Method of Screening the Health of Persons with High Risk for

Potential Lifestyle-related Diseases using LDA

Toward a Better Screening Method for Persons with High Health Risks

Keisuke Ogawa

, Kazunori Matsumoto

, Masayuki Hashimoto

and Ryoichi Nagatomi

KDDI R&D Labs, Saitama, Japan

Tohoku Graduate School of Biomedical Engineering, Miyagi, Japan

Keywords: Latent Dirichlet Allocation, LDA, Metabolic Syndrome, Lifestyle-Related Disease.

Abstract: Recently, the number of patients with lifestyle-related diseases, such as diabetes mellitus, has increased

dramatically. Lifestyle-related diseases are responsible for 60% of deaths in Japan. In order to screen

persons at potentially high risk for these diseases, medical checkups for metabolic syndrome are used

throughout Japan. Prediction and prevention of lifestyle-related diseases would yield a direct reduction in

medical costs. However, many cases cannot be screened with a metabolic syndrome checkup. In this paper,

we propose a new machine-learning-based screening method using medical checkup data and medical

billings. By processing the medical data into a bag-of-words representation and classifying the health factors

using latent Dirichlet allocation (LDA), the screening method achieves high accuracy. We evaluate the

method by comparing the accuracy of predictions of the future incidence of the diseases. The results show

that F-measure increases 0.17 compared with the conventional method. In addition, we confirmed that the

proposed method classified persons with different health risk factors, such as a combination of metabolic

disorders, hypertensive disorders, and mental disorders (stress).

1 INTRODUCTION

The number of patients with lifestyle-related

diseases, such as diabetes mellitus, has increased

dramatically. Lifestyle-related diseases are

responsible for 60% of the deaths in Japan (Health,

Labour and Welfare Statistics Association 2002). In

general, the medical costs related to lifestyle-related

diseases are expensive and occupy 30% of national

medical expenditures (Ministry of Health, Labour

and Welfare 2010). In Japan, to save medical costs,

the health insurance society sponsors an annual

medical checkup to screen persons with high health

risks, such as metabolic syndrome. Metabolic

syndrome is a combination of multiple metabolic

disorders; specifically, a combination of obesity and

hyperglycemia, hypertension, or dyslipidemia

(WHO 1999; Ogushi 2007). Patients with metabolic

syndrome have a greater possibility of acquiring

lifestyle-related diseases such as diabetes mellitus or

cardiovascular disease (K.G.M.M. Alberti et al.

2006). However, many cases cannot be screened

with a metabolic syndrome checkup. In our

investigation of a specific health insurance society,

only 14% of people with newly diagnosed lifestyle-

related diseases have metabolic syndrome. This fact

indicates that there are other risk factors for

lifestyle-related diseases (Maria D. Llorente et.al.

2006; H. Klar Yaggi 2006). As a result, many people

at high risk for these diseases are missed. So the cost

effect of annual medical checkups is limited. In this

paper, to solve this problem, we propose the

machine-learning-based screening method that uses

not only annual medical checkup data, but also

medical billings. They involve the personal history

of diseases that infers the various health risk factors.

2 LIFESTYLE-RELATED

DISEASES AND SCREENING

2.1 Lifestyle-related Diseases

The Ministry of Health, Labour and Welfare in

Japan defined a list of lifestyle-related diseases

(Mizushima research team of the Ministry of Health,

Labour and Welfare 2007). To prevent these

diseases, Japan developed the criteria to diagnose

metabolic syndrome in the Japanese.

502

Ogawa K., Matsumoto K., Hashimoto M. and Nagatomi R..

Method of Screening the Health of Persons with High Risk for Potential Lifestyle-related Diseases using LDA - Toward a Better Screening Method for

Persons with High Health Risks.

DOI: 10.5220/0005250905020507

In Proceedings of the International Conference on Health Informatics (HEALTHINF-2015), pages 502-507

ISBN: 978-989-758-068-0

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

2.2 Metabolic Syndrome

In Japan, the decision to diagnose metabolic

syndrome is based on the following criteria: waist

circumference, blood sugar level, HbA1c, systolic

blood pressure, diastolic blood pressure,

triglycerides, HDL cholesterol, and LDL cholesterol,

and people are classified into the metabolic

syndrome group, preliminary group, and normal

group. The screening method is explained in Figure

1 (Wataru et al. 2008).

Figure 1: Screening for metabolic syndrome in Japan.

This screening checks only the combination of four

risk factors: the combination of obesity and

hyperglycemia, hypertension, or dyslipidemia.

However, there are other risk factors reported, such

as mental disorders (Maria D. Llorente et al. 2006; H.

Klar Yaggi 2006). Therefore, many persons at high

risk for these diseases cannot be screened by this

method.

3 PROPOSED METHODS

To realize a screening method that can identify the

various health risk factors, we propose a machine-

learning-based screening method using medical

checkup data and medical billings. In general,

medical checkup data involve blood tests that

indicate health status, and medical billings involve

personal medical history that involves information

about all diseases. Technical knowledge is needed to

make the rules using medical billings for decisions

like metabolic syndrome. Thus, we applied machine-

learning techniques to handle the huge volume of

data statistically. In this paper, we propose using

latent Dirichlet allocation (LDA) (Blei et al. 2003).

LDA is a kind of topic model where machine-

learning techniques are mainly used for natural

language processing. With LDA, we can model data

(such as documents) as a mixture of multiple topics

more precisely than the mixed Gaussian distribution

such as k-means.

3.1 Latent Dirichlet Allocation

LDA has the advantage of easily modeling

documents and is now applied to various data

mining tasks, such as information retrieval and voice

recognition (Ishiguro et al. 2012; Otsuka et al. 2012),

data visualization, and image processing (Fei-Fei et

al. 2005; Wang et al. 2009; Wang and Mori 2009;

Niebles et al. 2008). LDA infers the topic of

documents containing many words from a document

set by assigning each word to a certain topic. In

LDA, documents are handled as a bag-of-words

representation, and these documents are analyzed

according to a word-topic probability matrix ( ϕ

matrix) and topic-document probability matrix (θ

matrix). Some approximation techniques estimate

the parameters of LDA, such as variational Bayes

(Blei et al. 2003), Gibbs sampling (Griffiths and

Steyvers 2004), and collapsed variational Bayes

(The et al. 2006). In this paper, we use the Gibbs

(Griffiths and Steyvers 2004) technique. Now, we

explain and review LDA following the notation of

(Griffiths and Steyvers 2004). Let there be T topics

and 



,…



represent bag-of-words representations

for each D document. (Document d becomes







,

,…

,

 where N be number of all types

of words. ) Also, let 



be the hidden topic from

which 



is generated, 





|, and







 for document d. LDA involves the

following generative model:

θ~Dirα





|









~







ϕ~Dirβ





|



,~







Dir and Mult mean the Dirichlet distribution and

multinomial distribution, respectively. α and βare

hyperparameters for the document-topic and topic-

word Dirichlet distributions, respectively. Here we

assume α and β are scalars resulting in symmetric

Dirichlet priors. Given observed words, we have to

infer the hidden topics. To approximate this

posterior, we resort to a Markov chain Monte Carlo

(MCMC) sampling scheme, specifically a collapsed

Gibbs sampling:

1.Confirmriskfactorofaccumulationofvisceralfat

・waistcircumference

>85centimeters(male)

>90centimeters(female)

2.Confirmadditionalriskfactors

hyperglycemia

hypertension

hyperlipidemia

・Bloodsugarlevel>110mg/dl

・HbA1c>5.5%

・Takingmedicineofdiabetesmellitus

・Triglyceride>150mg/dl

・HDLcholesterol<40mg/dl

・Takingmedicineofdyslipidemia

・SystolicBP>130mmHg

・DiastolicBP>85mmHg

・Takingmedicineofhypertension

3.Decision

RiskfactorNo.1

RiskfactorNo.2

RiskfactorNo.3

RiskfactorNo.4

Anyoneoftheseconditions

visceralfat

Anyoneoftheseconditions

Thecasethatsubjectpersonhas

・bothriskfactorNo.1and anytwoofadditionalfactors(No.2~4)

・bothriskfactorNo.1and anyoneofadditionalfactors(No.2~4)

・Exceptthecasesabove

Metabolicsyndromegroup

Preliminarygroup

Notmetabolicgroup

MethodofScreeningtheHealthofPersonswithHighRiskforPotentialLifestyle-relatedDiseasesusingLDA-Towarda

BetterScreeningMethodforPersonswithHighHealthRisks

503

P



k|



,w,α,β

∝



,





∑



,

















,









∑



,





′









′



where 

,



is the number of times topic k is used in

document d, and 

,







is the number of times word





is generated by topic k. The −i notation signifies

that the counts omit the value of 



. Here, we regard

the document as a person, words as the frequency of

word counts in medical billings and discretized

medical checkup data, and the topic as a health

factor, respectively.

3.2 Feature Extraction

In this subsection, we show the feature extraction

from medical checkup and medical billing data.

Medical billing is a receipt for medical activity that

the health insurance society uses to pay the medical

cost to the medical institution. It involves the name

of the disease, medicine, and inspection as decided

by physicians. We use the frequency of the disease,

medicine, and inspection from medical billings in

one year as a feature vector of LDA. The maximum

frequency is 12 because medical billings are

generated once a month. Table 1 shows examples of

the features of medical billings.

Table 1: Features of medical billings.

For medical checkups, blood tests, measurements,

and questionnaires about lifestyle and medicines are

involved. In this paper, we use only blood test and

measurement data (Table 2).

Table 2: Medical checkup data.

Also, because medical checkup data are continuous

data different from medical billings, we transform

the data into a bag-of-words representation that can

be used in the LDA (Figure 2).

Figure 2: Data preparation in proposed method.

The blood test and measurement data are not always

in a normal distribution, so we make the data

discrete using a cumulative distribution. Also, in

general, blood test and measurement data have

multiple medical meanings according to the value,

so we represent the data as a mixture of the

frequency of three words: high, normal, and low.

Specifically, we divide the checkup data into 13

classes and assign each pair of words in Figure 3.

Figure 3: Bag-of-words representation of medical checkup

data.

For example, in class 1, the bag-of-words

representation becomes {high-value-words of waist,

normal-value-words of waist, low-value-words of

waist} = {0,0,12}, in class 2, the bag-of-words

representation becomes {0,1,11} and so on.

Disease Medicine Inspection

Name Frequency Name Frequency Name Frequency

DiabetesMellitus 8 Mucodyne 100mg 8 Albumin 3

Allergic rhinitis 5 Zyloric 6 Bloodureanitrogen 3

Hyperuricemia 3 Seibule 6 Creatinie 3

・・・・・・・・・・・・・・・・・・

Measurement data Bloodtestdata

Height triglyceride

Weight HDLcholesterol

BMI LDLcholesterol

Waistcircumference GOT

Diastolic pressure GPT

Systolicpressure γ‐GTP

Fastingbloodsugarlevel

HbA1c

Ratioofwordsthatmean“lowvalue”

Ratioofwordsthatmean“normalvalue”

Ratioofwordsthatmean“highvalue”

Frequencyofperson

Waist(checkupdata)

Class1

Class2

Class3

Class4

Class5

Class6

Class7

Class8

Class9

Class10

Class11

Class12

Class13

Class1

Class2

Class3

Class4

Class5

Class6

Class7

Class8

Class9

Class10

Class11

Class12

Class13

HEALTHINF2015-InternationalConferenceonHealthInformatics

504

4 EXPERIMENT AND RESULTS

4.1 Arrangement of Experiments

To compare the prediction accuracy for the future

incidence of the diseases by the proposed method

with that by conventional metabolic syndrome

decisions, we perform experiments. We use the

medical checkup data and medical billings of a

specific common insurance society with about

30,000 members. We used data on men in 2010

(4404 members) for training LDA. To evaluate the

methods, we measured precision and recall for

persons who did not have medical billings for

lifestyle-related diseases in 2009 but who developed

lifestyle diseases in 2011–2013. Also, we set the

hyperparameter of LDA in Table 3.

Table 3: Hyperparameters of LDA.

4.2 Comparison with Conventional

Metabolic Syndrome Decision

We show the result of LDA (topic number is 3) and

metabolic syndrome in Table 4-1 and Table 4-2.

Persons are classified into 3 groups by metabolic

syndrome decision, so we use the same 3

topics(groups) in LDA. In LDA, we assign the topic

of the highest probability to each person. In Table 4-

1 and Table 4-2, extraction rate of new cases of

lifestyle-related diseases in 2010-2013(ratio of

numbers for each group to number of new cases of

lifestyle-related diseases) is shown as precision. (We

exclude people who already had medical billings for

lifestyle-related diseases in 2009 (already

developed).)

Table 4-1: Conventional screening result.

Table 4-2: Screening result of the proposed method.

†Number of new cases of lifestyle-related diseases in 2010-2013.

‡Number of lifestyle-related disease patients in 2009.

As a result, topic number 3 for LDA has the highest

F-measure (topic number 3). In this result, we think

topic number 3 is a high-risk cluster that involves

many persons at potentially high risk for lifestyle-

related diseases. In addition to this result, we can see

the health risk factors. Now, we look into the ϕ

matrix of these topics. In Tables 5-1 and 5-2, the

major terms for disease in the ϕ matrix and average

frequency for a person and averaged medical

checkup data for persons in each topic are shown.

Table 5-1: Major disease terms in ϕ matrix and averaged

frequency for a person (topic number 3).

Table 5-2: Averaged medical checkup data for persons in

each topic (topic number 3).

For example, in topic 2, the probability of lifestyle

diseases, such as hypertension, diabetes mellitus,

and hyperuricemia, is the highest but other topics are

not. Looking into Table 5-2, almost all of the

medical checkup data (except height, fasting blood

sugar level, and HDL cholesterol) in topic 3 are

higher than topic 1. So, from these results, we can

approximate that topic number 1 is the healthy

people topic, topic number 2 is the lifestyle disease

patient topic, and topic number 3 is the unhealthy

people topic.

α(Hyperparameter of

dirichlet priordist.)

β(Hyperparameter of

dirichlet priordist.)

0.1 0.01

L(Learningcountin

GibbsSampler)

40000

Group(Metabo

decision)

Number Numberof

outbreaks†

Numberof

excluded cases‡

Precision Recall F‐measure

Normal 2533 759 576 0.30 0.66 0.41

Preliminary 521 216 209 0.41 0.19 0.26

Metabolic 279 174 289 0.62 0.15 0.24

Group(Main

Top ic Number)

Number Numberof

outbreaks†

Numberof

excluded cases‡

Precision Recall F‐measure

1 1803 484 261 0.27 0.42 0.33

2 66 36 379 0.55 0.03 0.06

3 1464 629 431 0.42 0.55 0.48

Topic 1 Topic 2Topic3

Allergic rhinitis 0.39 1.40 0.40

Myopicastigmatism 0.19 0.55 0.13

Allergicconjunctivitis 0.13 0.28 0.14

・・・・・・・・・・・・

Hypertension 0.13 3.1 0.42

DiabetesMellitus 0.09 2.5 0.19

Hyperuricemia 0.09 1.7 0.18

・・・・・・・・・・・・

Acutebronchitis 0.13 0.31 0.15

Acuteupper respiratoryinflammation 0.10 0.22 0.12

MajorwordsofdiseaseinΦmatrix Averaged Frequencyfora

person

Topi c 1Topic2Topic3

Height

170.7 169.9 171.7

Weight

63.5 71.7 76.0

BMI

21.8 24.8 25.8

Waist

78.4 86.3 89.2

Diastolic pressure

117.6 124.0 126.5

Systolicpressure

75.0 80.6 82.8

triglyceride

99.7 146.4 166.5

HDLcholesterol

61.2 55.3 51.6

LDLcholesterol

116.3 117.0 130.4

GOT

19.9 25.9 26.6

GPT

19.9 31.7 36.3

γ‐GTP

39.1 61.6 66.8

Fastingbloodsugarlevel

90.2 105.5 96.6

HbA1c

5.0 5.6 5.3

MethodofScreeningtheHealthofPersonswithHighRiskforPotentialLifestyle-relatedDiseasesusingLDA-Towarda

BetterScreeningMethodforPersonswithHighHealthRisks

505

4.3 Proposal with More Topic

Numbers

In the proposed method, we can determine the topic

numbers at will. Here, we show the result of LDA

where the topic number increases. In Table 6, the

result of topic number 10 is shown. Here, also, we

exclude people who already had medical billings for

lifestyle-related diseases in 2009 (already

developed).

Table 6: Screening result of proposed method (number of

topics: 10).

In the result, topics 3, 4, 5, 6, and 9 reflect high

precision rates. Looking into major terms for disease

in the ϕ matrix and average frequency for a person

(in Table 7-1) and averaged medical checkup data

(in Table 7-2), we can see that the risk factors are

separated more precisely.

Table 7-1: Major disease terms in ϕ matrix and averaged

frequency for a person (topic number 10).

In topics 3 and 4, there are no diseases with high

probability. Topic 5 has insomnia, melancholy, and

the digestive disease gastritis (Table 9-1). On the

other hand, the checkup data of topic 3 are much

higher than that of others, especially the metabolic

disorder related items. Also, in topic 4, only blood

pressure is higher (Table 9-2). So, it seems that the

risk factors for topics 3 and 4 are abnormal checkup

values (combination of metabolic disorders and

hypertensive disorders, respectively), and the risk

factor for topic 5 is stress (mental disorders).

Table 7-2: Averaged medical checkup data for persons in

each topic (topic number 10).

Also, topics 6 and 9 have different diseases. In topic

6, the probability of digestive disease and liver

disease is higher, and in topic 9, the probability of

cardiovascular disease is higher. So, from these

results, we assume that topics 3, 4, and 5 are

unhealthy people topics with different health risk

factors (combination of metabolic disorders,

hypertensive disorders, and mental disorders) and

that topics 6 and 9 are lifestyle disease patient topics

with different lifestyle-related diseases (digestive,

liver and, cardiovascular diseases). Thus, we think

the topics are separated by different health risk

factors.

5 CONCLUSIONS

In this paper, we propose a new screening method

using latent Dirichlet allocation (LDA). By making

the medical checkup data and medical billings into a

bag-of-words representation, the screening method

achieves high accuracy. We evaluate the method by

comparing the accuracy of predictions for the future

incidence of the diseases. The result shows that F-

measure increases 0.17 compared with the

conventional method. In addition, by increasing the

topic numbers, we confirmed that the proposed

method classified high risk persons into each of the

different health factors of combination of metabolic

disorders, hypertensive disorders, and mental

disorders. Thus, we think the topics are separated by

different health risk factors.

REFERENCES

Mizushima Research Team of the Ministry of Health,

MainTopic 

Number

Number Numberof

outbreaks

Numberof

excluded cases

Precision Recall F‐measure

550 139 62 0.25 0.12 0.17

301 87 56 0.28 0.08 0.12

1079 478 370 0.44 0.42 0.43

136 46 19 0.34 0.04 0.07

79 33 76 0.42 0.03 0.06

43 24 145 0.56 0.02 0.04

337 100 44 0.30 0.09 0.14

732 214 135 0.29 0.19 0.23

7 6 183 0.86 0.01 0.02

69 22 121 0.31 0.02 0.04

Words Frequency Words Frequency Words Frequency

Allergic rhinitis 0.43 Ribfracture 0.01 Insomnia 2.67

・・・・・・

Melancholy 2.51

Gastritis

・・・

0.92

Words Frequency Words Frequency

Stomach ulcer:1.59 Hypertension 4.7

Diabetes mellitus: 1.95 Hyperlipidemia 4.81

Liverdysfunction

・・・

0.81 Diabetes mellitus

・・・

3.47

Topic 3 Topic 4 Topic5

Topi c6Topic9

Topi c3Topic4Topic5Topic6Topic9

Height

172.5 168.3 170.2 170.3 169.2

Weight

77.9 65.2 67.2 69.2 72.4

BMI

26.2 23.0 23.2 23.8 25.3

Waist

90.6 80.5 82.1 83.8 87.5

Diastolic pressure

129.4 126.5 117.7 120.0 125.1

Systolicpressure

85.1 81.0 76.6 77.7 80.8

triglyceride

168.3 81.5 127.7 136.8 159.2

HDLcholesterol

51.4 65.1 57.4 55.8 55.2

LDLcholesterol

130.6 97.1 121.3 115.6 114.0

GOT

27.3 20.9 22.2 23.4 26.8

GPT

38.2 21.0 24.5 25.7 33.5

γ‐GTP

67.9 43.0 48.7 50.7 65.9

Fastingbloodsugarlevel

98.3 86.8 89.1 102.1 110.9

HbA1c

5.34.95.05.45.9

HEALTHINF2015-InternationalConferenceonHealthInformatics

506

Labour and Welfare, Report of Lifestyle-Related

Disease Administration Using Medical Checkup and

Billing Data 2007.

Health, Labour and Welfare Statistics Association, Trend

of National Health, Journal of Health and Welfare

Statistics: 449-453, 2002.

Ministry of Health, Labour and Welfare, Overview of

national medical cost in 2010, http://www.mhlw.

go.jp/toukei/saikin/hw/k-iryohi/10/, 2010.

K. G. M. M. Alberti, P. Zimmet and J. Shaw, Metabolic

syndrome—a new world-wide definition. A

Consensus Statement from the International Diabetes

Federation, Diabetic Medicine, 23:469-480, 2006.

Maria D. Llorente and Victoria Urrutia, Diabetes,

Psychiatric Disorders, and the Metabolic Effects of

Antipsychotic Medications, Journal of Clinical

Diabetes, Vol.24 No.1:18-24, 2006.

H. Klar Yaggi, Andre B. Araujo and John B. McKinlay,

Sleep Duration as a Risk Factor for the Development

of Type 2 Diabetes, Journal of Diabetes Care, Vol.29

No.3:657-661,2006.

World Health Organization (WHO), Definition, Diagnosis

and Classification of Diabetes Mellitus and its

Complications, Report of a WHO consultation, 1999.

Ogushi, Metabo no wana, Kadokawa shinsho, 2007.

Wataru Sakamoto, Naoki Isogawa, and Masashi Goto,

Statistical problem of Japanese metabolic syndrome

criteria, The Behaviometric Society of Japan, 69:177-

192, 2008.

David M. Blei. Ng, A. Y. and Jordan, M. I., Latent

Dirichlet Allocation. Journal of Machine Learning

Research 3:993-1022, 2003.

Fei-Fei.L. and Perona P., A Bayesian Hierarchical Model

for Learning Natural Scene Categories, CVPR 2005.

IEEE Computer Society Conference, 2005.

Chong Wang, David M. Blei, and Li Fei-Fei,

Simultaneous image classification and annotation,

CVPR 2009, IEEE Conference, 2009.

Yang Wang, and Greg Mori, Human Action Recognition

by Semi-latent Topic Models, Pattern Analysis and

Machine Intelligence, IEEE Transactions, 2009.

Niebles et al., Unsupervised Learning of Human Action

Categories Using Spatial-Temporal Words,

International Journal of Computer Vision, Vol.

79:299-318,2008.

Griffiths T.L. and Steyvers M., Finding scientific topics,

proceedings of the National Academy of Science,

101:5228-5235, 2004.

Yee Whye Teh et al., A Collapsed Variational Bayesian

Inference Algorithm for Latent Dirichlet Allocation,

NIPS, Vol. 19, 2006.

Ishiguro et al., Probabilistic Speaker Diarization with Bag-

of-Words Representations of Speaker Angle

Information, IEEE Transcription, Vol. 20(2):447-460,

2012.

Otsuka et al., Bayesian Unification of Sound Source

Localization and Separation with Permutation

Resolution, Proc. AAAI, 2012.

MethodofScreeningtheHealthofPersonswithHighRiskforPotentialLifestyle-relatedDiseasesusingLDA-Towarda

BetterScreeningMethodforPersonswithHighHealthRisks

507
