Surprising Recipe Extraction based on Rarity and Generality

of Ingredients

Kyosuke Ikejiri, Yuichi Sei, Hiroyuki Nakagawa, Yasuyuki Tahara and Akihiko Ohsuga

Graduate School of Information Systems, University of Electro-Communications, Chofu-city, Tokyo, Japan

Keywords: Data Mining, Recipe, Information Recommendation.

Abstract: Many surprising recipes that utilize different ingredients or cooking processes from normal recipes exist on

user-generated recipe sites. The easiest way to find surprising recipes is to use the search function of the recipe

sites. However, the titles of surprising recipes do not always include a keyword, such as “surprise”, or an

indication that a recipe is unusual in any way. Therefore, we cannot find surprising recipes very easily. In this

paper, we propose a method to extract surprising or unique recipes from those user-generated recipe sites. We

propose an RF-IIF (Recipe Frequency-Inverse Ingredient Frequency) based on TF-IDF (Term Frequency-

Inverse Ingredient Frequency). First, we calculate the surprising value of the ingredients by using RF-IIF.

Then, we calculate the surprising value of each recipe by summing the surprising values of the ingredients that

appear in a recipe. Finally, we extract recipes that have high surprising values as surprising recipes of the dish

category. In the evaluation experiment, the subjects requested an evaluation about each surprising recipe. As a

result, we showed that the extracted recipes were valid recipes and also had a surprising or unusual element.

Therefore, we showed the usefulness of the proposed method.

1 INTRODUCTION

Planning meals for every day of the week is very

hard. Recently, many user-generated recipe sites,

where anyone can freely post their recipes, have

appeared on the Internet. The number of recipes and

users on these user-generated recipe sites are

increasing every year. Visitors to the site can use the

search function on the recipe sites to find recipes for

their desired dishes. Thus, many people use user-

generated recipe sites when they are in the planning

stage of their dishes and meals.

On user-generated recipe sites, there are not only

normal recipes, but also surprising or unusual

recipes. A “surprising recipe” has different

ingredients or cooking processes from the normal or

traditional version of the recipe. When a person feels

tired of normal recipes, they are able to cook a wider

variety of dishes if they can browse surprising

recipes. The easiest way to find surprising recipes is

to use the search function of the recipe sites.

However, the titles of surprising recipes do not always

include the keyword “surprise”. Therefore, we cannot

find those unique recipes simply by using the search

function. Many surprising recipes are buried within

the long lists of “normal” recipes.

We propose using RF-IIF (Recipe Frequency-

Inverse Ingredient Frequency) based on TF-IDF to

calculate the “surprise” value of an ingredient in a

recipe. The surprise value of a recipe is calculated by

summing the surprising values of ingredients used in

the recipe.

The next section describes application scenarios,

while Sections 3, 4, and 5 discuss our proposed

method in detail and evaluate it. In Section 6 we

introduce related work and Section 7 discusses future

work and concludes the paper.

2 APPLICATION SCENARIOS

Suppose that a housewife who cooks every day

from her normal repertoire wants to make a different

version of a dish from her standard fare. In that

situation, we consider that her satisfaction level will

increase if she can browse surprising, new recipes on

user-generated recipe sites.

For example, suppose that she wants to eat ground

steak, but is tired of standard ground steak recipes.

However, she can find a surprising recipe for ground

steak, which uses cucumber sauce, for example, if

she uses our proposed method. As another example,

428

Ikejiri K., Sei Y., Nakagawa H., Tahara Y. and Ohsuga A..

Surprising Recipe Extraction based on Rarity and Generality of Ingredients.

DOI: 10.5220/0004817304280436

In Proceedings of the 6th International Conference on Agents and Artiﬁcial Intelligence (ICAART-2014), pages 428-436

ISBN: 978-989-758-015-4

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

Figure 1: Overview of our proposed method.

let’s assume that she wants to find a surprising

recipe for pasta. In this case, she can find recipes,

such as one for cream pasta, which uses rice powder.

Yet again, she is able to create a surprising recipe if

she uses our proposed method, rather than a

traditional cookbook.

In our proposed method, the user can specify the

name of his or her favorite dish. Therefore, she can

browse a few different recipes than those she usually

makes. Thus, our proposed method is effective when

she wants to eat a slightly different dish, even if she

doesn’t want to try a completely new recipe.

3 APPROACH

In this paper, we calculate each surprising value of

an ingredient of the dish category specified by a user

to extract surprising recipes. We define surprising

recipes as those that use surprising ingredients.

Additionally, we define surprising ingredients as

ones that have a low frequency of appearance in

certain dish recipes within the specified category,

but have a high frequency of appearance in other

dish recipes.

First, we extract recipes from the dish category

(e.g., ground steak) that are specified by a user from

all recipes on the user-generated recipe site. Some of

the recipes in the user-generated recipe site are

categorized, but many of them are not categorized.

Therefore, we extract all recipes containing the

name of the dish category specified by a user in the

recipe name. However, recipes of other categories

may exist in the extracted recipes. Therefore, we

remove recipes from other categories from this set of

recipes and extract all the ingredients in these

recipes by the methods described in 3.1 and 3.2.

Then, we calculate surprising values of the

ingredients described in 3.3, and finally, we extract

surprising recipes by using the surprising value of

ingredients described in 3.4. We show an overview

of our proposed method in Figure 1.

3.1 Remove other Category Dishes

For example, we extract recipes containing “ground

steak” in the recipe title when we want to extract

ground steak recipes from the list of all recipes.

However, some extracted recipes may not belong to

the specified category. For example, the recipe

whose title is “ground steak bread” which should

belong to the “bread” category, can be extracted

when the user specify the category “ground steak”.

Therefore, we remove these recipes with the

following method. First, we make lists of categories

of dishes on the user-generated recipe site. However,

we can remove the category from the lists if the dish

name that we want to extract contains the category

name. For example, we want to extract recipes of

“ground steak”, but there is also “steak” on the list.

Then, we remove recipes from the extracted recipes

if the recipe title contains words on that list. As a

result, we will extract only the ground steak recipes.

3.2 Preliminary Processing

On a user-generated recipe site, users can write

down ingredients and the cooking processes of

SurprisingRecipeExtractionbasedonRarityandGeneralityofIngredients

429

specific recipes. Thus, the descriptions have words

that are not ingredients (e.g., comments for readers),

including spelling variations and extra words (e.g.,

“*”, “(1)”, “(2)”). First, we limit our search to only

ingredient names by removing symbols such as “*”

and “(1), (2), …”, as well as parentheses like

“(bigger)”. Then, we remove spelling variations of

ingredients. In this paper, we manually compile a list

of spelling variants of ingredients within two

categories of dishes in our evaluation (see section

. We consider we can automate this process using

such techniques (Young, 2012), (Maarten, 2008) on

spelling variations. We plan to apply these

techniques in the future. Finally, we manually

remove words that are clearly not ingredients.

3.3 Calculating Surprising Theoretical

Value of Ingredients

Let m represent the dish category specified by a

user. Ingredients with a low frequency of appearance

in the dish category m have possibility for surprising

ingredients within the dish category m. However,

such ingredients may not be well known among

users. If the user does not know the ingredients at

all, she might not feel that they are surprising. In this

paper, we propose that users feel surprised when

they are recommended to use ingredients that are

well known, but do not normally come up as

ingredients for the specified dish category.

Moreover, if the ingredients are very rare, users

cannot buy them in normal supermarkets. Therefore,

among those ingredients that have a low frequency

of appearance in the specified dish category, the

ingredients with a high frequency of appearance in

all recipes are considered surprising recipes within

the dish category m.

The technique, called TF-IDF (Term Frequency-

Inverse Document Frequency) is used to obtain the

characteristic word in a certain document. TF is the

frequency of appearance of words in the document.

IDF is the inverse frequency of appearance of words

in the document set. TF-IDF, which represents the

weight of a certain word, is calculated by

multiplying the TF and the IDF. In other words, the

weight of the word that appears frequently in a

certain document but does not appear in other

documents is high. Thus, it is possible to obtain the

characteristic words of a certain document. Many

people utilize a method based on TF-IDF in fields

We also applied the list to the third category. As a result, we

were able to remove the spelling variants of ingredients without

problem.

that involve information retrieval (Jiaul, 2013),

(Luis, 2012), (Senthil, 2012).

In this paper, we define surprising ingredients of

a certain dish category as “the ingredient that have a

low frequency of appearance in the specified

category, but a high frequency of appearance in

other categories”. This is similar to the idea of TF-

IDF. In order to extract surprising ingredients, we

propose RF-IIF (Recipe Frequency-Inverse

Ingredient Frequency), which is based on TF-IDF, to

calculate the surprising value of each ingredient. We

call the resultant value that is calculated based on

RF-IIF as the surprising theoretical value (STV).

RF-IIF

i,m;p

(Equation (1)) represents the

surprising value of ingredient i among the dish

category m, specified by a user, with the parameter

p. RF-IIF

i,m;p

is calculated from RF

(Equation (2))

and IIF

i,m

. RF

represents the generality of the

ingredient i, and IIF

i,m

(Equation (3)) represents the

rarity of the ingredient i within the dish category m.

all

is the number of all recipes, R

is the number of

recipes including the ingredient i within the list of all

recipes, R

is the number of recipes in the dish

category m, R

i,m

is the number of recipes that

include the ingredient i within the dish category m.

The parameter p is used for adjusting the weight of

the rarity and generality of ingredients. We can

extract ingredients with higher rarity from the dish

category m by increasing p.

miipmi

IIFRFIIFRF

,;,

- 

(1)

all

RF 

(2)

IIF

log

(3)

3.4 Calculating Surprising Theoretical

Value of Recipes

On most user-generated recipes sites, recipes usually

consist of five elements: title, completion image,

ingredients list, cooking process, and a comment by

the poster of the recipe. We think that most posters

will emphasize the inclusion of an ingredient when

they use it as a surprising ingredient. In this case,

they are likely to write the ingredient name on the

comment column. We morphologically analyze the

comments connected to the recipes of the dish

category m. If an ingredient name occurs in the

comment section of the recipe, then we add its

surprising value to the STV of the recipe. In this

way, we can calculate the STV of recipes.

ICAART2014-InternationalConferenceonAgentsandArtificialIntelligence

430

Specifically, we define E as a set of elements that

are used to calculate STV of the recipe and we

define I

as a multi-set of ingredients within element

E. We define S

r,m;p

as the STV of recipe r in dish

category m when the weight parameter is p. S

r,m;p

calculated by







EeIi

pmipmr

IIFRFS

;,;,

(4)

4 EVALUATIONS

4.1 Abstract of Evaluations

We evaluated the surprising recipes that were

recommended by our proposed method. Our results

demonstrate the effectiveness of our proposed

method.

We extracted surprising recipes from the dish

categories of “ground steak”, “pasta” and “gratin”

from a user-generated recipe site with our proposed

method. The weight parameter p was set to 5

because we had obtained a good result beforehand.

Then, we extracted 10 recipes with the top 10 STVs

as surprising recipes from each dish category.

In order to evaluate the validity of the extracted

surprising recipes, we conducted a questionnaire

survey. We presented the full text of the surprising

recipe in the questionnaire. The subjects were asked

to evaluate the text using a five-point Likert scale in

terms of the surprising value and proper value of

each surprising recipe. The surprising value

represents whether or not the recipe is surprising or

unusual from the subject’s perspective. The proper

value represents whether or not the recipe tastes

delicious to the subject. Furthermore, we asked the

subjects about their sex, age, and the usefulness of

the proposed method using a five-point Likert scale.

Table 1 represents the details of the questionnaire

regarding surprising value, proper value, and the

usefulness of the proposed method.

We divided the subject into two groups; one is a

group of specialists and the other is a group of non-

specialists. Specialists are those who have the

qualification of a chef or a dietitian. Non-specialists

could include anyone else. We collected the answers

of three specialists and 10 non-specialists about the

ground steak, answers from three specialists and 13

non-specialists about the pasta, and responses from

five specialists and 15 non-specialists regarding the

gratin. The sex ratio of male to female was 6:4 and

90 percent of the subjects were in their twenties.

Table 1: Details of the questionnaire about surprising

value, proper value, and the usefulness of the proposed

method.

4.2 Dataset

It is possible to extract surprising recipes using our

proposed method from Food.com, Allrecipes.com

and other similar sites, but in this paper, we used

data from COOKPAD (COOKPAD), which has the

highest number of Japanese users and recipes in

terms of user-generated recipe sites. We collected

data from 1,492,366 recipes and 12,826,094

ingredients from COOKPAD. We conducted

experiments on recipes for ground steak, pasta, and

gratin because in most recipes for ground steak and

gratin, relatively standard ingredients are typically

used, whereas in recipes for pasta, a wide range of

variation in seasoning and ingredients exists. All of

the researched dishes are very popular in Japan.

We extracted 12,327 recipes and 161,307

ingredients which contained the keyword “ground

steak” in a recipe title, 37,426 recipes and 371,797

ingredients that contained the keyword “pasta” in a

recipe title, and 14,056 recipes and 140,782

ingredients that contained the keyword “gratin” in a

recipe title. Next, we removed recipes that belonged

to other categories using the technique described in

3.1. After that, we extracted 11,645 recipes and

156,852 ingredients for ground steak, 35,593 recipes

and 367,837 ingredients about pasta, and 12,240

recipes and 122,995 ingredients related to gratin.

Then, we removed spelling variants and extra words

of ingredients using the technique described in 3.2.

4.3 Results

Table 3 represents the top 20 ingredients ranked by

surprising values that were obtained through our

proposed method. Cucumber and sweet potato are

found in the ground steak list, banana and konnyaku

for the pasta, and chocolate or kelp for the gratin.

These ingredients, which have high STVs, are not

thought to be traditionally used for making those

dishes. Table 4 represents the extracted surprising

surprising value proper value

usefulness of the

proposed method

5 very surprised

seems very

delicious

very useful

4 surprised seems delicious useful

3 neutral neutral neutral

2 unsurprised

seems

unappetizing

unuseful

1 very unsurprised

seems very

unappetizing

very unuseful

SurprisingRecipeExtractionbasedonRarityandGeneralityofIngredients

431

Table 3: Example about STV of ingredients.

recipes calculated by the STV of their ingredients.

We analyzed the results of the questionnaire. Table 5

represents the average of surprising measure value

(ASMV) and average of proper measure value

(APMV) about each dish. SMV of the recipe

represents the percentage of the persons who

selected “very surprised” or “surprised” from a five-

point Likert scale about the recipe. ASMV is

average of SMV of all recommended recipes (10

recipes). The same may be said of APMV.

ASMVs of non-specialists are higher than

ASMVs of specialists. That is because specialists

have more knowledge of the ingredients and dishes

than non-specialists and specialists are aware of

various cooking methods that use non-traditional or

surprising ingredients. Moreover, we can say that the

extracted recipes are useful because APMVs are 50

percent or more, and the maximum of APMV is

nearly 80 percent.

Figure 2 represents graphs of ASMVs of top x

recipes ranked by STVs. For example, Figure 2

represents ASMV of the top 5 recipes ranked by

STVs when x=5. From Figure 2, we know that SMV

tends to decrease with a decreasing STV. The graph

about the gratin is slightly different from the others,

but it shows the same result when x=4 or more.

Therefore, we can say that STV roughly correlates

with the SMV of the actual recipe.

Table 6 represents the percentage of the people

who selected “very useful” or “useful” for the

usefulness of the recommended recipes. More than

60 percent of subjects think that the recommended

recipes are useful, except for ground steak. Thus, we

can say that there would be a demand for our

proposed method of finding and extracting

surprising recipes from user-generated recipe sites.

5 DISCUSSION

First, we will discuss Table 5. Because specialists

have more knowledge of the various ingredients and

dishes than a non-specialist, we assumed that the

specialists would consider many recipes “not

surprising”. Thus, we suggest that we can extract

recipes that are well known for specialists but are

relatively unknown to non-specialists. Moreover, we

know from Table 5 that the evaluation results of

pasta are the lowest of the three. There are standard

ingredients for gratin, and recipes of gratin are

almost all similar to each other. The same is true for

ground steak. In contrast, there are various recipes

for pasta because there are many kinds of pasta

sauces and various uses of pasta itself. For this

reason, there is the possibility that many people

would not feel surprised at certain recipes, even if

she is recommended a recipe that she had never seen

before. Therefore, we think that the evaluation

rank ingredient name STV ingredient name STV ingredient name STV

1 bread flour 516 baking powder 1662 dry yeast 1711

2 baking powder 410 pancake mix 1406 cocoa 989

3 cucumber 247 vanilla 1144 baking powder 955

4 chicken leg 235 dry yeast 770 pancake mix 756

5 salt-free butter 212 banana 768 vinegar 603

6 fried tofu 209 cocoa 674 gelatin 583

7 fat-free milk 190 rice 437 cucumber 528

8 pasta 189 strawberry 336 chili oil 520

9 ham 169 chocolate 298 powdered gelatin 486

10 rice 143 coating of egg roll 293 kelp 484

11 fried oil 138 rice flour 253 sesame 369

12 sweet potapo 132 brown sugar lump 239 chocolate 355

13 apple 115 egg white 214 ginger 331

14 sausage 114 tempura flour 207 bean vermicelli 294

15 dried bonito 110 konnyaku 194 chocolate bar 293

16 cake flour 108 bread 191 chinese chive 285

17 chili bean sauce 108 scinnamon 191 pickled plum 268

18 plain yogurt 103 shortening 182 lettuce 267

19 seasoned cod roe 101 green powder 167 bread flour 257

20 cream cheese 99 dough 158 whole wheat flour 242

ground steak pasta gratin

ICAART2014-InternationalConferenceonAgentsandArtificialIntelligence

432

Table 4: Titles of extracted surprising recipes.

Table 5: The result of the questionnaire about the ASMV and APMV.

Table 6: The results of the questionnaire about the

usefulness of the proposed method.

resultof pasta is the lowest of the three. We suggest

that our proposed method is more effective to use for

dish categories that are commonly composed of

standard recipes.

In addition, as represented in Table 6, more than

60 percent of the subjects selected “very useful” or

“useful” for the recommended recipes, and more

than half of subjects answered that the proposed

method is useful. The ratio of answering “very

useful” or “useful” about recommended recipes of

ground steak is the lowest of the three, although the

ASMV of ground steak is higher than that of pasta.

This represents that usefulness is not dependent on

the ASMV of a recipe. As mentioned above, we

think that there are many restaurants that prepare

unusual ground steak, but there are fewer restaurants

that offer unusual pasta and gratin. Thus, we think

that the impression of a recipe being surprising for

ground steak is less than potentially surprising

recipes for pasta and gratin. We consider that if

surprising recipes of pasta and gratin exist, many

people would want to know them. For this reason,

we think that the usefulness of ground steak is the

lowest of the three.

Our proposed method extracts surprising recipes

by specifying the name of the dish category.

Therefore, we cannot use our proposed method

directly in a situation where an individual wants to

know a recipe that uses all the ingredients in the

refrigerator. Therefore, we think that the usefulness

may improve even further by proposing a method

that can extract a surprising recipe by specifying

names of ingredients, rather than by the name of the

dish category.

6 RELATED WORK

A great deal of research about the recipe of the dish

exists. The user has the taste of various ingredients,

so the user may not be satisfied if they are

recommended the same recipe. Then, a recipe

recommendation system that considers the taste of

rank ground steak pasta gratin

Good in summer. Ground steak of

yam and cucumber

Simple. Tropical curry soup pasta Ginger cream gratin of vegetables

Good in summer! Grated cucumber

ground steak

Pasta sauce. Rice gratin Vinegar potato gratin

A bite-size tofu ground steak. Chock

taste

Simple. Pasta dipped in rice flour gratin

of soft-boiled egg

Salt kelp yogurt! Healthy gratin of

fish

4 My favorite. Natto ground steak Isoflavone. Rice pasta

One material. Gratin of salt kelp and

radish

Magic powder!? Ground steak plump

anyone

Simple cream pasta with rice flour Egg gratin of spinach and kelp

Ground steak refreshing in

vegetables

To diet! Increased bulk pasta ultimate

Refreshing healthy gratin of chinese

cabbage and penne

Simple shotening of time lunch.

Cheese ground steak rice

Japanese-style rice flour pasta of

seasoned cod roe and maitake mashroom

Side dish gratin of avocado and salt

kelp

Ground steak. Japanese-style apple

sauce

Creamy tomato pasta Gratin of avocado and soybean curd

9 Soy pulp ground steak

Rice flour. Cream pasta of bok choy and

bacon

Texture of seaweed is a decisive

factor. Excellent gratin

10 Soybean plenty ground steak Scallop. Young sardines. Garlic pasta

Super easy! Potato gratin to make

with HM

ASMV APMV ASMV APMV ASMV APMV

non-specialist 0.62 0.62 0.55 0.78 0.81 0.75

specialist 0.23 0.67 0.17 0.57 0.60 0.74

ground steak pasta gratin



ground steak pasta gratin

non-specialist 0.70 0.85 0.87

specialist 0.33 0.67 0.80

SurprisingRecipeExtractionbasedonRarityandGeneralityofIngredients

433

(a) Ground steak (b) Pasta

Figure 2: ASMVs of top x recipes ranked by STVs.

an individual exists. Ueda et al. (Ueda, 2008)

calculated the score of each ingredient by using the

technique based on TF-IDF from the cooking history

of a user. They then calculated the score of the

recipe from the score of its ingredients. The high

score recipe was recommended as a suitable recipe

for a specific user. Moreover, Ueda et al. (Ueda,

2011) estimated the score of likes and dislikes about

various ingredients from the browsing history and

cooking history of a user. Then, they calculated the

score of the recipe from the score of its ingredients.

Furthermore, they set up a variable of time, so

recommendations for cooking similar recipes would

not happen every day. Moreover, Maruyama et al.

(Maruyama, 2012) recognized ingredients, through

image processing techniques, in images that site

users were taking on their mobile devices. The

system could then recommend a suitable recipe that

used the recognized ingredients.

These recipe recommendation systems that are

being considered do exist. Yajima et al. (Yajima,

2009) calculated the cooking difficulty of a recipe

from its ingredients, as well as the cooking processes

involved in the recipe by inputting ingredients,

seasoning, and personal taste of a user. Additionally,

a suitable recipe for the situation could be

recommended by inputting the schedule of a user.

Moreover, Akazawa et al. (Akazawa, 2012)

recommended recipes that could utilize the

ingredients in the refrigerator of a user by inputting

the quantity of the ingredients and their “best

before” date that were found in the user’s

refrigerator. They also calculated the leftover

quantity of the ingredients that were purchased,

which would remain after the necessary amounts of

ingredients were used for the recipe. In this way, the

user does not need to input all of the information the

next time.

A recommendation system that offers dietary

therapy support also exists (Kitamura,

2009)(Tagawa, 2013)(Youri, 2011)(Jill, 2010).

Tagawa et al. calculated the nutritional values of

recipes by making Linked Data from information

about the recipe and the Japanese standard

ingredient composition table. They obtained the

results of the nutrition calculation of the recipe by

0.0

0.2

0.4

0.6

0.8

1.0

14710

ASMV

ranktopx

non‐specialist

specialist

0.0

0.2

0.4

0.6

0.8

1.0

14710

ASMV

ranktopx

non‐specialist

specialist

0.0

0.2

0.4

0.6

0.8

1.0

14710

ASMV

ranktopx

non‐specialist

specialist

ICAART2014-InternationalConferenceonAgentsandArtificialIntelligence

434

comparing the name of the recipe to the same dish

name on the menu of the restaurant, then estimating

the nutritional facts about the menu of the restaurant.

In addition, the system distinguishes whether or not

a menu is a suitable menu in terms of nutritional

content by registering age, weight, and amount of

exercise of a user into the system. Moreover, Youri

et al. proposed the recommendation system for

healthy recipes. The system discriminates important

feature of the original recipe from its text, and

creates the feature vector, then calculates the

similarities between recipes. If the similar recipe has

a high health index, then the original recipe is

replaced by it.

Research about alternative ingredients in recipes

also exists. Karasawa et al. (Karasawa, 2004)

calculated the feature score of ingredients and the

cooking action of each recipe group by classifying

the recipes and using TF-IDF. They regarded the

ingredients that had a low feature score as general

ingredients. The system extracts the ingredients that

are normal and have a frequency of appearance in a

recipe group as ingredients that could substitute.

Moreover, Shidochi et al. (Shidochi, 2009) proposed

a system that extracts the ingredients and the

cooking action from each recipe text, and they

obtained the characteristic cooking action of each

ingredient by using TF-IDF. Furthermore, the

system creates the vector of the cooking action of

the ingredients, along with the characteristic cooking

action of the ingredients in the same dish category.

Then, the system extracts the ingredients that have

the vector of the cooking action with high cosine

similarity as the ingredients that can be substituted.

Moreover, Chun et al. (Chun, 2012) built a network

of ingredient complements and a network of

ingredient substitutes. They extract alternative

ingredients and remove ingredients used as options

by using both of their networks.

Fang et al. (Fang, 2012) proposed a system that

generates a menu (set of multiple recipes) for dinner,

as an example. The system calculates the similarity

between recipes from their ingredients. Moreover,

they obtained the co-occurrence relation of the

recipes from the site so a menu can be

recommended. Finally, the system generates a menu

that consists of a group of suitable recipes by

inputting the ingredients obtained by a user

In the field of information recommendation in

recent years, a system that recommends information

suited to the taste of the user has come under some

criticism, mainly because it has been argued that it

may not actually improve the satisfaction level of

the users. Instead, the element of surprise and

novelty about the information has attracted more

attention. (Murakami, 2008)(Yuan, 2012). However,

these systems recommend the information which is

of little interest to the user and never browsed by

using the user information. Therefore, it cannot be

used for our proposed method because their purpose

is different from our purpose.

As this section has made very clear, many

research studies about cooking recipes and

recommending culinary information exist. However,

there have not been any studies that focused on the

element of surprise about a recipe and its ingredient,

so the purpose and the techniques of the past studies

are different from our proposed method.

7 CONCLUSIONS AND FUTURE

WORK

In this paper, we proposed a method that extracts

surprising recipes from a dish category specified by

a user on user-generated recipe sites by using the

frequency of appearance of surprising ingredients.

We calculated the STV of each ingredient based

on RF-IIF, which is calculated from the rarity score

and the generality score of the ingredient. The rarity

score is the frequency of appearance of the

ingredient in the dish category, while the generality

score is the frequency of appearance of the

ingredient in all of the site’s recipes. Then, we

calculated the STV of each recipe based on the STV

of its ingredients, and extracted 10 surprising recipes

that had the top 10 highest STVs in three dish

categories ground steak, pasta, and gratin. In the

evaluation experiment, the subjects were requested

to make an evaluation about the surprising value and

the proper value of each surprising recipe. As a

result, we showed that 80 percent of the subjects

answered “seems very delicious” or “seems

delicious” about the extracted recipes, and more than

half considered the recipes to be surprising.

Moreover, we showed that our proposed method was

a valid method by showing that the STV, which is a

theoretical value of surprise, has a correlation with

SMV, which is the surprise value obtained from the

results of the questionnaires.

In any future work, we will improve the accuracy

of the surprising recipe extraction. In addition, we

will eliminate the redundancy of extracted recipes by

first calculating the similarity between recipes.

Furthermore, we will consider improvements to the

system that can extract surprising recipes by

specifying the ingredient names instead of

specifying a dish category name.

SurprisingRecipeExtractionbasedonRarityandGeneralityofIngredients

435

ACKNOWLEDGEMENTS

This research was subsidized by JSPS 24300005,

23500039, 25730038.

The authors would like to express their deepest

appreciation to the COOKPAD Inc., who provided

the recipe data of COOKPAD for us.

The authors would also like to express their

deepest appreciation to the entire staff of Professor

Honiden’s laboratory at the University of Tokyo and

Professor Fukazawa’s lab at Waseda University,

both of whom provided helpful comments and

suggestions.

REFERENCES

Young-J. C., 2012. Finding Food Entity Relationships

using User-generated Data in Recipe Service. In CIKM

2012. Proceedings of the 21st ACM international

conference on Information and knowledge

management.

Maarten C., Arjen P. de V., Marcel J. T. R., 2008.

Detecting Synonyms in Social Tagging Systems to

Improve Content Retrieval. In SIGIR 2008.

Proceedings of the 31st annual international ACM

SIGIR conference on Research and development in

information retrieval.

Jiaul H. P., 2013. A Novel TF-IDF Weighting Scheme for

Effective Ranking. In SIGIR 2013. Proceedings of the

36th international ACM SIGIR conference on

Research and development in information retrieval.

Luis F. S. T., Gabriel P. L., Rita A. R., 2012. An

Extensive Comparison of Metrics for Automatic

Extraction of Key Terms. In ICAART 2012.

Proceedings of the 4th International Conference on

Agents and Artificial Intelligence.

Senthil M., Rose C., Vibha S. S., Avinava D., 2012.

AUSUM: Approach for Unsupervised Bug Report

SUMmarization. In FSE 2012. Proceedings of the

ACM SIGSOFT 20th International Symposium on the

Foundations of Software Engineering.

“COOKPAD”. COOKPAD Inc.. http://cookpad.com.

Ueda M., Ishihara K., Hirano Y., Kajita S., Mase K., 2008.

Recipe Recommendation Method Based on Personal

Use History of Foodstuff to Reflect Personal

Preference. In Database Society of Japan Letters Vol.6

No.4, pp.29-32. (in Japanese).

Ueda M., Takahata M., Nakajima S., 2011. User’s Food

Preference Extraction for Personalized Cooking

Recipe Recommendation. In SPIM 2011. 2nd

Workshop on Semantic Personalized Information

Management: Retrieval and Recommendation.

Maruyama T., Kawano Y., Yanai K., 2012. Real-time

Mobile Recipe Recommendation System Using Food

Ingredient Recognition. In IMMPD 2012. Proceeding

of the 2nd ACM international workshop on Interactive

multimedia on mobile and portable devices.

Yajima A., Kobayashi I., 2009. “Easy” Cooking Recipe

Recommendation Considering User’s Conditions. In

WI-IAT 2009. Proceedings of The 2009

IEEE/WIC/ACM International Joint Conference on

Web Intelligence and Intelligent Agent Technology-

Volume03.

Akazawa Y., Miyamori H., 2012. Proposal of a Search

System for Cooking Recipes Considering Ingredients

in Refrigerators. In DEIM 2012. The 4th Forum on

Data Engineering and Information Management. (in

Japanese).

Kitamura K., Yamasaki T., Aizawa K., 2009. FoodLog:

capture, analysis and retrieval of personal food images

via web. In CEA 2009. Proceedings of the ACM

multimedia 2009 workshop on Multimedia for cooking

and eating activities.

Tagawa Y., Tanaka A., Minami Y., Namikawa D.,

Shimomura M., Ymaguchi T., 2013. Supporting Diet

Therapy Based on Japanese Linked Data. In JSAI

2013. The 27th Annual Conference of the Japanese

Society for Artificial Intelligence. (in Japanese).

Youri van P., Gijs G., Paul K., 2011. Deriving a Recipe

Similarity Measure for Recommending Healthful

Meals. In IUI 2011. Proceedings of the 16th

international conference on Intelligent user interfaces.

Jill F., Shlomo B., 2010. Intelligent Food Planning:

Personalized Recipe Recommendation. In IUI 2010.

Proceedings of the 15th international conference on

Intelligent user interfaces.

Karasawa T., Hamada R., Ide I., Sakai S., Tanaka H.,

2004. Extraction of Knowledge about the Material and

Recipe from Cooking Teaching Materials Text. In

IPSJ 2004. The 66th Annual Conference of the

Information Processing Society of Japan. (in

Japanese).

Shidochi Y., Takahashi T., Ide I., Murase H., 2009.

Finding Replaceable Materials in Cooking Recipe

Texts Considering Characteristic Cooking Actions. In

CEA 2009. Proceedings of the ACM multimedia 2009

workshop on Multimedia for cooking and eating

activities.

Chun-Y. T., Yu-R. L., Lada A. A., 2012. Recipe

recommendation using ingredient networks. In WebSci

2012. Proceedings of the 3rd Annual ACM Web

Science Conference.

Fang-Fei K., Cheng-Te L., Man-Kwan S., Suh-Yin L.,

2012. Intelligent menu planning: recommending set of

recipes by ingredients. CEA 2012. Proceedings of the

ACM multimedia 2012 workshop on Multimedia for

cooking and eating activities.

Murakami T., Mori K., Orihara R., 2008. Metrics for

Evaluating the Serendipity of Recommendation Lists.

In JSAI 2007. Proceedings of the 2007 conference on

New frontiers in artificial intelligence.

Yuan C. Z., Diarmuid O S., Danele Q., Tamas J., 2012.

Auralist: Intoducing Serendipity into Music

Recommendation. In WSDM 2012. Proceedings of the

fifth ACM international conference on Web search and

data mining.

ICAART2014-InternationalConferenceonAgentsandArtificialIntelligence

436
