Gesture Recognition Technologies for Gestural Know-how

Management

Preservation and Transmission of Expert Gestures in Wheel Throwing Pottery

Alina Glushkova

1,2,3

and Sotiris Manitsaris

2,3,4

Multimedia Technologies and Computer Graphics Lab., University of Macedonia, Thessaloniki, Greece

Rural Space Lab., University of Thessaly, School of Engineering, Volos, Greece

Robotics Lab, MINES ParisTech, PSL Research University, Paris, France

Equipe Interaction Son, Musique, Mouvement, Institut de Recherche en Coordination Acoustique/Musique, Paris, France

Keywords: Motion Capture, Gesture Recognition, Know-how Management, Expert Gesture, Sensorimotor Feedback.

Abstract: The acquisition of gestural know-how in manual professions constitutes a real challenge since it passes from

master to learner, through a many years long « in person » transmission. However this binding transmission

is not always possible for practical reasons; the learner must train himself alone, by using traditional

Knowledge Management tools such as e-documentation and multimedia contents. These tools present

important limitations, only providing the learner expert knowledge in a descriptive way, with a low

attractiveness and interaction level, without any sensorimotor feedback. It thus becomes crucial to find

novel ways to preserve and transmit know-how. In this work we present the idea of a methodological

framework for gestural know-how management in wheel throwing pottery, based on motion capture and

gesture recognition technologies. In combination with machine learning techniques, they permit to model

the practical, cinematic aspects of potter’s expertise. These technologies can be used to compare experts'

and learners' simulated performances and to provide real-time feedback to the learner, guiding him in the

adjustment of his gestures. The final goal is to propose a novel and highly interactive embodied pedagogical

application for gestural know-how transmission, supporting « self » trainings, and making them more

efficient.

1 INTRODUCTION

In actual context of globalisation and knowledge-

based economy it becomes more and more important

to manage knowledge efficiently. Providing tools to

deliver the right information to the right person at

the right moment in the most appropriate way

becomes the subject of Knowledge Management

(KM) discipline. But what happens when we want to

expand this idea not only to knowledge in general,

but also to know-how, to precise practical tasks and

gestures? In this case we can talk about Know-How

Management (KHM).

Issues linked to KHM have been studied by

different scientific fields such as anthropology,

ethnology and sociology. Their main goal was to

identify the components of know-how and to

propose the most efficient way for their

transmission. Methods and tools have been thus

proposed delivering know-how to the learner mostly

through documents and multimedia courses. In this

work we present a methodological framework for

gestural know-how management based on motion

capture and gesture recognition technologies. The

methodology has been applied in wheel throwing

pottery.

2 STATE OF THE ART

2.1 Traditional KM Tools Used for

KHM

Traditionally, gestural know-how is transmitted “in

person” from master to learner, physically present in

the same place at the same time. To better

understand “in person” transmission and to propose

pedagogical material it has been studied from an

ethnological and anthropological point of view

(Chevallier, 1991). Expert technical gestures have

been analysed; their parameters such as trajectory

405

Glushkova A. and Manitsaris S..

Gesture Recognition Technologies for Gestural Know-how Management - Preservation and Transmission of Expert Gestures in Wheel Throwing Pottery.

DOI: 10.5220/0005475904050410

In Proceedings of the 7th International Conference on Computer Supported Education (CSEDU-2015), pages 405-410

ISBN: 978-989-758-107-6

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

and acceleration have been defined (Bril, 2011).

Although “in person” transmission is not always

possible for practical reasons such as geographical

distance between the master and the learner, low

expert’s availability/accessibility or other factors.

Based on technological advances of the last

decade, ethnographists have started to use traditional

KM digital tools to create pedagogical content. E-

documentation has been enriched with videos,

images, audio recordings, to support teaching and

“self” trainings without master intervention. In

China a digital archive has been created presenting a

traditional method of weaving with a Bamboo

(Wang et al, 2011). In more industrial context, in a

plant of electric energy production, a video camera

has been placed on the helmet of the expert worker

to record his gestures. These videos have been used

to propose training material (Le Bellu, 2010).

However e-documentation presents two

important limitations: a) it provides limited

information about expert gesture’s execution

reducing it into two dimensions and b) it is based on

passive multimedia content (listening and watching)

and e-courses (speaking and writing) while know-

how learning is achieved through doing (Dale, 1969)

and through interaction with the master. When using

e-documentation the learner only receives

multimedia messages and cannot interact with the

pedagogical tool.

2.2 Gesture Recognition Technologies

for KH Capturing

Gesture recognition technologies (GRT) can be used

to overcome some of the limitations mentioned

above. They permit to capture biomechanical aspects

of a gesture and not only a two dimensional image

of it, providing a data that can be analysed and

modelled.

For example in artistic applications, a marker-

based approach has been used to capture and analyse

violin player’s performance (Rasamimanana et al.,

2009). However this technology is expensive and

not robust to occlusions that can easily occur in

other applications. For joints tracking and dancing

movements recognition, low cost technology has

been used, such as a depth camera (Raptis, 2011).

But this marker-less technology cannot provide

precise information about hand gestures and is also

self and scene occlusion dependent. Contrariwise,

wireless inertial sensors are occlusion independent

and well adapted to record continuously hand

gestures. They have been used for capturing,

modeling and recognition of expert gestures in

wheel throwing pottery in our previous study

(Manitsaris et al, 2014). However in research works

mentioned above the use of GRT is limited to

capturing expert gestures for know-how

preservation, while in the methodology described in

this paper we will enter the phase coming after and

will propose a methodology for know-how

transmission.

2.3 Sensorimotor Feedback Guidance

for KH Transmission

The use of GRT can also permit to overcome the

second disadvantage of traditional KHM tools,

proposing an interaction between the learner and the

pedagogical application. According to Piaget’s

theory (Piaget, 1976) embodied intelligence is

acquired through this interaction with the

environment, through senses and experiences.

Some studies in fields like sports or art have

been inspired from this statement. Taking inputs

from motion capture, sonic feedback is provided to a

speed skater to make him correct a regular error

observed in his performance (Godbout and Boyd,

2010). In i-maestro project, violin player’s

movements are analysed and instructive optical

feedback is given to help him to improve his

techniques (Ng et al., 2007). However in most of

existing studies where feedback is used in a

pedagogical perspective, reference gestures are

characterised by simple trajectories, or periodicity

and the feedback is provided based on a simple

tracking of body joints. In our approach we aim to

use machine learning techniques to model more

complex expert gestures, such as wheel throwing

pottery ones that will serve as reference gesture and

will be compared in real time with learner’s

gestures.

3 RESEARCH QUESTIONS

The main goal of this research is to propose a novel

and highly interactive embodied pedagogical

application for gestural know-how transmission,

supporting “self” trainings, and making them more

efficient. To achieve this goal and to provide

scientific evidence about our statement this research

has been structured around 3 research questions.

 Can cinematic aspects of expert technical

gestures be captured, modelled and recognized

by the machine?

If machine is able to recognise different gestures

executed multiple times by the same potter and the

CSEDU2015-7thInternationalConferenceonComputerSupportedEducation

406

recognition accuracy is high then the hypothesis can

be validated.

 Can GRT be used to evaluate pottery learner’s

performance during “self” trainings?

After having captured learner’s gestures performed

during “self” training we can compare them with

expert’s gestures. Machine’s ability to recognise

learner’s gestures using expert’s models as reference

will be used as indicator of the efficiency of “self”

training.

 Is “self” training with sensorimotor feedback

more efficient than without?

To answer this question we capture learner’s

gestures performed using our application providing

real-time sensorimotor feedback. Then we still train

the system with expert models and use for

recognition the gestures captured. If recognition

accuracy is higher here than in the previous

hypothesis, it will mean that pottery learner’s

gestures performed with feedback are closer to

expert gestures and that “self” trainings with

sensorimotor feedback are more efficient.

4 METHODOLOGY

4.1 Capture, Modelling and

Recognition of Expert Gestural KH

The first step of our methodology consists on

analysing and modelling expert’s gestural know how

with the use of GRT: a) knowledge is extracted

through collaboration with the expert and a gesture

vocabulary is created; b) then cinematic aspects of

gestures from this vocabulary are captured with a

suit containing 11 inertial sensors covering expert’s

upper body and recording joints’ rotations; c) after

the definition of the appropriate gestural descriptors,

and data normalisation we proceed to d) stochastic

modelling of expert’s gestures using a hybrid

machine learning approach based on Hidden Markov

Models (HMM) and Dynamic Time Warping

(DTW) (Bevilacqua, 2010). A single sample is used

to define a gesture class. HMMs calculate in real-

time computation measures between the models and

the incoming data and define the likelihood that the

hidden model generated the incoming observation

sequence. Then, we use the Jackknife cross

validation method, and the precision and recall

metrics to evaluate the ability of our system to

recognise different executions of different gestures

performed by the same potter. During this phase we

also use basic statistical analysis of expert’s motion

data to define the variance between the repetitions of

his gestures.

This system (ArtOrasis) and methodological

substeps are presented in details in the paper

“Capture, modeling and recognition of expert

technical gestures in wheel-throwing art of pottery”

(Manitsaris, 2014).

4.2 Expert/Learner Gestures

Comparison

In order to quantify and understand the limits of

“self” trainings while practicing wheel throwing

pottery it is necessary to capture the gestures from

the vocabulary but this time performed by the

learner. Then with ArtOrasis application we can

train the machine with expert models and use

learner’s dataset for recognition. At this phase our

statement is that more learner’s execution of the

gestures are close to master’s more his data is close

to the states inside the Hidden Markov Model and

the system will be able to provide an accurate

estimation of recognition probabilities. Additionally,

DTW is used to align temporally the hidden model

and the observation sequence. When two sequences

are warped this permits to calculate the distance

between them and to compare the set of master

gestures with learner’s performance. More learner

data is close to expert’s more recognition accuracy is

high. Precision and recall can be thus used as a

metric to evaluate learner’s performance.

4.3 Sensorimotor Feedback Mechanism

Once the limit of “self” trainings defined we can

proceed to the creation of the pedagogical

application providing sensorimotor feedback. The

goal of these real-time optical or sonic indications is

to alert the learner about his errors (implicit

feedback) and to guide him in the adjustment of the

gestures (explicit), to provide him a constructive

evaluation. Our statement at this phase is that this

interaction established between the learner and the

machine can contribute to efficient gestural know-

how learning and it can make “self” trainings more

efficient.

To verify this statement it is necessary to propose

the feedback mechanism. This must be inspired from

the types of feedback master gives during the “in

person” transmission and it strongly depends on the

case study. Generally, the transmission procedure

starts by showing the gestures to the learner. A video

presentation could correspond to this step. However

in our methodology we desire to go a step further

GestureRecognitionTechnologiesforGesturalKnow-howManagement-PreservationandTransmissionofExpert

GesturesinWheelThrowingPottery

407

and we include to our application a video annotated

with colocalizations, also called in literature direct

manipulations, i.e. superimpositions of expert’s

gestures and visual indications pointing out the most

important cinematic aspects of the gesture. Its’ goal

is to introduce the learning material and to attract

learner’s attention at the most difficult points.

Once the learner starts practicing, master

observes him and provides with constructive

comments that could be divided in 3 categories, as

we can see in the table 1. We consider that

sensorimotor feedback provided by the machine

should be inspired from this structure.

Table 1: 3 types of comments provided by the expert.

Preventive Corrective Evaluative

Function Warning

inform

Indicate

corrections

Provide a

score

At this stage we concentrate our work at the

feedback intervening first, the preventive one.We

propose an optical implicit feedback, warning the

user that an error is identified in his gesture. For this

we visualise the distance (in Euler angles rotations),

between learner’s and expert’s performance

calculated during the time warping. We also name

this application embodied since the apprentice uses

directly his body,without any intermediary devices

such as the mouse or joysticks, to interact with the

system. A high level interaction is thus achieved

between the learner and the application that adapts

the feedback provided depending on learner’s

gestural performance.

Figure 1: General overview of the methodology.

5 IMPLEMENTATION AND

FIRST RESULTS

5.1 Potter’s Gestural Kh Modelling

To answer to the first research question formulated

in the section 3, we have conducted an experiment

with the participation of 2 potters as described in the

corresponding paper (Manitsaris et al., 2014). A

gesture vocabulary with 4 or 6 gestures, used for the

creation of a simple bowl (18/23cm diameter) has

been created and 5 repetitions-subsets of each

gesture have been captured. After that, raw data has

been normalized and the appropriate descriptors

have been selected.

When applying the jackknife method we use one

of these repetitions of each gesture to train our GR

system and the other repetitions for recognion

sequence. All the data sets are once used for

machine learning. In the table 2 we can see the very

high real-time recognition accuracy for the 2 potters.

Table 2: Recognition accuracy rate of 2 expert potters.

Precision Recall

Potter A 100% 100%

Potter B 96% 97,5%

This machine’s ability to recognise different

expert’s gestures constitutes a confirmation of the

fact that cinematic aspects of gestures performed for

bowl’s creation, have been successfully modelled. It

also means that a) the gestures (models) are different

between them and it becomes evident from Levene’s

test results showing that the variances of experts’

gestures are not equal ; b) the 5 repetitions of the

same gesture are very similar and it can be

concluded if we compare the angles distances on the

3 axis.

5.2 Comparison of Pottery Expert and

Learner Gestures

In the second phase of the methodology, the goal is

to evaluate learner’s performance during « self »

trainings, without receiving any feedback or

guidance. To this end, the pottery learner of

beginner level was asked to execute 5 times the

same 4 gestures that the expert A showed him. It is

important to notice that in wheel throwing pottery,

when master teaches a beginner, the « in person »

transmission often starts by virtual simulation of

gestures. It helps the learner to memorise gestures

trajectories before using the clay and the wheel.

Virtually performed gestures have been captured

with the same 11 inertial sensors and a dataset of 20

gestures has been thus created. Then, we have

selected one indicative expert data sequence and

trained ArtOrasis system with it. However according

to the statistical analysis done in (Volioti et al.,

2014) all the 11 joints are not involved in pottery

Capturing

analysis

‐ Defini on of gesture

vocabulary

‐ Gesture segmenta on

Modelling

‐ Choice of descriptors

‐ Stochas c modeling

‐ Machine Learning

Recogni on

Alignment

‐ Recogni on of learner’s

gestures

‐ Alignment & comparison

with expert

‐ Distance calcula on

Sensorimotor

feedback

‐ Preven ve, correc ve,

evalua ve

‐ Op cal, sonic

‐ Implicite, explicite

CSEDU2015-7thInternationalConferenceonComputerSupportedEducation

408

gestures in the same degree. Hands and head

participate the most in the creation of a bowl. Based

on this statement, we compare only wrists rotations

data and use it for recognition. In the table 3 we

present the jackknife results. At horizontal axis are

indicated the 4 models and vertically the gestures

used for recognition.

Table 3: Recognition accuracy rate of the learner.

M1 M2 M3 M4 Recall

G1 2

0 1 2 40%

1 0 60%

0 0

0 100%

2 2 1

Precision

40% 60% 63% 0%

From these results we can see that our system’s

ability to recognise pottery learner’s gestures can be

estimated at 50%, which is almost the half of

expert’s recognition accuracy. If we interpret these

results from a semantic point of view they would

mean that learner’s performance declines from

expert’s by 50%. To compare more closely pottery

learner’s and expert’s gestures we also use the DTW

technique.

5.3 Learning Pottery with

Colocalisations & Implicit Optical

Feedback

To help the pottery learner reduce this distance we

propose a pedagogical application, accompanying

him in the learning process. Always inspired from

“in person” transmission we start by providing the

annotated video, reminding to the learner the most

important cinematic of the gestures, such as body

postures, gesture trajectories etc., as shown the

figure 2.

Figure 2: Expert’s video with colocalisations.

After the visualisation of the video the learner is

invited to pass to the practical part with the use of

sensors. For this, we have developed a simple user

interface in MaxMSP environment, dynamically

warning the user about his deviation, based on

ArtOrasis system. More precisely, during the

alignment of the model with the virtually performed,

simulated gesture we calculate the normalized

instant distance of rotation angles on 3 axes XYZ,

between 2 sequences for 2 hands with the following

equation.

(1)

Then, we visualise the absolute value of this distance

in real-time. For this feedback we decided to ignore

Z visualisation since wheel throwing pottery

movements for bowl creation on this axis are

limited. Learner’s goal is to keep the distance lines

as thin as possible. An interaction is thus installed

between the user and the application.

This feedback is preventive and implicit since

it’s goal is only to warn about a deviation from

expert’s potter and not to give precise indications on

how correct this deviation. At this stage we have

opted for optical feedback because during virtual

executions learner’s vision can be used to receive

information.

To active this implicit feedback we train the

system with one indicative expert model of the first

gesture, and we ask to the learner wearing the

sensors to perform this gesture. To send the data

flow from the sensors to our application in real-time

we use the OSC protocol. At this stage HMMs are

not mobilized since the system is trained only with

the gesture the learner wants to practice. But DTW

is aligning the 2 sequences and it permits us to

calculate and to visualise the absolute value of

learner’s distance.

Figure 3: Implicit optical feedback - visualisation of angle

deviations at X and Y axis for the left hand.

During this third experiment the learner in asked

to perform each gesture with the use of our

application 5 times and each repetition is captured.

After that, we proceed to a jackknife where 4 expert

models are used for the machine learning and 20

learner’s repetitions are used for recognition.

Table 4: Recognition accuracy rate of the learner’s

gestures performed with feedback.

M1 M2 M3 M4 Recall

G1 5

0 0 0 100%

0 0 100%

3 0

0 40%

0 0 1

80%

Precision

63% 100% 67% 100%



x, y, z









l earner

 k

exper t

GestureRecognitionTechnologiesforGesturalKnow-howManagement-PreservationandTransmissionofExpert

GesturesinWheelThrowingPottery

409

Then we perform Jackknife recognition tests,

while still training the models with expert gestures

and recognizing learner’s performed with feedback.

If we compare the results from the tables 3 and 4 we

can see that the recognition accuracy and

consequently machine’s ability to recognise these

pottery gestures have been improved, attending a

precision and recall around 80%. We consider that it

means that learner gestures performed with feedback

are closer to expert gesture.

6 PERSPECTIVES

In this paper we present the idea of valorising GRT

through an innovative KHM tool that could

contribute to the efficient transmission of gestural

know-how. The promising results presented in the

section 5 constitute the first argument supporting the

idea of this work. We can observe the tendency of

improvement of pottery learner’s gestures with the

use of optical implicit feedback.

However to confirm the third hypothesis we need

to conduct experiments with more than one user that

will also subjectively evaluate the application

through a questionnaire, and to test all the 3 types of

sensorimotor feedback involving optical and sonic

interaction. As underlined before, implicite optical

feedback is effective to alert the learner about his

errors but not to conduct him to their correction.

Another important future research goal is to propose

an efficient mechanism for corrective feedback

activation based on a dynamically simulated

statistical model.

ACKNOWLEDGEMENTS

The research project is implemented within the

framework of the Action «Supporting Postdoctoral

Researchers» of the Operational Program

"Education and Lifelong Learning" (Action’s

Beneficiary: General Secretariat for Research and

Technology), and is co-financed by the European

Social Fund (ESF) and the Greek State.

REFERENCES

Bevilacqua, F., Zamborlin, B., Sypniewski, A., Schnell,

N., Guédy, F. and Rasamimanana, N., 2010

‘Continuous realtime gesture following and

recognition’, LNAI 5934, pp.73–84.

Bril, B., 2011. Description du geste technique: Quelles

méthodes?. Techniques & Culture, (1), 243-244.

Chevallier, D., 1991, Savoir faire et pouvoir transmettre.

Transmission et apprentissage des savoir-faire et des

techniques. Les Editions de la MSH.

Dale E., Audiovisual Methods in Teaching, 1969, NY:

Dryden Press.

Godbout, A., & Boyd, J. E., 2010, Corrective sonic

feedback for speed skating: a case study. In

Proceedings of the 16th international conference on

auditory display, pp. 23-30.

Le Bellu S., Le Blanc B., 2010, How to Characterize

Professional Gestures to Operate Tacit Know-How

Transfer?, The Electronic Journal of Knowledge

Management Volume 10 Issue 2, pp142-153.

Manitsaris, S., Glushkova, A., Bevilacqua, F., &

Moutarde, F., 2014, Capture, modeling and

recognition of expert technical gestures in wheel-

throwing art of pottery. ACM Journal on Computing

and Cultural Heritage.

Ng, K. C., Weyde, T., Larkin, O., Neubarth, K.,

Koerselman, T., & Ong, B., 2007, 3d augmented

mirror: a multimodal interface for string instrument

learning and teaching with gesture support. In

Proceedings of the 9th international conference on

Multimodal interfaces, pp. 339-345, ACM.

Piaget, J., 1976, Piaget’s theory, pp. 11-23, Springer

Berlin Heidelberg.

Raptis M., Kirovski D., Hoppe H., 2011, Real-Time

Classification of Dance Gestures from Skeleton

Animation. Eurographics/ In Proceedings of ACM

SIGGRAPH Symposium on Computer Animation.

Rasamimanana N., Bevilacqua F., 2009, Effort-based

analysis of bowing movements: evidence of

anticipation effects. The Journal of New Music

Research, 37(4): 339 – 351.

Volioti, C., Manitsaris, S., & Manitsaris, A., 2014, June,.

Offline statistical analysis of gestural skills in pottery

interaction. In Proceedings of the 2014 International

Workshop on Movement and Computing, p. 172.

Wang, K. A., Liao, Y. C., Chu, W. W., Chiang, J. Y. W.,

Chen, Y. F., & Chan, P. C., 2011, Digitization and

value-add application of bamboo weaving artifacts. In

Digital Libraries: For Cultural Heritage, Knowledge

Dissemination, and Future Creation, pp. 16-25.

Springer Berlin Heidelberg.

CSEDU2015-7thInternationalConferenceonComputerSupportedEducation

410
