HIP_IKEv2: A Proposal to Improve Internet Key Exchange

Protocol-based on Host Identity Protocol

S. Smaoui

, F. Zarai

, M. S. Obaidat

, K. F. Hsiao

and L. Kamoun

LETI laboratory, University of Sfax, Sfax, Tunisia

Computer Science and Software Engineering Department, Monmouth University, West Long Branch, NJ 07764, U.S.A.

Dep. of Information Management, Ming-Chuan University, Taoyuan County 333, Taiwan

Keywords: IP Security, Simulation Analysis, Internet Key Exchange Version2, Host Identity Protocol, AVISPA,

SPAN.

Abstract: IKEv2 offers authentication, authorization and key agreement services to establish a security association

between two peers bound to IP addresses, but it is still vulnerable to some security problems such as denial

of service (Dos) and man-in-the-middle attack. Host Identity Protocol (HIP) is also a security protocol that

defines host identifiers for naming the endpoints and performs authentication and creation of IPsec security

associations between them bound to identifiers. The purpose of HIP is to support trust systems, enhance

mobility and greatly reduce the Denial of Service (Dos) attacks. We focus on an extension to IKEv2 in order

to enhance authentication, eliminate man-in-the-middle attack and guarantee denial of service to provide

better security between the two peers. In this paper, we describe our proposal that consists of combining the

IKEv2 with the HIP to set up a security association based on two parameters which are location and

Identity. This combination can provide better security properties than each protocol used alone. This

scheme, named (HIP_IKEv2) couples location and identity to define a security association between two

peers. We have used the Automated Validation of Internet Security Protocols and Applications (AVISPA)

and its Security Protocol Animator (SPAN), and two powerful automated tools in order to formally specify

and validate the HIP_IKEv2 protocol.

1 INTRODUCTION

With the development of wireless communication

systems, the needs for security are increasingly

become more important than ever before because

these systems present a set of challenges which are

distinct from those of wired based systems. A

successful security strategy in wireless networks

implies new needs such as, authentication of the

entities, integrity of the exchanged messages,

confidentiality of the transaction, and anonymity of

the certificate owner.

Before explaining the necessary security

mechanisms, it is important to enumerate some

possible attacks techniques like eavesdropping,

impersonation, man-in-the-middle, replay and denial

of service attacks (Gurtov, 2008).

In order to tackle these attacks, a preventive

mechanism is needed. Hence, it is desired to use

cryptography in communication between users and

different nodes in the network. In this context many

protocols have been designed to assure security

services such as authentication, authorization,

accountability, data integrity, confidentiality, non-

repudiation and privacy. Since the aim is to create

security services at the network layer and since

IPSec protocol is used to protect mobile Internet

protocol version6 (MIPv6) data and signals, we

choose to benefit from it to establish a security

tunnel between two peers.

With IPSec both communication endpoints must

agree on a set of algorithms and keys to achieve a

secure connection (Gurtov, 2008). To establish a

shared state, hosts can employ two different

protocols which are the Internet Key Exchange

IKEv2 (Kaufman et al., 2010) and the Host Identity

Protocol (HIP) (Henderson and Gurtov, 2012). The

shared security context is called a Security

Association (SA).

SA is a central concept in IPSec that supports

encryption, authentication, or both. They are

unidirectional, so in order to protect a duplex

404

Smaoui S., Zarai F., S. Obaidat M., F. Hsiao K. and Kamoun L..

HIP_IKEv2: A Proposal to Improve Internet Key Exchange Protocol-based on Host Identity Protocol.

DOI: 10.5220/0004630804040411

In Proceedings of the 3rd International Conference on Simulation and Modeling Methodologies, Technologies and Applications (SIMULTECH-2013),

pages 404-411

ISBN: 978-989-8565-69-3

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

channel two SAs are necessary (an incoming and an

outgoing one).

The IKEv2 exchange is designed to establish and

manage SA in four messages. In the two first one,

called IKE_SA_INIT, the communicating entities

negotiate cryptographic algorithms, exchange nonce

and make Diffie-Hellman exchange to obtain a

shared key. In the last two messages, called

IKE_AUTH, both entities authenticate the previous

messages and exchanges Identity. Finally, the SA

established by IKEv2 is essentially on based

location.

In the same context, the Host Identity Protocol is

used to establish a pair of IPSec security

associations between two hosts through the HIP

Base Exchange (HBE). The HBE consists also of

four messages (I1,R1,I2,R2) based on a classic

Diffie-Hellman key exchange with an inclusion of a

puzzle by the responder node as a cryptographic

challenge in order to avoid a Dos attack from an

illegitimate node that wishes to saturate the

responder node with HIP initiation messages (Arraez

et al., 2011). Finally, the SA established by HIP is

based essentially on the host identity name space

introduced by this protocol.

Developing new security protocols is a difficult

task and sometimes too difficult task for human

mind. So, the idea is benefiting from existing

protocols to create new one. We focus to extend the

IKEv2 in order to enhance authentication, eliminate

man-in-the-middle and reply attacks and guarantee

Dos attacks in order to provide better security

between the two peers. Hence in this paper, we

describe a proposal that consists of combining the

IKEv2 with HIP to set up a security association

based on two parameters which are location and

Identity. This combination may provide better

security properties than each protocol used alone.

This proposal, named (HIP_IKEv2) couple location

and identity to define a security association between

two peers. We have used the Automated Validation

of Internet Security Protocols and Applications

(AVISPA) and its Security Protocol Animator

(SPAN), two powerful automated tools to formally

specify and validate the HIP_IKEv2 protocol. The

rest of this paper is structured as follows. Section II

summarizes the state of the art related to this work.

Section III describes integrating HIP with IKEv2. In

Section VI, a formal specification and validation of

the HIP_IKEv2 with AVISPA and SPAN are

discussed. Finally, Section VII contains the

conclusions and future works.

2 RELATED WORK

This section details related work focused on IKEv2

and its improvement. Having several advantages,

IKEv2 still suffers from some deficiency, such as

man-in-the-middle and Dos attack. Hence, the issue

to protect peers form Dos attack has received the

attention of researchers.

According to (Iso-Anttila et al., 2007) the

resistance to Dos attacks is actually weaker in

IKEv2 than in Just Fast Keying (JFK) or Full-

SIGMA protocol in different networks. Therefore,

the authors present a proposal to improve IKEv2

negotiation (Iso-Anttila et al., 2007), based on using

cookies negotiation in order to detect a Dos attack,

and present an improved cookies negotiation to

remedy the weakness present in IKEv2. So the

authors focus on preventing the traditional

vulnerable cookies negotiation and adding a new

challenge to the initiator without adding

computational load. The proposed cookie

negotiation delays the responder's calculation work

to the last second and computational load is kept as

low as possible.

Reference (Xiaowei et al., 2010) proposes an

improvement of IKEv2, which is based on the

shared secret and asymmetric distribution of

calculations. By analyzing the improved IKEv2 with

a cost-based framework, Iso-Anttila concludes that

the improvement is robust against Dos attack.

Furthermore, associated with cookie mechanism, the

improvement can prevent flooding attack from

spoofed IP addresses. And the improvement can also

achieve the identity authentication in advance, resist

man-in-the-middle attack and replay attack.

In (Zhou et al., 2010), a modified IKEv2 based

on IP fragmentation, in which the authors design and

implement an IKE application fragmentation

protocol and put forward a series of other measures

related to prevent lKEv2 from Dos attacks. Hence,

they design a new IKEv2 header format called M-

ISAKMP, and add a new type of Notification

Payload and other related strategies. With the novel

application-based fragmentation mechanism, the

proposed solution achieves defending against Dos

attack successfully and efficiently.

3 INTEGRATION HIP WITH

IKEv2

This section describes a proposal that is based on

making modification to the IKEv2 initial exchange

HIP_IKEv2:AProposaltoImproveInternetKeyExchangeProtocol-basedonHostIdentityProtocol

405

and then combining this modification with the HIP

to set up a security association based on two

parameters which are location and Identity. This

combination may provide better security properties

than each protocol used alone. This scheme, named

(HIP_IKEv2), couples location and identity to define

a security association between two peers.

HIP_IKEV2 is dedicated to solve some secure

problems. The first subsection describes the

HIP_IKEV2 exchange, the following subsections

describe how HIP_IKEV2 defends the man-in-the-

middle, the Dos and the replay attack. Finally, the

last subsection describes how HIP_IKEV2 assures

the integrity of messages.

3.1 HIP_IKEv2 Exchange

We note that the two protocols mentioned previously

consist of four messages between the two peers

which are in the form of two pairs in two round-trip

times. So the idea is to combine each message from

the first protocol with a message from the second

protocol according to their hierarchical order. Thus

the HIP_IKEV2 exchange is composed of four

messages. The protocol is described with the

notation summarized in Table1.

The HIP_IKEV2 protocol negotiations start with

a combination between the I1 packet from the HIP

protocol and the first message of a modified IKEv2

Initial Exchange using public key in one message

named M1.

Table 1: Notation Used in HIP_IKEv2 Protocol.

Notation Description

HDR IKE header

SAi

, SAr

, Cryptographic algorithms

KEx Key exchange payload of x

Nx Nonce of x

HITx Host Identity tag of x

PK_x Public Key of x

PR_x Private Key of x

{M}

Encryption of message M with

key K.

CERTREQ Certificate Request Payload

CERT Certificate Payload

|| Concatenation operation.

H(M) Hash of message M

IDx Identity of x

AUTHx Authentication Payload of x

TSx Traffic selectors of x

SK Diffie-Hellman shared secret key

Ts Time Stamp

puzzle A cryptographic puzzle

Sol Solution of puzzle

In M1 the initiator sends the IKE header an H-ﬂag

set up to indicate that the HIP extension (HDR

contains the Security Parameter Indexes (SPIs),

version numbers, and flags of various sorts), the next

payload, which is a suite of cryptographic

algorithms SAi

, the third payload contains the

Diffie-Hellman value {KEi}

PK_R

followed by the

nonce {Ni}

PK_R

, the host identity tag HITi of the

initiator and a time stamp ticket Ts. The last payload

includes the HASH_1 payload, which contains a

hash function applied to all messages encrypted with

the private key to protect the integrity of the

message.

When the responder receives the M1 message, it

replies with an M2 message which presents a

combination between the R1 packet from the HIP

protocol and the second message of IKE_SA_INIT.

M2 contains the selected cryptographic algorithms

in SAr

, its Difﬁe-Hellman value {KEr}

PK_I

which

completes the Diﬃe-Hellman exchange followed by

a random nonce {Nr}

PK_I

, its HIT (the responder’s

HIT), a cryptographic puzzle to be solved by the

initiator, and optionally he can send a certificate

Request Payload (CERTREQ), if he want get

initiator’s certificate to authenticate him. M2

contains also a timestamp ticket and a HASH_2

payload. After these first two messages, the hosts

establish a secure tunnel. Until on receiving the M2

message, the Initiator can compute the keying

material for the shared secret. So a symmetric key is

in possession of the two peers.

Now, the initiator and the responder have all

necessary information for a cryptographic protected

conversation. All messages after M1 and M2

exchange are protected with the negotiated

cryptographic algorithm. Only the headers of the

next messages are not encrypted.

Once the puzzle is solved, the initiator can

replies with an M3 message containing the HITs of

the initiator and the responder, and the solution of

the puzzle, also the initiator reveal its identity IDi

and optionally he presents the certificate Payload

(CERT) which is only necessary if the responder

sent a CERTREQ. Also, he can sent a CERTREQ

payload if he want to get a certificate of the

responder. M3 contain also the second suite of

cryptographic algorithms SAi

, the authentication

data (AUTHi) which is used by the initiator to

authenticate its identity. The value of this AUTHi

payload is calculated using a shared secret. In the

last two payloads the initiator proposes traffic

selectors (TSi, TSr) which include policies like the

IP address range or the port range. This M3 message

presents a combination between the first message of

SIMULTECH2013-3rdInternationalConferenceonSimulationandModelingMethodologies,Technologiesand

Applications

406

Figure 1: The HIP_IKEv2 Exchange.

IKE_AUTH from the IKEv2 protocol and the I2

packet from the HIP protocol.

Finally, the responder send an M4 message

which couple the second message of IKE_AUTH

and the R2 packet containing also the HITs of the

initiator and the responder, its identity IDr, the

selected algorithms SAr

, the authentication data

(AUTHr) and traffic selectors (TSi, TSr). The M3

and M4 contain also a time stamp ticket and a

HASH_3 and HASH_4 payloads respectively.

Now, during the last two messages the hosts

identify each other and establish a security

association bound to IP addresses and HITs.

3.2 Defend Man-in-the-Middle Attack

Although IKEv2 is designed to improve IKEv1 and

solve related security problems, it still faces the

man-in-the-middle attack, especially in the IKEv2

initial exchange. In order to resist man-in-the-middle

attack, the responder and the initiator should confirm

the identity of each other before distributing

resources. Hence, the idea in our improvement is

based on public key cryptographic mechanism. In

the initial exchange of IKEv2 protocol, the initiator

Diffie-Hellman value (KEi), the initiator nonce (Ni),

the responder Diffie-Hellman value (KEr) and the

responder nonce (Nr) are transferred without any

kind of security. So, an attacker can easily intercept.

For example, the attacker can intercept in the first

message of this initial exchange by replacing KEi

with KEa1 also Ni with Na1 and send the replaced

payloads to the responder. So the responder instead

of receiving parameters of the initiator, it receives

those of the attacker. The same for the second

message, the attacker can also intercept by replacing

KEr with KEa2 and Nr with Na2 and send the

replaced payloads to the initiator. Thereby the

initiator instead of receiving parameters of the

responder, it receives those of the attacker. To

eliminate this thread, we propose to use mutual

public key in M1 and M2 message to encrypt KEi,

Ni, KEr and Nr. We also propose to sign these

messages with HASH payloads.

First, the initiator encrypt KEi and Ni with the

public key of the responder and add a HASH_1

payload that contains a hash function applied to the

all message encrypted with its private key to protect

the integrity of the message.

HASH_1= {H(SAi

||KEi||Ni||HITi||Ts)}

PR_I

Once received the responder uses its private key

to decrypt KEi and Ni payloads. Moreover, it uses

the public key of the initiator to decrypt HASH_1

and therefore obtain H(SAi

||KEi||Ni||HITi||Ts).

After that the responder applies the same hash

function on (SAi

||KEi||Ni||HITi||Ts) and compares it

with the previous one. If correct, it means that the

M1 comes from a legal initiator and there is not an

attacker. If not, the responder must terminate this

exchange.

Such a treatment is applied to the second

message. The responder encrypts KEr and Nr with

the public key of the initiator and adds a HASH_2

payload that contains a hash function applied to the

message encrypted with its private key to protect the

integrity of the message.

HASH_2={H(SAr

||KEr||Nr||[CERTEQ]||HITr||puzzle|

|Ts)}

PR_R

Once received the initiator uses its private key to

decrypt KEr and Nr payloads. Moreover, it uses the

public key of the responder to decrypt HASH_2 and

therefore obtain

H(SAr

||KEr||Nr||[CERTEQ]||HITr||puzzle||Ts).

After that the initiator applies the same hash

HIP_IKEv2:AProposaltoImproveInternetKeyExchangeProtocol-basedonHostIdentityProtocol

407

function on H(SAr

, KEr, Nr,[CERTEQ], HITr,

puzzle, Ts) and compares it with the previous one. If

correct, it means that the second message of this

initial exchange comes from a legal responder and

there is no attacker. If not, the initiator must

terminate this exchange.

So, this HIP_IKEv2 protocol is able to defend

against man in the middle attack by using public key

cryptography mechanism, since with the private key

of the initiator the attacker is unable to intercept.

3.3 Defend DoS Attack

As mentioned before although IKEv2 is designed to

improve IKEv1 and solve related security problems,

it still faces the Dos attack.

But unlike other attacks, Dos is a matter of

degree, so no protocol can completely protect

against Dos attack. However, we try to give a

solution more secure against the original one which

is basically the use of cookies negotiation.

The cryptographic puzzle exists to protect the

responder from Dos attacks. Hence, the idea is to

benefit from the Host Identity Protocol which uses a

cryptographic puzzle in its base exchange.

Before committing resources, the responder

should ask the initiator to solve a cryptographic

puzzle. To require a correct solution of the

cryptographic puzzle before allocating resources as

precondition reduces the attack rate as it is a brute

force computation. The puzzle is based on a

cryptographic Hash function and it is composed of

three components: the puzzle nonce I, the solution J

and the difficulty level K. Hence, if the responder

wants to defend against a Dos attack, he needs to

send a nonce I to the initiator. The initiator is asked

to find the solution J for which the K lowest order

bit for the binary representation of the result H(I||J)

is equal to zero. Hence, the initiator must vary J and

apply the hash function to the concatenation of the

nonce I with the new J every time until an

appropriate solution is found. The difficulty of a

cryptographic puzzle depends on the responder and

on its level of trust of the Initiator.

Therefore, the puzzle is used to reduce the effect

of Denial of Service attack without adding an extra

round trip to the exchange. We see that the

HIP_IKEv2 consists of four messages only and not

six as is the case in the solution of cookies

negotiation.

3.4 Defend Replay Attack

Since Timestamping is a way of preventing the

replay attack, we propose to add a time stamp

payload to all HIP_IKEv2 messages. So the initiator

and the responder accept only messages for which

the timestamp is included within a reasonable

tolerance. The advantage of this method is that there

is no need to generate random numbers.

3.5 Integrity of Messages

The HASH payload included in the four messages of

HIP_IKEv2 exchange assures the integrity of the

messages. The HASH payload presents always a

hash function applied to all messages encrypted with

its private key. Hence, when the communication

node receives the message, it can calculate the Hash

value, and then compare the result with the HASH

payload after decrypting it.

4 FORMAL SPECIFICATION

AND VALIDATION OF THE

HIP_IKEv2

We have chosen to verify the HIP_IKEv2 using the

“Automated Validation of Internet Security

Protocols and Applications” AVISPA, since it is the

most effective tools according to many comparatives

studies (Cheminod et al., 2009; Lafourcade et al.,

2010).

4.1 AVISPA and SPAN

AVISPA is a push-button tool for building and

analyzing security protocols. The AVISPA Tool is

equipped with a web-based graphical user interface

(www.avispa-project.org/software) that supports the

editing of protocol specifications and allows the user

to select and configure the different back-ends of the

tool (Armando, 2005).

AVISPA provides a modular and expressive

formal language called the High Level Protocol

Specification Language (HLPSL) for specifying

intended protocols and formally validating them

(Lim et al., 2007).

In order to help protocol designers in designing

and debugging HLPSL specifications, a new feature

“Security Protocol Animator” (SPAN) (Cheminod et

al., 2009) was created to facilitate the specification

phase by allowing the animation of the language

HLPSL (Armando et al., 2005).

We specify the HIP_IKEv2 between the initiator

and the responder with HLPSL language. Two

different agents have been defined in the modeling

SIMULTECH2013-3rdInternationalConferenceonSimulationandModelingMethodologies,Technologiesand

Applications

408

process: I which acts as the initiator and R which

acts as the responder.

4.2 Intruder Model

The AVISPA tool assumes that the protocol

messages are exchanged over a network that is under

the control of the Dolev_Yao (DY) intruder model.

This intruder has many capacities over the

communication channel. Hence, it can read all

messages exchanged between the agents and written

in the channel. It can also derive new messages from

its initial knowledge and the messages received from

honest principals during protocol runs. To derive a

new message, the intruder can encrypt and decrypt

messages, compose and decompose, in case he

knows the key. The knowledge of the intruder is

declared in the environment role, which is the top

level role. In our protocol, the intruder knows the

two communicating agents (I, R), their public keys

(PK_I, PK_R), and the solution of the puzzle (sol). It

can compute the Hash payload if it knows the key

and finally it possesses a public and private key

(PK_i, PR_i). So, the intruder knowledge is

summarized as follow:

intruder_knowledge= {I, R, PK_I,

HITi, HITr, PK_R, soln_, Hash, PK_i,

PR_i}

4.3 Security Goals

For security goal we are able to check the mutual

authentication of the agents and the secrecy of

Diffie-Hellman shared key.

4.3.1 Mutual Authentication

The two agents are authenticated on the Diffie-

Hellman shared key. The witness and request events

are goals related to authentication. So we have

modeled this goal in HLPSL as shown below:

role initiator (I,R: agent,……………)

played_by I

transition:

/\ request (I,R,SK1,SK)

role responder (I,R: agent,……………)

played_by R

transition:

/\ witness (R,I,SK1,SK)

Then, in the goal section of the protocol, we write:

authentication_on SK1

That is, the initiator requests a check of the shared

key agreed with the responder and identified by

SK1.

The same procedure is adopted to authenticate the

initiator by the responder. So we have modeled this

goal in HLPSL as shown:

role responder (I,R: agent,……………)

played_by R

transition:

/\ request (R,I,SK2,SK)

role initiator (I,R: agent,……………)

played_by I

transition:

/\ witness (I,R,SK2,SK)

Then, in the goal section of the protocol, we write:

authentication_on SK2

That is, the initiator requests a check of the shared

key agreed with the responder and identified by

SK2.

4.3.2 Secrecy of the shared key between I

and R

The Diffie-Hellman shared key must only be known

by authenticated entities: the initiator and the

responder. The secret is the goal fact related to

secrecy.

This goal has been modeled in HLPSL as

follows:

role initiator (I,R: agent,……………)

played_by I

transition:

/\ secret (SK, sec_a_SK,{I,R})

role responder (I,R: agent,……………)

played_by R

transition:

/\ secret (SK, sec_b_SK,{I,R})

In the goal section of the protocol, we just write:

HIP_IKEv2:AProposaltoImproveInternetKeyExchangeProtocol-basedonHostIdentityProtocol

409

secrecy_ofsec_a_SK, sec_b_SK,

That is, I declares the SK key as a secret shared

between I and R and identified by sec_a_SK.

Moreover, R declares it as a secret shared between R

and I; it is identified by sec_b_SK when sec_a_SK

and sec_b_SK are declared as a protocol_id.

4.4 Verifying the HIP_IKEv2 Protocol

We check the specification by the SPAN tool. For

our verification, we have used the OFMC and the

CL-AtSe back-end to search for the attacks on the

tunnel IPSec arrangement. The output gives details

about whether the specification is safe or not. If not

then it also gives the trace of the attack found, to

indicate secrecy attack or authentication attack. So

even though many properties of the protocol are to

be checked, only a few can be verified using SPAN

tool. Only authentication and secrecy goals are

supported by AVISPA and SPAN.

As already mentioned HIP_IKEv2 was tested

using OFMC and CL-AtSe verification techniques,

which assured its security. No attacks or

vulnerabilities were found.

Figures 2 and 3 demonstrate the messages

returned by OFMC and CL-AtSe verification

technique, respectively. As shown in the two figures

below, the proposed solution is safe to use and no

attacks were found.

Figure 2: Message Returned by AVISPA for HIP_IKEv2

with OFMC.

4 CONCLUSIONS

HIP_IKEv2 protocol makes security modification to

the initial exchange of IKEv2 protocol and then

integrates this modification with the HIP protocol to

Figure 3: Message Returned by AVISPA for HIP_IKEv2

with CL-AtSe.

enhance security and establish a security association

based on location and identity. HIP_IKEv2 has

effectively solved some secure problems such as

man in the middle, Dos and replay attack. It also

assures the integrity of messages. The solution has

been validated with the Automated Validation of

Internet Security Protocols and Applications

(AVISPA) and its Security Protocol Animator

(SPAN), which proves that the solution is safe and

no attacks were found.

Future works will be focused on trying to give

solution against some other types of attacks such as

connection hijacking, and impersonation.

REFERENCES

Gurtov, A., 2008. Host Identity Protocol (HIP): Towards

the Secure Mobile Internet. Helsinki Institute for

Information Technology (HIIT), Finland, Wiley

Kaufman, C., Hoffman, P., Nir, Y., Eronen, P., 2010.

Internet Key Exchange Protocol Version 2 (IKEv2),

IETF RFC5996; www.rfc-editor.org/info/rfc5996

Henderson, T., Gurtov, A., 2012. The Host Identity

Protocol (HIP) Experiment Report, IETF RFC6538;

www.rfc-editor.org/info/rfc6538

Arraez, L., Chaouchi, H., G.Ayadin, Z., 2011.

“Performance Evaluation and Experiments for Host

Identity Protocol”, IJCSI International Journal of

Computer Science Issues, Vol 8, Issue 2, pp 74 - 83

Iso-Anttila, L., Ylinen, J., Loula, P., 2007. “A Proposal to

Improve IKEv2 negotiation”, International

Conference on Emerging Security Information Systems

and Technologies (IEEE ICESIST), pp 169 - 174.

Xiaowei, Z., Zhou, H., Jun, L., 2010. “Analysis and

improvement of IKEv2 against denial of service

attack”, International Conference on Information

Networking and Automation (IEEE ICINA), pp 350 -

355.

Zhou, P., Qin, Y., Xu, C., Guan, J., Zhang, H., 2010.

“Security investigation and enhancement of IKEV2

SIMULTECH2013-3rdInternationalConferenceonSimulationandModelingMethodologies,Technologiesand

Applications

410

protocol”, 3rd International Conference on

Broadband Network and Multimedia Technology

(IEEE IC-BNMT), pp 65 - 69.

Cheminod, M., Bertolotti, I., Durante, L., Sisto, R.,

Valenzano, A., 2009. “Tools for cryptographic

protocols analysis: A technical and experimental

comparison”, Elsevier Computer Standards &

Interfaces, Vol 31, Issue 5, pp 954 - 961

Lafourcade, P., Terrade, V., Vigier, S., 2010.

“Comparison of Cryptographic Verification Tools

Dealing with Algebraic Properties”, Springer Formal

Aspects in Security and Trust(FAST), Vol 5983, pp

173-185.

Armando, A., Basin, D., Cuellar, J., Rusinowitch, M.,

Viganò, L., 2005. “The AVISPA Tool for the

Automated Validation of Internet Security Protocols

and Applications”, Springer Computer Aided

Verification(CAV), Vol 3576, pp 281- 285.

Lim, S., Bang, K., Yi, O., Lim, J., 2007. "A Secure

Handover Protocol Design in Wireless Networks with

Formal Verification", Springer Wired/Wireless

Internet Communications(WWIC), Vol 4517, pp 67 -

78.

HIP_IKEv2:AProposaltoImproveInternetKeyExchangeProtocol-basedonHostIdentityProtocol

411
