

over a period of two years. In this analysis we will

focus especially in the use of the variability points we

have described in previous sections for the different

user types (councils, companies, and workers).

As we have already explained in the introduction

of the paper, the system has been developed as a

service, so variability analysis and modelling has not

been applied as a way of obtaining (or automatically

generating) different versions of this software, but as

a tool for identifying and modelling all the parameters

that define the variability points required by each user

type. From its deployment, it has been

commercialized to a total of 100 councils and 132

assistance companies, which has resulted in 3554

workers using the platform to reflect the result of their

daily work (see Table 1).

Table 1: Number of users of each user type in the real

deployment over a period of two years.

User type

# of users

City council

100

Assistance company

132

Auxiliar

3554

Although these data may seem strange at first,

remember that the service provided by this system

can be purchased by city councils, assistance

companies or a combination of both. That is, an

assistance company may use the system to manage

the daily operations even if the city councils for which

it works are not using the platform (or vice versa).

In the analysis of the real deployment we have

especially focused on how the different variability

points we have developed have been used. Table

2 shows for each variability point and for each of its

possible options, the number of users who are

currently using each option. The table structures in

three sections the variability points for the three user

types supported in the software: councils (variation

points from 1 to 8), companies (variation points from

9 to 18), and auxiliary assistance workers (variation

points from 19 to 22).

The description of the variability points provided

in the previous section states the different values for

each of them. Most of them can take just two values

(yes or no), while others can take more values (for

example, VP

can take five different values).

Interesting results can be seen in the data shown

in Table 2. In most variation points one of the values

is used by a large portion of the customers, so that

value acts as a kind of default value. More

interestingly, here is an important difference between,

for example, the variation points VP

and VP

. Both

can be used by city councils but, while 19 users use

the first option for VP

, only one uses that value for

. This triggered an important question for a real

software development company. According to these

data, we concluded that introducing the variation

point VP

in the system was worthwhile, since a 81%

of the customers are using the default option for this

point, while a 19% are using the other option.

However, in the case of VP

only one customer is

using an option different from the default value. Was

it worthy/profitable to introduce this variation point

in the system? It is not so clear in this case. From the

data, it just seems that this variation point does not

respond to a clear need of many options for an

average customer, but for something that may have

been identified as a variation point but that was really

a customized development for the specific need of

one customer.

Without the pretension of establishing a formal

and complete metric to evaluate the usefulness of

introducing a variation point in a system, we have

further analyzed these data by computing for each

variation point the quotient between the smallest and

the largest values between the number of users who

chose each option for the binary variation points.

Figures from 1 to 3 graphically represent the results

we obtained for each user type. As we can see in the

results, some variation points can be considered more

valuable than others from the point of view of the

number of users using each possible option for them.

Although this would require a greater effort, we think

that this may be a basis for establishing a way of

deciding if a given development must be included in

Applying Variability Management in the Development of a Complex SaaS System: Real Experience and Findings

395

Table 2. Number of users taking each value (Vi) for each variation point (VP

the system as a variation point or if it should be

considered as a customized development for a given

customer.

Figure 1. Use of the variation points for councils.

Figure 2. Use of the variation points for companies.

Figure 3. Use of the variation points for auxiliar assistance

workers.

5 CONCLUSIONS

In this paper, we have presented a real experience on

using variability management to analyze and model

the variability in a complex real web system delivered

as a service. Applying variability management has

allowed the developers to analyze the variation points

of the system under a solid framework, and in a

systematic and comprehensive way. This approach

has allowed the development team to deal with

variation in an easy and natural way.

In addition to presenting the system and the

variation points we have identified during its

development, we have presented real data on the

APMDWE 2018 - 3rd International Special Session on Advanced practices in Model-Driven Web Engineering

396

deployment of the system and the use of the variation

points introduced in the system by the different user

profiles it supports (councils, companies, and auxiliar

assistants). In this analysis we have found interesting

results regarding the use of the variation points. Some

of them are considered by the company that

developed the system as worthwhile or profitable,

since many customers use of the options and also

many users use the other options for that variation

point. However, the data also reflect that some

variation points have been developed only for the

specific need of one specific customer, so they are

considered by the company that developed the system

as less profitable.

In addition, while dependencies had not been

found during the variability analysis, the data

suggests that some dependencies do really exist

among different features, since the number of

customers using one of its options is the same.

We consider that these results raise interesting

questions for future work, in which we are currently

working. First, some way of introducing the concept

of return on investment in the variability management

framework would be of interest for many companies,

since this would help not only in identifying and

analyzing variation points, but also in making the

decision of whether introducing them in the system is

worth or not. On the other hand, this real project has

helped us to detect that identifying dependencies

between features is not always direct during the

analysis phase. Analyzing the real-world data

collected from real systems to try to automatically

identify such dependencies is also an interesting

problem for future work.

ACKNOWLEDGEMENTS

This work has been funded by Xunta de Galicia /

FEDER-UE CSI: ED431G/01 (Centros ingulares de

Galicia), Xunta de Galicia / FEDER-UE CSI:

ED431C 2017/58 (Grupo de Referencia

Competitiva), MINECO-CDTI / FEDER-UE CIEN

LPS-BIGGER: IDI-20141259, MINECO-CDTI /

FEDER-UE INNTERCONECTA uForest: ITC-

20161074, MINECO-AEI / FEDER-UE ETOME-

RDFD3: TIN2015-69951-R.

REFERENCES

Apel, S., Batory, D., Kästner, C., Saake, G., 2013, "Feature-

Oriented Software Product Lines: Concepts and

Implementation", Springer.

Siegmund, N., Sobernig, S., Apel, S., 2017, “Attributed

variability models: outside the comfort zone”. In Procs.

of the 11th Joing meeting on Foundations of Software

Engineering (ESEC/FSE 2017), ACM, pp. 268-278.

Moens, H., Truyen, E., Walraven, S., Joosen, W., Dhoedt,

B., and De Turck, F, 2012, “Developing and Managing

Customizable Software as a Service Using Feature

Model Conversion,” in Procs. of the IEEE Network

Operations and Management Symposium (NOMS

2012), pp. 1295–1302.

Lizhen, C., Haiyang, W., Lin, J. and Pu, H., 2010,

“Customization Modeling based on Metagraph for

Multi-Tenant Applications,” in Procs. of the 5th

International Conference on Pervasive Computing and

Applications (ICPCA 2010), pp. 255–260.

Mietzner, R., Metzger, A., Leymann, F., and Pohl, K.,

2009, “Variability Modeling to Support Customization

and Deployment of Multi-Tenant-Aware Software as a

Service Applications,” in Procs. of ICSE Workshop on

Principles of Engineering Service Oriented Systems

(PESOS 2009), pp. 18–25.

Weiping, L., 2009, “An analysis of new features for

workflow system in the SaaS software”, in Procs. of the

2nd Int. Conference on interaction sciences:

information technology, culture and human (ICIS

2009). ACM Press.

Galster, M., Zdun, U.,Weyns, D., Rabiser, R., Zhang, B.,

Goedicke, M., Perrouin, G., 2016, “Variability and

complexity in software design: towards a research

agenda”. ACM SIGSOFT Software Engineering Notes,

41 (6), ACM.

Applying Variability Management in the Development of a Complex SaaS System: Real Experience and Findings

397
