Adaptation to the Unforeseen: Can We Trust Autonomous and

Adaptive Systems?

(Position Paper)

Emil Vassev and Mike Hinchey

Lero – The Irish Software Research Centre, University of Limerick, Limerick, Ireland

Keywords: Smart Vehicles, Autonomous Systems, Adaptive Systems, Adaptability.

Abstract: Autonomous and adaptive systems perform tasks without human intervention and are among the most

challenging topics in technology today. Autonomous cars have already appeared on our streets and

unfortunately due to some severe accidents they appear to be not as secure as we had hoped them to be. This

paper tackles the question of how far we can push the boundary towards achieving such behavior and still

provide autonomic operations at least in a certain context with highest safety guarantees to establish trust in

autonomous systems.

1 INTRODUCTION

Autonomous systems are becoming ubiquitous and

will definitely make it into our daily lives. For

example, autonomous cars are already seen on our

streets and the first severe accidents prove that they

are not as secure as we had hoped them to be. In a

perfect world, autonomous cars would be able to

share the road with other cars, motorists and

bicyclists without any accident. But obviously we

are not there yet. The hope, however, is that robotic

cars, which are great at monitoring other cars, will

be able to identify and avoid any other obstacles on

the road.

This position paper presents the authors' vision

regarding trust in autonomous cars and adaptive

systems in general.

2 ADAPTABILITY - A

DESIRABLE PROPERTY?

Without much doubt, the term "adaptive" identifies

one of the most challenging topics we currently

explore in technology. It identifies systems with the

property of being able to react to all situations

occurring during its lifetime, both correctly and

reliably and the question arises as to whether such a

behavior is feasible, implementable, or even

desirable.

2.1 Adaptability

Adaptability is conceptually a product of awareness

and automation, or automation through awareness

(Vassev and Hinchey, 2012). Awareness is about

representing and processing knowledge along with

monitoring, while automation is machine replication

of human operations.

While automation is more or less about

performing a sequence of operations under well-

defined conditions, awareness is the capability that

drives the automation, i.e., it identifies the specific

automation conditions.

Awareness incorporates means by which a

computerized machine can perceive events and

gather data about its external and internal worlds.

Therefore, to exhibit awareness, intelligent systems

must sense and analyze components as well as the

environment in which they operate.

Determining the state of each component and its

status relative to performance standards, or service-

level objectives, is therefore vital for an aware

system. Such systems should be able to notice

changes, understand their implications, and apply

both pattern analysis and pattern recognition to

determine normal and abnormal states. Generally

366

Vassev, E. and Hinchey, M.

Adaptation to the Unforeseen: Can We Trust Autonomous and Adaptive Systems? - (Position Paper).

DOI: 10.5220/0006390703660372

In Proceedings of the 3rd International Conference on Vehicle Technology and Intelligent Transport Systems (VEHITS 2017), pages 366-372

ISBN: 978-989-758-242-4

speaking, a self-adaptation should be automation

performed to fix abnormal states.

2.2 Need and Feasibility

Without any doubt, we believe that adaptability is a

desirable property, but its value really depends on

the system context. No adaptability, partial

adaptability, full adaptability, and controlled

adaptability are different levels or adaptability that

will make it both a desirable and realistic property

for most of the systems today.

Also, when reasoning on the feasibility of this

property, it is important to note that it has both

learning and implementation curves, which along

with the technology limitations also depend on the

thrust in technology. Nowadays, adaptability is a

desirable property wherever human control is not

possible (e.g., deep space exploration) or a quick

reaction is required. For example, to prevent disaster

a fuel pump can be automatically stopped in the

event of leakage in a fuel system. Other examples

where adaptability is not just desired, but even

essential, could be related to deep space exploration

or any case where human control is not possible due

to hazards threatening human lives or due to

inability to provide such control.

2.3 Adaptability and Evolution

Our computers are commonly considered as being

the most adaptive systems mankind has ever

invented and, observing how computers penetrate all

aspects of our lives and take control in almost all

applications, we have to acknowledge at least the

universality of computing equipment. Obviously, the

underlying reason for being adaptive and universal

originates from its very simple basic mechanism to

manipulate numbers in the dual system and the

ongoing minimization technologies for electronic

circuits. However, more important for becoming

adaptive, of course, is the programmability of such

machines using human intelligence and creativity,

and the human’s abilities to master complexity using

mathematics and computer science technologies.

Adaptability through evolution could be the next

level of adaptation where a system evolves to go

beyond its original meaning. Such an evolutionary

adaptation could tackle, for example, safety

properties which are no longer required, because the

related hazards had been permanently removed.

Another example, could be evolution in the

awareness capabilities of the system.

Let’s assume that an AI system is programmed to

self-adapt its hazard identification capabilities to

improve the same or to identify new hazards that

were not originally planned to be tackled. Well, we

will most probably get to the next level of AI where

it evolves and goes beyond its original meaning.

This situation can be addressed as technological

singularity (

Vinge, 1993). Note that the term

singularity has been used in math to describe an

asymptote-like situation where normal rules no

longer apply. For example, an originally

programmed AI can stop detecting specific hazards,

just because its evaluation criteria has evolved, and

these hazards are not hazards anymore. From this

point forward, we will be not that far from the

moment in the future where our technology’s

intelligence exceeds our own.

For example, an email spam filter can be loaded

with intelligence about how to figure out what is

spam and what is not and it will start to learn and

tailor its intelligence to us as it gets experience with

our particular preferences and habits. However, we

may often delete emails that we want to read but do

not want to keep in our email box. This can be

misinterpreted by the spam filter and it can start

filtering these important messages for us.

3 MACHINE LEARNING AND

ADAPTABILITY

The term machine learning (ML) is provocative as it

imputes that machines can learn similar to human

beings. In this section we will try to present our

interpretation of ML and how it is connected to

adaptability.

In general, ML is concerned with computer

programs that automatically improve with

experience (Mitchell, 1997). To do so, ML tries to

use a successful past solution and adapts it to a

similar problem, i.e., a sort of reasoning by analogy.

This is a principle that can be found in case-based

reasoning (CBR) systems applied to both simple and

structured knowledge representation (Aamod and

Plaza, 1994). Such a CBR system works along a

cyclic process, by retrieving the most similar cases,

reusing the cases in the attempt to solve the problem,

revising the proposed solution, if necessary, and

retaining the new solution as part of a new case.

ML is perhaps the most advanced field currently

explored for self-adaptation in software intensive

systems. The problem of adaptation through learning

has been a core research issue for a long time. An

Adaptation to the Unforeseen: Can We Trust Autonomous and Adaptive Systems? - (Position Paper)

367

example of ML connected to adaptability is ML in

dynamically changing environments where the

adaptation is performed through learning and

identification of context changes.

But how does ML distinguish from human

learning?

Currently, ML is only possible at a small scale

where self-adaptation is usually related to

formalisms used in Fuzzy Systems, Artificial Neural

Networks, and Evolutionary Computation (Baier and

Katoen, 2008). ML covers both symbolic methods

(decision trees and rules, etc.), sub-symbolic

methods (neural networks, Bayesian networks, etc.)

(Berger, 1985) and has several connections with

traditional statistics (discriminant analysis,

regression analysis, cluster analysis, etc.).

Still, mainly due to its mathematical

underpinning, ML is not biased, i.e., humans can be

biased in their decisions, but ML is strictly

mathematical. Human learning involves different

methods and different sources - their “knowledge

base” has common facts and strictly personal facts.

Experience can be transferred.

4 TRUST IN AUTONOMOUS

SYSTEMS

In today’s technologies, the term autonomous plays

a major role. It denotes systems which perform their

tasks without human intervention as e.g., automatic

lawn mowers, smart home equipment, driverless

train systems, or autonomous cars. The most

challenging question which comes up when

following the life cycle of the term “autonomy“ is

the potential to construct a system that behaves and

operates similarly to, or even better than, a human

being. Hence, it is reasonable to discuss how far we

can push the boundary towards such behavior and

provide autonomic operations at least in a certain

context with highest safety guarantees, and finally

establish trust in its innocuous operation.

But, will robots ever be able to fully substitute

humans?

Our answer is “probably not”. It really depends

a lot on the overall impact, not only technological

but also political that should be expected from a

universal autonomous system that successfully

replaces human beings. Autonomous systems that

will take over the entire traffic control and

transportation—yes, because this will eliminate

hazards related to human errors, e.g., fatigue. But it

is less likely that we will see robots that will ever

replace humans in decision making related to social

organization, for example.

The means to establish trust in autonomous

systems can be roughly described as a twofold

objective based on both boundaries and a technical

approach: 

1. Establish boundaries or a range of adaptation

— certain properties (e.g., safety) should be

unavoidably held, and thus unforeseen

adaptations that may mitigate such properties,

should not be allowed without change (human

control) in the established adaptation range.

2. Pursue autonomy in a stepwise manner where

autonomy can be gradually introduced: no

autonomy, partial autonomy, controlled

autonomy, and full autonomy. Hence in earlier

stages, autonomy should be used in less risky

domains.

4.1 Dominant Role of Autonomy

It is hard to imagine a system being constructed by a

human which adapts itself to all and especially all

unforeseen situations as the term unforeseen

describes circumstances the human himself has not

foreseen.

If we restrict ourselves to some foreseen

unforeseen behaviors which we might be able to

handle, we have to consider a problem of

completeness. Did we cover the whole set of

behaviors or did we omit some of the behaviors?

This, of course, raises questions of complexity as the

number of such situations might be close to infinity

and thus, not foreseeable at all. In order to handle

such complexity, we have to restrict the adaptability

of our systems to a certain context in which we are

able to capture all different behaviors, or which at

least enables us to classify and cluster such

situations. Home environments with a few sensors

only might be such a context as well as autonomous

transportation systems, e.g., smart trains.

Some other contexts in which autonomy could

play a dominant role are contexts where systems

operate in environments that change dynamically,

e.g., space, ocean, weather stations, etc. In such

cases, it is impossible to identify and predefine all

possible behaviors. A solution could be related to the

use of granularity in behavior modeling, i.e., a self-

adaptive system should not handle all the possible

behaviors, but categories (or classes, or clusters) of

possible behaviors. Then, known behaviors shall be

classified and let the learning process cope with

these.

VEHITS 2017 - 3rd International Conference on Vehicle Technology and Intelligent Transport Systems

368

The awareness-learning process will be able to

identify a class of behaviors close to the requested

behavior and then pick up a behavior from this class

(a low-level behavior). This could be done in a

probabilistic manner, when the low-level behavior

identification is not possible. Moreover, behaviors

based on combinations of predefined behaviors can

be identified by a reasoner on an input-output basis.

Therefore, scientists vote again for more math

and formalisms in their development but obviously

this is much more difficult than it was to prove a

non-autonomous system correct. Obviously, it is not

just a matter of logic and logical proofs but it has to

incorporate statistical evidence, too, and last but not

least, it has to integrate the physical properties of

such systems, as e.g., acceleration, loss of weight or

the compression of gas under pressure in order to

prepare for adaptability. We assume that in order to

capture autonomicity in a safe and reliable way, we

will see in the near future a convergence of

modeling and development techniques based on

logics, statistics, and numerics.

4.2 Autonomy and Adaptation Cannot

Be 100% Safe

In regards to autonomy and adaptation, the

application of formal methods can only add to

safety. Even if we assume that proper testing can

capture all the autonomy flaws that we may capture

with formal verification, with proper use of formal

methods we can always improve the quality of

requirements and eventually derive more efficient

test cases, and consecutively, a safer autonomy.

Moreover, formal methods can be used to create

formal specifications, which subsequently can be

used for automatic test-case generation. Hence, in

exchange for the extra work put to formally model

the autonomy and adaptability of a system, you get

not only the possibility to formally verify and

validate these features, but also to more efficiently

test their implementation.

It is evident that 100% safe autonomy cannot be

guaranteed, but when properly used, formal methods

can significantly contribute to this by not replacing,

but complementing testing. The quantitative

measure of how much safety can be gained in

autonomy may be regarded in three aspects:

1. Formal verification and validation allows for

early detection of autonomy and adaptation

flaws, i.e., before implementation.

2. The high quality of autonomy requirements

improves the design and implementation of

these requirements.

3. Formally specified autonomy requirements

assist in the derivation and generation of

efficient test cases.

To be more specific, although it really depends on

the complexity of the system in question, our

intuition is that these three aspects complement each

other and together they may help us build a system

that has a considerably higher safe autonomy. This

principle can further emphasize a systems' ability to

autonomously tackle various hazards.

4.3 Correct Adaptations

How do we prove adaptations to be correct and

reliable? And is there a difference between such

proofs for foreseen and unforeseen behaviors?

Adaptations are related to non-determinism and

thus, their correctness proof, if possible, is a tedious

task. Simulation is one solution. Another one is

probabilistic guarantees—probabilistic model

checking is a powerful technique for formally

verifying quantitative properties of systems that

exhibit stochastic behavior (Baier and Katoen,

2008).

Probabilistic behavior may arise, for example,

due to failures of unreliable components, dynamic

environment, etc. Unforeseen behavior cannot be

model-checked. It can be eventually simulated (to

some extend) through a random generation of the

simulated conditions and verified via testing.

4.4 Are Autonomous Systems More

Vulnerable?

Considering their adaptive nature, do we expect

autonomous systems to be more vulnerable against

malicious attacks?

Our definitive answer to this questions is “Yes”.

Moreover, the risk of a successful malicious attack is

extremely high if the parameterization of their

adaptive autonomy is known to the attackers. For

example, attackers can use adaptation to open a hole

in the security firewall (e.g., a new port can be

opened for additional communication link as part of

a self-adaptation behavior) that can be unavoidably

used for malicious attacks.

An eventual solution could be encryption in

communication and why not in autonomy as well.

For example, the autonomy-related knowledge base

shall be encrypted. Moreover, identification of the

autonomy agents shall be required at any level of

interaction.

Adaptation to the Unforeseen: Can We Trust Autonomous and Adaptive Systems? - (Position Paper)

369

4.5 Connectivity and Safety of

Autonomous Transportations

Communication and connectivity are two significant

factors that have impact on safety of autonomous

transportation. Autonomous smart vehicles are

connected, so they are able to share data with other

vehicles on the road or with the infrastructure. In

general, both vehicle-to-vehicle (V2V) connectivity

and vehicle-to-infrastructure (V2I) connectivity help

to reduce road accidents, and thus increase the

transportation safety. Ultimately, vehicles and road

infrastructure are connected via multiple

complementary technologies of connectivity such as

Wi-Fi, Bluetooth, GPS, DSRC (dedicated short-

range communications), etc. Wireless vehicular

communication has the potential to enable a class of

safety applications that can prevent collisions and

save lives as well as improve traffic congestion and

fuel efficiency. The effectiveness of these

technologies though is highly dependent on

cooperative standards for interoperability. For

example, DSRC is particularly useful for V2x

communications, because it can support very low-

latency, secure transmissions and fast network

acquisition. It is also considered to be highly robust

in adverse weather conditions (Hill, 2015).

The automotive industry has recognized the

importance of connected cars by pairing up with

other cars and road infrastructure, smart phones, and

other smart devices. Moreover, a swarm of sensors

is used in vehicle internals such as GPS sensors, air

pressure sensors, vehicle speed sensor, steering

angle sensors, and fire detection sensors among

others. In this swarm of sensors, the various

electrical components in a car, known as Electronic

Control Units (or ECUs), are connected via an

internal network. Therefore, a smart vehicle exhibits

extreme connectivity involving both the external

environment and internal ECUs. One of the central

challenges in this connectivity is cyber security.

Unauthorized access to the external or internal

network of a smart vehicle can easily create safety

risks. For example, if hackers manage to gain access

to a car’s Bluetooth or infotainment system, from

there they may be able to take control of safety

critical ECUs like its brakes or engine and wreak

havoc (Toews, 2016).

A contemporary smart vehicle can have over one

hundred ECUs and more than one hundred million

lines of code. Verification of a complex source code

is a tedious task. Further complication is stemming

from the fact that vehicle manufacturers source

ECUs from many different suppliers, meaning that

no one is in control of, or even familiar with, all of a

vehicle’s source code. Production of complex source

code, in particular, increases the security risks and

thus the threat of automotive cyber attacks and

safety hazards.

5 SELF-DRIVING CAR

EXAMPLE

The example presented here should be regarded with

the insight that “100% safe autonomy is not

possible”, especially when the system in question

(e.g., a self-driving car) engages in interaction with a

non-deterministic and open-world environment

(Wirsing, Holzl, Koch, Mayer, 2015) (see Figure 1).

What we should do though, to maximize the safety

guarantee that “the car would never injure a

pedestrian” is to determine all the critical situations

involving the car itself in close proximity to

pedestrians.

Then, we shall formalize these situations as

system and environment states and formalize self-

adaptive behavior, e.g., as self-* objectives (Vassev

and Hinchey, 2013, Vassev and Hinchey, 2014)

driving the car in such situations (Vassev and

Hinchey, 2015).

Figure 1: Self-driving Car Interacts with the Environment.

For example, a situation could be defined as “all the

car’s systems are in operational condition and the

car is passing by a school”. To increase safety in this

situation, we may formalize a self-adaptive behavior

such as “automatically decrease the speed down to

20 mph when getting in close proximity to children

or a school”.

Further, we need to specify situations involving

close proximity to pedestrians (e.g., crossing

pedestrians) and car states emphasizing damages or

malfunction of the driving system, e.g., flat tires,

malfunctioning steering wheel, malfunctioning

brakes, etc. For example, we may specify a self-

adaptive behavior “automatically turn off the engine

when the brake system is malfunctioning and the car

is getting in close proximity to pedestrians”.

VEHITS 2017 - 3rd International Conference on Vehicle Technology and Intelligent Transport Systems

370

6 HOW TO CONSTRUCT

RELIABALE AUTONOMOUS

SYSTEMS

How can particular modeling techniques,

programming concepts and verification methods

help to construct reliable autonomous systems?

6.1 Structured Autonomy

Formal methods need to be used in both analysis and

code generation. Autonomy requirements need to be

properly handled and then both design and

implementation should consider formalization of

these requirements.

The autonomy part of the system behavior (or

the autonomy) needs to be tackled separately - that's

it, any system has its purpose (objectives) it needs to

follow and functionality that basically supports its

objectives. Autonomy is an extra feature (or layer)

that is often desirable and its implementation should

be definitely separated from that of the system itself.

Autonomy must be structured, implemented, and

eventually verified via proper methods, e.g., ARE

(Vassev and Hinchey, 2014) and KnowLang

(Vassev and Hinchey, 2015). Obviously, the

formalization of well-defined properties (e.g., with

proper states expressed via boundaries, data range,

outputs, etc.) is a straightforward task. However, it is

not that easy to formalize uncertainty, e.g., liveness

properties. Although, probabilistic theories such as

the classical and quantum theories, help us formalize

“degrees of truth” and deal with approximate

conclusions rather with exact ones, the verification

tools for fuzzy control systems are not efficient due

to the huge state-explosion problem.

Note that, testing systems implemented over

probabilistic theories, is also not efficient, simply

because, statistical evidence for their correct

behavior may be not enough. Hence, any property

that requires a progressive evaluation (or partial

satisfaction, e.g., soft goals) is difficult and often

impossible to be formalized for use in formally

verified systems. Here, it seems the right answer is

simulation that will help gain enough statistical

evidence for the autonomy behavior correctness.

6.2 Legal and Warranty Issues

Besides the mentioned technical properties, another,

often neglected aspect are public laws and

regulations the systems have to be conform with.

Adaptation will probably make it more difficult to

handle such non-functional requirements and

requests strict and probably new methods to prove

conformity of adaptations with them. For example,

engineers currently argue that the most severe

obstacles to drive autonomously on our streets are

not of technical but of legal nature and concern

warranty and guilt.

How could we cover legal and warranty issues in

the development and dissemination phases of

systems?

We strongly believe that in order to cope with

law and warranty, self-adaptive systems need to be

introduced in a stepwise manner. Laws and concerns

will be changed only if the self-adaptive and

autonomous systems prove to be better than human

operators.

7 CONCLUSION

If we assume a self-driving vehicle loaded with AI,

it as a subject to uncertainty due to potential

nondeterministic environment it operates on. Often,

this lack of determinism is extended by

requirements, business conditions, available

technology, and the like. Therefore, if we want to

construct reliable autonomous systems (e.g.,

intelligent vehicles), it is important to capture and

plan for uncertainty as part of the system's R&D.

Failure to do so may result in systems that are overly

rigid for their purpose, an eventuality unsafe in their

autonomy and adaptation.

Formal methods can assist in the construction of

reliable adaptive systems. To do so, formal methods

need to be used in both analysis and code

generation. Moreover, autonomy requirements need

to be properly handled and then both design and

implementation should consider formalization of

these requirements. For example, contemporary

formal verification techniques can be very helpful in

verifying safety properties via the formalization of

non-desirable system states along with the

formalization of behavior that will never lead the

system to these states.

ACKNOWLEDGEMENTS

This work was supported with the financial support

of the Science Foundation Ireland grant 13/RC/2094

and co-funded under the European Regional

Development Fund through the Southern & Eastern

Regional Operational Programme to Lero—the Irish

Software Research Centre (www.lero.ie).

Adaptation to the Unforeseen: Can We Trust Autonomous and Adaptive Systems? - (Position Paper)

371

REFERENCES

Aamod, A., Plaza, E., 1994. Case-Based Reasoning:

Foundational Issues, Methodological Variations, and

System Approaches. In Artificial Intelligence

Communications 7(1994):1, 39-52.

Baier, C., Katoen, J.P., 2008. Principles of Model

Checking. MIT Press.

Berger, J.O., 1985. Statistical Decision Theory and

Bayesian Analysis. Springer Series in Statistics.

Springer-Verlag. 2

edition.

Hill, K., 2015. What is DSRC for the connected car? In

RCR Wireless News, url: http://www.rcrwireless.com/

20151020/featured/what-is-dsrc-for-the-connected-

car-tag6

Mitchell, T. M., 1997. Machine Learning, McGraw-Hill

Science/Engineering/Math. 1

edition.

Toews, R., 2016. The Biggest Threat Facing Connected

Autonomous Vehicles is Cybersecurity. In TC

Sessions. https://techcrunch.com/2016/08/25/the-

biggest-threat-facing-connected-autonomous-vehicles-

is-cybersecurity/

Vassev, E., Hinchey, M., 2012. Awareness in Software-

Intensive Systems. In IEEE Computer 45(12), 84–87.

Vassev, E., Hinchey, M., 2013. Autonomy requirements

engineering. In IEEE Computer 46(8), 82–84.

Vassev, E., Hinchey, M., 2014. Autonomy Requirements

Engineering for Space Missions. In NASA

Monographs in Systems and Software Engineering.

Springer.

Vassev, E., Hinchey, M., 2015. Knowledge representation

for adaptive and self-aware systems. In Software

Engineering for Collective Autonomic Systems,

Volume 8998 of LNCS. Springer.

Vinge, V., 1993. The coming technological singularity:

How to survive in the post-human era. https://www-

rohan.sdsu.edu/faculty/vinge/misc/singularity.html

Wirsing, M., Holzl, M., Koch, N., Mayer, P. (eds.)., 2015.

Software Engineering for Collective Autonomic

Systems. Volume 8998 of LNCS. Springer.

VEHITS 2017 - 3rd International Conference on Vehicle Technology and Intelligent Transport Systems

372
