A Change Impact Analysis Model for Aspect Oriented Programs

Fabrice Déhoulé, Linda Badri and Mourad Badri

Department of Mathematics and Computer Science, University of Quebec, Trois-Rivières, Canada

Keywords: Software Evolution, Aspect-Oriented Programming, Change, Ripple Effect, Impact Analysis, Predictive

Analysis, Model, Impact Rules, Empirical Analysis.

Abstract: Software change impact analysis (IA) plays a crucial role in software evolution. IA aims at identifying the

possible effects of a source code modification. It is often used to evaluate the effects of a change after its

implementation. However, more proactive approaches use IA to predict the potential effects of a change

before it is implemented. In this way, IA provides useful information that can be used, among others, to

guide the implementation of the change and to support regression tests selection. This paper aims at

proposing a change impact analysis model for AspectJ programs. Aspect-Oriented Programming (AOP) is a

natural extension of Object-Oriented Programming (OOP). It particularly promotes improved separation of

crosscutting concerns into single units called aspects. The IA techniques proposed for object-oriented

programs are not directly applicable for aspect-oriented programs due to the new dependencies introduced

by aspects. The proposed model was designed to particularly support predictive IA. The model includes

several impact rules based on the AspectJ language constructs. We performed an empirical evaluation of the

model using several AspectJ programs. In order to assess the model prediction quality, we used two

traditional measures: precision and recall. The reported results show that the model is able to achieve high

accuracy.

1 INTRODUCTION

As software systems are used for a long period of

time, software evolution is inevitable. Indeed,

software systems need to continually evolve for

various reasons, including: adding new features to

satisfy user requirements, changing business needs,

introducing novel technologies, correcting faults,

improving quality, and so forth. So, as software

evolves, the changes made to the software must be

carefully managed. It is particularly important to

ensure that modified software still verifies its

specification and whether new errors were

introduced inadvertently (Kung et al., 1995;

Rothermel and Harrold, 1997; Harrold et al., 2001;

Hunt et al., 2008). It is, therefore, crucial to find

where changes occur and to identify parts of the

software that are possibly affected by the changes,

parts that must be correctly retested. Indeed, for

obvious reasons, retesting all the software after

instantiating a change is inefficient, costly and

unacceptable in practice (Rothermel and Harrold,

1996). In the software life cycle, maintenance plays

a fairly important role (Lehman et al., 1997). It is

during this step that we can change a program to

improve it, adapt it to new specifications, or prevent

any errors (Law and Rothermel, 2003; Lehnert,

2011). Its importance is even more increased by the

fact that the systems produced nowadays are

becoming more complex and voluminous (Lehman

et al., 1997).

Software evolution faces many challenges

(Lehman, 1980; Lehman et al., 1997; Ebert and De

Man, 2005; Mens et al., 2008). Software

maintenance is, in this context, a vital activity

(Bennett and Rajlich, 2000). It is, however, costly

(Grubb and Takang, 2003; Abran et al., 2004).

Several experts agree that two of the most important

activities of software maintenance are:

understanding the software and evaluating the

potential effects of a change (Barros et al., 1995;

Aggarwal et al., 2002; Riaz et al., 2009; Baggen et

al., 2011; Cho et al., 2011). The second activity is

closely related to the first one. Indeed, to understand

the effects of a given change, it is necessary to

understand the system beforehand (Lee et al., 2000).

The software design, particularly the dependencies

between its components, can make this task difficult.

144

Déhoulé, F., Badri, L. and Badri, M.

A Change Impact Analysis Model for Aspect Oriented Programs.

DOI: 10.5220/0006350701440157

In Proceedings of the 12th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2017), pages 144-157

ISBN: 978-989-758-250-9

A change to a system, even minor, can lead to

several unintended effects (ripple-effect). One

effective way to deal with this important issue is to

develop models (and techniques) that can be used to

support the evaluation of the potential effects of a

change. This can be used to guide the decision-

making of software development managers seeking

to produce high quality software.

Software change impact analysis (IA) plays a

crucial role in software evolution. Bohner and

Arnold (1996) defined change impact analysis as

“the process of identifying the potential

consequences of a change, or estimate what need to

be modified to accomplish a change”. IA allows,

indeed, developers assessing the possible effects of a

given source code modification (Yau and Collofello,

1980; Li and Henry, 1995; Li and Offutt, 1996;

Bohner and Arnold, 1996; Briand et al., 1999; Lee et

al., 2001; Chaumun et al., 2002; Law and

Rothermel, 2003; Ren et al., 2004; Ackermann and

Lindvall, 2006; Li et al., 2012). IA can be used to

support various maintenance tasks such as: planning

changes, assessing the cost of changes,

implementing changes, tracking the effects of

changes and regression tests selection (Law and

Rothermel, 2003; Orso et al., 2003; Orso et al.,

2004; Ackermann and Lindvall, 2006).

Aspect-Oriented Software Development (AOSD)

is a promising new software engineering paradigm

(Sabbah, 2004; Dong, 2011). AspectJ, as an aspect-

oriented programming language, represents an

interesting extension of Java (Przybylek, 2011). In

fact, existing object-oriented programming

languages suffer from a serious limitation in

modularizing adequately crosscutting concerns

(Przybylek, 2011). Many concerns crosscut several

classes in an object-oriented program. Crosscutting

is a structure that goes beyond hierarchy as stated in

(Bernardi and Di Lucca, 2007; Bernardi et al., 2009;

Przybylek, 2011). The code related to a crosscutting

concern is generally duplicated within several

classes in an object-oriented program. Consequently,

these classes would be difficult to understand,

maintain and reuse. Aspect-Oriented Programming

(AOP) deals with scattered and tangled code related

to crosscutting concerns. It particularly promotes

improved separation of crosscutting concerns into

single units called aspects (Zhao, 2004; Baggen et

al., 2011; Przybylek, 2011).

Although AOP was introduced to separate

concerns and improve software modularity,

modifying aspect-oriented programs will lead to

more complex impacts than in object-oriented

programs (Zhang et al., 2008; Burrows et al., 2010).

Storzer (2007) indicates that the aspects and the base

code are decoupled at syntax and that we need to

know the relationships between classes and aspects

of the program. He also indicates that aspects can

interfere with each other, interference that may be

difficult to resolve. It is important to mention that

the evolution of the base object code may change or

break the aspects’ semantic, since they are based on

the object code.

With an aspect-oriented program, there will be

four impact possibilities: (i) impacts of changes

introduced into the object-code part on itself (Object

- Object), (ii) impacts of changes made in the object

code part on the aspect part (Object - Aspect), (iii)

impacts of changes in the aspect code (Aspect -

Aspect), and (iv) impacts of changes made into the

aspect part on the object part (Aspect - Object). Our

work focuses on the last three types of impacts. The

first type of impacts concerns only object-oriented

programs and has been addressed in our previous

work (Badri et al., 2015).

We present, in this paper, a new static change

impact analysis model for AspectJ programs. The

model, including several impact rules based on the

AspectJ language constructs, was designed to

support predictive impact analysis. We performed an

empirical evaluation of the model using several

AspectJ programs. We considered in the study

different types of changes. In order to assess the

model prediction quality, we used two traditional

measures: precision and recall. In addition, we

evaluated the proposed approach using the

properties of the Framework proposed by Li et al.

(2012) characterizing impact analysis techniques.

The proposed model complements, in fact, the

Change Impact Model for Java programs (CIMJ)

that we developed in our previous work (Badri et al.,

2015).

The rest of the paper is organized as follows:

Section 2 presents an overview of the main related

work. Section 3 provides a brief overview of aspect-

oriented programming (AOP). Section 4 introduces

the impact analysis model we propose. Section 5

presents the empirical study we conducted in order

to assess the performance on the proposed model.

Section 6 gives a conclusion and some future work

directions.

2 RELATED WORK

Change impact analysis aims to predicting which

parts of the code will be affected following a

modification (Ackermann and Lindvall, 2006). IA

A Change Impact Analysis Model for Aspect Oriented Programs

145

3



allows identifying the consequences of a change, or

estimating the parts to modify in a program to ensure

that the change is made correctly (Ali et al., 2012).

IA is very important because it allows, among

others, to help change management, and keeping the

system stable (Arnold and Bohner, 1993; Ali et al.,

2012).

Many criteria have been proposed in the

literature for classifying existing IA techniques

(Kilpinen, 2008; Lehnert, 2011; Li et al., 2012; Sun

et al., 2014). These techniques addressed, in fact,

various specific tasks of software maintenance.

Existing IA techniques can be static and/or dynamic

(Lee et al., 2000; Law and Rothermel, 2003; St-

Yves, 2007; Petrenko and Rajlich, 2009; Zhou et al.,

2011; Acharya and Robinson, 2012; Li et al., 2012),

based on the source code of the program and/or on

models (St-Yves, 2007; Petrenko and Rajlich, 2009).

Static IA techniques include structural static

analysis, textual analysis, and historical data analysis

(Zimmermann et al., 2005; Petrenko and Rajlich,

2009; Gethers and Poshyvanyk, 2010; Sun et al.,

2014). Static analysis techniques are based on the

syntax and semantic dependencies of the program.

These techniques use most of the time system

representations such as call graphs, control flow

graphs, etc. Dynamic analysis techniques are based

on information gathered during the execution of the

program (Sun et al., 2010).

Impact analysis techniques can be divided in two

major classes: impact analysis techniques that

support predictive analysis - pre-change (Chaumun

et al., 2000; Badri et al., 2005; St-Yves, 2007; Abdi

et al., 2007; Badri et al., 2015) and impact analysis

techniques that support retrospective analysis - post-

change (Kabaili et al., 2001; Ren et al., 2004).

Predictive impact analysis techniques are used

before the change is implemented, and aim mainly at

predicting the potential effects of a change, which

allows assessing the effort required for its

implementation. Retrospective impact analysis

techniques are used after a change has been

implemented. These techniques aim mainly at

supporting the correction of potential errors that are

introduced by changes, and regression testing

(Kabaili et al., 2001; Orso et al., 2003; Orso et al.,

2004; Ren et al., 2004; Li et al., 2012).

Different approaches have been proposed to

predict the impact of changes made on aspect-

oriented programs. Bernardi and Di Lucca (2007)

developed an Inter-procedural Aspect Control Flow

Graph. This graph shows the relationships between

class’s methods and advices in aspect code, and also

indicates where the advice code will be inserted in a

method during weaving. One of the benefits of the

graph, according to the authors, is to save time

during maintenance steps, about 20% less time. The

graph do not take into account neither exception

management, nor inter-type declarations and static

initializers, and the result may be a large number of

nodes, making the analysis a little more complex.

The authors have addressed the static analysis of the

code, even if the graph is also able to manage the

dynamic analysis.

Shinomi and Tamai (2005) developed an

algorithm that aims to list the impacts. This

algorithm successively generates a syntactic abstract

tree, a control flow graph, a call graph of methods or

advices and finally a dependency graph for each

method. Once all these graphs are obtained, the

algorithm establishes a starting point of impact list

for each aspect. Then, from each starting point of

impact corresponding to an aspect (weaving point),

the parts affected by aspects are marked. This impact

analysis is done after the weaving and concerns only

impacts on object code after changes made in aspect

code.

The impact analysis technique proposed by

Zhang et al. (2008) identifies the parts of the source

program and the tests affected by a change. This

technique relies on atomic changes that capture the

semantic differences between two versions of a

program. These atomic changes are at the level of

the source program, but also in the aspect code.

Atomic change transactions are meant for an

addition / deletion / modification of method, aspect,

pointcut, class or attribute. Thus, to determine which

parts of the program may be affected by a change

(atomic change), the authors list the changes. Then,

a program call graph is generated. The code

fragments affected by a change will be the nodes of

the graph that are linked to the modified node. This

is the transitive closure of each modified node. This

impact analysis technique has the disadvantage of

not being predictive since it is necessary that the

modifications were made before determining which

pieces of the code are affected.

Zhao (2002) operates on a slicing aspect oriented

system dependency graph (Aspect-Oriented System

Dependence Graph) made of several modules

dependencies graphs (Module Dependence Graph)

interconnected.

3 ASPECTJ: BASIC CONCEPTS

AspectJ is an aspect-oriented extension to the Java

ENASE 2017 - 12th International Conference on Evaluation of Novel Approaches to Software Engineering

146

language (Gradecki and Lesiecki, 2003). With

AspectJ, the aspect code will be incorporated into

the basic program through weaving when compiling

the code. AspectJ introduces several new language

constructs (aspect members) such as: aspect, join

points, pointcuts, advice as well as inter-type

declarations (Kiczales et al., 2001; Dong, 2011).

These various elements allow an aspect expressing a

concern that crosscut several basic classes. Aspects

are built like object classes, in which all elements

related to an aspect are defined. A join point

represents well-defined points in the program flow

where the aspects will be weaved; such as method

calls, exceptions, interfaces or other instructions of

the basic object classes. Pointcuts describe join

points and context to expose. An advice is a method-

like abstraction that defines code to be executed

when a join point is reached. Pointcuts are used in

the definition of an advice. Inter-type declarations

define how AspectJ modifies a program's static

structure, namely, the members and the relationships

between components. Inter-type declarations alter

the structure of the object program by adding

methods or attributes to an object class, changing the

inheritance of a class, or by specifying that a class

implements one or more interfaces. Pointcuts and

advices dynamically affect program flow, and inter-

type declarations statically affect a program's class

hierarchy. For further information on AspectJ

mechanisms, one can see (Kiczales et al., 2001;

Przybylek, 2011).

4 IMPACT MODEL

4.1 Objectives

We present, in this section, the Impact Analysis

Model that we defined for Changes in AspectJ

programs. Our model aims to predicting the different

parts of an aspect-oriented application that will be

affected due to a change in the program. An aspect-

oriented program contains object code and aspect

code, so there will be changes that may affect both

parts. The model specifies for each type of change a

set of impacts which provide useful information

allowing taking into account cascading impact. The

model includes various atomic changes. An atomic

change is the smallest unit of change that cannot be

decomposed into other changes. Atomic changes are

divided in two distinct groups: structural and non-

structural changes. Our Aspect Oriented Change

Impact Model (AOCIM) complements the CIMJ

(Badri et al., 2015), developed in our previous work

for Java programs, and will be used in a predictive

analysis context.

Change Impact Model for Java (CIMJ) was

developed by N. Joly et al. (Joly, 2010; Badri, et al.,

2015). The impact model considers the impact of

object code to object code. As mentioned, the CIMJ

allows a predictive impact analysis and a post-

analysis. However, the emphasis was on predictive

analysis. It is an impact model that allows a cascade

impact analysis, responding to the problem of the

ripple effect of change impacts. The MICJ is limited

only to the object-oriented programs. Indeed, it only

considers the impacts that will occur in the object-

oriented code following the changes made on the

same object-oriented code. To extend the CIMJ to

the aspect part of the program, we have introduced

three impacts categories:

Impacts - object to aspect: Here, we will see the

impact of any changes in the classes, methods,

attributes on the aspect code. These changes will

also involve exceptions and inheritance

relationships.

Impacts - aspect to aspect: This category of

impacts will be located only in the aspect code. We

deal here with the consequences that will occur on

the remaining aspect code following the changes

performed at portions such as a pointcut or

intertypes declarations.

Impacts - aspect to object: When changing the

aspect part of a program, this could affect the object

code. Therefore, it is about to determine which parts

of the object code will be impacted.

4.2 Relationships in an Aspect-oriented

Program

Three types of relationships in an aspect-oriented

program were considered in the impact model.

Association: a module referring to another (Kumar

et al., 2007). An association relationship is created

between an aspect and one or more classes through

joinpoints or by inter-type statements. The

association is also created at the level of the advices

when an object of a class is instantiated in an advice.

Finally, there will be an association between an

aspect and a class when a method at the aspect level

will take as parameter object type of the class.

Inheritance: an inheritance link created between

two modules leads child to benefits from the

properties of the parent module (Kumar et al., 2007).

An aspect S can inherit from a class A but also from

another aspect P.

A Change Impact Analysis Model for Aspect Oriented Programs

147

5



Local pseudo-relationships: some impacts may

occur inside the aspect in which the change takes

place (Kumar et al., 2007). This happens for

example when the parameters of a pointcut are

changed. Therefore, it will also change the

parameters of advices related to this pointcut.

4.3 Structural and Non-structural

Changes

A structural change is a change that alters the

structure of a class or an aspect. These changes can

be for example a removal of a pointcut, an addition

or deletion of a class, a method, an attribute. We

have counted a total of 61 structural changes, 22 at

the object code level and 39 at the aspect code level

(see annex 1). As shown in Figure 1, removing the

pointcut setter (in bold) would be a structural change

since it changes the structure of the appearance of

the aspect.

Figure 1: Structural change.

Figure 2: Non-structural change.

Non-structural changes will not alter the program

structure. They are within a method or a cup or an

advice. One example of no structural change is

removing a method call. In the example given in

Figure 2, there will be no structural impact at the

after-advice in which the call of addkeyListener

method is deleted (in bold in the example).

4.4 Concept of Certainty

The AOCIM model uses the notion of certainty, a

concept which also exists in the CIMJ model. The

notion of certainty allows basically mitigating the

information provided by the impact analysis using

the AOCIM model. To illustrate this concept, let us

consider two simple examples. As a first example,

let us consider the atomic change “deleting a

pointcut". This removal will impact all uses of this

pointcut. To compile the code after removing the

pointcut, we must also remove all its uses (advices

attached to it). In this case, we are talking about an

impact that is certain (certainty of the impact). Let

us take as a second example the atomic change "add

of joinpoint to a pointcut". Normally, if we add a

joinpoint to a pointcut, it is that we intend to use it.

Otherwise, it would be an unnecessary change, but

which nevertheless remains possible. So, we can

expect an impact related to the addition of the use of

this joinpoint. In this case, we are talking about an

impact that is uncertain (uncertainty of the impact).

The AOCIM model is based on several impact rules,

which make the distinction between the impacts that

are certain and the impacts that are uncertain. So, the

model makes a difference between what will be

impacted and what could possibly be impacted.

4.5 Impact Rules

A total of 41 impact rules have been defined. We

classified these impact rules based on the three

impact categories we mentioned above, which are

the impacts of the object part on the aspect part (17

rules), impacts occurring in the aspect code

following a change in the aspect code (23 rules), and

the impact of the aspect code on the object code (1

rule) (see annex 2). For the first two impact

categories, the targeted elements are located only at

the aspects level. The last impact category, aspect on

object impact, will target only elements in classes.

The rules presented in our model take into account

all possible impacts that are related to AOP. To a

better understanding of how the model we developed

works, we will take few examples.

4.6 Cases of Objet Code Impacts on

Aspects

When changes are made on the object code of an

aspect-oriented program, the impacts could occur in

the aspect code. Our model presents 17 rules to

identify these impacts.

pointcut setter(Point p):

all(void Point.set*(*)) &&

target(p);

void around(Point p): setter(p) {

String

propertyName=thisJoinPointStaticPart.getSignature().ge

tName().substring("set".length());

int oldX = p.getX();

int oldY = p.getY();

proceed(p);

if (propertyName.equals("X"))

{

firePropertyChange(p, propertyName, oldX,

p.getX());

} else {

firePropertyChange(p, propertyName, oldY,

p.getY());

}

after () returning (Player player): call

(Player+.new(..)) {

Enumeration elements = DISPLAYS.elements();

while (elements.hasMoreElements() ) {

Display display =

(Display)elements.nextElement();

display.addKeyListener(player);

}

}

ENASE 2017 - 12th International Conference on Evaluation of Novel Approaches to Software Engineering

148

4.6.1 Removing a Method

As a first example, we will take the removal of a

method in a class (void calculate()). The relationship

between aspects and classes will be done through

joinpoints. Following the deletion of a method in a

class, the joinpoint associated with this method is

automatically affected.

Figure 3: Class to aspect relationship.

Figure 3 shows how a method is referenced by a

joinpoint in an aspect. This joinpoint belongs to a

pointcut called "

pcCalculateCircle " (bold text).

And finally, an advice is linked to this pointcut in

order to execute a code. Thus, when the method in

question will be removed, first, there will be an

impact on the joinpoint, then on the pointcut

containing that joinpoint, and finally on the advice

related to that joinpoint. So, we have the following

impact rule:

Mr -> JPr + PCm + ADVm

"M" refers to a method, "JP" for a joinpoint, "PC"

for pointcut and finally "ADV" for advice. The letter

"r" means that the item is removed and the letter "m"

means that the item is modified. The rule is read as

follows: The suppression of a method (Mr) causes (-

>) the suppression of the referring joinpoint (JPr),

followed by the modification of the pointcut

containing the joinpoint (PCm) and finally the

modification of the advice associated to the pointcut

(ADVm).

4.6.2 Distinctive Feature of the Removal of a

Class

In an aspect, multiple joinpoint and several intertype

statements can be defined. These joinpoints and

intertype declarations can be linked to different

classes as shown in Figure 4.

In this example, the aspect "Logging Aspect" is

related to the "Client" and "Article" classes. By

removing the Client class, only the advice and the

method associated with the class Client (bold an

italic text in the figure) will be affected, not

forgetting the import of Client class (bold and

underlined text in Figure 4).

To increase the accuracy of the impact rule

concerning the suppression of a class, we added a

variable indicating the class concerned by the

deletion. This will result to focus only on the

elements of the aspect having a link with the deleted

class. Thus, we have the following impact rule:

Figure 4: Aspect related to several classes.

Impact rule: Cr(Class) -> JPr + [PCm || PCr] +

[ADVr|| ADVm] + I-TYr + DCLm + Mm + IMPr

Removing of class in brackets (Cr (Class)) implies

the removal of the joinpoints (JPr) potentially

followed by (represented by the brackets) the

suppression or the modification of the pointcut

public class Circle extends Figure

{

private double radius;

public void calculate()

{

circumference =2*3.14*radius;

}

}

public aspect AspectFigure

{

public pointcut pcCalculateCircle():

execution (void Circle.calculate());

before():pcCalculateCircle()

{

System.out.println("Circumference calculation");

}

}

import ca.uqtr.gl.entities.Article;

import ca.uqtr.gl.entities.Client;

public aspect LoggingAspect {

private Logger logger =

Logger.getLogger("trace");

pointcut addClientMethod():

call(void addClient(..));

pointcut addArticleMethod():

call(void addArticle(..));

after() returning() : addClientMethod() {

Object[] paramValues =

thisJoinPoint.getArgs();

String lastName = (String) paramValues[0];

String firstName = (String) paramValues[1];

Client client = new Client(lastName,

firstName);

logger.logp(Level.INFO, null, null, "\n "

+ "New CLIENT\n" + getLogClient(client)

);

}

private String getLogClient(Client c) {

String log = "Full name: " + c.getFirstName()

+ " " + c.getLastName();

return log;

}

after() returning() : addArticleMethod() {

Object[] paramValues =

thisJoinPoint.getArgs();

Article a = new Article();

a.setCode((String) paramValues[0]);

a.setDescription((String) paramValues[1]);

logger.logp(Level.INFO, null, null, "\n "+

"New ARTICLE\n"+ getLogArticle(a));

}

private String getLogArticle(Article a) {

il "d" d()"

A Change Impact Analysis Model for Aspect Oriented Programs

149

7



([PCm || PCr]). Then, the possible removal or

modification of an advice ([ADVr ||ADVm]), the

removal of inter-type declarations (I-TYr), and the

modification of the declarations (DCLm). Finally,

we have the modification of the methods using the

class (Mm) and the suppression of import of the

class in question in the aspect (IMPr

Applying this impact rule to our example, the

advice and the method using the Client class are well

indicated by the impact rule and the import will be

also deleted.

4.7 Cases of Aspect Impacts to Aspect

Code

Aspects include various elements such as advices

and pointcuts, but also attributes and methods. In

addition, several aspects are interlinked through

inheritance. Our model allows knowing which parts

of the aspect will be impacted after an element of the

aspect is changed. Our model presents 23 rules for

this category of impacts.

4.7.1 Removing a Pointcut

Deleting a pointcut will give the following impact

rule:

PCr -> PJr + ADVr + PCm(L) + PCr(H) +

PJr(H) + ADVr(H)

Removing a pointcut (PCr) automatically leads to

the suppression of joinpoints (PJR) and the removal

of the advices attached to them (ADr). Also,

pointcuts referencing the deleted pointcut will be

modified (PCm (L)). All pointcuts redefining the

deleted pointcut in a child aspect will be also deleted

(PCr (H)) as well as joinpoints and advices of this

child aspect (PJr(H) + ADVr(H)).

In this impact rule, the "L" indicates that the

change is made at the aspect, that is to say locally.

Meanwhile, the "H" indicates that impacts occur in

aspect inheriting from the aspect where the

modification has been made.

As shown in Figure 5, pointcut "xSet" (in bold in

Figure 5) is related to an "after" advice and is also

referenced by another pointcut, the pointcut "Set"

(underlined and bold in Fugure 5). When we remove

pointcut xSet, the advice related to it is no longer

useful, so we can remove it. Also, in the pointcut

Set, an impact will occur because we have to remove

the reference to that pointcut xSet.

Before removal of pointcut

After removal of pointcut

Figure 5: Example of impact rule: removal of pointcut.

4.7.2 Deleting a Method in an Aspect

Modification or deletion of a method in the aspect

code will impact the elements using this method in

this aspect, but also the child aspects. So we have

the impact rule:

Mr -> ADVm + Mm(L) + Mm(H)

The removal of a method (Mr) will cause the

modification of advices using this method (ADVm).

There will also be an impact on the methods using

the method deleted not only locally (Mm (L)) but

also at the level of child aspects of that modified

aspect (Mm

(H)).

Figure 6 shows an example of removing a method in

an aspect. After removing the loggedAllCatalogues

method (bold text in the figure), the advices using

the method (italic and underlined text in the figure)

will be impacted.

public aspect Intro

{

pointcut xSet():

set(int Point.x);

after(): xSet()

{

System.out.println("Attribute X modified");

}

pointcut ySet():

set(int Point.y);

pointcut Set():

xSet()||

ySet();

after(): Set()

{

System.out.println("X and Y modified");

}

public

spect Intro

{

pointcut xSet():

set(int Point.x);

after(): xSet()

{

System.out.println("Attribute X modified");

}

pointcut ySet():

set(int Point.y);

pointcut Set():

xSet()||

ySet();

after(): Set()

{

System.out.println("X and Y modified ");

}

}

ENASE 2017 - 12th International Conference on Evaluation of Novel Approaches to Software Engineering

150

Figure 6: Example of an aspect impact on object code.

4.8 Cases of Aspect Impacts on Object

Code

In the relationship between object classes and

aspects, aspects depend on object classes. In

addition, adding an aspect does not affect the object

code in a static point of view (before weaving).

Thus, any modification, addition or deletion of

joinpoint, pointcut or advice in an aspect will have

no impact on the object code which that aspect is

attached to.

However, there will be an impact of the aspect

code on the object code at the intertype declaration

level. Indeed, any declaration inserted into the aspect

code can be used in the object code. Thus, any

modification or deletion of these intertype

statements will affect the object code. Therefore, one

only rule was developed for this type of impact:

I-TYr | I-TYm-> Mm

Any deletion or modification of an intertype

declaration will result to impacts on the object code

methods (Mm) where intertype declaration is

invoked.

Figure 7 shows that in the aspect

"Aspect_Limousine", an attribute is introduced in

the "Drivers" class with an intertype declaration

(bold text). This attribute appears in the two methods

of the "Drivers" class. If we delete this attribute in

the aspect, the reference to it in both methods will no

longer exist, causing an impact in those methods.

We will then have to modify the code of the

methods to keep the code errorless.

Figure 7: Example of impact from aspect code to object

code.

4.9 Cascading Analysis

Our model is able to perform a cascading analysis.

Thus, when a change is made, we can see the

consequence of this modification on the rest of the

program. Cascading analysis means change impact

analysis of impacts (Badri et al., 2015). This is the

ripple effect of a change made on the rest of the

program. Using the cascading analysis, programmers

will have a good idea on the ripple effect following a

change. We will take an example to illustrate this

type of analysis.

In Figure 8, the "BoundPoint" aspect contains an

intertype declaration that introduces in "Point" class

an attribute named "support" of type

"PropertyChangeSupport" (bold text in Figure 8).

Plus, there is a pointcut named "setter" (italic

underlined text in Figure 8) related to that "Point"

class. If the "Point" class is deleted, there will be

direct impacts on the "BoundPoint" aspect as the

pointcut "setter" and the intertype declaration

pointcut loggedDelete(Object elem) :

call(*Catalogue*.delete*(..)) &&

args(elem)&&!withincode(* *Test.*(..));

after(Object elem) : loggedDelete(elem)

{

String msg = "Element deleted";

loggedAllCatalogue(msg, elem,thisJoinPoint);

}

private void loggedAllCatalogue(String

msgLog,Object elem,JoinPoint thisjoinpoint)

{

if(elem instanceof Client)

{

elem = (Client)elem;

}

else if(elem instanceof Article)

{

elem = (Article)elem;

}

msgLog = elem.getClass().getName().toString())

+ “ ” + elem.toString();

logger.info("\n\t"+msgLog);

}

public aspect Aspect_Limousine

{

int Drivers.iNbMaxRun = 100;

public pointcut pcNewRun():

initialization(Run.new(String, int,

Limousine));

after(): pcNewRun() {

System.out.println("New run created");

}

public class Drivers {

private Run aRun[];

private int iNbRun, iYearOfHiring;

private String sLastName;

private String sFirstName;

private String sAddress;

private boolean bAvailable;

public Drivers(int yearOfHiring, String lastName,

String firstName, String address)

{

iNbRun = -1;

iYearOfHiring = yearOfHiring;

sLastName = lastName;

sFirstName = firstName;

sAddress = address;

bAvailable = true;

aRun = new Run[iNbMaxRun];

}

public void addRun(Run r)

{

if((bAvailable == true) && (iNbRun < iNbMaxRun -

1))

{

bAvailable = false;

iNbRun ++;

aRun [iNbRun] = r;

System.out.println("Run created");

}

else

{

System.out.println("Impossible to add this

un");

A Change Impact Analysis Model for Aspect Oriented Programs

151

9



introducing the "support" attribute should be

removed from the code.

Figure 8: Example of cascading analysis.

However, the pointcut "setter" is linked with an

advice around (italic text in Figure 8) and the

attribute "support" is used in the

"firePropertyChange" method (bold, italic and

underlined text in Figure 8). Therefore, given that

the attribute "support" and the pointcut "setter" are

going to be removed due to the impact caused by the

deletion of class "Point", the "firePropertyChange"

method and the around advice are going to be also

impacted.

5 EMPIRICAL EVALUATION

In order to evaluate the ability of the AOCIM model

to accurately predict the impact of changes, we

conducted an empirical study. We have developed

different programs using AspectJ and used projects

developed by students in the Department of

mathematics and computer science (University of

Quebec at Trois-Rivières) (see Table 1).

Table 1: List of tested programs.

Projects # classes # aspects

Bean 3 1

Introduction 1 3

Observer 6 2

Spacewar 17 10

Telecom 10 3

TJP 1 1

Tracing (version 1) 5 3

Bank 2 1

Living beings 6 2

Figure 4 2

Matrix handling 3 1

Limousine 5 1

QuickSort 2 1

Stack 2 1

Soft. Eng. project 1 49 3

Store management 58 2

Soft. Eng. project 2 45 3

TOTAL 219 40

For some programs, we added a second aspect

that inherits from another. Also, we used the

programs contained in the file of the supplied

examples provided with the AspectJ compiler to

achieve our tests. In order to measure objectively the

performance of the model, we used in this study two

traditional measures: precision and recall. We

considered the following types of changes: removal

of class or aspect - rename of classes, aspects,

methods and attributes - addition, modification and

removal of methods, attributes - modification of

pointcuts and removal of inheritance link. For each

change, we introduced in a program, we observed

the consequences.

5.1 Metrics

We used two well-known measures to evaluate the

quality of the prediction of the impact analysis

model: precision and recall. Impact analysis may

have some false positives (elements in the impact set

which aren’t really impacted) and false negatives

(elements really impacted which aren’t identified in

the impact analysis) (Li et al., 2012). During the

evaluation, we obtained three types of results: the

number of actual impacts due to a given change, the

number of impacts predicted by the model and the

number of impacts correctly predicted by the model.

The recall, which is an inverse measure of false

negatives, is the ability of the model to predict all

real impacts (% of actual impacts). This allows

assessing whether the rules of the impact model

aspect BoundPoint

{

private PropertyChangeSupport Point.support = new

PropertyChangeSupport(this);

public void

Point.addPropertyChangeListener(PropertyChangeList

ener listener)

{

support.addPropertyChangeListener(listener);

}

pointcut setter(Point p): call(void Point.set*(*))

&& target(p);

void around(Point p): setter(p) {

String propertyName =

thisJoinPointStaticPart.getSignature().getName

().substring("set".length());

int oldX = p.getX();

int oldY = p.getY();

proceed(p);

if (propertyName.equals("X"))

{

FirePropertyChange (p, propertyName, oldX,

p.getX());

}

else

{

FirePropertyChange (p, propertyName, oldY,

p.getY());

}

void firePropertyChange(Point p,String

property,double oldval, double newval)

{

p.support.firePropertyChange(property, new

Double(oldval), new Double(newval)) ;

}

}

ENASE 2017 - 12th International Conference on Evaluation of Novel Approaches to Software Engineering

152

predict all real impacts. The precision, which is an

inverse measure of false positives, is the ability of

the model to predict correctly the impacts (% of

predicted impacts corresponding to reality). This

indicates whether the model is accurate enough to

predict only the real impacts and also validate the

recall. If it is too high than the precision, this means

that the model predicts too many impacts. A perfect

model would be a model having a recall of 100%

and a precision of 100 %. The model succeeds in

this case only to predict the actual impacts and to

predict them all.

5.2 Evaluation Procedure

To conduct our experiments, we have made changes

to the used aspect-oriented programs. These changes

were made both in the object code and in the aspect

code. For example, we deleted classes, renamed

methods, changed the scope of an attribute or

modified pointcuts. These changes are made without

considering the impact given by the rules of the

proposed model. Once these changes were made, we

identified the different impacts that occurred. To do

so, we went through the program and searched every

part of the code related to the change we made.

Some impacts were highlighted by the IDE we used

(Eclipse), and others were about relationships (i.e.

inheritance, association). This step allowed us to

determine the number of real impacts on each

modified program. Then, we toke each of the

changes and identify the impacts that our model has

predicted. Finally, a comparison of the results was

carried out after the previous phases. We were then

able to determine: (1) the ratio of impacts predicted

by the model which actually occurred compared to

observed impacts (precision), and (2) the percentage

of real impacts predicted by the model compared to

the set of predicted impacts by the model in relation

with the change made (recall).

5.3 Results and Discussion

Table 2 presents a summary of the results obtained

during the experiments. As it can be seen, we have

an accuracy of 98% and a recall of 86.6%. Our

impact model is able to detect almost all the impacts

that will occur following a change in the aspect-

oriented program. For Object impacts to Aspect, we

have an accuracy of 100%. However, for Aspect

impacts to Aspect, we have an accuracy of 95%.

Impacts from aspects to object code present a recall

and an accuracy of 100%. This is explained by the

fact that there is only one impact rule for this impact

category, and only methods will be impacted after

changing an intertype declaration. Recalls of 93%

and 77.8% respectively for the impacts from object

to aspect and aspect to aspect are due to the fact that,

in certain situations, the model can identify more

impacts than those observed after a change because

of the uncertain impacts. Indeed, it may happen that

the impacts are not reported (following an effective

change) because they do not affect the program run.

It will be left up to the programmer's discretion to

consider these impacts in order to keep consistency

in the maintenance of the current program.

Table 2: Summary of the results.

Impacts

predicted

by the

model

Observed

Impacts

Real

impacts

predicted

by the

model

Precision Recall

Object

impacts

to aspect

37 37 100% 93%

Aspect

impacts

to aspect

22 21 95% 77,8%

Aspect

impacts

to object

3 3 3 100% 100,0%

TOTAL

67 59 58 98% 86,6%

5.4 Limits of the Model

The model we propose is a static impact analysis

model and focuses only on the syntactic aspects of

the code. Some semantic aspects of the code are

unfortunately not taken into account in the current

version of the model. An example of semantic

aspects, which have not been considered in our

model, is the use of wildcards and pointcuts

designators (Kiczales et al., 2001) in the aspect

code. In fact, those wildcards can refer to any class

or method in the Java code and pointcuts designators

determine the moment the joinpoints are reached at

runtime (call, execution, etc.). However, if a class or

a method is modified, the wildcard is not impacted

from a syntactic point of view as the program is still

consistent and able to run. But from a semantic point

of view and during execution of the program, there

may be an impact as the join point related to the

change is never reached.

6 CONCLUSION AND FUTURE

WORK

In this paper, we proposed a predictive change

impact analysis model for aspect-oriented programs.

Three change impact categories were identified:

A Change Impact Analysis Model for Aspect Oriented Programs

153

11



object code impacts on aspect code, aspect code

impacts on aspect code and aspect code impacts on

object code. The model includes 41 impact rules.

Experiments were conducted on several aspect-

oriented programs in order to show the effectiveness

of the model. Two prediction quality measures were

used: precision and recall. The results show that our

model is quite effective in predicting impacts.

Although some rules indicate uncertain impacts,

they still allow the programmer to have a good idea

on the changes to be done to keep the program

consistent. Combined with the CIMJ model, which

we developed in our previous work for Java

programs, our impact analysis model could be very

useful during program maintenance stages.

Moreover, the proposed approach allows a better

support for cascading impact analysis. Furthermore,

the approach satisfies five of the seven properties of

the Framework proposed by Li et al. (2012)

characterizing impact analysis techniques. These

properties are: object- the change set and the source

analysis, impact set- the impacted elements of the

system, type of analysis- static analysis or dynamic

analysis, intermediate representation, language

support- support various programming paradigms,

tool support, and empirical evaluation. Our work

could also help solving the pointcut fragility

problem mentioned in some studies in the literature.

The work presented in this paper should be

viewed as exploratory rather than conclusive. The

model we proposed has some limitations that will be

addressed in our future work. In addition, the study

should be replicated on many other aspect-oriented

programs in order to draw more general conclusions.

As future work, we plan: (1) to address the

limitations of the model, particularly by taking into

account semantic relationships in aspect-oriented

programs, (2) to develop a tool supporting the

proposed technique, which should allow us to

experiment the model on large aspect-oriented

programs, (3) to improve the accuracy of our model,

and (4) to perform other tests on many other aspect-

oriented applications in order to have more general

conclusions.

REFERENCES

Abdi M.K, Lounis H. and Sahraoui H., 2007: Analyse et

prédiction de l’impact de changements dans un

système à objets : Approche probabiliste. In

proceedings of LMO 2009.

Abran A., April A., Dumke R., 2004: SMCMM Model to

Evaluate and Improve the Quality of the Software

Maintenance Process, 8th European Conference on

Software Maintenance and Reengineering.

Acharya M., Robinson B., 2012: Practical Change Impact

Analysis Based on Static Program Slicing for

Industrial Software Systems, SIGSOFT’12/FSE-20,

ACM, November 11–16, Cary, NC, USA.

Ackermann C., Lindvall M., 2006: Understanding Change

Requests to Predict Software Impact, 30th Annual

IEEE/NASA Software Engineering Workshop, pages

66 - 75, Columbia, MD, USA.

Aggarwal K.K., Singh Y. and Chhabra J.K., 2002: An

integrated measure of software maintainability,

Proceedings of the 2002 Reliability and

Maintainability Symposium, pp. 235-241.

Ali H.O., Abd Rozan M.Z.A., Sharif A.M., 2012:

Identifying Challenges of Change Impact analysis for

software projects, International Conference on

Innovation Management and Technology Research,

pages 407-411.

Arnold R.S. and Bohner S.A., 1993: Impact analysis -

towards a framework for comparison, In Proceedings

of the International Conference on Software

maintenance (CSM '93), pp. 292-301, Canada.

Badri L., Badri M., and St-Yves D., 2005: Supporting

Predictive Change Impact Analysis: A Control Call

Graph Based Technique, In Proceedings of the 12th

Asia-Pacific Software Engineering Conference

(Apsec'05) - APSEC. IEEE Computer Society, 167-

175.

Badri L., Badri M., Joly N., 2015: Towards a Change

Impact Analysis Model for Java Programs: An

Empirical Evaluation, Journal of Software, vol. 10, no.

4, pp. 441-453.

Baggen R., Correia J. P., Schill K and Visser J, 2011:

Standardized code quality benchmarking for

improving software maintainability, Software Quality

Barros S., Bodhun Th., Escudie A., and Voidrot J.P.,

1995: Supporting Impact Analysis: A semi-automated

technique and associated tool, Proceedings of the 1995

IEEE Conference on Software Maintenance, pp. 42-

51, Piscataway, NJ.

Bennett K. and Rajlich V., 2000: Software maintenance

and evolution: a roadmap, in Proceedings of the

Conference on the Future of Software Engineering, pp.

73–87, ACM, New York, NY, USA.

Bernardi M. L., Di Lucca G. A., Ceccato M., 2009:

Workshop on Maintenance of Aspect Oriented

Systems, 13th European Conference on Software

Maintenance Reengineering, pages 273-274,

Kaiserslautern, Germany.

Bernardi M.L., Di Lucca G.A, 2007: An Interprocedural

Aspect Control Flow Graph to Support the

Maintenance of Aspect Oriented Systems. IEEE

International Conference on Software Maintenance,

pages 435-444, Paris, France.

Bohner S.A. and Arnold R., 1996: Software Change

Impact Analysis, IEEE Computer Society Press, Los

Alamitos, CA, USA.

ENASE 2017 - 12th International Conference on Evaluation of Novel Approaches to Software Engineering

154

Briand L.C., Wust J., and Lounis H., 1999: Using coupling

measurement for impact analysis in object-oriented

systems, Proceedings of the IEEE International

Conference on Software Maintenance (ICSM '99), pp.

475 – 482.

Burrows R., Ferrari F. C., Lemos O. A.L., Garcia A.,

Taïani F., 2010: The Impact of Coupling on the Fault-

Proneness of Aspect-Oriented Programs: An Empirical

Study, IEEE 21st International Symposium on

Software Reliability Engineering, pages 329-338, San

Jose, CA, USA.

Chaumun M. A., Kabaili H, Keller R. K., Lustman F. and

Saint-Denis G., 2000: Design properties and object-

oriented software changeability, in Proceedings of the

Fourth Euromicro Working Conference on Software

Maintenance and Reengineering, pages 45-54, Zurich,

Switzerland, IEEE.

Chaumun M. A., Kabaili H., Keller R. K. and Lustman F.,

2002: A change impact model for changeability

assessment in object-oriented software systems,

Science of Computer Programming, Volume 45,

Issues 2-3, pp. 155-174.

Cho H., Gray J., Cai Y, Wong S. and Xie T., 2011: Model-

Driven Impact Analysis of Software Product Lines, in

Model-Driven Domain Analysis and Software

Development: Architectures and Functions, Chapter

13, IGI Global.

Déhoulé F., 2014: Analyse de l’impact dans les systèmes

orientés aspect (SOA) : Élaboration d’un modèle

d’impact, M. Sc., Université du Québec à Trois-

Rivières, Québec, Canada.

Dong Z., 2011: Aspect Oriented Programming

Technology And The Strategy Of Its Implementation,

International Conference on Intelligence Science and

Information Engineering, pages 457-460, Wuhan,

Chine.

Ebert C., and De Man, J., 2005: Requirements uncertainty:

Influencing factors and concrete improvements,

Proceedings of the 27th International Conference on

Software Engineering.

Gethers M., Poshyvanyk D., 2010: Using relational topic

models to capture coupling among classes in object-

oriented software systems, In Proceedings of the 2010

IEEE International Conference on Software

Maintenance, pp. 1–10.

Gradecki J. D., Lesiecki N., 2003: Mastering AspectJ,

Aspect Oriented Programming in Java. Indianapolis,

Indiana, USA.

Grubb P., Takang A. A., 2003: Software Maintenance:

Concepts and Practice, Publisher: World Scientific

Publishing Company. ISBN: 9812384251.

Harrold M. J., Jones J. A., Li T. et al., 2001: Regression

test selection for Java software, in Proceedings of the

Conference on Object-Oriented Programming,

Systems, Languages and Applications (OOPSLA ’01).

Hunt B., Turner B., McRitchie K., 2008: Software

Maintenance Implications on Cost and Schedule,

Aerospace Conference, Big Sky, MT.

Joly N., 2010: Towards a Change Impact Analysis Model

for Java Programs: An Empirical Evaluation, Mémoire

de maîtrise, Université du Québec à Trois-Rivières,

Canada.

Kabaili H, Keller R. K. and Lustman F., 2001: A change

impact model encompassing ripple effect and

regression testing, in Proceedings of the Fifth

International Workshop on Quantitative Approaches in

Object-Oriented Software Engineering, pages 25-33,

Budapest, Hungary, June.

Kiczales G., Hilsdale E., Hugunin J., Kersten M., Palm J.,

and Griswold W. G., 2001: An Overview of AspectJ,

In J. Lindskov Knudsen, editor, European Conference

on Object-oriented Programming, volume 2072 of

Lecture Notes in Computer Science, pages 327–353.

Springer.

Kilpinen M., 2008: The Emergence of Change at the

Systems Engineering and Software Design Interface –

An Investigation of Impact Analysis, PhD thesis,

Cambridge University, Engineering Department.

Kumar A., Kumar R., Grover P.S., 2007: An Evaluation of

Maintainability of Aspect-Oriented Systems: a

Practical Approach, International Journal of Computer

Science and Security (IJCSS), Pages - 1 - 9, Kuala

Lumpur, Malaysia.

Kung D. C., Gao J., Hsia P., Lin J., and Toyoshima Y.,

1995: Class firewall, test order, and regression testing

of object-oriented programs, Journal of Object-

Oriented Programming, vol. 8, no. 2, pp. 51–65.

Law J., Rothermel G., 2003: Whole Program Path-Based

Dynamic Impact Analysis, Proc. of the International

Conference on Software Engineering, pp. 308-318.

Lee M, Offutt A. J. and Alexander R. T., 2000:

Algorithmic Analysis of the Impacts of Changes to

Object-Oriented Software, 34th International

Conference on Technology of Object-Oriented

Languages and Systems (TOOLS USA '00), pages 61-

70, Santa Barbara, CA, August.

Lehman M. M., 1980: On Understanding Laws, Evolution,

and Conservation in the Large-Program Life Cycle,

Journal of Systems and Software, vol. 1, no. 3.

Lehman M. M., Ramil J. F., Wernick P. D., Perry P. E.,

and Turski W. M., 1997: Metrics and Laws of

Software Evolution – The Nineties View, Proceedings

of the 4th International Software Metrics Symposium,

pp. 20-32.

Lehnert S., 2011: A Taxonomy for Software Change

Impact Analysis, IWPSE-EVOL’11, September 5–6,

Szeged, Hungary, ACM.

Li W. and Henry S., 1995: Maintenance support for

object-oriented programs, The Journal of Software

Maintenance, Research and Practice, 7(2):131-147,

March-April.

Li B., Sun X., Leung H. and Zhang S., 2012: A survey of

code-based change impact analysis techniques,

Software testing, Verification and Reliability; 23:613-

646, Wiley Online Library.

Li L. and Offutt A. J., 1996: Algorithmic analysis of the

impact of changes to object-oriented software,

Proceedings of the IEEE International Conference on

Software Maintenance, CA, USA, pp 171-184.

A Change Impact Analysis Model for Aspect Oriented Programs

155

13



Mens T., Fernandez-Ramil J., and Degrandsart S., 2008:

The Evolution of Eclipse, Proceedings of the IEEE

International Conference on Software Maintenance

(ICSM), pp. 386-395.

Orso A., Apiwattanapong T., and Harrold M.J., 2003:

Leveraging field data for impact analysis and

regression testing, Proceedings of the European

Software Engineering Conference, and ACM

SIGSOFT Symposium on the foundations of software

Engineering (ESEC/FSE’03), Helsinki, Finland.

Orso A., Apiwattanapong T., J. Law, Rothermel G., and

Harrold M.J., 2004: An Empirical Comparison of

Dynamic Impact Analysis Algorithms, Proceedings of

the International Conference on Software Engineering

(ICSE’04), pp. 491-500, Edinburg, Scotland.

Petrenko M., Rajlich V., 2009: Variable granularity for

improving precision of impact analysis, Proceedings

of the International Conference on Program

Comprehension, pp. 10–19.

Przybylek A., 2011: Impact of aspect-oriented

programming on software modularity, 15th European

Conference on Software Maintenance and

Reengineering, pages 369-372, Oldenbourg,

Allemagne, 1-4.

Ren X., Shah F., Tip F., Ryder B. G. and Chesley O.,

2004: Chianti: A tool for change Impact analysis of

Java Programs, OOPSLA’04. Proceedings of the 19th

annual ACM SIGPLAN Conference on Object-

Oriented Programming, Systems, Languages, and

Applications.

Riaz M., Mendes E. and Tempero E., 2009: A systematic

review of software maintainability prediction and

metrics, Proceedings of the 2009 3rd International

Symposium on Empirical Software Engineering and

Measurement.

Rothermel G. and Harrold M. J., 1996: Analyzing

regression test selection techniques, IEEE

Transactions on Software Engineering, vol. 22, no. 8,

pp. 529–551.

Rothermel G. and Harrold M. J., 1997: A safe, efficient

regression test selection technique, ACM Transactions

on Software Engineering and Methodology, vol. 6, no.

Ryder B. G. and Tip F., 2001: Change Impact Analysis for

object-Oriented Programs. In ACM SIGPLAN-

SIGSOFT.

Sabbah D., 2004: From Promise to Reality, Proceedings of

the 3rd international conference on Aspect-oriented

software development (AOSD’04).

Shinomi I., Tamai T., 2005: Impact Analysis of Weaving

in Aspect-Oriented Programming, Proceedings of the

21st IEEE International Conference on Software

Maintenance, pages 357-660.

Störzer M., 2007: Impact Analysis for AspectJ, A Critical

Analysis and Tool-Based Approach to AOP,

Dissertation, Passau.

St-Yves D., 2007: Dépendances et gestion des

modifications dans les systèmes orientés objet:

utilisation des graphes de contrôle, Thèse de maîtrise,

Université du Québec à Trois-Rivières, Canada.

Sun X., Leung H., Li B., Li B., 2014: Change impact

analysis and changeability assessment for change

proposal: An empirical study, Journal of Systems and

Software, 96, pp. 51-60, Elsevier.

Sun X., Li B., Tao C., Wen W., Zhang S., 2010: Change

Impact Analysis Based on a Taxonomy of Change

Types, 2010 IEEE 34th Annual Computer Software

and Applications Conference, pages 373-382, Seoul.

Yau S.S., Collofello J. S., 1980: Some Stability Measures

for software maintenance. IEEE Transactions on

Software Engineering, 6(6): pp. 545-552.

Zhang S, Gu Z, Lin Y, Zhao J., 2008: Change Impact

Analysis for AspectJ Programs, IEEE International

Conference on Software Maintenance, pages 87-96,

Beijing.

Zhao J., 2002: Change Impact Analysis for Aspect-

Oriented Software Evolution, Proceedings of the

International Workshop on Principles of Software

Evolution, New York, NY, USA.

Zhao J., 2004: Measuring Coupling in Aspect-Oriented

Systems, Information Processing Society of Japan

(IPSJ), pages 14-15, Japon.

Zhou X., Jiang Y., Wang H., 2011: Method on change

Impact Analysis for Object-oriented Program, 2011

Fourth International Conference on Intelligent

Network and Intelligent Systems, IEEE.

Zimmermann T., Zeller M.A., Weissgerber, P., Diehl, S.,

2005: Mining version histories to guide software

changes. IEEE Transactions on Software Engineering,

31 (6), pp. 429–445.

ANNEX 1: PARTIAL LIST OF

CHANGES (DÉHOULÉ, 2014).

Change Meaning

Aspect level

ASr Remove an aspect

ASnm Change name of an aspect

ASt

Type : abstract to non-abstract

ASha Inheritance : add

AShr Inheritance :remove

Asia Interface : add

Asir Interface : remove

IMPr Import : remove

Class level

Remove a class

Cnm Chan

e name of a class

Remove of inheritance

Remove of interface

Remove a metho

ENASE 2017 - 12th International Conference on Evaluation of Novel Approaches to Software Engineering

156

ANNEX 2: PARTIAL LIST OF

IMPACT RULES (DÉHOULÉ,

2014).

Change Impact rule

Cr Cr(Class) -> JPr + [PCm || PCr] + [ADVr ||

Cnm Cr -> JPr + [PCr] + [ADVr || ADVm] + I-

Chr Chr -> Mpm(L) + Mm(L) + JPm + PCm +

Cir Cir -> [Mr + JPr + PCr || PCm + ADVr ||

Mr Mr -> JPr + PCm + ADVm

Mnm Mnm -> JPm + PCm + ADVm

Mpa

Mpa | Mpm | Mpr -> JPpm + PCm +ADVm

Mpm

Mpr

Mtr

Mtrm -> JPm + PCm + ADVm

-> [JPm + PCm + ADVm]

| Mt

-> [JPm + PCm + ADVm]

Ar Ar -> JPr{dg} || JPr{mu} +PCm + ADVm

Anm

Anm -> JPm{dg} || JPm{mu} +PCm +

ADV

Atm Atm ->Mpm{mu} + Mtrm{ac} + JPm +

-> JPm + PCm + ADVm + Mm{AS}

| At

-> JPm{dg} || JPm{mu} +PCm +

ADVm

| At

-> JPm{dg} || JPm{mu} +PCm +

ADVm

Nrtc Nrtc -> JPr + PCr + ADVr

A Change Impact Analysis Model for Aspect Oriented Programs

157
