Multilinear Objective Function-based Clustering

Giovanni Rossi

Departments of Computer Science and Engineering - DISI, and Mathematics

University of Bologna, Mura Anteo Zamboni 7, 40126, Bologna, Italy

Keywords:

Fuzzy Clustering, Similarity Matrix, Pseudo-Boolean Function, Multilinear Extension, Local Search.

Abstract:

The input of most clustering algorithms is a symmetric matrix quantifying similarity within data pairs. Such

a matrix is here turned into a quadratic set function measuring cluster score or similarity within data subsets

larger than pairs. In general, any set function reasonably assigning a cluster score to data subsets gives rise to an

objective function-based clustering problem. When considered in pseudo-Boolean form, cluster score enables

to evaluate fuzzy clusters through multilinear extension MLE, while the global score of fuzzy clusterings

simply is the sum over constituents fuzzy clusters of their MLE score. This is shown to be no greater than the

global score of hard clusterings or partitions of the data set, thereby expanding a known result on extremizers of

pseudo-Boolean functions. Yet, a multilinear objective function allows to search for optimality in the interior

of the hypercube. The proposed method only requires a fuzzy clustering as initial candidate solution, for the

appropriate number of clusters is implicitly extracted from the given data set.

1 INTRODUCTION

Clustering means identifying groups within data, with

the intent to have similarity between elements in a

same group or cluster, and dissimilarity between el-

ements in different groups. It is important in a variety

of ﬁelds at the interface of computer science, artiﬁcial

intelligence and engineering, including pattern recog-

nition and learning, web mining and bioinformatics.

In hard clustering the sought group structure is a par-

tition of the data set, and clusters are blocks (Aigner,

1997); each data point is in precisely one cluster,

with full or unit membership. In fuzzy clustering data

points distribute [0,1]-ranged memberships over clus-

ters. This yields more ﬂexibility, which is useful in

many applications (Kashef and Kamel, 2010; Valente

de Oliveira and Pedrycz, 2007).

In objective function-based clustering, the prevail-

ing clusters obtain by maximizing or minimizing an

objective function: any solution is mapped into a real

quantity, i.e. its efﬁciency or cost, obtained as the

sum over clusters of their own quality. Thus in hard

clustering this sum is over blocks, with a cluster score

set function taking real values over the 2

− 1-set of

non-empty data subsets (Roubens, 1982), n being the

number of data. How to specify cluster score is the

ﬁrst issue addressed below.

When dealt with in pseudo-Boolean form, cluster

score admits a unique polynomial multilinear exten-

sion MLE over n-dimensional unit hypercube [0,1]

Such a MLE is a novel and seemingly appropriate

measure of the score of fuzzy clusters. This is where

to start for the clustering method proposed here. As

fuzzy clusterings are collections of fuzzy clusters,

attention is placed on those such collections where

the data distribute memberships adding up to 1, with

optimality found where the sum over fuzzy clusters

of their MLE-score is maximal. If global cluster

score is evaluated via the MLE of cluster score, then

its bounds are on hard clusterings. This expands a

known result in pseudo-Boolean optimization (Boros

and Hammer, 2002). Clustering is thus approached in

terms of set partitioning, with this latter combinatorial

optimization problem extended from a discrete to a

continuous domain (Pardalos et al., 2006) and solved

through a novel local search heuristic.

1.1 Related Work and Approach

Objective function-based fuzzy clustering mainly de-

velops from the fuzzy c-means FcM (Bezdek and Pal,

1992) and the possibilistic c-means PcM (Krishnapu-

ram and Keller, 1996) algorithms. Given n data points

in R

, with m observed features, both FcM and PcM

iteratively act on c < n cluster centers or prototypes,

aiming to minimize a cost: the sum over clusters of all

distances between cluster elements and their center.

For any c centers as input, at each iteration the mem-

Rossi, G..

Multilinear Objective Function-based Clustering.

In Proceedings of the 7th International Joint Conference on Computational Intelligence (IJCCI 2015) - Volume 2: FCTA, pages 141-149

ISBN: 978-989-758-157-1

 2015 by SCITEPRESS – Science and Technology Publications, Lda. All r ights reserved

141

berships of data to clusters is re-deﬁned so to mini-

mize the sum of (fuzzy) distances from centers, and

next centers themselves are re-calculated so to min-

imize the sum of distances from (fuzzy) members.

In FcM (but not in PcM) membership distributions

over the c clusters add up to 1. The iteration stops

when two consecutive fuzzy clusterings (specifying c

centers and c × n memberships) are sufﬁciently close

(or coincide). This converges to a local minimum,

and given non-convexity of the objective function, the

choice of suitable initial cluster centers is crucial. Ini-

tial cluster centers have to be arbitrary, and it is harsh

to assess whether c is a proper number of clusters

for the given data set (M

enard and Eboueya, 2002).

Much effort is thus devoted to ﬁnding the optimal

number of clusters. One approach is to validate fuzzy

clusterings obtained at different values of c by means

of an index, and then selecting the value of c for the

output that scored best on the index (Zahid et al.,

2001). This validation may be integrated into the FcM

iterations, yielding a validity-guided method (Bensaid

et al., 1996). Main cluster validity indices are: clas-

siﬁcation entropy, partition coefﬁcient, uniform data

functional, compactness and separation criteria. They

may be analyzed comparatively in terms membership

distributions over clusters (Pal and Bezdek, 1995). A

common idea is that clustering performance is higher

the more distributions are concentrated, as this for-

malizes a non-ambiguous classiﬁcation (Rezaee et al.,

1998; Xie and Beni, 1991).

Recent clustering methods such as neural gas

(Cottrell et al., 2006), self organizing maps (Wu and

Chow, 2004), vector quantization (Lughofer, 2008;

Du, 2010) and kernel methods (Shawe-Taylor and

Cristianini, 2004) maintain special attention on ﬁnd-

ing the optimal number of clusters for the given

data. In several classiﬁcation tasks concerning protein

structures, text documents, surveys or biological sig-

nals, an explicit metric vector space (i.e. R

above)

is not available. Then, clustering may rely on spec-

tral methods, where the





similarities within data

pairs are the adjacency matrix of a weighted graph,

and the (non-zero) eigenvalues and eigenvectors of

the associated Laplacian are used for partitioning the

data (or vertex) set. Speciﬁcally, the sought partition

is to be such that lightest edges have endpoints in dif-

ferent blocks, whereas heaviest edges have both end-

points in a same block. Although spectral clustering

focuses on hard rather than fuzzy models, still it dis-

plays some analogy with the local search method de-

tailed below, as in both cases full membership of data

points in prevailing clusters is decided in a single step.

In fact, spectral methods mostly focus on some ﬁrst

c < n eigenvalues (in increasing order) (von Luxburg

et al., 2008; Ng et al., 2002), thus constraining the

number of clusters. Here, such a constraint is possi-

ble as well, although with suitable candidate solution

the proposed local search autonomously ﬁnds an op-

timal (unrestricted) number of clusters.

Clustering is here approached by ﬁrstly quantify-

ing the cluster score of every non-empty data subset,

and secondly in terms of the associated set partition-

ing combinatorial optimization problem (Korte and

Vygen, 2002). Cluster score thus is a set function

or, geometrically, a point in R

−1

, and rather than

measuring a cost (or sum of distances) to be mini-

mized (see above), it measures a worth to be maxi-

mized. The idea is to quantify, for every data subset,

both internal similarity and dissimilarity with respect

to its complement. This resembles the “collective

notion of similarity” in information-based clustering

(Slonim et al., 2005). Objective function-based clus-

tering intrisically relies on the assumption that every

data subset has an associated real-valued worth (or,

alternatively, a cost). A main novelty proposed below

is to deal with both hard and fuzzy clusters at once by

means of the pseudo-Boolean form of set functions.

In order to have the same input as in many clustering

algorithms, the basic cluster score function provided

in the next section obtains from a given similarity ma-

trix, and has polynomial MLE of degree 2 (Boros and

Hammer, 2002, pp. 157, 162). This also keeps the

computational burden at a seemingly reasonable level.

2 CLUSTER SCORE

Given data set N = {1,..., n}, the input of most clus-

tering algorithms (Xu and Wunsch, 2005) is a sym-

metric similarity matrix S ∈ [0, 1]

n×n

, with S

i j

quan-

tifying similarity within data pairs {i, j} ⊂ N. If data

points belong to a Euclidean space, i.e. N ⊂ R

, then

similarities S

i j

= 1−d(i, j) may obtain through a nor-

malized distance d : N ×N → [0,1]. Not only pairs but

also any data subset A ⊆ N may have a measurable in-

ternal similarity (and, possibly, dissimilarity with re-

spect to its complement A

= N\A), interpreted as its

score w(A) as a cluster. How to specify set function

from given matrix S is addressed hereafter.

For 2

= {A : A ⊆ N}, collection {ζ(A,·) : A ∈ 2

}

is a linear basis of the vector space R

of real-

valued functions w on 2

, where ζ : 2

× 2

→ R

is the element of the incidence algebra (Rota, 1964;

Aigner, 1997) of Boolean lattice (2

,∩, ∪) deﬁned by

ζ(A,B) = 1 if B ⊇ A and ζ(A,B) = 0 if B 6⊇ A. That is,

the zeta function. Any w corresponds to linear combi-

nation w(B) =

∑

A∈2

(A)ζ(A,B) =

∑

A⊆B

(A) for

all B ∈ 2

, with M

obius inversion µ

: 2

→ R given

FCTA 2015 - 7th International Conference on Fuzzy Computation Theory and Applications

142

by (note that ⊂ denotes strict inclusion) µ

(A) =

∑

B⊆A

(−1)

|A\B|

w(B)



with ζ(B,A) = (−1)

|A\B|



= w(A) −

∑

B⊂A

(B) (recursion, with w(

0) = 0).

This combinatorial “analog of the fundamental theo-

rem of the calculus” (Rota, 1964) yields the unique

MLE f

: [0,1]

→ R of w, with values w(B) =

= f

(χ

) =

∑

A∈2

∏

i∈A

(i)

(A) =

∑

A⊆B

(A)

on vertices, and f

(q) =

∑

A∈2

∏

i∈A

(A) (1)

on any point q = (q

,. .., q

) ∈ [0, 1]

. Convention-

ally,

∏

i∈

:= 1 (Boros and Hammer, 2002, p. 157).

A quadratic MLE is a polynomial of degree 2, i.e.

(A) = 0 if |A| > 2. Geometrically, this means that

w is a point in a



n+1



-dimensional vector (sub)space,

i.e. w ∈ R

(

n+1

)

, as all its 2

− 1 values are deter-

mined by the values taken by µ

on the n single-

tons and on the





pairs (with n +







n+1



Similarity matrix S factually has only





valid en-

tries (see below), and trying to exploit them beyond

a quadratic form for cluster score w seems clumsy.

Also, S is intended precisely to measure such a score

i j

for all





data pairs. The sought quadratic clus-

ter score function w is thus already deﬁned on such

pairs, i.e. w({i, j}) = S

i j

for all {i, j} ∈ 2

. How

to assign scores w({i}) to singletons {i}, i ∈ N seems

a more delicate matter. If such scores are set equal

to the n entries S

= 1 along the main diagonal, then

obius inversion µ

takes values µ

({i}) = 1 on sin-

gletons and µ

({i, j}) = S

i j

− S

j j

< 0 on pairs

(while µ

(A) = 0 for 1 6= |A| 6= 2). This is a sufﬁ-

cient (but not necessary) condition for sub-additivity,

i.e. w(A ∪B)−w(A)−w(B) ≤ 0 for all A,B ∈ 2

such

that A ∩ B =

0. Then, the trivial partition where each

data point is a singleton block is easily checked to be

optimal. On the other hand, setting w({i}) = 0 for all

i ∈ N yields a M

obius inversion with values µ

(A) ≥ 0

for all A ∈ 2

, and this is sufﬁcient (but not necessary)

for super-additivity, i.e. w(A ∪ B) − w(A) − w(B) ≥ 0

for all A,B ∈ 2

with A ∩ B =

0. Then, it becomes

optimal (and again trivial) to place all n data points

into a unique grand cluster. An interesting alternative

to these two unreasonable situations seems to be

w({i}) =

−

2(n − 1)

∑

l∈N\i

∑

l∈N\i

1 − S

2(n − 1)

In this way, 1 − S

quantiﬁes diversity between i ∈ N

and l ∈ N\i, which must be equally shared among

them. The cluster score of singleton {i} then is the av-

erage of such n − 1 diversities

1−S

,l ∈ N\i collected

by i. M

obius inversion takes values µ

({i}) = w({i})

on singletons and, recursively,

({i, j}) =

i j

− 1

n − 1

−

∑

l∈N\{i, j}

2 − (S

+ S

)

2(n − 1)

on pairs. Note that the cluster score w(A) of any

A ∈ 2

does not depend on those



n−a



entries S

of matrix S such that l, l

∈ A

, where a = |A|.

In particular, if S

i j

= 1 for i ∈ A, j ∈ A\i and S

= 0

for i ∈ A,l ∈ A

, then w(A) =

a(a

−3a+n+1)

2(n−1)

= a ·

n − a

2(n − 1)







1 −

n − a

n − 1



, with

w(A) =

,1, ... ,

−4n+5





for a = 1,2, ... ,n −1,n.

In terms of spectral clustering (see above), the cor-

responding adjacency matrix identiﬁes a subgraph

spanned by vertex subset A which is a clique, and

where all edges have maximum weight, i.e. 1, with re-

markable implications for the eigenvalues of the nor-

malized Laplacian; see (Schaeffer, 2007, p. 42).

This quadratic w, obtained from given similar-

ity matrix S, is conceived as the main example of a

cluster score function. Multilinear objective function-

based clustering deals with generic set functions, pos-

sibly non-quadratic, but reasonably measuring a clus-

ter score of data subsets. In fact, the MLE (1) of set

functions w is where to start for the investigation pro-

posed in the remainder of this work. In view of the

rich literature on pseudo-Boolean methods (Crama

and Hammer, 2011), the MLE of cluster score ap-

pears very suitable for evaluating fuzzy clusters, espe-

cially in that established deﬁnitions of neighborhood

and derivative may be expanded to ﬁt the broader set-

ting formalized in the sequel. Speciﬁcally, while the

n variables of traditional pseudo-Boolean functions

range each in [0,1], the n variables of the novel near-

Boolean form (Rossi, 2015) considered here range

each in a 2

n−1

−1-dimensional unit simplex. The rea-

son for this is the purpose to use the MLE of cluster

score for evaluating not only fuzzy clusters, but also

and most importantly fuzzy clusterings, which are

collections q

,. .., q

∈ [0,1]

of fuzzy clusters, and

thus global score is quantiﬁable as

∑

1≤k≤m

). In

this respect, note that PcM algorithms allow for mem-

bership distributions adding up to quantities < 1 (see

above) for handling outliers. These shall be placed

each in a singleton block of the partition found here

via gradient-based local search. Therefore, member-

ship distributions are like in FcM methods, i.e. rang-

ing in a 2

n−1

− 1-dimensional unit simplex.

Multilinear Objective Function-based Clustering

143

3 FUZZY CLUSTERING

A fuzzy clustering is a m-set q

,. .., q

∈ [0, 1]

fuzzy clusters, with (q

,. .., q

) being i’s member-

ship distribution. The 2

n−1

-set of subsets containing

each i ∈ N is 2

= {A : i ∈ A ∈ 2

}, and ∆

n

,. .., q

n−1



∈ R

n−1

∑

1≤k≤2

n−1

= 1

identiﬁes the corresponding 2

n−1

− 1-dimensional

unit simplex, where

{

,. .., A

n−1

}

= 2

and q

∈ ∆

Deﬁnition 1. A fuzzy cover q speciﬁes, for each

data point i ∈ N, a membership distribution over

the 2

n−1

data subsets A ∈ 2

containing it. Hence

q = (q

,. .., q

) ∈ ∆

, where ∆

= ×

1≤i≤n

∆

Equivalently, q =



0 6= A ∈ 2

∈ [0,1]



is a 2

− 1-set whose elements q



,. .., q



are

n-vectors corresponding to non-empty data subsets

0 6= A ∈ 2

and specifying a membership q

for each

i ∈ N, with q

∈ [0,1] if i ∈ A while q

= 0 if j ∈ A

Fuzzy covers thus generalize traditional fuzzy clus-

terings, as these latter are commonly intended as col-

lections {q

,. .., q

} as above where, in addition, for

every fuzzy cluster q

the associated data subset im-

plicitly is {i : q

> 0}. Conversely, fuzzy covers allow

for situations where 0 < |{i : q

> 0}| < |A| for some

0 6= A ∈ 2

, although an exactness condition intro-

duced below shows that such cases may be ignored.

Fuzzy covers being collections of points in [0,1]

and the MLE f

of w allowing precisely to evaluate

such points, the global score W (q) of any q ∈ ∆

the sum over all its elements q

,A ∈ 2

of their own

score as quantiﬁed by f

(see (1)). That is,

W (q) =

∑

A∈2

) =

∑

A∈2

∑

B⊆A

∏

i∈B

(B)

or W (q) =

∑

A∈2

∑

B⊇A

∏

i∈A

(A). (2)

Example 2. For N = {1,2, 3}, consider cluster scores

w({1}) = w({2}) = w({3}) = 0.2, w({1, 2}) = 0.8,

w({1,3}) = 0.3, w({2, 3}) = 0.6, w(N) = 0.7. Mem-

bership distributions of data points i = 1, 2,3 over

subsets 2

are denoted by q

∈ ∆













, q













, q













If ˆq

= ˆq

= 1, then any membership q

∈ ∆

yields

w({1,2}) +



+ q



({3}) =

= w({1, 2}) + w({3}) = 1. This means that there is a

continuum of fuzzy covers achieving maximum score:

W ( ˆq

, ˆq

) = 1 independently from q

. In order to

select the one

q = ( ˆq

, ˆq

) where ˆq

= 1, attention

must be placed only on exact ones, deﬁned hereafter.

For any two fuzzy covers q = {q

0 6= A ∈ 2

}

and

q = { ˆq

0 6= A ∈ 2

}, deﬁne

q to be a shrinking

of q if there is a subset A, with

∑

i∈A

> 0, such that

ˆq



if B 6⊆ A

0 if B = A

for all B ∈ 2

,i ∈ N,

∑

B⊂A

ˆq

= q

∑

B⊂A

for all i ∈ A.

In words, a shrinking reallocates the whole member-

ship mass

∑

i∈A

> 0 from A ∈ 2

to all proper sub-

sets B ⊂ A, involving all and only those data points

i ∈ A with strictly positive membership q

> 0.

Deﬁnition 3. Fuzzy cover q ∈ ∆

is exact as long as

W (q) 6= W (

q) for all shrinkings

q of q.

Proposition 4. If q is exact, then for all A ∈ 2





i ∈ A : q

> 0





∈ {0,|A|}.

Proof. For

0 ⊂ A

(q) =



i : q

> 0



⊂ A ∈ 2

, with

α = |A

(q)| > 1, notice that

) =

∑

B⊆A

(q)

∏

i∈B

(B). Let shrinking

with ˆq

= q

if B

6∈ 2

(q)

, satisfy conditions

∑

B∈2

∩2

(q)

ˆq

= q

∑

B∈2

∩2

(q)

for all i ∈ A

(q)

and

∏

i∈B

ˆq

∏

i∈B

∏

i∈B

for all B ∈ 2

(q)

,|B| > 1.

These are 2

− 1 equations with

∑

1≤k≤α





> 2

variables ˆq

,B ⊆ A

(q). Thus there is a continuum

of solutions, each providing precisely a shrinking

where

∑

B∈2

(q)

( ˆq

) = f

) +

∑

B∈2

(q)

This entails that q is not exact.

For given w, the global score of any fuzzy cover

also attains on many fuzzy clusterings. This justiﬁes

the following (in line with standard terminology).

Deﬁnition 5. Fuzzy clusterings are exact covers.

The global score of any fuzzy clustering is shown

below to also attain on some hard clustering, thereby

expanding a result on extremizers of pseudo-Boolean

functions (Boros and Hammer, 2002, p. 163).

FCTA 2015 - 7th International Conference on Fuzzy Computation Theory and Applications

144

4 HARD CLUSTERING

Hard clusterings or partitions of N (Aigner, 1997) are

fuzzy clusterings where q

∈ {0,1} for all A ∈ 2

and

all i ∈ A. Among the maximizers of any objective

function W as above there always exist fuzzy clus-

terings (q

,. .., q

) ∈ ∆

such that q

∈ ex(∆

) for all

i ∈ N, where ex(∆

) denotes the 2

n−1

-set of extreme

points of ∆

. For q ∈ ∆

,i ∈ N, let q = q

−i

, with

∈ ∆

and q

−i

∈ ∆

N\i

= ×

j∈N\i

∆

. Then, for any w,

W (q) =

∑

A∈2

) +

∑

∈2

) =

∑

A∈2

∑

B⊆A\i

∏

j∈B



(B ∪ i) + µ

(B)



∑

∈2

∑

⊆A

∏

∈B

)

at all q ∈ ∆

and for all i ∈ N. Now deﬁne

−i

) =

∑

A∈2

∑

B⊆A\i

∏

j∈B

(B ∪ i)

−i

) =

∑

A∈2

∑

B⊆A\i

∏

j∈B

(B)

∑

∈2

∑

⊆A

∏

∈B

)

yielding W (q) = W

−i

) +W

−i

). (3)

Proposition 6. For all q ∈ ∆

, there are q, q ∈ ∆

such that



(i) W (q) ≤ W (q) ≤ W (q) and,

(ii) q

∈ ex(∆

) for all i ∈ N.

Proof. For all i ∈ N and q

−i

∈ ∆

N\i

, deﬁne w

−i

→ R by

−i

(A) =

∑

B⊆A\i

∏

j∈B

(B ∪ i). (4)

Let A

−i

= arg maxw

−i

and A

−

−i

= arg minw

−i

, not-

ing that A

−i

0 6= A

−

−i

at all q

−i

. Most importantly,

) =

∑

A∈2



· w

−i

(A)



= hq

−i

i, (5)

where h·,·i denotes scalar product. Thus for given

membership distributions of all j ∈ N\i, global score

is affected by i’s membership distribution through a

scalar product. In order to maximize (or minimize)

W by suitably choosing q

for given q

−i

, the whole

of i’s membership mass must be placed over A

−i

(or

−

−i

), anyhow. Hence there are precisely |A

−i

| > 0

(or |A

−

−i

| > 0) available extreme points of ∆

. The

following procedure selects (arbitrarily) one of them.

ROUNDUP(w, q)

Initialize: Set t = 0 and q(0) = q.

Loop: While there is a i ∈ N with q

(t) 6∈ ex(∆

set t = t + 1 and:

(a) select some A

∗

∈ A

−i

(t)

(b) deﬁne, for all j ∈ N,A ∈ 2

(t) =







(t − 1) if j 6= i

1 if j = i and A = A

∗

0 otherwise

Output: Set q = q(t).

Every change q

(t − 1) 6= q

(t) = 1 (for any

i ∈ N, A ∈ 2

) induces a non-decreasing variation

W (q(t)) − W (q(t − 1)) ≥ 0. Hence, the sought q is

provided in at most n iterations. Analogously, replac-

ing A

−i

with A

−

−i

yields the sought minimizer q.

Remark 7. For i ∈ N, A ∈ 2

, if all j ∈ A\i 6=

0 sat-

isfy q

= 1, then (4) yields w

−i

(A) = w(A) −w(A\i),

while w

−i

({i}) = w({i}) regardless of q

−i

. For

quadratic w obtained above from similarity matrix S,

−i

(A) = w({i}) +

∑

j∈A\i

({i, j}).

If the global score of fuzzy clusterings is quan-

tiﬁed as the sum over constituents fuzzy clusters of

their MLE-score, then for any w there are hard clus-

terings among both the maximizers and minimizers.

This seems crucial because many applications may

be modeled in terms of set partitioning, and in such

a combinatorial optimization problem fuzzy cluster-

ing is not feasible. An important example is winner

determination in combinatorial auctions (Sandholm,

2002), where a set N of items to be sold must be

partitioned into bundles towards revenue maximiza-

tion. The maximum bid received for each bundle

0 6= A ⊆ N deﬁnes the input set function w. The above

result entails that if the objective function is multilin-

early extended over the continuous domain of fuzzy

clusterings, then any found solution can be promptly

adapted to the restricted domain of partitions, with no

score loss. The problem can thus be approached from

a geometrical perspective, allowing for novel search

strategies. Partitions P = {A

,. .., A

|P|

} ⊂ 2

of N are

families of pairwise disjoint subsets whose union is N,

i.e. N = ∪

1≤k≤|P|

and A

∩ A

0,1 ≤ k < l ≤ |P|.

Any P corresponds to the collection {χ

: A ∈ P} of

Multilinear Objective Function-based Clustering

145

those |P| hypercube vertices identiﬁed by the charac-

teristic functions of its blocks (see above). Partitions

P can also be seen as p ∈ ∆

where p

= 1 for all

A ∈ P,i ∈ A. The above ﬁndings yield the following.

Corollary 8. For any w, some partition P satisﬁes

W (p) ≥W (q) for all q ∈ ∆

, with W (p) =

∑

A∈P

w(A).

Proof. Follows from propositions 4 and 6.

A further remark concerns cluster validity (Wang

and Zhang, 2007), with focus on those indices that

validate fuzzy clusterings by relying exclusively on

membership distributions. As already observed, a ba-

sic argument is that the more such distributions are

concentrated, the less ambiguous is the fuzzy classi-

ﬁcation. Evidently, hard clusterings provide n distri-

butions each concentrated on a unique extreme point

of the associated unit simplex. The above result indi-

cates that if global score is evaluated through MLE,

then validation may ignore membership distributions,

as the score of any optimal fuzzy clustering also ob-

tains by means of a hard one.

5 LOCAL SEARCH

Deﬁning global maximizers is clearly immediate.

Deﬁnition 9. Fuzzy clustering

q ∈ ∆

is a global

maximizer if W (

q) ≥ W (q) for all q ∈ ∆

Concerning local maximizers, consider a vector

ω = (ω

,. .., ω

) ∈ R

of strictly positive weights,

with ω

∑

j∈N

, and focus on the equilibrium

(Mas-Colell et al., 1995) of the game where data

points are players who strategically choose their

memberships distribution q

∈ ∆

while being re-

warded with fraction

W (q

,. .., q

) of the global

score attained at any strategy proﬁle (q

,. .., q

Deﬁnition 10. Fuzzy clustering

q ∈ ∆

is a local

maximizer if W

( ˆq

−i

) ≥ W

−i

) for all q

∈ ∆

and all i ∈ N (see (3)).

This deﬁnition of local maximizer entails that the

neighborhood N (q) ⊂ ∆

of any q ∈ ∆

N (q) =

[

i∈N

q :

q = ˜q

−i

, ˜q

∈ ∆

Deﬁnition 11. The (i,A)-derivative of W at q ∈ ∆

∂W (q)/∂q

= W (q(i, A)) −W (q(i, A)) =

= W



(i,A)|q

−i

(i,A)



−W



(i,A)|q

−i

(i,A)



with q(i,A) =



(i,A), ... ,q

(i,A)



given by

(i,A) =







for all j ∈ N\i,B ∈ 2

1 for j = i,B = A

0 for j = i,B 6= A

and q(i,A) =



(i,A), ... ,q

(i,A)



given by

(i,A) =



for all j ∈ N\i,B ∈ 2

0 for j = i and all B ∈ 2

thus ∇W (q) = {∂W(q)/∂q

: i ∈ N,A ∈ 2

} ∈ R

n−1

is the (full) gradient of W at q. The i-gradient

∇

W (q) ∈ R

n−1

of W at q = q

−i

is set function

∇

W (q) : 2

→ R deﬁned by ∇

W (q)(A) = w

−i

(A)

for all A ∈ 2

, where w

−i

is given by (4).

Remark 12. Membership distribution q

(i,A) is the

null one: its 2

n−1

entries are all 0, hence q

(i,A) 6∈ ∆

The setting obtained thus far allows to conceive

searching for a local maximizer hard clustering q

∗

from given fuzzy clustering q as initial candidate so-

lution, and while maintaing the whole search within

the continuum of fuzzy clusterings. This idea may be

speciﬁed in alternative ways yielding different local

search methods. One possibility is the following.

LOCALSEARCH(w, q)

Initialize: Set t = 0 and q(0) = q, with require-

ment |{i : q

> 0}| ∈ {0, |A|} for all A ∈ 2

Loop 1: While 0 <

∑

i∈A

(t) < |A| for a A ∈ 2

set t = t + 1 and

(a) select a A

∗

(t) ∈ 2

such that

∑

i∈A

∗

(t)

−i

(t−1)

∗

(t)) ≥

∑

j∈B

− j

(t−1)

(B)

for all B ∈ 2

such that 0 <

∑

i∈B

(t) < |B|,

(b) for i ∈ A

∗

(t) and A ∈ 2

, deﬁne

(t) =



1 if A = A

∗

(t),

0 if A 6= A

∗

(t),

∗

(t) and A ∈ 2

with A ∩ A

∗

(t) =

deﬁne q

(t) = q

(t − 1)+







w(A)

∑

B∈2

B∩A

∗

(t)6=

(t − 1)













∑

∈2

∩A

∗

(t)=

w(B

)







−1

(d) for j ∈ N\A

∗

(t) and A ∈ 2

with A ∩ A

∗

(t) 6=

deﬁne

(t) = 0.

Loop 2: While q

(t) = 1,|A| > 1 for a i ∈ N and

w(A) < w({i}) + w(A\i), set t = t + 1 and deﬁne:

(t) =



1 if |

A| = 1

0 otherwise

for all

A ∈ 2

(t) =



1 if B = A\i

0 otherwise

for all j ∈ A\i,B ∈ 2

(t) = q

(t − 1) for all j

∈ A

B ∈ 2

FCTA 2015 - 7th International Conference on Fuzzy Computation Theory and Applications

146

Output: Set q

∗

= q(t).

Both ROUNDUP and LOCALSEARCH yield a se-

quence q(0),.. .,q(t

∗

) = q

∗

where q

∗

∈ ex(∆

) for all

i ∈ N. In the former at the end of each iteration t

the novel q(t) ∈ N (q(t − 1)) is in the neighborhood

of its predecessor. In the latter q(t) 6∈ N (q(t − 1))

in general, as in |P| ≤ n iterations of Loop 1 a parti-

tion {A

∗

(1),. .., A

∗

(|P|)} = P is generated. Selected

clusters or blocks A

∗

(t) ∈ 2

, t = 1, ... , |P| are any

of those where the sum over data points i ∈ A

∗

(t)

of (i,A

∗

(t))-derivatives ∂W (q(t − 1))/∂q

∗

(t)

(t − 1)

is maximal. Once a block A

∗

(t) is selected, then

lines (c) and (d) make all data points j ∈ N\A

∗

(t)

redistribute the entire membership mass currently

placed on subsets A

∈ 2

with non-empty intersec-

tion A

∩ A

∗

(t) 6=

0 over those remaining A ∈ 2

such that, conversely, A ∩ A

∗

(t) =

0. The redistri-

bution is such that each of these latter gets a frac-

tion w(A)/

∑

B∈2

:B∩A

∗

(t)=

w(B) of the newly freed

membership mass

∑

∈2

∩A

∗

(t)6=

(t − 1). The

subsequent Loop 2 checks whether the partition gen-

erated by Loop 1 may be improved by exctracting

some outliers from existing blocks and putting them

in singleton blocks of the ﬁnal output. An outlier ba-

sically is a data point displaying very unusual fea-

tures. In the limit, cluster score w may be such that

for some data points i ∈ N global score decreases

when i joins any cluster A ∈ 2

,|A| > 1, that is to say

w(A)− w(A\i)− w({i}) =

∑

B∈2

A\i

:|B|>1

(B) < 0.

Proposition 13. Output q

∗

of LOCALSEARCH(W, q)

is a local maximizer.

Proof. It is plain that the output corresponds to a par-

tition P. With the notation of corollary 8 in section

4, q

∗

= p. Accordingly, any data point i ∈ N is ei-

ther in a singleton cluster {i} ∈ P or else in a cluster

A ∈ P,i ∈ A such that |A| > 1. In the former case,

any membership reallocation deviating from p

{i}

= 1,

given memberships p

, j ∈ N\i, yields a cover (fuzzy

or hard) where global score is the same as at p, be-

cause

∏

j∈B\i

= 0 for all B ∈ 2

\A (see example

2 above). In the latter case, any membership reallo-

cation q

deviating from p

= 1 (given memberhips

, j ∈ N\i) yields a cover which is best seen by dis-

tinguishing between 2

\A and A. Also recall that

w(A) − w(A\i) =

∑

B∈2

A\i

(B). Again, all mem-

bership mass

∑

B∈2

> 0 simply collapses on sin-

gleton {i} because

∏

j∈B\i

= 0 for all B ∈ 2

\A.

Therefore, W (p) −W (q

−i

) = w(A) − w({i})+

−





∑

B∈2

A\i

:|B|>1

(B) +

∑

∈2

A\i

)







− q



∑

B∈2

A\i

:|B|>1

(B).

Now assume that q is not a local maximizer, i.e.

W (p) −W (q

−i

) < 0. Since p

− q

> 0 (because

= 1 and q

∈ ∆

is a deviation from p

), then

∑

B∈2

A\i

:|B|>1

(B) = w(A) − w(A\i) − w({i}) < 0.

Hence q cannot be the output of Second Loop.

In local search methods, the chosen initial candi-

tate solution determines what neighborhoods shall be

visited. The range of the objective function in a neigh-

borhood is a set of real values. In a neighborhood

N (p) of a hard clustering p or partition P only those

∑

A∈P:|A|>1

|A| data points i ∈ A in non-sigleton blocks

A ∈ P,|A| > 1 can modify global score by reallocat-

ing their membership. In view of the above proof, the

only admissible variations obtain by deviating from

= 1 with an alternative membership distribution q

such that q

∈ [0, 1), with W (q

−i

) − W (p) equal

to (q

− 1)

∑

B∈2

A\i

,|B|>1

(B) + (1 − q

)w({i}).

Hence, choosing partitions as initial candidate solu-

tions of LOCALSEARCH is evidently poor. A sen-

sible choice should conversely allow the search to

explore different neighborhoods where the objective

function may range widely. A simplest example of

such an initial candidate solution is uniform distribu-

tion q

= 2

1−n

. On the other hand, the input of local

search fuzzy clustering algorithms is commonly de-

sired to be close to a global optimum, i.e. a max-

imizer in the present setting. This translates here

into the idea of deﬁning a suitable input by means

of cluster score function w. Along this line, consider

= w(A)/

∑

B∈2

w(B), yielding

w(A)

w(B)

for

all A,B ∈ 2

∩ 2

and all i, j ∈ N.

With a suitable initial candidate solution, the

search may be restricted to explore only a maximum

number of fuzzy clusterings, thereby containing (to-

gether with the quadratic MLE of cluster score w) the

computational burden. In particular, if q(0) is the

ﬁnest partition {{1},.. .,{n}} or q

{i}

(0) = 1 for all

i ∈ N, then the search does not explore any neighbor-

hood at all, and such an input coincides with the out-

put. More reasonably, let A

max

= {A

,. .., A

} denote

the collection of maximal data subsets where input

memberships are strictly positive. That is, q

> 0

for all i ∈ A

,1 ≤ k

≤ k as well as q

= 0 for all

B ∈ 2



∪ · ·· ∪ 2



and all j ∈ B. Then, the out-

put shall be a partition P each of whose blocks A ∈ P

satisﬁes A ⊆ A

for some 1 ≤ k

≤ k. Hence, by suit-

ably choosing the input q, LOCALSEARCH outputs

Multilinear Objective Function-based Clustering

147

a partition with no less than some maximum desired

number k(q) blocks.

6 CONCLUSIONS

This paper approaches objective function-based fuzzy

clustering by ﬁrstly eliciting a real-valued cluster

score function, quantifying the positive worth of data

subsets in the given classiﬁcation problem. Cluster-

ing is next interpreted in terms of combinatorial opti-

mization via set partitioning. The proposed gradient-

based local search relies on a novel expansion of the

MLE of near-Boolean functions (Rossi, 2015) over

the product of n simplices, each of which is 2

n−1

− 1-

dimensional, n being the number of data. The method

needs not the input to specify a desiderd number of

clusters, as this latter is determined autonomously

through optimization, and applies to any classiﬁcation

problem, handling data sets not necessarily included

in a Euclidean space: proximities between data points

and within clusters may be quantiﬁed in any conceiv-

able way, including information theoretic measure-

ment (Pirr

o and Euzenat, 2010).

REFERENCES

Aigner, M. (1997). Combinatorial Theory. Springer.

Reprint of the 1979 Edition.

Bensaid, A., Hall, L., Bezdek, J., Clarke, L., Silbiger,

M., Arrington, J., and Murtagh, R. (1996). Validity-

guided (re)clustering with applications to image seg-

mentation. IEEE Trans. on Fuzzy Sys., 4(2):112–123.

Bezdek, J. and Pal, S. (1992). Fuzzy Models for Pattern

Recognition. IEEE Press.

Boros, E. and Hammer, P. (2002). Pseudo-Boolean opti-

mization. Discrete App. Math., 123:155–225.

Cottrell, M., Hammer, B., Hasenfuß, A., and Villmann, T.

(2006). Batch and median neural gas. Neural Net-

works, 19(6-7):762–771.

Crama, Y. and Hammer, P. L. (2011). Boolean Functions:

Theory, Algorithms, and Applications. Cambridge

University Press.

Du, K.-L. (2010). Clustering: a neural network approach.

Neural Networks, 23:89–107.

Kashef, R. and Kamel, M. S. (2010). Cooperative cluster-

ing. Pattern Recognition, 43(6):2315–2329.

Korte, B. and Vygen, J. (2002). Combinatorial Optimiza-

tion. Theory and Algorithms. Springer.

Krishnapuram, R. and Keller, J. (1996). The possibilis-

tic c-means algorithm: insights and recommendations.

IEEE Transactions on Fuzzy Systems, 4(3):148–158.

Lughofer, E. (2008). Extensions of vector quantization for

incremental clustering. Pattern Recognition, 41:995–

1011.

Mas-Colell, A., Whinston, M. D., and Green, J. R. (1995).

Microeconomic Theory. Oxford University Press.

enard, M. and Eboueya, M. (2002). Extreme physical

information and objective function in fuzzy clustering.

Fuzzy Sets and Systems, 128:285–303.

Ng, A. Y., Jordan, M. I., and Weiss, Y. (2002). On spectral

clustering: analysis and an algorithm. In Dietterich,

T. G., Becker, S., and Ghahramani, Z., editors, Ad-

vances in Neural Information Processing Systems 14,

volume 2, pages 849–856. MIT Press.

Pal, N. and Bezdek, J. (1995). On cluster validity for the

fuzzy c-means model. IEEE Transactions on Fuzzy

Systems, 3(3):370–379.

Pardalos, P., Prokopyev, O., and Busygin, S. (2006). Con-

tinuous approaches for solving discrete optimization

problems. In Appa, G., Pitsoulis, L., and Williams,

H., editors, Handbook on Modeling for Discrete Opti-

mization, pages 39–60. Springer.

Pirr

o, G. and Euzenat, J. (2010). A feature and information

theoretic framework for semantic similarity and relat-

edness. In Proceedings of The Semantic Web Confer-

ence ISWC 2010, pages 615–630. LNCS 6496.

Rezaee, M., Lelieveldt, B., and Reiber, J. (1998). A new

cluster validity index for the fuzzy c-means. Pattern

Recognition Letters, 19:237–246.

Rossi, G. (2015). Continuous set packing problems and

near-Boolean functions. arXiv 1509.07986v1. Sub-

mitted to ICPRAM 2016.

Rota, G.-C. (1964). On the foundations of combinatorial

theory I: theory of M

obius functions. Z. Wahrschein-

lichkeitsrechnung u. verw. Geb., 2:340–368.

Roubens, M. (1982). Fuzzy clustering algorithms and their

cluster validity. European Journal of Operational Re-

search, 10(3):294–301.

Sandholm, T. (2002). Algorithm for optimal winner deter-

mination in combinatorial auctions. Artiﬁcial Intelli-

gence, (135):1–54.

Schaeffer, S. E. (2007). Graph clustering. Computer Sci-

ence Review, 1(1):27–64.

Shawe-Taylor, J. and Cristianini, N. (2004). Kernel Method

for Pattern Analysis. Cambridge University Press.

Slonim, N., Atwal, S. G., Tka ˇcik, G., and Bialek, W. (2005).

Information-based clustering. PNAS, 102(51):18297–

18302.

Valente de Oliveira, J. and Pedrycz, W. (2007). Advances in

fuzzy clustering and its applications. Wiley.

von Luxburg, U., Belkin, M., and Bousquet, O. (2008).

Consistency of spectral clustering. The Annals of

Statistics, 36(2):555–586.

Wang, W. and Zhang, Y. (2007). On fuzzy cluster validity

indices. Fuzzy Sets and Systems, 158:2095–2117.

Wu, S. and Chow, T. W. S. (2004). Clustering of the self-

organizing map using a cluster validity index based on

inter-cluster and intra-cluster density. Pattern Recog-

nition, 37:175–188.

Xie, X. and Beni, G. (1991). Validity measure for fuzzy

clustering. IEEE Transactions on Pattern Analysis

and Machine Intelligence, 13(8):841–847.

FCTA 2015 - 7th International Conference on Fuzzy Computation Theory and Applications

148

Xu, R. and Wunsch, D. (2005). Survey of clustering algo-

rithms. IEEE Trans. on Neural Net., 16(3):645–678.

Zahid, N., Abouelala, O., Limouri, M., and Essaid,

A. (2001). Fuzzy clustering based on k-nearest-

neighbours rule. Fuzzy Sets and Sys., 120:239–247.

Multilinear Objective Function-based Clustering

149
