Analyzing Taiwan Bridge Management System for Decision Making

in Bridge Maintenance

A Big Data Approach

Nie-Jia Yau and Yu-Han Chuang

Graduate Institute of Construction Engineering and Management, National Central University,

300 Jhongda Rd., Jhongli District, Taoyuan City, Taiwan

Keywords: Bridge Maintenance, Bridge Management, Big Data, Decision Making.

Abstract: The Taiwan Bridge Management System (TBMS) has been online for 15 years and has an inventory of

33,275 bridges, including all kinds of bridges and culverts in Taiwan. Currently, the number of fields in all

tables in the databases of TBMS is around 6,500 with more than 3 million data records in its databases.

Meanwhile, bridge inspection data and maintenance data are increasing at a speed of 15,000 records

annually. Thus, the TBMS databases are deemed as “Big Data.” There are more than 9,500 bridges that are

over 20 years old with another 7,200 bridge having unknown built years in the TBMS. The bridges in

Taiwan have stepped into the stage where maintenance is crucial and frequently required. Therefore, this

research aims at analysing the database in the TBMS using “Big Data” approach for determining

maintenance strategies for these bridges. This paper describes results of the first year’s research efforts.

Relevant literature in bridge maintenance, prioritization, and life-cycle bridge management were firstly

reviewed. Concepts, theories, techniques, and available software for analysing “Big Data” were also

intensively examined and summarized. In next year, functions will be programmed and applied to the

TBMS databases using appropriate “Big Data” software to obtain useful information in bridge deterioration,

repair methods, and maintenance costs.

1 INTRODUCTION

The Taiwan Bridge Management System (TBMS)

has been online since 2000 (TBMS, 2014). Its

inventory includes 33,275 bridges with 6,524 fields

in all tables, and the total amount of data records is

3,457,274 which increase 15,000 records annually.

Among these fields, there are 475 fields containing

kernel management information of a bridge such as

inventory data, inspection results, and repair records.

Thus, the databases in the TBMS have met the

definition of “Big Data.”

Table 1 shows the amount of bridge components

which are deemed necessary for maintenance

actions. It also shows that the number of seriously

deteriorated components still increase gradually,

even though maintenance activities have been

expedited by responsible agencies for many of such

components.

Due to limited budgets, especially for local

governments, prioritization of bridge maintenance is

Table 1: Amount of bridge components need maintenance

actions.

Road level 2010 2011 2012 2013 2014

City/

County

1,200 463 575 578 857

Freeway/

Highway

17 18 16 24 35

Railways 0 26 28 3 2

Total 1,217 507 619 605 894

always a tough task for the bridge management

agencies, in addition to determining which option is

better between maintaining and rebuilding of the

bridge. Life-cycle cost analysis is a feasible solution

for such problem; however, such technique requires

an appropriate deterioration prediction model which

does not yet implemented in the TBMS.

In order to effectively evaluate cost efficiency of

repairing work and rebuilding of bridge, this

research aims to analyze the TBMS databases to

obtain characteristics of bridge deterioration in

Taiwan that are useful for determining maintenance

Yau N. and Chuang Y..

Analyzing Taiwan Bridge Management System for Decision Making in Bridge Maintenance - A Big Data Approach.

DOI: 10.5220/0005554000730078

In Proceedings of the 10th International Conference on Software Engineering and Applications (ICSOFT-EA-2015), pages 73-78

ISBN: 978-989-758-114-4

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

strategies. This two-year research project has two

stages. For the first year, in addition to literature

review in bridge maintenance, techniques and

available software related to big data are thoroughly

investigated; and application of these techniques and

software to the TBMS databases is planned to be

performed in the second year.

For this research, it is anticipated to obtain

maintenance information such as repairing method,

repairing cost, maintenance period, progressive of

deterioration conditions, and factors that trigger the

repairing actions. Finally, a decision support and

evaluation model for rebuilding of deteriorated

bridges will be established from this research.

2 LITERATURE REVIEW

2.1 Factors caused Bridge

Deterioration in Taiwan

Su (Su, 2003) collected 935 bridge inspection data in

Taichung to analyze the relevancy between bridge

deterioration and its environment by a logistic

regression. The study discovered that the age of

bridge, the distance to sea, and using of I-type

girders are the major factors that caused

deterioration. In addition, Lin (Lin, 2007)

successfully established a service life prediction

model for expansion joint that obtained a 9%

difference between the predicted and the actual

service year, he also discovered that horizontal

acceleration, number of spans and traffic flow are

the most significant factors in determining the

service life of an expansion joint.

2.2 Prioritization of Bridge

Maintenance

For both central and local governments, distribution

of bridge maintenance budgets is always a difficult

task. Chen (Chen, 2007) established a model to

calculate a danger factor (DF) for a bridge by

assigning weights to its major components based on

their deterioration ratings multiplied by a traveller’s

factor determined by level of road that bridge was

on; then the component having the highest value was

normalized to represent the DF of the bridge. The

DF can be used for both prioritization of bridge

maintenance and distribution of maintenance

budgets. This model is currently incorporated by the

TBMS.

2.3 Effectiveness of Maintenance

Budget

Budget spent for bridge maintenance needs to be

effective. Feasible ways to check the effectiveness

of is to investigating results of maintenance within a

time period or under limited budgets. Weng (Weng,

2009) compared the same amount of cost spent

within a time period for fixing or replacing certain

components to find which way is more effective.

Lay (Lay, 2001) developed a maintenance cost

analysis model that allowed the user to input the

amount of budget for a given number of years, and

the model would allocate the budget to the bridges to

achieve the most effective result. Huang (Huang,

2007) proposed a concept of concurrently

maintaining multiple components on a bridge to

reduce the overall time spent for repairing various

components of the bridge.

2.4 Bridge Life-cycle Management

Many researchers have promoted life cycle cost

concept for bridge management for many years.

However, current practice in most bridge

construction bids still not yet considers maintenance

costs. Zhu (Zhu, J. and B. Liu, 2013) established an

optimal model for calculating bridge total life cycle

cost for RC beam bridges, considering travellers’

cost and social cost. Safi (Safi, M., H. Sundquist,

and R. Karoumi, 2014) analyzed the Sweden bridge

management system to find a total maintenance cost

for bridge components. The research results also

showed that the total maintenance cost is 15% to

25% of life cycle cost of a bridge, while different

types of bridges may have more than 50% difference

in construction cost.

2.5 Summary

Several studies in deterioration factors and

maintenance prioritization have obtained certain

valuable results for the bridges in Taiwan. However,

actual maintenance frequency, costs, and methods of

various bridge components could be used to generate

a life cycle cost model which is crucial to obtain a

more effective maintenance strategy. In addition,

decision making between continuing maintenance

actions and rebuilding of a new bridge still not yet

clarified. Thus, answers to these doubts by digging

into the actual inspection results and maintenance

records in the TBMS have become the major

objectives of this research.

ICSOFT-EA2015-10thInternationalConferenceonSoftwareEngineeringandApplications

3 TAIWAN BRIDGE

MANAGEMENT SYSTEM

(TBMS)

Supported by the Institute of transportation, Ministry

of Transportations and Communications, the TBMS

was developed by National Central University in

1999. TBMS is used by all the governmental

agencies which are responsible for bridge

management. There are 9 modules in TBMS, such as

Inventory, Inspection Data, Maintenance Records,

Statistic, Decision Support, etc., as shown in Figure

1. This research focuses on data in three of these

modules; they are Inventory, Inspection Data, and

Maintenance Records modules, as described below.

Figure 1: Major functional modules of the TBMS.
