Constructing Empirical Tests of Randomness

Marek S

ys, Petr

Svenda, Martin Ukrop and Vashek Maty

Masaryk University, Botanicka 68a, Brno, Czech Republic

Keywords:

eSTREAM, Genetic Programming, Random Distinguisher, Randomness Statistical Testing, Software Circuit.

Abstract:

In this paper we introduce a general framework for automatic construction of empirical tests of randomness.

Our new framework generalises and improves a previous approach (

Svenda et al., 2013) and it also provides

a clear statistical interpretation of its results. This new approach was tested on selected stream ciphers from

the eSTREAM competition. Results show that our approach can lay foundations to randomness testing and

it is comparable to the Statistical Test Suite developed by NIST. Additionally, the proposed approach is able

to perform randomness analysis even when presented with sequences shorter by several orders of magnitude

than required by the NIST suite. Although the Dieharder battery still provides a slightly better randomness

analysis, our framework is able to detect non-randomness for stream ciphers with limited number of rounds

(Hermes, Fubuki) where both above-mentioned batteries fail.

1 INTRODUCTION

We usually test randomness using batteries of empir-

icall test of randomness. Problem of the batteries is

that they implement a ﬁxed set of tests and can detect

only limited types of patterns. Batteries detect only

evident trivial defects and there is no problem to ﬁnd

sequences with some type of pattern (other than the

tested ones) that pass all tests in the test battery. Since

cryptographic functions have a deterministic output, it

is a priori clear that they cannot pass all possible tests

of randomness and there must exist empirical tests of

randomness that reveal sequences as non-random.

In this work we introduce a novel framework for

constructing empirical tests of randomness that can

succeed in ﬁnding such a test (at least hypothetically).

Our goal is to ﬁnd an empirical test of randomness

that indicates a given sequence is either non-random

(with a high probability) or sufﬁciently random. In

our framework, we iteratively construct randomness

tests that adapt to the processed sequence. The con-

struction is stochastic and uses genetic programming.

Tests are constructed from a predeﬁned pool of oper-

ations (building blocks). Set of operations, together

with a limit for the number of operations, allows us to

control the complexity of tests. The framework theo-

retically allows us to construct an arbitrary (according

to limited resource) randomness test over a set of cho-

sen operations. Therefore it can be viewed as a gen-

eral framework for the test construction and should

(hypothetically) provide a better detection ability than

standard tests. Last but not least, a lower amount of

data extracted from a given function is necessary to

provide a working test.

This paper is organised as follows: Section 2 is

devoted to randomness testing and general descrip-

tion of standard randomness tests. A reader familiar

with these issues can proceed straight to the follow-

ing section. In Section 3 we describe our new ap-

proach and compare it to the previous one. Section

4 describes testing procedures and experiment results

obtained from testing the chosen eSTREAM candi-

dates. Section 5 concludes the paper. The Appendix

describes generalised empirical tests of randomness

and used Goodness-of-Fit tests. The Appendix also

describes settings used in our experiments and testing

of both the model and its implementation.

1.1 Previous Work

Knuth described basic simple tests of randomness in

the second book (Knuth, 1997) of his well-known se-

ries. These tests form the basic randomness testing

procedures and have been implemented (at least some

of them) in all known test batteries. Marsaglia with

Tsang proposed tests (Marsaglia and Tsang, 2002)

that belong to the strongest that have been proposed so

far. These tests were implemented in the Diehard bat-

tery (Marsaglia, 1995). The Diehard battery, as well

as its newer version called Dieharder (Brown, 2004),

is focused on testing sequences of random numbers.

It consists of 20 powerful tests that work with small

229

Sýs M., Švenda P., Ukrop M. and Matyáš V..

Constructing Empirical Tests of Randomness.

DOI: 10.5220/0005023902290237

In Proceedings of the 11th International Conference on Security and Cryptography (SECRYPT-2014), pages 229-237

ISBN: 978-989-758-045-1

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

sample sizes padded to 32 bits. The Statistical test

suite developed by NIST (Rukhin, 2010) was pro-

posed for testing and certiﬁcation of random number

generators used in cryptographic applications. It con-

sists of 15 tests with a small overlap with Diehard.

The Diehard battery along with the NIST STS are the

most popular tools for randomness testing.

In 2007 Lecleuyer and Simard introduced quite

a strong test battery called TestU01 (L’Ecuyer and

Simard, 2007). TestU01 resolves the problems of

Diehard and implements a larger variety of tests than

any other battery. Other test suites exist, yet they are

either commercial (Crypt-X (W. Caelli, 1992)) or pro-

vide only basic testing (ENT (Walke, 1993)). Ear-

lier work (

Svenda et al., 2013) comes with the ap-

proach of distinguisher construction that we use as

the grounding concept for our general framework pre-

sented in this paper.

1.2 Previous Approach

In the work (

Svenda et al., 2013) the authors looked

for a distinguisher of a bitstream produced by a cryp-

tographic function (stream cipher) and a truly random

bitstream (reference bitstream) produced by a physi-

cal source of randomness (quantum random generator

(Stevanovi, 2007)). The implementation is available

as an open-source project EACirc (

Svenda and Ukrop,

2013).

Their distinguisher is constructed as a circuit-like

software from a predeﬁned set of operations. The

circuit-like software is a small program that simu-

lates a standard hardware circuit. It consists of wires

and gates (operations) grouped into layers. The most

important fact is that the functionality of the circuit

(circuit-like software) can be simply changed by re-

placing operations in gates or by redirection of wires.

This property is used for an iterative construction of

distinguishers. The construction is controlled by a ge-

netic algorithm (GA) that uses the success rate (per-

centage of correct answers) of distinguisher as its ﬁt-

ness value.

Using this approach, the authors obtained results

that are somewhat comparable to those obtained by

the NIST STS battery. The main problem of the pre-

vious approach is the interpretation of results. To

evaluate randomness, the authors compare the com-

puted average success rate of circuits with its refer-

ence value obtained by distinguishing two truly ran-

dom bitstreams. When the reference average success

rates are signiﬁcantly different, it is evident that the

distinguishing really works and circuits can be de-

clared as real distinguishers. For close rates, it is hard

to decide whether a small difference of success rates

was caused by GA and its stochasticity or a weak dis-

tinguisher was found. In the new approach we give

clear statistical interpretation of results and we mag-

nify sensitivity of randomness test.

2 RANDOMNESS TESTING

Empirical tests of randomness fall under the standard

statistical model – statistical hypothesis testing. Tests

formulate a H

hypothesis “the bitstream is random”

and an alternative hypothesis “the bitstream is not ran-

dom”. Each randomness test is deﬁned by the test

statistic S, which is a real-valued function of a nu-

meric sequence. Tests are evaluated by comparing the

P-value (computed from the test statistic value) with

a chosen signiﬁcance level α. For the P-value com-

putation, it is necessary to know an exact distribution

of S under hypothesis H

or at least its close approxi-

mation.

2.1 Standard Tests of Randomness

All standard tests of randomness are deﬁned by the

test statistic S carefully chosen to minimize the prob-

ability (β) of the Type II error (acceptance of H

for

a non-random bitstream) for a ﬁxed signiﬁcance level

α (probability of Type I error, rejection of H

for a

random bitstream).

Note 1. It should be noted that we do not construct

standard empirical tests of randomness since S is con-

structed randomly and Type II error is not minimized.

A P-value is computed from the “observed” test

statistic a value s

obs

using a theoretical distribution

of test statistic values under the H

hypothesis. This

reference distribution is determined by mathematical

methods. It represents the distribution of test statis-

tic values for random bitstreams. The signiﬁcance

level of standard tests is usually set to α = 1%. This

means that standard tests accept the H

hypothesis if

the P-value is greater than α = 0.01. In such case we

conclude that the examined bitstream is random with

respect to the analysed feature.

Note 2. Besides acceptance (pass) and rejection (fail)

of the H

hypothesis, Diehard tests can also give a

third result – weak. Diehard tests provide two-tailed

testing with the treshold α = 0.5% for weak data and

0.1% for non-random data (failed).

Each standard test of randomness can be per-

formed using the χ

test (Sheskin, 2003). It sufﬁces

to apply an appropriate categorisation function C to

the analysed bitstream and to compare the obtained

results with the expected results. Standard tests of

SECRYPT2014-InternationalConferenceonSecurityandCryptography

230

randomness can be implemented using an appropri-

ate categorisation function C in the following steps:

1. Computation of observed frequencies: According

to the purpose of the test, apply the function C

to an adequate blocks of the bitstream B. Based

on the function result, categorise each block and

compute (observed) frequencies for each cate-

gory.

2. Expected frequencies estimation: Estimate exact

probabilities for each category if C would be ap-

plied to blocks of an inﬁnite truly random bit-

stream. Using estimated probabilities, compute

corresponding expected frequencies for a ﬁnite

bitstream of a given length (length of B).

3. Evaluation: Use the χ

test to compare observed

and expected frequencies.

More detailed explanation and a general description

of standard tests can be found in Section B of the Ap-

pendix.

Each standard randomness test in the equivalent

form is fully deﬁned by the function C and by this

function is applied to the bitstream. In order to de-

scribe the general test we need to describe the general

function C. In fact, we need to answer the following

questions:

• Can the categorisation function C be described

generally?

• How to apply function C to the bitstream?

To answer these questions, let us have a look at stan-

dard tests. In the BlockFrequency and Monobit tests

different blocks of a ﬁxed length are mapped to dis-

joint categories. In more complicated tests, such as

Rank test, Linear Complexity test or Spectral test, the

function C transforms the bitstream (or its parts) into

other structures (matrix, LFSR, etc.) and after that it

categorises them. Evidently, there is no simple gener-

alisation of the C function functionality. On the other

hand, we can identify several common properties of

functions used in standard tests. All functions C pro-

cess blocks of bits of a ﬁxed length. Moreover, the

number of resulting categories is small and therefore

C can be simulated by a function with a small output.

We have two situations with respect to the input size.

Processed blocks are either quite long (1/100 of the

length of B) or very small (several bits).

To answer the second question we made an obser-

vation that C is usually applied to consecutive non-

overlapping blocks of the bitstream (original or trans-

formed).

3 NEW APPROACH

Our goal is to construct simple tests of randomness

that indicate a given bitstream to be non-random with

a high conﬁdence (small P-value). We aim to con-

struct randomness tests in their general form (see

Section B of the Appendix) deﬁned by a categori-

sation function C. We assume functions C with a

small input size (up to 1000 bits) that are applied to

non-overlapping blocks of the bitstream. Since tests

can be also viewed as distinguishers from random

bitstreams, we can use an implementation (EACirc

project (

Svenda and Ukrop, 2013)) of the previous

approach (

Svenda et al., 2013). In fact, we try to im-

prove the previous approach and to give a clear sta-

tistical interpretation of its results. Our new approach

is based on ideas and principles used in standard em-

pirical tests of randomness combined with the distin-

guisher construction.

3.1 Test Construction

In the previous approach, the authors looked for dis-

tinguishers represented by circuit-like software while

in the new approach, we look for distinguishers based

on empirical tests of randomness. For this purpose,

we have slightly modiﬁed the previous implementa-

tion. In the new implementation (EACirc2), the cir-

cuit C

represents a categorisation function C that de-

ﬁnes the test of randomness. The new implemen-

tation could be divided into two modules: The ﬁrst

module, genetic algorithm module (GA), controls the

construction of randomness tests (categorisation func-

tions C). This module was taken from the previous

approach without changes. The new second module,

test of randomness module (TR), undertakes the test-

ing of randomness based on the categorisation func-

tion C represented by the circuit. The GA module

controls the evolution of circuits C

. The TR module

uses circuits C

(categorisation function) for computa-

tion of ﬁtness values for GA. Both modules work with

circuits C

with ﬁxed size input (n bits) and output (m

bits).

Test construction is iterative and one iteration can

be described by the following pseudocode:

1. The GA module sends evolved categorisation

functions C (circuits C

) to the TR module.

2. The TR module uses C

to test randomness of

a given bitstream (its part) and sends computed

P-values back to the GA module.

3. The GA module takes the P-values and uses them

as ﬁtness values for evolving of the next genera-

tion of circuits.

ConstructingEmpiricalTestsofRandomness

231

The GA controls evolution of functions C in order to

minimize P-values.

3.2 TR Module

In the TR module, the circuit C

is used for random-

ness testing according to the general testing proce-

dure described more precisely in Section B of the Ap-

pendix. The testing procedure consists of the follow-

ing three steps:

1. computation of observed frequencies,

2. estimation of expected frequencies,

3. evaluation.

In the ﬁrst step, we apply the circuit C

to the anal-

ysed bitstream and we obtain observed frequencies (a

histogram of results). In the second step, we com-

pute the exact expected (theoretical) frequencies. The

prediction of exact frequencies is for a general cir-

cuit C

without uniform distribution of the output a

hard task. Therefore we use an estimation of the ex-

pected frequencies instead. A close estimate of ex-

pected frequencies can be obtained if we apply C

a sufﬁciently long truly random bitstream generated

by a physical source of randomness. In the third step,

we use one sample Pearson’s χ

test (Sheskin, 2003)

to compare observed and expected frequencies and to

compute the P-value of the test.

We have undertaken basic experiments and re-

alised that for a sufﬁciently close estimate of expected

frequencies we need to apply C

to a very long ran-

dom bitstream. However, for practical reasons, C

is applied only to a short bitstream. To solve prob-

lems occurring from inaccurate approximation of ex-

pected frequencies, obtained and expected frequen-

cies can be compared using a two-sample test. In our

approach, we use the two-sample χ

test from (NIST,

1993) since the distribution of test statistic values for

two-sample χ

tests is also the χ

distribution.

Now we describe the ﬁnal version of the TR mod-

ule in more detail. Let us assume that circuit C

has n

bits of input and an m-bit output. In the TR module,

is applied to non-overlapping blocks of the size n.

In the practice, we divide the bitstream B to blocks

, called test vectors of the length of n bits. In fact,

the TR module processes two bitstreams. The ﬁrst

bitstream (B) is the bitstream we want to test for ran-

domness. The second (reference) bitstream R (pro-

duced by a physical source of randomness) is used

for computation of expected frequencies. For sim-

plicity, we assume bitstreams R,B of the same length.

Thus corresponding sets of test vectors R

have the

same size denoted by k. The TR module computes

the P-value for the test vectors R

, j ∈ {1,··· , k}

as follows:

1. Computation of observed frequencies: The cat-

egorisation function C represented by the circuit

is applied to all test vectors B

, j ∈ {1,··· , k}.

Frequencies o

for each category (deﬁned by re-

sulting value O

of C) are computed using o

|{B

, j ∈ {1,··· ,k} : C(B

) = O

,}|.

2. Expected frequencies estimation: Expected fre-

quencies are computed by the same way from the

test vectors R

of the truly random bitstream, i.e.,

= |{R

, j ∈ {1,··· ,k} : C(R

) = O

}|.

3. Evaluation: Two-sample χ

test is used to com-

pute the test statistic value deﬁned as

obs

∑

i=1

−e

)

+ e

3.3 GA Module

As was stated before, we used GA module from previ-

ous EACirc project (

Svenda and Ukrop, 2013). In this

section we describe GA on general level only. More

details about GA module can be found in (

Svenda

et al., 2013).

The GA module controls the evolution of circuits

based on ﬁtness values (P-values) computed in

the TR module. In the GA module, test vectors are

changed in order to prevent overlearning of circuits

to a speciﬁc bitstream. The evolution consists of two

phases: learning and testing. These two phases peri-

odically alternate during the evolution. In the learn-

ing phase, test vectors are ﬁxed and circuits are eval-

uated according to them. In the testing phase, the

test vectors are changed and the TR module computes

P-values from these new test vectors. The learning

phase lasts for a ﬁxed number of iterations (genera-

tions). The testing phase lasts a single iteration. This

iteration starts a new learning phase with new test vec-

tors.

More precisely, let f (frequency of changing test

vectors) denotes the number of generations in each

learning phase, then test vectors are changed in each

l f -th iteration (population of circuits) for some inte-

ger l. Thus learning phases start in l f -th iteration and

end in the ((l + 1) f −1)-th iteration. Testing phases

are performed in the iterations i f for some integer i.

3.4 Results and their Interpretation

Results of our approach consist of series of P-values

computed during the whole evolution (e.g., 30000

generations). The interpretation of computed

SECRYPT2014-InternationalConferenceonSecurityandCryptography

232

P-values is based on the fact that for a true H

hypoth-

esis P-values are uniformly distributed in the interval

[0,1]. This is, in fact, true for all statistical tests as

well as for the tests of randomness.

Of course, the basic criterion of statistical test-

ing must be fulﬁlled: “Analysed data must be taken

from a random sample.” In our case, this criterion

can be interpreted as independence between the cir-

cuits (statistical tests) and test vectors. Since circuits

are evolved according to test vectors, test vectors are

independent from circuits only in the testing phases,

where test vectors just changed. For clear interpre-

tation we can use only one P-value computed in the

testing phase. The reason is that circuits are partially

correlated and thus P-values computed from a given

set of test vectors are also correlated. Let P

denotes

set of all P-values computed in i-th generation. Dur-

ing the evolution sets P

,··· ,P

30000

of P-values

are computed. Let P denotes the set of P-values P =

,··· ,P

30000/ f

}, where each P-value P

∈ P

i f

taken from different testing phase (iteration i f ). In

the case of a true H

hypothesis each P

is taken from

uniformly distributed set P

i f

on the interval [0,1]. In

such case all P-values in the set P are also uniformly

distributed on the interval [0,1].

For testing uniformity of P-values, we use the

Kolmogorov-Smirnov (KS) test described in Section

A of the Appendix. Of course, KS computes its own

P-value that can be compared to the signiﬁcance level

(chosen as α = 5%) to evaluate the KS test. Since

P-values computed by the KS test could be smaller

than α even for uniformly distributed P-values, we

prefer to repeat the whole process several (r) times.

For a proper and clear statistical interpretation we

test whether 5% of P-values computed by the KS

test from different sets P are smaller than the cho-

sen signiﬁcance level α = 5%. In practice, we do

not compute the P-value of the KS test, but use an-

other approach. We compare the KS statistic value

with the critical statistic value D =

1.36

√

computed for

α = 5% (see Section A.3 of the Appendix) and for the

set P = {P

,··· ,P

} where t > 35.

4 EXPERIMENTS

In this section we describe settings and results of per-

formed experiments. We used our approach for ran-

domness testing of bitstreams produced by selected

stream ciphers from the eSTREAM project. Truly

random data used for test vectors were produced by

the Quantum Random Bit Generator Service (Ste-

vanovi, 2007). We did all experiments with the new

open-source implementation of EACirc2 project that

can be found with previous EACirc and other testing

tools and under following link (

Svenda and Ukrop,

2013).

For expermiments we used following parameters

of GA module:

1. circuit resources:

• input length n = 128 bits, output length = 8 bits,

• number of layers = 4, maximum number of

connectors to gate = 4,

• set of operations = Byte XOR, AND, NOR,

NAND, NOT;

2. GA setting:

• population size = 1, crossover probability = 0,

mutation probability = 0.05,

• number of generations gen = 30000, frequency

of changing test vectors f = 100, number of test

vectors k = 500,

• ﬁtness value = P-value of the test C

applied to

test vectors.

Most of the parameter values were taken from

the previous work (

Svenda et al., 2013) in order to

compare our new approach with the previous one. It

should be noted that results strongly depend on the

character of examined data and therefore it is quite

difﬁcult to ﬁnd an optimal setting. However, sensitiv-

ity of the tests is given by resources of the circuits.

In general, the more resources (larger input/output

length, more layers, etc.) means better results. On

the other hand, it also means more time needed for

execution. Parameters such as output length, set of

operations and ﬁtness function were changed to im-

prove the detecting ability of tests and to get results in

reasonable time. More details about the settings can

be found in Section C of the Appendix.

Before testing stream ciphers, we performed ex-

periments that conﬁrmed correctness of the statisti-

cal model and its implementation. More details about

the implementation and model testing can be found

in Section D of the Appendix. We tested a reference

situation – randomness testing of a random bitstream.

The model expects that a set of 300 (gen/ f ) P-values

is uniformly distributed on the interval [0,1] for each

run of the algorithm. We performed 1000 runs, 49

out of which failed the KS test for uniformity. This is

in a good agreement with the statistical model since

4.9%(=49/1000) is almost identical to expected value

α = 5% of the KS test.

After testing the model and its implementation we

used our approach for randomness analysis of bit-

streams produced by stream ciphers Grain, Decim,

Fubuki, Hermes, LEX, Salsa20, TSC9 and Hermes

with a limited number of rounds. Results of our

ConstructingEmpiricalTestsofRandomness

233

approach (EACirc2) are summarised in tables to-

gether with results of previous approach (EACirc),

Dieharder battery (version 3.31.1) and NIST STS

(version 2.1). Results of the Dieharder battery, NIST

STS and previous approach are taken from (

Svenda

et al., 2013).

Each cell in the Dieharder battery or NIST STS

column represents the number of tests that de-

tected non-randomness in the given bitstream. Since

Dieharder tests provides three levels of evaluation

(pass, weak, fail, see NOTE 2 in section 2.1), val-

ues 1, 0.5, 0 respectively, were assigned to these lev-

els and sum over all tests was taken. There were 20

tests from the Dieharder battery and 162 tests (tests

with different parameters (

Svenda et al., 2013)) from

NIST STS with chosen signiﬁcance level α = 1% for

both batteries. Cells in the EACirc column represent

average success rates (percentage) of constructed dis-

tinguishers with 52% as the reference value obtained

when distinguishing between two random bitstreams.

Cells in the EACirc2 column represent percentage of

runs for which the set of the P-values failed the KS

test for uniformity with the signiﬁcance level α = 5%

as the reference value (theoretical and practical). Note

that values in different columns are not directly com-

parable and must be compared to different reference

values. These reference values (0, 0, 52, 5) of par-

ticular (Dieharder, NIST, EACirc, EACirc2) columns

are obtained from tests performed over the random

sequence. We will get values (20,162,100,100) in the

case of a ‘totally’ non-random sequence.

Table 1: Results for Grain.

Rounds Dieharder NIST EACirc EACirc2

1 20.0 162 100 100

2 20.0 162 100 100

3 0.5 2 52 4

Table 2: Results for Decim.

Rounds Dieharder NIST EACirc EACirc2

1 20 162 100 100

2 19.5 162 54 100

3 19 162 53 100

4 16.5 83 52 100

5 15.5 83 52 92

6 1 4 52 5

Table 3: Results for FUBUKI.

Rounds Dieharder NIST EACirc EACirc2

1 0 0 52 7

2 0 0 52 5

Results in the EACirc2 column that were obtained

from 100 runs (repetitions r = 100 of whole test-

ing process) shows that our approach is signiﬁcantly

Table 4: Results for Hermes.

Rounds Dieharder NIST EACirc EACirc2

1 0 0 52 3

2 0 0 52 9

Table 5: Results for LEX.

Rounds Dieharder NIST EACirc EACirc2

1 20 162 100 100

2 16 161 100 100

3 19.5 161 100 98

4 0 0 52 8

Table 6: Results for Salsa20.

Rounds Dieharder NIST EACirc EACirc2

1 14.5 161 87 100

2 14.5 161 87 100

3 0 0 52 4

Table 7: Results for TSC.

Rounds Dieharder NIST EACirc EACirc2

1-8 20 162 100 100

9 19 161 100 100

10 18 149 100 8

11 10 5 52 6

12 4 0 52 13

13 0 0 52 5

better than the previous approach EACirc (

Svenda

et al., 2013). While the Dieharder battery is still a

slightly better tool for randomness testing compared

to our approach, we achieve results comparable to

those of NIST STS. Results of testing FUBUKI with

1 round, Hermes with 2 rounds, LEX with 4 rounds

and TSC with 12 rounds indicate that EACirc2 detects

non-randomness in some cases where NIST STS and

Dieharder batteries, and previous approach (EACirc),

fail. We tested the above-mentioned ciphers again

with an additionally increased number of runs (r =

1000) in order to conﬁrm previous results. We ob-

tained results: 6.4% for FUBUKI, 6.4% for Hermes,

5.9% for LEX and 4.3% for TSC. Results conﬁrm

that our approach clearly detected non-randomness

for Hermes with 2 rounds and FUBUKI with 1 round.

5 CONCLUSION

We have proposed a general design for the construc-

tion of empirical tests of randomness. Our new ap-

proach is based on work (

Svenda et al., 2013) and

improves it in two ways. It gives a clear statistical in-

terpretation of its results and improves efﬁciency and

success rate of the distinguisher (test of randomness)

SECRYPT2014-InternationalConferenceonSecurityandCryptography

234

construction. We have tested our approach on sev-

eral stream ciphers (with a reduced number of rounds)

taken from the eSTREAM competition. Obtained

results imply that our approach provides a signiﬁ-

cantly stronger randomness analysis than the previ-

ous one. Moreover, we have been able to detect non-

randomness in some bitstreams (Hermes reduced to 2

rounds, FUBUKI reduced to 1 round) that fully pass

standard batteries Dieharder and NIST STS. While

the Dieharder battery is still a slightly better tool for

randomness testing than our approach, we achieve re-

sults comparable to those of the NIST STS battery.

Our future work will cover randomness testing of eS-

TREAM ciphers and SHA-3 candidates with various

settings of our approach.

ACKNOWLEDGEMENT

The ﬁrst author was supported by the Min-

istry of Education, Youth, and Sport project

CZ.1.07/2.3.00/30.0037 – Employment of Best

Young Scientists for International Cooperation Em-

powerment. Other authors were supported by the

Czech Science Foundation, project GAP202/11/0422.

REFERENCES

Brown, R. G. (2004). Dieharder: A random number test

suite, version 3.31.1.

Knuth, D. E. (1997). The Art of Computer Program-

ming, Volume 2 (3rd Ed.): Seminumerical Algo-

rithms. Addison-Wesley Longman Publishing Co.,

Inc., Boston, MA, USA.

L’Ecuyer, P. and Simard, R. (2007). TestU01: A C library

for empirical testing of random number generators.

ACM Trans. Math. Softw., 33(4).

Marsaglia, G. (1995). The marsaglia random number

CDROM including the diehard battery of tests of ran-

domness. http://www.stat.fsu.edu/pub/diehard/.

Marsaglia, G. and Tsang, W. W. (2002). Some difﬁcult-to-

pass tests of randomness. Journal of Statistical Soft-

ware, 7(3):1–9.

NIST (1993). Two-sample χ

test. http://www.itl.nist.gov/

div898/software/dataplot/refman1/auxillar/chi2samp

.htm.

Rukhin, A. (2010). A statistical test suite for the valida-

tion of random number generators and pseudo ran-

dom number generators for cryptographic applica-

tions, version STS-2.1. NIST Special Publication 800-

22rev1a.

Sheskin, D. J. (2003). Handbook of parametric and non-

parametric statistical procedures. crc Press.

Stevanovi, R. (2007). Quantum random bit generator ser-

vice. http://random.irb.hr/.

Svenda, P. and Ukrop, M. (2013). EACirc project,

https://github.com/petrs/eacirc.

Svenda, P., Ukrop, M., and Maty

s, V. (2013). Towards

cryptographic function distinguishers with evolution-

ary circuits. In SECRYPT, pages 135–146. SciTePress.

W. Caelli, e. a. (1992). CryptX package docu-

mentation. Technical report, Information Se-

curity Research Centre and School of Math-

ematics, Queensland University of Technology.

http://www.isrc.qut.edu.au/resource/cryptx/.

Walke, J. (1993). Ent - a pseudorandom number sequence

test program. http://www.fourmilab.ch/random/.

Zhang and Jin. Incomplete gamma function.

http://www.crbond.com/math.htm.

APPENDIX

A Goodness-of-Fit Tests

The family of Goodness-of-Fit tests can be formally

divided into two main classes. According to the num-

ber of analysed samples we talk about one-sample

tests or two-sample tests. The one sample Goodness-

of-Fit test measures how well a given sample ﬁts a

statistical model (expected distribution). The two-

sample test analyses whether two samples came from

the same distribution. Two of the most frequently

used statistical tests are Pearson’s χ

test (Sheskin,

2003) and Kolmogorov-Smirnov (KS) test (Sheskin,

2003).

A.1 χ

Test

The χ

test is typically used for testing whether

the observed frequency distribution ﬁts the theoret-

ical distribution. This test is applied to categorised

(binned) data and test statistics depended on the data

categorisation. In the test we assume that observa-

tions of some events fall into k mutually exclusive

categories. The one sample χ

test statistic is deﬁned

∑

i=1

−e

)

where o

denotes the frequency in the i-th cathegory.

The P-value of the test is computed using the refer-

ence χ

distribution that is determined by the degree

of freedom (k −1).

Note 3. In practice, P-value is computed from χ

test

statistic by the gamma function and the incomplete

gamma function. We tested several open-source im-

plementations of the incomplete gamma function, but

most of them are inaccurate for extremal arguments

ConstructingEmpiricalTestsofRandomness

235

(close to zero, greater than 200). We use the im-

plementation of the incomplete gamma function from

(Zhang and Jin, ) that produces correct values for ar-

bitrary arguments.

The χ

test uses distribution with k categories that

closely approximates binary distributed variable (k =

2) or multinomially distributed variable (k > 2). For

a sufﬁcient approximation of a multinomial variable,

frequency in each category should be greater than 5,

i.e., e

≥ 5 for all i ∈ {1,··· ,k}.

A.2 Two-sample χ

Test

In our approach we use a two-sample χ

test (NIST,

1993) that compares the distributions of two sam-

ples since expected frequencies e

can not be approxi-

mated closely. The test statistic for the two-sample χ

test changes to χ

∑

i=1

−e

)

. The reference dis-

tribution is also the χ

distribution with d −1 degrees

of freedom. In the two-sample χ

test, d represents

the number of non-empty categories (o

+ e

> 0).

Moreover, for a correct analysis using the two-sample

test, it is required that the sum o

+ e

should be at

least 5. Thus only categories with o

≥5 are used

for computation of the test statistic value.

A.3 Kolmogorov-Smirnov Test

The one sample Kolmogorov-Smirnov (KS) (Sheskin,

2003) test is a more universal Goodness-of-Fit test

than the χ

test since it can be used also for test-

ing continuous distributions. The KS test compares

an empirical distribution of the sample with the ref-

erence distribution using the cumulative distribution

functions (CDF). Let

F(x) denotes an empirical CDF,

then

F(x) is deﬁned as

F(x) = Pr(X < x) . The KS

test statistic D is deﬁned by D = sup

x∈R

F(x)−F(x)|,

where F(x) denotes the expected value of the cumu-

lative distribution. We use the KS test for testing the

uniformity of P-values (P

, i ∈ {1, 2,··· ,t}) on the

interval [0,1]. In a such discrete case the CDF has the

form

F(t) =

#i : P

< x

For sorted P-values P

≤ P

≤ ··· ≤ P

we can write

(x) = i iff P

≤ x and P

i+1

> x. Reference CDF is

deﬁned on the interval of our interest as F(x) = x.

The KS test statistic D can be computed as D =

max

t−1

i=1

(max(|

−P

|,|

i+1

−P

|)). For our computa-

tions we use the critical value D

of the signiﬁcance

level α = 0.05 that can be computed as D

0.05

1.36

√

for t > 35.

B General Description of Standard

Tests

For better understanding of general tests, we ﬁrst de-

scribe a standard test of randomness. In the standard

tests, statistic S is applied to the bitstream to obtain

the test statistic value s

obs

. This value is used for com-

putation of the corresponding P-value. To clarify the

testing procedure, let us take the simplest randomness

test, the Monobit test from NIST STS (Rukhin, 2010).

Example 1. The Monobit test looks for irregularities

in the proportion of counts of ones and zeros in a se-

quence. The Monobit test is deﬁned by the test statis-

tic S =

√

. The value S

is computed as an absolute

value of difference of count of ones and zeros in the

bitstream of the length n. The value S

is computed as

∑

i=1

, for ε

∈ {1,−1} (zero bits converted

to −1). The reference distribution (under H

hypoth-

esis) of the test statistic (for large n) is half normal.

The test uses er f c() function for computation of the

P-value from normal distributed

obs

√

Let us assume a bitstream ε = 1011010101 with

the length n = 10. Using the previous expressions,

we can compute S

= 2 and the statistic test value

obs

√

. To compute the P-value we apply the

er f c() function to

obs

√

and we ﬁnally get

P −value = er f c



√



= 0.52708926.

Evaluation of the H

hypothesis from the previ-

ous example can be also done using other appropri-

ate statistical tests. The Monobit test of randomness

checks whether the frequencies o

of zeros (o

) and

ones (o

) in a sequence ﬁt to the expected theoretical

frequencies e

. We can therefore use any one sample

Goodness-of-Fit test such as the χ

test or the KS test.

The Monobit test for the bitstream of the length n

can be evaluated by the χ

test as follows:

1. Computation of observed frequencies: take each

bit of the analysed bitstream, categorise it accord-

ing to its value (0 or 1) and compute the frequency

for each category (o

= 4,o

= 6).

2. Expected frequencies estimation: estimate proba-

bilities of bits for a truly random inﬁnite bitstream

= p

= 0.5 for zeros and ones) and use them to

compute the expected frequencies for a bitstream

of the given length (e

= e

= 5).

3. Evaluation: compare observed and expected fre-

quencies by the χ

test with 1 degree of freedom

(P-value = 0.52708926).

In fact, these steps can be generalized for all other

empirical tests of randomness.

SECRYPT2014-InternationalConferenceonSecurityandCryptography

236

The categorisation function corresponds to the

purpose of the test and can be deduced directly from

its test statistic. In the case of the Monobit test, the

categorisation function was applied to individual bits,

but in general it can process parts of the examined

bitstream or its transformed equivalent. In general,

we also assume that the number of categories is arbi-

trary (not only two), and so is the related degree of

freedom.

C Parameters and Settings

Size of the population was changed to one, since

only one P-value can be taken for the correct statis-

tical interpretation (see Section 3.4). This compen-

sates for the fact that the whole process must be re-

peated several times (for the correct interpretation of

results). The ﬁtness value of the GA was changed to

the P-value since the P-value clearly represents the

most relevant value of the testing procedure.

Note 4. It is possible to use two-sample χ

test statis-

tic as the ﬁtness value but it does not reﬂect degrees

of freedom.

Since the population consists of only one circuit,

the crossover probability is automatically set to zero.

To choose appropriate circuit settings, a deeper ana-

lysis of the evolution is needed. Let us consider a

ﬁxed setting of the circuit parameters (number of lay-

ers, number of gates in the layer, . . . ). Since the cir-

cuit resources are limited, they should be used ef-

fectively. This means that the pool of available op-

erations should consist of complex operations. The

reason for that is that complex operations constructed

from trivial ones consume a lot of available resources.

On the other hand, too many deﬁned operations sig-

niﬁcantly enlarge the space where GA works and

could mislead the evolution process. Therefore the set

of operations should consist of complex but meaning-

ful operations. In the case of stream cipher, operations

used in the cipher design can be considered meaning-

ful. Therefore we use only simple Byte “boolean”

operations like AND, OR, NOR, NOT, etc.

The main problem of the previous approach is that

the output from the last layer of the circuit is inter-

preted as a single bit. Clearly, this leads to a loss

of distinguishing ability of circuits, since results of

many gates are often discarded. To avoid this, more

bits from the last layer should be used for the interpre-

tation. This perfectly ﬁts to our framework since the

categorisation function of the test can work with arbi-

trary many categories. It can be expected that we get

the most sensitive test of randomness if all categories

are deﬁned by single output value of the circuit, i.e.,

if C with 2

categories is represented by a circuit C

with m output bits. Unfortunately, application of the

test (Section A of this Appendix) requires that the

frequency in each category should be at least 5. This

means that for C

with 8 output bits there should be

either more test vectors (more than used k = 1000) or

the number of categories should be smaller. We have

reduced the number of categories. For 1000 test vec-

tors, it must be smaller than 200. In such case each

category could be deﬁned by 7 bits of a circuit output

byte. Of course, the GA does not ﬁll the categories

evenly and therefore we need to use less categories.

For our experiments we have chosen 8 categories de-

ﬁned by the last 3 bits of all 8 output bits.

D Implementation and Model Testing

In this part we describe tests that conﬁrm correct-

ness of the statistical model and correctness of its

implementation. We want to conﬁrm that P-values

computed by two-sample χ

(from category frequen-

cies) are distributed uniformly on the interval [0, 1].

Besides the statistical model we also need to check

our implementation of statistical tests (two-sample χ

test, KS test).

Firstly, we have tested the implementation of the

KS test. We analysed 10

sets P of t = 300 uniformly

distributed randomly generated real numbers from the

interval [0,1]. Using the KS test we have obtained

the total of 497496 test statistics values that were lo-

cated in the critical region deﬁned by α = 0.05. This

value represents 4.97% of all tested sets and is in good

agreement with the expected 5% value.

Secondly, to check the χ

test implementation we

simulate the circuit generation process. We generated

300 pairs of number samples S

i,1

i,2

,i ∈{1,··· ,300}

from the set {0, ··· ,7}. For each i, both sets S

i,1

i,2

were randomly generated according to the given ran-

dom distribution. We applied the two-sample χ

test

to compare samples S

i,1

i,2

for each i ∈{1,··· ,300}.

We obtained the set P of 300 P-values P

. This set was

tested by KS test for uniformity on the [0, 1]. We re-

peated the whole process 10

times (runs) and realised

that 5.1% of KS test statistic values were located in

the 5% critical region. This observation is also in a

good agreement with the model. All performed tests

indicate that the statistical model, our implementa-

tions of the KS test and the two-sample χ

test are

correct.

ConstructingEmpiricalTestsofRandomness

237
