Semantic Approach to WMO Codes

Enrico Fucile

European Centre for Medium-range Weather Forecasts

Shinfield Park, Reading, RG27HQ, U.K.

Keywords: BUFR, WMO Codes, Observations, IWXXM, METCE, EcCodes.

Abstract: Two initiatives are presented to make the WMO codes usable by a wider community: a new decoding li-

brary (ecCodes) and new WMO data formats based on a logical data model and ISO standards. Both are

served by a web accessible registry as a source of semantics. The European Centre for Medium-range

Weather Forecasts (ECMWF) has developed a decoding software (ecCodes) providing unified semantic ac-

cess to the WMO codes through a web accessible registry. The software is very effective in providing easy

access to the existing codes and to support conversion to a new set of WMO codes based on a logical data

model (METCE) which enables wide interoperability support through a unified semantics conforming to

ISO/TC 211. The first of such codes is IWXXM (ICAO Weather Information Exchange Model) which is

the new worldwide standard for the exchange of meteorological information in the context of the Air Traf-

fic Management.

1 INTRODUCTION

The World Meteorological Organization (WMO) is

the specialized agency of the United Nations for

meteorology (weather and climate), operational

hydrology and related geophysical sciences. It has

developed the Global Observing System (GOS)

(WMO, 2010) as a coordinated system of methods

and facilities for making meteorological and other

environmental observations on a global scale. The

observations made in GOS comprise in-situ meas-

urements of atmospheric parameters from several

platforms, satellite and other remote sensing obser-

vations. The data produced in these observations are

exchanged on a co-ordinate global system of tele-

communication facilities named GTS (Global Tele-

communication System) (WMO, 2009).

GTS makes available to the National Meteoro-

logical Services and to their Numerical Prediction

Centres a constant stream of observations on the

state of the atmosphere used to produce weather

forecasts at local and global scale. As an example

the European Centre for Medium-range Weather

Forecasts (ECMWF) is processing more than 300

million observational data elements every day to

produce forecasts of weather and chemical composi-

tion of the atmosphere.

To make effective use of such a huge number of

observations coming from a wide variety of sensors

an internationally agreed data format designed for

operational exchange is needed. At this purpose

WMO has developed a set of code forms with a

strong governance to make the exchange of infor-

mation possible in a worldwide scale. This set of

WMO codes constitutes an international standard for

the exchange of information on weather, climate and

hydrology. The importance of having a globally

governed set of code forms for the exchange of

observations is connected with the level of opera-

tional availability and quality of the data needed for

the use of National Meteorological Service opera-

tional activities.

WMO codes are a complex set of coding stand-

ards developed in more than fifty years and in con-

tinuous evolution. They are divided in two distinct

sets of alphanumeric and binary codes. The alpha-

numeric codes were developed for the transmission

on telegraphic lines and are made to be written man-

ually by a human observer and interpreted without

machine support. With the evolution of telecommu-

nications a new set of binary codes was developed

to improve the quality and to provide compression

algorithms which are needed in the transmission of

the high volumes of data produced by satellites and

some other remote sensing platforms as well as the

409

Fucile E..

Semantic Approach to WMO Codes.

DOI: 10.5220/0004843404090414

In Proceedings of the 3rd International Conference on Sensor Networks (MOEOD-2014), pages 409-414

ISBN: 978-989-758-001-7

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

forecast fields produced with numerical models.

Moreover the progressive replacement of the

manned observing stations with automatic stations

has made the binary production of observation re-

ports more convenient and effective.

The continuous evolution of the WMO codes

and the heterogeneous nature of the observing sys-

tem have resulted in a very complex set of codes

which makes very difficult for a user to access the

information requested in a consistent way across the

various parts of the coding system. To improve

consistency across the codes the Table Driven Code

Forms (TDCF) (WMO, 2003) have been developed

to replace the traditional alphanumeric codes (TAC).

2 TAC VS. TDCF

There are 76 different traditional alphanumeric

codes (TAC) (WMO, 2012a). An example of TAC

message is the Aerodrome routine meteorological

report (METAR) (WMO, 2012a) which is the mes-

sage of observation produced every hour by the

airport observation station and used by the air traffic

control to inform the pilots on the weather condi-

tions at the airport. The code form is quite complex,

but is made to be interpreted by a trained operator.

Here follows an example:

METAR EDDF 120550Z 03015KT 1400

R07R/P2000N R07C/P2000N

R07L/1900U SN DRSN BR VV///

M04/M04 Q1000 R07L/11//90

R07C/15//90 R07R/15//90 BECMG

4000 NSW=

The code starts with the word METAR and ends

with the sing “=”. A set of numbers and letters are

divided in groups which are recognized for their

position and for their alphanumeric pattern. The

element EDDF is the four character code for the

airport, meaning that the observation refers to

Frankfurt airport. The second element 120550Z says

that the observation is for the 12

of the month at

5:50 UTC (the month and the year are not expressed

in the message). The third element 03015KT means

that the wind is coming from 30 degrees with a

speed of 15 Knots. It is clear that decoding of each

of the elements does not follow any general rule

except the fact that information is split in groups

with different meaning.

Another example of TAC is the SYNOP (Report

of surface observation from a fixed land station). An

example of this kind of message is the following:

AAXX 13094 03002 45462 /0514

10097 20073 30238 40256 58011

90850 333 88/11=

Where AAXX is the start of the report of this kind

and “=” is the end. Only numbers and “/” are al-

lowed in the body of the message, which are

grouped in groups of 5 with exception of the groups

marking new sections like the group 333 which

denotes the start of section 3. The first element

13094 means that the observation is valid for the

of the month (no explicit indication of month

and year) at 9 am and the number 4 means that the

wind speed is observed with an anemometer and is

reported in knots. Decoding the elements of the

message is out of our scope we only want to point

out that each group has a different meaning and each

number within the groups has quite complicated

decoding rules which are different group by group

and code figure by code figure.

A coding system like the one used in the TAC

without general rules, in which each element has

different decoding rules is difficult to extend, to

maintain and makes impossible the task of produc-

ing a general decoder. To overcome these limita-

tions of the alphanumeric codes it was decided to

produce a new system based on a unique set of ta-

bles providing a list of elements reusable in different

contexts. A unique set of rules to decode a message

were also provided in a form that is possible to im-

plement decoding software to access information

from the message. The fundamental concept of these

new codes called Table Driven Code Forms (TDCF)

was the separation between the coding rules and the

elements used in the code forms. The rules are ge-

neric and apply to all the different types of messag-

es, while the tables of elements and sequences are

provided as external support to the decoding soft-

ware in the form of a palette of elements to be re-

used in different contexts and a set of sequences of

elements with a special meaning to be used in the

definition of a single message. With the TDCF ap-

proach is possible to produce a decoder implement-

ing the decoding rules, which can take as input the

Tables and decode the message, allowing a big flex-

ibility and extensibility connected with the fact that

new messages can be defined through new elements

and sequences without changing the decoding soft-

ware.

WMO has developed two different TDCF named

BUFR (Binary Universal Form for the Representa-

tion of meteorological data) and GRIB (General

Regularly-distributed Information in Binary form).

To limit the scope of this paper we will consider

SENSORNETS2014-InternationalConferenceonSensorNetworks

410

only BUFR which is also the more generic of the

two formats.

BUFR (WMO, 2012b) was developed as a con-

tinuous bit-stream made of a sequence of octets (1

octet = 8 bits). A general structure of the message

was defined and general rules for the decoding

where based on tables of elements in which the

number of bits used by that element and the parame-

ters to get an integer or a floating point value from

the content of the bits is given.

The message is composed of five sections. The

first three sections can be considered headers and

the last section is an end of message. The infor-

mation is coded in section 3 and 4. Section 3 is a list

of descriptors each of which occupies 2 octets and is

made of three parts: F (2 bits), X (6 bits) and Y (8

bits). The sequence F-X-Y identifies uniquely the

meaning and decoding rule for the descriptor. When

F=0 the descriptor is a simple element and is coded

as an integer I of N bits. To obtain the decoded real

value I must be multiplied by 10

-S

and a reference R

must be added. A decoder will be able to decode the

data by knowing the three coding parameters: S

(scale), R (reference value), N (number of bits) for

each descriptor with F=0. Tables of descriptors are

provided in the WMO Manual on Codes [5] with the

meaning and the coding parameters to be used by

decoding software.

An example for the dew point temperature is

given in table 1. When in section 3 of the BUFR

message the element 0-12-003 is read by a decoder

it means that in section 4 (data section) there are 12

bits in which an unsigned integer I is stored, that

multiplied by 10

-1

gives a “Dew point temperature”

in Kelvin (the reference value is 0 in this example

and therefore nothing needs to be added to the re-

sult).

BUFR decoding rules comprise also descriptors

with F=1, 2 or 3. F=1 called replication descriptors

and are used to realise repetitions of groups of de-

scriptors. Descriptors with F=2 are operators acting

on the following descriptors by changing their

meaning or their decoding parameters. Descriptors

with F=3 are called sequences and are used to define

sequences of descriptors having a particular mean-

ing and used in many cases to build other sequences.

It is not the scope of this paper to give a detailed and

comprehensive description of the decoding rules of

BUFR. We only want to highlight that BUFR is

based on general rules, which are very complex in

some aspects and are based on external tables of

descriptors which are published in the WMO Manu-

al on Codes and in text or XML format from WMO

web site www.wmo.int.

3 A SEMANTIC APPROACH

TO BUFR

The approach implemented in BUFR provides a

great flexibility in the definition of new messages

and therefore in dealing with the growing set of

sensors and observation types. However the connec-

tion between the BUFR code (0 12 003 in table 1)

and its meaning has forced a generation of scientists

to learn the code figures and to use them in their

software. The fact that the meaning is connected

with the code figure and that the code tables are

external and can be easily replaced with convenient

tables compiled by the user has made the use of

BUFR code very difficult. The usability of a coding

system as BUFR is very important. Indeed the fact

that decoding is a process based on code numbers

can prevent the use of useful information by the

scientific community and slow down the implemen-

tation of new observations in the processing system

of a numerical prediction centre. There are several

initiatives to make BUFR more users friendly. They

are based on the importance of giving clear seman-

tics to the information in the message in a way that it

will be easily accessed by any user and that the

interoperability of different systems will be im-

proved.

ECMWF is producing new decoding software

(ecCodes) providing semantic elements to the user

rather than numeric codes. The semantics used by

ecCodes is going to be exposed in a web accessible

registry to the benefit of a wide community and to

make the decoding software independent from the

semantic source which will be external and accessed

by the software itself. On another initiative WMO

has started an activity of review of the codes to

enforce the semantics in the design of the coding

systems using UML modelling to produce data

models which are semantically rich and more

Table 1: BUFR table B entry for dew point temperature giving meaning and decoding parameters for the element

Code Name Unit Scale

Reference

value

Number

of bits

0 12 003 Dew point temperature K 1 0 12

SemanticApproachtoWMOCodes

411

suitable to work in an integrated web environment.

The two initiatives aim to address the problem in

two different time scales: ecCodes and the web

registry are an attempt to give better accessibility to

the existing codes, while the model based develop-

ment of codes is a longer term initiative which will

require the replacement of the current code forms

with new data formats designed with different prin-

ciples.

3.1 Decoding based on Semantics

The new decoding software developed at ECMWF,

called ecCodes, is based on the concept of making a

clear separation between the coding (binary) level

and the semantic level of a BUFR message.

The software is written in C and provides bind-

ings for FORTRAN, Python and Perl. It also pro-

vides a set of command line tools to perform simple

operations on the messages.

ecCodes is not only a BUFR decoder. It is a gen-

eral purpose decoder able to decode with the same

function calls alphanumeric and binary WMO mes-

sages. The software is made of two main compo-

nents: decoding engine and decoding rules. The

engine is written in C and able to read the appropri-

ate decoding rules from text files while parsing a

binary or alphanumeric input message. The decod-

ing rules are written in a language interpreted by the

decoding engine and they are cached for efficiency

reasons. Writing new decoding rules is fairly simple,

but is not part of the work that a user has to do to

decode a message. The decoding rules are provided

with the library and are used at runtime while decod-

ing messages. The interface provided to the user is

based on a key/value approach. In all the available

bindings there is a get function which is getting the

value of an element of information associated to a

key name. As an example to access the “dew point

temperature” in a METAR or in a SYNOP or in a

BUFR message, the function call is the same for the

three types of messages:

codes_get(m,’dewPointTemperature’

,dewPointTemperature)

where m is the message previously loaded with an

appropriate function, dewPointTemperature is

the key name and the third argument is the variable

to which the value found in the message is assigned.

The example is of a FORTRAN function, but also

Python, Perl and C equivalents are provided with

similar syntax.

The function is actually looking for the element

0-12-003 in BUFR or for the corresponding ele-

ments in METAR and SYNOP to provide the value

of the dew point temperature.

There are two problems that the software has to

address in this operation. There can be more than

one dewPointTemperature element in the

message and the association with the unified seman-

tics is a complex and difficult operation requiring a

deep analysis of the BUFR tables and of the alpha-

numeric coding because they were not designed to

support a unified semantics.

The first problem is solved with a specification

of the information element. As an example if there

are two different dewPointTemperature ele-

ments corresponding to different hours of the day it

will be possible to distinguish them with

codes_get(m,’/hour=6/dewpointTemp

erature’,dt1)

codes_get(m,’/hour=9/dewpointTemp

erature’,dt2)

where dt1 and dt2 are the values of dew point

temperature at 6 and 9 respectively.

An analysis of the code forms is being performed

with the aim to provide a durable link between the

numeric codes and the key names allowing the se-

mantic access. It is evident that if the results of this

analysis are made available only to the decoding

software this will have the drawback of limiting the

semantic access to ecCodes. With the aim of build-

ing a semantic of general use and accessible to any

decoding software WMO is developing a web ac-

cessible registry to make the codes and its semantics

publicly available and persistent. ecCodes will use

the WMO codes registry as semantic source for the

message decoding and will provide to the user a

quick way of inspecting the meaning of each ele-

ment of the message by navigating the registry. The

WMO codes registry is already accessible at

codes.wmo.int and provides at the moment only

support for a small part of the WMO codes (the

aviation codes) for which there was a requirement of

building an XML format and supporting it with web

accessible registry. The WMO codes registry will be

soon developed to support BUFR.

3.2 Building Semantics in the Message

Structure

It is sometimes very difficult to provide semantic

access to a coded message when it was developed

without the purpose of giving to it a clear semantic

structure. Therefore WMO is planning to change the

SENSORNETS2014-InternationalConferenceonSensorNetworks

412

way a code form is designed by developing first a

logical data model and deriving the corresponding

physical coding with an automatic process. With this

technique a logical model providing clear semantics

is developed first and from this model a physical

coding is derived by means of an automatic process.

The same logical model can therefore produce

BUFR and XML format implementing the same

semantics. This will allow users of two very differ-

ent coding systems like BUFR and XML to share

the semantics and therefore to work independently

from the coding format.

The process of deriving a data format from a log-

ical data model has been applied by WMO for the

first time in the messages used for aviation purpos-

es: METAR (Aerodrome routine meteorological

report)/ SPECI Aerodrome special meteorological

report ), TAF (Aerodrome forecast) and SIGMET

(Significant Meteorological Information) [4]. The

project is being developed by the WMO Task Team

on Aviation XML (TT-AvXML), and the first re-

lease version of the logical model and the XML

schemas, automatically derived from the model

where publicly released in September 2013

A model has been developed METCE (Modele

pour l’Echange des informations sur le Temps, le

Climat et l’Eau) which is designed with the purpose

of enabling semantic interoperability in the fields of

weather, climate and water. At this aim it has been

decided to make it compatible with the ISO/ TC 211

Geographic information/Geomantic. METCE makes

use of the ISO 19156 Observation & Measurement

to provide conceptual definitions of meteorological

observations to be imported in domain specific ap-

plication schemas.

An example of domain specific application

schema is the ICAO (International Civil Aviation

Organisation) Weather Information Exchange Mod-

el (IWXXM) which was developed by TT-AvXML

to define the semantics for the aviation meteorologi-

cal messages for which an XML version was re-

quested by ICAO.

To illustrate the advantage of using a unified se-

mantics derived from a logical model to build the

code format we take a single group from a METAR

message reporting the wind observed at the aero-

drome:

17006G12MPS

Downloadable from http://www.wmo.int/pages/prog/www/WIS/

wiswiki/tiki-index.php?page=AvXML-1

The logical model can be visualised from http://wis.wmo.int/

AvXML/AvXML-1.0/index.htm.

the meaning of this group is that the wind is blowing

from the direction of 170 degrees with a mean speed

of 6 metres per second and gusts of 12 metres per

second. The corresponding XML conformal to the

schema produced from the logical model is:

<iwxxm:surfaceWind>

<iwxxm:AerodromeSurfaceWindForecast vari-

ableWindDirection="false">

<iwxxm:meanWindDirection

uom="deg">170</iwxxm:meanWindDirection>

<iwxxm:meanWindSpeed

uom="m/s">6</iwxxm:meanWindSpeed>

<iwxxm:windGustSpeed

uom="m/s">12</iwxxm:windGustSpeed>

</iwxxm:AerodromeSurfaceWindForecast>

</iwxxm:surfaceWind>

this construct is using terms which are defined in the

logical model and are linked to a unified semantics

published in the WMO codes registry at

codes.wmo.int. The advantage of basing the code

system on a unified semantics is that the terms are

publicly accessible, reusable in different contexts

and used with the same meaning in different coding

systems. It is possible indeed to produce a BUFR

format from the same logical model to allow the use

of the same semantics from a very different coding

standard.

4 CONCLUSIONS

The evolution of WMO codes used to exchange

observations from a wide variety of sensors and

platforms is a continuous process. The original al-

phanumeric codes where based on specific and

fragmented decoding rules based on the meaning of

sequences of numbers and letters with lack of a

general unified semantics. TDCF were introduced to

provide general decoding rules separated from the

specific definition of the elements of information.

The large and growing number of different ob-

servation types requires a unified semantics to make

use of the information in different contexts. There

are several initiatives to provide access to the obser-

vations through a unified semantics. We have dis-

cussed two of these initiatives: development of a

decoding software (ecCodes) exposing unified se-

mantics for WMO TAC and TDCF messages,

changing the development process of WMO codes

making it dependant on the design of a logical data

model providing a unified semantics. Both initia-

SemanticApproachtoWMOCodes

413

tives are based on a web accessible registry as a

central source of semantic.

The two approaches complement each other be-

cause the decoding software will provide at a given

extent the same semantics that will be built with a

logical data model, provided that ecCodes will use

the same terms that will be used in the development

of the logical data model. At this aim a web accessi-

ble registry of semantic terms is being published by

WMO under codes.wmo.int to provide the semantics

for the decoding software and for the data model-

ling. This web registry will represent an authorita-

tive source of terms maintained by WMO usable in

different contexts and for different purposes.

WMO has started to develop a logical data mod-

el called METCE and the first specific domain ap-

plication schema IWXXM for aviation meteorologi-

cal data and the technique of designing a logical data

model to automatically produce an XML schema has

proven successful and will be applied to produce

BUFR formats.

REFERENCES

Manual on Global Observing System, WMO No. 544

(2010)

Manual on the Global Telecommunication System, WMO

No. 386 (2009)

Guide to WMO Table-Driven Code Forms FM 94 BUFR

and FM 95 CREX, WMO 2003. Available from

http://www.wmo.int/pages/prog/www/WMOCodes/G

uides/BUFRCREXPreface_en.html

WMO Manual on Codes Part A - Alphanumeric Codes,

WMO No. 306 Vol. I.1 (2012)

WMO Manual on Codes, WMO No. 306 Vol. I.2 (2012)

SENSORNETS2014-InternationalConferenceonSensorNetworks

414
