Natural Language Processing for Risk Identification in Business

Process Repositories

Avi Wasser

and Maya Lincoln

University of Haifa, Mount Carmel, Haifa, Israel

ProcessGene Ltd, MATAM Science Park, Haifa, Israel

Keywords: Risk Management, Risk Design, Business Process Repositories, Business Process Management,

Natural Language Processing (NLP), ProcessGene.

Abstract: In recent years, researchers have become increasingly interested in developing methods and tools for

automating the design of governance, risk and compliance (GRC) models. This work suggests a method for

machine-assisted identification and design of new risks, based on business logic that is extracted from real-

life process repositories using a linguistic analysis of the operational similarity between process conducts.

The suggested method can assist process analysts, audit executives and risk managers in identifying new

organizational risks while making use of knowledge that is encoded in existing process repositories. The

suggested framework was tested on the ProcessGene process repository, showing our approach to be

effective in enabling the identification and design of new risks within real-life business process models.

1 INTRODUCTION

With the increase of regulatory requirements on one

hand, and the attempts to optimize business

outcomes on the other, organizations are required to

invest more efforts in identifying, managing and

mitigating risks. Executive officers are specifically

required to demonstrate effective risk management

practices, and to ensure corporate transparency and

visibility into the business. The risk management

process is continuous, and needs to be closely

monitored. As management is personally responsible

for monitoring risk levels, this responsibility

requires significant management attention and

allocation of time and effort.

Risk modelling is considered a manual, labour

intensive task, whose outcome depends on personal

domain expertise with errors or inconsistencies that

lead to bad risk prevention and high risk related

costs (Muller et al, 2007). Hence, automating the

identification and design of risks does not only save

design time but also supports non-expert designers

in defining new risks within business process

models.

While some works focus on the design of new

process models, mostly for a specific functional

domain, none refers to new risk definition and

identification within process repositories.

This work aims to suggest a generic method for

designing risks within business process models

related to any functional domain. The suggested

method guides business analysts and risk managers

that opt to identify and design new risks, by

suggesting new risks within a process repository.

The business logic for such suggestions is extracted

from process repositories through the analysis of

existing business process activities and their related

risks. We show through an empirical evaluation that

by utilizing operational process similarity analysis, it

is possible to effectively support the design of new

risks within process models.

The work proposes an innovative method for

assisting designers in designing brand new risks

while making use of knowledge that is encoded in

the design of existing, related process models. Our

work presents the following innovations: (a) it

provides generic support to the design of new risks

within existing process repositories; (b) it extends

the PDC model (Lincoln et al, 2007) to support the

representation of risks; and (c) it enables the design

of new risks based on extraction of business logic

from business process repositories.

The rest of the paper is organized as follows: we

present related work in Section 2, positioning our

608

Wasser, A. and Lincoln, M.

Natural Language Processing for Risk Identiﬁcation in Business Process Repositories.

In Proceedings of the 18th International Conference on Enterprise Information Systems (ICEIS 2016) - Volume 2, pages 608-613

ISBN: 978-989-758-187-8

work with respect to previous research. In Section 3

we present an extended model for representing

process risks based on the process descriptor notion,

presented first in the work of Lincoln et al (2007),

and extended in this work for the field of new risk

design. Then, we describe our method for designing

new risks in Section 4. Section 5 introduces our

empirical analysis. We conclude in Section 6.

2 RELATED WORK

Most of the efforts invested in developing methods

and tools for designing process models focus on

supporting the design of alternative process steps

within existing process models. Such a method is

presented by Schonenberg et al (2008) aiming to

provide next-activity suggestions during execution

based on historical executions and optimization

goals. Similarly, Gschwind et al (2008) suggest an

approach for helping business users in understanding

the context and consequences of applying pre-

defined patterns during a new process design.

Few works were devoted to the design of brand

new process models within specific and predefined

domains. The work presented by Muller et al (2007)

utilizes the information about a product and its

structure for modeling large process structures.

Reijers et al (2003) present a method, for designing

new manufacturing related processes based on

product specification and required design criteria.

Works in the domain of risk design also focus on

specific risk domains, such as credit risks (Giesecke,

2004; Galindo and Tamayo, 2000), inventory

management risks (Michalski, 2009), and financial

risks (Barbaro and Bagajewicz, 2004). Our work

offers a generic design method that is domain

agnostic and does not rely on product design data. In

addition our work assists in the design of risks rather

than process activities.

A requirement for the support of business

process design involves the performance of a

structured reuse of existing building blocks and pre-

defined patterns that provide context and sequences

(Gschwind et al, 2008). The identification and

choice of relevant process components are widely

based on the analysis of linguistic components -

actions and objects that describe business activities.

Most existing languages for business process

modeling and implementation are activity-centric,

representing processes as a set of activities

connected by control-flow elements indicating the

order of activity execution (Wahler and Kuster,

2008). In recent years, an alternative approach has

been proposed, which is based on objects (or

artifacts/entities/documents) as a central component

for business process modeling and implementation.

Our work supports this approach and focuses on

objects for the purpose of risk identification and

modeling.

Finally, the work of Lincoln et al (2007) presents

the concept of business process descriptor that

decomposes process names into objects, actions and

qualifiers. In this work we take this model a

significant step forward by extending the framework

to support also the representation of risks using a

new taxonomy - the “risk descriptor.”

3 THE DESCRIPTOR MODEL

In the Process Descriptor Catalog model (“PDC”)

(Lincoln et al, 2007) each activity is composed of

one action, one object that the action acts upon, and

possibly one or more action and object qualifiers, as

illustrated in Figure 1, using UML relationship

symbols. Qualifiers provide an additional

description to actions and objects. In particular, a

qualifier of an object is roughly related to an object

state. State-of the art Natural Language Processing

(NLP) systems, e.g., the “Stanford Parser” (Stanford

parser, 2016), can be used to automatically

decompose process and activity names into

process/activity descriptors.

Figure 1: The activity decomposition model.

For example, the activity “Manually Calibrate

the Color Machine” generates an activity descriptor

containing the action “calibrate, the action qualifier

“manually, the object “machine and the object

qualifier “color.” In short, this descriptor can be

represented as the tuple

(calibrate,manually,machine,color) - where the

action and its qualifier are followed by the object

and its qualifier. In general, such tuple can be

represented as (A,AQ,O,OQ), where A represents

the action, AQ represents the action qualifier, O

represents the object and OQ represents the object

qualifier.

Natural Language Processing for Risk Identiﬁcation in Business Process Repositories

609

In this work we extend the descriptor model for

representing risk names. To do that, we have

analysed 842 real-life risk names from the

ProcessGene repository (ProcessGene, 2016), e.g.

“employee has criminal records”, “corrupt backup

tapes”, “signature forgery”. We found out that in

98.2% of the cases risks are linguistically phrased as

states (an object with 0-n qualifiers) without any

action and action qualifiers. We also found out that

it was possible to convert the other 1.8% of the risk

names into a state format (e.g. the risk “Data

Restoration will Fail” can be converted into the

state: “Data Restoration Failure”). Therefore, risk

names can be represented by a partial (degenerate)

descriptor model, with null values for the action

related constructs. For example, the risk “Backup

Restoration Failure” can be represented by a

descriptor containing a NULL action, NULL action

qualifiers, the object “backup and the object

qualifier “restoration failure. In short, the risk's name

can be represented by the tuple (NULL, NULL,

backup, restoration failure).

4 THE RISK IDENTIFIER

METHOD

The Risk Identifier method analyses an underlying

process repository and suggests the addition of

missing risks.

Figure 2: The risk identifier mechanism.

The risk identifier is illustrated in Figure 2. The

identification process starts when a user (e.g. a risk

manager or a process designer) seeks to reveal

additional risks that are not represented within a

process repository. In response, the risk identifier

searches the process repository and retrieves

operationally similar processes (phase #1, see

elaboration in Section 4.1). It then compares the

risks at each process model and identifies potentially

missing ones - meaning risks that exist in one

process model (namely “reference risks”) and are

missing at a similar process model (namely, an

“examined process model”) (phase #2). Based on the

examined process model content on one hand, and

the reference risk name on the other hand, the risk

identifier suggests a name for the new risk candidate

(phase #3, elaborated in Section 4.2).

Going back to the examined process model, and

prior to suggesting the new risk to the user, the risk

identifier verifies that the new risk candidate is not

already represented in the examined process model

(phase #4, Section 4.3). The new risk candidates are

then ranked according to their user acceptance

likelihood. This is done using a learning mechanism

that collects data regarding the user inputs in

previous risk identification procedures (phase #5,

Section 4.4). This results in an output of a ranked list

of new risk candidates that is presented to the user

(phase #6).

The user reviews the output option list and

selects the relevant risks that in her opinion should

be added to the process repository (phase #7). She

then modifies and adjusts the auto-generated risk

names (phase #8, Section 4.5). The risk identifier

analyses the user's selection and modifications and

adjusts his underlying learning mechanism for future

risk identification runs (phase #9).

4.1 Searching for Operationally

Similar Process Models

The goal of this phase is to find process models

within the process repository that are similar in

operation terms. Such processes achieve a different

business goal but are similar in the way (how) they

are conducted. Since risks refer to the modus

operandi facet of the process, it is assumed that such

similar processes will also share similar risks. This

assumption is validated and supported by

experiments in Section 5.

To perform such operation-based search we

apply the search method presented by Lincoln and

Gal (2011). As an example, the following process

models were found as operationally similar:

“Background check-up of a new employee

candidate” and “supplier assessment.” Although

these process models are not semantically similar,

their activity flow is similar. Note that a semantic-

based similarity search would not have found the

two example processes since they do not share

similar terminology but are rather similar in the way

they are executed. For a more profound discussion

1. Search for

operationally

similar process

models

Risk Identifier

2. Compare risks

and locate

potentially

missing ones

Risk Identifier

3. Suggest

new risk’s

name

Risk Identifier

4. Verify the

suggested risk is not

already represented

in the process model

Risk Identifier

7. Select

relevant risks

User

6. Output: a

ranked list

of new risk

suggestions

9. Learn from

user’s

selection and

adjustments

Risk Identifier

8. Modify and

adjust selected

risks

User

5. Rank new risk

suggestion according

to their acceptance

likelihood

Risk Identifier

ICEIS 2016 - 18th International Conference on Enterprise Information Systems

610

on operational vs. semantic process search see the

work of Lincoln and Gal (2011).

4.2 Suggesting a Name for the New

Risk Candidate

The goal of this phase is to construct an appropriate

name for the new risk (“nr”) candidate. To do this

the following procedure is detailed as follows.

1. Decompose the reference risk (“rr”) name into

a risk descriptor (see Section 3), represented as

(NULL,NULL,O

,OQ

2. Decompose the reference process (“rp”) name

into a process descriptor (see Section 3), represented

as (A

,AQ

,OQ

3. Decompose the examined process (“ep”) name

into a process descriptor (see Section 3), represented

as (A

,OQ

4. If O

then the new risk candidate name is:

(NULL,NULL,O

,OQ

5. Else: the new risk candidate name is:

(NULL,NULL,O

,OQ

Following the above example, the risk “Missing

data about the employee candidate” was located

within the process model of “Background check-up

of a new employee candidate.” As a consequence,

according to this phase, a new risk candidate was

offered to the “Supplier assessment” process,

named: “Missing data about the supplier.”

4.3 Redundancy Check-up

This phase aims at verifying that the new risk

candidate is not already represented as part of the

examined process model. To do that, it is required to

semantically compare between each of the risks

related to the examined process and the new risk

candidate's name.

4.4 Preparing a Set of Output Options

The input for this phase is a set of several new risk

candidates. In order to assist the user in reviewing

the list options, this phase aims at ranking the new

risk candidate list according to their user acceptance

likelihood. This is done by learning and analysing

the user's inputs in previous risk identification

procedures as follows.

At the end of each risk identification procedure

the user is required to select relevant risks and also

modify and adjust selected risks (phases #7 and #8

in Figure 2). These user actions from previous runs

influence the grade each new risk candidate receives

at the current run in the following way. First, each

risk candidate is labeled with an identical grade=1.

Then, the grade of each risk candidate is adjusted as

follows:

1. Penalty Due to Risk Content. This correction

aims to add a penalty to risks that are usually

removed, by increasing the risk candidate's grade

according to the number of times a risk with the

same name was marked as irrelevant in previous

runs. Similarly, the grade increases according to the

number of times a risk with the same name was

added to the repository in previous runs. Such

additions of the same risk can also indicate that this

risk was neglected in the original process repository.

2. Penalty Due to the Nature of the Examined

Process. This correction aims to take into account

the “safety” nature of the examined process. A

“safe” process is a process that the chance of adding

risks to it are low (it may consist risks but they are

already being fully handled by the process).

Therefore, the risk's grade is increased according to

the number of times a risk within the same examined

process model was marked as irrelevant in previous

runs. Similarly, the risk's grade is decreased

according to the number of times a risk within the

same examined process model was added in

previous runs.

3. Penalty Due to Inaccuracy. This correction

aims to take into account the expected accuracy of

the risk. Therefore, the grade will increase according

to the total number of changes the user made to the

descriptor of the same risk name in previous runs. A

change is considered as any replacement of an object

or an object qualifier name.

After calculating each of the new risk list

options, the risk identifier sorts the list in an

ascending order - from the most probable to the most

improbable in terms of the chances the user will

finally accept and add the risk to the process

repository.

4.5 Adjusting the Auto-generated Risk

Names

In case the user decides that the newly suggested

risk is relevant to the examined process, she re-

examines its name and optionally modifies one or

more of its risk descriptor components (object and/or

object qualifiers).

Natural Language Processing for Risk Identiﬁcation in Business Process Repositories

611

5 EXPERIMENTS

We now present an empirical evaluation of the

proposed method effectiveness. First, we present the

experimental setup and describe the data sets that

were used. Based on this setup we present the

implemented methodology. Finally, we present the

experiment results and provide an empirical analysis

of these results.

5.1 Data

We chose a set of 43 process models from the

ProcessGene repository that have at least one

operationally similar process. The selected process

models are part of different business categories (e.g.

manufacturing, procurement, human resource

management) and have a different number of risks.

5.2 Evaluation Methodology

To evaluate the suggested method we conducted 43

experiments. At each experiment, the risks of a

single process were removed from the database and

then reconstructed using the risk identifier method.

This “machine assisted reconstruction” enables us to

objectively measure the method's effectiveness. In

addition, a risk management expert was asked to

assess risks that were offered by the risk identifier

and did not belong originally to the process

repository.

5.3 Results and Analysis

Table 1 presents a summary of the experiment

results. On average, 24% risks from the ProcessGene

repository were missing from the generated risk lists

(see column #1). This means that 76% of the risks in

the repository were reconstructed successfully by the

risk identifier mechanism, showing a high level of

usefulness to the method.

Table 1: Experiment results.

Column # 1 2 3

Column

name

% of

missing

risks in the

generated

risk list

% of

redundant

risks in

the

generated

risk list

% of

generated

risks that are

not

represented

in the

ProcessGene

repository

Avg. 24% 9% 4%

In addition, on average, 9% of the risks

candidates were redundant - meaning they were not

relevant to the examined process (see column #2),

again, highlighting the level of accuracy of the

generated risk list.

Finally, on average, the risk management expert

chose to add 4% of the risks that were not

represented in the ProcessGene repository (see

column #3). This indicates that the risk identifier

mechanism's ability to generate new risks was not

dependent on the specific given repository.

To summarize, the experiments have

demonstrated the usefulness of the machine-based

risk identification assistant in constructing risks to

process models. We have also measured and

evaluated the effectiveness of the method in the

given experimental setup, both in terms of the

amount of missing risks and in the amount of

redundant risks.

6 CONCLUSIONS

We proposed a mechanism for automating the

generation of risks within a process repository. Such

a mechanism saves design time and supports non-

expert designers in creating new risks for business

process models. The proposed method and

experiments provide a starting point that can already

be applied in real-life scenarios, yet several research

issues remain open, including: (1) an extended

empirical study to further examine the quality of the

framework; (2) extending the method to include

mitigating controls as well; and (3) extending the

learning mechanism to further predict the user's

behaviour.

REFERENCES

Barbaro, A., Bagajewicz, M., J., 2004. Managing

Financial risk in planning under uncertainty. AIChE

Journal, 50(5):963989.

Galindo, J., Tamayo, P., 2000. Credit risk assessment

using statistical and machine learning: basic

methodology and risk modelling applications.

Computational Economics, 15(1-2):107143.

Giesecke, K., 2004. Credit risk modelling and valuation:

An introduction. Available at SSRN 479323.

Gschwind, T., Koehler, J., Wong, J., 2008. Applying

patterns during business process modelling. In BPM,

volume 5240, pages 419. Springer.

Lincoln, M., Gal, A., 2011. Searching business process

repositories using operational similarity. On the Move

ICEIS 2016 - 18th International Conference on Enterprise Information Systems

612

to Meaningful Internet Systems: OTM 2011, pages

219.

Lincoln, M., Karni, R., Wasser, A., 2007. A Framework

for Ontological Standardization of Business Process

Content. International Conference on Enterprise

Information Systems, pages 257263.

Michalski, G., 2009. Inventory management optimization

as part of operational risk management. Economic

Computation and Economic Cybernetics Studies and

Research, pages 213222.

Muller, D., Reichert, M., Herbst, J., 2007. Data-driven

modelling and coordination of large process structures.

Lecture Notes in Computer Science, 4803:131.

ProcessGene website, 2016. http://processgene.com/busin

ess-process-repository/.

Reijers, H.A., Limam, S., Van Der Aalst, W.M.P., 2003.

Product-based workflow design. Journal of

Management Information Systems, 20(1):229262.

Schonenberg, H., Weber,B., van Dongen, B.F, van der

Aalst, W.M.P., 2008. Supporting flexible processes

through recommendations based on history. In

International Conference on Business Process

Management (BPM 2008), volume 5240, pages 5166.

Springer.

Stanford parser, 2016. http://nlp.stanford.edu:8080/parser/i

ndex.jsp.

Wahler, K., Kuster, J.M., 2008. Predicting Coupling of

Object-Centric Business Process Implementations. In

Proceedings of the 6th International Conference on

Business Process Management, page 163. Springer.

Natural Language Processing for Risk Identiﬁcation in Business Process Repositories

613
