Anomalies Correlation for Risk-Aware Access Control Enhancement

Pierrette Annie Evina, Faten Labbene Ayachi, Faouzi Jaidi and Adel Bouhoula

Higher School of Communications of Tunis (Sup'com), University of Carthage, Tunis, Tunisia

Keywords: Anomalies, Correlation, Access Control Policy, Database, Risk Management.

Abstract: In the context of database management systems (DBMS), the integrity of access control policies (ACP) is a

constantly neglected aspect. However, throughout its evolution, ACP is not valid and free from irregularities

due to users and administrators actions, intentionally or not. So, considering regular ACP updating

activities, we pay a particular attention on anomalies in ACP expression. Taking into account the correlation

that exists between two or more of such anomalies, we present the “correlated threats management system”

(CORMSYS). This system must detect and analyze the correlation between anomalies since we believe that

handling correlations between anomalies can reveal sophisticated intrusion scenarios in DBMS. The

presented system also produces the necessary input for new risk management approach that will consider

and overcome the effects induced by the correlation between anomalies found in the ACP expression.

CORMSYS is composed of four main parts: (i) the Correlation Definition and Analysis subsystem; (ii) the

Users Tracking subsystem; (iii) the Intrusion Scenario Identification subsystem and (iv) the Illegal Behavior

Modeling subsystem.

1 INTRODUCTION

For access control, the detection and the analysis of

anomalies and intrusions are widely discussed in the

field of information systems (IS) and particularly in

database management systems (Bertino et al., 2010).

Actually, the integrity of ACP is a neglected

aspect in the literature as many authors

spontaneously think about the reliability of the

access control policies expression. Although,

policies that govern access control in IS or DBMS

are also subjected to anomalies that make them

vulnerable at one stage or another in their lifetime.

Focused on anomalies in ACP expression, we

then propose to assess regular ACP updating

activities. This action can inevitably lead to a variety

of anomalies such as those stated in (Jaidi et al.,

2017). These anomalies are sometimes due to a

partial implementation or they are just anomalies of

non conformity, redundancy, inconsistency and

contradiction in the expression of policies. So, in

this context, what is the induced impact of this

correlation when these anomalies are correlated with

each other? Can the assessment of this impact have

positive consequences on the overall risk

management of ACP?

Our intention is to implement a “correlated

threats management system” (CORMSYS). This

system uses identified anomalies found in the ACP

expression, analyzes the correlation existing

between them in order to produce a database of risk

factors related to the effects induced by the

anomalies correlation.

Of course, the study of correlation is nowadays

increasingly used for the risk analysis. But, to the

best of our knowledge, the correlation between

anomalies in ACP has never been discussed and we

think that if this is done, it can enhance the well-

functioning of ACP in DBMS. Our contribution

aims to design a system that detect and report

correlations between anomalies in ACP expression,

for the revelation of sophisticated intrusion scenarios

that constitute a major threat in systems. Our system

will furnish inputs for a new risk management

approach that will precisely consider the effects

induced by the anomalies correlation in ACP

expression.

The remainder of the paper comprises the

following sections: section 2 gives the problem

statement; section 3 proposes the basic

representation of the topic related terms; section 4

presents our proposed framework; section 5 gives

the methodology used; section 6 discusses the

related works; section 7 concludes the paper.

Evina, P., Labbene Ayachi, F., Jaidi, F. and Bouhoula, A.

Anomalies Correlation for Risk-Aware Access Control Enhancement.

DOI: 10.5220/0006766802990304

In Proceedings of the 13th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2018), pages 299-304

ISBN: 978-989-758-300-1

299

2 PROBLEM STATEMENT

ACP is a set of access control statements

materializing the association between user, action and

object. In ISS and particularly in DBMS, ACP are

subject to attacks of various types as well as the

access control systems they govern and the impact of

these attacks often has considerable effects. Thus,

ACP is said to be corrupt if an access control state-

ment is illegally added, modified or suppressed in that

ACP. The identification of these statements or anoma-

lies is carried out in a validation phase which consists

in analyzing two consecutive versions of the policy: a

reference version and an active current version.

The syntax analysis of the anomalies makes it

possible to identify the correlations that may exist

between them. A correlation between anomalies

underlies an elaborate scenario of policy corruption

and therefore an elaborate scenario of intrusion. We

presume that the harness of the statistical link

existing between two anomalies or more can

considerably improve the treatment of the risk of

degradation of the information systems, precisely,

that of the DBMS. Moreover, in order to alleviate or

remedy the effects of these anomalies, it is

appropriate to set up a risk management system. We

believe that it is necessary to deeply carry out the

analysis of anomalies in ACP by the establishment

of a learning system for the management of

incidents or attacks and to perform the assessment of

the risks arising from the correlation between these

anomalies of non-conformity.

Taking into account the attacks on AC in DBMS

as well as the discrepancies that may exist between a

concrete ACP and the initial version of the same

policy, we plan to produce a formal approach for the

risk management in the case of policies degradation

in DBMSs. Our approach takes into account the

recommendations of the ISO 31000 standard and

will be able to analyze and evaluate the risk induced

by the correlation of ACP anomalies. A “correlated

threat management system” (CORMSYS) is

designed to enhance the presented risk management

approach by producing the necessary input. Thus

the present paper aim to present the CORMSYS

framework situated upstream on the overall risk

management system proposed for the future.

3 BASIC REPRESENTATIONS

As ACP (access control policy) defines the

authorized access of users to database objects, an

access control statement can be represented by the

triplet (U

, A

, O

) where U

designates a given

authorized user and (A

, O

) designates the

permission to execute an authorized action A

on a

visible object O

An authorized user is any user identified in the

DBMS by a login and a password and being

authorized to connect the database server.

An authorized action is any action being

specified in the ACP i.e. insert, select, update,

delete, execute, etc.

A visible database object is any object being

specified in the ACP i.e. a table, a view, a procedure,

etc.

We introduce in the following the syntax that we

adopt to materialize the possible alterations of an

access control statement.

(a)

, Ā

, Ō

Authorized user assigned

not specified permission.

(b)

(Ū

, A

, O

Unauthorized user

assigned authorized

permission.

(c)

, Ā

, O

Authorized user assigned

unauthorized action on

visible database object.

(d)

(Ū

, Ā

, Ō

Not specified access

control statement.

(e)

(Ū

, Ā

, O

Unauthorized user

assigned unauthorized

action on visible database

object.

Users referenced in (a), and (c) are authorized

users being however corrupted.

Users referenced in (b), (d) and (e) are

definitively intruders.

4 PROPOSED FRAMEWORK

CORMSYS framework is shown in figure 1 and is

composed by the following four subsystems: (1)

Correlation Analysis subsystem; (2) Users Tracking

subsystem; (3) Intrusion Scenario Identification

subsystem; (4) Illegal Behavior Modeling

subsystem.

ENASE 2018 - 13th International Conference on Evaluation of Novel Approaches to Software Engineering

300

Correlation Analysis Subsystem (CAS)

operates the analysis of anomalies and detects

correlation between them. These anomalies are

irregularities or differences visible when comparing

the ACP at different stages. The anomalies, listed

and located in a specified database, are scrutinized

and some characteristics are determined in order to

establish the statistical links existing between these

anomalies. They are then translated into formal

language allowing inference and deduction. This

subsystem provides two kinds of outputs. (1) The set

of database objects referenced in the anomalies. This

set is relevant for the Risk Management subsystem

for updating risk factors. (2) Set of users to be

revoked and set of users to be closely supervised.

Users Tracking Subsystem (UTS) provides an

investigation phase where log files are scanned to

retrieve accesses made by revoked and/or supervised

users. For each access, this phase extracts the four

following properties: session identifier, user login,

user actions on database objects. Indeed, to access

data in the DBMS, a user needs to have been granted

some authorizations and privileges. So, in this stage,

the granted privileges are examined as well as the

authorization to log into the system

Intrusion Scenario Identification Subsystem

(ISIS) builds the intrusion scenarios for each user

identified in the previous session. A scenario is a

sequence of elementary accesses achieved on the

database during a user session. So a sequence of

events is described to characterize the effects

involved. For example, it will be necessary to

describe the user's intrusion process or the type of

requests commonly used by an alleged user who

wants to make use of unauthorized privilege on a

given object.

Illegal Behavior Modeling Subsystem (IBMS)

provides two main functions. (1) It compares

intrusion scenarios and identifies their similarities.

(2) It classifies scenarios according to a predefined

resemblance function. By classifying the wicked

actions of the DBMS users, this subsystem

determines the actions that are harmful to the

DBMS. At this stage, risk factors are sorted and

constitute the main entries to the further risk

management process. Although risk factors are

constantly changing, we can contemplate a general

view of these factors as there may be a constant

identification of new threats and new vulnerabilities.

The quantity and quality of threats are evaluated, as

well as their frequency. Dangerous users are

determined, listed and ranked in order of danger.

That allows having a precise representation of illegal

access.

Figure 1: the proposed framework.

Anomalies Correlation for Risk-Aware Access Control Enhancement

301

Risk Management Subsystem (RMS) evaluates

risk. A threshold is established for the regulation of

exposure of DBMS to risk. Critical anomalies are

registered as they are source of high level risk in

DBMS.

Indeed, these anomalies have important impact

over confidentiality, integrity and availability of data

in the system. Also, they have a significant impact

on the integrity of the policy.

Inside the risk management module, there is a

correction phase that intervenes to mitigate or to

eliminate the risk of degradation of the DBMS. It is

associated to a testing and control phases in order to

constantly keep the system safe.

5 METHODOLOGY

In order to get more information related to our work

plan, the documentary research is performed. An

important number of publications have been

identified and studied in order to precisely identify

our contribution.

We will then formally describe our learning

approach and explore the DBMS's log files in order

to collect information about recurrent attacks, i.e

data that are regularly and improperly exploited, as

well as all the defections occurring in the ACP.

Also, a comparison is done between two states of

the ACP and lead to the establishment of a list of all

the anomalies and their frequency of occurrence.

Then, a formal description of the correlation

definition and evaluation procedure is produced. For

that purpose, a correlated threats management

system (CORMSYS) is designed. CORMSYS

supplies a risk management module and that will

furthermore lead to the analysis and the evaluation

of the risk related to the correlated identified threats.

We will adapt the features of our system to work

with a real database, with real schemes and tables

created. It will then be possible to confirm the

results, qualitatively and quantitatively.

We expect to reach the following results:

1. Listing anomalies related to unauthorized

update of access control policy.

2. Detecting induced faults through analysis of

correlation between detected anomalies with

more specific results:

 Definition of the list of the recurrent

targeted and sensitive data.

 Detection and establishment of intrusive

user behavior and thus, reinforcement of

the Intrusion Detection Systems.

 Production of a global and comprehend-

sive system for risk management in

access control systems.

6 RELATED WORKS

Several works exist in the literature, leading to the

detection of anomalies in access control systems

including those in databases. Elisa Bertino et al had

done a recap of such works in (Bertino et al., 2007).

From that work, we learn that, Anomalies Detection

Systems (ADS) designed in DBMS are generally

intended to counter attacks related to the use of data

by users.

The ADS allow detecting abnormal activities of

users or applications. It doesn’t take into account

anomalies related to alteration of ACP

specifications. In the present paper, we are

especially concerned with the ACP defections

caused intentionally by authorized users or database

administrators.

Concerning risk management, several works deal

with risk assessment techniques but generally

concern the risk related to the user-data relationship.

Very few works linger on the rules governing this

relationship, i.e the ACP.

In (Cheng et al., 2007) and in ( Khambhammettu

et al., 2012), authors provide a solution to overcome

the risk related to unauthorized access of users on an

object in an access control system. To address this

risk, the authors evaluate user confidence and the

object sensitivity. Authors in (Diep et al., 2007) plan

to make the access control management more

dynamic and precised. They evaluate the action of

users or processes on the system and take into

account the context parameters. These parameters

are also considered as input in the risk assessment

process. (Colantonio et al., 2010) evaluate the risk

occurred when managing users and permissions

through the Role based access control (RBAC)

during the pre-mining phase (Colantonio et al.,

2010). They consider the constant modification due

to the users or access permissions creation,

modification, or deletion in the access control

system. In (Burnett et al., 2014), the authors provide

a solution to avoid unwanted disclosure information

by corrupted users. They consider the risk occurred

when a user manage his own data. In (Ma et al.,

2010), authors mainly consider the role delegation

issue which is source of risk. Authors in (Baracaldo

et al., 2013) propose an access control framework to

mitigate insider threats with a risk management

ENASE 2018 - 13th International Conference on Evaluation of Novel Approaches to Software Engineering

302

process which is adaptive. The changes in users

behaviour are osculated.

Regarding risk in ACP, few authors are

concerned. (Celikel et al., 2008) deal with the risk

management in the access control policy, notably the

RBAC in distributed databases. They think that

user's queries are risky especially when there is a

misapplication of the rules established in the access

control policy. Thus, in (Celikel et al., 2008) the

user's queries are the main elements observed and

considered while assessing risk. Some authors also

sort out non-compliance defaults that occur in a role-

based ACP during its lifecycle and evaluate the risk

associated to the identified attacks and alterations

that corrupt the ACP. They intended to ensure a high

surety to that ACP.

In AC as well as in ACP, authors do not worry

about the correlation that can exist between the

anomalies detected. To the best of our knowledge,

none of these works evokes the notion of correlation

in attacks analysis. In addition to the in-depth study

of the threats in ACP, we plan to explore the

correlation between these threats.

Many authors already adopted machine learning

techniques for the automatization of procedures of

detection of anomalies and intrusions in IS and

precisely in DBMS. So, authors in (Costante et al.,

2013) for example, developed a machine-learning-

based system that automatically acquires knowledge

related to the normal behaviour of users during the

database activities. Their system compares the user's

sql queries exchanged with the database server and

also it evaluates the sensitivity of the manipulated

data in order to avoid the data leakage in DBMS. In

(Darwish, 2016) the author proposes to detect

anomalies using the correlation among queries in

DBMS transactions with log-records. We do not use

machine learning for the anomalies detection as

authors in (Grushka-Cohen, 2016) do. But there

exist a difference between our work and theirs.

Indeed, they use detected anomalies and produce a

ranking alerts system that enables to prioritize

anomalies according to their importance. While we

use identified anomalies and study the correlation

existing between these anomalies in order to identify

sophisticated scenarios and be able to adjust the risk

factors when preventing ACP expression from

degradation.

7 CONCLUSIONS

Over its life cycle, an access control policy faces

some irregularities or anomalies in its expression.

This is source of vulnerabilities for information

systems (IS), especially for database management

systems (DBMS).

In the current paper, we presented the

CORrelated threats Management SYStem

(CORMSYS) that takes into consideration the

critical anomalies that threatens the ACP and

analyses the correlation between these anomalies.

Our contribution aims to enhance the proper

functioning of ACP by considering a wide range of

anomalies for which the correlation is identified and

handle for the purpose. To the best of our

knowledge, the analysis of such correlations has

never been carried out. We are convinced that the

handling of these correlations and that of the

induced effects can (1) reveal some subtle scenarios

during the exploitation of data in DBMS, (2) leads to

the supervision of the illegal behaviour of some

DBMS users and (3) contributes to overcome

anomalies that undermine the integrity of access

control policies in DBMS. In a nearest future, we

intend to develop the CORMSYS by explicitly

formalizing each subsystem in order to produce,

upstream, the necessary inputs for a new risk

management approach.

REFERENCES

Sandhu, R., Coynek, E. J., Feinsteink, H. L., and

Youmank, C. E., 1996. Role-Based Access Control

Models, IEEE Computer, vol. 29, no. 2, (pp. 38-47).

International Electrotechnical Commission, International

Standard, ISO/IEC 27000:2014.

International Electrotechnical Commission, International

Standard, ISO/IEC 31010:2009, First Edition, 2009.

Cheng, P.-C., Rohatgi, P., Keser, C., Karger, P. A.,

Wagner, G. M., Reninger, A. S., 2007. Fuzzy MLS:

An Experiment on Quantified Risk–Adaptive Access

Control, In Security and Privacy, (pp.222–230).

Bertino, E., Ghinita, G., Kamra, A., 2011. “Access Control

for Databases: Concepts and Systems” Foundations

and Trends in Databases Vol. 3, http://dx.doi.org/

10.1561/1900000014.

Khambhammettu, H., Boulares, B., Adi, A., Logrippo, L.,

2012. “A framework for threat assessment in access

control systems” that appeared in Proceedings of

27th IFIP TC 11 Information Security and

Privacy Conference. http://dx.doi.org/10.1007/978-3-

642-30436-1_16.

Diep, N. N., Hung, L. X., Zhung, Y., Lee, S., Lee,

Y. K., Lee, H., 2007. “Enforcing Access Control

Using Risk Assessment”, Proceedings of the

Fourth European Conference on Universal

Multiservice Networks (ECUMN'07). http://dx.doi.org/

10.1109/ECUMN.2007.19.

Anomalies Correlation for Risk-Aware Access Control Enhancement

303

Colantonio, A., Di Pietro, R., Ocello, A., Verde, N.V.,

2010. “Evaluating the Risk of Adopting RBAC

Roles”, ara Foresti; Sushil Jajodia. Data and

Applications Security and Privacy XXIV, 6166,

Springer. http://dx.doi.org/10.1016/j.dss.2010.08.022.

Burnett, C., Chen, L., Edwards, P., Norman, T. J.,

“TRAAC: Trust and Risk Aware Access Control”,

2014. Twelfth Annual International Conference on

Privacy, Security and Trust (PST). http://dx.doi.org/

10.1109/PST.2014.6890962.

Ma, J., Adi, K., Mejri, M., Logrippo, L., 2010. Risk

analysis in access control systems. In Eighth Annual

International Conference on Privacy Security and

Trust (PST), pp. 160-166.

Baracaldo, N., Joshi, J., 2013. “An adaptive risk

management and access control framework to mitigate

insider threats”, Computers & Security. http://dx.doi.

org/ 10.1016/j.cose.2013.08.001.

Celikel, E., Kantarcioglu, M., Thuraisingham; D., Bertino,

E., 2009. A risk management approach to RBAC”.

Risk and Decision Analysis 1 (2009) 21–33. DOI

10.3233/RDA-2008-0002. IOS Press.

Costante, E., Vavilis, S., Etalle, S., Petkovic M., Zannone,

N., 2013. Database Anomalous Activities: Detection

and Quantification, SECRYPT 2013: 603-608.

Grushka-Cohen, H., Sofer, O., Biller, O., Shapira, B.,

Rokach, L., 2016. CyberRank-Knowledge Elicitation

for Risk Assessment of Database Security, 2016 ACM.

DOI: http://dx.doi.org/10.1145/2983323.2983896.

Darwish, S. M., 2015. Machine learning approach to

detect intruders in database based on hexplet data

structure. Journal of Electrical Systems and

Information Technology 3 (2016) 261–269,

http://dx.doi.org/10.1016/j.jesit.2015.12.001.

Jaidi, F., Ayachi, F. L., Bouhoula, A., 2017,

A Comprehensive Formal Solution for Access Control

Policies Management: Defect Detection, Analysis and

Risk, SCSS 2017. The 8th International Symposium on

Symbolic Computation in Software Science 2017,

Volume 45, 2017, Pages 120–132.

Boulares, S., Adi, K., Logrippo, L., 2017, Insider Threats

Likelihood Assessment for Flexible Access control,

International Conference on e-technologies. DOI-

10.1007/978-3-319-59041-7_5.

Boulares, S., Adi, K., Logrippo, L., 2017, Insider Threats

Likelihood Assessment for Access control:

quantitative approach, International Symposium on

foundation and prectice of security. DOI-10.1007/978-

3-319-51966-1_9.

ENASE 2018 - 13th International Conference on Evaluation of Novel Approaches to Software Engineering

304
