Abusing Social Networks with Abuse Reports

A Coalition Attack for Social Networks

Slim Trabelsi

and Hana Bouafif

SAP Labs France, 805, Av Dr Maurice Daunat, Mougins, France

ESPRIT, Tunis, Tunisia

Keywords: Social Networks, Attack, Coalition, DoS, Abuse Report, Coalition.

Abstract: In Social Network websites, the users can report the bad behaviors of other users. In order to do so, they can

create a kind of escalation ticket called abuse report in which they detail the infraction made by the “bad”

user and help the website moderator to decide on a penalty. Today Social Networks count billions of users,

the handling of the abuse reports is no more executed manually by moderators; they currently rely on some

algorithms that automatically block the “bad” users until a moderator takes care of the case. In this paper we

purport to demonstrate how such algorithms are maliciously used by attackers to illegally block innocent

victims. We also propose to automate such an attack to demonstrate the big damage that can be caused in

current social network websites. We also took the case study of Facebook as proof of concept.

1 INTRODUCTION

Social networks (SNs) are strongly influencing the

daily life of millions of citizens, companies,

administrations, universities, etc. Initially, such

online communities were designed to virtualize the

networking activities and to facilitate social

interactions between people. Unfortunately, as for

any computing systems, various malicious behaviors

appear aiming to corrupt the standard execution

process of such a system. SNs are managing huge

amount of personal and professional data, attracting

cybercrime and cyber terrorism organizations to

maliciously exploit such sensitive information.

Recently, some political and ideological groups used

SNs to attack specific SNs user profiles (Morozov,

2011) in order to isolate them from any virtual

activity. This attack exploits a common vulnerability

in the abuse reporting systems of the most popular

SNs. Very popular SNs count hundreds of million

users, it is clear that the moderation task to manage

abuse reports cannot be done manually. This is why

SN sites use abuse management algorithms to

handle, filter and categorize the reports. Then, if

need be, these reports are escalated to the

moderation team to take a decision based on a

human analysis. One basic and naïve algorithm

consists in blocking a user profile, a page, or a group

after receiving a specific number of abuse reports

targeting them. The targeted element will be blocked

until a human moderator studies the case. In order to

perform this attack the criminal organization can

rely on an important number of attackers. This is

what we categorize under the umbrella of coalition

attack (Srivatsa, 2005). In this paper, we propose to

automate this attack in order to get rid of the

necessity of having a large attacking community of a

criminal organization. The goal, of our attack tool is

of course not to help malicious users to perform such

DoS attacks, but to explain and proof that such

attack can be easily executed over thousands victim

profiles with a simple mouse click that takes only a

few seconds. We thus claim that it is crucial to the

SNs security officers to change and upgrade their

automatic abuse reporting management algorithms.

As proof of concept, we tested our attacking tool in

Facebook (Facebook, 2012) as the most popular SN

in the world. The execution of the tool gives some

interesting hints on how the abuse reporting system

is working in Facebook. We analyze most of the

reporting parameters in order to propose some

possible countermeasures.

This paper is structured as follows: in section II

we give an overview of the current state of the art

related to the coalition attack exploiting social

networks aspects, in section III we explain the

theoretical aspect of the coalition attack, in section

IV we detail our proof of concept that automates this

500

Trabelsi S. and Bouaﬁf H..

Abusing Social Networks with Abuse Reports - A Coalition Attack for Social Networks.

DOI: 10.5220/0004523005000505

In Proceedings of the 10th International Conference on Security and Cryptography (SECRYPT-2013), pages 500-505

ISBN: 978-989-8565-73-0

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

attack in a real SN, in section V we propose a set of

countermeasures to prevent the different variants of

this attack.

2 RELATED WORK

Abuse reporting systems in SNs can be defined as a

specific application of the traditional reputation

system. To be more precise, it refers to negative

feedback reputation systems (Tennenholtz, 2004)

where reporting users are only solicited to declare

negative behaviors of other users. As any reputation

system, the abuse reporting algorithms are

vulnerable to what we call coalition attacks, also

called orchestrated attacks (Srivatsa, 2005), and

when this attack is automated as we show it in this

paper it becomes a DoS attack. Hoffman et al

(Hoffman, 2007) clearly defined and distinguished

these different levels of attacks in reputation

systems. The bridge between generic reputation

systems and social organization was initially pointed

out by (Cristani, 2011), inspired by the study on

logic for coalition power in game theory defined by

Pauly in (Pauly, 2002) and (Pauly, 2001). (Cristani,

2011) formally proved that in social groups, a

coalition of agents can behave in a malicious way in

order to corrupt the normal behavior of the system.

Such approach was declared as generic, but it is

clearly not applicable for the specificities of SNs

where several parameters are not taken into account

(relationships between users, shared virtual

ideology, group memberships, etc.). A spontaneous

solution was proposed by (Slashdot, 2012)

contributors called “Crowdsourcing the Censors: A

Contest” (Von Ahn, 2003). It was proposed in order

to delegate the administration and moderation task to

group of SN users. With this approach the number of

volunteers should be sufficient to give a response to

all the abuse report requests. Attackers can also be

part of these volunteers, but they assume that if the

number of volunteers is huge and the selection of the

user is random they will not affect the process. This

subjective solution has two main limitations: the

language and the cultural background of the

volunteers are not systematically adapted to the

content of the report. When abuse report is claiming

that the targeted user account is fake. How a simple

user can verify this statement?

To our knowledge, there has not been yet any

scientific study on the impact of coalition attacks in

SNs, nor an attempt at automating this attack to

become a powerful nor damaging DoS tool for

social communities.

3 COALITION ATTACK

PRINCIPLE FOR SOCIAL

NETWORK USERS BLOCKING

The ideologically based coalition attack represents

the manual approach for a DoS rush on the abuse

system of the SN. This kind of attack requires an

important investment in manpower and a certain

complexity in synchronizing these actors. In order to

formalize such attack, we propose to represent the

user interaction description of social networks in a

basic model defining a subset elements related to a

generic social network.

Figure 1: Basic user model for social networks.

The terminology related to this model is described below:

 User: is a virtual profile social network person

member of the online community. This user can

create and administrate groups, be member of

several groups, publish posts and abuse reports.

 Group: is a set of users sharing a common interest.

The group of users may be structured as a

hierarchical community with a group creator or a

group administrator.

 Post: a post is a message or a text posted by the user

in the social network. This post can be sibling or

referencing a user.

 Report: a report is an abuse or warning message that

notifies the illegal behavior of a user or a non-ethical

post sent by a user or a group of users. The report is

created by a user and sibling a user or a post.

Let’s assume that



the group of N abuse reports

r sibling the user s where:



sofsiblingrrrrr

 _.|,.....,,,

321

We will later observe that this number N can vary

in certain SNs according to the “popularity of s”

The attack becomes malicious, coordinated and

ideologically motivated if the authors of



are

AbusingSocialNetworkswithAbuseReports-ACoalitionAttackforSocialNetworks

501

sharing the same preference groups. We call these

groups



that gather all the user authors of the

reports





is the set of users that reported the

abuse against s. The attack must be coalition is in this

group all or most of the members share a secret or a

motivation.



creatorruuuuu

iiN

.|,....,,,

321



Where

s

this is due to the fact that we

consider that the targeted victim should not be

member of these ideological groups as he is designed

as enemy.

Starting from this model we will explain later on

how to detect and prevent such a “manual” attack by

performing internal checking from the SNs abuse

report engines.

The detection task become more complex if the

attacker user profiles are not human, generated on the

fly without sharing any common interest or ideology.

4 AUTOMATING THE

COALITION ATTACK: THE

FACEBOOK SOCIAL

NETWORK AS A CASE STUDY

As a proof of concept for this vulnerability we

decided to target the attack to the most popular SN

nowadays: Facebook (Facebook, 2012). With more

than 1 billion active users spread all over the world,

Facebook is a very good playground to test our

approach. This SN is also reputed to be one of the

most secure against external attacks, and relies on a

very dynamic code deployment that makes that

reverse engineering process very complicated.

4.1 Basic Abuse Report Process

We describe in this section the usual process of an

abuse report action sent by a normal user (see Fig2).

In addition to the basic look and feel interface shown

to the user we give you some information about the

metadata exchanged between the Facebook server

and the user’s browser.

1. Once the user access Facebook’s URL and

display it, a new cookie is initialized and

stored in the browser’s cache.

2. The user authenticates himself with his

credentials

3. Display of the user’s page

4. A new sessions is active



Figure 2: Abuse report process in Facebook.

5. The user can search for a non-friend target

user profile or request access to a friend

profile.

6. Once the targeted profile is selected the

webpage depicting his information is

displayed in the browser

7. The user requests an abuser report in order

to notify a bad behavior of the target profile

8. A report Ajax window is then displayed in

the user’s browser

9. The user selects the type of infraction he

wants to report

10. The report is sent to the Facebook server

11. A confirmation request is sent back to the

user (in case of mistake)

12. Once the report is confirmed it becomes an

active abuse report triggered on Facebook’s

server.

The user in Facebook has the possibility to

choose several types of Abuse reports. According to

our experience the type that generates the highest

process time during the report treatment from

Facebook administrators is the “This timeline is

pretending to be someone or is fake”. This long

delay is due to the verification procedure; the target

SECRYPT2013-InternationalConferenceonSecurityandCryptography

502

account can be blocked until the owner of the profile

proves his identity. This verification delay is added

to the treatment delay of an abuse report.

The coalition attack consists then to synchronize

with a group of users to perform the same action

more or less simultaneously on a common profile

target with the report type “fake account”. After N

reports Facebook report abuse handling algorithm

will automatically block the target account until a

human administrator comes and verifies the

legitimacy of the reports. The target profile owner

will then be contacted by e-mail and requested to

provide a copy of his ID card or passport to prove

his identity.

4.2 Manual Simulation of the Coalition

Attack

In order to replay the attack described in the

previous section, we created a dummy testing

account that will play the role of victim, then we

asked to our colleagues to join us in a coalition

attack. For the sake of efficiency, we synchronized

our attack in order to be all in all executed in a

window time frame of 4 hours. The coalition was

composed of 44 volunteer Facebook users. The

attack was executed during 5 hours. After the last

abuse report was sent, the target account was

blocked. The lesson learned from this experience, is

that 44 reporters is maybe lower than the minimum

threshold N. Our attack was at the end successful,

but we don’t have any guarantee or proof that the

targeted account was blocked by the automated

abuse report system and not by a human

administrator. The next step is to automate and

simulate the attackers in order to prove the attack

and try to identify N.

4.3 DoS Attack for the Abuser

Reporting System: Automating

the Coalition Attack

4.3.1 Analyzing an Abuse Report Request

In order to simulate an abuser reporting action, we

have to study all the parameters exchanged between

the browser and the Facebook server through HTTP.

We captured and analyzed all the HTTP traffic

generated during one report abuse action. We used

the Zed Attack Proxy (OWASP, 2012) from

OWASP that offers a powerful web application

scanner monitoring, interception and modifying the

different parameters of the application.

This is the list of variables that are sent to the

server during an abuse report action. These variables

are requested by a Javascript form. (This list may

change over time according to the releases of the

Facebook API):

 phase_branch: abuse treport type (fake account,

impersonation of id, etc.).

 authentic_uid: impersonation of the uid.

 impersonated_user_name: fake user name.

 duplicate_id: impersonation.

 sub_lost_access: ?

 sub_fake_profile: sub option of fake account.

 rid: facebook identifier of the victim.

 cid: facebook identifier of the victim.

 hour: the hash of the reporting link.

 content_type: the content type of the request.

 are_friends: check of the relation of friendship

between both profiles.

 is_ following: check of the relation of

following between both profiles.

 time_flow_started: time of reporting starting

 is_tagged: check if both accounts share photos

in common.

 on_profile: check of a profile relationship

between both accounts

 duplicate_id: check if there is duplication of id.

 ph: ?

 phase: defines the reporting phase.

 expand_report: if yes, a second window of

reporting complement will appear.

 nctr [_mod]: location of the reporting button

differs in case of a timeline account.

 __ d: request limiter.

 fb_dtsg: variable of session.

 __ user: attacker Facebook identifier.

 phstamp: equal to the sending request hashing

All these variables are not officially documented

by Facebook, then we proposed our definition. The

parameters that we did not defined (marked by a

“?”) are optional, can be replayed (are not dependent

from any timestamp or session ID).

4.3.2 Generating Fake Abuse Report

Messages

Generating automated abuse report consists in Filling

the user ID and the targeted profile ID. The rest of

the variables are just replayed as received from the

server (see Fig3.). Here is a non-exhaustive list of

variables that we replayed during the attack: The

variables ph, phstamp , post_form_id and fb_dtsg do

AbusingSocialNetworkswithAbuseReports-ACoalitionAttackforSocialNetworks

503

not change although the session changes. The

variable time_flow_started is composed of the

timestamp and a sequence number that is

incremented by one every request.

The challenging part of the attack is the creation

of dummy attackers profiles then the login. The

creation of these accounts was quite tricky due to the



Figure 3: Automating the abuse reporting.

confirmation request that is mandatory to validate a

new account. The absence of client-side challenge-

response mechanisms made this task easier. The

second “vulnerability” concerns the possibility to

execute two actions for a new account before being

asked for a confirmation. These two actions can be

abuse report sending. These weaknesses are quite

enigmatic, because nowadays most of the websites

are preventing the automatic creation of accounts.

4.3.3 Result of the Attack

The setup phase of the attack is the creation of fake

user accounts. Then, fake reports are sequentially

sent until the victim account is blocked. We

performed several tests on fake victim accounts,

with very limited activities and a small number of

virtual “friends” in the SN. All of these accounts

where blocked in few seconds. The only observation

that we made, is that more a user account is

“popular” more N is large. Popular profile means

with a lot of friends and activity (publications).

During our tests we did not execute the attack

against real users for ethical reasons. We are

currently trying to create several fake accounts with

a certain popularity to have a wider scope in terms

of testing profiles.

5 PREVENTING USER

BLOCKING ATTACKS

IN SOCIAL NETWORKS

In this section we provide two main solutions to

prevent such attacks in SNs.

5.1 Preventing Coalition Attacks

As defined at the beginning of the paper the manual

collation attack, mainly motivated by ideological

reasons, and executed by a group of SN users that

agreed to block a specific user profile. The victim is

not chosen randomly, but most of the time chosen

according to the adversity of his ideological beliefs.

Starting from this observation, an SN administrator

can extract some information that can be useful to

differentiate between a real abuse report flow and a

coalition attack. We re-use the formal notation

depicted in section.

We already defined



as the set of reports

sibling the target profile s.



is the group of users

that reported the abuse against s in a certain

constrained period of time (that must be defined). We

propose a list of verifications to execute before

blocking the targeted profile.



is the list of social groups to which belong

all the users in







subscriberuGGGG

iii

.,...,,

321



 GI is the intersection of all the groups

representing the common social interests of the

users in



)(

GGI 



 The common ideological interest can be

automatically detected at this stage if most of

the reporters share a social interest or belongs to

the same interest group. If the reporters mainly

belong to the same groups.



is a threshold

value defined by the SN administrator that

identifies the users sharing the same interests.

The targeted profile s must not belong to these

groups.







)(.countGI

 The targeted profile s must not belong to one of

these groups.

 If in these interest groups a link to s profile is

detected this can be the proof that the victim

was added in a kind of black list of users the

must be blocked. This check point is optional.

SECRYPT2013-InternationalConferenceonSecurityandCryptography

504

The solution proposed here tends to identify the

common interest of the attacker with some analytics

queries. Making these verifications before blocking

the target profile can be beneficial to the victims of

the coalition attacks. Of course these checking

should not prevent any human intervention of the

SN moderators to evaluate the credibility of a set of

abuse reports. We also propose a reputation and

penalties system for the attackers if the SN

moderator detects the coalition attack via our

solution. A kind of caution message can be sent to

the suspected attacker to warn him against a fake

abuse report action.

5.2 Preventing Automated DoS Attack

It is clear that the execution of the automated DoS

attack is more powerful and damaging than the

coalition attack. Few seconds are sufficient to block

any profile. The countermeasure is less complex

than the one proposed for the coalition attack. The

traditional client-side security challenge response

tests (Mirkovic, 2004) are to our opinion the most

appropriate solution. These solutions must be

applied during the creation of new SN accounts, then

during the abuse response sending. The challenges

will limit the creation of fake accounts, and the

generation abuse reports without a human

intervention.

6 CONCLUSIONS

In this paper we have formally identified a serious

vulnerability in the abuse reporting systems that are

currently deployed in most of the SN websites. We

first observed the problem in the real world where

ideological groups of users in different SNs are

permanently setting up coalition attacks based on a

particular misuse of the abuse reporting systems in

order to block other innocent users that are judged as

ideological enemies. We provided a technical

analysis of this attack then we proposed to automate

it in order to exploit this vulnerability through a DoS

attack. We developed a proof of concept exploiting

this vulnerability in the SN website Facebook that is

also considered as one of the most secure. Although

incomplete, the first results obtained clearly

demonstrate the damages that can be caused by such

DoS tools, especially if we upgrade the attack from a

DoS to a DDoS where (executing the attack

simultaneously). We propose two different

approaches to prevent against such attacks and

specially the coalition attack. The study is still at its

initial phase, we are not yet able to clearly define the

variable N representing the number of abuse reports

that will automatically block a user profile. More

advanced tests are currently executed to explore all

the dimensions of this vulnerability.

ACKNOWLEDGEMENTS

The research leading to these results has received funding

from the European Community's Seventh Framework

Program in the context of PPP Fi-Ware project and the

EIT – KIC Trust in the Cloud EU Project.

REFERENCES

Morozov, E., 2011. “The Net Delusion: The Dark Side of

Internet Freedom” (New York: Public Affairs, 2011)

Srivatsa, M., Xiong, L., Liu, L., 2005. “TrustGuard:

Countering Vulnerabilities in Reputation Management

for Decentralized Overlay Networks”, Proceeding of

the 14th international conference on World Wide Web

(WWW’05), New York, USA

Hoffman, K., Zage, D., Nita-Rotaru, C., 2007. “A Survey

of attacks on Reputation Systems”, Computer Science

Technical Report – Number 07-013 – Perdue

University (2007)

Tennenholtz, M., 2004 “Reputation Systems: An

Axiomatic Approach”, UAI '04 Proceedings of the

20th conference on Uncertainty in artificial

intelligence - Pages 544-551 - AUAI Press Arlington,

Virginia, United States 2004.

Cristani, M., Karafili, E. and Viganò, L., 2011. “Blocking

Underhand Attacks by Hidden Coalitions”, 3rd

International Conference on Agents and Artificial

Intelligence, Rome, Italy, 28-30, ICAART 2011.

Pauly, M., 2002 “A modal logic for coalition power in

games”. Journal of Logic and Computation,

12(1):149–166. (2002)

M. Pauly, “Logic for social software”. PhD thesis,

Institute for Logic Language and Computation,

University of Amsterdam. (2001)

Facebook, https://www.facebook.com/

Von Ahn, L., Blum, M., Hopper, N. and Langford, J.,

2003. “CAPTCHA: Using Hard AI Problems for

Security”. In Proceedings of Eurocrypt 2003, May 4-

8, 2003, Warsaw, Poland.

Mirkovic, J. and Reiher, P., 2004. “A taxonomy of DDoS

attack and DDoS defense mechanisms”. ACM

SIGCOMM 2004, Comput. Commun.

OWASP Zed Attack Proxy Project

Slashdot, http://tech.slashdot.org/story/11/04/15/1545213/

Crowdsourcing-the-Censors-A-Contest

AbusingSocialNetworkswithAbuseReports-ACoalitionAttackforSocialNetworks

505
