On the Claim for the Existence of “Adversarial Examples”

in Deep Learning Neural Networks

Costas Neocleous

and Christos N. Schizas

Department of Mechanical Engineering and Materials Science and Engineering,

Cyprus University of Technology, 30 Archbishop Kyprianou Str., 3036, Limassol, Cyprus

Department of Computer Science, University of Cyprus, 1 University Avenue, 2109, Nicosia, Cyprus

Keywords: Deep Neural Networks, Adversarial Examples, Feature Distribution in Neural Networks.

Abstract: A recent article in which it is claimed that adversarial examples exist in deep artificial neural networks

(ANN) is critically examined. The newly discovered properties of ANNs are critically evaluated.

Specifically, we point that adversarial examples can be serious problems in critical applications of pattern

recognition. Also, they may stall the further development of artificial neural networks. We challenge the

absolute existence of these examples, as this has not been universally proven yet. We also suggest that ANN

structures, that correctly recognize adversarial examples, can be developed.

1 INTRODUCTION

In a recent paper that has been presented by a team

of researchers from Google, Facebook, New York

University and the University of Montreal (Szegedy

et al., 2014) at the 2

International Conference on

Learning Representations in April 2014, two

debatable and counter-intuitive properties of deep

neural networks were claimed. In the authors own

words (hereby quoted in italics), these are (bold

letters indicate the most important points):

QUOTES

CLAIM #1: On the distribution of semantic

information

…Generally, it seems that it is the entire

space of activations, rather than the

individual units, that contains the bulk of

the semantic information…

CLAIM #2: On the existence of adversarial

examples

…we find that applying an imperceptible

non-random perturbation to a test image, it

is possible to arbitrarily change the

network’s prediction. These perturbations

are found by optimizing the input to maximize

the prediction error. We term the so per-

turbed examples “adversarial examples”…

and elswhere,

… we found that adversarial examples are

relatively robust, and are shared by neural

networks with varied number of layers,

activations or trained on different subsets of

the training data. That is, if we use one

neural to generate a set of adversarial

examples, we find that these examples are

still statistically hard for another neural

network even when it was trained with

different hyperparemeters or, most

surprisingly, when it was trained on a

different set of examples.

…Our main result is that for deep neural

networks, the smoothness assumption that

underlies many kernel methods does not hold.

Specifically, we show that by using a simple

optimization procedure, we are able to find

adversarial examples, which are obtained by

imperceptibly small perturbations to a

correctly classified input image, so that it is

no longer classified correctly. This can never

occur with smooth classifiers by their

definition…

…The above observations suggest that

adversarial examples are somewhat

universal and not just the results of

overfitting to a particular model or to the

specific selection of the training set.

306

Neocleous C. and N. Schizas C..

On the Claim for the Existence of “Adversarial Examples” in Deep Learning Neural Networks.

DOI: 10.5220/0005152503060309

In Proceedings of the International Conference on Neural Computation Theory and Applications (NCTA-2014), pages 306-309

ISBN: 978-989-758-054-3

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

In this position paper we attempt to evaluate and

critically appraise the two claims made by Szegedy

et al., henceforth referred to by the abbreviation

SZSBEGF2014.

The SZSBEGF2014 researchers used a large, but

not exhaustive, range of different artificial neural

network (ANN) structures to study the properties

they claim that exist. However, all of them were of

feedforward (FF) topology. The structures studied

ranged from simple to complicated ones, such as the

deep NN paradigms (11-layered MLFF network).

They have also done numerous tests on well-

known machine learning databases. Namely, on the

Mixed National Institute of Standards and

Technology database (MNIST) and on the ImageNet

database. They also did simulations on image

samples from YouTube.

Considering their findings, we will present some

supportive and some counter-supportive arguments

to either claim.

2 CRITIQUE OF THE CLAIM

FOR THE DISTRIBUTION OF

SEMANTIC INFORMATION

The SZSBEGF2014 authors claim that, following

numerous studies on a diverse set of artificial neural

network structures, they had found that “…it seems

that it is the entire space of activations, rather than

the individual units, that contains the bulk of the

semantic information…”.

That is, the various semantic factors are encoded

in a distributive manner in a multitude of artificial

neuronal units rather than in specific single artificial

units (neurons).

This is in contrast to the prevailing theory that

suggests that the activation levels of individual

hidden layer neurons correspond to expressions for a

meaningful feature.

In natural/biological neural networks, it is well

established that different parts of the brain process

different afferent signals. There is a hierarchical

structure, and different modules specialize on

processing specific tasks. Thus, there exists

specificity of function that seems to happen in

modular manner, where groups of neurons, operate

in concerted manners. They process information in a

distributed manner. So, within modules, the

information is distributed and we cannot attribute

specific semantics to specific single neurons.

Based on the previous comments, we propose

that the SZSBEGF2014 claim concerning the

semantic distribution, is correct within the context of

activations of single artificial neurons belonging to a

neural subsystem (module). Different modules

however, can specialize in processing certain

features that are associated to semantic attributes.

It is however difficult, and possibly impossible to

precisely identify the functionality and boundaries of

such modules, and hence the specific attributes they

process. It could be that the distribution properties

that we presume that exist in groups of neurons in a

module, also exist for groups of modules in a larger

supersystem.

It is appropriate to point that the SZSBEGF2014

researchers have done their simulations only on

feed-forward neural structures. But the brain is

highly dynamic, having a vast number of local and

remote feedbacks.

3 CRITIQUE OF THE CLAIM

FOR THE EXISTENCE OF

ADVERSARIAL EXAMPLES

The SZSBEGF2014 researchers claim that they

found blind spots in the process of generalization of

feedforward ANNs. Indeed, they say that by

“…applying an imperceptible non-random

perturbation to a test image, it was possible to

arbitrarily change the network’s prediction…”. If

this is universally true, then we have here a case

where the network generalization is deficient.

This hypothesis and the associated claim has

been tested by the SZSBEGF2014 researchers

through the systematic generation of specific images

(cases) that they called "adversarial samples". That

is, even though they were very similar to some other

samples (having imperceptible differences as seen

by a human eye and brain), they were not correctly

classified.

Basically, the SZSBEGF2014 researchers

developed an optimization algorithm that, starting

from a correctly classified image, tries to find a

small perturbation of this that drives the output of

the network to a wrong classification. The

phenomenon is a case where starting from slightly

different initial conditions, the network gives a

diverse output.

If this is true, we have a serious situation where

feedforward network classifications, and more

specifically the deep neural network paradigms, fail

to generalize. They lead to false classifications, and

thus – for crucial applications – may result to severe

repercussions, that may even lead to human deaths.

OntheClaimfortheExistenceof"AdversarialExamples"inDeepLearningNeuralNetworks

307

It is pointed here that such phenomena have been

well established in engineering and science, as for

example in some dynamic-chaotic systems that are

highly sensitive to initial conditions. In these, a

small perturbation of the initial conditions could

drive the system to totally different extremes

(behaviour).

As pointed, this second claim is a counter-

generalization observation, which may have a

profound negative impact on the development of

ANNs, especially for critical applications such as in

critical medical diagnostic and other systems such as

in autonomous/driverless cars and other vehicles, in

crucial google glass applications, in salvage

operations, in critical/sensitive military applications,

etc.

Here are some more specific examples that may

make one think twice before relying on feedforward

ANNs for decisions:

 A self-driving/autonomous car that uses an

ANN (e.g. deep neural network) does not

recognize a human standing in front of the

car. It may interpret the road as clear,

resulting in highly risky and dangerous

situations for pedestrians.

 An ANN that is used in a critical medical

diagnostic operation that misclassifies as a

false positive a specific cancer image or

medical signal.

 An ANN that is used in military operations

and misclassifies a building as having

terrorists that should be bombed!

 A prisoner convicted to death penalty, where

the realization of this verdict depends on

his/her IQ being above a certain threshold,

which had been wrongly established by an

ANN (e.g. case of Ted Herring in Florida

State, USA).

An interesting issue that comes to mind is

whether such “blind spots” also exist in biological

neural networks. We know that certain blind spots

(static or dynamic) have been observed, e.g. the

attentional blink (Marois et al. 2000; Neokleous et al

2009). This occurs in a large number of individuals.

That is, it has a high statistical significance, but it is

not universal. That is, we may speculate that some

biological neural networks express a uniformly blind

spot.

Even though, for most people, the brain has an

impressive capacity to recognize images in diverse

orientations, lighting conditions, deformations,

modifications, perturbations etc., may occasionally

make wrong classifications, generalizations,

interpretations. It can even properly identify words

in the well-known Cambridge University

observation, popularized by the following extract:

“The phaonmneal pweor of the hmuan mnid,

aoccdrnig to a rscheearch at Cmabrigde Uinervtisy,

it dseno't mtaetr in waht oerdr the ltteres in a wrod

are, the olny iproamtnt tihng is taht the frsit and lsat

ltteer be in the rghit pclae. The rset can be a taotl

mses and you can sitll raed it whotuit a pboerlm.

Tihs is bcuseae the huamn mnid deos not raed ervey

lteter by istlef, but the wrod as a wlohe”.

If it is a fact that the biological brains may

misclassify, misinterpret, miscalculate and

misunderstand, then this creates numerous legal,

ethical, and philosophical questions.

Concerning the claim for the existence of

adversarial examples, we suggest the following

criticism.

a) This is a premature claim. The

SZSBEGF2014 researchers have tested a

large number of ANN structures, but they

were all of feedforward topology. They did

not say whether they have also tested

recurrent structures (dense or sparse). How

could we know whether similar behavior

occurs in artificial neural structures that

have recurrences? We know, for instance

that biological neural networks, and more

profoundly the human brain, are highly

recurrent structures. Thus, more

investigation into this issue is needed.

b) Even though one can conduct extensive

simulations on diverse networks, there will

still be gray areas, unless one manages to

prove in a coherent - preferably

mathematical formalism - that the blind

spots are universal to all network structures.

So, here is a new research field for

exceptional theoreticians!

c) Considering the cases of blind spots in

biological neural recognizing systems such

as the human brain, one can observe that

these blind spots are not universal. Indeed,

one can find human brains that correctly

identify images that they were erroneously

mislabeled by a large population. Thus,

there may be ANNs that can correctly

identify adversarial examples. It is rather a

matter of finding these networks.

In any case, as it is, it should make us very

cautious in building critical applications in which

ANNs are embedded, e.g. in medical diagnostic

systems for critical diseases.

NCTA2014-InternationalConferenceonNeuralComputationTheoryandApplications

308

Indeed, this issue may hold back the development

and application of ANNs, analogous to the Minsky

and Papert effect that held back developments back

in the 1960s.

4 CONCLUSIONS

Adversarial examples, if exist in a universal and

absolute manner, can be serious problems in critical

applications of pattern recognition. They may also

stall the further development of artificial neural

networks. However, their absolute existence has not

been proven. Nor have they been verified in

recurrent neural structures. We believe that

appropriate ANN structures that correctly recognize

adversarial examples, can be found, developed and

applied.

ACKNOWLEDGEMENTS

The Cyprus University of Technology.

The University of Cyprus.

REFERENCES

http://www.image-net.org/ Seen in June 2014.

http://www.nytimes.com/2014/05/31/us/on-death-row-

with-low-iq-and-new-hope-for-a-reprieve.html?_r=0

Seen in June 2014.

LeCun Y., Cortes C., Burges C., The MNIST database of

handwritten digits. http://yann.lecun.com/exdb/mnist/

Seen in June 2014.

Marois R., Chun M., Gore J., 2000, Neural Correlates of

the Attentional Blink, Neuron, Vol. 28, pp. 299–308.

Minsky M., Papert S., 1972, Perceptrons: An Introduction

to Computational Geometry, (2nd edition with

corrections, first edition 1969), The MIT Press,

Cambridge MA.

Neokleous K., Avraamides M., Neocleous C., Schizas C.,

2009. A neural network model of the attentional blink

phenomenon. International Journal of Engineering

Intelligent Systems for Electrical Engineering and

Communications, Vol. 17, pp. 115-126.

Szegedy C., Zaremba W., Sutskever I., Bruna J., Erhan

D., Goodfellow I., Fergus R., 2014. Intriguing

properties of neural networks, 2nd International

Conference on Learning Representations, Rimrock

Resort, Canada, April 14-16, 2014.

OntheClaimfortheExistenceof"AdversarialExamples"inDeepLearningNeuralNetworks

309
