Russian Sub-Word Based Speech Recognition Using

Pocketsphinx Engine

Sergey Zablotskiy and Maxim Sidorov

Institute of Communications Engineering, Ulm University, Ulm, Germany

Keywords:

Russian, LVCSR, Sub-words.

Abstract:

Russian is a synthetic language with a large morpheme-per-word ratio and highly inﬂective nature. These

two peculiarities increase the lexicon size for Russian automatic speech recognition (ASR) by tens of times in

comparison to that for English covering the same out-of-vocabulary (OOV) rate. The employment of sub-word

units is a widely spread state-of-the-art approach to reduce the abundant lexicon and lower the perplexity (PP)

of the language model. The choice of sub-word units affects the accuracy of the entire speech recognition

system, its performance as well as the complexity of the spoken phrase synthesis. Here, different recognition

units are investigated using pocketsphinx-engine while recognizing the vocabulary of several million word

forms. A designed text normalization approach is also brieﬂy presented. This rule-based algorithm allows

keeping diverse Russian abbreviations and numerals in the language model (LM) and avoiding the statistics

distortion. The approach is directly applicable and useful for Russian text-to-speech translation as well.

1 INTRODUCTION

Similarly to the other Slavic languages Russian is

highly inﬂective with a large morpheme-per-word ra-

tio. Five basic parts of Russian speech (a noun, a

verb, an adjective, a numeral and a pronoun) are in-

ﬂected according to different grammatical categories:

6 cases, 3 genders, etc. There are no articles or aux-

iliary words at all. Each word has its own meaning.

All the grammatical information is embedded into the

word itself by the use of grammatical afﬁxes. For

example, “oni prygajut” (they jump), “oni prygali”

(they were jumping), “on prygnut” (they will jump),

“oni prygnuli” (they have jumped). A lot of various

preﬁxes form different meaning nuances of one ba-

sic word. For instance, “on igral” (He was playing),

“on doigral” (He has stopped playing), “on vyigral”

(He has won), “on proigral” (He has lost) and many

others.

The above mentioned language peculiarities re-

sult in an abundance of word forms. For example,

the verb “delat”’(to do) has more than 100 differently

spelt word forms. The vocabulary of 2.3 million word

forms used in this study corresponds to 130 thousand

lemmas only.

Up-to-date non-server ASR systems handle the

lexicon size of several hundred thousand words, if the

real time factor (RTF) is expected to be less than 1

using a standard PC. Such an abundant Russian lexi-

con sophisticates the employment of the full-word N-

gram approach owing to the excessively large compu-

tational time and the necessity of huge statistical data

collection. A signiﬁcantly larger amount of textual

data is also required due to the very relaxed word or-

der constraints in Russian. Even the subject and pred-

icate have no predeﬁned position in the sentence or

may be omitted completely in a grammatically cor-

rect sentence. Although, some word permutations are

meaningless or do not sound naturally.

There are different approaches in literature ad-

dressing the same problem for Russian and other

highly inﬂective or agglutinative languages. The

common way to reduce the lexicon is the employment

of sub-word units. In (Byrne et al., 2000; Arsoy et al.,

2009; Karpov et al., 2011) morphemes are used as

the smallest linguistic components having a semantic

meaning. The syllables (Xu et al., 1996; Shaik et al.,

2011) are often chosen from the speech production

point of view. Different statistically derived units and

units appended by their pronunciation are exploited as

well (Shaik et al., 2011). In some cases the algorithms

are even able to recognize the OOV-words as the com-

bination of sub-words (Bisani and Ney, 2005). Each

type of unit has its own advantages and drawbacks.

For Russian and many other languages the number of

syllables is signiﬁcantly smaller than number of mor-

840

Zablotskiy S. and Sidorov M..

Russian Sub-Word Based Speech Recognition Using Pocketsphinx Engine.

DOI: 10.5220/0005148008400844

In Proceedings of the 11th International Conference on Informatics in Control, Automation and Robotics (ASAAHMI-2014), pages 840-844

ISBN: 978-989-758-040-6

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

phemes for the same full-word dictionary. However,

the major challenge and the source of SR errors is the

word synthesis out of recognized syllables, since they

are mostly smaller in size.

To make the choice of proper Russian sub-words

easier, the comprehensive comparison of different

units is presented in this paper from the SR perspec-

tive. All experiments are conducted under the same

conditions for comparison to be fair.

We also brieﬂy describe here data used for acous-

tic (AM) and language modeling. A special issue

is the preprocessing of texts. Particularly, the han-

dling of abbreviations, Arabic and Roman numerals,

is worth noting, since their inﬂection mostly depends

on the context and grammar and is not the trivial task

for Russian.

2 ACOUSTIC MODELING

Since the basic idea of this study is a fair compar-

ison of different sub-word LMs, all the phonemes

(senones) were trained only once. The same set of

phonemes and corresponding HMMs were used in

each experiment for all sub-word units. Pronuncia-

tion dictionaries were built in a way, that the pho-

netic transcriptions of concatenated sub-words coin-

cide with the corresponding full-word transcriptions.

That was done by modifying a grapheme-to-phoneme

converter provided by the Laboratory for Speech and

Multimodal Interfaces of Russian Academy of Sci-

ences (Kipyatkova and Karpov, 2009). The tool ap-

plies around 100 phonetic rules and requires two

dictionaries: an emphasis dictionary and a ”jo”-

dictionary. The former is essential, since stressed

vowels are differently pronounced (e.g. letter ”o” is

spellt as phoneme ”o!” if emphasised and phoneme

”a” otherwise). Stressed vowels often alter the neigh-

bouring sounds as well. The latter dictionary is re-

quired, since in written Russian letters ”jo” are usu-

ally replaced by ”je” causing pronunciation ambigu-

ity.

The ISABASE-2 (Bogdanov et al., 2003) corpus

used in our work is one of the largest high-quality read

speech corpora for Russian.

The lexical material of the speech database con-

sists of 3 non-intersecting sets:

• R-set: 70 sentences chosen by linguists to cover

all phonemes at least three times.

• B-set: 3060 sentences for training.

• T-set: 1000 sentences for testing.

The sets B and T were chosen from newspaper ar-

ticles and internet pages of different domains. Some

sentences were taken without adaptation while some

of them were pruned in order to be mostly no longer

than 10 words. The result sets provide the sufﬁcient

allophone coverage.

Sentences from the sets R and B were spoken by

100 speakers: 50 male and 50 female. Each speaker

has uttered all 70 sentences from R-set and 180 sen-

tences from B-set. For any two speakers B-subsets

either coincide or do not intersect at all. Therefore,

each sentence from the R-set was spoken by all 100

speakers and each sentence from the B-set was pro-

nounced by several male and female persons.

The test set was uttered by other 10 speakers: 5

male and 5 female. Each of them read 100 unique

sentences from the T-set.

All speakers were non-professional speakers liv-

ing in Moscow and having mostly the Moscow pro-

nunciation type.

Every utterance is presented as a separate Wav-ﬁle

(22050 Hz, 16 bit) along with its information ﬁle. The

information ﬁle includes the following:

• Speaker personal information: sex, age, educa-

tion, place of birth and residence, etc.;

• Textual transcription of the utterance;

• Expected phonetic transcription;

• Data from experts (phoneticians): actual utterance

transcription and estimation of the speaker’s ac-

cent type.

The total duration of speech is more than 34 hours

including 70 minutes of the development and test ma-

terial.

For acoustic modelling the sphinxtrain (Carnegie

Mellon University, 2012) tool was utilized. Features,

extracted from an acoustic signal are 13 MFCCs, their

ﬁrst and second derivatives. 40 Mel-ﬁlters were ap-

plied in the frequency range from 130 till 6800 Hz.

20 different AMs were trained on the whole training

set and tested on the development set to ﬁnd the op-

timum number of senones (tied states of triphones)

and Gaussian mixture components. The best found

parameters for Russian AM are 2000 senones and 16

Gaussians in one mixture.

The phoneme set consists of 48 sounds: 1 silence

phoneme, 18 plain and 18 palatalized consonants, 6

stressed and 5 unstressed vowels (unstressed ”o” does

not exist).

RussianSub-WordBasedSpeechRecognitionUsingPocketsphinxEngine

841

3 PRE-PROCESSING OF

RUSSIAN TEXT CORPORA

AND LANGUAGE MODELING

The largest available digital text sources are usually

scanned or typed books, newspaper archives and in-

ternet articles. The most of texts, especially from

newspapers, comprise a lot of abbreviations and num-

bers. For less inﬂective languages it does not pose any

challenge and they can be easily substituted by full

words performing some minor grammatical adapta-

tion. For Russian this substitution turns into a multi-

step procedure involving morphological and syntacti-

cal knowledge. Such sentences could be simply omit-

ted, like it is often done for Russian SR. Unfortu-

nately, this leads to the undesired statistics falsiﬁca-

tion and the model poorly represents almost all the

numbers and abbreviations in diverse contexts.

The algorithm of the text pre-processing (Zablot-

skiy et al., 2011b) was implemented by the authors as

a single Perl-script invoking the morphological tool

“mystem” (Segalovich, 2003) which is even able to

estimate precisely enough morphological properties

of words absent in its dictionary. At the moment of

writing the script consisted of 14 thousand lines of

very compressed scripting language code. Two real

examples taken from the script’s log-ﬁle are presented

in Fig 1.

Arabic Numerals

Old: V predelah 1,5 tys. t.

New: V predelah pol utor a tysjach tonn

(no more than 1,5 thousand tonn)

Arabic Numerals

Old: Na 1,5 tys. t.

New: Na poltor y tysjach i tonn

(for 1,5 thousand tonn)

Figure 1: Automaitic number-to-text transcription.

The algorithm was applied for the texts of Maxim

Moshkov’s library (Moshkov, 2012) and the archive

of “Nezavisimaya Gazeta” newspaper (www.ng.ru).

It takes about 12 hours to process 1Gb of plain texts

on a single Intel

Core

2 Duo PC. The result texts

were processed by the SRILM toolkit (A. Stolcke and

Abrash, 2011) to estimate the back-off 3-gram LMs.

Two smoothing techniques (Good-Turing discounting

with Katz back-off smoothing (Chen and Goodman,

1998) and Kneser-Ney smoothing (Kneser and Ney,

1995)) were applied resulting in different WER (up to

2% absolute difference) on the same development set

using same AMs. Therefore, due to the limitation of

space, ﬁnal results in Table 1are only shown for the

smoothing techniques which correspond to the better

performance on the development set. Mostly it is the

Kneser-Ney smoothing.

4 EXPERIMENTAL EVALUATION

The recognition of sub-word units was performed by

the pocketsphinx recognizer (Carnegie Mellon Uni-

versity, 2012). All the possible conditions for dif-

ferent sets were uniﬁed to make the honest compari-

son. The number of sub-words is determined by split-

ting of the available phonetic dictionary (2.3M word

forms). This implies, that all the built systems are

able to recognize the words from this lexicon. How-

ever, due to the different size of units, the systems

may recognize different number of OOV words. In

Table 1 the recognition results for development and

test set are presented.

Table 1: Speech recognition results for various LMs.

LM, Lex. OOV

SWER WER

type size (%) (%) (%)

Development set

SylBE 36k 0 31 21.9 68.4

SylE 32k 0 33 22.6 67.9

MrphPA 193k 0.04 118 26.8 55.9

MrphA 217k 0.11 149 47.4 89.7

MrphS 397k 0 166 51 88.9

Test set

SylBE 36k 0 31 25.4 74.7

SylE 32k 0 33 26.7 74.4

MrphPA 193k 0.06 118 32.9 64.7

MrphA 217k 0.09 149 51.9 92.1

MrphS 397k 0 166 53.6 95.6

Here, the following abbreviations are used. SylE

- is the syllable LM with the words’ last syllables

marked by ” e”. Since the number of syllables in Rus-

sian words is large on average and a 3-gram LM is

used, the SylBE model is tested as well. The only dif-

ference to the previous LM is the presence of marker

” b” appended to the words’ ﬁrst syllables. MrphA

and MrphPA are morpheme LMs which morphemes

were determined according to a morphological dic-

tionary. MrphPA is a ”preﬁx+stem+afﬁx” model, Mr-

phA has only afﬁx markers. MrphS is a pseudo-

morpheme LM which lexicon consists of sub-words

extracted by the Morphessor tool (Creutz and Lagus,

2005). 86% of words were split into 2 parts only.

However, a lot of words were divided into the larger

ICINCO2014-11thInternationalConferenceonInformaticsinControl,AutomationandRobotics

842

number of parts (up to 7). No changes were applied to

the default settings of Morphessor and corresponding

morpheme division. SWER stands for the sub-word

ER. The RTF for syllable LMs is 0.58, for morpheme

LMs - 0.45 and for MrphS LM - 0.49.

As can be seen, the best sub-word recognition ac-

curacy was achieved for syllable LMs, since the lexi-

con size is relatively small and each Russian syllable

consists obligatory of one vowel which usually pro-

nounced longer and is easier to recognize. However,

after straight-forward word synthesis the ”base+afﬁx”

MrphA LM turns to be the best choice for very large

vocabulary Russian ASR despite of high perplexity

(PP). It’s also worth mentioning, that OOV-rate on the

development and test sets was non-zero for morpheme

LMs only. Other LMs were able to ﬁnd the appropri-

ate sub-word units to cover the unknown words. In-

teresting result is that the inclusion of preﬁxes into

the morpheme LM decreases dramatically the recog-

nition accuracy. This is explained by the small size of

preﬁxes on average and by the fact, that lots of Rus-

sian preﬁxes do not include vowel sounds. The same

explanation is valid for MrphS LM: the vast amount

of small sub-words without vowels in the model.

5 CONCLUSION AND FUTURE

WORK

In this study different sub-word LMs were compared.

The language and acoustic training were conducted

under the same conditions, using the same textual and

speech material. The ”stem+afﬁx” morpheme model

outperformed signiﬁcantly other LMs being an opti-

mum trade-off between the number of sub-words and

their size. Relatively low recognition accuracy is ex-

plained by the highly inﬂective nature of Russian and

conforms with the results of other state-of-the-art re-

search for Russian SR (Karpov et al., 2011). The

word forms of one lemma in Russian sound often very

similar making them hard to distinguish even for a

human listener. Quite relaxed word order constraints

complicates the statistical modeling of word inﬂec-

tion.

The graphone LMs (Shaik et al., 2011) were

not investigated in this study. However, they could

achieve the better recognition accuracy for Russian

and should be tested in the future. As shown in (El-

Desoky et al., 2009) it is better for sub-word LM to

not decompose the N most frequent words. In our ex-

periments all the decomposable words were split into

parts that resulted in the low WER but this was done

on purpose to compare the LMs under similar condi-

tions.

As shown in our previous work (Zablotskiy et al.,

2011a), it is possible to concatenate the sub-words

even without any markers using the genetic global

search algorithm capable to correct some SR errors.

However, for this algorithm to work the relatively

small SWERs are required. From this perspective, the

syllable LM is the most suitable for Russian LVCSR.

ACKNOWLEDGEMENTS

This work is partly supported by the DAAD (German

Academic Exchange Service).

REFERENCES

A. Stolcke, J. Zheng, W. W. and Abrash, V. (2011). SRILM

at sixteen: Update and outlook. In Proc. IEEE Auto-

matic Speech Recognition and Understanding Work-

shop, Waikoloa, Hawaii.

Arsoy, E., Can, D., Parlak, S., Sak, H., and Saras¸lar, M.

(2009). Turkish broadcast news transcription and re-

trieval. IEEE Transactions on Audio, Speech and Lan-

guage Processing, 17(5).

Bisani, M. and Ney, H. (2005). Open vocabulary speech

recognition with ﬂat hybrid models. In Proc. of the

European Conf. on Speech Communication and Tech-

nology (Eurospeech’05), pages 725–728, Lisbon (Por-

tugal).

Bogdanov, D., Bruhtiy, A., Krivnova, O., Podrabinovich,

A., and Strokin, G. (2003). Organizational Con-

trol and Artiﬁcial Intelligence, chapter Technology

of Speech Databases Development (in Russian), page

448. Editorial URSS.

Byrne, W., Haji

c, J., Ircing, P., Krbec, P., and Psutka, J.

(2000). Morpheme based language models for speech

recognition of Czech. In Sojka, P., Kopecek, I., and

Pala, K., editors, Text, Speech and Dialogue, volume

1902 of Lecture Notes in Computer Science, pages

139–162. Springer Berlin / Heidelberg.

Carnegie Mellon University (2012). CMUSphinx. Open

source toolkit for speech recognition.

Chen, S. F. and Goodman, J. (1998). An empirical study of

smoothing techniques for language modeling. Techni-

cal Report TR-10-98, Computer Science Group, Har-

vard University.

Creutz, M. and Lagus, K. (2005). Unsupervised mor-

pheme segmentation and morphology induction from

text corpora using morfessor 1.0. Technical Report

A81, Helsinki University of Technology.

El-Desoky, A., Gollan, C., Rybach, D., Schlter, R., and Ney,

H. (2009). Investigating the use of morphological de-

composition and diacritization for improving Arabic

LVCSR. In Proc. of the 10th Annual Conference of

the International Speech Communication Association

(Interspeech’09), Brighton (UK).

RussianSub-WordBasedSpeechRecognitionUsingPocketsphinxEngine

843

Karpov, A., Kipyatkova, I., and Ronzhin, A. (2011). Very

large vocabulary ASR for spoken Russian with syn-

tactic and morphemic analysis. In Proc. of the 12th

Annual Conference of the International Speech Com-

munication Association (Interspeech’11), Florence

(Italy).

Kipyatkova, I. and Karpov, A. (2009). Creation of mul-

tiple word transcriptions for conversational russian

speech recognition. In Proc. of the 13th Conference

“Speech and Computer” (SPECOM’2009), pages 71–

75, St.Peterburg (Russia).

Kneser, R. and Ney, H. (1995). Improved backing-off for m-

gram language modeling. In Acoustics, Speech, and

Signal Processing, 1995. ICASSP-95., 1995 Interna-

tional Conference on, volume 1, pages 181–184 vol.1.

Moshkov, M. (2012). Maxim mashkov’s library.

Segalovich, I. (2003). A fast morphological algorithm with

unknown word guessing induced by a dictionary for a

web search engine. In MLMTA, pages 273–280.

Shaik, M., Mousa, A.-D., Schluter, R., and Ney, H. (2011).

Using morpheme and syllable based sub-words for

polish LVCSR. In Acoustics, Speech and Signal Pro-

cessing (ICASSP), 2011 IEEE International Confer-

ence on, pages 4680 –4683.

Xu, B., Ma, B., Zhang, S., Qu, F., and Huang, T. (1996).

Speaker-independent dictation of Chinese speech with

32K vocabulary. In Spoken Language, 1996. ICSLP

96. Proceedings., Fourth International Conference on,

volume 4, pages 2320 –2323 vol.4.

Zablotskiy, S., Shvets, A., Semenkin, E., and Minker, W.

(2011a). Recognized Russian syllables concatenation

by means of co-evolutionary asymptotic algorithm.

In Proc. XIV International Conference “Speech and

Computer” (SPECOM’2011).

Zablotskiy, S., Zablotskaya, K., and Minker, W. (2011b).

Automatic pre-processing of the Russian text cor-

pora for language modeling. In Proc. XIV In-

ternational Conference “Speech and Computer”

(SPECOM’2011).

ICINCO2014-11thInternationalConferenceonInformaticsinControl,AutomationandRobotics

844
