A Real-time, Automatic Target Detection and Tracking Method for

Variable Number of Targets in Airborne Imagery

Tunc¸ Alkanat, Emre Tunali and Sinan

Image Processing Department, ASELSAN Inc. Microelectronics, Guidance and Electro-Optics Division, Ankara, Turkey

Keywords:

Real-time Target Detection, Multiple Target Tracking, Temporal Consistency, Data Association, Target

Probability Density Estimation, Adaptive Target Selection.

Abstract:

In this study, a real-time fully automatic detection and tracking method is introduced which is capable of

handling variable number of targets. The procedure starts with multiple scale target hypothesis generation in

which the distinctive targets are revealed. To measure distinctiveness; ﬁrst, the interested blobs are detected

based on Canny edge detection with adaptive thresholding which is achieved by a feedback loop considering

the number of target hypotheses of the previous frame. Then, the irrelevant blobs are eliminated by two

metrics, namely effective saliency and compactness. To handle the missing and noisy observations, temporal

consistency of each target hypothesis is evaluated and the outlier observations are eliminated. To merge data

from multiple scales, a target likelihood map is generated by using kernel density estimation in which weights

of the observations are determined by temporal consistency and scale factor. Finally, signiﬁcant targets are

selected by an adaptive thresholding scheme; then the tracking is achieved by minimizing spatial distance

between the selected targets in consecutive frames.

1 INTRODUCTION

Multiple target detection and tracking has signiﬁcant

importance for many applications, including recon-

naissance and surveillance in which the major goal

is to reveal trajectories of the targets throughout the

scenario. Considering the recent developments, many

electro-optical systems are in need of full automa-

tion for achieving this task. Therefore, many multi-

tracking algorithms include two fundamental stages

as the automatic, time independent detection of tar-

gets; and association of the detections in the temporal

space. Although there exists many research on the

subject (Berclaz et al., 2011; Niedfeldt and Beard,

2014; Andriyenko and Schindler, 2011), problem re-

mains to be challenging mainly due to unknown and

changing number of targets; noisy and missing obser-

vations; interaction of multiple targets. Moreover, all

these challenges are needed to be solved in a time ef-

ﬁcient manner for real-time applications.

The outstanding target detection concept can be

interpreted in different ways and many interest point

detection techniques can be used as a starting point

to determine such objects on an image. In the lit-

erature, there exists numerous interest point detec-

tion methodologies based on blob detection (Lowe,

2004; Bay et al., 2008), corner detection (Harris and

Stephens, 1988; Rosten and Drummond, 2006) and

edge detection (Canny, 1986; Prewitt, 1970; Sobel

and Feldman, 1968). Rather than searching for cor-

ners or blobs, deﬁning the outstanding object from the

contrast is a better choice for our application since we

are not only interested in cornered or blob-like struc-

tured objects. In this sense, usage of edge detectors

yields better generalization and among edge detec-

tions methods Canny edge detection shows its supe-

riority due to its ability of generating closed contours

by merging weak edges with the strong edges around

their vicinity. Furthermore, the low computational

cost of the Canny edge detector also allows the us-

age of pyramid structure in order to respond targets in

different scales without introducing any restriction for

real-time processing which is one of the major goals.

Another important aspect of the detection phase

is determining the number of targets dynamically

since the selection of predetermined number of targets

would be problematic. To be clearer, if the number of

targets is smaller than the expected number of targets,

the system is forced to introduce insigniﬁcant targets

to the track list. Likewise, in the scenes having higher

number of signiﬁcant targets than the expected, some

of the signiﬁcant targets will be ignored. To deal with

Alkanat T., Tunali E. and Öz S..

A Real-time, Automatic Target Detection and Tracking Method for Variable Number of Targets in Airborne Imagery.

DOI: 10.5220/0005298400610069

In Proceedings of the 10th International Conference on Computer Vision Theory and Applications (VISAPP-2015), pages 61-69

ISBN: 978-989-758-090-1

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

Figure 1: Sample outputs of the proposed solution demonstrating successful tracking for variable number of targets.

the unknown, changing number of targets and develop

an unsupervised approach, a target selection proce-

dure is also introduced.

Temporal association of detections is the funda-

mental problem of multi-target tracking. Despite ex-

istence of many detection methodologies, none of the

detection methods can provide robust detection re-

sults to be used in the data association stage. To

be more precise, detections may be misleading from

time to time and the outlier data should be handled

while achieving the data association. For this purpose,

one of the most popular and well studied method is

Kalman ﬁltering (Kalman, 1960) which deals with

the outliers by achieving a compromise between the

probabilistic model of the target motion and the mea-

surement. Although this methodology is effectively

used in many applications (Tsai et al., 2010; Ra-

makoti et al., 2009), requirement of the predetermined

motion model becomes a signiﬁcant restriction. Us-

age of particle ﬁlters (Ristic et al., 2004) can address

some of the limitations of the Kalman ﬁlters by ex-

ploring multiple hypotheses; however this results in

an increased computational complexity. Other widely

used techniques for the association problem are joint

probability density association ﬁlters (JPDAF) (Fort-

mann et al., 1980) and multiple hypothesis track-

ing (MHT) (Reid, 1979). The JPDAF actually uses

soft data assignment by considering the probability

of a measurement belonging to more than one track

which results in a single hypothesis for summariz-

ing all the previous measurements. The main limita-

tion of JPDAF is the assumption on number of targets

which is stated to be ﬁxed. Hence, it is not capable of

handling targets entering/leaving the scene. In MHT,

this problem is solved by integrated track initiation.

Association algorithm of MHT is a hypothesis based

brute force implementation which aims to generate all

possible hypotheses and requires high computational

load. Moreover, MHT also requires a large memory

space to be used; since the different hypotheses from

previous frames are kept in the memory. Instead, the

proposed method obtains measurements with a pyra-

mid structure and beneﬁts from motion heuristics to-

gether with a probability density estimation method-

ology which is designed for merging measurements

from different levels of the observation pyramid. The

density estimation method is based on Parzen win-

dowing (Parzen, 1962), and beneﬁts from a weight-

ing scheme to tolerate missing and noisy observations

with low computational cost.

The rest of the paper is organized as follows: The

proposed target detection and tracking method is ex-

plained in Section 2, the conducted experiments are

analyzed in Section 3, and ﬁnally the study is con-

cluded in Section 4 where discussions are made.

2 PROPOSED METHOD

The multiple target detection and tracking method

proposed in this paper consists of 4 main steps: First,

target hypotheses are generated for different scales

based on distinctiveness and compactness assump-

tions of target model, then temporal consistency of

each target hypothesis is calculated for both reject-

ing outliers and compensating missing detections in a

time efﬁcient manner. By using these consistent target

Figure 2: General overview of the proposed solution.

VISAPP2015-InternationalConferenceonComputerVisionTheoryandApplications

hypotheses, from each scale of the observation pyra-

mid, a target likelihood map is generated represent-

ing the target existence likelihood at each pixel. Fi-

nally, outstanding (relevant) targets are selected form

the likelihood map by using an adaptive thresholding

scheme and selected targets are associated in consec-

utive frames to reveal their trajectories.

2.1 Target Hypotheses Generation

To achieve automatic target detection, each target

candidate fulﬁlling some preliminary requirements

should be further analyzed to decide whether it is a

relevant target or not. The target candidates are re-

ferred as target hypotheses and generated at each scale

of the observation pyramid, obtained by downsam-

pling the original frame, separately. Therefore, for

both hypotheses generation and selection, some as-

sumptions are made to describe the target model.

The ﬁrst assumption is the distinctiveness assump-

tion stating that target candidates should be distinctive

from their surroundings. Actually, this assumption

is made based on human visual attentional system in

which robust saliency detection mechanisms provide

focus of attention to the salient regions pre-attentively

for further processing. Again similar to human vi-

sual system, the distinctiveness is measured by the

intensity difference. Most of the saliency detection

methods are founded on the same principle; however

saliency detection in global scale (by considering the

whole scene) would generally require high process-

ing time which may not be suitable for real-time ap-

plications. Since the computational complexity is one

of the key issues, target hypothesis generation proce-

dure starts with edge detection which is a simple way

of detecting contrast between neighboring pixels. For

edge detection, Canny edge detector is preferred for

both its low computational complexity and capability

of generating closed contours by merging weak edges

with the strong edges around their vicinity. After em-

ploying Canny edge detection, morphological closure

(to increase probability of generation of closed con-

tours) and ﬁlling operations are performed on edge

map to obtain the possible target blobs. The impor-

tance of ﬁlling operation becomes more prominent

when a possible target has a layered structure, hav-

ing nested closed contours inside the target as in Fig.

3 in which an inner loop is detected due to the reﬂec-

tion of the daylight. In such a scenario, detection of

the complete vehicle is more preferable than detec-

Figure 3: Effect of ﬁlling on a target with layered contours

Figure 4: Flowchart for target hypotheses generation

tion of the spot as a separate target; and ﬁlling the

closed contours inherently yields the selection of the

outer most closed contour since both the inside of the

spot and the vehicle are ﬁlled. After morphological

operations, centroids of the resulting ﬁlled blobs are

obtained by using connected component analysis.

Usage of static thresholding in Canny edge detec-

tion can be problematic since different scenes may

have different contrast spans. Therefore, while a static

threshold can satisfactorily detect targets in scenes

having high contrast, it may fail to disclose any edges

in scenes having low contrast in which targets are

still visible to the human visual system. Since the

aim is to detect relatively high intensity differences,

a dynamic thresholding scheme is applied in which

Canny thresholds are adjusted dynamically with a

feedback loop, Fig. 4, whose input is the target hy-

pothesis count from the previous frame. To achieve

dynamic thresholding, high threshold of the Canny

is simply decreased/increased with a certain amount

if the target hypothesis count is less/higher than the

desired number of hypothesis. In this manner, dy-

namic thresholding provides another advantage which

is keeping the number of blobs and thus targets within

a limit.

Although edge detection reveals regions with rela-

tively high contrast from its surroundings, it can only

give some insight about the distinctiveness level of

the target. To mathematically represent distinctive-

ness of the target candidates, a new metric referred

as effective saliency is introduced based on a saliency

detection methodology (Wei et al., 2012) in which the

saliency problem is tackled from a different perspec-

tive by focusing on background more than the object.

Although there are various saliency detection algo-

rithms (Hou and Zhang, 2007; Achanta et al., 2009;

Cheng et al., 2011), the main motivation of using

this method is its capability of extracting a saliency

map with low computational cost. However, usage

of this technique is restricted with the boundary as-

sumption which is the reﬂection of a basic tendency

that a cameraman does not crop salient objects in the

frame. Thus, the image boundary is assumed to be

background. Satisfying the assumption, the salient

regions are determined by identifying the patches

with high geodesic distance to the image boundaries.

For the calculation of geodesic distance, deﬁnitions

of (Wei et al., 2012) is followed and the image is

divided into vertices which are composed of inner

AReal-time,AutomaticTargetDetectionandTrackingMethodforVariableNumberofTargetsinAirborneImagery

patches P

and background nodes (B, image bound-

aries). Hence, two types of edges: internal edges,

connecting all adjacent patches; and boundary edges,

connecting image boundary edges to the background

node are obtained (ξ = (P

, P

is ad jacent to P

) ∪

, B|P

is on the image boundary)). Then, the

geodesic saliency of a patch P is calculated by ac-

cumulating edge weights (intensity differences) along

the shortest path from P to virtual background node B

in an undirected weighted graph as given in Eqn.1,

Saliency(P) = min

=P,P

,...,P

n−1

∑

i=1

weight(P

, P

i+1

s.t.(P

, P

i+1

) ∈ ξ

(1)

In our case, the boundary assumption of (Wei

et al., 2012) is fulﬁlled by calculating saliency map

from the image patches that are co-centered the blobs

obtained from Canny edge detection and that encap-

sulate objects with their immediate surrounding. Ac-

tually, selection of the image patch is the ﬁrst step

of calculating effective saliency metric. After calcu-

lating the saliency map, a binarization threshold is

obtained by using Otsu’s thresholding (Otsu, 1979).

Then, the effective saliency (E

(t)), is calculated for

each blob as in Eqn. 2 where dominant components

(D.C.) represent the pixels whose saliency values are

greater than the binarization threshold and S

blob

(x) is

the saliency map obtained for each blob. High dis-

tinctiveness is a signiﬁcant sign of a possible target,

hence candidates that do not have a certain level of

distinctiveness are eliminated.

(t) =

∑

x∈D.C.

blob

(x)

∑

y∈S

blob

(y)

. (2)

Another assumption that is made for target model

is the compactness assumption. Since the Canny

edge detection reveals not only edges of the objects

but also edges belonging to structural details in the

scene, some of the detected blobs must be eliminated.

Therefore, a further selection procedure is applied to

the blobs satisfying the distinctiveness assumption.

To achieve the task, the compactness metric is used

which is actually nothing but a scalar specifying the

proportion of number of the pixels belonging to blobs

to the area of the minimum sized bounding box encap-

sulating the blob. Using this feature, the targets hav-

ing degraded from rectangular shape are eliminated.

This procedure is illustrated in Fig. 5. The remaining

blobs satisfying both distinctiveness and compactness

assumptions are referred as target hypotheses and fur-

ther processed to ﬁnd out their temporal consistency.

Figure 5: On left, original image. On right, blob mask of

the original image with relevant targets, inconsistent targets,

blobs violating compactness, blobs violating distinctiveness

marked with green, white, red and blue, respectively.

2.2 Temporal Consistency Evaluation

by Blob Matching

Although Canny edge detection is one of the sim-

plest methods for contrast detection; it is vulnera-

ble to noise and consequently becomes a source for

noisy observations. More precisely, Canny edge de-

tection may fail to provide closed contours, yielding

missing observations in some frames or can produce

artiﬁcial closed contours due to noise. Generation

of faulty observations is a common problem and in

some well-known techniques (Kalman, 1960; Fort-

mann et al., 1980), solution is based on probabilis-

tic model on target behavior. However, this would

be over-restricting for our problem since dealing with

moving cameras generally result in complex motion

patterns. Thus, for rejection of outliers and handling

missing data, proposed method identiﬁes an observa-

tion point as a target hypothesis if and only if the ob-

servation point keeps its presence for multiple frames.

In other words, temporal consistency of a target is

assured based on a scoring scheme in which higher

score of a target hypothesis represents higher reliabil-

ity.

The proposed scoring scheme is applied at each

frame and starts with associating newly generated and

existing target hypotheses. At ﬁrst, for each new tar-

get hypothesis, existing hypotheses are searched in a

neighborhood to satisfy the motion heuristic known

as maximum velocity, (Yilmaz et al., 2006). Usage

of such a simple model is both less restricting and

requires much less computational load compared to

other motion models. Existence of a match is de-

cided by minimizing the norm of vectors that con-

tain spatial distance and mean intensity difference of

a new hypothesis to existing target hypotheses within

the neighborhood. If match is found, the score of the

matched existing target is increased. After matching

all new target hypotheses, the score of the remaining

(unmatched) existing target hypotheses are decreased.

Then, unmatched new target hypotheses are consid-

ered as possible new targets entering the scene and

initial scores are assigned according to their similarity

VISAPP2015-InternationalConferenceonComputerVisionTheoryandApplications

Figure 6: Proposed scoring scheme

to the target model description which is measured by

the effective saliency metric. After adding new target

hypotheses to the existing target list and adjusting the

scores, target hypotheses list is reconstructed by elim-

inating the ones that below the score threshold. Fol-

lowing the scheme, the missing observations for lim-

ited number of frames would be tolerated since they

are still considered as target hypotheses until their

scores go below the threshold. In a similar fashion,

the observations that are generated due to noise will

also be eliminated within a limited number of frames

since they are not persistent. On the contrary, new

targets entering the scene will be considered as target

hypotheses given that they are consistent. The pro-

posed scoring scheme is summarized in Fig. 6.

2.3 Target Likelihood Map Generation

An important problem introduced by Canny edge de-

tector is the false partitioning of a single object into

multiple closed contours which is due to a failure

in detecting the outermost contour of an object as a

closed contour. This problem would result in mul-

tiple target initialization for a single object and ap-

pears more frequently for large sized objects due to

the nature of the edge detector. Obviously, usage of

the data provided by each scale of the pyramid to-

gether would deﬁnitely decrease the occurrence rate

of the problem. Actually merging the data of different

scales can be considered as a probability density es-

timation problem whose solution identiﬁes the target

likelihood map representing the existence probability

of a target at each pixel.

Since no prior information exists about the target

probability distribution, estimation is preferred to be

achieved based on a non-parametric approach. To

achieve this task, kernel density estimation (Parzen

window method (Parzen, 1962)) is employed in which

normal distribution is selected as the kernel function.

Normal distribution is preferred assuming that effect

of a target hypothesis on neighboring pixels yields a

normal distribution whose peak is located on the cen-

troid of the target hypothesis. In this manner, the

variance of the normal distribution will determine the

distance between the centroids of different target hy-

potheses to be merged.

To generate the target likelihood map, different

from classical Parzen windowing, data is weighted

with respect to its signiﬁcance that is deﬁned by

two scalars which are temporal consistency and scale

weights. Since the signiﬁcance of a target increases

with its temporal consistency, consistency weight

) is obtained by the score whose calculation is ex-

plained in Sec. 2.2. Therefore, while decreasing the

effect of mis-detected hypotheses from one scale of

the pyramid, the weights of the corresponding target

hypotheses are increased at the relevant scale yielding

better localization. The second scalar, scale weight

) is designed to select the importance of different

scales of the pyramid. Since the partitioning occurs

generally for the large objects; to compensate the er-

roneous data, detections obtained from lower resolu-

tions (downsampled by a higher factor) are weighted

proportional to the downsampling factor. The formal

deﬁnition of the target likelihood for each pixel (x, y)

is given in Eqn. 3,

P(x, y) =

∑

j∈H

· w

· exp



−

(x−x

)

+(y−y

)

2σ



∑

∀pixels

∑

j∈H

· w

· exp



−

(x−x

)

+(y−y

)

2σ



(3)

where (x

, y

) is the locations from the set of target

hypotheses H.

2.4 Target Selection and Tracking

Once the target likelihood map is obtained, target

selection becomes nothing but a threshold selection

problem which determines the lowest probability in

the target likelihood map that will be considered as a

target. Although the simplest solution is to use static

threshold; dynamic thresholding is preferred due to

the utilized scoring scheme applied to the target hy-

potheses. To achieve the task, the dynamic threshold-

ing methodology proposed by (Aytekin et al., 2014)

is followed which is designed to reveal distinctive in-

tensity falls on a given image. This method analyzes

the relationship between the local maxima of input

image and the threshold is calculated using weighted

AReal-time,AutomaticTargetDetectionandTrackingMethodforVariableNumberofTargetsinAirborneImagery

Figure 7: From top to bottom and left to right: Target hypotheses at scale 1 (original image), target hypotheses at scale 2 (2x

downsampled), target hypotheses at scale 3(3x downsampled), original image, and generated target likelihood map. Masks

for each scale are resized for visualization.

average of local maxima. Obviously, the critical

part is to obtain the appropriate weights. To calcu-

late the weights, ﬁrst, the local maxima are detected.

Then, they are sorted in descending order to form a

vector (LocalMax

sorted

). The weights are obtained

by calculating the normalized laplacian of this vec-

tor since higher laplacian represents distinctive falls.

This methodology ﬁts well to our problem since dis-

tinctive falls indicate splits between different target

hypothesis groups having similar likelihood values;

so it achieves successful separation of distinctively

more signiﬁcant target hypotheses. The formal def-

inition of the weighting procedure is shown in Eqn. 4

and 5.

T hr = LocalMax

sorted

.∇

norm

(LocalMax

sorted

), (4)

∇

norm

( f ) =

∇

( f ) − min



∇

( f )



∑

∇

( f )

− min(∇

( f ))

. (5)

After selection of the target hypotheses as relevant

targets, the tracking is simply achieved by matching

the relevant targets from consecutive frames just by

minimizing spatial distance.

3 EXPERIMENTS

The proposed method was tested for two different as-

pects: Detection and tracking capabilities. For the de-

tection part, success is deﬁned as detecting all true

targets while rejecting non-target background clutter.

Thus, to examine the detection performance, two suc-

cess measures, which are false discovery rate (Eqn. 6)

and true positive (Eqn. 7) rate, are used together.

FDR =

FP + T P

, (6)

T PR =

T P

T P + FN

. (7)

Another important task that should be achieved is

tracking of the detected targets. Despite existence of

multiple targets in each scenario of the VIVID dataset

(VIVID, 2005), the ground truth is only provided for

the primary target. Due to lack of ground truth data

for secondary targets, we followed the same proce-

dure used in (Bolme et al., 2010). Thus, the track-

ing performance of the proposed method was evalu-

ated by manually labeling the results as good track-

ing; tracking had drifted off center, or lost. A track

is described as good track when the track center is

within the object; labeled as drifted track when the

track center is located outside of the object bound-

ary and a track stated to be lost whenever track gate

ceases its existence in the presence of the target. One

exemplary illustration is given in Fig. 8 for good and

drifted tracks respectively.

For the experiments, the VIVID dataset is pre-

ferred due to the challenges on each scenario includ-

ing out of plane rotation, pose variation, occlusion,

low contrast, existence of similar targets in the vicin-

ity and defocusing. Since the algorithm is designed to

be used with single band images (especially for IR),

Figure 8: Examplary outputs showing the drifted track, on

left, and successful track, on right.

VISAPP2015-InternationalConferenceonComputerVisionTheoryandApplications

Figure 9: Sample result on VIVID dataset. Top row, columns 1-2: Scale changes. Top row, columns 2-4: Defocusing. Bottom

row, columns 1-2: Different motion patterns, changing number of targets. Bottom row, columns 3-4: Occlusion.

the 3-channel sequences of the dataset are converted

to grayscale. However, extending the scheme to RGB

requires nothing but replacing edge detection phase

with an RGB compatible version.

For each scenario, effective saliency and compact-

ness thresholds were set to 0.7 and 0.4, respectively.

The variance of the normal distribution that was used

to generate target likelihood maps was set to 0.15 and

a three-level pyramid structure was used: 1

level

processing original image, 2

level processing orig-

inal image downsampled by 2 and 3

level by 3.

Since optimum number of scales depends on the span

of expected target size, minimum number of scales

should manually be selected considering the applica-

tion. Likewise, shape and window size of the morpho-

logical operator should also be selected accordingly.

In the testing procedure, a 5x5 circular shaped opera-

tor is used.

In Figure 9, some of the important ﬁndings of the

experimental results are demonstrated. The ﬁrst two

images of the ﬁrst row illustrates the success of the al-

gorithm against scale changes which is achieved with

the usage of pyramid structure. Remaining images

of the ﬁrst row demonstrates the behavior of the pro-

posed method in case of missing observations. In

this scenario, the target detection fails for a while

due to defocusing of the camera. Despite the missing

observations, tracks are continued without breaking

and the targets are again well localized after refocus-

ing of the camera. However, one should note that a

false alarm is generated after the defocusing since the

Canny threshold is automatically adjusted to tolerate

the low contrast. The importance of the selection of

a simple motion model (maximum velocity) is illus-

trated on the ﬁrst two images of the 2

row. If a re-

strictive probabilistic motion model was used, some

of the targets having different turning angles would

be lost. Moreover, these sub-ﬁgures also visualizes

the success in handling varying number of targets. Fi-

nally, last two images of the second row visualizes

the major weakness of the proposed algorithm which

is the incapability of occlusion handling resulting in

track losses.

Table 1: Performance results of proposed method for detec-

tion and tracking on VIVID dataset (in percentage %).

Dataset

False Detection

Rate (FDR)

True Positive

Rate (TPR)

Track

Quality

egTest01 0.626 94.098 98.651

egTest02 10.521 77.188 99.440

egTest03 18.127 74.124 88.631

egTest04 4.676 83.203 81.478

Total 8.487 82.153 92.050

The results of the experiments are summarized in

Table 1. According to the results, target selection

scheme can detect ≈ 82% of the targets with an ac-

ceptable FDR of ≈ 8.5% . Moreover, ≈ 92% of the

detected targets were tracked successfully, meaning

that the window was not drifted off of the center of the

object. In addition to the detection and tracking per-

formance of the proposed method, another important

aspect is the computational load. The proposed solu-

tion was tested using un-optimized C++ code running

on a single core of an Intel i5-3470 3.2GHz CPU and

was able to run at a minimum rate of 30.12fps and an

average rate of 35.63fps for maximum 256 target hy-

potheses at each scale of the pyramid. Note that, the

frame-rate can further be improved by using parallel

processing or advanced optimization techniques.

The results show that it is possible to have both

detection and tracking with a sufﬁcient quality and

low computational cost using the proposed method.

More importantly, the results imply that it is possi-

ble to achieve an acceptable tracking performance by

simply using spatial distance minimization of mea-

AReal-time,AutomaticTargetDetectionandTrackingMethodforVariableNumberofTargetsinAirborneImagery

surements with an appropriate detection scheme.

4 CONCLUSIONS

In this study, a multi-target detection and tracking

method designed for real-time systems is introduced.

The experiments showed that the proposed algorithm

achieves a sufﬁcient true positive rate with a rela-

tively low false discovery rate on the utilized test sets.

Moreover, it is also seen that, usage of a successful

detection scheme reduces the complexity of tracker;

and even with the simplest association scheme, a suf-

ﬁcient tracking performance can be obtained.

Usage of the designed algorithm introduces many

advantages including time efﬁciency, scale-invariance

and adaptability to changing number of targets in the

scene. Moreover, the algorithm requires no super-

vision which makes it a suitable option for electro-

optical surveillance and reconnaissance systems. On

the other hand, the algorithm is shown to have some

disadvantages. Although the proposed method can

achieve tracking with high frame rates, it has no

mechanism for occlusion handling which decreases

the performance. Another signiﬁcant disadvantage of

this algorithm is caused by the target hypothesis gen-

eration method: Canny edge detection method may

fail on low contrast scenes despite its dynamic thresh-

olding scheme since edge detection may fail in low

contrast.

As a future work, we plan to employ tracklet

concept to increase the performance of the proposed

method on the scenes where frequent occlusions are

present. Also we plan to work on the target hypothe-

ses generation scheme to make the proposed method

invariant to the properties of the input imaging system

yielding increased robustness and reliability.

REFERENCES

Achanta, R., Hemami, S., Estrada, F., and Susstrunk, S.

(2009). Frequency-tuned salient region detection.

In Computer Vision and Pattern Recognition, 2009.

CVPR 2009. IEEE Conference on, pages 1597–1604.

Andriyenko, A. and Schindler, K. (2011). Multi-target

tracking by continuous energy minimization. In Com-

puter Vision and Pattern Recognition (CVPR), 2011

IEEE Conference on, pages 1265–1272. IEEE.

Aytekin, C., Tunalı, E., and

Oz, S. (2014). Fast semi-

automatic target initialization based on visual saliency

for airborne thermal imagery. In Proceedings of

the 9th International Conference on Computer Vision

Theory and Applications, Visapp’14, pages 490–497.

Bay, H., Ess, A., Tuytelaars, T., and Van Gool, L. (2008).

Speeded-up robust features (surf). Computer vision

and image understanding, 110(3):346–359.

Berclaz, J., Fleuret, F., Turetken, E., and Fua, P. (2011).

Multiple object tracking using k-shortest paths opti-

mization. Pattern Analysis and Machine Intelligence,

IEEE Transactions on, 33(9):1806–1819.

Bolme, D. S., Beveridge, J. R., Draper, B. A., and Lui, Y. M.

(2010). Visual object tracking using adaptive correla-

tion ﬁlters. In Computer Vision and Pattern Recogni-

tion (CVPR), IEEE Conference on, pages 2544–2550.

Canny, J. (1986). A computational approach to edge detec-

tion. Pattern Analysis and Machine Intelligence, IEEE

Transactions on, (6):679–698.

Cheng, M., Zhang, G., Mitra, N. J., Huang, X., and Hu,

S. (2011). Global contrast based salient region detec-

tion. In Proceedings of the 2011 IEEE Conference on

Computer Vision and Pattern Recognition, CVPR ’11,

pages 409–416. IEEE Computer Society.

Fortmann, T. E., Bar-Shalom, Y., and Scheffe, M. (1980).

Multi-target tracking using joint probabilistic data as-

sociation. In Decision and Control including the Sym-

posium on Adaptive Processes, 1980 19th IEEE Con-

ference on, volume 19, pages 807–812. IEEE.

Harris, C. and Stephens, M. (1988). A combined corner and

edge detector. In Alvey vision conference, volume 15,

page 50. Manchester, UK.

Hou, X. and Zhang, L. (2007). Saliency detection: A spec-

tral residual approach. In Computer Vision and Pat-

tern Recognition, 2007. CVPR ’07. IEEE Conference

on, pages 1–8.

Kalman, R. E. (1960). A new approach to linear ﬁltering

and prediction problems. Journal of Fluids Engineer-

ing, 82(1):35–45.

Lowe, D. G. (2004). Distinctive image features from scale-

invariant keypoints. International journal of computer

vision, 60(2):91–110.

Niedfeldt, P. C. and Beard, R. W. (2014). Multiple target

tracking using recursive ransac. In American Control

Conference (ACC), 2014, pages 3393–3398. IEEE.

Otsu, N. (1979). A threshold selection method from gray-

level histogram. IEEE Transactions on System Man

Cybernetics, SMC-9, No:1:62–66.

Parzen, E. (1962). On estimation of a probability density

function and mode. The annals of mathematical statis-

tics, pages 1065–1076.

Prewitt, J. M. (1970). Object enhancement and extraction.

Picture processing and Psychopictorics, 10(1):15–19.

Ramakoti, N., Vinay, A., and Jatoth, R. K. (2009). Par-

ticle swarm optimization aided kalman ﬁlter for ob-

ject tracking. In Advances in Computing, Control, &

Telecommunication Technologies, 2009. ACT’09. In-

ternational Conference on, pages 531–533. IEEE.

Reid, D. B. (1979). An algorithm for tracking multiple

targets. Automatic Control, IEEE Transactions on,

24(6):843–854.

Ristic, B., Arulampalam, S., and Gordon, N. (2004). Be-

yond the Kalman ﬁlter: Particle ﬁlters for tracking

applications, volume 685. Artech house Boston.

VISAPP2015-InternationalConferenceonComputerVisionTheoryandApplications

Rosten, E. and Drummond, T. (2006). Machine learning

for high-speed corner detection. In Computer Vision–

ECCV 2006, pages 430–443. Springer.

Sobel, I. and Feldman, G. (1968). A 3x3 isotropic gradient

operator for image processing. a talk at the Stanford

Artiﬁcial Project in, pages 271–272.

Tsai, C., Dutoit, X., Song, K., Van Brussel, H., and Nuttin,

M. (2010). Robust face tracking control of a mobile

robot using self-tuning kalman ﬁlter and echo state

network. Asian Journal of Control, 12(4):488–509.

VIVID (2005). http://vision.cse.psu.edu/data/vivideval/

datasets/datasets.html.

Wei, Y., Wen, F., Zhu, W., and Sun, J. (2012). Geodesic

saliency using background priors. In Proceedings of

the 12th European conference on Computer Vision -

Volume Part III, ECCV’12, pages 29–2, Berlin, Hei-

delberg. Springer-Verlag.

Yilmaz, A., Javed, O., and Shah, M. (2006). Object track-

ing: A survey. Acm computing surveys (CSUR),

38(4):13.

AReal-time,AutomaticTargetDetectionandTrackingMethodforVariableNumberofTargetsinAirborneImagery
