Transparent Persistence Appears Problematic for Software Maintenance

A Randomized, Controlled Experiment

Pietu Pohjalainen

Department of Computer Science, University of Helsinki, Helsinki, Finland

Keywords:

Transparent Persistency, Self-conﬁguring Software Architecture, Randomized, Controlled Experiment.

Abstract:

Information retrieval from a database is the backbone of many applications. For building object-oriented

systems with a relational persistence engine, a common approach is to use an object-to-relational mapping

library for handling the mismatch between object-oriented and relational data models. These components

should make the application programmer oblivious to the choice of relational database.

To study the effects of transparent persistency, we conducted a randomized, controlled study for 16 students,

who were given a number of maintenance tasks on a sample software. For half of attendees, the sample

software was written using the transparent persistency approach. For the second half the sample software used

a self-conﬁguring component for automatically generating database queries.

We found out that the group using transparent persistency were performing worse than the group using self-

conﬁgurative queries. Attendees in both groups were using the same amount of time for performing the given

maintenance tasks, but the transparent persistency group was outperformed by a factor of three in the number

of correct submissions. The use of transparent persistency turned out to be a major error source. This gives us

a reason to doubt the usefulness of transparent persistency in the long run.

1 INTRODUCTION

Relational databases are used for storing data in vir-

tually all kinds of information systems. Telephone

switching systems, e-commerce transaction systems,

human resources information systems and e-mail in-

dexing systems, for example, have implemented data

persistency by relying on relational database engines.

Although these engines often include some support

for building application logic into them, it is popu-

lar to build applications using a general purpose lan-

guage, such as Java or C#.

In these cases the way in which the relational

database is used is a major architectural decision. Us-

ing plain database interfaces, such as Java’s database

connectivity interface (Fisher et al., 2003) easily

leads to tedious work of manually implementing rou-

tines for storing and retrieving data to and from the

database. Some researchers estimate that the low-

level code for accessing a database can be up to 30%

of the total line count of a normal business application

written in direct access style (Atkinson et al., 1983;

Bauer and King, 2004). Manual labour is known

to be error-prone and have low productivity ﬁgures.

For this reason, many architects choose to use object-

to-relational mapping components, such as those de-

ﬁned by the Java persistency interface (DeMichiel and

Keith, 2007) to handle the mismatch between object-

oriented program logic and relational database mod-

els.

Object-to-relational mapping (ORM) components

aim to reduce the manual labour needed in build-

ing object-oriented database applications. Instead of

manually deﬁning database queries for retrieving ap-

plication data, an external component handles the

generation of the needed queries. This is done by

deﬁning mappings between application objects and

database tables. These mappings deﬁne how object-

oriented structures, such as inheritance, object collec-

tions, and other object links should be made persistent

in the database. The goal of this component is to lib-

erate the object-oriented programmer from thinking

at a relational database abstraction level. For this, the

we use the term transparent persistency.

Transparent persistency refers to the idea of data

persistency should not affect the way programmers

build the application logic. Instead, persistency

should be a modular aspect, as envisioned in aspect-

oriented programming (Kiczales et al., 1997). At ﬁrst

glance, this seems to be a clever idea: in many cases,

the routines needed for storing and retrieving data

from the database makes algorithms look unnecessar-

Pohjalainen P..

Transparent Persistence Appears Problematic for Software Maintenance - A Randomized, Controlled Experiment.

DOI: 10.5220/0004417900250035

In Proceedings of the 8th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE-2013), pages 25-35

ISBN: 978-989-8565-62-4

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

ily complex and cluttered.

However, the drawback of the approach is that the

exact workings of the software system are blurred,

since the database accessing code is faded away from

the working view of the programmer. Since transpar-

ent persistency removes the link between algorithms

using the data from the database and the accessing

code, programmers who are not intimately familiar

with the system may conceive an incorrect under-

standing of the system.

Self-conﬁguring components are a recently intro-

duced novel approach to building links between dif-

ferent software layers. The idea is to recognize au-

tomatically resolvable dependencies within the code-

base, and to implement corresponding resolver com-

ponents. This helps in maintenance, since instead of

the programmer manually following all the dependen-

cies in the event of a functionality change, the au-

tomated component does the task. Examples have

been implemented in areas of building consistent user

interfaces (Pohjalainen, 2010) and database queries

(Pohjalainen and Taina, 2008).

Currently, it is not very well known how these ar-

chitectural decision affect programmer performance.

To gain understanding on what works in practice, em-

pirical validation is needed. To better understand

the effect of transparent persistency’s consequence

for maintenance, we have formulated the following

research questions regarding development speed and

quality:

An initial hypothesis for introducing conﬁgur-

ing component that is based on meta-programming

on byte-code level would suggest that at least ini-

tially it would be harder and slower to produce cor-

rectly working code. Probably after a run-in pe-

riod, the programmers involved would learn to under-

stand the workings and responsibilities of the meta-

programming component. This leads us to formulate

a null hypothesis:

: Do self-conﬁguring components make it

faster to perform maintenance tasks?

: Do self-conﬁguring components produce

better quality in maintenance tasks?

: Do self-conﬁguring components make pro-

grammers more productive?

To gain initial insight in these questions, we con-

ducted a randomized, controlled experiment on us-

ing Java persistency interface for database queries. In

this experiment, the attending students were randomly

divided into two groups, the transparent persistency

group and the control group. Attendees were given

slightly modiﬁed versions of the same software and

were asked to perform given maintenance tasks upon

the software. We tracked the time for performing the

asked modiﬁcations. Each submission was afterwards

graded for correctness. Productivity is deﬁned as a ra-

tio of the number of correct submissions per hour used

on the tasks.

The rest of the paper is organized as follows. Sec-

tion 2 gives a short introduction to self-conﬁguring

software components, object-to-relational mappings

and implementation techniques used in the presented

experiment. Section 3 deﬁnes the used research

methodology. Section 4 shows results obtained in the

experiment. Section 5 discusses these ﬁndings. Sec-

tion 6 concludes the paper and outlines future work.

2 PRELIMINARIES

In this section we ﬁrst review the object-to-relational

approach to using databases in object-oriented pro-

grams. We then introduce self-conﬁguring queries in

the context of the example used in the experiment.

Object-to-relational mapping components are com-

monly used to allow developers concentrate to code

within one paradigm. The idea is that special map-

pings are used to translate an object’s persistent ﬁelds

into corresponding relational database concepts.

These mappings provide a placeholder for deﬁn-

ing handling rules for issues rising from the mismatch

between object and relational paradigms. Examples

of these problems are e.g. the problem of handling

inheritance, navigability of one-way object links ver-

sus bi-directionality of relational links, and represen-

tation of object collections, to name a few. The map-

ping also provides a place for deﬁning the fetching

rules for certain object classes. This is often a major

source of performance problems in applications using

the object-to-relational approach for persistency.

Title: String

Author: String

ISBN: String

Book Title

BookIdentiﬁer: Int

Book

< is instance

Figure 1: One-to-many mapping in the experiment applica-

tion.

The fundamental problem in using default rules in

database fetches is that most often the set of data ob-

jects being fetched from the database is context sen-

sitive. For example, let us consider a fragment of our

experiment’s class diagram that is presented in Figure

1. The model shows a one-to-many connection be-

tween a book title and a number of books. The idea is

to show that for each book title, its author name and

ISBN number are stored only once; and for each book

copy, there’s a distinct object in the system.

ENASE2013-8thInternationalConferenceonEvaluationofNovelSoftwareApproachestoSoftwareEngineering

The use case of listing all book titles in a given

database is implemented as Algorithm 1. This algo-

rithm fetches only objects of the BookTitle class.

Algorithm 1: List all book titles.

procedure PRINTTITLES(List allTitles)

for all title in allTitles do

print title.Author

print ": "

println title.Title

end for

end procedure

Another use case for this system is to count all

copies of a certain title. This is implemented as Algo-

rithm 2. This version needs to fetch not only objects

of the BookTitle class, but also to consult the Book

class as well.

Algorithm 2: List all book copies.

procedure PRINTBOOKS(List allTitles)

for all title in allTitles do

print title.Author

print ": "

println title.Title

cnt ← 0

for all book in title.Books do

println book.BookIdentifier

cnt ← cnt + 1

end for

println cnt + ” copies.”

end for

end procedure

Given these two use cases, using a default fetch-

ing rule for the BookTitle class is always somehow

wrong: if the default rule is to eagerly fetch Books

with its BookTitle, then the execution of Algorithm

1 is unnecessarily slow, since the algorithm does not

need all that information. However, if the default rule

is not to fetch associated books with their titles, then

Algorithm 2 cannot be executed unless the default

rule is overridden or some other internal magic is per-

formed.

A common approach in this case is to use the

Proxy design pattern (Gamma et al., 1995) to guard

against cases where the algorithm is requiring some

object data that is not fetched from the database. The

proxy represents the object’s external interface, and

upon usage of the object data, it generates the nec-

essary database queries needed to lazily retrieve that

data from the database.

This is a way to implement transparent persis-

tency: all algorithms can be written in an object-

oriented language, and it is the responsibility of the

object-to-relational mapping component to provide

the implementation for relational database queries.

The downside of this approach is that it is easy

to implement inefﬁcient algorithms, as the proxying

approach queries the database only at when a certain

object is ﬁrst accessed. This creates the n+1 queries

problem, which happens when traversing collections

of objects. The ﬁrst query to the database fetches the

root object. For each object link in the root object that

is being accessed by the traversal algorithm, a new

query is generated. Due to n + 1 round-trip queries to

the database, performance usually severely degrades.

For this reason, the object-to-relational mapping

frameworks provide means to explicitly specify a

query for fetching an initial data set. However, this

approach is arguably an inelegant solution, since it

breaks the promise of transparent persistency and

generates dependencies between the explicitly spec-

iﬁed query sites and actual data usage sites.

One solution to provide more precise control over

the fetched data set is to use self-conﬁguring database

queries (Pohjalainen and Taina, 2008). In this ap-

proach, the software contains a query-resolved com-

ponent, which analyzes the code that accesses the

database and estimates the right database query to use.

It is claimed that the component improves software

maintainability, since the database usage is made

more explicit, yet the dependencies between the data

accessing algorithms and data fetching code are auto-

matically resolved.

To the application programmer, the use of self-

conﬁguring database queries is shown by the need

to parametrize database access with the algorithm

that the queried data is being subjected upon. In

traditional transparent persistency, the programmer

fetches an initial object, e.g. a certain Title from

the database and then executes the handling code,

such as the one shown in Algorithm 2. With self-

conﬁguring queries, instead of providing an initial

guess for the needed data, the programmer gives the

name of the algorithm (PrintBooks in this case) to

the self-conﬁguring component. The self-conﬁguring

component analyzes the behavior of the algorithm

and provides an approximation of the required data

for running the algorithm with an optimal number of

database queries.

In our implementation, the self-conﬁguring query

component analyzes the byte code of the method in

the containing Java class. The conﬁgurator builds a

control-ﬂow graph of method execution, and includes

database joins to the generated query whenever a class

with object-to-relational mapping is encountered in

the control ﬂow. The control ﬂow of Algorithm 2 is

TransparentPersistenceAppearsProblematicforSoftwareMaintenance-ARandomized,ControlledExperiment

shown in Figure 2. For this control ﬂow, the self-

conﬁgurator deduces that for all BookTitles the at-

tributes Author and Title and for all Books the at-

tribute BookIdentiﬁer will be used during algorithm

execution.

Begin

BookTitle.Author

BookTitle.Title

Book.BookIdentiﬁer

Last

Booktitle?

Last Book?

BookTitle.Books

NoNo

Yes

End

Yes

Figure 2: Control ﬂow of persisted entities in Algorithm 2.

From the control ﬂow graph in Figure 2, the self-

conﬁgurator deduces that a query set of {book titles,

booktitle.books} will be a sufﬁcient query.

This approach is believed to give beneﬁts in two

ways: improved maintainability and improved mod-

ularity. Maintainability is improved, because the

database query site does not explicitly deﬁne what

data to fetch from the database, but instead the self-

conﬁguring query determines that. For this reason,

the database accessing algorithms can be changed

more easily, since dependence on the database query

site is automatically updated to reﬂect the updated al-

gorithm.

Modularity is improved because the one self-

conﬁguring component can handle a number of dif-

ferent usage sites. This is an improvement of the

traditional n-tiered software architecture, where the

database access layer needs to contain functionality

speciﬁc to business logic. In the context of this exper-

iment, the traditional way would be to implement one

database query that fetches all book titles for execut-

ing Algorithm 1 and another query that joins all the

book titles with the books for running Algorithm 2.

3 METHODOLOGY

To gain understanding on how this approach works

in practice, we recruited a sample of 16 students to at-

tend a randomized, controlled experiment. About half

of the students were freshmen (n=10), and the rest

were in their ﬁnal bachelor year or master’s students

(n=6). Before attending the test, a two-hour lecture on

concepts of relational databases, object-oriented pro-

gramming and object-to-relational mapping tools was

given to each participant.

We built two versions of a simple library book-

keeping application. The application consists of ﬁve

classes that are programmed to manage book titles,

books, lenders and book loans in a database. Each

attendee is randomly assigned to one of the versions,

in which he stays during the whole experiment. The

baseline application contains a functionally working

version of the software with the same set of function-

ality implemented in both of them. For example, use

cases for listing all book titles, as implemented in Al-

gorithm 1 and for listing all books, as implemented

in Algorithm 2 are contained in the package given to

each test subject.

The ﬁrst version (group ’transparent persistency,

TP’) of the sample application was written in the

style of transparent persistency: the complexity of

handling database queries is hidden behind the per-

sistency framework’s internals, which in this case

was to use bytecode-instrumented proxying imple-

mentation of database queries. In the second ver-

sion (group ’self-conﬁgred, SC’), the application con-

tained method calls to self-conﬁguring instructions to

automatically prefetch the correct objects from the

database, and to rewrite the corresponding fetching

query.

In the variant given to the self-conﬁgured group,

the database access is not fully obscured away. The

database access component is parametrized with the

actual algorithm that is going to be executed. The

component analyzes the algorithm and produces the

database query to be used at the subsequent database

access time. This construct helps to remove depen-

dencies between database access code and the ac-

tual algorithms that are being executed. A change in

the algorithm is automatically reﬂected by the self-

conﬁguring component, thus removing the need to

manually update the database query.

The initial application consists of a functionally

consistent set of program code. The test subjects are

asked to perform modiﬁcations to the sample applica-

tion; depending on the skill and speed of the attendee,

up to 7 functional tasks can be performed during the

trial. Each task was time-boxed, meaning that the at-

ENASE2013-8thInternationalConferenceonEvaluationofNovelSoftwareApproachestoSoftwareEngineering

tendee is asked to return his version even if it is in-

complete when the time is up. If an attendee thinks

that he/she cannot be performing any more tasks, he

is free to leave at any given point. Attendees were

awarded with credit units or extra points to a course

test regardless of how many tasks they opted to com-

plete during the test. All test subjects were physi-

cally present in the classroom during the experiment.

The submission mechanism was to send the source

code for each application version via e-mail after each

completed task.

To moderate the application complexity, the sam-

ple application was written as a command-loop tool.

In the following code listings we will illustrate the dif-

ferences between the two groups’ variants using the

following notation: line preﬁx ”TP” notiﬁes that this

line is present only in the transparent persistency vari-

ant. ”SC” lines are present in the self-conﬁgured vari-

ant. ”C” lines are common to both of the variants.

Using this notation, the command line loop for the

use case of listing all book copies in the database is

implemented as listed in Program 1.

Program 1: Two variants of the list books use case.

C: switch(cmd) {

C: [..]

C: case "list books":

SC: String alg="BookTitles.PrintBooks";

SC: Resolver r = new Resolver(alg);

SC: bookTitles.fetchFromDatabase(r);

TP: bookTitles.fetchFromDatabase();

C: bookTitles.printBooks();

C: break;

C: }

As can be seen in the listing, the only difference

between the two variants is that the self-conﬁgured

version contains a stronger hint of the fact that this

command is accessing the database. The Resolver

component is parametrized with the name of the al-

gorithm that is going to be executed subsequently. It

is important to note that in the transparent variant,

although the name of the method suggests that the

method is going to access the database, there is no

explicit link between the data-fetching code and the

algorithm used to print out the books. Consequences

of this omission are further explored later in the re-

sults section.

In the resolver version, the component analyzes

the internal workings of the method that is given as

an argument and produces an estimate of what data

objects should be fetched. This gives the maintainer a

stronger binding between the data-fetching code and

the algorithm used to process the fetched data.

The fetchFromDatabase routine as listed in Pro-

gram 2 also differs a bit in the two variants. The

variant for the transparent persistency group creates a

database query by using the object querying language

deﬁned in the Java persistency interface. This query

fetches an initial set of book titles from the database.

In this variant when Algorithm 2 execution arrives to

a book copy that has not yet been fetched from the

database, the automatically generated proxy instance

generates a new query to get the missing information.

Program 2: Two variants of database fetching code.

SC: void fetchFromDatabase(Resolver r) {

TP: void fetchFromDatabase() {

TP: Query q;

TP: q = createQuery("from BookTitle");

SC: Criteria q = r.resolve();

C: bookTitles.clear();

C: List<BookTitle> list = q.list();

C: for(BookTitle bt : list)

C: bookTitles.add(bt);

C: }

In the self-conﬁguring variant, Algorithm 2 is

given as an argument to the resolver component. The

resolver analyzes the code of the algorithm and initi-

ates a database query to fetch the required data. If the

resolver happens to underestimate the required set of

objects, the normal proxy-based fallback is used as a

safeguard. At this point, it is important to note that the

self-conﬁgured version does not contain the match-

ing between database and business logic, but instead

it operates in the business logic domain.

The essential difference between the two variants

is the degree of how explicit the database query is. In

the transparent persistency variant, the database ac-

cess code is minimized, with the design goal of reduc-

ing the mental load of the programmer, as he should

not be worrying about how to access a database. This

can also be misleading, since there is no hint of the

mechanism of how the persistency framework should

be used. In the control group variant, the database ac-

cessing is more explicit, since the algorithm calling

site generates the database query component before

actually executing the query.

Armed with the initial example cases of Algo-

rithms 1 and 2 given to the test subjects, they are

asked to implement a number of maintenance tasks to

the software. All of the tasks follow the same pattern:

fetch some data from the database and then print

out information. Task 0, which was to change the

source code character set to UTF-8, was not graded.

It was used to give the attendees an opportunity to

gain understanding of the sample application and

to practice the submission procedure. The tasks are

TransparentPersistenceAppearsProblematicforSoftwareMaintenance-ARandomized,ControlledExperiment

summarized below:

Identiﬁer Task description

Task 0 Fix source code charset (not graded,

used to practice the submission proce-

dure)

Task 1 List all book loaners in the system

Task 2 List all book loans in the system

Task 3 Fetch speciﬁc book title by its ISBN

Task 4 Modify task 3 result to print out all

books associated with the given title

Task 5 Fetch speciﬁc lender by his social secu-

rity number

Task 6 Modify task 5 result to print out all

books borrowed by this lender

Task 7 Modify the list of book titles to print out

all lent books associated with that title

The tasks list contains maintenance tasks that can

be classiﬁed as adaptive maintenance in IEEE Std

14764-2006 terms (IEEE14764, 2006). Each of the

tasks delivers an added functionality that is requested

to make the sample software able to be a better ﬁt for

its task of handling a database of library books. Each

of the tasks are implementable without inducing new

requirements or other needs for architectural changes.

4 RESULTS

We graded each submission based on correctness on

a dichotomous scale: a correct submission to a given

task is programmed to connect to the database, fetch

certain data, and print out corresponding results. Mi-

nor stylistic problems, such as output formatting did

not affect the grading.

In the freshmen group, the assignments were gen-

erally considered to be hard. This is understandable,

since outside the persistency code, the implementa-

tion followed object-oriented principles in both ver-

sions. However, even in this group, some test subjects

succeeded in getting some of the tasks submitted cor-

rectly.

The second problem to occur frequently among

all test subjects was the failure to fetch the database

correctly. Often the modiﬁed application seemed to

work perfectly, but an underlying problem (”a bug”)

was introduced by accidentally re-using the applica-

tions internal data instead of targeting the query to

the database. This problem was most often seen in

the transparent persistency group. We believe this

to be the consequence of the interface between busi-

ness logic and database access code. Since the busi-

ness logic explicitly deﬁnes only the initial object

of the processed object graph, thus making all other

database access translucent, the students often failed

to correctly handle the cached versions of the objects.

Other programming errors included various incor-

rect structures, such as null pointer exceptions, cache-

handling errors etc. Each of these were unique to the

given submission.

For each test subject, we noted the state of his

studies (freshman/advanced), randomization group

(transparent persistency / self-conﬁgured), time spent

on each submission (rounded to next 5 minutes) and

the correctness of the submission. Overall, these re-

sults are shown in Figure 3. In the ﬁgure, the symbol

Xis used to show a correct submission and the sym-

bol 7 shows an incorrect submission. Each attempt

was also followed by a submission. An empty box

means that the test subject did not attempt the task in

question.

To study the productivity between the two ap-

proaches, we measured the time for producing a sub-

mission to all given tasks. However, we are analysing

this information in the advanced group only. The

test subjects in the freshmen group are omitted due

to their submissions having such low success rate;

there is only one pair of submissions where two test

subjects belonging to different randomization groups

have been able to produce a correct submission to the

corresponding task (test subjects #7 and #8 for task

3).

In the advanced students’ group, there was one

case, where the test subject had to leave early due

to a medical condition before he was able to send a

single submission. He was randomized to the self-

conﬁguring. Due to the nature of that situation, his

results are not included in the analysis. Outside this

case, no test subject left the experiment prematurely.

4.1 RQ1

Given this information, we can return to our research

questions. RQ1 proposes that self-conﬁguring queries

make it faster to perform maintenance tasks. Accord-

ing to Figure 3, the test subjects in the transparent

persistency group returned a total number of 27 sub-

missions, be they correct or incorrect. The test sub-

jects in the self-conﬁgured group returned 33 submis-

sions. There are an equal number of subjects in each

of the randomization groups, and the maximum al-

lowed time was the same for everybody.

The self-conﬁguring turned in more submissions,

but the difference between the two groups is small.

From this viewpoint, we cannot support the idea

of transparent persistency making the completion of

these maintenance tasks faster, but the self-conﬁgured

group does not get a decisive victory, either.

ENASE2013-8thInternationalConferenceonEvaluationofNovelSoftwareApproachestoSoftwareEngineering

Subject # Study state Randomization Task 1 Task 2 Task 3 Task 4 Task 5 Task 6 Task 7

#1 freshman SC 7 7

#2 freshman TP 7 7

#3 freshman TP 7

#4 freshman SC X 7

#5 freshman SC 7 X 7

#6 freshman TP 7 7 7

#7 freshman SC X 7 X

#8 freshman TP 7 7 X

#9 freshman SC 7 7 7

#10 freshman TP 7 7 7

#11 advanced SC X X X X X X X

35 45 35 10 5 10 5

#12 advanced SC X X 7 X X 7 X

30 55 15 30 15 30 15

#13 advanced TP X 7 X X X 7

45 50 20 10 20 15

#14 advanced SC X X X X X X X

30 45 10 10 10 10 10

#15 advanced TP 7 7 7 7 7

55 35 20 15 20

#16 advanced TP 7 7 7

45 30 40

#17 advanced (*)

Figure 3: Summary of results: Xfor a correct submission, 7for incorrect; number below the result indicates minutes spent on

the task.

4.2 RQ2

Figure 4 summarizes the frequency of correct sub-

missions. For example, two attendees in the self-

conﬁgured group got zero submissions correct and six

attendees in the transparent persistency group got zero

submission correct.

0" 1" 2" 3" 4" 5" 6" 7"

!A#endee!count!

Number!of!correct!submissions!

Self.conﬁgured"

Transparent"persistency"

Figure 4: Count of correct submissions for both groups.

The grading distribution in Figure 4 leads us to

formulate the null hypothesis for RQ2:

: Transparent persistency makes it easier

to produce correct database handling code than

self-conﬁguring queries.

When the test data is normally distributed, a

parametrized test should be used to determine dif-

ferences between populations. Otherwise, a non-

parametric test should be used (Robson, 2011, p. 450-

452). Our data is based on human behavior, and

could be believed to be normally distributed. How-

ever, the results look like a non-normal distribution.

For this reason, we calculated both parametric and

non-parametric statistical tests.

Both the one-tailed independent samples t-test and

Mann-Whitney U test result a p-value of α < 0.05,

giving a suggestion that the null hypothesis needs to

be rejected. Informally, the self-conﬁgured group was

performing much better than the transparent persis-

tency group: two attendees who got assigned the self-

conﬁguring, query rewriting-based base software got

all seven graded tasks implemented correctly. On the

other hand, six attendees using the traditional trans-

parent persistency failed to produce a single correct

submission.

4.3 RQ3

Finally, as a measure of productivity, we consider

the time consumed in programming tasks in the non-

freshmen group. The times for producing a correct

submission (n=23) varied between 5 and 55 minutes.

TransparentPersistenceAppearsProblematicforSoftwareMaintenance-ARandomized,ControlledExperiment

There was no statistically signiﬁcant difference in

time consumed between the two groups.

As the number of correctly returned submission

series is low, statistical analysis of these series would

not serve a purpose. As a reference information, when

ordering the correct by-task submissions as a speed

contest, all test subjects in the self-conﬁgured group

were producing submissions faster, on average.

We deﬁned productivity as a number of correct

submissions per time consumed. Thus, for an indi-

vidual we calculate his productivity index as

∑

i=1

time

∑

i=1

corr

where the variable time

refers to the time for produc-

ing the answer for task i and corr

is 1 for a correct

answer and 0 for an incorrect answer in task i. This

formula slightly favors the productivity of incorrect

answers, since the time needed to rework an incor-

rectly piece of software, as would happen in a real-

world software development situation, is not included

in this productivity index.

Applying this formula to the test subjects in the

advanced group yields a productivity index of 105

minutes per correct task submission in the transpar-

ent persistency group. For the self-conﬁgured group,

the index stands at 24 minutes.

For producing correctly working code, the self-

conﬁgured group outperformed the transparent persis-

tency group by a factor of four.

4.4 Threats to Validity

We have found a statistically signiﬁcant effect be-

tween two alternative ways of querying a database in

an object-oriented program. However, a number of

threats to the validity of this ﬁnding do exist.

In general, a controlled experiment like this differ-

entiates from industrial use in the scope of time that

can be spent in understanding the associated technolo-

gies. In an industrial setting, programmers usually

work with the same technology stack for months or

years. In this study, some of the test subjects were ex-

posed to the technologies for the ﬁrst time. However,

some of this concern can be argued to be mitigated

by the randomization process; these technologies can

be assumed to be equally unknown to both groups. A

related problem is the small size of the software used

in the experiment. It might be the case that the com-

plexity of transparent persistency pays off only after a

certain software size has been achieved.

Another concern is that using students in con-

trolled experiments limits the generalizability of re-

sults to a industrial setting. However, previous stud-

ies, e.g. (Arisholm and Sjoberg, 2004) have found a

high correspondence between (1) undergraduate and

junior programmers; and (2) graduate and senior pro-

grammers in terms of understanding object-oriented

programming, which can be interpreted to mean that

at least half of the experiment population were up to

industrial standards. This distribution of attendees is

probably not fully unrealistic, since companies often

use junior programmers to perform maintenance tasks

(Gorla, 1991). Another interpretation of our work is

that the ﬁnding in (Arisholm and Sjoberg, 2004) is

probably valid: the advanced group in our study was

able to grasp the functionality of the object-oriented

system, while the freshmen group clearly had prob-

lems understanding it.

Our third concern is the the sample size, which

is small. We conducted this study on 17 students,

of whom 10 were in their ﬁrst year, and 7 students

were more advanced. Since one student in the ad-

vanced group was excluded from the experiment due

to a medical condition, the total number of test sub-

jects is 16. Due to the small sample size, individual

performance shows a large role in our statistical anal-

ysis.

Our fourth concern regards the use of number of

submissions as productivity measure. Most of the

tasks are equidistant in substance in the sense that for

most tasks, the task n is not dependent on whether

he succeeds in n + 1. For tasks T 4 and T 6 there is

a dependency to the previous task. This dependency

plays some role for subjects #12 and #13. Subject #12

failed in task T3, but was able to ﬁx the problem in T4

submission. He also got task T5 correct but failed his

task T6. The latter dependency is present for subject

#13 as well.

5 DISCUSSION AND RELATED

WORK

The use of transparent persistency for storing objects

is not a new idea. A number of systems for vari-

ous languages and programming environments have

been described in the literature; (Atkinson et al.,

1983; Atkinson and Morrison, 1995; Bauer and King,

2004), to name a few.

Similarly to the self-conﬁgured queries, re-

searchers have used the program source as a source

model for model transformations in various contexts.

For example when building portable interpreters, the

opcode deﬁnitions can be implemented in the inter-

ENASE2013-8thInternationalConferenceonEvaluationofNovelSoftwareApproachestoSoftwareEngineering

preter implementation language. When the deﬁni-

tion is compiled, the end result, in byte code or other

low-level representation can be used as a building

block when interpreting the opcode in question (El-

liott et al., 2003; Yermolovich et al., 2008).

Using program analysis for extracting database

queries has been proposed by various researchers. We

used the component documented in previous work

(Pohjalainen and Taina, 2008), using the same object-

to-relational mapping framework, Hibernate (Bauer

and King, 2004). In addition to this style, Ibrahim and

Cook have proposed a dynamically optimizing query

extractor (Ibrahim and Cook, 2006). Wiedermann et.

al have implemented a version which combines static

and dynamic techniques (Wiedermann et al., 2008).

In the simple examples used in this experiment, a sim-

ple analyzer was able to deduce the required queries.

However, when the business logic involves more com-

plex decisions, the automated self-conﬁguring com-

ponent needs to be updated to be able to handle the

more complex case. In a way, the situation resem-

bles the full-employment theorem of compiler writ-

ers (Rice, 1953): since the business logic can be ar-

bitrarily complex, the evolution for implementations

of automated resolvers are restricted by laws of eco-

nomics rather than some self-conﬁgurator being opti-

mal to every case.

Although various systems for implementing trans-

parent persistency have been available for decades,

it seems that its actual usage patterns have not been

studied very well. This implementation was ini-

tially employed in an industrial project for building

a product-line for provisioning governmental mobile

subscriptions (Pohjalainen, 2011), where the need for

modular constructs was critical to development suc-

cess and transparent persistency turned out to lack the

support for efﬁcient modularity. However, accord-

ing to our best knowledge, comparisons of the effect

of transparent persistency versus any alternative have

not been empirically studied so far. Considering the

fact that transparent persistency is a frequently em-

ployed technique in industrial software engineering,

the lack of empirical studies is a surprise.

The use of orthogonal, transparent persistency can

be seen as a specialized case of modularizing orthog-

onal features. To relate our ﬁndings, we can refer to

literature on empirical studies of aspect-oriented pro-

gramming (Kiczales et al., 1997). We can consider

transparent persistency to be one of the cross-cutting

aspects of the software.

The empirical response to productivity in aspect-

oriented programming seems to be mixed. For exam-

ple, in (Bartsch and Harrison, 2008), the researchers

were unable to ﬁnd any positive impact of using as-

pect orientation for building maintainable and easier-

to-comprehend software.

Kulesza et al. studied the use of aspect-oriented

programming for a maintenance task (Kulesza et al.,

2006). They implemented two similar systems, the

ﬁrst one in an object-oriented fashion and the second

one in an aspect-oriented fashion and compared both

systems’ internal metrics, such as size, coupling and

cohesion, before and after a speciﬁed maintenance

task. Their conclusion is that the aspect-oriented style

was superior in terms of observed software character-

istics. They did not measure the time spent on pro-

ducing the different versions of the software, nor the

time spent on implementing the maintenance tasks.

Thus, productivity of the maintenance task cannot be

assessed. Contrary to our study, the person doing the

maintenance task was presumably an expert program-

mer and familiar with the system being maintained.

In our setting we had a sample of junior programmers

performing a series of maintenance tasks on a previ-

ously unknown system.

Endrikat and Hanenberg measured the time for

building a system and then performing a number of

adaptive maintenance tasks on a number of test sub-

ject (Endrikat and Hanenberg, 2011). For many of

the tasks, the object-oriented way in the control group

was faster, but for combined build+maintenance time

they suggest that aspect orientation can be beneﬁcial.

Another, indirect ﬁnding on this study was the

poor programming performance in the freshmen

group: 70% of test subjects in this group were hav-

ing serious problems with the experiment. Although

they had completed the ﬁrst programming courses of-

fered by the university and were given a fully func-

tioning system, they failed to perform even simplest

modiﬁcations to it. For this reason the university

has already adjusted our ﬁrst programming courses

to use a new studying method based on extreme ap-

prenticeship (Vihavainen et al., 2011; Vihavainen and

Luukkainen, 2013). In future work, it would be inter-

esting to compare how these adjustments to teaching

methodologies have affected freshmen programming

skills in maintenance tasks.

6 CONCLUSIONS

We performed a randomized, controlled experiment

to assess the usefulness of transparent persistency. In

the experiment we built two versions of a small sam-

ple application and asked a number of test subjects

to perform a number of maintenance tasks upon their

software variant.

We measured the time used to do these main-

TransparentPersistenceAppearsProblematicforSoftwareMaintenance-ARandomized,ControlledExperiment

tenance tasks and related them to successful sub-

mission rates. As a result, we concluded that the

self-conﬁgured group was performing much better in

terms of producing correctly behaving code.

In terms of correctly returned submissions, the

self-conﬁgured group outperformed the transparent

persistency group by a factor of three. This result is a

statistically signiﬁcant difference (p value α < 0.05)

between the two populations.

In productivity, the self-conﬁgured group outper-

formed the transparent persistency group by a factor

of four: on average, the self-conﬁgured group was

able to produce a correct submission in under half an

hour. In the transparent persistency, on average it took

almost two hours to do the same. However, due to the

low sample size, we did not perform any statistical

analysis on productivity.

This result casts a shadow of disbelief on the con-

cept of transparent persistency: if the application is

going to access a database, it probably is not a good

idea to try to disguise its functionality to be something

else. This disguise seemed to be the main source of

program miscomprehension within the test subjects in

the transparent persistency group. However, the small

sample application limits the generalizability of the

result. Experiments with larger software and larger

populations are needed to understand the usefulness

of transparent persistency for software development.

On the other hand, the result gives an initial empirical

validation of the usefulness of using self-conﬁguring

software components to reduce the maintenance effort

and to improve architectural modularity.

REFERENCES

Arisholm, E. and Sjoberg, D. I. K. (2004). Evaluating

the effect of a delegated versus centralized control

style on the maintainability of object-oriented soft-

ware. IEEE Trans. Softw. Eng., 30(8):521–534.

Atkinson, M. and Morrison, R. (1995). Orthogonally per-

sistent object systems. The VLDB Journal, 4(3):319–

402.

Atkinson, M. P., Bailey, P. J., Chisholm, K., Cockshott,

W. P., and Morrison, R. (1983). An approach to per-

sistent programming. Comput. J., 26(4):360–365.

Bartsch, M. and Harrison, R. (2008). An exploratory study

of the effect of aspect-oriented programming on main-

tainability. Software Quality Control, 16(1):23–44.

Bauer, C. and King, G. (2004). Hibernate in Action (In

Action series). Manning Publications Co., Greenwich,

CT, USA.

DeMichiel, L. and Keith, M. (2007). JSR 220: Enterprise

JavaBeans 3.0. Technical report, Sun Microsystems.

Elliott, C., Finne, S., and de Moor, O. (2003). Compiling

embedded languages. Journal of Functional Program-

ming, 13(2).

Endrikat, S. and Hanenberg, S. (2011). Is aspect-oriented

programming a rewarding investment into future code

changes? A socio-technical study on development and

maintenance time. In Proceedings of IEEE 19th In-

ternational Conference on Program Comprehension,

ICPC’11, pages 51 –60.

Fisher, M., Ellis, J., and Bruce, J. C. (2003). JDBC API

Tutorial and Reference. Pearson Education, 3 edition.

Gamma, E., Helm, R., Johnson, R. E., and Vlissides,

J. (1995). Design Patterns: Elements of Reusable

Object-Oriented Software. Addison-Wesley, Reading,

MA.

Gorla, N. (1991). Techniques for application software

maintenance. Inf. Softw. Technol., 33(1):65–73.

Ibrahim, A. and Cook, W. R. (2006). Automatic prefetch-

ing by traversal proﬁling in object persistence archi-

tectures. In Proceedings of the 20th European confer-

ence on Object-Oriented Programming, ECOOP’06,

pages 50–73, Berlin, Heidelberg. Springer-Verlag.

IEEE14764 (2006). International Standard - ISO/IEC

14764 IEEE Std 14764-2006 software engineering

#2013; software life cycle processes #2013; mainte-

nance. ISO/IEC 14764:2006 (E) IEEE Std 14764-

2006 Revision of IEEE Std 1219-1998), pages 1–46.

Kiczales, G., Lamping, J., Mendhekar, A., Maeda, C.,

Lopes, C. V., Loingtier, J.-M., and Irwin, J. (1997).

Aspect-oriented programming. In Proceedings of the

11th European Conference on Object-Oriented Pro-

gramming, ECOOP’97, pages 220–242.

Kulesza, U., Sant’Anna, C., Garcia, A., Coelho, R., von

Staa, A., and Lucena, C. (2006). Quantifying the

effects of aspect-oriented programming: A mainte-

nance study. In Proceedings of 22nd IEEE Interna-

tional Conference on Software Maintenance, ICSM

’06, pages 223 –233.

Pohjalainen, P. (2010). Self-conﬁguring user interface com-

ponents. In Proceedings of the 1st International Work-

shop on Semantic Models for Adaptive Interactive

Systems, SEMAIS ’10, pages 33–37, New York, NY,

USA. ACM.

Pohjalainen, P. (2011). Bottom-up modeling for a software

product line: An experience report on agile modeling

of governmental mobile networks. In Proceedings of

15th International Software Product Line Conference,

SPLC’11, pages 323–332.

Pohjalainen, P. and Taina, J. (2008). Self-conﬁguring

object-to-relational mapping queries. In Proceedings

of the 6th international symposium on Principles and

practice of programming in Java, PPPJ ’08, pages 53–

59, New York, NY, USA. ACM.

Rice, H. G. (1953). Classes of recursively enumerable sets

and their decision problems. Trans. Amer. Math. Soc.,

74:358–366.

Robson, C. (2011). Real World Research: A Resource for

Users of Social Research Methods in Applied Settings.

John Wiley & Sons.

Vihavainen, A. and Luukkainen, M. (2013). Results from

a three-year transition to the extreme apprenticeship

method. In To appear in Proceedings of the The 13th

ENASE2013-8thInternationalConferenceonEvaluationofNovelSoftwareApproachestoSoftwareEngineering

IEEE International Conference on Advanced Learn-

ing Technologies, ICALT ’13.

Vihavainen, A., Paksula, M., and Luukkainen, M. (2011).

Extreme apprenticeship method in teaching program-

ming for beginners. In Proceedings of the 42nd ACM

technical symposium on Computer science education,

SIGCSE ’11, pages 93–98, New York, NY, USA.

ACM.

Wiedermann, B., Ibrahim, A., and Cook, W. R. (2008). In-

terprocedural query extraction for transparent persis-

tence. In Proceedings of the 23rd ACM SIGPLAN con-

ference on Object-oriented programming systems lan-

guages and applications, OOPSLA ’08, pages 19–36,

New York, NY, USA. ACM.

Yermolovich, A., Gal, A., and Franz, M. (2008). Portable

execution of legacy binaries on the Java virtual ma-

chine. In Proceedings of the 6th international sym-

posium on Principles and practice of programming in

Java, PPPJ ’08, pages 63–72, New York, NY, USA.

ACM.

TransparentPersistenceAppearsProblematicforSoftwareMaintenance-ARandomized,ControlledExperiment
