A Metamodel-driven Architecture for Generating, Populating

and Manipulating “Possible Worlds” to Answer Questions

Imre Kilián

and Gábor Alberti

Department of Informatics, University of Pécs, H-7624 Pécs, Ifjúság útja 6, Hungary

Department of General Linguistics, University of Pécs, H-7624 Pécs, Ifjúság útja 6, Hungary

Keywords: Representational Dynamic Discourse Semantics, Information State, Modal Logic.

Abstract: The architecture we are developing can serve many ends: it can be used, for instance, as an intelligent

personal diary for private purposes, or even as a dynamic “epistemic” protocol for legal cases or criminal

investigations. Two of its special features make our architecture capable of performing these tasks. One of

them is a DRT-based (Kamp et al., 2011) formal cognitive theory called eALIS (Alberti, 2009; Alberti

and Kleiber, 2012; Alberti and Károly, 2012), which is responsible for the particular structure of our

databases; the other one is a Prolog-based logical framework, which is responsible for populating the

database and for logically “closing” its appropriate substructures. The major contribution of eALIS to this

project is a traditional relational model (w

) of the relevant segment of the external world coupled up with

an unlimited set (W={w

,…}) of “wordlets”, each of which is an appropriately modified and highly

partial copy of w

, capable of registering the beliefs, desires and intentions of a group of people, as concerns

the facts of w

at selected points of time (T), as well as one another’s beliefs and other wordlets of WT.

The Prolog inference system operates on a partially ordered structure with which we furnish WT, in order

to answer users’ yes/no questions and to provide entities of wordlets as answers to wh-questions

1 THE ARCHITECTURE

OF THE SYSTEM

The architecture shown in Figure 1 is shared by

several eALIS-based projects. What this particular

project focuses on is the generation of a partially

ordered tree of worldlets with w

, “the external-

world model”, at its roots; the population of these

wordlets with entities, relations/predicates; and,

finally, the appropriately localized manipulation of

these entities by Prolog inference steps. One of our

other projects is responsible for the continuous

extension of the linguistic fragments that users’

input questions are to be based upon.

2 GENERATING WORLD(LET)S

As shown in Figure 1, the World-Model Generator is

clearly distinguished from the Module of World-

Model Population.

Why? The answer lies with our approach in

which the former module is practically an interface

Figure 1: System Architecture.

which enables the user to define either a new

worldlet, or a new predicate, or a new entity, or to

create an intersection of the world at a given point of

time. It is the programmers’ task to write a program

so that the user’s each and every request is followed

by a query concerning the provision of data that

should satisfy the request. The only task of the user

World Model

Generator

Linguistic

Generator

World-

Model

Population

Truth-model Interpretation

+ Dynamic Interpretation

Lexicon

Population

Logical

Operations

Cultural/

Encycl.

Knowledge

Kilián I. and Alberti G..

A Metamodel-driven Architecture for Generating, Populating and Manipulating “Possible Worlds” to Answer Questions.

DOI: 10.5220/0004596000740078

In Proceedings of the 8th International Joint Conference on Software Technologies (ICSOFT-EA-2013), pages 74-78

ISBN: 978-989-8565-68-6

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

is to provide the required data; this procedure is, in

fact, the actual population of the world model. The

person responsible for the Module of World-Model

Population, thus, is the writer of the diary or the

legal expert himself (cf. Abstract). He/she is the one

who can and should describe the part of the external

world relevant to him/her (e.g. as in a complex legal

case), as well as all the beliefs, desires and intentions

that he/she attributes to the agents who he/she

qualifies as relevant participants/observers in the

given case.

In what follows, we shall overview the procedure

of the query from the user’s perspective.

3 POPULATING THE WORLD

MODEL

Due to the reciprocal and lifelong character of our

discourse-semantic background (Reciprocal And

Lifelong Interpretation System → hence, eALIS),

what we use as a world model is not only a

representation of (a part of) “the world outside” but

also a representation of people’s temporary

information states—since human beings together

with their minds’ content form part of the world.

Practically, the relational model of the relevant

external situation multiplies in an arbitrarily

proliferating manner of “mutation”. A person’s

desire, for instance, can be represented by providing

some of the external relations/facts (1a), typically

with opposite polarity values (1b). A complex belief

can also be construed as a mutation of external facts

in respect of polarity (1c):

(1) a. 1. Mary is gorgeous. (+: This is true.)

2. Mary loves Peter. (+: This is true.)

3. Mary loves John. (–: This is false.)

b. 1. Mary is gorgeous. (+: This coincides with

John’s desire.)

2. Mary loves Peter. (–: This does not belong

to John’s desires.)

3. Mary loves John. (+: This is John’s

desire.)

c. 1. Mary is gorgeous. (+: This is John’s

opinion.)

2. Mary loves Peter. (+: John knows that this

true.)

3. Mary loves John. (+: John believes that

this is true.)

We multiply worlds, but the external-world model is

retained as a standard simple information structure,

in which “[Axiom 10] No argument is an infon,

relation or role”, to avoid the theoretical

complications discussed in (Seligman and Moss,

1997) (NB. Axiom 10 is violated in the highly

partial constructions we call wordlets). (2a) below

shows an infon i which belongs to w

at moment t

and expresses the piece of information that defines if

entities u

, u

, ..., u

stand in a k-ary relation p.

(2) a. p(w0, t, +, i, u1, u2, ..., uk)

b. p(w, t, +, e, r1, r2, ..., rk)

c. lambda(w', w", ...)

d. +/–//0/0

e. DES,r

John

,t,–^BEL,r

John

,t,0

f. alpha(u, r, ...), and alpha(r', r", ...)

In (2a), ʻ+ʼ can be replaced with ʻ–ʼ or ʻʼ. These

polarity values mean, respectively, that the entities

in question stand in a given relation (e.g. the pair of

Peter and Mary, at moment t, belong to a set of pairs

of people which consists of pairs where the first

element loves the second one, at t; i.e., “Peter loves

Mary”) / are outside of the given relation (“Peter

does not love Mary at the given moment”) / do not

belong to the domain of the given relation (it does

not make any sense to register e.g. “the table loves

Mary” in the model of the external world).

Thus, the external world at moment t can be

described by means of Prolog-facts, similarly to (1a).

In the case of each k-ary relation p, the Cartesian

product U

is partitioned into three subsets in the way

described above (+/–/), where U is the set of

external entities, fixed once and for all (NB. If a

person is associated with a predicate at moment t

when he/she does not exist, i.e. before his/her birth

or after his/her death, the polarity value ʻʼ

(“meaningless”) is to be applied).

The formula in (2b) above is a “true copy” of the

formula in (2a) in an arbitrary worldlet w. The u

external entities have been replaced with r

internal

entities, and w has been substituted for w

Furthermore, infon i is replaced with an eventuality e.

Instead of a “true copy”, mutated copies can also be

produced by choosing a polarity value (out of the set

shown in (2d) above) which differs from the polarity

value in the Prolog-fact serving as the source of copy.

Here the ʻ+ʼ should be replaced with a ʻ–ʼ, for

example; which would mean that a positive fact is

believed or desired to be negative in a worldlet of

belief/desire. If a ʻ0ʼ appears in the place of a ʻ+ʼ in

the source, then the positive source fact is not known

or not desired in the target worldlet of belief/desire.

(2c) shows the scheme of the Prolog-fact

providing the relation between a worldlet (of

someone’s belief/desire/intention) and the external-

world model, or between two worldlets. The series

of points in (2c) shows the place in the formula

where the position of w" is to be given relative to

AMetamodel-drivenArchitectureforGenerating,PopulatingandManipulating"PossibleWorlds"toAnswerQuestions

that of w' in the “tree of worldlets” mentioned above.

In the theory of eALIS (Alberti, 2009; Alberti and

Kleiber, 2012; Alberti and Károly, 2012), this piece of

information is called a lambda-label. If w', for

instance, is the worldlet of Peter’s belief, then w" is

defined as the worldlet consisting of the situations

that, in Peter’s opinion, John does not long for, if the

lambda-label is DES,r

John

,t,–. (2e) illustrates the

application of the special polarity value marked by a

crossed-out zero: if eventuality (1b.3) is associated

with the polarity-segment label mentioned in (2e), this

means that John wants to know if Mary loves him or

not. The decisive part of the calculus of ʻ0ʼ is that this

desire is satisfied by receiving either a positive or a

negative answer.

Anchoring relations between entities of w' and

entities of w" must also be given (2f).

The copying and mutating of infons of the

external-world model in internal worldlets does not

belong to the task of the programmer. The polarity

values are permitted to stand in an arbitrary relation,

depending on the legal or private case that the user of

our system intends to model. What the software

evaluates via its Module of Truth-Conditional

Interpretation (see Figure 1 above), is practically the

system of polarity values that belongs to the same

relation/predicate. As some values pertain to beliefs,

desires and intentions at different moments, their

comparison enables us to define “numerically” such

pragmatic things as lie, bluff or convincing. Due to

Prolog, an existential piece of information (say,

“Mary loves someone”) can also be evaluated so that,

in addition to a yes/no answer, we can also receive the

entities satisfying the existential statement.

4 LOGICAL FRAMEWORK

Choosing Prolog as a programming language also

means choosing logics as a modelling tool, and

generally choosing logic programming as an

implementation paradigm. For modelling the multi-

agent world along with its belief-desire-intention

(BDI) mental relationship, eALIS uses an

epistemic/temporal multimodal logic framework and

an appropriate logic language (eALIS Modal

Language/eALM).

Beyond the logic framework and the language,

the target model and/or the runtime-environment

must also be defined. Owing to Prolog, the closer the

target model to pure first-order logic, the more

efficient the inference. We simply intend to use

Prolog, whenever possible, as a theorem-proving

engine based on linear input resolution. If this

strategy is not satisfactory, the necessary

enhancements have to be made.

Questions are basically answered by the

theorem-prover. Theorem proving, however, is not

complete: it follows human interpreters’ capabilities.

Instead of less efficient mathematical proofs for each

provable theorem, we aim to use a mixed-strategy

theorem-prover which combines the results of

theme-dependent but quick solvers (Kilián, 2007).

On the level of Prolog implementation we define a

controlling meta-language which enables the system

to control the different external solvers that may be

plugged-in.

In order to map modal-logic statements to first-

order logic, we apply a slightly improved version of

Ohlbach’s mapping rules (Ohlbach, 1988).

According to this, each literal statement is extended

with two new logical parameters. One describes the

epistemic modal context of the statement

(practically, it denotes the “wordlet” where the

literal statement is valid). The second extra

parameter describes the temporal context (and/or the

actual time). This representation enables the easy

mapping of modal logic axioms.

Some of the modal axioms are stored in an

explicite form: compiled into the knowledge base.

This means that, for each piece of knowledge, new

rules are to be added which perform the possible

inferential steps. Although this allows for the

immediate utilisation of the Prolog engine, at the

same time it multiplies storage demand. Therefore

we only follow this approach with the most

frequently used axioms (e.g. inheritance). The rarely

used axioms are interpreted by a meta-interpreter,

rather than compiled.

Being an interpretation framework for natural

languages, eALIS uses multi-valued logics (True,

False, Not provable, Meaningless, etc.). This also

correlates with the Open World and Closed World

Assumptions: wherever Closed World cannot be

applied, a „Not provable” result must be returned.

Whenever the usage constraints of certain predicates

are violated, the inference engine should generate

„Meaningless” value. In the future, the logical

framework may need to be extended even to a fuzzy

model.

5 METAMODEL

We use the word ’meta-’ in reference to the

description of a target structure. In object-oriented

technology, the mass of data that a software

ICSOFT2013-8thInternationalJointConferenceonSoftwareTechnologies

manipulates is described by a model – the data are

instances of the model. For common software

products, the model is fixed, and a common

programming language implements it. In certain

cases, however, the model can develop over time

and we must also regard this as part of the data of

the software. The model for such a software cannot

be fixed: the metamodel, that is the model of the

model is fixed and programmed.

The application data for eALIS are individual

entities, their actual relationships and the inference

rules governing them. The layer over them is the

model layer that contains the description of

predicates, classes, properties etc. of the individual

layer. These together form the knowledge-base of

the software.

For the seamless handling of these two layers,

the structure of the model-layer must also be

described. This is called the metamodel describing

what the model looks like.

Moreover, we can suppose that even the

metamodel cannot be fixed as it is continuously

corrected in the course of software development.

Therefore, we must also define the model of the

metamodel (the meta-metamodel), which can be

finally hard-coded (Kilián, 2008).

The four-layer structure described above has

been introduced by OMG for object-oriented

software (OMG, 1997).

Figure 2: Four level metamodel structure.

The most important relation between the application

data is the wordlet structure. The superindividual

layer of this describes those groupings and usage-

environments that collect the common knowledge of

several individual actors.

The individual layer of the wordlet structure

mostly contains individuals who interpret texts, but

we also map other text-interpreting contexts here,

e.g., literary works or legal cases.

The supraindividual layer of wordlets has a

forest topology the roots of which are the individuals

themselves. A wordlet from this layer always has

reference to its ancestor, thus they are not to be

defined explicitly.

6 EXPORT/IMPORT

AND INFERENCE

In research there have been a number of ontologies

designed over the past decade. There are so called

‘upper-level ontologies’ which contain the most

general and abstract concepts of our knowledge, but

there are also specialized ‘domain ontologies’ for

narrow special fields. It would be a serious mistake

to not utilize the ontologies developed so far. The

system must be equipped with a plug-in-like

extendable import/export interface. The first such

plug-in loads the OWL ontologies of the Semantic

Web initiative.

Another export/import requirement is to store

instance-information in a relational database, and to

load them in a lazy way, only when it is necessary.

The most straightforward solution maps a class to a

relational table, and an instance to a line in a table.

Since the indexing mechanism is only efficient for

more than thousands of data, for classes with less

instances of data, a simple Prolog textual export can

be much more efficient.

The elements of the knowledge-base that were

compiled directly can also be invoked directly, by

Prolog. For the overall architecture, a plug-in-

interface is proposed which enables the system to

invoke externally connectable inference engines.

One such possibility is to use Contralog (Kilián,

2011) which builds a forward chaining inference

engine upon Prolog. As another possibility, meta-

interpreters can easily be designed in Prolog. For

certain decidable subsets of mathematical logics,

however (e.g. for description logics, DL), there are

free inference engines available which can be

downloaded or invoked as a Web application.

7 CURRENT STATUS

AND FUTURE WORK

The integration of OWL ontologies, their modal

extension and model-driven integration have been

successfully completed, and the system is under

extensive testing. The integration of the Contralog

forward-chaining framework is also successful.

Based on our experience, we have redesigned the

system to meet the requirements of metamodell-

driven architecture, and to implement the plug-in

Entities/relationships

Predicate definitions

Metamodel

(description of the

model

)

Meta-metamodel

AMetamodel-drivenArchitectureforGenerating,PopulatingandManipulating"PossibleWorlds"toAnswerQuestions

interface for import-export operations and for

external inference engines. This phase is still under

development. The completion of this step can open

new ways to extensive language-technological

experiments. As soon as the engine is coherent, we

are planning to extend it by a Java GUI.

ACKNOWLEDGEMENTS

We are grateful to a Hungarian national fund for

their contribution to our costs at ICSOFT 2013

(Reykjavík): SROP-4.2.1.B-10/2/KONV/2010/

KONV-2010-0002 (Developing Competitiveness of

Universities in the Southern Transdanubian Region).

Writing this paper is due to another project: SROP-

4.2.2.C-11/1/KONV-2012-0005 (Well-Being in the

Information Society).

We also express our thanks to our colleagues:

Márton Károly and Judit Kleiber for their

contribution.

REFERENCES

Alberti, G.: eALIS: An Interpretation System which is

Reciprocal and Lifelong. Workshop ‘Focus on

Discourse and Context-Dependence’ (16.09.2009,

13.30-14.30 UvA, Amsterdam Center for Language

and Comm.); http://lingua.btk.pte.hu/realispapers

(2009)

Alberti, G., J. Kleiber Where are Possible Worlds?

(Arguments for eALIS). Acta Linguistica Hungarica

59 (1-2) (ed. Katalin É. Kiss). 3–26. (2012)

Alberti, G., M. Károly: Multiple Level of Referents in

Information State. A. Gelbukh (ed.): Computational

Linguistics and Intelligent Text Processing,

CICLing2012, New Delhi, India. LNCS7181. Springer

Verlag, Berlin, Heidelberg, pp. 34–362 (2012)

Kamp, H., van Genabith, J., Reyle, U.: Discourse

Representation Theory. In Handbook of Philosophical

Logic, vol. 15, pp. 125–394. Springer-Verlag, Berlin

(2011)

Kilián, I.: Modellvezérelt szoftverek készítése I-II (in

English: Creating Model-driven Software) Alkalmazott

Matematikai Lapok MTA, Budapest 2008.

Kilián, I.: Contralog: egy előre haladó Prolog motor és

alkalmazása eALIS nyelvi elemzésre (in English:

Contralog: a Forward-Chaining Prolog Engine and its

Application for eALIS Lingual Parsing) Erdélyi

Magyar Műszaki Tudományos Társaság, SzámOkt

2011. konferencia kiadványa, Kolozsvár, 2011, pp.

199-205.

Kilián, I.: Mixed strategy reasoning. An approach for

resolution based verification of OCL constraints in

UML models, Pollack Periodica, Vol. 2 Supplement,

Akadémiai Kiadó, Budapest 2007.

OMG Joint Revised Submission: Meta Object Facility

(MOF) Specification OMG Document 1997.

Seligman, J., Moss, L. S.: Situation Theory. In van

Benthem, J., and ter Meulen, A. eds.: Handbook of

Logic and Language. Elsevier, Amsterdam, MIT

Press, Cambridge, Mass, pp. 239–309 (1997)

ICSOFT2013-8thInternationalJointConferenceonSoftwareTechnologies
