Principles and Metrics to Improve Quality in SOA Applications

Joyce M. S. Franc¸a

and Michel S. Soares

Federal University of Uberlˆandia, Faculty of Computing, Uberlˆandia, Brazil

Federal University of Sergipe, Department of Computing, S˜ao Crist´ov˜ao, Sergipe, Brazil

Abstract:

Service-Oriented Architectures (SOA) have emerged as an architectural approach for building distributed ap-

plications based on the concept of assembling services. Currently, the growing complexity of software re-

quires greater attention about the quality of the produced applications. Many advances in SOA quality have

been proposed in the literature, such as deﬁnitions of quality models, attributes and some metrics. However,

many research gaps were found and thus much more needs to be done in this research area. There is a lack

of metrics and tools to evaluate quality in SOA. Another aspect that needs to be addressed is the application

and evaluation of research in accordance with the ISO 25000 standard. Therefore, this research project is

mainly aimed at addressing relevant issues in the quality of service-oriented applications that have not been

adequately explored. This paper presents the state of the art in the area of quality in SOA, the objectives that

have been deﬁned, the methodology to be followed to achieve the objectives, and the expected outcomes of

the research project.

1 INTRODUCTION

Service-Oriented Computing (SOC) is the comput-

ing paradigm that utilizes services as fundamental el-

ements for developing applications/solutions (Papa-

zoglou, 2003). A service is a capability of the busi-

ness organization that is implemented and made avail-

able on the Internet (or Intranet) so that other ap-

plications can access it. Services are autonomous,

platform-independent computational entities that can

be used to create large, complex applications.

An important concept related to SOC is the

Service-Oriented Architecture (SOA). Many deﬁni-

tions on SOA were proposed in the literature. Ac-

cording to the Open Group SOA Working Group

(SOA, 2014), SOA is an architectural style that sup-

ports service-orientation, and service-orientation is a

way of thinking in terms of services and service-

based development and the outcomes of services.

SOA has also been deﬁned as a distributed archi-

tecture with services distributed in an environment

working together to perform some tasks (Steen et al.,

2005). In summary, SOA can be deﬁned as a

paradigm or an architecture to implement loosely-

coupled, platform-independent distributed software

systems using communicating services. Currently,

SOA is well-recognized as an established architec-

tural paradigm for distributed systems (Goeb and

Lochmann, 2011).

Services performs functions that can be simple re-

quests for activities or complex business processes.

Therefore, services can be of simple nature or com-

posite. Composite services involve the concept of or-

chestration. The concept of orchestration is related

to automating business processes. The orchestration

allows services to be composed of other services, in

such a way that the logic of the process is centralized

by orchestration that enables extensibility (composi-

tion of new services).

Another important concept of the SOA paradigm

is choreography(Erl, 2005), which enables collabora-

tion between organizations of different applications.

Choreography is essentially a collaborative process

designed to enable organizations to interact in an en-

vironment that is not owned by any partner. The WS-

CDL

speciﬁcation (WSCDL, 2014) enables the ex-

change of information among multiple organizations

(or even different applications within the organiza-

tion).

Service-oriented computing is not the ﬁrst pro-

posed paradigm for systems integration. Several dis-

tributed solutions have been proposed, with varying

degree of success and limitations. Integration of soft-

ware systems became a key reference in the late 1990s

and many organizations were not well-prepared for it

Web Services Choreography Description Language.

M. S. França J. and S. Soares M..

Principles and Metrics to Improve Quality in SOA Applications.

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

(Erl, 2007). Thus, many systems were developed with

little elaboration and integration point to point was

created according to the needs that were emerging.

This approach produced a tangle of complex connec-

tions, difﬁcult maintenance and problems associated

with lack of stability, extensibility and inadequate in-

teroperability frameworks. The EAI

platforms intro-

duced the middleware that allowed more robust and

extensible architectures. Despite improvements in in-

tegration over time, middlewares were often consid-

ered to be complex and expensive (Erl, 2005).

Service-oriented computing proposes the use of

open standards such as SOAP

(SOAP, 2014) and

XML (to deﬁne the WSDL

(WSDL, 2014)). The

SOAP protocol is used for data transmission. The

WSDL describes the information about the service

such as the service functionality description and data

types transmitted in a structured way using a gram-

mar described in XML. The use of these open stan-

dards facilitates the development of service-oriented

applications because the exchanged information has a

standardized format.

Service in SOA is platform independent (Papa-

zoglou, 2003). This feature is of great advantage be-

cause SOA enables integration in heterogeneous envi-

ronments. Thus, no matter what platform the system

has been developedin, it is always possible to propose

integration using SOA.

The possibility of interacting systems in hetero-

geneous environments makes SOA a very attractive

technology because it enables reuse of legacy sys-

tems. Legacy systems hold the key and complex busi-

ness processes of companies. Legacy systems were

developed in the past decades using programming

languages such as COBOL, RPG, and C/C++ (Ben-

nett, 1995). These systems are known to be inﬂexible

and difﬁcult to maintain. It is estimated that more than

80% of business data in the world are executed on

COBOL and 50% -70% of total IT costs are expent for

the maintenance of these systems (Koutsoukos et al.,

2006). SOA has emerged with the promise of allow-

ing legacy systems to expose their core functionality

as services (Khadka et al., 2011).

With software systems becoming more complex

over time, quality assurance become increasingly im-

portant. Software quality is a challenge for software

engineering, and this challenge extends to SOA ap-

plications. The emergence of service-oriented archi-

tecture introduced new challenges. One of these chal-

lenges is the need to create design principles and spe-

ciﬁc design patterns for SOA in order to design high

Enterprise Application Integration middleware.

Simple Object Acess Protocol.

Web Services Description Language.

quality applications. These quality properties need to

be evaluated in practice, but few researches on spe-

ciﬁc quality attributes, tools and metrics for SOA ap-

plications were proposed in the literature. This is the

core of this thesis proposal.

2 STAGE OF THE RESEARCH

The ﬁrst stage of this project was to determine the real

applicability of SOA design principlesin practice, and

further evaluating the inﬂuence of these design prin-

ciples on the quality of SOA applications. This study

aims to analyze if these principles are used in practice,

how they are implemented, in which domains they are

most used, what advantages are obtained in their use,

and how the application of these principles inﬂuences

the quality of the application. A systematic literature

review has been performed to answer properly these

research questions.

The designed strategy to perform a systematic lit-

erature review was to search empirical studies that

mentioned the use of design principles. Articles pre-

senting researches in which SOA applications were

developed as case studies were recovered in the sys-

tematic review for an analysis of how the principles of

SOA design are used and if any mention was made to

the inﬂuence of the use of these principles in practice.

Among the results of this review, an interesting

one is that few studies mentioned the use of design

principles when developing SOA applications in case

studies. The reason is not yet clear. Therefore, the

second part of the project is to interview profession-

als and academic researchers with focus on trying to

better understand this and other results found within

the systematic review.

3 OUTLINE OF OBJECTIVES

The main objective of this study is to research on un-

derexplored topics in SOA quality. Several research

gaps were found in the area of quality in SOA. For

instance, lack of tools for measuring quality of SOA

applications (Goeb and Lochmann, 2011) and lack of

service design principles (Papazoglou et al., 2008).

In addition, few studies were published considering

the ISO 25000 standard (ISO/IEC, 2005) that deals

with quality and has been recently proposed to replace

the ISO 9126 (Goeb and Lochmann, 2011) (ISO/IEC,

2001).

The speciﬁc objectives of this research are:

1. To Systematically Evaluate the Applicability of

SOA Design Principles.

PrinciplesandMetricstoImproveQualityinSOAApplications

This study aims to contribute with design princi-

ples that improve the development and quality of

SOA applications. The existing SOA principles

have to be classiﬁed, for example, in relation to

their real applicability in practice, measured ad-

vantages and scope of use. Thus, during this re-

search a systematic review has been developed to

investigate these issues.

2. To Propose New Metrics.

Another objective of this study consists of evalu-

ating the existent metrics to measure SOA qual-

ity and to analyze them. It is of fundamental im-

portance to know if there exist metrics to evaluate

all SOA quality attributes, including the ones de-

scribed in ISO 25000. This work intends to pro-

pose new relevant metrics to assess the quality of

service-oriented applications.

3. To Propose Improvement in Tools.

From the literature review, it is possible to notice

the lack of tools to automatically collect metrics

to assess quality attributes of service-oriented ap-

plications. This study aims also to explore this

research gap in SOA. The strategy to achieve the

goal is to detect existing tools that measure qual-

ity in SOA applications. Thus, one can analyze

the quality of these tools based on predeﬁned cri-

teria and verify which metrics are automatically

used to measure SOA quality.

4. To Contribute with SOA Quality Attributes

Based on ISO 25000.

Several founded studies are based in the ISO

9126 standard that was replaced by ISO 25000.

This study aims to contribute with new metrics to

measure quality attributes in SOA based on ISO

25000.

5. To Produce Case Studies to Validate the Re-

search.

Software Engineering studies, in general, have

received critics regarding the few amount of re-

search with quantitative validation (Shaw, 2002)

(Runeson and H¨ost, 2009). One objective of this

research is to produce case studies with quantita-

tive validation. The case studies will be devel-

oped to suggest design principles for SOA that

improve quality application. Therefore, tools for

evaluating SOA quality will be used to produce

the quantitative validation. The qualitative analy-

sis of case studies will be performed by applying

questionnaires and interviews with users, students

and professionals.

4 RESEARCH PROBLEM

The research problem addressed by this study is re-

lated to quality of SOA applications. Several research

gaps were found in the literature in quality about

SOA. Thus, there are many SOA quality topics that

need to be better explored.

The research problem addressed by this study was

divided into three sub-problems presented below.

1. SOA Design Principles.

Initially, the purpose of this study is to focus on

a research challenge presented by Papazoglou in

(Papazoglou et al., 2008): Design principles for

engineering service applications. This research

topic covers the search for fundamental principles

that are the basis for designing services. It is im-

portant to ﬁnd out if this gap, proposed in 2008,

has been adequately addressed by researchers in

the past ﬁve years. Some research questions arise

from this topic: the literature provides all the fun-

damental principles for design services? How

these principles are used? What advantages are

obtained in their use? In what areas are they being

used? SOA applications are used only for legacy

systems or new systems too? Is there experimen-

tal evidence on the inﬂuence of these principles in

the quality of the application?

The ﬁrst hypothesis to this research is: H1 - Cur-

rent speciﬁc SOA design principles are necessary

and sufﬁcient to improve quality in SOA applica-

tions.

2. Lack of Metrics and Tools to Measure SOA

Quality Based on ISO 25000.

Several quality models speciﬁc for SOA have

been presented in the literature. However, these

quality models have their limitations related with

lack of metrics and tools to measure quality in

SOA applications. The proposed quality models

describe several quality attributes but do not pro-

vide tools for evaluating the degree of quality at-

tributes in SOA applications. Most quality models

were proposed in the literature in order to provide

quality attributes in accordance with the old ISO

9126. However, the ISO 25000 is more complete

and have a wider range of quality requirements for

software. Thus, there is a lack of research studies

addressing quality attributes based on ISO 25000.

Another important analysis is to verify if the exist-

ing quality attributes based on ISO 9126 complies

with the ISO 25000, and if ISO 25000 will bring

any beneﬁt at all when compared with ISO 9126.

The second hypothesis is: H2 - The ISO 25000

brings important beneﬁts to SOA applications

when compared to ISO 9126.

ICEIS2014-DoctoralConsortium

5 STATE OF THE ART

Literature review involves analyzing the studies al-

ready produced in the area. Literature review for this

project ia divided into two main areas: software qual-

ity for SOA and SOA design principles. The follow-

ing subsections describe some studies in these two ar-

eas.

5.1 Software Quality for SOA

The evaluation of software quality is an extremely im-

portant activity in the software development process.

According to Sanders and Curran (Sanders and Cur-

ran, 1994), quality is crucial for survival and success.

The software market is increasingly global, and com-

panies will have difﬁculties in succeeding on the mar-

ket unless they produce quality products and services.

According to Sommerville (Sommerville, 2010),

software quality is evaluated from internal and exter-

nal quality attributes. The factors that affect quality,

and can be directly measured, are called internal qual-

ity attributes (for example lines of code). Factors that

can only be indirectly measured are called external

quality attributes such as maintainability.

SOA quality can be evaluated by using several

external attributes, as for instance (O’Brien et al.,

2007): Interoperability, Performance, Security, Reli-

ability, Availability, Modiﬁability, Testability, Usabil-

ity, and Scalability. However, there is a lack of met-

rics to measure attributes such as modiﬁability and

reusability.

Quality models are elaborated to describe, to eval-

uate and to predict the quality of a SOA application.

These models can be provided, for example, by or-

ganizations of international standards or guidelines

(Voelz and Goeb, 2010). Speciﬁc models for SOA

quality have been proposed in the literature: S-Cube

(Gehlert and Metzger, 2008), WSQM2.0

(WSQM,

2005), Quamoco-extended (Goeb and Lochmann,

2011), and quality model for evaluating reusability

(Choi and Kim, 2008). SOA Quality models are most

often structured into a set of quality attributes that

should be found in SOA applications. Some models,

such as the one proposed by Choi and Kim (Choi and

Kim, 2008) also deﬁnes metrics to assess the deﬁned

quality attributes.

S-Cube is a quality reference model for service-

based applications. This quality model consists of

89 quality attributes for service oriented computing

based on software engineering attributes (ISO 9126

and UML proﬁles). The weaknesses found in this

OASIS Quality Model for Web Services (WSQM2.0).

model (Goeb and Lochmann, 2011) are the high com-

plexity and lack of clarity in many settings, the fact

that the model does not fully follow the rules of ISO

9126 and does not provide a tool to assess the pro-

posed quality attributes (actually the authors indicate

that the development of a tool will be addressed in

future work).

WSQM is a quality model for Web Services de-

ﬁned by OASIS (Organization for the Advancement

of Structured Information Standards)

. WSQM has

a similar approach to S-Cube in which it establishes

a set of important attributes of quality in the ﬁeld of

web services. However, according to Goeb (Goeb and

Lochmann, 2011), this model is not mature enough

because many settings are not accurate.

The research project Quamoco

(Kl¨as et al.,

2011) (Lochmann and Heinemann, 2011) formed a

quality model for software that deﬁnes a generic

meta-model that enables the creation of tools for

many types of systems. However, the Quamoco

model is restricted to unique systems, and therefore

does not provide support for SOA applications. Thus,

an extension to Quamoco was created to include ap-

plications in SOA meta-model (Goeb and Lochmann,

2011). The extended Quamoco listed several upcom-

ing activities to complete the project, one of them is

to create a tool to produce quality measures.

Other articles have been published presenting

metrics for evaluatingquality in SOA. Most case stud-

ies are focused on presenting metrics to evaluate the

quality of service (QoS). One of these studies was per-

formed by Choi and Kim (Choi et al., 2007) where

QoS metrics have been deﬁned to evaluate whether

services provide the responses for consumer appli-

cation (a Consumer Application is a partner organi-

zation application that provides information for ser-

vice). A set of metrics has been created to evaluate

each of the following six quality attributes: perfor-

mance, availability, reliability, dynamic discoverabil-

ity, dynamic adaptability and dynamic composability.

A case study was proposed to explore the applicabil-

ity of the metrics. Only one application was used as

case study, a Hotel Reservation Service (HRS). Met-

rics related to the availability of services were used

and it was concluded that the services of the HRS

have high availability. Considering the services per-

formance metrics, one service received long response

time indicating that improvements should be imple-

mented to optimize the service. The other proposed

metrics have not been evaluated by limitations in the

applicability. The study described in the paper was

based on the ISO 9126 quality model.

https://www.oasis-open.org/

http://www.quamoco.de

PrinciplesandMetricstoImproveQualityinSOAApplications

In 2008, Choi and Kim published another study

(Choi and Kim, 2008) that proposes metrics to evalu-

ate service reusability. In the study, reusability was

evaluated using quality attributes such as modular-

ity and adaptability. One case study in the ﬁeld of

ﬂights management with booking and purchasing air-

line tickets services was used to apply the new pro-

posed metrics. The study did not use tools to auto-

matically collect the results of the metrics.

It is possible to notice that much more needs to be

done regarding SOA quality research. There is a lack

of metrics and tools to evaluate quality in SOA. An-

other aspect that needs to be addressed is the produc-

tion of studies in accordance with the ISO 25000 stan-

dard because it is more complete in relation to quality

attributes than ISO 9126.

5.2 SOA Design Principles

According to the SWEBOK (Software Engineering

Body of Knowledge) (IEEE Computer Society, 2004),

software design principles are key notions considered

fundamental to many different software design ap-

proaches and concepts. Several design principles for

software have been proposed in the literature with the

aim of improving the logic of the solution and/or deal

with the problem complexity. The principles of soft-

ware engineering are useful for the emergence of best

practices (Bourque et al., 2002) that collaborate to

create consistent designs.

Examples of design principles for software en-

gineering found in SWEBOK (IEEE Computer So-

ciety, 2004) are abstraction, coupling and cohe-

sion, decomposition and modularization, encapsula-

tion/information hiding, separation of interface and

implementation, sufﬁciency, completeness and primi-

tiveness.

A brief description of each of the above princi-

ples are presented as follows based on various publi-

cations (Bass et al., 1998) (Bosch, 2000) (Buschmann

et al., 1996) (Jalote, 1997) (Liskov and Guttag, 2000)

(Pﬂeeger, 2001) (Pressman, 2009).

Abstraction: Abstraction is the process of represent-

ing data and programs omitting the implementa-

tion details.

Coupling and Cohesion: The coupling is deﬁned as

the degree of relationship between the modules.

Cohesiveness is deﬁned as the way that elements

of a module are related.

Decomposition and Modularization: Process to

decompose and modularize large software into

several smaller parts, often with the goal of

assigning different functions or responsibilities in

different components.

Encapsulation/Information Hiding:

Encapsulation/information hiding means group-

ing and packaging the elements and internal

details of an abstraction and making those details

inaccessible.

Separation of Interface and Implementation:

Separation of interface and implementation

involves deﬁning a component by specifying a

public interface, known by the client and separate

the details of how the component is implemented.

Sufﬁciency, Completeness and Primitiveness:

Achieving sufﬁciency, completeness and prim-

itiveness means ensuring that a software com-

ponent captures all the important features of an

abstraction and nothing more.

A literature review was proposed with the aim of

analyzing if the principles for software engineering

in general are applicable to SOA. Few studies in this

area were found. The study presented by Huhns and

Singh (Huhns and Singh, 2005) demonstrates how the

principle of abstraction is applied speciﬁcally in SOA.

Another important publications is the book from Erl,

T. (Erl, 2007) in which eight speciﬁc design principles

for SOA are highlighted. These studies are detailed as

follows.

Huhns and Singh (Huhns and Singh, 2005) show

how to apply the principle of abstraction in SOA. Ser-

vices provide high level of abstraction for large-scale

organizational applications. The article describes a

hospital system that provides a range of services to

exemplify existing levels of abstraction. A large hos-

pital has, among other activities, the challenge of

making the payment, providing suitable scales and

interacting with account systems. A hospital system

provides service within the organization itself, which

exempliﬁes a level of intra-enterprise abstraction, as

well as with other organizations. SOA allows that

legacy systems components can be encapsulated as

services, preserving the component behavior and fa-

cilitating composition. That way, the services enable

interoperability of systems belonging to the hospital.

Another level of abstraction highlighted in this ar-

ticle (Huhns and Singh, 2005) is the inter-enterprise

one. For better understanding the following situation

is illustrated. A traditional approach would be to send

paper bills for agencies and insurance companies that

receive it and type again data into their own informa-

tion system. Of course, these approaches are disap-

pearing in favour of online sales.

The service-oriented computing provides the abil-

ity for interaction between companies and allows the

choreography of the parties and automatically apply

local policies to suit the inter-enterprise processes.

ICEIS2014-DoctoralConsortium

The other level of abstraction presented was the in-

frastructure. The activities related to building com-

plex applications on distributed platforms, such as

network architectures, are difﬁcult and have led to an

interest in modular interfaces based services. Cur-

rently, companies can focus on their core business

and outsource their computing infrastructure to spe-

cialized companies.

According to Erl (Erl, 2007), a principle of de-

sign is deﬁned as a widespread and accepted con-

cept by the market. A principle can be compared to

good practice by the fact that both propose a means of

achieving something based on experience or market

acceptance. Erl presents eight speciﬁc principles for

SOA design: service contract, service loose coupling,

service abstraction, service reusability, service auton-

omy, service statelessnes, service discoverable, ser-

vice discoverable and service composability. These

design principles are considered fundamental princi-

ples for SOA applications and are widely referenced

in the literature. A brief description of each principle

is highlighted as follows.

Service Contract: services share standardized con-

tracts. A service contract consists of a technical

interface or one or more service description docu-

ments. Each service contract must comply with

the same standards applied to other design ser-

vices contracts within a service inventory.

Service Loose Coupling: services are loosely cou-

pled. The existence of a service contract, ideally,

is decoupled from the implementation details and

technology.

Service Abstraction: services are designed to limit

information in the service contract to what is re-

ally necessary for the service to be functionally

useful to consumers. Information beyond that is

published in a service contract and is considered

private and should not be made available for cre-

ating potential consumers of service. Services

are consistently abstract, and speciﬁc information

about technology, logic and function in the world

is outside the service boundary.

Service Reusability: services are reusable. The ser-

vice encapsulates the logic that is useful for more

than one service request. The encapsulated by the

service logic is generic enough to allow many us-

age scenarios and can be used for different types

of service consumers.

Service Autonomy: services are autonomous. That

way, the services have a contract that expresses

a well-deﬁned functional threshold which should

not involve other services.

Service Statelessnes: services minimize dependence

on the state. The services are speciﬁcally de-

signed to minimize the period during which they

exist in a condition of dependence on state infor-

mation.

Service Discoverable: services are designed to be

effectively discovered and interpreted so that the

discovery, its purpose and capabilities are clearly

understood. Service contracts should contain ad-

equate metadata that will be referenced correctly

when viewing queries are issued.

Service Composability: services are designed to act

as effective composition participants, regardless

of the size and complexity of the composition.

Services can be composed to automate business

processes of a company.

Besides presenting eight principles for SOA, Erl

(Erl, 2007) also provides an important insight into

other principles of SOA. The author asserts that some

principles and concepts of SOA were inspired by

principles of the object-oriented paradigm. A com-

parison of design principles for service orientation

was held for several fundamental principles of ob-

ject orientation. A section of the book discusses

how service orientation is related to each principle

of object-oriented design: Encapsulation, Inheritance,

Generalization and Specialization, Abstraction, Poly-

morphism, Open-Closed Principle (OCP), Don’t Re-

peat Yourself (DRY), Single Responsibility Princi-

ple (SRP), Delegation, Association, Composition and

Aggregation.

The work proposed by Erl deﬁnes the speciﬁc de-

sign principles for SOA. However, it is important to

deﬁne how these principles are applied in practice,

whether they are sufﬁcient and to what extent they

aggregate quality on applications.

6 METHODOLOGY

According to Shaw (Shaw, 2002), research in Soft-

ware Engineering in general seek for better ways to

develop and evaluate software. This study aims to

contribute with better ways of developingand evaluat-

ing SOA applications. The following research meth-

ods were planned to achieve the proposed objectives

(section 3).

Initially, the purpose of this study is to focus on a

research challenge presented by Papazoglou in (Papa-

zoglou et al., 2008): Design principles for engineer-

ing service applications. This research topic covers

the search for fundamental principles that are the ba-

sis for design service. It is important to ﬁnd out if this

PrinciplesandMetricstoImproveQualityinSOAApplications

gap, proposed in 2008, has been adequately addressed

by researchers in the past ﬁve years. In other words,

the literature provides all the fundamental principles

for design service? In addition, how these principles

are used? What advantages are obtained in their use?

In what areas are they being used? SOA applications

are used only for legacy systems or new systems too?

The literature provides few speciﬁc design prin-

ciples for SOA. Moreover, the existing principles are

focused on deﬁning the essence of a service and not to

contribute to improving the quality of applications in

SOA. Based on this, the ﬁrst planned step in this study

is developing a systematic literature review (Kitchen-

ham, 2004). The systematic review has the purpose

of analyzing the following research questions:

• What are the speciﬁc principles for SOA mostly

used in service-oriented applications?

• How these principles are applied in practice?

• In which areas these principles are used?

• The application of each principle has measurable

advantages in the quality of the application?

• The cited principles are sufﬁcient to develop qual-

ity SOA applications or there is need for propos-

ing new principles?

The proposed systematic literature review focuses

on searching empirical studies that use design prin-

ciples for developing their SOA applications. The

found studies are analyzed with the intention of an-

swering the research questions proposed previously.

In order to evaluate the proposed hypothesis, the

initial idea is to propose case studies (Yin, 2003)

(Runeson and H¨ost, 2009) to evaluate the quality of

SOA from the application of speciﬁc principles for

SOA. From experience and lessons learned in the de-

velopment of case studies, principles that enable qual-

ity improvement in SOA will be proposed.

Another research gap found in the literature is a

lack of metrics and tools to measure SOA quality.

In the research study presented by Goeb (Goeb and

Lochmann, 2011), he cited many speciﬁc quality met-

rics for SOA, however these models have no speciﬁc

tool support. Thus, it can be seen that there is much

to be done in the context of quality of services.

Case studies proposals are presented in the next

section. These proposals were based on ideas for im-

plementing service-oriented architecture in areas that

do not yet use this technology, or at least they are

still very incipient, and would represent an important

innovation to facilitate the implementation of several

activities.

6.1 Proposed Case Studies

A case study is deﬁned as “an empirical inquiry that

investigates a contemporary phenomenon within its

real-life context, especially when the boundaries be-

tween phenomenon and context are not clearly evi-

dent” (Yin, 2003). Rather than using samples, case

study methods involve an in-depth examination of a

single instance or event. When selected with care,

even a single case study may be successful in terms

of theory formulation and testing (Yin, 2003). This

might be because it is a critical case for testing a

well-formulatedtheory, and if the theory holds for this

case, it is likely to be true for many others.

There are several applications examples in SOA

that can be used as case study. The following two

examples are services oriented applications that may

be developed during the research.

1. University Students. Brief Description: Several

services must be performed by a student when

starting an undergraduate university course, such

as: registering at the library, request the card to

use University Restaurants, request various kinds

of student ﬁnancial support, such as student hous-

ing and transportation, access to research labs.,

and so on. The process to be done by the student

would be simpler if there was an application for

accessing all these services.

2. Hospital System. Brief description: A hospital

system has many complex processes that can be

automated. An example of a process that can be

automated is a solicitation to buy hospital sup-

plies. The service responsible for conducting the

purchase can access the system by the selling

company, request items, generate the full amount

of purchase, request permission from the purchase

to the hospital leader and then authorize to for-

ward the invoice to the hospital ﬁnancial area.

6.2 Validation

This study will be validated through qualitative and

quantitative analysis. Proposing a new solution to a

problem is not enough, and this solution needs to be

validated for its applicability in practice. Two ap-

proaches can be used to validate a study: quantita-

tive and qualitative. Quantitative consists in evaluat-

ing the product solution through numbers that can be

analyzed by statistical methods, while qualitative in-

volves descriptions, pictures and diagrams and can be

analyzed through categorization (Runeson and H¨ost,

2009).

This study proposes to contribute with a set of

principles, metrics and tools to collaborate with im-

ICEIS2014-DoctoralConsortium

provements in quality of SOA applications. This set

of principles, metrics and tools (called product of this

research) must be validated. The way to evaluate the

applicability of the product will be through a qual-

itative evaluation. The qualitative evaluation in this

case is to introduce the developed work during the re-

search for professionals through questionnaires to as-

sess whether the proposed product presents relevance

on its use. To perform this qualitativeanalysis, human

subjects, including master and doctoral students, uni-

versity professors, in addition to professionals work-

ing in industrial SOA applications are to be used with

the expectation that they can provide valuable feed-

back. For the development of controlled experiment,

the number of people is estimated to be between 15

and 20.

Validation of case studies will be done through

quantitative and qualitative evaluations. According

to Seaman (Seaman, 1999), a combination of quali-

tative and quantitative data often provides better un-

derstanding of the studied phenomenon.

The Quantitative analysis of the case studies in-

volves the use of metrics and tools for SOA. Thus,

SOA applications developed in this research will be

submitted to be evaluated with the implemented tools

regarding the quality of the produced application.

The qualitative analysis will be divided into two

steps. The ﬁrst is based on experience gained dur-

ing the development of case studies, such as lessons

learned and conclusions. The second step is to

produce a controlled experiment (Seaman, 1999) in

which the applications are introduced to human sub-

jects and they return feedback. The assessment will

be based on questionnaires and interviews.

7 EXPECTED OUTCOME

Two paradigms characterize much of the research in

Information Systems: behavioral science and design

science (Hevner et al., 2004). The behavioral science

paradigm seeks to develop and verify theories that ex-

plain or predict human or organizational behavior. It

has its roots in natural science research methods. The

main objectives are to developand justify theories that

explain or predict organizational and human phenom-

ena surrounding the analysis, design, implementation,

management, and use of information systems.

The design science paradigm, which is followed

in this research, has its roots in engineering. As a

matter of fact, it is fundamentally a problem solving

paradigm with emphasis on products and solutions

(Rossi and Sein, 2003).

There is lack of consensus as to the precise desired

outputs of design research. The resulting products of

this research, according to (Hevner et al., 2004), in-

clude 1) constructs or concepts, i.e., abstractions and

representations that deﬁne the terms used when de-

scribing an artifact; 2) models, i.e., abstractions and

representations, that are used to describe and repre-

sent the relationship among concepts; and 3) instanti-

ations, i.e., implemented or prototyped systems, that

are used to realize the artifact.

This study expects to contribute with research on

SOA quality. Some research gaps were found, such

as few speciﬁc design principles for SOA, few stud-

ies using ISO 25000 standards and lack of metrics and

tools to evaluate quality in SOA applications. Accord-

ing to (Shaw, 2002), Software Engineering projects

may produce different outcomes as ﬁnal products.

Therefore, the expected outcomes are:

1. SOA Design Principles Report.

The present study aims to contribute to a cata-

log that deﬁnes the principles of design speciﬁc to

SOA. In addition, to inform the actual applicabil-

ity of these design principles. That is, how prin-

ciples are applied in practice, the application do-

mains in which SOA is more widely used, and es-

pecially what are the effects of using these princi-

ples regarding the quality of the application. Most

of the answers contained in this report come from

the systematic literature review conducted in this

study. Another part can be produced from the ex-

periences and lessons learned during the develop-

ment of the case studies to be developed during

this research.

2. New Quality Attributes and Metrics in Accor-

dance With ISO 25000.

Another expected result of this research is to

propose quality attributes according to the ISO

25000. Most of studies address quality attributes

in accordance to the old ISO 9126. However, the

ISO 25000 provides a larger range of quality re-

quirements for software product. In addition to

proposing attributes, this study wants to produce

as a result an analysis to determine whether the

existing quality attributes based on the old ISO

9126 are in accordance with the ISO 25000.

3. Set of Metrics and Tools to Evaluate SOA

Quality.

Another important research result of this study is

a package of metrics and tools that can be used

to measure quality in SOA applications. The im-

plemented tool should automatically collect met-

rics results to analyze quality attributes contained

in SOA application such as modiﬁability and

reusability. This tool can collaborate with SOA

PrinciplesandMetricstoImproveQualityinSOAApplications

developers to investigate whether the chosen so-

lution design produced a quality application ac-

cording to the quality attributes.

4. Speciﬁc Solution - Case Studies.

According to Shaw (Shaw, 2002), a research re-

sult in software engineering can be a speciﬁc so-

lution which means to present a solution to an ap-

plication problem that shows use of software en-

gineering principles. Therefore, an important re-

search result is to develop an application using de-

sign principles and thereby producing a good so-

lution for the problem. This study will develop

two case studies (proposed in subsection 6.1) to

validate the metrics and tools produced. These

case studies will also be useful to analyze the use

of design principles and to discuss what it can be

inferred in the SOA applications quality.

REFERENCES

Bass, L., Clements, P., and Kazman, R. (1998). Software

Architecture in Practice. Addison-Wesley Longman

Publishing Co., Inc., Boston, MA, USA.

Bennett, K. (1995). Legacy Systems: Coping with Success.

IEEE Software, 12(1):19–23.

Bosch, J. (2000). Design and Use of Software Architec-

tures: Adopting and Evolving a Product-Line Ap-

proach. ACM Press/Addison-Wesley Publishing Co.,

New York, NY, USA.

Bourque, P., Dupuis, R., Abran, A., Moore, J. W., Tripp,

L., and Wolff, S. (2002). Fundamental Principles of

Software Engineering - A Journey. Journal of Systems

and Software, 62(1):59–70.

Buschmann, F., Meunier, R., Rohnert, H., Sommerlad, P.,

and Stal, M. (1996). Pattern-Oriented Software Ar-

chitecture: a System of Patterns. John Wiley & Sons,

Inc., New York, NY, USA.

Choi, S. W., Her, J. S., and Kim, S. D. (2007). QoS Metrics

for Evaluating Services from the Perspective of Ser-

vice Providers. In Proceedings of the IEEE Interna-

tional Conference on e-Business Engineering, pages

622–625. IEEE Computer Society.

Choi, S. W. and Kim, S. D. (2008). A Quality Model for

Evaluating Reusability of Services in SOA. In Pro-

ceedings of the 10th IEEE International Conference

on E-Commerce Technology (CEC 2008) / 5th IEEE

International Conference on Enterprise Computing,

E-Commerce and E-Services (EEE 2008), pages 293–

298.

Erl, T. (2005). Service-Oriented Architecture Concepts,

Technology, and Design. Prentice Hall Professional

Technical Reference.

Erl, T. (2007). SOA Principles of Service Design (The Pren-

tice Hall Service-Oriented Computing Series from

Thomas Erl). Prentice Hall PTR, Upper Saddle River,

NJ, USA.

Gehlert, A. and Metzger, A. (2008). Quality Reference

Model for SBA. Technical report.

Goeb, A. and Lochmann, K. (2011). A Software Qual-

ity Model for SOA. In Proceedings of the 8th in-

ternational workshop on Software quality, WoSQ ’11,

pages 18–25, New York, NY, USA. ACM.

Hevner, A. R., March, S. T., Park, J., and Ram, S. (2004).

Design Science in Information Systems Research.

MIS Quarterly,, 28(1):75–105.

Huhns, M. N. and Singh, M. P. (2005). Service-Oriented

Computing: Key Concepts and Principles. IEEE In-

ternet Computing, 9(1):75–81.

IEEE Computer Society (2004). Software Engineering

Body of Knowledge (SWEBOK). Angela Burgess,

EUA.

ISO/IEC (2001). Software Engineering - Product Quality,

ISO/IEC 9126-1. Technical report, International Or-

ganization for Standardization.

ISO/IEC (2005). ISO/IEC 25000 - Software engineering -

Software product Quality Requirements and Evalua-

tion (SQuaRE) - Guide to SQuaRE. Technical report.

Jalote, P. (1997). An Integrated Approach to Software En-

gineering. Springer-Verlag New York, Inc., Secaucus,

NJ, USA, 2nd edition.

Khadka, R., Reijnders, G., Saeidi, A., Jansen, S., and

Hage, J. (2011). A Method Engineering based Legacy

to SOA Migration Method. In Proceedings of the

2011 27th IEEE International Conference on Software

Maintenance, ICSM ’11, pages 163–172, Washing-

ton, DC, USA. IEEE Computer Society.

Kitchenham, B. (2004). Procedures for Performing System-

atic Reviews. Technical report, Keele University and

NICTA.

Kl¨as, M., Lochmann, K., and Heinemann, L. (2011). Eval-

uating a Quality Model for Software Product Assess-

ments – A Case Study. In Proceedings of 4. Workshop

zur Software-Qualit¨atsmodellierung und -bewertung

(SQMB’11).

Koutsoukos, G., Andrade, L., Gouveia, J., and El-Ramly,

M. (2006). Service Extraction. Technical Report

D6.2a, Sensoria Project.

Liskov, B. and Guttag, J. (2000). Program Development in

Java: Abstraction, Speciﬁcation, and Object-Oriented

Design. Addison-Wesley Longman Publishing Co.,

Inc., Boston, MA, USA, 1st edition.

Lochmann, K. and Heinemann, L. (2011). Integrating Qual-

ity Models and Static Analysis for Comprehensive

Quality Assessment. In Proceedings of the 2Nd Inter-

national Workshop on Emerging Trends in Software

Metrics, WETSoM ’11, pages 5–11, New York, NY,

USA. ACM.

O’Brien, L., Merson, P., and Bass, L. (2007). Qual-

ity Attributes for Service-Oriented Architectures. In

Proceedings of the International Workshop on Sys-

tems Development in SOA Environments, SDSOA ’07,

Washington, DC, USA. IEEE Computer Society.

Papazoglou, M. P. (2003). Service-Oriented Computing:

Concepts, Characteristics and Directions. In Proceed-

ings of the Fourth International Conference on Web

ICEIS2014-DoctoralConsortium

Information Systems Engineering, WISE ’03, Wash-

ington, DC, USA. IEEE Computer Society.

Papazoglou, M. P., Traverso, P., Dustdar, S., and Leymann,

F. (2008). Service-Oriented Computing: a Research

Roadmap. International Journal Cooperative Infor-

mation System, 17(2):223–255.

Pﬂeeger, S. L. (2001). Software Engineering: Theory and

Practice. Prentice Hall PTR, Upper Saddle River, NJ,

USA, 2nd edition.

Pressman, R. S. (2009). Software Engineering: A Practi-

tioner’s Approach. McGraw-Hill Higher Education,

7th edition.

Rossi, M. and Sein, M. (2003). Design Research Workshop:

A Proactive Research Approach. In Proceedings of the

26th Information Systems Research Seminar in Scan-

dinavia (IRIS 2003).

Runeson, P. and H¨ost, M. (2009). Guidelines for Con-

ducting and Reporting Case Study Research in Soft-

ware Engineering. Empirical Software Engineering.,

14(2):131–164.

Sanders, J. and Curran, E. (1994). Software Quality: a

Framework for Success in Software Development and

Support. ACM Press/Addison-Wesley Publishing Co.,

New York, NY, USA.

Seaman, C. B. (1999). Qualitative methods in empirical

studies of software engineering. IEEE Transactions

on Softwate Engineering, 25(4):557–572.

Shaw, M. (2002). What Makes Good Research in Software

Engineering. International Journal of Software Tools

for Technology Transfer, 4:1–7.

SOA (2014). Service Oriented Architecture: What Is SOA?

online.

SOAP (2014). Simple Object Access Protocol (SOAP) 1.1.

W3C Note. . online.

Sommerville, I. (2010). Software Engineering. Addison

Wesley, Essex,UK, 9 edition.

Steen, M., Strating, O., Lankhorst, T., and ter Doest, H.

(2005). Service-Oriented Enterprise Architecture,

chapter Service-Oriented Software System Engineer-

ing: Challenges and Practice, pages 132–154. Her-

shey, London, UK.

Voelz, D. and Goeb, A. (2010). What is Different in Quality

Management for SOA? pages 47–56. IEEE Computer

Society.

WSCDL (2014). Web Services Choreography Description

Language Version 1.0. online.

WSDL (2014). Web Services Description Language

(WSDL) 1.1. W3C Note. . online.

WSQM (2005). Quality Model for Web Services

(WSQM2.0). Working draft, OASIS.

Yin, R. K. (2003). Case Study Research. Design and Meth-

ods, volume 5 of Applied Social Research Method Se-

ries. Sage Publications, California, USA, third edi-

tion.

PrinciplesandMetricstoImproveQualityinSOAApplications
