Key Features for a Successful Model-Driven Development Tool

Beatriz Marín

, Andrés Salinas

, Juan Morandé

, Giovanni Giachetti

and Jose de la Vara

Facultad de Ingeniería, Universidad Diego Portales, Av. Ejército 441, Santiago, Chile

Facultad de Ingeniería, Universidad Andres Bello, Sazié 2325, Santiago, Chile

Certus Centre for Software V&V, Simula Research Laboratory, P.O.Box 134, 1325 Lysaker, Norway

Keywords: Model-Driven Development (MDD), Tools, MDA, Features.

Abstract: The main focus of Software Engineering discipline is to establishing methods and processes for the effective

and efficient development of software projects. One of the most relevant paradigms for achieving this goal

is Model-Driven Development (MDD). MDD uses models at different abstraction levels to automatically

generate software products by means of model-transformations. However, one of the main issues related to

the development of MDD technologies is the lack of standardization in terms of the features that need to be

considered to support the current industry needs. This difficults the comparison of existing technologies

since there are not a reference point for the creation of new MDD approaches with their corresponding

supporting tools. This paper analyses these industry needs through an exploratory study. From the results

obtained, it states the main features that must be supported by MDD tools. In addition, this paper presents an

analysis about the presence or absence of these features in a set of industrial MDD tools.

1 INTRODUCTION

The goal of Software Engineering is to establishing

methods and processes for the effective and efficient

development of software projects (Kitchenham and

Pfleeger, 1996). The Model-Driven Development

paradigm (Selic, 2003) has become into a relevant

mean for achieving this purpose at both, industry

and academic domains.

MDD approaches use models at different

abstraction levels that are independent of technical

platforms to generate different kinds of software

products by means of model transformations (such

as code, documentation, new modeling artifacts,

etc.). Thus, a correct model specification is essential

to automatically generate a complete software

solution without programming a single line of code.

In this context, the MDD paradigm is moving the

software development processes to a different

dimension, from the solution space (software

product) to the problem space (conceptual models).

In this journey, the success of adopting MDD

solutions is in direct relation with the capability of

the available tools to satisfying the needs of the

different development projects.

However, even though there exists an important

amount of MDD tools in the software industry

(Marín et al., 2013), there is a lack of references that

state the key aspects that need to be considered for

selecting (or developing) a MDD tool properly

aligned with industrial MDD processes.

In this context, this paper presents a twofold

contribution: (1) this paper presents and analyses a

set of key features that an MDD tool must have to be

successfully adopted in industry software

developments; and (2) the paper also presents which

of these key features are currently taken into account

by considering a set of existing MDD tools.

The rest of the paper is organized as follows:

Section 2 presents some relevant related work.

Section 3 presents an exploratory study. Section 4

presents the key features. Section 4 presents an

analysis of these features in relation to a set of MDD

tools that are currently available. Finally, Section 5

presents some conclusions and further work.

2 RELATED WORK

Bran Selic in (Selic, 2003) proposes the following

success criteria for the development MDD tools by

considering his experience in the development of the

IBM Rational Software.

Standards. The use of standards is essential to

541

Marín B., Salinas A., Morandé J., Giachetti G. and De la Vara J..

Key Features for a Successful Model-Driven Development Tool.

DOI: 10.5220/0004723705410548

In Proceedings of the 2nd International Conference on Model-Driven Engineering and Software Development (MODELSWARD-2014), pages 541-548

ISBN: 978-989-758-007-9

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

spread the adoption of new technologies and reduce

the learning curve related to the application of MDD

software production processes. In this context, the

Model-Driven Architecture (MDA) proposed by

OMG is probably the most referenced

implementation schema for MDD tools.

Observability and executability of the model. The

observability refers to the integration of comparing

tools that helps in the identification of model’s

versions. The executability refers to the capacity to

execute the models in early stages of software

development, providing a learning ability though

experimentation.

Efficiency of the generated code. The efficiency of

the generated code can be decomposed in

performance and use of memory. In addition, it is

also important taking into account the size of the

generated system and the compilation time of the

models.

Furthermore, Richard Paige and Dániel Varró in

(Paige and Varró, 2012) presents the knowledge

obtained during the development of two tools:

Epsilon (Epsilon, 2010) and VIATRA2 (Balogh and

Varró, 2006), which is briefly analysed below.

Use of requirement models for driving the

development process. The use of requirement

models in MDD processes help to motivate and

thread the development complexity, i.e.; it drives the

construction in terms of development iterations.

Flexibility of architectures and modeling tools. At

the beginning, it is promoted the flexibility of

architectures instead of the selection of the correct

architecture. Having a flexible architecture it is

possible to adapt the generation of the final software

products to different architectural patterns in

accordance to the needs of the development project.

Modeling technologies. Modeling technologies

refers to the methods used to represent the models,

for instance EMF model representation. The

selection of the modeling technology significantly

affects in the usability and flexibility of the

modeling tool in terms of the implementation of

model transformations, typing of model elements,

etc. In addition, the final user do not necessarily

must to know how the representation of models is

implemented; final users just need to know the

graphical representation of models in order to avoid

complexity of the modeling technology.

Summarizing, the works analyzed consider

specific views of the development of MDD tools by

introducing some desirable features. However, these

features are not validated in industrial contexts. To

tackle this situation, we perform an exploratory

study in order to discover the relevant features that

an MDD tool must have.

3 EXPLORATORY STUDY

The exploratory study consists in an online

questionnaire of 19 questions. These questions have

been defined by considering strong and weak points

of previous works analyzed. Moreover, the model

verification and interoperability criteria were added

to the study.

The model verification is a relevant feature in

MDD tools since this assures that all the model

information can be transformed into the

corresponding software artifacts (syntactic

verification) and the final software product is

properly aligned with the users’ requirements

(semantic verification).

The model interoperability is a key feature to

facilitate (and automate) the interchange of

modeling information among tools related to a same

domain (e.g. interoperability among different UML

tools), as well as the interoperability among different

modeling approaches (e.g. for bridging requirement

and design modeling approaches).

Table 1 shows the questions and the related

feature of the questionnaire. Each question was

answered by using a 5-point Likert scale. To obtain

qualitative aspects related to each question, an open

text box that can be filled with open answers was

placed.

The estimated time to response was specified in

15 minutes. In order to present the questions in an

attractive way, different icons that represent the

values of the Likert scale were used (from totally

disagree represented by 1 to totally agree

represented by 5). The questionnaire can be seen at

https://testmodeproject.typeform.com/to/eUhWIU.

Four relevant tool vendors response the online

questionnaire and automatically the answers were

sent to the authors. Collected answers were located

in a table to further analysis (see Table 2). In Table

2, the column Id represents the number of the

question, and TV1 to TV4 represents the tool

vendors that response the questionnaire.

MODELSWARD2014-InternationalConferenceonModel-DrivenEngineeringandSoftwareDevelopment

542

Table 1: Questions and related features of the questionnaire.

Id Question Feature

Q1 The MDD tool must support the standard UML. Standarization

Q2 The MDD tool must support MDA in terms of CIM, PIM, PSM Standarization

Q3 The MDD tool must provide extension mechanisms for modeling languages customization to

allow the communication with different tools?

Interoperability

Q4 The MDD tool must provide extension mechanisms that allow the

communication/interoperability with different tools

Interoperability

Q5 It is necessary to have a graphical visualization of a model. Observability

Q6 It is necessary to have a version manager of models. Observability

Q7 It is necessary to have easy human interaction (such as touch screens) to work with models. Efficiency

Q8 The MDD tool must provide verification mechanisms of the models Verification

Q9 The MDD tool must provide automatic defect detection for the models Verification

Q10 The MDD tool must provide automatic test case generation of the models Verification

Q11 The MDD tool must provide simulations of the executability of the model Executability

Q12 The MDD tool must allow redefinitions of the transformation of the models Flexibility

Q13 The generated code of an MDD tool must have the same efficiency than the code generated

with traditional programming

Flexibility

Q14 The MDD tool must allow the selection of different architectural patterns to generate code Flexibility

Q15 The MDD tool must be able to generate code reviews Code Generation

Q16 The MDD tool must generate at least the skeleton of the code Code Generation

Q17 The MDD tool must generate totally executable code Code Generation

Q18 The MDD tool must support the specification of all views of a system Requirements

Q19 The MDD tool must save the traceability from requirements to code Requirements

4 FEATURES FOR MDD TOOLS

This section presents a set of features that any MDD

tool designed to work in industrial projects should

offer. At this point, it is important to note that (1) the

main input of MDD tools is a conceptual model that

is independent from the development platform used,

and (2) the MDD tool must be able to generate code

through the model specified.

4.1 Standardization

and Interoperability

Since its inception, the Object Management Group

(OMG) has promoted the standardization of

different model-based and object-oriented

approaches for software development. In this

context, the main exponent of OMG standards is

UML (OMG, 2010). Other standard defined by

OMG is Model-Driven Architecture (MDA) (OMG,

2003), which provides a standard architecture to

support MDD developments.

Table 2: Results of the questionnaire.

Id TV1 TV2 TV3 TV4 Id TV1 TV2 TV3 TV4

Q1 5 3 3 5 Q11 4 5 3 3

Q2 4 4 2 2 Q12 5 2 1 3

Q3 5 5 5 2 Q13 1 1 3 4

Q4 4 3 5 4 Q14 4 4 3 5

Q5 4 5 3 4 Q15 2 3 3 3

Q6 2 1 5 5 Q16 5 5 4 5

Q7 3 1 4 5 Q17 1 5 3 3

Q8 4 5 4 5 Q18 4 3 3 2

Q9 4 2 2 4 Q19 5 5 4 3

Q10 4 5 1 3

Standardization promotes significant progress in the

development of a MDD tool, allowing to establish

an agreement of good practices that facilitate the

reuse and interoperability among different tools and

modelling approaches, for example by using XMI

(OMG, 2007b).

KeyFeaturesforaSuccessfulModel-DrivenDevelopmentTool

543

Standardization also promotes specialization of

tools in specific domains, leading the development

of tools with more concrete and sophisticated

features according to different application contexts.

Results of the exploratory study shows that 50%

of the subjects are totally agree about the MDD tool

must support the standard UML, and the other 50%

answers are neutral about this question. For Q2, 50%

of subjects are not agree regarding if it is necessary

that MDD tools support the MDA architecture in

terms of CIM, PIM, and PSM; and the other 50% of

the subjects are agree with this question.

Regarding the interoperability, the exploratory

study shows that 75% of subjects are totally agree

with the affirmation of the MDD tool must provide

extension mechanisms for modeling languages

customization. Regarding Q4, 75% of the subjects

state that MDD tool must provide extension

mechanisms that allow the communication or

interoperability with different tools.

4.2 Visualization and Management

of Models

Due to the main input artifact in a MDD approach is

a model, which specifies all the views that allow the

complete representation of a system, it is essential

that an MDD tool provides a suitable set of

management and visualization features for models

definition.

The minimum feature to be considered is the

possibility of visualizing the models at design time.

In particular, it is necessary to provide a graphical

interface that facilitates the management of multiple

views that are normally used for a system model

specification. The exploratory study shows that 75%

of the subjects state that it is absolutely necessary to

have a graphical visualization of the model.

However, to appreciate graphically the model is

not the only concern related to visualization that

should taking into account when an MDD tool is

built. Nowadays, more than ever, it is necessary to

provide user interfaces that take into account quality

characteristics such as usability (ISO/IEC, 2001);

and new characteristics of hardware devices, such as

touch panels in desktop and laptop computers

(Garber, 2012). In the exploratory study we found

that 50% of subjects agree to have an easy human

interaction to work with models, and the other 50%

answer that it is not necessary.

Regarding versioning of the models, the

exploratory study shows that 50% of the subjects

state that it is absolutely necessary to manage the

versioning of the models. This is the only way to

work in collaborative industrial projects, where

different members of a development team can work

over the same models. However, the remaining 50%

of subjects response that it is not mandatory to have

a version manager, but it is a desirable feature.

4.3 Verification

In MDD, the modeling language assumes the role of

an implementation language due to it achieves a

complete and automatic code generation; i.e., the

model becomes the new programming code. In this

context, the generated code becomes into a black

box, rarely reviewed, as is rarely reviewed the

machine code generated by a programming language

compiler, because this generation is performed using

widely accepted standards in the industry.

Thus, the verification of the model should be a

mandatory feature of an industrial MDD tool. 100%

of subjects response in the exploratory study that the

MDD tools must provide verification mechanisms.

This means using the MDD tool to find the presence

of desirable characteristics and the absence of

undesirable characteristics.

Regarding to the absence of undesirable

characteristics, different researchers have applied

reading techniques or heuristics to identify defects in

UML models, such as (Travassos et al., 1999),

(Conradi et al., 2003), (Lange and Chaudron, 2004),

(Egyed, 2006). Reading the question if it is

necessary that the MDD tool provides automatic

defect detection of the models, the exploratory study

reveals that it is desirable, but with a desactivation

possibility because some defects depends on the

methodology selected in the project; i.e. it should be

good to plug custom defect detection mechanisms to

supporting architects’ needs.

4.4 Testing

Even though there exist several defect detection

techniques proposed by the academia, the most

important and most frequently used quality

assurance technique applied in industry is testing.

Usually, testing of software systems take up to more

than 50% of development cost and time (Vos et al.,

2010). For this reason, it is very important to

perform the testing as early as possible in order to

diminish this high cost. Despite there are several

tools and methods for testing planning and control,

and test case execution and monitoring, there still

are a limited amount of approaches for test case

design, selection of test data, and test evaluation.

To perform testing of models, there are several

MODELSWARD2014-InternationalConferenceonModel-DrivenEngineeringandSoftwareDevelopment

544

researchers who have applied model-based testing to

generate test cases (Dias Neto et al., 2007). These

approaches usually create a state transition model to

represent the current state of a system and the next

state, specifying the events that occur to change the

state. In these models, test designs are focused on

paths of the execution of the events. However, state

transition models only provide a partial view of the

final software system (behavioural view). Thus, after

the application of test cases generated from these

models, it is necessary to manually testing the

remaining functionality of the system. In order to

reduce the human effort doing testing, MDD tools

must provide model-based testing approaches that

will be focus in holistic models.

Regarding testing, the exploratory study shows

that 50% of the subjects answer that the MDD tool

must provide automatic test case generation from

models, and the other 50% answer that it could be

good, but it is not essential.

4.5 Code Generation and Simulation

The MDD tool must generate at least the skeleton of

the code. The exploratory study supports this

asseveration with 75% of full agreement and 25% of

agreement.

Supporting technologies for automating the

model-based operations, such as, model

transformations, model validation and verification,

generation of software products (model

compilation), are essential to achieve the benefits of

MDD. In this context, level of generation facilities

that a MDD tool provides is of paramount

importance. Depending of the tools, the code

generation can go from the skeleton or code

fragments to the generation of the complete software

products. Nevertheless, the exploratory study shows

that only 25% of the subjects agreed with the fact

that an MDD tool must generate totally executable

code. 50% of subjects state that in some cases the

total code generation is adequate, arguing that the

model that generates the complete executable code

has the same complexity than the code generated.

Regarding simulation, MDD tools should allow

the execution of models even though they are

incomplete (but valid). The main idea is not to wait

until the model is finished to see how it looks like

the software obtained from the part of the model that

is already specified. This allows the correction of the

model specification as early as possible. The

exploratory study shows that 50% of the subjects

agree in that the MDD tools must generate

simulations of the models defined.

4.6 Transformation

The transformation of a model corresponds to a set

of rules and activities such as refactoring, reverse

engineering, application of patterns, among others.

Transformations take one or more models as input,

and by applying the rules specified, generate one or

more output models, including the code of the final

software product (implementation model).

A suitable MDD tool must offer a number of

predefined transformations for assuring a complete

model transformation. However, features oriented to

define or customize the transformation rules

implemented by an MDD tool are supported by 25%

of the subjects in the exploratory study.

4.7 Efficiency and Scalability

MDD tools should significantly reduce time and

efforts, and simplify the development of final

software products. The productivity gained by using

MDD tools can be significant when the code

generated is quite equivalent in terms of efficiency

and scalability to the code manually generated.

Various attempts have been performed in this

direction. One prominent effort was computer-aided

software engineering (CASE) in the beginning of

80s, which focused on developing software methods

and tools that enabled developers to express their

designs in terms of general-purpose graphical

programming representations, such as state

machines, structure diagrams, and dataflow

diagrams (Schmidt, 2006). However, CASE tools

were not successful in industry due to its inability to

handle complex, production-scale systems in a broad

range of application domains (Schmidt, 2006).

A relevant efficiency measure that can be

considered when evaluating a MDD tool is related to

the performance in terms of the volume of

information handled, and the amount of memory

used. Is expected that the automatically generated

code efficiency has a deviation not greater than 10%

compared to manually created code (Selic, 2003).

One way of evaluating this would be comparing the

amount of generated code lines between tools and

their equivalent constructed by hand. A more

appropriate way to evaluate this would be comparing

the functional size measurement of both

applications. For measuring the functional size of

conceptual models it is possible to apply IFPUG

measurement standards (ISO/IEC, 2003) and

COSMIC (ISO/IEC, 2011), by applying, for

example, the procedure presented in (Marín et al.,

2010).

KeyFeaturesforaSuccessfulModel-DrivenDevelopmentTool

545

Results of the exploratory study reveals that

efficiency in the generated code is not a relevant

feature taking into account the increase in the

productivity of MDD projects.

4.8 Architectures and Maintenance

Since, MDD tools work with platform independent

models; the tool must support the transformation to

executable code not only to a variety of languages,

but also to different architecture design patterns. For

example, if you want to generate in a particular

programming language, the MDD tool may allow

the selection between a client-server architecture

(Berson, 1996) or model view controller (MVC)

architecture (Reenskaug, 2003). The exploratory

study reveals that 75% of the subjects agree that the

MDD tool must allow the selection of different

architectural patterns to generate code.

Regarding the generation of code reviews, 75%

of the subjects are neutral about the ability of MDD

tools to perform partial generation of code from

model changes; i.e., it is not necessary to recompile

the whole model if a small change is performed. We

state that this would facilitate the maintenance of the

system to small changes or corrections that may

exist during the lifetime of the software created.

4.9 Requirements

Even though there exist standards for requirements

documentation (such as IEEE 830 (IEEE, 1984)), the

requirements elicitation phase is the less technical by

nature. However, it is desirable that the MDD tool

supports the traceability from requirement

specification to the other views of the system.

The exploratory study shows a 75% of subjects

agreed regarding traceability of MDD tools. The

remaining 25% answer that it depends on the usage

of the tool.

5 GENERAL ANALYSIS

This section presents a general analysis of the

features that existing tools have. To do this analysis,

a list of products that are compliant with the MDA

approach were considered (OMG).

There are 48 MDA tools recognized by OMG

(OMG). However, many of these tools are not

longer available are not updated for more than one

year. From the 48 MDA tools, only 10

(corresponding to 21%) are currently in use and

have active support. The remaining 79% were

deprecated or acquired by a larger company.

The 10 available tools provide support for

different domains, such as real-time or management

information systems (MIS). We focus the analysis in

MDD tools of the management information systems

since it is broadly used in industry. Thus, just three

tools were taking into account in the analysis.

In order to make a more representative analysis,

open-source tools that are not included in the OMG

site were also included. Therefore, to complement

the analysis, five open-source tools were added.

Thus, eight MDD tools were finally analyzed.

First, a characterization of the selected tools was

performed regarding the modeling language used,

the system views covered by the tool, the language

for the specification of the functional view, and the

software product generated (see Table 3).

As Table 3 shows, seven tools support UML

Table 3: Characterization of MDD tools analyzed.

MDD tool

Modeling

Language

System Views

Functional

View Language

Products Generated

AndroMD

UML by using

MagicDraw

Structural and Dynamic Views - Structure of the system

OpenMDX UML - POJO -

Acceleo

UML2 by using

EMF

Structura, Dynamic, and

Functional Views

OCL Code Skeleton.

TopCased

UML2 by using

EMF

Structura, Dynamic, and

Functional Views

OCL

Code Skeleton. Documentation. Allows

complete code generation by using plugins.

StarUML UML 2.0

Structura, Dynamic, and

Functional Views

Code Skeleton and requirements and

implementation documents

Integranov

OO-Method

Structural, Dynamic, Functional,

and Presentation Views

OASIS

Complete fully working generation code.

Documentation. Fucntional size Measurement.

IBM

Rational

Rose

UML2.1 Structural and Dynamic Views OCL Complete fully working generation code

Blu Age UML 2.1

Structural, Dynamic, Functional,

and Presentation Views

OCL Complete fully working generation code

MODELSWARD2014-InternationalConferenceonModel-DrivenEngineeringandSoftwareDevelopment

546

(OMG, 2007a) (OMG, 2010) and one tool support

OO-Method (Pastor et al., 2001) as modeling

language. UML is the standard the facto to be used

in industry, and OO-Method starts from the UML

class diagram and adds semantic information to

allow the generation of fully-executable code. Using

UML or UML-based modeling languages reduces

the learning curve of the tool and facilitates the

integration with different project management tools.

In order to avoid or diminish defects and faults

of the generated applications, it is very important

that the MDD tool provides support to the holistic

representation of a system in a conceptual manner,

which includes the static, dynamic, functional, and

presentation views. More details of these views can

be found in (Marín et al., 2013). From the eight tools

analyzed: one tools does not detail the different

views supported; two tools support the structural and

the dynamic views; four tools support the structural,

dynamic and functional views; and only two tools

supports structural, dynamic, functional, and

presentation views.

Regarding the language for the specification of

system functionality, four tools uses OCL (OMG,

2006), one tool uses OASIS (Pastor et al., 1992), and

one tool uses Plain Old Java Objects (POJO).

Regarding the product generated, one tool does

not specify the final product generated, four tools

generate the skeleton of code, and just three tools

generate the code completely.

An analysis performed to the features established

in Section 3 shows that regarding to standardization,

most of the tools use the UML modeling language.

Only one tool does not support UML, but it supports

an extension of UML called OO-Method. However,

not all the tools support the same version of UML,

which will alleviates the exportation of the models

to other supported formats and promotes the

interoperability of tools.

Regarding the visualization of the models, the

analyzed tools provide graphical visualization or

connections with graphical tools (such as

MagicDraw or Eclipse EMF). However, there not

exist tools that take advantage of new interaction

features that could increase the productivity of

software engineers.

Regarding the verification of the model, some

tools offer verification of syntactical defects in the

models and verification of the consistency of the

different views supported. Nevertheless, it is also

necessary that MDD tools offer verification of

semantic defects in order to prevent faults when the

generated system is executed.

Regarding testing and simulation of the models,

analyzed MDD tools do not offer options to generate

tests or simulation artifacts in order to properly

validate the models, rather than testing the code once

the system is generated.

Regarding the transformation, even though the

tools analyzed offer refactoring and reverse

engineering features, they do not provide facilities to

customize transformations in particular situations.

With respect to efficiency and architecture,

commercial tools such as Rational or Integranova

can export to a number of different architectures, but

at open-source tools this option is available. In

addition, none of the eight tools provides support to

code optimization.

Finally, with respect to requirements traceability,

the tools analyzed do no provide mechanisms to

keep the traceability from requirements to code.

6 CONCLUSIONS

This paper presents a set of features that an MDD

tool should have for successful application and

adoption of the Model-Driven Development

paradigm in industry. An exploratory study was

performed to validate this set of key features for

MDD tools.

In addition, an analysis of available MDD tools

has been presented to evaluate the adoption of

existing tools regarding the features proposed. To

perform this analysis, the current OMG catalogue of

tools was considered. However, almost the 80% of

these tools are deprecated, which dramatically

reduce the set of MDD tool that met with the

features proposed and are aligned with the needs of

software development projects.

The remaining tools in the OMGs list have

reached a level of maturity in which it is possible to

generate solutions from a model, however, none of

these tools support all the features presented in this

paper. Thus, an interesting challenge is to

collaborate with the existing MDD tool providers to

analyze in deep the features proposed and to develop

a tool (or a suite of tools) that be aligned with all

these features.

This work is part of a research agenda that aims

to develop MDD tool for systems in the domain of

information systems management. In addition, this

agenda also include the development of techniques

to semantically verify the models and generate test

cases automatically from conceptual models, and

empirical studies that validate these techniques.

KeyFeaturesforaSuccessfulModel-DrivenDevelopmentTool

547

ACKNOWLEDGEMENTS

This work was funded by FONDECYT project

TESTMODE (Ref. 11121395, 2012-2015).

REFERENCES

Balogh, A. & Varró, D. 2006. Advanced Model

Transformation Language Constructs in the VIATRA2

Framework. ACM Symposium on Applied Computing

– Model Transformation Track (SAC 2006). Dijon:

ACM Press.

Berson, A. 1996. Client/server architecture, McGraw-Hill.

Conradi, R., Mohagheghi, P., Arif, T., Hegde, L. C.,

Bunde, G. A. & Pedersen, A. 2003. Object-Oriented

Reading Techniques for Inspection of UML Models –

An Industrial Experiment. 17th ECOOP. Springer.

Dias Neto, A. C., Subramanyan, R., Vieira, M. &

Travassos, G. H. 2007. A survey on model-based

testing approaches: a systematic review. 1st ACM

international workshop on Empirical assessment of

software engineering languages and technologies

(WEASELTech '07). NY, USA: ACM.

Egyed, A. 2006. Instant Consistency Checking for the

UML. 28th ICSE. Shangai, China: ACM.

Epsilon. 2010. http://www.eclipse.org/gmt/epsilon

(Online).

Garber, L. 2012. Tangible User Interfaces: Technology

You Can Touch. IEEE Computer, 45, 15-18.

IEEE 1984. IEEE 830 Guide to Software Requirements

Specifications.

ISO/IEC 2001. ISO/IEC 9126-1, Software Eng. – Product

Quality – Part 1: Quality model.

ISO/IEC 2003. ISO/IEC 20926, Software Engineering –

IFPUG 4.1 Unadjusted Functional Size Measurement

Method – Counting Practices Manual.

ISO/IEC 2011. ISO/IEC 19761, Software Engineering –

COSMIC – A Functional Size Measurement Method.

Kitchenham, B. & Pfleeger, S. 1996. Software Quality:

The Elusive Target. IEEE Software, 13, 12-21.

Lange, C. & Chaudron, M. 2004. An Empirical

Assessment of Completeness in UML Designs. 8th

Conf. on Empirical Assessment in Software Eng.

(EASE). IEEE.

Marín, B., Pastor, O. & Abran, A. 2010. Towards an

accurate functional size measurement procedure for

conceptual models in an MDA environment. Data &

Knowledge Engineering, 69, 472–490.

Marín, B., Pereira, J., Giachetti, G., Hermosilla, F. &

Serral, E. 2013. A General Framework for the

Development of MDD Projects. 1st International

Conference on Model-Driven Engineering and

Software Development - MODELSWARD 2013.

Barcelona - Spain: SciTePress.

OMG. MDA Products and Companies [Online].

Available: http://www.omg.org/mda/committed-

products.htm.

OMG 2003. MDA Guide Version 1.0.1. In: JOAQUIN

MILLER & MUKERJI, J. (eds.).

OMG 2006. Object Constraint Language 2.0

Specification.

OMG 2007a. UML 2.1.2 Infrastructure Specification.

OMG 2007b. XMI 2.1.1 Specification.

OMG 2010. UML 2.3 Superstructure Specification.

Paige, R. F. & Varró, D. 2012. Lessons learned from

building model-driven development tools. Software &

Systems Modeling, 11, 527-539.

Pastor, O., Gómez, J., Insfrán, E. & Pelechano, V. 2001.

The OO-Method Approach for Information Systems

Modelling: From Object-Oriented Conceptual

Modeling to Automated Programming. Information

Systems, 26, 507–534.

Pastor, O., Hayes, F. & Bear, S. 1992. OASIS: An Object-

Oriented Specification Language. Int. Conference on

Advanced Information Systems Engineering (CAiSE).

Manchester, UK.

Reenskaug, T. 2003. The Model-View-Controller (MVC),

Its Past and Present. University of Oslo.

Schmidt, D. 2006. Model Driven Engineering. IEEE

Computer, 39, 25-31.

Selic, B. 2003. The Pragmatics of Model-Driven

Development. IEEE Software, 20, 19–25.

Travassos, G., Shull, F., Fredericks, M. & Basili, V. 1999.

Detecting Defects in Object-Oriented Designs: Using

Reading Techniques to Increase Software Quality.

OOPSLA' 99. Denver, CO, USA.

Vos, T. E., Baars, A. I., Lindlar, F., Kruse, P. M.,

Windisch, A. & Weneger, J. 2010. Industrial Scaled

Automated Structural Testing with the Evolutionary

Testing Tool. Third International Conference on

Software Testing, Verification and Validation (ICST).

IEEE Computer Society.

MODELSWARD2014-InternationalConferenceonModel-DrivenEngineeringandSoftwareDevelopment

548
