O3 - A Webpage Preprocessing Tool

Karthik Senthil, Karthik S. Bhat, Nitin Jamadagni, Sudeep Sureshan and Gaurav Prasad

Department of Information Technology, National Institute of Technology Karnataka, Surathkal, India

Keywords:

Front-end, Optimization, Load Time, Performance, Optimization Methods, Preprocessing.

Abstract:

One of the prime factors for the success of the internet is determined by the time taken to load a web page.

Even a difference of a few hundred milliseconds in the response time will largely affect the number of users

of a web page to shift from one to the other. So, in the commercial market, providing quick service to the

users is of utmost importance in remaining ahead of competitors. In this paper, we mainly address this issue

by applying various optimization techniques at the front-end to improve the user experience by reducing the

load time of the web pages. Though the overall optimization is purely web page-dependent, the optimization

techniques not only reduce the time taken to load the page, but also reduce the load on the server.

1 INTRODUCTION

Web based applications and websites are being visited

more and more frequently in the recent times due to

the ease of access to the internet. It has reached such

an extent that there are many countries where there is

an internet connection in every household. This has

led to the increased number of web pages altogether,

as organizations have created personal web pages as a

marketing strategy, social networking sites are on the

rise and so on. Website loading is an inherent part of

the user experience in using a website.

At the browser level, when a website is re-

quested for, the browser sends a HTTP request to the

server and the server in turn sends the response in a

HTTP response packet which is then received by the

browser. The data is being represented in the form of

a Document Object Model (DOM) which can be uni-

versally rendered by all browsers. The DOM is a tree

structure of the contents of the webpage. Webpages

generally consist of HTML, which is the markup,

CSS which adds styling to the markup and client-

sided JavaScript. During the rendering of the DOM,

the browser loads the HTML and its associated CSS

together, as they go hand in hand. Scripts are, how-

ever, rendered differently. Since scripts have the ca-

pacity to modify the DOM structure dynamically, the

loading of the DOM is halted until all of them have

ﬁnished loading. This results in an unnecessary loss

of time, as many scripts are irrelevant to the user (like

click counter or analytics). This is a drawback that

has been widely discussed. In this paper we discuss

some ways to improve the DOM loading speed and in

essence to improve the loading time of webpages.

In this paper, section two discusses the motivation

behind the creation of the tool. Section three dis-

cusses the previous work similar/related to this tool.

Section ﬁve discusses the methodology followed dur-

ing the implementation of the project. Section six (a),

discusses in detail the techniques used to achieve the

speed-up of loading of the web pages. Section six

(b) shows the results we obtained and compare them

to unprocessed websites and thereby shows how opti-

mization effectively improves page-load time.

2 MOTIVATION

Large access frequency and increased user-

friendliness of webpages has led to an increase

in the amount of resources used by the web pages.

The escalated number of page accesses, fuelled by

the number of users, has forced the hosting agencies

to add extra web servers to handle these requests.

This has in turn led to increased expenditure for the

organization. This rise in number of resources used

by web pages not only multiplies load on the server,

but also on the client who is connected to the site

affecting the user experience while using the web

page. User experience plays a critical role in page

ranking, as a better experience leads to better rating

for a web page and consequently, a higher page rank.

Steve Souders (Souders, 2012) suggests that 80-

90% of the end-user response time is spent on the

Senthil K., S. Bhat K., Jamadagni N., Sureshan S. and Prasad G..

O3 - A Webpage Preprocessing Tool.

DOI: 10.5220/0005438100150020

In Proceedings of the 11th International Conference on Web Information Systems and Technologies (WEBIST-2015), pages 15-20

ISBN: 978-989-758-106-9

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

frontend. This claim has been supported by statis-

tics, among the top 10 ranked websites 76% end-user

time has been recorded on the front end,among the top

9990+ ranked websites a staggering 92% of the same

and among the top 50000 ranked websites a 87% has

been recorded.This seems to suggest that much of the

optimization techniques must be concentrated on the

front-end of websites.

According to surveys conducted by Akamai (Aka-

mai, 2012), close to half of web users have a time

limit expectation of about 2 seconds or less, and tend

to abandon a site that hasn’t loaded within 3 sec-

onds.79% of the online shoppers who have trouble

with their shopping websites tend to not visit the site

again to buy products and 44% of them would tell a

friend that he had a bad experience with the online

shopping website.Seeing these statistics, it is a neces-

sity for online shopping websites to optimize the web

pages, which otherwise would lead to a loss of many

potential sales.

The page-load time and bandwidth requirement of

web pages can be reduced by applying various front-

end optimization techniques. These techniques not

only optimize the load-time on the client side, but also

reduce the load on the web server, by decreasing the

bandwidth requirement and the number of connected

clients.

3 RELATED WORK

Some related work/tools in webpage optimization are:

1. Google PageSpeed

PageSpeed (Zhenhua et al., 2012) is a set of tools

designed to improve the performance of a web-

site.It helps a developer in identifying high per-

formance oriented practices that can be applied to

the website. It also includes optimization tools

that can help the developer automate this process.

2. Radware’s FastView

FastView (Radware, 2012) is a web performance

optimization(WPO) and acceleration tool which

permits better performance of a website or web-

based application in real time. It has an automated

functionality to reduce the complexity of the front

end optimization process.

3. Akamai’s Front End Optimization (FEO)

FEO (Akamai, 2012) is a service offered by Aka-

mai for the clients using their cloud computing

service. It allows mobile optimization of web

content primarily for smartphone and tablet users.

The Akamai FEO engine analyses the target web

content and then identiﬁes the possible optimiza-

tions for different device capabilities and environ-

ments.

4. JCH Optimize

JCH Optimize (Marshall, 2013) is a plugin of

Joomla! that aims at speeding up a website by

combining JavaScript and CSS ﬁles into a single

ﬁle,hence minimizing expensive HTTP requests

and ultimately optimizing the net download time

of a webpage.

5. Iliev, I. et al.’s work (Iliev and Dimitrov, 2014)

has also discussed various front end optimization

techniques.

In comparison to the above mentioned tools, the O

web preprocessing tool performs a comprehensive

evaluation and graphically represents the results ob-

tained before and after the optimizations made by the

tool.

4 PROBLEM STATEMENT

In the current era of high speed internet we observe

that various front-end optimization techniques are

prevalent and used, but these are being done man-

ually by the web page designers/developers. This

project aims at automating this time-consuming pro-

cess thereby saving on development time while also

implementing optimization techniques for the web

page in parallel.

5 METHODOLOGY

The methodology adopted in this project is essen-

tially the development of Python scripts to automate

the optimization techniques on a given set of web

pages, which we have found to give measurable out-

comes.The observations and results obtained by us

are speciﬁc to WEBrick server version 1.3.1. We

have measured the speed-up of the web page’s loading

time, by using some performance-measuring tools,

such as YSlow and ab Tool, as benchmarking tools

for quantitative analysis.

We aim to achieve optimization using the following

techniques:

1. Placing Scripts at the bottom of the page

2. Removing Duplicate Scripts

3. Using External Scripts

4. JavaScript Miniﬁcation

5. CSS Miniﬁcation

WEBIST2015-11thInternationalConferenceonWebInformationSystemsandTechnologies

6. Using Compression techniques

7. Using CDNs(Content Delivery Networks)

8. Using Cache Techniques

6 IMPLEMENTATION

The following tools/libraries were used during the im-

plementation of the above techniques:

1. BeautifulSoup : BeautifulSoup which is a pack-

age of Python, is used for HTML documents pars-

ing. It builds a parse tree for web pages it parses,

which can then be used to modify the DOM struc-

ture.

2. Requests : Requests is a simple, elegant HTTP

library for Python licensed by Apache2.

3. YUICompressor : A Java based compres-

sion/miniﬁcation tool.

4. ab Tool : ab is a tool for benchmarking Apache

Hypertext Transfer Protocol (HTTP) server. It

simulates any test case by taking number of re-

quests and number of concurrent requests as in-

put.

The optimization was performed using the follow-

ing techniques:

1. Placing Javascript at the bottom of the page

This technique involves the manipulation of the

DOM structure built by the browser, before the

rendering of the web page to the user. We ﬁnd

the node which has the script tag and extract

it, simultaneously replacing it with an empty

tag after its removal. We now traverse through

the entire DOM tree again to ﬁnd the last child

node of the body tag and thereafter append the

extracted script tag as the last child and complete

the DOM structure, which is then ﬁnally parsed

to display to the user the web page.

The reason behind this approach is that while

rendering a web page, if the browser comes

across a script tag, the downloading of web page

is paused until the entire script is fetched (as it

can affect the DOM structure), thereby increasing

the page load time. So, by moving the scripts to

the end of the page we can ensure that the page

download happens completely before the scripts

are fetched, ultimately cutting down a signiﬁcant

portion of page load time.

2. Moving script contents to an external

JavaScript ﬁle

In our next technique we have removed all the

Figure 1: Placing scripts at the bottom of the page.

script tags from the HTML page and moved them

to a separate external Javascript ﬁle. The HTML

ﬁle is parsed and the content inside script tags

are removed and placed in a new ﬁle named

”external.js”. Consequently, this external.js is

included in the head section of the HTML page.

Also, we have ensured that the order of inclusion

of other external JavaScript ﬁles is maintained.

This is done to reduce effective HTML document

length of the web page, thus reducing the page

load time. This also leads to simple DOM tree

structure without any script tags.

3. CSS and JavaScript Miniﬁcation

In our ﬁnal technique we have made use of the

concept of miniﬁcation. Miniﬁcation is the re-

moval of all unnecessary characters from source

code without changing its functionality. This is

done to bring in some signiﬁcant change in the

ﬁle size(of the JS or CSS ﬁle).

Here we used a JAVA based command-line compres-

sion tool, namely YUICompressor. Among all the

style-sheets and Javascript ﬁles that were fetched for

a particular web page, we identiﬁed the un-miniﬁed

ﬁles. These were consequently fed to the tool and

the miniﬁed output was used to replace the unminifed

ﬁles.

O3-AWebpagePreprocessingTool

Figure 2: Placing scripts in external ﬁle.

Figure 3: CSS and script miniﬁcation.

Miniﬁcation is proven to give an average of 25% efﬁ-

ciency in compression. We observed the same results

with our techniques.

(a)

(b)

(c)

Figure 4: Results obtained (a) Technique 1 on google.com.

(b) Technique 1 with JS on top. (c) Technique 1 with JS in

the middle.

7 RESULTS OBTAINED AND

ANALYSIS

The results obtained on moving the content of the

script tags in google.com to the bottom of the page

resulted in an improvement of 12.95% in Mean Load

Time (MLT) and an increase of 9.3% in Data Trans-

ferred (Bytes) as shown in Figure 4(a).

The results obtained on moving the content of the

script tags to the bottom of the page with JS on top

resulted in an improvement of 12.95% in MLT and

an increase of 9.3% in Data Transferred (Bytes) as

shown in Figure 4(b).

The results obtained on moving the content of the

script tags to the bottom of the page with JS in the

middle resulted in an improvement of 20.97% in MLT

and an increase of 11.37% in Data Transferred (Bytes)

as shown in Figure 4(c).

It can be noted that in all cases of Technique 1,

the data transferred has increased after optimization,

which is contrary to expected behavior.

The results obtained on moving the content of the

script tags to an external JS in goolge.com resulted in

an improvement of 28.02% in MLT and an increase of

WEBIST2015-11thInternationalConferenceonWebInformationSystemsandTechnologies

(a)

(b)

(c)

Figure 5: Results obtained (a) Technique 2 on google.com.

(b) Technique 2 with JS on top. (c) Technique 2 with JS in

the middle.

9.3% in Data Transferred (Bytes) as shown in Figure

5(a).

The results obtained on moving the content of the

script tags to an external JS with JS at the top of the

page resulted in an improvement of 27.14% in MLT

and an increase of 7.7% in Data Transferred (Bytes)

as shown in Figure 5(b).

The results obtained on moving the content of the

script tags to an external JS with JS in the middle

of the page resulted in an improvement of 23.85% in

MLT and an increase of 11.3% in Data Transferred

(Bytes)as shown in Figure 5(c).

The results obtained on CSS and JS miniﬁcation in

yottaa.com resulted in an improvement of 5.01% in

MLT and an decrease of 64.01% in Size(Bytes) as

shown in Figure 6(a). It can be noted from Figure 6(a)

that the resulting MLT for 100 requests has increased

from the non-optimized version. This is an anomaly

to the expected behavior.

The results obtained on CSS and JS miniﬁcation

in w3schools.com resulted in an improvement of

9.495% in MLT and an increase of 19.56% in Data

Size(Bytes) as shown in Figure 6(b).

The results obtained on CSS and JS miniﬁca-

tion in simplecartjs.com resulted in an improvement

(a)

(b)

(c)

Figure 6: Results obtained (a) Technique 3 on yottaa.com.

(b) Technique 3 on w3schools.com. (c) Technique 3 on sim-

plecartjs.com.

of 7.32% in MLT and an decrease of 22.45% in

Size(Bytes) as shown inFigure 6(c).

Experimental Steps for Implementation and

Result Analysis

1. The existing ideas had to be implemented manu-

ally, but we have automated three of the optimiza-

tion techniques through a tool. The tool automates

the procedure by changing the DOM structure of

the web page to be optimized.

2. We have also done a thorough evaluation of the

strategies by:

(a) Evaluating the techniques for a variety of web

pages with different structures.

(b) Benchmarking with standardized tools like the

abTool.

Table 1: Performance Improvement in Technique 1.

NO. OF REQUESTS % DECREASE IN MCT

25 27.69

100 11.33

200 13.78

Average 17.6

O3-AWebpagePreprocessingTool

Table 2: Performance Improvement in Technique 2.

NO. OF REQUESTS % DECREASE IN MCT

25 28.845

100 31.089

200 25.411

Average 28.448

• Varying number of requests for the page.

• Varying number of concurrent requests for the

page.

3. Static and dynamic graphical representations of

the benchmarked results, for better comparison

and evaluation.

4. Analysis of the size of HTML documents and the

related ﬁles for further network latency bench-

marking.

5. Use of platform independent technologies and

easily available/accessible tools for building the

optimization tool.

6. All the strategies have been tested on multiple

browsers (Ex. Google Chrome, Mozilla Firefox,

Apple Safari, Internet Explorer) as well as ’wget’

and the results have been conﬁrmed to be consis-

tent.

8 CONCLUSIONS AND FUTURE

WORK

The above techniques, when implemented individ-

ually, give a slight improvement in performance.

However, in conglomeration with the other tech-

niques of optimization, it is sure to give a signiﬁcant

measurable increase in performance in terms of time

required to load a webpage.

Other techniques mentioned in the paper need to be

implemented, and if possible, a new technique that

has not yet been accounted for can be discussed,

and the performance optimization can be mea-

sured. It is also a signiﬁcant problem to determine

which optimization techniques together generate

the best performance optimization. This is because

performing all optimization techniques may have

a performance overhead, so determining the best

combination of techniques is necessary. In addition

Table 3: Performance Improvement in Technique 3.

NO. OF REQUESTS % DECREASE IN MCT

25 5.97

100 1.8

Average 3.885

Table 4: Document Size Analysis - I.

TECHNIQUE % INCREASE IN

DOCUMENT LENGTH

1 9.358

2 9.35

Table 5: Document Size Analysis - II.

TECHNIQUE % DECREASE IN FILE SIZE

3 26.44

to this, the anomalies obtained in our results needs to

be explained, after proper analysis.

An appreciable performance acceleration must be

achieved after the implementation of a signiﬁcant

number of front-end optimization techniques.

ACKNOWLEDGEMENTS

We would like to thank Mr. Sanket Ingole and Mr.

Shridhar Sanshi for their support and valuable inputs

towards the improvement and completion of this pa-

per. We would also like to thank Mr. Raghavendra

G. S. for his timely help towards the organisation and

formatting of this paper.

REFERENCES

Akamai, A. (2012). Akamai’s front end optimiza-

tion. http://www.akamai.com/html/resources/front-

end-optimization-feo.html. Accessed on: 14th

November 2014.

Iliev, I. and Dimitrov, G. P. (2014). Front end optimization

methods and their effect. In Information and Commu-

nication Technology, Electronics and Microelectron-

ics (MIPRO), 2014 37th International Convention on,

pages 467–473. IEEE.

Marshall, S. (2013). Jch optimize. https://www.jch-

optimize.net/documentation/how-the-plugin-

works.html. Accessed on: 14th November 2014.

Radware, R. (2012). Radware’s fastview.

http://www.radware.com/Products/FastView/. Ac-

cessed on: 14th November 2014.

Souders, S. (2012). The performance golden rule.

http://www.stevesouders.com/blog/2012/02/10/the-

performance-golden-rule/. ”Accessed on: 14th

November 2014”.

Zhenhua, C., Crowell, J., Grigorik, L., Kaufman, J.,

and van der Schaaf, O. (2012). Pagespeed.

https://developers.google.com/speed/pagespeed/. Ac-

cessed on: 14th November 2014.

WEBIST2015-11thInternationalConferenceonWebInformationSystemsandTechnologies
