Towards a Language for Representing and Managing the Semantics

of Big Data

Ermelinda Oro

1,2

, Massimo Ruffolo

1,2

, Pietro Gentile

and Giuseppe Bartone

Institute of High Performance Computing and Networking, CNR, Via P. Bucci 41/C, 87036 Rende (CS), Italy

ALTILIA srl, Piazza Vermicelli, snc, 87036 Rende (CS), Italy

Keywords: Knowledge Representation and Reasoning, Big Data, Smart Data, Unstructured Data, Data Integration,

Extract Transform and Load (ETL), Smart ETL, Database, NoSQL.

Abstract: The amount of data in our world has been exploding. Integrating, managing and analyzing large amounts of

data – i.e. Big Data - will become a key issue for businesses for better operating and competing in today’s

markets. Data are only useful if used in a smart way. We introduce the concept of Smart Data that is web

and enterprise structured and unstructured big data with explicit and implicit semantics that leverages

context to understand intent for better driving business processes and for better and more informed decisions

making. This paper proposes a language able to give a representation of Big Data based on ontologies and a

system that implements an approach capable to satisfy the increasing need for efficiency and scalability in

semantic data management. The proposed MANTRA Language allows for: (i) representing the semantics of

data by knowledge representation constructs; (ii) acquiring data from disparate heterogeneous sources (e.g.

data bases, documents); (iii) integrating and managing data; (iv) reasoning and querying with Big Data. The

syntax of the proposed language is partially derived from logic programming, but the semantic is

completely revised. The novelty of the language we propose is that a class can be thought of as a flexible

collection of structurally heterogeneous individuals that have different properties (schema-less). The

language also allows executing efficient querying and reasoning for revealing implicit knowledge. These

have been achieved by using a triple-based data persistency model and a scalable No-SQL storage system.

1 INTRODUCTION

One of the key challenges in making use of Big Data

lies in finding ways of dealing with heterogeneity,

diversity, and complexity of the data. Big Data

volume, variety and velocity forbid the adoption of

data integration and management solutions available

for smaller datasets based on traditional Extract

Transformation and Load (ETL) or manual data

manipulation approaches.

Big Data, locked in the web and enterprise

sources, can include both structured and

unstructured data. If smartly utilized it can yield

unprecedented insights into solving tough business

issues and improving customer relations. We

introduce the concept of Smart Data that is data with

explicit semantics combined with implicit semantics

that leverages context for better understanding

intent, optimizing business processes, and

supporting smarter decision-making. The challenge

is using Smart Data, rather than just Big Data, to

unlock the value held in data.

Implicit semantics can be obtained, for instance,

by means of annotation, entity and metadata

extraction, and natural language processing.

Inference and machine learning techniques can

discover implicit semantics. Ontologies are

considered a key technology enabling semantic

interoperability and integration of data, processes

and querying (Motta, 1999)(Staab et al. 2001) for

both structured data and unstructured data (Haase et

al., 2008)(Cimiano et al., 2007).

Associating Big Data to an ontology description

that allows for reasoning on large amounts of data is

becoming an issue assuming increasingly

importance. In order to recognize and join

information contained in a system to concepts in the

web or outside of your system, it is necessary a

language in which represent, organize and reason

about entities. This is the goal of the Semantic Web

of the last 15 years (Berners-Lee et al., 2001).

However, semantic web systems generally generate

651

Oro E., Ruffolo M., Gentile P. and Bartone G..

Towards a Language for Representing and Managing the Semantics of Big Data.

DOI: 10.5220/0004916906510656

In Proceedings of the 6th International Conference on Agents and Artiﬁcial Intelligence (ICAART-2014), pages 651-656

ISBN: 978-989-758-015-4

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

metadata and identify entities manually or

serializing database values. Actually, the tagging

process is very hard. An important issue is how to

store ontologies and how to reason with them,

without losing out of sight the need for scalability.

In fact, the effective use of ontologies requires not

only a well-designed and well-defined semantic

language, but also adeguate support to operations.

The Linked Data paradigm (Bizer et al., 2009) is one

approach to cope with Big Data. Linked Data

represents semantically well-structured,

interconnected, syntactically interoperable datasets.

Numerous commercial and non-commercial

organisations have started to utilize Linked Data for

purposes like acquisition, enrichment, or integration

of information. But, only a small part of the web of

documents is represented as rich data.

In this work we provide an initial contribution on

open issues related to the semantic management of

Big Data. The objective of this paper is twofold.

First, we describe initial work on a new language,

named MANTRA Language (ML), which allows for:

(i) representing the semantics of data by knowledge

representation constructs; (ii) acquiring Big Data

from disparate heterogeneous sources (e.g.

databases, web documents, social networks); (iii)

integrating and managing data; (iv) reasoning and

querying. Second, we present a triple-based data

persistency model, which enables efficient storage

and querying of Smart Data, and the implemented

system supporting the ML. This has been achieved

by using a triple-based data persistency model and a

scalable storage system that allows to store Big Data

in the form of triples, like RDF (W3C RDF) for the

Semantic Web, and to execute efficient querying and

reasoning operations in a distributed way. Roughly

speaking, the ML and its supporting system enable

to deal with Big Data from a knowledge

representation perspective. They enable to extract

data from heterogeneous data sources in order to

integrate them and execute efficient reasoning and

querying operations to reveal implicit knowledge.

The paper is organized as follows: Section 2

presents the MANTRA Language and Section 3

presents the main architecture of the system

supporting the language.

2 MANTRA LANGUAGE

Businesses are increasingly looking for semantic

tools that enable to model and manage complex

domain-knowledge and to solve real-world problems

(Dao, 2011) (Blomqvist, 2012). It is necessary a

language in which represent, organize and reason

about entities.

This section presents the MANTRA Language

(ML). The ML introduces ontological constructs and

database and linguistic descriptors, which enable to

extract and integrate data available in heterogeneous

data sources. The syntax is based on the intuitive

logic programming. In particular, ontological

constructs are partially derived from OntoDLP

(Calimeri et al., 2003) (Ricca and Leone, 2007),

whereas acquisition formalism are based on the

XOnto language (Oro and Ruffolo, 2008) (Oro et Al,

2009). OntoDLP introduces many interesting

features, including complex types, e.g. sets or lists,

and intentional relations, which are used in ML.

XOnto describes a simple way to equip ontological

element by a set of rules that describe how recognize

and extract objects contained into documents.

2.1 Ontology Constructs

Constructs that enable to define the structure of an

ontology (light schema) and its instances are

presented in the following.

Classes. A class can be thought of as a flexible

collection of structurally heterogeneous individuals

that may have different properties. Such collections

can be defined by using the keyword class followed

by its name. Class attributes can be specified by

means of pairs (attribute-name:attribute-type),

where attribute-name is the name of the property

and attribute-type is the class the attribute belongs

to. Class attributes model canonical properties

present in class instances and admit null and

multiple values by exploiting the triple-based data

persistency model. Unlike OntoDLP, the ML allows

for storing objects which properties do not match the

declared class schema and objects that have different

set of attributes. The syntax for declaring a class is

shown below:

class_person(name:string, age:integer,

father:person).

Class Instances. Class domains contain individuals,

which are called objects or instances. Each

individual in the ML belongs to a class and is

uniquely identified by a constant called object

identifier (oid). Objects are declared by asserting a

special kind of logic facts (asserting that a given

instance belongs to a class). However, as shown in

following paragraphs, the most common way to

define class instances in the ML is to use

descriptors. The syntax that allows defining objects

is the following:

ICAART2014-InternationalConferenceonAgentsandArtificialIntelligence

652

oid:class_name(att_name_1:value_1,…,

att_name_n:value_n).

p1: person(name:‘Jhon’, age:21,

father:p2).

P2: person(name:‘Sam’, age:50,

father:p3, income:3000).

Tanomies. Ontology concepts are usually organized

in taxonomies by using the

specialization/generalization mechanism. This is

usually done when it is possible to identify subsets

of individuals having different sets of attributes. In

particular, individuals that have at least one attribute

more than a given set of objects can be considered a

sub-class (specialization) of such objects. In the ML

are allowed specializations that represent not

exhaustive decompositions of the instances of a class

in which objects may have different sets of

attributes. The syntax that allows defining subclass

is the following:

subclass_name(new_att_name_1:value_1,…,

att_name_n:new_value_n)

subclassof superclass_name().

Relations. Another important feature of an ontology

language is the ability to model n-ary relationships

among individuals. Relations are declared like

classes: the keyword relation precedes a list of

canonical attributes. The set of attributes of a

relation is called relation schema and can be flexible

as for classes. The cardinality of the schema, also

called arity, can vary for different relation instances.

The ML allows for organizing relations in

taxonomies. Relation instances are equipped with an

oid when the number of attributes is above two

(reification).

2.2 Data Integration Constructs

Database and linguistic descriptors, which enable to

extract and integrate data available in heterogeneous

data sources, are presented in the following.

Descriptors are founded on the basic idea

described in (Oro and Ruffolo, 2008) and (Oro et Al,

2009) which describe a system for Information

Extraction (IE) from PDF documents. It represents

an approach founded on the idea that objects and

classes of ontologies can be equipped by a set of

rules that describe how recognize and extract objects

contained into an external source. We use

descriptors in order to acquire Big Data from

disparate heterogeneous sources. In particular, we

present two different kind of descriptors: for

database and for documents in natural language.

A descriptor is a rule with the form h



b in

which b (descriptor body) constitutes a pattern of

ontology objects that allows recognizing a (set of)

specific object defined in the left-side h (descriptor

head). Database and Linguistic descriptors are

described separately as follows.

Database descriptors. These descriptors allow for

describing how to recognize and extract objects and

relations instances starting from tuples stored in a

relational database. Database descriptors can be

defined by using the keyword descriptor followed

by related class (or relation) name in the head. While

in the body of the rule, there are: a built-in that

enables database connection and the list of atoms

that perform query operations on the knowledge

base. For each concept in the ontology, can be

defined a database descriptor able to connect the

database, perform queries and assign the query

results to variables declared in the head.

For example, suppose to have the following two

relations:

holdsCar(owner:Person, car:Car)

hasCar(owner,car)

where the relation holdsCar assign for each Person,

the owned Car. The table hasCar connects the

owners to their cars, stored on disk.

If we want to extract information about the owned

cars of the known persons from a database and

populate the ontology, we have to state as follows:

Descriptor holdsCar(O,C) 

#query(“mysql:port:user:password”,SELEC

T * FROM hasCar”,O,C),O:Person().

The assignment of the value to the variables in the

head can be done in the #query construct directly or

in the following part of the descriptor body. If the

view returned from the query has more variables

than those in the list, the schema of the class

(relation) in the head is increased with new attributes

of generic type named with the column name. So a

class can be seen as a container of objects potentially

belonging to multiple subclasses. This implicit

knowledge can be made explicit by reasoning

operations and specific algorithms.

Linguistic descriptors. These descriptors extract

concepts from an input text or document. For

example, given the input string “John owns a

Bentley Continental GT”, the following descriptors

enable to extract the person, the car and the relation

between them.

person(X) <- X:#entity(“Person”).

car(X) <- X:#dictionary(“Car”).

TowardsaLanguageforRepresentingandManagingtheSemanticsofBigData

653

carOwner(X,Y) <<- (sentence)

X:#entity(Person) Z:#lemma("own")

Y:#dictionary("Car").

In this example, we search the concept carOwner as

a weak sequence of concepts: a person, a lemma of

the verb “to own” and a car. In order to identify

persons we used the construct #entity that

enables to use sophisticated algorithms for

recognizing a specific type of entities, whereas for

recognizing cars we used a simple dictionary by

exploiting the construct #dictionary. In the

example, a car is recognized only if the term in the

input text matches to a term contained into the

dictionary named

"Car". In order to recognize a

lemma of the verb “to own” we used the construct

#lemma. The constraints

(sentence) ensure that

these items are contained in the same sentence.

2.3 Querying and Reasoning

The language enables to define reasoning tasks that

reason on the knowledge base and infer classes and

relations. As said before, the ML gives the

possibility to define classes as collections of

instances belonging to different, potentially

unknown, subclasses. So, in order to explicit

subclasses membership of instances, reasoning

modules are required to create new subclasses based

on certain properties.

In ML, it is possible to derive new knowledge

not only by reasoning on class and relation

instances, but also by meta-reasoning on the

structure of classes and relations. Currently, meta-

reasoning is possible by using the following built-in

constructs:

 #class (name:string): contains a fact class(“c”) for

each class with name “c”;

 #relation (name:string): contains a fact

relation(“r”) for each relation with name “r”;

 #subclass(sub:string,super:string): contains a fact

for each class “sub” that is subclass of “super” (a

built-in with the same meaning exists for the

relationships #subrelation);

 #type(class:string, instance:object): for each

instance of class “c” contains a fact

#type(class:“c”,instance:oid);

 #attribute( name:string,attr:string): contains a fact

#attribute(name:“c”,attr:“a”) for each

class/relation “c” that has an attribute named “a”.

The language can be used not only to derive new

knowledge but also simply to query in order to

extract knowledge contained in the ontology also not

directly expressed.

For example, suppose you want to find all the

Persons from Rome who have at least two cars. To

express the query we have to use the following

expression:

holds2Cars(N) <- person(name:N,

city:”Rome”), holdsCar(N,C1),

holdsCar(N,C2),C1<>C2.

Querying and meta-querying constructs can be

merged in order to obtain also the schema

information about objects.

3 SYSTEM IMPLEMENTATION

This section shortly describes the system

implementing ML. The system represents a

complete framework that allows for acquiring and

integrating data coming from heterogeneous sources,

for transforming data into Smart Data and for

querying and reasoning on them.

Main components of the system implementing

the ML are shown in Figure 1 and are described in

the following.

 The Parser Module reads code listing and builds,

in main memory, an image of the ML constructs it

recognizes. Eventually, it throws error messages if

syntax errors are found.

 The Type Checker module checks for

inconsistencies in the ontology. It verifies the

defined ontology contains some admissibility

problem (i.e. a class is declared twice). It also

ensures the compatibility of the defined and

assigned types. Enabling schema-less

representation consistency checking is a more

robust problem that is better to not address here

due to lack of space.

 The Descriptor Evaluator Module executes

descriptors on data sources. In particular, for

database descriptors, this module executes

connection and queries to the particular database

that contains data to extract. for linguistic

descriptors, this module evaluates linguistic

patterns on a given document and extract object

instances when patterns are recognized.

 The functionalities of Reasoning and Querying

Modules execute reasoning and querying tasks. It

is noteworthy that the novelty of our approach

consists in the triple-based data model with

distributed persistency. This allows pushing

integration algorithms directly within data storage

environments exploiting map reduce approaches

(Dean and Ghemawat, 2008).

In particular the use

of triple model enable to use map reduce approach

ICAART2014-InternationalConferenceonAgentsandArtificialIntelligence

654

presented in (Sun and Jin, 2010) to querying

distributed data store.

 Persistency Manager module deals with the

persistency of schema and instances of the

ontology.

Figure 1: System Architecture.

To perform querying and reasoning operations is

necessary to define a storage model able to make

efficient operations. In fact, although OWL (Smith

and Welty, 2003), based on Descriptive Logics

(Baader et al., 2003), has been designed for the

semantic Web, data in OWL is not easy to

manipulate or query when they grow up. In order to

overcome this problem, we need to study a tailored

storage model for our ML. We believe that a specific

physical representation of schemas and instances

and an ad hoc index structures are necessary. In this

work, we decided to store the ontology structure (T-

Box in OWL) separate from the data (A-Box in

OWL). The proposal is to obtain scalability by

storing light schemas of ontologies and instances

using NoSQL technologies. In particular, light

schemas can be expressed by graphs in which nodes

represent classes and reified relations of the

ontology, while edges represent semantic

relationships between classes (e.g. subclass,

equivalence) and roles. Therefore, the use of graph

database seems to be the most natural solution to

store light schemas. In particular, we decided to

store ontology structure in Neo4j (Neo4j). It is a full

ACID-transaction compliant graph database written

in Java. Although the data can also be viewed as a

graph, it is not possible to adopt the same storage

pattern seen for the schema above. We have to

consider the different nature of the operations to be

performed and the larger size of the data respect to

the schema. We believe that querying operations

respect some well-defined patterns. The most

common queries consist in finding an object with a

certain value for a specific attribute, all objects

having a specific property, etc. Each query involves,

like in SPARQL for RDF, three different entity:

subject (S), predicate (P) and object (O). This led us

to choose triple-based storage model for ontology

instances. We decided to adopt the well-known open

source project, Hbase, for distributed storage of

triples. A data row in HBase is composed of a

sortable row key and an arbitrary number of

columns, which are further grouped into column

families. Regarding the storage model, we adopt the

idea of (Sun and Jin, 2010) which uses six tables to

persist triples, one for each combination of subject,

predicate and object: S_PO, P_SO, O_SP, PS_O,

SO_P and PO_S. In these tables data are stored in

row keys and column names (values are left empty).

Each of these has only one column family and all

columns belong to this. As we can see in (Sun and

Jin, 2010), this storage model enable to execute

efficient querying operations on distributed data

store using map reduce strategy. The disadvantage

of this approach is that it requires more storage

space. There are several copies of data which locate

in different tables. But storage space can be

considered as infinite in a distributed environment.

4 CONCLUSIONS

In this work we addressed open issues related to the

semantic management of Big Data emerging in

several application areas. We described initial work

on the MANTRA Language (ML) and the supporting

system, which allows for representing the semantics

of big data, acquiring big data from heterogeneous

sources and enabling efficient reasoning and

querying on them. Even though the MANTRA

Language has a logic programming based syntax, it

differs from logic programming becouse the schema

of classes or relations is not fixed. This is possible

because of the underlying triple-based persistence

model, an one of the key feature of our framework.

As future work we will deeply study and define

formal syntax and semantic of the language and

related coplexity issues. We will define semantic

integration algorithms that can be pushed directly

within data storage environments exploiting map

reduce approaches (Dean and Ghemawat, 2008).

Moreover, real examples of applications will be

provided.

TowardsaLanguageforRepresentingandManagingtheSemanticsofBigData

655

REFERENCES

Baader, F., Calvanese, D., McGuinness, D. L., Nardi, D.,

Patel-Schneider, P. F., 2003. The Description Logic

Handbook: Theory, Implementation, and Applications,

Cambridge University Press, Cambridge.

Berners-Lee, T., Hendler, J., Lassila, O., 2001. The

Semantic Web. Scientific American, 279 (5): p.34-43.

Bizer, C., Heath, T., Berners-Lee, T., 2009. Linked Data -

The Story So Far. International Journal on Semantic

Web and Information Systems, Volume 5.

Blomqvist, E., 2012. The use of Semantic Web

Technologies for Decision Support – A Survey,

Semantic Web.

Calimeri, F., Galizia, S., Ruffolo, M., Rullo, P., 2003.

OntoDLP: a Logic Formalism for Knowledge

Representation. Anwer Set Programming.

Cimiano, P., Haase, P., Herold, M., Mantel, M., Buitelaar,

P., 2007. LexOnto: A Model for Ontology Lexicons

for Ontology-based NLP. In Proceedings OntoLex

(Workshop ISWC).

Dao, F., 2011. Semantic technologies for enterprises.

Technical report, SAP AG.

Dean, J., Ghemawat, S., 2008. MapReduce: simplified

data processing on large clusters. Commun. ACM 51.

Haase, P., Lewen, H., Studer, R., Erdmann, M., Gmbh, O.,

2008. The NeOn Ontology Engineering Toolkit. In

17th International World Wide Web Conference.

Motta, E., 1999. Reusable Components for Knowledge

Modelling, IOS Press. Amsterdam, The Netherlands.

Neo4j Graph Database, http://www.neo4j.org/. Retrieved

12/2013.

Oro, E., Ruffolo, M., 2008. XONTO: An Ontology-Based

System for Semantic Information Extraction from

PDF Documents. ICTAI.

Oro E., Ruffolo, M., Saccà, D., 2009. Ontology-Based

Information Extraction from PDF Documents with

Xonto. International Journal on Artificial Intelligence

Tools 18(5): 673-695.

Ricca, F., Leone, N., 2007. Disjunctive logic programming

with types and objects: The DLV+ system, Journal of

Applied Logic, Volume 5, Issue 3, 545-573.

Smith, M. K., Welty, C., McGuinnes, A.L., 2003. OWL

web ontology language guide. World Wide Web

Consortium.

Staab, S., Erdmann, M., Studer, R., Sure, Y., Schnurr, H.-

P., 2001. Knowledge Processes and Ontologies. IEEE

Intelligent Systems, 16(1): p.26-34.

Sun, J., Jin, Q., 2010. Scalable RDF Store Based on

HBase and MapReduce. ICACTE.

W3C. RDF. The Resource Description Framework.

http://www.w3.org/RDF/. Retrieved 12/2013.

ICAART2014-InternationalConferenceonAgentsandArtificialIntelligence

656
