Semi-Automatic Assessment Approach to Programming Code for

Novice Students

Selim Buyrukoglu, Firat Batmaz and Russell Lock

Department of Computer Science, Loughborough University, Epinal Way, Loughborough, U.K.

Keywords: Automatic Assessment, Programming Language, Intelligent Tutoring System, Online Assessment.

Abstract: Programming languages have been an integral element of the taught skills of many technical subjects in

Higher Education for the last half century. Moreover, secondary school students have also recently started

learning programming languages. This increase in the number of students learning programming languages

makes the efficient and effective assessment of student work more important. This research focuses on one

key approach to assessment using technology: the semi-automated marking of novice students’ program

code. The open-ended, flexible nature of programming ensures that no two significant pieces of code are

likely to be the same. However, it has been observed that there are a number of common code fragments

within these dissimilar solutions. This observation forms the basis of our proposed approach. The initial

research focuses on the ‘if’ structure to evaluate the theory behind the approach taken, which is appropriate

given its commonality across programming languages. The paper also discusses the results of real world

analysis of novice students’ programming code on ‘if’ structures. The paper concludes that the approach

taken could form a more effective and efficient method for the assessment of student coding assignments.

1 INTRODUCTION

Automation in the assessment of programming

exercises has become an important and also

increasingly complex consideration in the marking

of students’ programming exercises (Rubio-Sánchez,

2014). Many students learn programming languages

over a number of years of study. In recent years,

younger people have also started to learn

programming languages in Further Education (FE)

and secondary schools (Resnick et al., 2009) rather

than just in Higher Education (HE). Instead of using

general high-level languages such as Java or C++ to

teach younger, novice students, specialist languages

have been developed, with one of the more popular

being scratch (Meerbaum-Salant et al., 2013).

The manual programming assessment process is

not efficient for assessors, partly because it scales

linearly and suffers significant duplication of effort

given the commonality of many fragments of code

(Palmer et al., 2002). Many researchers therefore

focus on automatic assessment, because each

program could be assessed and analysed more

efficiently by computer if a computer could be

configured to do so (Ala-Mutka, 2005). Sharma et al.

(2014) indicated that students’ programming code

can be analysed dynamically or statically. In

dynamic analysis, each student’s program code is

executed and then the result is checked to ascertain

the correctness of the program. By contrast, during a

static analysis, the code is examined and evaluated

without running the program.

The purposes of automatic assessment systems

are different, and can be summative or formative.

Scriven, (1967) stated that at the end of the learning

period, students’ learning is measured and their own

achievement, which is reported through a summative

assessment. Melmer et al. (2008) specified that

formative assessment is directly related to the

enhancement of a student’s education based on

feedback. Students may understand their learning

more deeply through formative assessment (Clark,

2011). Assessment systems can assess syntax errors,

logic errors and semantic errors relating to the

source code. Syntax errors represent incorrect

statements in programming languages

(Kaczmarczyk et al., 2010). Semantic errors involve

programming code which is syntactically correct;

buy includes incorrect conditions (Schmidt, 2012).

Programs with logic errors run without faults but

produce incorrect results (Spohrer and Soloway,

2013).

Buyrukoglu, S., Batmaz, F. and Lock, R.

Semi-Automatic Assessment Approach to Programming Code for Novice Students.

In Proceedings of the 8th International Conference on Computer Supported Education (CSEDU 2016) - Volume 1, pages 289-297

ISBN: 978-989-758-179-3

289

Students’ programming assignments were mostly

assessed manually before the early 2000s (Cheang et

al., 2003). Within manual approaches to assessment,

each programming assignment is assessed only by a

human (Cheang et al., 2003). Both automatic and

manual assessments have some key advantages and

disadvantages. With automatic assessment, students

can expect to receive feedback in a shorter period of

time compared to that of manual assessment (Foxley

et al., 2001). However, automatic assessment

systems may return limited feedback, and are

heavily dependent on lecturing staff correctly

configuring systems with model solutions. Manual

assessment can be effective for students in terms of

detailed feedback if the examiner assesses students’

assignments as well; that is, if examiners focus on

the strengths and weaknesses of the students’

programming assignments, they can provide

comprehensive feedback. However, manual

assessment is an inefficient process, and can lead to

minor inconsistencies in commenting accuracy and

depth (Cheang et al., 2003). Jackson, (2000)

indicated that the merger of both automatic and

manual assessment is a beneficial solution, because

students’ programming assignments can be assessed

not only in a short time, but also with more detailed

feedback than if based on assessment by computer

alone. Such an approach is termed semi-automatic

assessment (Jackson, 2000). This research focuses

on semi-automatic assessment in order to give a

better quality of feedback whilst retaining much of

the efficiency increase associated with automated

approaches. The research initially deals with the

assessment of ‘if’ structures in order to prove the

theory behind the approach, because novice

programmers initially learn ‘if’ structures.

The structure of the paper is as follows: the next

section introduces related works in the field. Section

3 presents our approach, including potential

identifying, codifying, grouping and marking

processes. Section 4 includes a real-world case study

evaluation of the approach developed. Section 5

discusses the current issues and limitations posed by

the outlined approach, and the final section provides

conclusions and outlines the potential for future

work in this area.

2 RELATED WORK

In literature, there have been many approaches

proposed for the automatic assessment of

programming code. This paper will examine five

key existing approaches which have influenced our

own.

In the system developed by Wang et al. (2007),

semantic similarity is measured between students’

code and model answers to provide the grade. The

semantic similarity measurement includes program

size, structure and statement matching. In this

approach, the student’s program code structure is

standardised using specific rules to measure the

semantic similarity. Otherwise, the student program

and the model answers cannot be matched in terms

of the different ordering of statements or code

structure in the assessment process. Thus, some rules

are created in the system to standardise the students’

program code. The aim of the standardisation is to

eliminate unimportant syntactic variations from a

feedback perspective, and so reduce the number of

model answers, improving the program matching in

this system. For example, expressions, control

structures, and function invocation are standardized

by the system. Then, variables are renamed,

redundant statements are removed and statements

are reordered to improve automatic matching by the

system. Lastly, the semantic structures of student

program and model answers are matched, and then

the student gets the grade.

The aim of the system developed by Sharma et al.

(2014) is to teach students only using an ‘else-if’

structure, rather than a broader range of control

structures. Within the approach, a student’s ‘else-if’

structure, a block of programming that analyses

variables and chooses the direction in which to go

based on given parameters, is normalised in order to

compare it with a model answer. In order to

normalise the ‘else-if’ structure, each condition,

nested logic operator, arithmetic clause and

relational operator is automatically converted to a

clearer form using rules applied by the system. After

the normalisation of each statement in the ‘else-if’

structure, the system checks the ordering of the

conditions.

Scheme-Robo is a system developed by

Saikkonen et al. (2001). In this system, students can

resubmit their own assignments a certain number of

times. Students’ code structures are checked by the

system using an abstract tree for the code writing

exercises. This tree includes the general structure of

code or special sub-patterns. That is, the system

executes the tree to ascertain the correctness of the

students’ code structure. The system provides

feedback on failed parts of code as comments.

Jackson, (2000) indicated that human comment

is important to provide comprehensive feedback in

the semi-automatic assessment systems, and so he

developed a semi-automatic assessment. The system

CSEDU 2016 - 8th International Conference on Computer Supported Education

290

assesses the students’ program source code. In the

testing phase, the system gives the lecturer the

opportunity to view the students’ source code. The

system also asks the lecturer questions regarding

students’ program code as part of the assessment

process. The examiner gives an answer to questions

posed choosing one possible answer from the listed

answers such as awful, poor, fair, very good etc.,

and then the assessment process continues. It also

applies software metrics to students’ programs.

Lastly, students get feedback on his/her exercises.

In the system developed by Joy et al. (2005), the

correctness, style and authenticity of the student

program code is assessed. It is designed for

programming exercises. Students can submit their

programs using the BOSS system (a submission and

assessment system) (Joy et al., 2005). In the

feedback process, a lecturer tests and marks the

students’ submissions using BOSS. The system also

allows lecturers to get information on students’

results according to the automatic test applied and to

view original source code. Thus, the examiner can

then give further feedback in addition to the

system’s feedback. At the end of the assessment, the

student gets feedback including comments and a

score, rather than just a score.

2.1 Discussion of Related Work

In the related work section five studies were

introduced in terms of their strengths and

weaknesses. Although some of them may provide

sufficient feedback if correctly applied, they are not

designed to significantly alleviate the workload of

the examiner. That is, providing feedback may

impact negatively on the time taken by the examiner

to assess student work. The workload of the

examiner entirely depends on the approach of the

assessment systems. In addition to this, the workload

of the examiner also depends on the length of the

code script which could be short or long.

The systems of Wang et al. (2007) and Sharma et

al. (2014) and Saikkonen et al. (2001) focus on

student programming code structures, which can be

useful, but limiting in terms of feedback. While the

systems of Wang et al. (2007) and Saikkonen et al.

(2001) focus on the whole code structure in their

own systems, the system of Sharma et al. (2014)

covers only the ordering of conditions in the ‘else-if’

structure. The aim of the standardisation of the code

structure in the system of Wang et al. (2007) is to

reduce the number of model answers. Furthermore,

code structure is standardised to provide grade

students’ code rather than to provide comment

(feedback) on the code structure. On the other hand,

the system of Saikkonen et al. (2001) assesses the

return values instead of actual output strings because

of the differences in wording in students’ answers.

In other words, the system focuses on the execution

of abstract tree. In this case, the system of Saikkonen

et al. (2001) may not provide comprehensive

feedback for students. Also, Sharma et al. (2014)

system can be used only for ‘else-if’ structures,

which is effective for providing feedback to novice

programmers, but only on ‘else-if’. However, the

theory behind the system could allow it to handle

other control structures, loops and functions in the

future. Moreover, the quality of feedback could have

been enhanced by inclusion of a human in the

assessment process.

The system developed by Jackson (2000) and

Joy et al. (2005) highlights the importance of human

in the assessment process in providing

comprehensive feedback. In Jackson (2000) system

the examiner is part of the assessment process;

however, the examiner is used after the assessment

process in Joy et al. (2005) system. In these systems,

humans check each student’s code separately.

Therefore, the systems cannot reduce the workload

of examiners significantly, although they can

provide sufficient feedback using these approaches.

One significant drawback to Joy et al. (2005) system

is that while examiners can give additional

comments to students, the system could also

potentially provide inconsistent comments (as this is

not checked by the system). It is this automatic reuse

of feedback provided for given segments of code

that would have allowed greater consistency and

efficiency to be achieved. On the other hand, in

Jackson (2000) system, the examiner chooses one

comment from the suggested comments. However,

the system cannot provide comprehensive feedback

because the examiner cannot add comments to the

student’s code.

To conclude, the discussed assessment studies

intended to provide sufficient feedback and reduce

the workload of the examiner. However, they have

generally focused on whole code segments rather

than control structures, loop, functions etc. Thus,

they have generally provided superficial feedback

although some of them reduce the workload of the

examiner. Moreover, these discussed studies

generally based on the semantic similarity. The

proposed approach also related to semantic and

structure similarity. The main difference between

them is that the proposed approach does not need

model answer(s) although the discussed studies do.

Therefore, the proposed approach parses the whole

Semi-Automatic Assessment Approach to Programming Code for Novice Students

291

code script based on the repetitive parts of code

structures such as sequence part of code segments,

‘if’ control structures, loops and functions etc.

before the examiner providing feedback on them.

The following section discusses the approach of this

research.

3 APPROACH

This section describes the proposed approach, which

is based on analysing the source code of novice

programmers. It focuses on commenting the

repetitive elements of students’ program code. All

programming languages could potentially be

assessed using the proposed approach. That is, this

approach can be applied equally well independent of

programming language. Previous observations by

the paper authors of student code indicate that

students’ code structures generally contain similar

code segments. Table 1 shows examples of code

segments.

Table 1: A code example.

Name Program Code

if (x==5){

print ‘x equals to 5’}

else{

print ‘x is not equals to 5’}

In Table 1, code segments A and B together form

code referred to as ‘AB’. In this example, code

segment A refers to an ‘if’ structure, including the

condition and block parts. The condition part is

‘(x==5)’, while the block part is ‘print ‘x equals to

5’’. Table 2 gives example on same code segments

among students code.

Table 2: Programming codes.

Student 1 Student 2 Student 3 Student 4

A A A A

B B D B

C C C C

Each of the letters in Table 2 refers to a common

code segment. To simplify the explanation, the code

segments are illustrated as letters. This approach has

four key processes, which are identifying, codifying,

grouping and marking. Figure 1 shows the process

model of the proposed semi-automatic assessment

approach.

Figure 1: Processes model of the proposed Semi-

Automatic assessment approach.

The processes included in Figure 1 outlined

further in the bullet points below.

• Process 1: Students attempt to code an answer

to a question and then submit it.

• Process 2: Similar code segments are

identified by the system.

• Process 3: Similar code segments are

automatically codified by the system. For

example, in Table 2, four different similar code

segments are codified: the components A, B, C

and D. (After the codifying process, they are

called as components).

• Process 4: Components are automatically

grouped by the system in this process.

• Process 5: The examiner comments on each

different component once for each group.

Then, the examiner comments are utilised to

mark the rest of the component in the same

group by the system.

• Process 6: If any similar code segments cannot

be automatically codified by the system, they

can be marked and commented on manually by

the examiner.

• Process 7: Students’ results can be given as

feedback.

Using this assessment process, examiners’

workloads may be partially alleviated. On the other

hand, examiners have to ask very clear questions to

find similar code segments in different students’

code. Thus, the question type is very critical within

this approach. The following sections discuss the

CSEDU 2016 - 8th International Conference on Computer Supported Education

292

identifying, codifying, grouping and marking

processes in detail.

3.1 Identifying Process

Different students’ code can contain similar code

segments. Their similarities can be identified in this

process. This process refers to Process 2 in Figure 1.

Similar code segments can also include similar

control structures, conditions and block parts. The

following bullet points explain the details of similar

code segments.

• Similar Control Structure: If students’ code

segments include only the same control

structures, and disregard the condition and block

parts, they are considered similar control

structures.

• Similar Condition: If the numbers of arguments

in the condition parts of structures are the same,

regardless of the control structure name and

block parts, they are considered similar

conditions.

• Similar Block: If the block parts of control

structures include the same line, they are

considered similar block parts.

In this approach, if different students’ code

includes similar control structures, similar

conditions and similar block parts all together, they

are considered similar code segments (i.e.

similar(code segment)= similar(control structure) +

similar(condition) + similar(block)). In Table 3, two

similar code segments are illustrated.

Table 3: Examples of similar code segment.

Name Similar Code Segment

Similar

Code

Segment-1

if ((x = 0)and(t = 0)){

y = x + 1

z = t - 1

print ‘y is positive’

print ‘z is negative’}

Similar

Code

Segment-2

if ((t = 0)and(x = 0)){

z = t - 1

y = x + 1

print ‘z is negative’

print ‘y is positive’}

In Table 3, two code segments are considered

similar code segments because they have similar

code structures, similar conditions and similar block

parts. Both of them include only ‘if’ structures,

regardless of the condition and block parts of them,

and so they are considered similar code structure. In

the condition part of the two similar code segment

entities, it is obvious that the number of argument

remain unchanged. Therefore, those two condition

parts can be considered as similar conditions. Lastly,

the block parts include four lines, regardless of the

meaning, and so they are considered to be similar

blocks. To conclude, two different code segments, in

Table 3, can be considered similar code segments in

this paper. Similar code segments can be codified

after the identifying process.

3.2 Codifying Process

The aim of the codifying process is to increase the

number of standard forms among students’ solutions.

Students’ program codes are naturally different from

each other. The rest of this section discusses the

details of the codifying processes.

This process refers to Process 3 in Figure 1. In

this process, similar code segments can be codified

using rules. These rules can arrange the order of

arguments in the condition part and the order of

block lines of the similar code segments. For

example, in Table 3, the order of conditions of

similar code segments are different from each other.

After the codifying the condition parts of similar

code segments, the condition part of similar code

segment-2 can be identical with the condition part of

similar code segment-1. Additionally, the order of

block parts of similar code segments can be also

identical after the codifying process. Then, both

similar code segment-1 and similar code segment-2

from Table 3 can be called component A which is

illustrated in Table 4.

Table 4: Component A.

Component A

if ((x = 0)and(t = 0)){

y = x + 1

z = t - 1

print ‘y is positive’

print ‘z is negative’}

After the codifying process, there will be a

transformation from the two similar code segments

into the component A. The similar code segments

can be seen in the Table 3 while component A is

illustrated in the Table 4. Thus, the two similar code

segments from the Table 3 can be codified through

this process.

3.3 Grouping Process

String matching is the main part of the grouping

process. The result of the string match directly

affects the group numbers. After the codifying

Semi-Automatic Assessment Approach to Programming Code for Novice Students

293

process, the components can be grouped by the

system. This process refers to Process 4 in Figure 1.

In this process, each different component can be

grouped in terms of component structure in this

process. The component structure can be an ‘if’,

‘else-if’ or ‘else’ structure. For example, component

A refers to the ‘if’ structure in Table 4. Moreover, if

component A is used by 25 students, all of them can

be put into same group. That is, the created group

includes 25 components A according to this example.

In addition to this, a whole code script may

include not only ‘if’ structures but also sequence

part of code segments, loops, functions etc. That is, a

component could represent a sequence part of a code

segment, control structure, loop or function etc.

Each of them can be put into required groups

through the grouping process. In this case, more

complex assignments can also be assessed using the

approach taken by this research. However, the

grouping process should be applied systematically.

For instance, a group may include different

components which are not identical between each

other. Thus, the grouping process is very important

in this approach.

3.4 Marking Process

In this process, the examiner needs to comment and

mark only one component from each group, rather

than all of the components and the rest of the

components from each group can be automatically

marked by the system using the examiner comments.

This process refers to Process 5 in Figure 1. That is,

each component from same group can get same

comments through this process. Table 5 shows the

two programs’ code showing the same components

as letters.

Table 5: Two program code.

Code-1 Code-2

For example, in Table 5, after the examiner

comments component A from Code-1, another

component A can be automatically commented in

Code-2. In addition to this, we envisage that, in the

eventual tool each commented component could be

illustrated with different colours. For example, all

components A could be highlighted after the

examiner comments it (showing that those areas can

be ignored when reading other students code as they

have already been commented upon).

At the end of the marking process, the examiner

can also comment the non-codified similar code

segments. This process refers to Process 6 in Figure

1. Thus, each student’s code script can be marked

and commented by the examiner through the

proposed semi-automatic assessment approach.

4 FEASIBILITY OF THE

APPROACH

This section gives information on data collection, and

the analysis and discussion of parts of the case study.

The following sub-section explains the data collection.

4.1 Data Collection

Data was collected to ensure the feasibility of the

approach proposed in this research. A question on

‘else-if’ control structures was asked to students

taking semester one (2014) of the introduction to

programming module at Loughborough University.

The lab exam, which 53 students attempted, asked

about the usage of ‘else-if’ structures. 51 of the 53

students tried to use an ‘else-if’ structure; in other

words, 96% of students used ‘else-if’ structures in

their solutions. The students used the Python

programming language to complete the task, which

was as follows:

Write a program which asks the user to enter

integer values for the radius of the base and the

height of a cone. The program should then

calculate the surface area and the volume of the

cone, and the program should check for the

following conditions before calculating the area:

If the radius or height is not a positive number

then the program should print the message:

ERROR: Both the r and h values must be

positive numbers!

If the radius or the height is more than 100

then the program should print the message:

ERROR: Both the r and h values must be

less than or equal to 100 cm!

You MUST utilise the ‘if...elif…else’ statement

in your code.

According to the question, students must use the

‘else-if’ structure in his/her program code. Each

requirement needs to be highlighted in the questions

such as variable names, print messages, control

structures etc.

4.2 Analysis and Discussion

Students’ code segments were manually identified,

CSEDU 2016 - 8th International Conference on Computer Supported Education

294

codified, grouped and marked in this research. The

analysis section assumes that code segments written

by students are similar code segments. This process

refers to Process 2 in Figure 1. They have been

analysed in terms of ‘if’ control structures which are

‘if’, ‘else-if’ and ‘else’ structures. Table 6 shows the

three real source code which were written by the

students.

Table 6: Real similar code segments of students.

Name Students’ Similar Code Segments

if (h<=0 or r<=0):

print "r and h must be

positive"

elif (h>100 or r>100):

print "r and h less than 100"

else:

s=3.14*r(r+(h*h+r*r)**0.5)

v=(3.14*r*r*h)/3

print s, "and", v

if (h<=0 or r<=0):

print "r and h must be

positive"

if (h>100 or r>100):

print "r and h less than

100"

else:

s=3.14*r(r+(h*h+r*r)**0.5)

v=(3.14*r*r*h)/3

print s, "and", v

The X refers to the ‘else-if’ structure; Y refers to

the ‘if’ structure, and lastly, Z refers to the ‘else’

structure in Table 6. Initially, each of them is

manually codified. This process refers to Process 3

in Figure 1. In this process, the orders of arguments

in condition parts of theirs and the orders of block

lines of theirs were fixed manually. Then, they were

considered component X, Y and Z after the

codifying process. Table 7 gives information on the

numbers of components which were obtained from

the codifying process.

Table 7: Number of components.

Component Name Number of Components

X (else-if structure)

Y (if structure)

Z (else structure)

According to Table 7, 43 students used

component X, and one student used both

components Y and Z (out of a total of 53 students).

That is, 44 students’ similar code segments were

codified using this approach. For the remaining nine

students’ similar code segments were not codified

because their segments did not resemble the code

structures X, Y and Z. Eight of these nine students

tried to use ‘else-if’ structures without else

statements. The remaining one of these nine students

used nested structures. Thus, these nine students’

code segments would have to be marked and

commented on by the examiner because they were

not codified, which is shown as Process 6 in Figure

1. Then, the component X, Y and Z were put into

groups. This process refers to Process 4 in Figure 1.

Table 8 shows the groups of components.

Table 8: Groups of components.

Group

Name

Group1 Group2 Group3

Component

Name

Group 1 includes component X, Group 2

includes component Y and Group 3 includes

component Z. After the grouping process, only one

components from the each group needs to be marked

and commented by the examiner. Then, the rest of

the non-commented components form each group

need to be assessed by the system. This process

refers to Process 5 in Figure 1. Table 9 shows the

components assessed by the examiner using the

proposed approach.

Table 9: Numbers of components marked by examiner and

proposed approach.

Component

Name

Component

Number

Assessed

by the

Examiner

Assessed

by the

Proposed

Approach

X 43 1 42

Y 1 1 0

Z 1 1 0

In Table 9, three of 45 components need to be

marked by the examiner which refers to 7% of

components. The rest of the components, 42 of the

45 components which refer to 93% of components,

can be assessed by the proposed approach.

At the end of the assessment process, only the

three different components and the nine non-

codified similar code segments need to be marked

by the examiner. These highlighted numbers are

only related to the introduced example in this paper.

However, their numbers can change due to certain

issues. The next section will discuss issues identified

with the approach outlined.

Semi-Automatic Assessment Approach to Programming Code for Novice Students

295

5 ISSUES WITH THE PROPOSED

SEMI-AUTOMATIC

ASSESSMENT APPROACH

Although we successfully analysed the short

solutions of novice students, we did encounter some

problems. For example, different variable names,

print messages and order of components are a

problem for this approach. These problems are

discussed below.

5.1 Problem 1: Use of Different

Variable Names

Table 10 shows two different similar code segments.

‘a’ and ‘area’ are variable names in Table 10.

Table 10: Different similar code segments.

No Code

if(a < 0)

print “should be positive”

if(area < 0)

print “should be positive”

Although both statements are meant to make the

same comparison, two different components can be

created by the codifying process due to the use of

different syntax in variable names. That is, this issue

can cause the creation of extra, redundant

components.

5.2 Problem 2: Use of Different Print

Messages

Table 11 shows two different similar code segments.

‘Should be positive’ and ‘should not be negative’ are

the print message parts of the code.

Table 11: Different similar code segments.

No Code

if(a < 0)

print “should be positive”

if(a < 0)

print “Should not be negative”

Although both programs give the same message

in terms of meaning, their wording (i.e. strings) is

very different. Thus, in the codifying process, they

are codified differently; two different components

can be created due to the use of different syntax in

print messages.

Both problem 1 and problem 2 can cause the

creation of a new component in the assessment

process. If these issues are solved, component

numbers and also group numbers do not increase

redundantly. They can be solved through a user

interface. For example, it can be designed such as

the Scratch programming user interface (Resnick et

al., 2009). Students can drag and drop each part of

the code segment and so students will use same

variable names and print messages.

5.3 Problem 3: Order of Components

The differing order of components could be another

issue for this approach. Table 12 shows two different

programming codes showing components as a letter.

Table 12: Two different programming code.

Code-1 Code-2

In Table 12, two different program codes include

components which are A, B, C, D and E. The orders

of components in the students’ code are different

from each other. In this case, the automatically

commented components can be commented

incorrectly due to different orders of the components.

That is, students may get some incorrect feedback

because the incorrect order of the components can

cause logical errors. Thus, the different order of

components is a recognised issue for this approach

which needs to be addressed in the future.

6 CONCLUSIONS

This research paper has introduced a semi-automatic

assessment approach which helps examiners by

reducing the number of components to be marked. It

was applied manually and the initial results are very

encouraging. This approach has four important parts:

identifying, codifying, grouping and marking.

Codifying the similar code segments is also a

challenging part of it. The similarity measurement of

code segments is also discussed briefly, though

outlining this further will be the role of another

paper due to space constraints. Potential issues

relating to the application of this approach are also

discussed. To conclude, the proposed approach is

feasible according to the result of the case study

because the examiner only needed to assess three

components from 45 components. That is, 7% of

components were assessed by the examiner. Thus,

CSEDU 2016 - 8th International Conference on Computer Supported Education

296

examiner workloads can be partially reduced and

consistent feedback can be provided through the

proposed semi-automatic assessment approach.

6.1 Further Work

The approach outlined focuses primarily on ‘if’

structures. However, in order to provide a useful tool,

additional control structures will need to be

supported. The first step in this will be support for

‘for’ loops, as these are common across all high-

level programming languages. Similarity

measurement is also very important in order to

identify similar code segments in different students’

code. This particular area will be developed further

in the future. In terms of tool support to enable real

world testing of the approach a drag and drop user

interface is under development at the present time.

REFERENCES

Ala-Mutka, K.M. (2005). A survey of automated

assessment approaches for programming assignments.

Computer science education, 15(2), 83-102.

Cheang, B., Kurnia, A., Lim, A., & Oon, W. C. (2003). On

automated grading of programming assignments in an

academic institution. Computers & Education, 41(2),

121-131.

Clark, I. (2011). Formative Assessment: Policy,

Perspectives and Practice. Florida Journal of

Educational Administration & Policy, 4(2), 158–180.

Foxley, E., Higgins, C., Hegazy, T., Symeonidis, P. &

Tsintsifas, A. (2001). The CourseMaster CBA system:

Improvements over Ceilidh.

Jackson, D. (2000). A semi-automated approach to online

assessment. ACM SIGCSE Bulletin ACM, 164.

Joy, M., Griffiths, N. & Boyatt, R. (2005). The boss online

submission and assessment system. Journal on

Educational Resources in Computing (JERIC), 5(3), 2.

Kaczmarczyk, L.C., Petrick, E.R., East, J.P. & Herman,

G.L. (2010). "Identifying student misconceptions of

programming", Proceedings of the 41st ACM technical

symposium on Computer science educationACM, pp.

107.

Meerbaum-Salant, O., Armoni, M. & Ben-Ari, M. (2013).

Learning computer science concepts with scratch.

Computer Science Education, 23(3), 239-264.

Melmer, R., Burmaster, E., & James, T. K. (2008).

Attributes of effective formative assessment.

Washington, DC: Council of Chief State School

Officers. Retrieved October, 7, 2008.

Palmer, J., Williams, R., & Dreher, H. (2002). Automated

essay grading system applied to a first year university

subject – How can we do it better?. In Proceedings of

Informing Science 2002 Conference, Cork, Ireland,

June (pp. 19-21).

Resnick, M., Maloney, J., Monroy-Hernández, A., Rusk,

N., Eastmond, E., Brennan, K. & Kafai, Y. (2009).

Scratch: programming for all. Communications of the

ACM, 52(11), 60-67.

Rubio-Sánchez, M., Kinnunen, P., Pareja-Flores, C. &

Velázquez-Iturbide, Á. (2014). Student perception and

usage of an automated programming assessment tool.

Computers in Human Behavior, 31, 453-460.

Saikkonen, R., Malmi, L. & Korhonen, A. (2001). Fully

automatic assessment of programming exercises. ACM

Sigcse Bulletin ACM, pp. 133.

Schmidt, D.A. (2012). [Online] Programming Language

Semantics. Kansas State University. Available from:

http://people.cis.ksu.edu/~schmidt/705a/Lectures/chap

ter.pdf [Accessed 02 September 2015]

Scriven, M.S. (1967). The methodology of evaluation

(Perspectives of Curriculum Evaluation, and AERA

monograph Series on Curriculum Evaluation, No. 1.

Chicago: Rand NcNally.

Sharma, K., Banerjee, K., Vikas, I. & Mandal, C. (2014).

Automated checking of the violation of precedence of

conditions in else-if constructs in students' programs.

MOOC, Innovation and Technology in Education

(MITE), 2014 IEEE International Conference on

IEEE, 201.

Soloway, E. & Spohrer, J. C. (2013). Studying the novice

programmer. Psychology Press.

Wang, T., Su, X., Wang, Y. & Ma, P. (2007). Semantic

similarity-based grading of student programs.

Information and Software Technology, 49(2), 99-107.

Semi-Automatic Assessment Approach to Programming Code for Novice Students

297
