A Decentralized and Remote Controlled Webinar Approach, Utilizing

Client-side Capabilities: To Increase Participant Limits and Reduce

Operating Costs

Roy Meissner, Kurt Junghanns and Michael Martin

Institute of Applied Informatics, Leipzig University, Hainstrasse 11, Leipzig, Germany

Keywords:

WebRTC, Remote Control, Peer-to-Peer, Online Lecture, Webinar, Accessibility, SlideWiki, Decentralization.

Abstract:

We present a concept and implementation on increasing the efﬁciency of webinar software by a remote con-

trol approach using the technology WebRTC. This technology enables strong security and privacy, is cross-

device usable, uses open-source technology and enables a new level of interactiveness to webinars. We used

SlideWiki, WebRTC, and browser speech to text engines to provide innovative accessibility features like mul-

tilingual presentations and live subtitles. Our solution was rated for real world usage aspects, tested within the

SlideWiki project and we determined technological limits. Such measurements are currently not available and

show that our approach outperforms open-source market competitors by efﬁciency and costs.

1 INTRODUCTION

A modern vision for education, that many teachers,

students, professors as well as the European Union

(EU)

shares is that education should be:

• Open

• Free for everyone

• Accessible

• Inclusive

• Modern

• Based on Open Ed-

ucational Resources

(OER)

• Multilingual

• High-Quality

• Engaging

The recent two decades showed that education

uses more and more digital approaches. Thus more

and more specialized tools for e.g. webinars ap-

peared. Most of these tools have not been created by

this vision, but fulﬁl some of these aspects and are

thus usable for educational purposes. But they lack to

project the vision holistically. In contrast, SlideWiki

is an EU project about creation and management of

OER and realizes all aspects of the painted vision. We

chose to extend SlideWiki by a tool for educational

lectures, usable for webinars and hybrid lectures

See http://ec.europa.eu/education/policy/strategic-frame

work en and linked documents

A hybrid lecture is a face-to-face lecture, for which indi-

viduals are able to participate from a remote location.

We show in this paper how a remote-control ap-

proach, that focuses on utilizing client-side capabil-

ities decreases server load and thus overall costs for

providing a webinar service. This approach allows us

to support much more participants than known com-

petitors free of cost and thus enables more people

world wide to join or give lectures. Our focus on a

browser only solution is considered inclusive to e.g.

rising countries, as modern browsers are available on

all devices, even low-end ones. Furthermore the in-

tegration with SlideWiki and use of WebRTC enables

us to support multilingual audiences in an inclusive

way, which no competitor yet achieved. We want to

also present how the technology WebRTC is utilized

to remote control a browser application as of a we-

binar scenario. Furthermore we ﬁll the gap for sci-

entiﬁc measurements of resource usage and limits in

this technological context. Thus our main contribu-

tions are:

• Increased participant limit of a webinar by ap-

prox. 1:10 by using a remote-control approach

• Utilization of client-side capabilities to reduce

server-side workload and thus operating costs

• Measurements for three different WebRTC broad-

cast scenarios and of technology speciﬁc limits

At ﬁrst, we introduce into the use case and ob-

served real world aspects that inﬂuenced the design

of our solution. Starting with section 2.2, we present

Meissner, R., Junghanns, K. and Martin, M.

A Decentralized and Remote Controlled Webinar Approach, Utilizing Client-side Capabilities: To Increase Participant Limits and Reduce Operating Costs.

DOI: 10.5220/0006923901530160

In Proceedings of the 14th International Conference on Web Information Systems and Technologies (WEBIST 2018), pages 153-160

ISBN: 978-989-758-324-7

153

technical aspects of the developed tool and showcase

possibilities and limits of the used technologies. In

section 3 we evaluate the tool by measuring its per-

formance characteristics as close to our targeted use

case as possible. Finally, in section 4 related projects

are presented, as well as a separation of our work from

different existing tools and approaches.

2 PRESENTATION ROOMS

The educational material at SlideWiki is intended

for lecture series at educational institutions, online

courses and self education. Especially for the for-

mer two and in university courses, a typical scenario

is that some educator presents a deck (a collection

of slides) in a lecture style to the audience, regard-

less whether this is online or not. The audience is in-

tended to follow the presentation and to ask questions

about what they have seen and heard afterwards. De-

pending on the lecturers style sometimes also during

the presentation. Lecturers often use dynamic prac-

tices like to conduct polls or to ask for suggestions

that aim at including the audience and to keep it moti-

vated. Even though many studies, like (Mason et al.,

2013; Strayer, 2012; Raymond et al., 2016) promise

advantages of peer learning or the inverted classroom

concept, a large part of university, higher schools and

online courses are held in a lecturer centred style. We

thus chose to use this style as a basis for our con-

cept. According to our own experiences, dynamic

practices like mentioned above are not very well sup-

ported in today’s online lecture systems. Thus these

are often issued as tasks that shall be completed later

on and thus no longer fulﬁl the presented aims. Be-

sides these participation challenges, disabilities and

language barriers make it difﬁcult or prevent to ac-

cess educational content. Especially language bar-

riers are typically ignored by today’s online lecture

systems. In contrast, our approach focuses on these

issues and barriers and is based on the ideas and con-

cepts of university face-to-face lectures, extended by

the advanced possibilities of online lecture systems

and new technologies. We have come up with a pure

web solution that is usable for face-to-face lectures,

online lectures as well as for hybrid lectures.

In our approach a presenter opens a new virtual

room in which a chosen deck shall be presented. In-

terested people may join this room via an invitation

or by discovering it on SlideWiki as part of the deck

overview. We decided that each room is public and

not access restricted by any means. This aims at sup-

porting libre and free teaching on a libre and free

OER platform. Nevertheless, access restrictions may

be easily added for other use cases. A room enables

to share the presenters slide progress and voice to the

participants. This may be imagined like screen and

audio sharing. We have added various dynamic fea-

tures for the presenter, that are intended as proof of

concepts (POCs) and may be extended or altered in

the future. One of these POCs is to ask the audience to

complete a task and to receive live feedback about the

audiences progress. Another POC is a one way chat

for participants to the presenter in order to ask ques-

tions or to send in requested input. We chose this to

be text based as we want the presenter to be in control

of the presentation and thus to decide the point in time

and if at all to react to input, like a lecturer would in a

face-to-face lecture. Sent messages are only readable

by the presenter, not by any other participant. Further-

more we added two features that aim at improving the

accessibility of the tool, besides having an accessible

user interface. One is a live transcription of the pre-

senters voice to text, that is displayed as a subtitle to

participants (also a POC). This enables aurally hand-

icapped persons to attend presentations. The second

one is about multilingual presentations and described

in the paragraph below. All of the above described

features are named a presenter console, that is styl-

ized in ﬁgure 1.

As mentioned above, a room is publicly listed on

SlideWiki and interested people do not need a user

account on SlideWiki to join it. A participants view

of a room is very similar to the presenter console (see

ﬁgure 1), showing the currently presented and remote

controlled deck, a subtitle, some controls as well as

the one way chat. The available controls allow par-

ticipants to pause and resume the remote control of

the shown deck. This means that participants can

switch slides individually and e.g. continue to read

a slide that the presenter already left. A SlideWiki re-

lated feature is that everyone joining a room is able

to choose the language of the presented deck from

the available translations on SlideWiki without loos-

ing the remote control by the presenter. So one par-

ticipant may view the deck in Indonesian, another one

in French, even though the presenter chose to present

the deck in English. This feature is currently limited

to the deck itself and we do not offer to live trans-

late the presenters voice or the subtitle, even though

this is imaginable. Participants may switch between

available languages at any time while the presenta-

tion is in progress. SlideWiki focuses on a crowd-

sourced approach to improve and maintain decks and

slides. Thus we have added links for participants to

navigate to the currently shown slide on SlideWiki to

e.g. improve it and to issue a change request of the

improvement to the deck owner (SlideWiki feature).

WEBIST 2018 - 14th International Conference on Web Information Systems and Technologies

154

If the presenter chose to leave the room, participants

are still able to use it, e.g. for navigating slides, to

reread the subtitle and also their issued questions, un-

til they leave the room themselves.

Figure 1: Components of the presenter/learner console.

2.1 Security, Privacy and Requirements

Slides and decks may be modiﬁed on SlideWiki while

a presentation of the same deck is in progress. Due

to the SlideWiki revision feature it is impossible to

manipulate an ongoing presentation. Each update of

a slide or deck on SlideWiki creates a new revision

of these and does not override an existing one. If a

room is opened up it is associated with a speciﬁc deck

revision.

In the current state of implementation, all partici-

pants of a room create room speciﬁc data that are only

temporarily saved at the participants local devices, but

not on any remote servers. In case a presentation was

ﬁnished and the room was left by all participants, all

room speciﬁc data is discarded - even that the room

existed.

Our implementation depends on a stable and

working network connection of the presenter. It is

currently not possible to recover a room on network

issues. If the network connection is unstable and thus

not usable for online or hybrid lectures, we recom-

mend to use the SlideWiki presentation mode instead.

Furthermore the used browser needs to support We-

bRTC.

2.2 Technical Background

We are using WebRTC as a base technology. While

using this technology a presenter acts as a broadcast-

ing

peer that has opened up a room on a socket.io

server. Other peers may to join this room via our

application. The socket.io server acts as a signal-

ing server for WebRTC and maintains a live list of

all opened rooms. This list is used to display avail-

able rooms at decks on SlideWiki. WebRTC itself

”broadcast” is used for simplicity reasons, even though

these are several unicasts

negotiates via its signaling process an end-to-end en-

crypted peer-to-peer connection between the broad-

casting peer and all other peers. We chose to estab-

lish a one way connection for audio (microphone of

the presenter) and a two way connection for data, us-

ing audio streams and data channels. Thus, audience

members can not speak up. The mentioned data chan-

nel is used to broadcast the current application state

to connected peers. This enables them to mirror the

application state of the presenter at their local ma-

chine. We use data channels furthermore to transmit

the speech transcript, as well as commands for fea-

tures introduced in section 2.

We have modularized our approach and are using

an Iframe to display both, the remote controlled appli-

cation at participants, as well as the source application

at the presenter. In order to mirror the presenter ap-

plication state and control the remote application, we

are gathering emitted events of the source application,

execute a postprocessing and send relevant events to

peers. Received events are preprocessed and issued to

the remote controlled application in order to trigger

the same action that was executed at the source appli-

cation. This ﬂow is depicted in ﬁgure 2. As WebRTC

data channels support to keep sent messages in order,

we do not need to care about event reordering.

Figure 2: Remote Control Pipeline.

Iframes are due to browser security policies

only controllable from their parent page if both,

the parent page, as well as the Iframe originate

at the same domain. Thus this is precondition

to relay any events that originate in an Iframe.

Due to a bug of the Blink engine

(used by

Chromium, Google Chrome, Opera and more

browsers), events must be issued as generic events.

The concrete problem and solution is described as of

https://stackoverﬂow.com/questions/45457271/forwar

Blink engine bug about event creation: https://bugs.chrom

ium.org/p/chromium/issues/detail?id=327853

A Decentralized and Remote Controlled Webinar Approach, Utilizing Client-side Capabilities: To Increase Participant Limits and Reduce

Operating Costs

155

d-a-keydown-event-from-the-parent-window-to-an-

iframe-that-contains-reveal.

For speech recognition (SR) we have used the cur-

rent experimental browser API, that is currently only

available on Google Chrome. Chrome’s SR is usable

for short phrases, but is problematic for continuous

input as it spontaneously stops transcoding without

proper error reports. Furthermore it can not recognize

punctuation characters, unless explicitly spoken.

All source-code has been implemented as part of

the SlideWiki FLOSS project and is hosted at Github

https://github.com/slidewiki/slidewiki-platform/tree/

master/components/webrtc for WebRTC speciﬁc

functionality and for the signaling server at https://git

hub.com/slidewiki/WebRTC-Signaling-Service.

2.3 Technical Security Considerations

Besides the initial signaling process to establish a

WebRTC connection, no server is involved to trans-

mit any data between peers. The only server-side

available information is the room id and presented

slideshow. These information are only available for

the time a room exists. The encrypted peer-to-peer ap-

proach (see (W3C, 2018)) results in a partly resistance

against server-side failures and unauthorized data col-

lection. It has no impact on already opened rooms and

connected peers if the signaling service or SlideWiki

itself is not reachable. The only impact is that no new

rooms can be opened up and no peers are able to join

existing rooms.

In case of client-side issues, an erroneous audi-

ence peer has no impact on the room or presenter peer.

Such peers may just join the room again as of a new

browser tab. In contrast, if the presenter-peer fails, the

room will be marked as closed and the presenter needs

to open up and share a new room. This has been only

experienced rarely due to browser tab crashes that we

expect to get less frequent in the future as the imple-

mentation of WebRTC stabilizes.

As of possible attacks, we can only imagine man-

in-the-middle attacks by breaking into the server-side

signaling service or SlideWiki itself. There are two

possible scenarios, besides common scenarios like

system intrusion:

1. Mallory manipulates SlideWiki and exchanges the

link for joining a room, that is displayed at decks.

Thus, every new peer connects to Mallory instead

of the actual presenter. Mallory is using a custom

client that is connected to the actual presenter and

relays everything to Mallory’s peers.

2. Mallory manipulates the signaling service and

acts like in scenario 1, without exchanging the

link for joining a room on SlideWiki.

Both scenarios require that Mallory breaks into a

server system and manipulates or exchanges running

code. In both scenarios Mallory tries to attack the

connection establishment process between a presenter

and peers. There exists an approach to improve the

security of the signaling process, that we outline in

section 5.1.

2.4 Workload Estimation

WebRTC requires to open up a new connection for ev-

ery peer, for which streams are encoded speciﬁcally

to the capabilities of this peer. Singh et al. showed in

(Singh et al., 2013) that WebRTC chooses automati-

cally the most efﬁcient codec possible, which are self

adapting to bandwidth limits. Thus the presenter ma-

chines upload and processing capabilities are the ma-

jor limitations to the number of connected peers and

thus the amount of audience members in a broadcast

scenario. Furthermore the workload is inﬂuenced by

the availability of hardware encoders for various au-

dio and video formats

, like VP8, VP9 and OPUS.

As WebRTC requires to open up a new connection

for every peer we expect the workload to increase lin-

ear to the number of connected peers. We determined

the limits for an exemplary machine in an unrestricted

network, as well as measured possible side effects.

Results are presented as of section 3.

In contrast, a participant machine does not need to

provide extensive capabilities, as it receives only one

audio and data stream, that it needs to decode. This

enables to use low-end devices, like Smartphones as

peers. Their workload is also inﬂuenced by the avail-

ability of hardware decoders for the used formats.

3 EVALUATION

The presented approach is integrated with SlideWiki,

has several novel features and uses experimental tech-

nologies. Thus, it might be evaluated for many differ-

ent aspects, like impact on learning performance of

students, workﬂow changes for teachers, usability for

pure online lectures, and many more. All of the men-

tioned evaluations need to be settled on a foundation

that classiﬁes and rates the implemented by technol-

ogy speciﬁc limits. This is why we focus on tech-

nological performance and limit measurements in the

following subsections. Performance measurements

are important in order to

See the following URLs for supported codecs: https://

webrtc.org/faq/#what-codecs-are-supported-in-webrtc and

https://developers.google.com/web/updates/2016/01/vp9-

webrtc

WEBIST 2018 - 14th International Conference on Web Information Systems and Technologies

156

• show the efﬁciency of the approach in terms of

hardware as well as software and service costs

• know in which area the software is applicable, e.g.

to not schedule courses with too many students,

which the software can not handle

• ﬁll the gap for scientiﬁc measurements about the

broadcast WebRTC usage scenario.

3.1 Experiment Description

We identiﬁed 5 aspects that are listed below and need

to be measured. To be able to measure any as-

pect, a WebRTC data channel must be established

(see next paragraph for the measuring method de-

scription). Measuring data transmission and audio

streaming has been chosen as this matches our imple-

mented approach. Furthermore we chose to measure

data transmission, audio and video streaming as this

is what all listed tools in section 4 do. All of the fol-

lowing aspects aim at identifying possible limits and

to gain insights into their respective resource usage.

• Maximum number of simultaneously connected

peers

• Signal delay for increasing number of peers

• CPU and RAM usage for data channels only for

increasing number of peers

• CPU and RAM usage for data channels and audio

streams for increasing number of peers

• CPU and RAM usage for data channels, audio and

video streams for increasing number of peers

We have set up three different scenarios to mea-

sure these aspects - (1) determine the maximum peer

number for a browser tab, the maximum peer num-

bers for audio only (2) and audio and video stream-

ing (3), as well arising delays in each of the scenar-

ios. Signal delays are measured by regularly send-

ing the current timestamp to all connected peers via

a WebRTC data channel. The ﬁrst peer that connects

to the presenter measures a default delay. For rising

peer numbers, the measuring peer continues to com-

pare sent timestamps to its local timestamps minus

the default delay to calculate the effective signal de-

lay (100 measurements per data point). The default

delay has been measured for each scenario indepen-

dently. System statistics, like CPU and RAM usage,

are monitored independently by an OS speciﬁc pro-

gram, called sysstat. To exclude network interfer-

ence effects, we have measured all scenarios in a lo-

cal network that routes packages through a maximum

of 2 switches. We have executed all scenarios on a

Core i7-6500U with 8GB DDR3 RAM, SATA-SSD,

and Gigabit Ethernet. As browsers we use Google

Chrome (version 63.0.3239.132) and Firefox (version

57.0.1) on Fedora 27 (Linux Kernel 4.14.11).

We described all needed steps to repeat the exper-

iment inside the Readme ﬁle of the Github reposi-

tory https://github.com/rmeissn/WebRTC-Broadcast-

Performance-Test. This repository also contains all

measured data in one of its branches. The different

scenarios need minor code modiﬁcations, that are im-

plemented and described as branches of the reposi-

tory.

3.2 Results

A often cited value for the maximum number of con-

nected peers per browser tab is 256 peers

. We

showed in scenario 1 that the maximum number of

connected peers per browser tab can be higher. We

expect that there is only a soft limit determined by

hardware and software capabilities, like the maximum

number of simultaneous network connections. Due

to hardware limitations, we were not able to measure

more than 280 peers. Our scenario (1) was to dis-

able audio and video streams, so only a data channel

is opened up. This reduced CPU, RAM and network

usage of the test setup to a minimum. We furthermore

observed that there is no signiﬁcant delay increase for

rising peer numbers, no signiﬁcant impact on RAM

usage and only a minor impact on CPU usage, namely

≈21% per 200 connected peers. The exact results are

depicted in ﬁgure 3. As is visible in this ﬁgure, the

delay increases about linear to the number of peers.

In a second scenario (2) we tested for the maxi-

mum number of peers for audio streaming and data

transmission. As the audio stream will be encoded

the same number of times as peers are connected (see

(W3C, 2018)), the limiting factor for the number of

peer connections is the processing capability of the

presenters computer. We were able to connect up to

70 peers before WebRTC started to adjust the audio

quality (see network and CPU usage in ﬁgure 4). The

overall delay is a little higher than in ﬁgure 3, but still

low enough to speak of real-time streaming and in-

creases on a linear scale, as in scenario 1. Due to

hardware limitations at the load generating machine

we were only able to connect up to 110 peers, before

the machine reached its capacity. According to the

results the presenter machine is able to connect more

peers and we anticipate about 140 possible connec-

tions before the presenter machine runs into hardware

Maximum WebRTC connections per tab: https://stackover

ﬂow.com/questions/16015304/webrtc-peer-connections-li

mit or https://stackoverﬂow.com/questions/41194545/maxi

mum-number-of-rtcpeerconnection/41205991#41205991

and see section 4

A Decentralized and Remote Controlled Webinar Approach, Utilizing Client-side Capabilities: To Increase Participant Limits and Reduce

Operating Costs

157

10 20 30 40 50 60 70 80 90 100 110

delay in ms

Peers

delay

10 20 30 40 50 60 70 80 90 100 110

100

delay in ms

cpu in %

Peers

cpu usage

10 20 30 40 50 60 70 80 90 100 110

1.6

3.2

4.8

6.4

delay in ms

mem in GB

Peers

memory usage

10 20 30 40 50 60 70 80 90 100 110

300

600

900

1200

1500

delay in ms

net in KB/s

Peers

network usage

Figure 3: Simultaneously connected peers as of the data only scenario (1).

10 20 30 40 50 60 70 80 90 100 110

delay in ms

Peers

delay

10 20 30 40 50 60 70 80 90 100 110

100

delay in ms

cpu in %

Peers

cpu usage

10 20 30 40 50 60 70 80 90 100 110

1.6

3.2

4.8

6.4

delay in ms

mem in GB

Peers

memory usage

10 20 30 40 50 60 70 80 90 100 110

300

600

900

1200

1500

delay in ms

net in KB/s

Peers

network usage

Figure 4: Measurements as of the data transmission and audio streaming scenario (2).

caused performance issues, e.g. because of too much

memory consumption.

As of the third scenario (3) we tested for the max-

imum number of peers for video streaming, audio

streaming and data transmission. As the video and

audio streams are encoded the same number of times

as peers are connected (see (W3C, 2018)), the limit-

ing factor for the number of peer connections is the

same as in scenario 2, but we expected a signiﬁcantly

lower number of possible connections than for sce-

nario 2. A signiﬁcant delay started to occur at 12 con-

nected peers, as well as visible codec adjustments (see

network and CPU usage in ﬁgure 5). The presenter

machine reached its processing limits at 14 connected

peers, resulting in visible jitter effects of the video

stream at the peers.

These results show that without a TURN server

the ﬁrst two scenarios (1, 2) are the only two scenarios

that are suitable for a larger number of peers. The re-

sults also show that our remote controlling approach

A server that relays streams to peers

is superior (in terms of resource usage) to screencast-

ing (video streaming) with the same technology, as

about seven times more peers are able to connect be-

fore any codec adjustments are implied. About ten

times before the presenter machine reaches its pro-

cessing limits. Thus these results reveal the beneﬁts of

our chosen remote-control approach, outlined in sec-

tion 2.2. Our ﬁndings also align with the results of

Muaz Kahns tests, that are presented in section 4. All

of the presented competing solutions from section 4

are using a video streaming approach. Some of them

also use WebRTC and might be thus used in a de-

centralized scenario too (without a turn server). Nev-

ertheless we expect them to match the performance

characteristics of scenario 3, as they rely on video

streaming. We have further discussed beneﬁts and

possible downsides of our solution in sections 2 and

WEBIST 2018 - 14th International Conference on Web Information Systems and Technologies

158

-200

200

400

600

800

2 4 6 8 10 12 14 16 18

delay in ms

Peers

delay

-200

200

400

600

800

2 4 6 8 10 12 14 16 18

100

delay in ms

cpu in %

Peers

cpu usage

-200

200

400

600

800

2 4 6 8 10 12 14 16 18

1.6

3.2

4.8

6.4

delay in ms

mem in GB

Peers

memory usage

-200

200

400

600

800

2 4 6 8 10 12 14 16 18

1000

2000

3000

4000

5000

delay in ms

net in KB/s

Peers

network usage

Figure 5: Measurements as of the data transmission, audio and video streaming scenario (3).

4 RELATED WORK

Based on the vision for modern education in section

1 we compare our solution to tools that meet three

criteria: open-source, free of cost and browser-based.

Video conferencing tools may be pooled into one cat-

egory. The ones that match our criteria are: Jitsi, Jan-

gouts, Spreed WebRTC, and Nextcloud Talk. There

are no information available about participant lim-

its for a and whether data is shared peer-to-peer or

end-to-end encrypted for these tools, even though we

assume so for the the last two as of the used tech-

nologies. Google Hangouts (that also uses WebRTC)

for instance supports up to 10 participants per con-

ference on their free plan

. Nextcloud Talk, Jangouts,

and Spreed WebRTC need dedicated hosting of server

components before these are usable, which forms a

technological burden. As of accessibility and inclu-

siveness aspects, no special features are supported and

we did not ﬁnd basic accessibility support the source

codes.

Another category is specialized webinar software.

The only available tool that matches our criteria

is BigBlueButton (BBB). BBB satisﬁes accessibil-

ity level A success criteria of WCAG 2.0

. Further-

more BBB supports all features of the former cate-

gory, as well as a live whiteboard, shared notes, break-

out rooms, manual closed captioning and the possibil-

ity to record a session. BBB is an exceptional webinar

software and supports more features than our solution

does. Nevertheless needs a dedicated hosting, which

forms a technological burden. A downside of BBB

Participant limits of Google Hangout: https://productfor

ums.google.com/forum/#!topic/hangouts/vuVoVNDFVeI

BBB accessibility information: https://bigbluebutton.org/

accessibility/

is the usage of the technology Flash. Flash has been

discontinued by Adobe, is regularly associated with

security issues, and is not open-source. Furthermore

BBB does not build upon peer-to-peer or end-to-end

encrypted connections, but has a server based relay

data ﬂow.

Some research engages into the same technolo-

gies and similar approaches. Muaz Khan developed

several WebRTC experiments that showcase a broad-

cast like solution for audio and video via WebRTC.

He states at his experiments that there is a maximum

peer limit of 256 peers

and stated via an email con-

versation that none of his experiments provides the

possibility to broadcast a video stream to more than

10 peers, due to CPU and network limits.

Pinikas et al. include in (Pinikas et al., 2016) an

approach to send commands via WebRTC data chan-

nels to peers in order to trigger functionalities. They

have focused on a IoT scenario and have introduced a

custom on top protocol speciﬁcally for IoT devices.

They did not justify the need for a custom proto-

col and how this relates to their high level demo, in

which they share virtual whiteboard sessions among

all peers.

Zhao et al. present in (Zhao et al., 2016) a solu-

tion to stream video data via WebRTC data channels

without the need to encode the stream for every peer

separately, named MPEG DASH. This is lowering the

CPU and memory usage of the streaming peer, but is

not usable without third-party browser plugins as of

July 2018.

Peer Limit: https://github.com/muaz-khan/WebRTC-Exp

eriment/tree/master/webrtc-broadcasting

A Decentralized and Remote Controlled Webinar Approach, Utilizing Client-side Capabilities: To Increase Participant Limits and Reduce

Operating Costs

159

5 SUMMARY

We have presented in this paper a hybrid approach to

teach online in a lecture hall style. Our tool is aligned

with the vision of modern education, the EU project

SlideWiki and offers educators, as well as students

an alternative to expensive and proprietary competi-

tor solutions. The tool is focused on interactive lec-

tures, accessibility and inclusiveness, security, as well

as privacy. We showed that the current implemen-

tation is suited for courses up to approximately 140

participants and we provided novel resource and limit

measurement results for a WebRTC broadcast sce-

nario. Furthermore we showed that by sending data

that allows clients to replicate the same screen as the

presenter sees, we extended the participant limit of a

webinar about 10 times. We have tested our proof of

concept to work as of various courses at participating

institutions of the SlideWiki project.

5.1 Future Work

We have presented in this paper technological limits

of a broadcast WebRTC usage and conceptually new

ideas to webinar solutions. Thus we created a founda-

tion to start other evaluations of the presented concept

in the area of paedagogy, like outlined in section 3.

Muaz Khan (see section 4) showed that it is pos-

sible to use peers as relay peers in a broadcast sce-

nario, effectively lowering the hardware requirements

of the broadcaster as not all peers need to be directly

connected to it. This eliminate the need to host a

TURN server and leverage’s computational power of

the peer network even more. We expected this solu-

tion to increase the measured limits from section 3

tremendously, but it may need additional logic, like

network optimization algorithms.

Another imaginable approach is to use a speech to

text engine to transcribe the presenters voice, transmit

the transcript to the peers and to use a text to speech

(TTS) engine to regenerate audio output, instead of

transmitting an audio stream. According to our test

results, a data channel only setup is the most efﬁcient

one and thus allows the highest number of connected

peers. E.g. Google presented in a recent (yet unpub-

lished) research paper (Shen et al., 2017) a TTS en-

gine that is mostly indistinguishable from a human

voice and that might be usable in this scenario.

The mentioned signaling server is the only re-

maining part of the network or process that is con-

sidered central and needs to be hosted. Paik et al.

showed in (Paik and Lee, 2015) a method to transfer

the signaling process to a distributed hash table. This

eliminates several use-case speciﬁc signaling servers

and introduces a decentralized way to handle signal-

ing. Based on their results, it seems like a promising

solution to secure the signaling process.

ACKNOWLEDGEMENTS

This work was partly supported by the European

Union’s Horizon 2020 research and innovation pro-

gram for the SlideWiki Project under grant agreement

No 688095.

REFERENCES

Mason, G. S., Shuman, T. R., and Cook, K. E. (2013). Com-

paring the effectiveness of an inverted classroom to a

traditional classroom in an upper-division engineering

course. IEEE Transactions on Education, 56(4):430–

435.

Paik, J. H. and Lee, D. H. (2015). Scalable signaling pro-

tocol for web real-time communication based on a

distributed hash table. Computer Communications,

70:28–39.

Pinikas, N., Panagiotakis, S., Athanasaki, D., et al. (2016).

Extension of the webrtc data channel towards remote

collaboration and control. In Proceedings of AmiEs

’16.

Raymond, A., Jacob, E., Jacob, D., et al. (2016). Peer learn-

ing a pedagogical approach to enhance online learn-

ing: A qualitative exploration. Nurse education today,

44:165–169.

Shen, J., Pang, R., Weiss, R. J., et al. (2017). Natural tts syn-

thesis by conditioning wavenet on mel spectrogram

predictions. arXiv preprint arXiv:1712.05884.

Singh, V., Lozano, A. A., and Ott, J. (2013). Performance

analysis of receive-side real-time congestion control

for webrtc. In 20th International Packet Video Work-

shop, pages 1–8. IEEE.

Strayer, J. F. (2012). How learning in an inverted classroom

inﬂuences cooperation, innovation and task orienta-

tion. Learning Environments Research, 15(2):171–

193.

W3C (2018). W3c editor’s draft speciﬁcation for webrtc.

Last access time: 16 January 2018.

Zhao, S., Li, Z., and Medhi, D. (2016). Low delay mpeg

dash streaming over the webrtc data chan-

nel. In IEEE ICMEW, pages 1–6. IEEE.

WEBIST 2018 - 14th International Conference on Web Information Systems and Technologies

160
