Experiences of Tool-Based Enterprise Modelling as Part of
Architectural Change Management
Cameron Spence
Capgemini, Woking, United Kingdom
Vaughan Michell
University of Reading, Whiteknights, Reading, United Kingdom
Keywords: Enterprise modelling, business modelling, enterprise architecture.
Abstract: Enterprise Architecture is widely practised as a part of a strategic business change methodology and is often
vital to successful business change. This paper examines the pragmatic use of enterprise architecture
modelling (EAM) tools. A pilot survey of EAM practitioners identified that many companies abandon the use
of EAM tools despite the benefits that should result from their use. Some of the reasons for lack of
sustainability include (a) failures in modelling governance, (b) lack of alignment with the change method, (c)
users withholding information and (d) poor perception of EA itself.
1 INTRODUCTION
Enterprise architecture is a growing field that enables
the major aspects of business and IT activity to be
modelled and plans made for their change
(Hoogervorst, 2004). The use and application of an
integrated model of the business is key to supporting
change decision-making. However, a survey of the
current literature identified firstly that EA modelling
is often abandoned (e.g. (Meertens et al., 2011b));
secondly that business models vary greatly and do
not have a clearly agreed definition (Vermolen,
2010)); and thirdly there is a gap in the existing
literature regarding how enterprise architecture
modelling (EAM) can be made sustainable and
effective in its use as part of a principle change
methodology.
This paper first summarises some relevant
terminology related to the modelling of Enterprise
Architecture. We then present results from a pilot
survey of practitioners of enterprise architecture
modelling (EAM) based around the issues identified
from the literature. We then consider a number of
issues identified by the respondents in the execution
of tool-based EAM as motivation for further study.
2 THE PRACTICE OF
TOOL-BASED ENTERPRISE
MODELLING AS PART OF
CHANGE MANAGEMENT
Enterprise Architecture Modelling (EAM) is carried
out in both end-user and consulting organisations
(Hall and Harmon, 2005, Ganesan, 2008). This
section briefly explains and grounds some terms
related to tool-based EAM.
2.1 Enterprise Architecture
Rood (Rood, 1994) suggests an Enterprise
Architecture comprises: people, information and
technology. TOGAF (The Open Group, 2011) divides
the Enterprise into four domains: Business, Data,
Applications and Technology. Capgemini’s IAF
(Wout et al., 2010) uses four similar domains to
255
Spence C. and Michell V.
Experiences of Tool-Based Enterprise Modelling as Part of Architectural Change Management.
DOI: 10.5220/0005887902550260
In Proceedings of the Fifth International Symposium on Business Modeling and Software Design (BMSD 2015), pages 255-260
ISBN: 978-989-758-111-3
Copyright
c
 2015 by SCITEPRESS – Science and Technology Publications, Lda. All rights reserved

TOGAF, but worded slightly differently. All broadly
recognise the need to cover business, information and
technology.
2.2 EA Frameworks
These provide a standard structure, vocabulary and
(sometimes) a process for carrying out EA work.
Examples of EA frameworks include TOGAF (The
Open Group, 2011)), DODAF (DoD, 2010)) and
Zachman’s Enterprise Architecture Framework
(ZEAF) (Zachman, 1987)). There are also reference
frameworks that help position and compare the EA
frameworks: the Generic Enterprise Reference
Architecture and Method (GERAM) (Bernus and
Nemes, 1996) which packages these within
Ontological Theories; and the newer EAF2 (Franke et
al., 2009).
2.3 Enterprise Architecture Model
An Enterprise Architecture Model is a miniaturisation
or representation of the components making up an
enterprise. These models might take a number of
forms, but are likely to consist (in terms of content)
mainly of representations of the entities, attributes
and relationships relevant to a particular viewpoint or
perspective. These may for example support decision
making (e.g. “show me a view of all business services
that are reliant upon obsolete infrastructure”, as
described in (Spence and Michell, 2011). This is
helpful in governing the evolution of the enterprise IT
portfolio, as discussed later.
2.4 Enterprise Architecture Modelling
EAM is the activity of producing and maintaining EA
Models. The content of the models may well be
created by multiple agents, and also viewed by
multiple agents for a variety of reasons. These agents
will need views tailored to meet their specific needs,
showing different entity subsets, attributes and
relationships. The selection and creation of these
views and the entities and attributes in them, may or
may not be specified by a particular architecture
framework in use, but will typically need adapting to
the specific context needed for modelling. This drives
the need for EAM tool to be customisable.
2.5 Enterprise Architecture Tools
An EA Tool is an instrument used for EA Modelling.
Whilst EA Models can use pen and paper, or simple
drawing tools (e.g. Microsoft Visio®), it is much
more efficient using a software tool designed
specifically to do the job (Hall and Harmon, 2005).
TOGAF 9.1 (The Open Group, 2011) refers to EA
tools, (in chapter 42) as “automated tools”. This paper
focuses on tool-based EAM, as distinct from non-
tool-based EAM.
Commercial research organisations (Brand, 2014,
Peyret et al., 2011, Hilwa and Hendrick, 2012) divide
“modelling and architecture tools” into the following
categories:
• Object Modelling tools
• Business Process Modelling Tools
• Enterprise Architecture Tools
• Data Modelling Tools
EA Tools are, in terms of revenue, the fastest
growing in this particular market segment [21]. When
combined with a large failure rate (our survey
indicated perhaps an 85% failure rate, if failure is
defined as the modelling having ceased) from
modelling efforts, we can see that aside from failure
to gain the required benefits, the amount of spend on
EAM tools that ends up being wasted might be in the
region of $230M in 2016 (if the percentage failure
rate in our qualitative survey were to be
representative of general EAM activities).
3 TOOL-BASED ENTERPRISE
ARCHITECTURE MODELLING
EXPERIENCES
To explore whether the EAM issues identified earlier
in the literature (such as (Meertens et al., 2011b),
discussed later) occur in practice, we carried out
qualitative research. We interviewed seven
consulting Enterprise Architects who responded to an
email invitation sent to approximately 400 staff
within an IT services company, seeking volunteers to
be interviewed that had prior experience with tool-
based EAM. This is not as small as percentage as it
may appear, given that the majority of the staff will
have had no experience with EA modelling tools,
which are not used as standard within this company;
and so the pool of qualified subjects available at this
stage was relatively small.
A set of structured/ telephone interviews was
carried out on the respondents. As our future research
direction is focused on the value of the tool-based
EAM, and the factors affecting its sustainability, we
gathered information about the value (expected and
Fifth International Symposium on Business Modeling and Software Design
256

perceived) of the EAM effort and what lessons were
learned. Some questions also related to possible
activities that might lead to it being more sustainable.
The key questions were:
• Who was the client, in what industry sector?
• What EA tool was used?
• How was the tool used (e.g. single/multiple
users, one-off or part of lifecycle process, were
multiple users able to do updates in parallel)?
• What support was given (training, coaching,
documentation)?
• What was the scope of the modelling (business,
information, technology)?
• Who was responsible for introducing the tool
(client or supplier)?
• Who paid for the tool?
• What value did the client, and the supplier,
expect to get from it?
• How was that, or how could that been, measured?
• What value did the client, and the supplier,
actually get from the tool?
• What processes were in place to support and
govern the use of the tool?
• What were the factors in the modelling
environment (people, process or technology) that
helped the EAM activity? What factors hindered
it?
• Are there any features of the tool that would help,
or hinder, its sustained use over the longer term?
• Is the client still using the EA tool? If not, why
not?
• In hindsight, what do you wish you had known
before you started using the tool, and what would
you change if you did it again?
A summary of the key results is offered below.
These reflect a subset of the answers to the questions
posed:
Table 1: Summary of Some EA Modelling Experiences.
Expected value Actual value What helpe
d
What hindere
d
Still in
use?
Abandoned
b
ecause
Quicker project
lifecycle reducing
costs and risks due
to less ambiguity
Projects were
no faster as
decisions
delayed
anywa
y
Training;
top-down initiative
Cultural and
political issues; the
need to win people
over
?
N
o specific
expectations
Single version
of truth;
enabled
persuasion and
challenge;
detect errors,
saved wasted
effort and time
Many ways of
creating a model;
not one fixed
standard
N
ot enough
p
eople
had access to tool;
cultural resistance
Barely Seen as
opposed to
Agile (“high
ceremony”)
Supplier made it
prerequisite for
replatforming IT
estate
Saved a month
by skipping
due diligence
as information
was already
captured
Librarian role;
buy-in from
business;
publishing results;
lessons learnt;
people signing off
on conten
t
Tool struggling to
produce suitable
diagrams; scope
unclear at start;
people holding
onto ‘their’
information
N
o Replatforming
finished; client
believed they
no longer
needed the
information
Looking to save
money, so required
to understand the IT
estate and therefore
support
rationalisation
Unsure but
client architects
seemed pleased
Having a librarian
for the tool;
having clear scope
for modelling
Tool not easy to
use; lack of
training
Yes
Traceability
–
impact of change –
how strate
gy
is
Understood
impact of
chan
g
e
Tool supplier staff
very helpful; easy
to use;
Tool reports
sometimes hard to
read; some tool
N
o Unknown
Experiences of Tool-Based Enterprise Modelling as Part of Architectural Change Management
257

worked out in IT
p
ro
j
ects
features non-
intuitive
Understand IT
estate as
prerequisite for
application
rationalisation and
modernisation
Complete
picture of their
estate to enable
application
rationalisation
Having core
modelling team to
help others;
quality control
Lack of
governance;
reporting hard to
configure
N
o Tool issue
(reporting) and
process issue
(not following
proper
p
rocesses)
Understand IT
estate as
prerequisite for
application
rationalisation
Ability to
perform
complex
analysis,
communicate
b
usiness value
Repository
management
features, ease of
customisation
Tool quirks; high
cost of tool
N
o Client felt tool
was too
expensive
This pilot survey clearly suggests there is an issue
sustaining the use of EA tools; it confirms that the
majority abandoned the use of EAM (see “Still in
use” column in table). This prompts the research
question: why? - In only one of the 7 case studies has
the end-user organisation continued to carry out the
modelling activity, in some cases despite the benefits
that were being obtained.
The failure to produce benefits has been traced in
some cases to issues with the way it was being used
(e.g. “our main issue was caused by people not
following process / guidelines, and not updating
repository as designs were changed”).
In some cases the issue was with the tool itself
(e.g. “the client realised that the repository couldn’t
actually be generated from the tool, they believed it
couldn’t deliver the expected value: format wasn’t
good”).
4 DISCUSSION OF SURVEY
RESULTS VS RELEVANT
LITERATURE
This section sets the results in the context of the
current literature.
A systematic review of business modelling carried
out in 2010 (Vermolen, 2010), relating to the
Business layer of Enterprise Architecture concluded
that literature related to business modelling had a gap
in terms of the use of theory; and that there appears to
be a lack of papers in the leading IS journals on the
topic of business models.
Meertens et al. (Meertens et al., 2011a)
recognises that many projects involving business
modelling (a subset of EA modelling) end after an
initial phase and do not deliver the expected benefits;
this mirrors our experience from the limited case
studies above.
The topic of business modelling is the subject of
much existing research, including a proposed
research framework published in 2004 (Pateli and
Giaglis, 2004), which organises business model
research into a number of categories including
“Design Methods and Tools” and “Adoption factors”,
both of which seem initially to be relevant to the topic
at hand (sustainability of EA modelling). Some
primary and secondary sources are organised
according to these categories. In the Design Methods
and Tools category, papers describing two specific
modelling languages (UML (Eriksson and Penker,
2000) and eBML (Lagha et al., 2001)) are listed, but
nothing that addresses the specific question of the
value of Enterprise Architecture modelling using
tools such as discussed above.
The motivations for EAM are to allow the
visualisation and reporting on aspects of the
Enterprise Architecture (part of the governance
referred to below), and to provide an environment
where the structure of the Enterprise can, in a
simulated fashion, be altered in some way to examine
the consequences of the alternation. There may be
specific business scenarios that lend themselves to
this kind of activity, for application rationalisation
(one of the scenarios encountered in the survey), or
mergers and acquisitions (Freitag and Schulz, 2012).
Some of the tasks mentioned in this paper are related
to expected business benefits, for example carrying
out due diligence (to reduce risk and cost through
better knowledge). However, the study does
recognise that the literature does not confirm (or
disconfirm) that using this kind of EA management
technique (including modelling) improves the
success rate of mergers and acquisitions.
The literature surveyed so far focuses mainly on
discrete elements (for example, specific methods or
Fifth International Symposium on Business Modeling and Software Design
258

languages), rather than the activity of EAM that
draws them together for a particular benefit. The
value of business process modelling in particular is
discussed by Indulska (Indulska et al., 2009) where
three particular areas of concern are raised; two of
these have potential relevance in areas wider than just
business processes (standardisation of modelling
approaches and the identification of the value
proposition of the modelling). Standardisation of the
modelling language is covered by Lankhorst
(Lankhorst, 2013), as is the use of a particular
modelling tool.
The value of the modelling seems to be assumed
by Jonkers (Jonkers et al., 2004) to relate to
“informed governance” and references (Op't Land et
al., 2008) that discusses the value of EA in terms of
the governance of an enterprise and its
transformation. The relationship between the
acquisition and use of a tool and a major
transformation initiative is illustrated in one of the
cases surveyed, where a supplier insisted that the
modelling had to be done as a prerequisite for a
replatforming effort. The survey suggested that some,
but not all, modelling was done explicitly in order to
help a particular transformation exercise; and that
having a clear reason for the tool is no guarantee that
its use will be sustained over time.
Given the link between EA and IT governance,
this suggests that one line of reasoning that may bear
further research, related to IT governance and tool-
based EAM, might be:
(1) Effective IT governance requires EA
(2) Effective (accurate and comprehensive)
management of EA information requires an EA
tool
(3) Effective IT governance requires an EA tool
(from (1) and (2))
Echoing a comment from one of the pieces
surveyed, there is a need to do further research in a
number of related areas:
• What is the value that we can actually expect to
get from this activity (tool-based EAM), and in
particular can the argument related to IT
governance be more clearly clarified and
investigated?
• What needs to be done in order to make this
sustainable rather than a short-term activity?
5 CONCLUSIONS
We have identified that although widely used as a part
of change management, EAM is often abandoned and
that there is a lack of formal definition and
understanding of the benefits of these models. We
have shown in a pilot survey in section 3 that there
may be an issue in practice with the sustainability of
attempts to execute EAM; these include:
• Issues with the tool itself
• Poor governance of the modelling
• Perception of EAM and EA being unnecessary
• Lack of ability to tailor the tool
• Need for cultural change
• People not wanting to share their information
• Modelling scope is not always clear
• Need to maintain quality in modelling
We have also identified in section 4 a gap in the
literature related to tool-base EA modelling as a
discipline. There is little work done on tool-based
EAM, and in particular in the business domain, a lack
of common understanding about what business
models should comprise. There is a recognition that
business modelling efforts often fail, with little
analysis of why this is so, and what should be done to
improve the situation. We have also identified a
possible direction for future research, related to the
value that tool-based EAM adds to Enterprise
Architecture and hence to IT governance.
ACKNOWLEDGEMENTS
The authors wish to thank a number of employees of
Capgemini who have provided information about
their professional experiences with EA modelling
tools: Steve Bramwell, Vincent Owens, Stephen
Timbers, Ian Mackie, Rebecca Paul and Andrew
Lazarou. Thanks also are due to Al Hilwa of IDC for
information on the market for EA modelling tools.
REFERENCES
Bernus, P. & Nemes, L. 1996. A framework to define a
generic enterprise reference architecture and
methodology. Computer Integrated
Manufacturing Systems, 9, 179-191.
Brand, S. 2014. Magic Quadrant for Enterprise Architecture
Tools. Gartner.
Experiences of Tool-Based Enterprise Modelling as Part of Architectural Change Management
259

DoD, D. 2010. Department of Defense Architecture
Framework (DoDAF) Version 2.02. In: Officer,
D. D. C. I. (ed.). U.S. Department of Defense.
Eriksson, H.-E. & Penker, M. 2000. Business Modeling
with UML: Business Patterns at Work, John
Wiley & Sons.
Franke, U., Hook, D., Konig, J., Lagerstrom, R., Narman,
P., Ullberg, J., Gustafsson, P. & Ekstedt, M.
EAF2- A Framework for Categorizing Enterprise
Architecture Frameworks. Software
Engineering, Artificial Intelligences, Networking
and Parallel/Distributed Computing, 2009. SNPD
'09. 10th ACIS International Conference on, 27-
29 May 2009 2009. 327-332.
Freitag, A. & Schulz, C. 2012. Investigating on the role of
EA management in Mergers & Acquisitions.
BMSD2012. Geneva.
Ganesan, E. 2008. Building Blocks for Enterprise Business
Architecture. SETLabs briefings.
Hall, C. & Harmon, P. 2005. The 2005 enterprise
architecture, process modeling & simulation
tools report. Business Process Trends, 1-206.
Hilwa, A. & Hendrick, S. D. 2012. Market Analysis:
Worldwide Modeling and Architecture Tools
2012–2016 Forecast and 2011 Vendor Shares.
IDC.
Hoogervorst, J. 2004. Enterprise Architecture: Enabling
Integration, Agility and Change. International
Journal of Cooperative Information Systems, 13,
213-233.
Indulska, M., Recker, J., Rosemann, M. & Green, P. 2009.
Business Process Modeling: Current Issues and
Future Challenges. In: van Eck, P., Gordijn, J. &
Wieringa, R. (eds.) Advanced Information
Systems Engineering. Springer Berlin
Heidelberg.
Jonkers, H., Lankhorst, M., Buuren, R. v.,
Hoppenbrouwers, S., Bonsangue, M. & Torre, L.
v. d. 2004. Concepts for modeling enterprise
architectures. International Journal of
Cooperative Information Systems, 13, 257-287.
Lagha, S. B., Osterwalder, A. & Pigneur, Y. Modeling e-
Business with eBML. 5th Int'l Workshop on the
Management of Firms' Networks (CIMRE'01),
Mahdia, Tunisia, 2001. Citeseer.
Lankhorst, M. 2013. Enterprise Architecture at Work:
Modelling, Communication and Analysis (The
Enterprise Engineering Series). Springer.
Meertens, L., Iacob, M. & Nieuwenhuis, L. 2011a.
Developing the business modelling method.
Meertens, L. O., Iacob, M. E. & Nieuwenhuis, L. J. M.
2011b. Developing the business modelling
method. In: Shishkov, B. (ed.) First International
Symposium on Business Modeling and Software
Design, BMSD 2011. Sofia, Bulgaria: SciTePress
- Science and Technology Publications.
Op't Land, M., Proper, E., Waage, M., Cloo, J. & Steghuis,
C. 2008. Enterprise architecture: creating value
by informed governance, Springer Science &
Business Media.
Pateli, A. G. & Giaglis, G. M. 2004. A research framework
for analysing eBusiness models. Eur J Inf Syst,
13, 302-314.
Peyret, H., DeGennaro, T., Cullen, A. & Cahill, M. 2011.
The Forrester Wave: Enterprise Architecture
Management Suites, Q2 2011. Forrester.
Rood, M. A. Enterprise architecture: definition, content,
and utility. Enabling Technologies:
Infrastructure for Collaborative Enterprises,
1994. Proceedings., Third Workshop on, 17-19
Apr 1994 1994. 106-111.
Spence, C. & Michell, V. Assessing the Business Risk of
Technology Obsolescence through Enterprise
Modelling. In: Shishkov, B., ed. Symposium on
Business Modeling and Software Design, 2011
Sofia. SciTePress.
The Open Group 2011. The Open Group Architectural
Framework (TOGAF) 9.1.
Vermolen, R. Reflecting on IS Business Model Research:
Current Gaps and Future Directions. Proceedings
of the 13th Twente Student Conference on IT,
University of Twente, Enschede, Netherlands,
2010.
Wout, J. v. t., Waage, M., Hartman, H., Stahlecker, M. &
Hofman, A. 2010. The Integrated Architecture
Framework Explained, Berlin Heidelberg,
Springer-Verlag.
Zachman, J. A. 1987. A framework for information systems
architecture. IBM Systems Journal, 26, 276-292.
Fifth International Symposium on Business Modeling and Software Design
260
