Extending CryptDB to Operate an ERP System on Encrypted Data

Kevin Foltz and William R. Simpson

Institute for Defense Analyses, 4850 Mark Center Drive, Alexandria, VA 22311, U.S.A.

Keywords: Enterprise, Enterprise Resource Planning, Database, System Design, Confidentiality, Integrity,

Homomorphic Encryption, Partial Homomorphic Encryption, Application Security, Security, Cloud

Services, End-to-End Encryption, Key Management, Database Security.

Abstract: Prior work demonstrated the feasibility of using partial homomorphic encryption as part of a database

encryption scheme in which standard SQL queries are performed on encrypted data. However, this work

involved only translating raw SQL queries to the database through the CryptDB proxy. Our work extends

the prior work to an Oracle application. The goal for this work was to determine feasibility for a full-scale

implementation on a real Oracle Enterprise Resource Planning (ERP) system. This requires accommodating

extra features such as stored procedures, views, and multi-user access controls. Our work shows that these

additional functionalities can be practically implemented using encrypted data, and they can be

implemented in a way that requires no code changes to the ERP application code. The overall request

latency and computational resource requirements for operating on encrypted data are under one order of

magnitude and within a small factor of those for unencrypted data. These results demonstrate the feasibility

of operating an Oracle ERP on encrypted data.

1 INTRODUCTION

Homomorphic encryption provides a way to

manipulate encrypted data to perform computations

on the underlying plaintext without decrypting the

data. It provides added security for hosting in a

cloud, where sensitive data may be accessible to an

untrusted third party. By homomorphically

encrypting data prior to storing it in the cloud, the

data can be used for computations while remaining

protected. This stops threats to confidentiality posed

by the cloud provider, its employees, and any

external entity that may compromise the cloud

provider.

Full homomorphic encryption (FHE) allows any

sequence of operations to be performed on the

encrypted data, so any computation can be done

encrypted (Gentry, 2009). However, FHE is

prohibitively slow for all but the simplest of

computations (Gligor, 2014). Partial homomorphic

encryption (PHE) has higher performance, but it

allows only a single type of operation, such as

addition or multiplication. An extensive survey of

homomorphic encryption methods is provided in

(Acar et al., 2017).

Our prior work suggested that FHE was not

practical, but methods using PHE showed promise

(Foltz and Simpson, 2017). Research involving PHE

has shown that a SQL database (DB) can be

encrypted such that standard SQL queries can be run

against this encrypted database (Popa et al., 2011).

The encryption is performed by the CryptDB proxy,

which is located between the database requester and

the database. The CryptDB proxy translates queries

on unencrypted data into queries on encrypted data,

allowing a user to access the encrypted database as if

it were not encrypted. The CryptDB proxy also

translates encrypted responses to unencrypted

responses.

Real systems are not as simple as a single

database. A typical Enterprise Resource Planning

(ERP) system has the following additional

complications:

• Proprietary ERP code that cannot be changed,

• Primary and foreign key reference integrity,

• Stored procedures,

• Views, and

• Multiple accounts with different permissions.

The original CryptDB implementation used

MySQL and did not account for these complications.

Foltz, K. and Simpson, W.

Extending CryptDB to Operate an ERP System on Encrypted Data.

DOI: 10.5220/0006661701030110

In Proceedings of the 20th International Conference on Enterprise Information Systems (ICEIS 2018), pages 103-110

ISBN: 978-989-758-298-1

103

Our work ports CryptDB from MySQL to Oracle’s

SQL database and addresses the items listed above.

This demonstrates that CryptDB can be integrated

with existing operational Oracle ERP systems and is

not restricted to the research laboratory or custom-

built systems.

2 RELATED WORK

There are many approaches to securing database

information. Monomi, another CryptDB-based

approach, allows more complex queries by splitting

computation between server and client (Tu et al.,

2013). The L-EncDB system uses techniques to

preserve the data formats and lengths between

unencrypted and encrypted data (Li et al., 2015).

The BigSecret system secures NoSQL databases

using property-preserving encryption on indices of

data encrypted with standard techniques (Pattuk et

al., 2013). A modular framework for providing

varying degrees of privacy and performance for

NoSQL databases is provided in (Macedo et al.,

2017).

3 RESEARCH METHODS

This section presents the experimentation and test

process. Maintaining correct functionality was

required. Experiments determined relative

performance in encrypted searches. This work

consists of the following steps:

1) Select database,

2) Determine the selected database schema,

3) Develop partial homomorphic encryption

schemes,

4) Perform credential mapping,

5) Develop SQL translation schemes,

6) Develop a web application test harness,

7) Establish a set of nominal work queries, and

8) Measure performance.

The implementation was performed in a lab with

commodity hardware and software, with the

exception of the CryptDB proxy and other code and

scripts written specifically for this work.

3.1 HR Database Selection

This work used the Oracle 12c database system and

the sample HR database that is provided with it by

Oracle. This database was used as the starting point

for development and testing. It provided an adequate

test system for many of the complexities of a full-

scale HR ERP system.

3.2 HR Database Schema

The HR DB schema consists of seven tables:

• Employees,

• Jobs,

• Job_History,

• Departments,

• Locations,

• Countries,

• Regions.

The Employees table schema is shown in Figure

1. The HR schema and the data for the HR DB were

used for unencrypted operation of the ERP and

served as the baseline for performance

measurements.

Figure 1: HR Schema for Employees Table.

For encrypted operation, the HR DB schema had

to be modified for encrypted data. This involved

modification of data types and sizes to accommodate

encrypted data. It also included additional columns

for multiple encryption methods where required. The

names of tables and columns were encrypted as well.

The ERP was not modified for these changes. It

communicated through the CryptDB proxy, which

mapped requests from the unencrypted schema to

the encrypted schema.

3.3 Encryption Schemes

Different encryption methods offer different

properties that are useful for operations on encrypted

data. The proper encryption scheme for data depends

on its intended use. The encryption methods and

supported SQL operations are shown in Table 1.

ICEIS 2018 - 20th International Conference on Enterprise Information Systems

104

Table 1: Encryption Methods.

Type

Encryption

Method

SQL

Operation

RND AES in CBC mode None

HOM Paillier Addition

SEARCH * Word Search

DET_EQ AES in CBC mode Equality

OPE * Order

EQ_JOIN * Join

OPE_JOIN * Range Join

* custom encryption methods

These encryption methods are listed in

approximate order of security protection, from

highest to lowest. Security protection decreases as

more information is revealed about the data. For

example, assuming the cryptographic methods are

known, random encryption reveals essentially no

information about the plaintext. Deterministic

encryption (DET) allows determination of whether

two encrypted values have the same plaintext values

without revealing what this plaintext is. Order-

preserving encryption (OPE) leaks the relative size

of the plaintext values without revealing the values

themselves.

Generally speaking, the encryption methods

reveal the amount of information needed to perform

the associated SQL operation. A determination of

whether this amount is acceptable must be made at

design time (Akin and Berk, 2015; Naveed et al.,

2015). For this work, we assume this is acceptable

for our intended use cases. In cases in which this is

not acceptable, there are methods to reduce it, and

these are briefly mentioned as future work.

Because different encryption schemes may reveal

different information when the cryptographic

methods are known, it is possible to layer them.

Plaintext can be encrypted with EQ_JOIN, and this

can again be encrypted with DET. We refer to a data

element that has undergone this multi-layer

encryption as an “onion,” with each different

encryption method being a layer of the onion. The

four encryption onions listed below are used for this

work. The EQ onion is illustrated in Figure 2.

1) Search: SEARCH

2) Add: HOM

3) EQ: RND, DET, EQ_JOIN

4) Ord: RND, OPE,

OPE_JOIN

Figure 2: EQ Onion Layering.

For situations in which these innermost onion

layers are rarely used, the onions-and-layers

approach provides increased security by revealing

the least secure inner layers only when needed. For

simplicity and performance, it is also possible to use

only the innermost layer.

3.4 Credential Mapping

To provide proper access to different users, different

accounts are set up within the ERP and database.

The ERP uses its accounts and credentials to make

queries to the database. To use these accounts

through the CryptDB proxy, separate accounts must

be created for the encrypted database. The CryptDB

proxy maps the existing accounts for the

unencrypted database to accounts for the encrypted

database.

Along with the accounts are keys and other

information that a user must have to encrypt requests

and decrypt responses. These keys are themselves

encrypted using information from the user account

so that only the appropriate accounts have access to

the proper cryptographic keying material. Other

accounts may be able to access the database of ERP

cryptographic keys, but they will not be able to

decrypt and use keys for which they are not

authorized.

3.5 SQL Translation Schemes

With the encryption methods and accounts set up,

we need a way to translate an unencrypted request to

an encrypted request. This translation depends on

the type of data and the type of encryption. For

normal requests, the column names and data are

encrypted. For other requests, such as addition, the

query itself must be modified. For example, with

Paillier encryption addition of plaintext corresponds

to multiplication of ciphertext.

Other translations are similar. For searching, text

strings must be converted to binary values. If a

numerical value is part of a query, it may need to be

encrypted in multiple ways if it is used with data in

different columns with different encryption methods

or keys.

With multiple users, which user will be calling a

stored procedure is not known, so encrypted values

in stored procedure queries cannot be pre-

determined. In this case, these values must be

inserted at execution time by determining the user

and updating the query based on the appropriate

user-specific information.

Extending CryptDB to Operate an ERP System on Encrypted Data

105

3.6 Web Application

To test an encrypted versus unencrypted database, a

web application was implemented to act as a

frontend for both the encrypted and unencrypted

databases. This web application runs natively on the

unencrypted database, and it can send requests to the

CryptDB proxy for operation on the encrypted

database. No code changes are needed in the

application itself. The switch to operate on

encrypted data is simply a configuration change.

In addition to the web application frontend,

various tools allowed more in-depth testing of the

encrypted database. Direct queries of the encrypted

database are possible using the sqlplus tool, but due

to the encrypted values, it is difficult to create the

requests or interpret the results. A script, cryptdb-

sqlplus was developed to make a subset of such

queries on the encrypted database. It uses the

CryptDB keys and mappings to translate and send

user requests to the encrypted DB and translate

responses.

3.7 Assessments

Assessment of the encrypted database consists of

three parts. The first part validates that each

implemented capability works as expected. A

sequence of requests is made to the unencrypted and

encrypted databases, and the results are compared.

Identical results confirm that the capabilities are

implemented correctly.

The second part consists of performance tests in

which the same sequence of queries is sent to the

same application, first using the unencrypted

database and then using the encrypted database

through CryptDB. Latency and throughput of the

encrypted database queries are compared to the

values for the unencrypted database.

The third part consists of multiple users with

simultaneous access, to confirm that the multi-user

access controls are performing properly and not

negatively affecting performance.

3.8 Lab Setup

The development work for the encrypted database

was done on a single machine. This allowed

functional testing and very limited performance

testing. For full performance testing, a dedicated lab

was set up with the following equipment:

• Database server laptop;

• Application server laptop;

• Multi-use desktop for application server,

loader, and client;

• Additional client laptop; and

• Ethernet switch.

The application server was a Dell Mobile

Precision 7710 laptop with four cores @ 3 GHz, 64

GB memory, 2 TB SSD, and 1 Gb/s Ethernet

running Windows 10.

The database server was identical to the

application server, except storage was two 1 TB

PCIe drives in a RAID 0 configuration.

A Dell Precision Tower 7910 served as multi-use

desktop. It had dual 20 core processors @ 2.2 GHz,

512 GB memory, a 2 TB SSD, and 1 Gb/s Ethernet

running Windows 10.

The additional client laptop had two cores @ 2.8

GHz, 8 GB memory, and 100 Mb/s Ethernet running

Windows 10.

Connecting these machines was an eight-port

gigabit Ethernet switch.

Software included the following:

• Oracle 12c database – database to store both

unencrypted and encrypted data;

• H2 database – database to store the CryptDB

keys and other cryptographic and mapping

data;

• CryptDB proxy – ported to Oracle from

original MySQL implementation;

• WebLogic 12.1.3 – web server for the test

application;

• Java JDK 7 update 80 for Windows x64 –

platform for various applications;

• JMeter – test tool to execute test scripts and

capture performance data;

• Bouncycastle – library for cryptographic

operations;

• Cygwin – application that enables Linux-style

scripting within a Windows operating system;

• Various scripts and tools developed for

automating the setup of the encrypted database

and loading the encrypted data into the

encrypted database.

4 RESULTS

This section presents the results for tests of proper

functionality and performance.

4.1 Proper Functionality

Porting the MySQL-based CryptDB implementation

to an Oracle-based implementation was tested first.

ICEIS 2018 - 20th International Conference on Enterprise Information Systems

106

Direct queries on the encrypted database showed

that the tables, columns, and values were properly

encrypted. Queries through the CryptDB proxy on

the encrypted database provided results that matched

results from the unencrypted database. This

confirmed the proper functioning of the encrypted

database and CryptDB.

4.2 Enhancements

Next, certain improvements were made to the

CryptDB implementation, including referential

constraints, views, and stored procedure capabilities.

These features, which are required for an ERP

instantiation, were not part of the original MySQL

implementation.

Stored procedures in the unencrypted database

are converted to stored procedures that perform

equivalent operations on the encrypted database.

This involves encrypting raw data in the procedures,

mapping table and column names, changing

operations (such as addition to multiplication for

Paillier encryption), and changing commands where

appropriate. Stored procedures use the PL/SQL

language, and for this work, a core subset of

PL/SQL was implemented to enable testing of stored

procedures.

Referential constraints are important for primary

key and foreign key references. When the primary

and foreign keys are encrypted with different

encryption keys, the database cannot guarantee

integrity across these two columns. CryptDB has

been modified to recognize these references and add

two additional columns that contain keyed hashes of

the primary and foreign keys. The keyed hash of the

foreign key is set to reference the keyed hash of the

primary key. CryptDB uses the same key to generate

the two columns of hashes, which allows the

database to maintain referential integrity of the

primary and foreign keys through these extra

columns.

Views are like tables, but they have some

important differences that require special

consideration for implementation. A table has one

column for random initialization vectors (IVs).

However, a view must have multiple such columns

because it may be constructed as a join across

multiple tables, each with its own IVs. CryptDB

must also maintain the mappings from each

encrypted column to its IV column.

Like tables, views can operate at different onion

layers of encryption. If these layers are unwrapped

or rewrapped on the underlying tables, the views

must keep track of these changes. A query on a view

that requires adjusting onion layers also requires

changes to the base tables. As a result, the query

translation for views is more complicated, and the

resulting query may contain additional queries to

change onion layers on the view and associated

tables, and changes to internal state to keep track of

the view-to-table mappings.

Stored procedures are groups of SQL statements

and control statements. They offer many benefits,

including performance, security, scalability, and

maintainability. However, they require CryptDB to

be extended to support creating, dropping, and

calling these stored procedures.

Additional complications arise in stored

procedures. The same encrypted value in a query

may be used across multiple columns and onions.

Instead of simply encrypting a value once, it must be

encrypted for each possible use. With multiple users,

a method for determining which principal is making

a request is required to select and use the proper key.

An additional challenge is that a result may be

from one or another column, and which column the

value comes from is determined at runtime. In this

case, CryptDB must keep track of which column,

onion, and principal a response came from, and use

this additional information for proper decryption.

The issues of multi-user stored procedures and

dynamic column determination have not been

addressed yet, and these present challenges for

future work. However, the solution concepts are

generally understood, so the challenge is simply

implementing them.

4.3 Performance

Performance testing was conducted to assess how

well suited this new CryptDB implementation is for

real-world implementations.

4.3.1 Operational Latency and Throughput

Operational performance testing was conducted

through the web application using a web browser.

For normal queries that completed quickly, there

was no noticeable difference in latency. For longer

queries that returned hundreds of thousands of

results, the difference was noticeable. However,

upon closer inspection, much of the time was

actually due to the larger data sizes for encrypted

data and the correspondingly longer time to transmit

them over Ethernet. Although this larger

transmission time is a valid concern for real-world

systems, it is only observed in queries with very

large result sets.

Extending CryptDB to Operate an ERP System on Encrypted Data

107

For a more comprehensive analysis, JMeter was

used as a test tool with a set of queries that

represented a normal mix for typical business. The

mix of queries included at least one use of each of

the following:

• Insert, Update, and Delete,

• DET-based queries,

• ORD-based queries,

• HOM-based queries.

In general, HOM, which is implemented using

Paillier encryption, is the most costly. It imposes a

significant computational burden on the Application/

CryptDB server beyond not only the unencrypted

queries but also the other encrypted queries. ORD is

also computationally expensive, but less so. The

others impose little additional overhead. The mix of

queries used for testing consisted of the following:

1) 3% Get all managers (35% of all employees

returned),

2) 2% Search on employees (3% returned),

3) 1% Search on employees (.15% returned),

4) 1% Search with salary range (1% returned),

5) 1% Search on employees (85% returned),

6) 3% Search on employees (5% returned),

7) 10% Search on employees (few returned),

8) 5% Search with salary range (ORD) (few

returned),

9) 5% Search on employees (few returned),

10) 10% Search with salary range (ORD) (few

returned),

11) 10% Search on employees (few returned),

12) 5% Search for employees with salary range

(ORD) (0 returned),

13) 2% Search for partial match in phone number

(1 returned),

14) 2% Search with partial match (1 returned),

15) 5% Search with addition of a constant to

results (HOM) (.2% returned),

16) 15% Insert an employee (Ins),

17) 15% Update an employee (Upd),

18) 5% Delete an employee (Del).

Queries 1 through 6 return large data sets, and it

is anticipated that these types of queries would be

executed occasionally only by users with special

privileges. Queries 7 through 18 represent standard

application queries that would be expected during

ongoing business operations.

Figure 3: Performance Summary, Queries 7–15.

To compare the user experience and resource

requirements for encrypted operation versus

unencrypted operation, increasing numbers of active

threads repeatedly cycled through queries 7 through

15, with the relative ratios as listed. This excludes

the queries with large result sets as well as the insert,

update, and delete operations, and it is intended to

represent normal user queries.

Figure 3 shows the observed latencies and

throughputs on the databases with one million users.

For this mix, the baseline latency was approximately

double with the encrypted database (36 ms vs. 19

ms), and achievable throughput was about 25% (155

req/s vs. 575 req/s). This suggests that encrypted

operation for these queries would require four times

the computational resources as unencrypted

operation to support the same request rates, and

latency would be approximately double under these

conditions.

Figure 4: Latency Ratios for Individual Queries and Mixes of Queries.

Completed requests per second

Encrypted

Unencrypted

Latency (sec)

ICEIS 2018 - 20th International Conference on Enterprise Information Systems

108

Additional testing was performed for each

individual query and for some combinations of

queries. Latency results are shown in Figure 4.

Queries 7 through 15 (Q7 – Q15), inserts (Ins),

updates (Upd), and deletes (Del) were tested

individually. Mixes 1 through 4 were as follows:

1) Q7-15, Ins, Upd, Del;

2) Q8, Q10, Q12;

3) Q7, Q9, Q11, Q13-15, Ins, Upd, Del;

4) Q7, Q9, Q11, Q13, Q14, Ins, Upd, Del.

Mix 1 is the baseline experience, representing a

normal mix of queries. Mix 2 examines just Queries

8, 10, and 12, which individually show improved

performance on encrypted data. In combination, they

show no change compared to unencrypted data. Mix

3 excludes Queries 8, 10, and 12 from the baseline

and shows degraded performance compared to the

baseline. Mix 4 is similar to Mix 3, but it excludes

the computationally intensive Query 15, revealing

that the degradation with increasing users was due

primarily to Query 15.

Query 15 performance degrades roughly linearly

with increasing request loads beyond five users. This

is because throughput is already saturated on the

encrypted system and additional queries simply

queue up and wait longer. For these tests the CPU

approached 100% utilization at seven users.

The Paillier encryption (HOM) of Query 15 is

the biggest bottleneck for performance and is the

most likely target for performance improvements in

a real system. The simple solution is to allocate

more resources to this type of encryption, either

through more servers, higher-performance servers,

or offloading the Paillier computations to more

efficient and parallelized GPUs rather than faster but

less parallel CPUs.

Although full multi-user functionality that

includes the use of stored procedures is not yet

implemented, performance testing was conducted

for multiple users on queries that do not use stored

procedures. For such queries the test tool JMeter was

launched with up to 100 parallel threads of

execution on a single machine. This simulates a high

load from many different users. This leveraged the

powerful desktop’s ability to run many threads.

Tests were also run from multiple requester

machines using multiple requester threads on each

machine.

Performance for multiple users showed no

significant degradation compared to the single user

case until CPU and other resources were nearly

consumed. No problems with encryption-related

locking of database resources were observed.

4.3.2 Data Load Time

The main question to answer for loading is whether

encryption adds significantly to the loading time.

Even when query performance is acceptable,

excessive time to encrypt and load the data may

create complications when a database must be

reloaded. Testing with a high-performance

commodity machine showed that encrypting the

database with one million employee records can be

completed in about one hour.

Figure 5: Database Loading Times.

The times are nearly linear in the size of the

database to be loaded. The speed of encryption is

also nearly linear in the number of processors. Thus,

the encryption time can be reduced by increasing

parallelism. Figure 5 shows results for single

machines with 4 and 40 cores.

5 CONCLUSIONS

This work assesses whether running an ERP on an

encrypted database is feasible. Prior work showed

that basic queries without the full complexities of a

real system were possible, but it was not clear

whether the additional complexities of a real system

could be accommodated and if so, whether the

performance would be acceptable.

The primary conclusion is that the Oracle-based

CryptDB system shows strong feasibility for real-

world implementations. It supports referential

integrity, views, and stored procedures, which are

three major areas of concern for real systems that

were not previously implemented.

The performance measured across individual

queries and in aggregate showed a small degradation

compared to the same queries on unencrypted data.

This degradation varies among the individual

Extending CryptDB to Operate an ERP System on Encrypted Data

109

queries, so a careful consideration of the mix of

queries is important.

Overall computational resource requirements are

increased due to the need for encryption, extra logic,

and processing, with an overall increase of a small

factor over the unencrypted computing resources.

This factor may vary depending on the particular

application and mix of queries.

Performance with multiple users showed good

scalability, with no observable encryption-related

latency.

Using CryptDB with an encrypted database is

feasible for moving a sensitive database to an

untrusted cloud hosting environment. The latency

performance is comparable to the use of an

unencrypted database, and comparable throughput

can be achieved with additional resources to support

the encryption-related computation.

6 FUTURE WORK

Follow-on work to this study includes testing on an

operational Oracle ERP system under normal use

cases and workflows.

Additional extensions and improvements are

planned for CryptDB, and PL/SQL support is to be

expanded. Performance improvement for Paillier

encryption may be possible using GPUs, which

should improve performance and reduce the load on

the CPU. This will provide the benefits of improved

scalability for Paillier encryption and reduced CPU

contention for other queries.

It was noted earlier that there are possible

leakages of information about plaintext through

some of the encryption schemes. For example,

relative sizes and distributions of numbers can be

calculated for OPE encryption, which could lead to a

few known values revealing other encrypted values.

This leakage cannot be completely eliminated,

but it can be reduced by various methods. First,

additional entries can be added to the database to

smooth out the distribution of values. Additional

queries would be inserted periodically to access

these otherwise unused values. Second, existing

entries with the same values can be split into

different categories by CryptDB so that they appear

different in the database. Third, encryption keys can

be changed periodically. These all impose a resource

burden on the system through additional storage and

computation.

ACKNOWLEDGEMENTS

The authors wish to acknowledge Virgil Gligor for

his deep insights and broad knowledge in

homomorphic encryption and related areas.

REFERENCES

Acar, A., Aksu, H., Uluagac, A. S., and Conti, M. A.

Survey on Homomorphic Encryption Schemes:

Theory and Implementation. arXiv preprint

arXiv:1704.03578v1, April 12, 2017.

Akin, I. H., and Berk, S. 2015. “On the Difficulty of

Securing Web Applications using CryptDB,”

International Association for Cryptologic Research.

Available at https://eprint.iacr.org/2015/082.

Foltz, K. and Simpson, W. Enterprise Level Security with

Homomorphic Encryption. In Proceedings of 19

International Conference on Enterprise Information

Systems (ICEIS 2017), Porto, Portugal, April 26–29,

2017.

Gentry, C. 2009. “A Fully Homomorphic Encryption

Scheme.” Doctoral thesis. Stanford University.

Available at https://crypto.stanford.edu/craig/craig-

thesis.pdf.

Gligor, V. 2014. “Homomorphic Computations in Secure

System Design,” Final Report. Pittsburgh, PA:

Carnegie Mellon University.

Li, J., Liu, Z., Chen, X., Xhafa, F., Tan, X., and Wong, D.

S. “L-encdb: A lightweight framework for privacy-

preserving data queries in cloud computing,” Knowl.-

Based Syst., vol. 79, pp. 18–26, 2015.

Macedo, R. et al., “A Practical Framework for Privacy-

Preserving NoSQL Databases,” 2017 IEEE 36th

Symposium on Reliable Distributed Systems (SRDS),

Hong Kong, 2017, pp. 11–20.

Naveed, M., Kamara, S., and Wright, C. V. “Inference

Attacks on Property-Preserving Encrypted Databases.”

In: CCS’15, Denver, CO, 2015.

Pattuk, E., Kantarcioglu, M., Khadilkar, V., Ulusoy, H.,

and Mehrotra, S. “Bigsecret: A secure data

management framework for key-value stores,”

International Conference on Cloud Computing, 2013.

Popa, R. A., Redfield, C. M.S., Zeldovich, N., and

Balakrishnan, H. 2012 “CryptDB: Processing Queries

on an Encrypted Database,” Comm. ACM, vol. 55, no

9, Sept. 2012 (also Proc. of 23rd ACM SoSP, Sept.

2011).

Tu, S., Kaashoek, M. F., Madden, S., and Zeldovich, N.

“Processing analytical queries over encrypted data,”

Proc. VLDB Endow., 2013.

ICEIS 2018 - 20th International Conference on Enterprise Information Systems

110
