Challenges of Model-driven Modernization

An Agile Perspective

Stavros Stavru

, Iva Krasteva

and Sylvia Ilieva

3,1

Faculty of Mathematics and Informatics, Sofia University St. Kliment Ohridski, James Bouchier Str. 5, Sofia, Bulgaria

Rila Solutions, Acad. G. Bonchev Str., bl. 27, Sofia, Bulgaria

IICT-BAS, Acad. G. Bonchev Str., bl. 2, Sofia, Bulgaria

Keywords: Agile Software Development, Software Modernization, Software Migration, Model-Driven Development,

Model-Driven Modernization, Systematic Review.

Abstract: Software organizations are nowadays facing increased demand for modernizing their legacy software

systems using up-to-date technologies. The combination of Model-Driven Development and delivery

models like Cloud and Software as a Service have become a very promising approach for software

modernization that possesses a lot of advantages, including great deal of automation and reuse of system

functionality. However, the use of such new and immature technologies is very challenging and requires a

comprehensive methodology for their seamless application within the software modernization projects.

When developing such methodology, questions on whether agile methods and techniques should be

incorporated and what could be the benefits and implications from that become of particular interest. To

help answering these questions, the paper evaluates the potential of agile methods and techniques to address

the challenges of Model-Driven Modernization. The challenges are extracted through a systematic review of

the existing body of literature on Model-Driven Development and Software Modernization, and the

evaluation is conducted through the Delphi technique. As a result, a ranked list of applicable agile

techniques is proposed and suggestions for their use in Model-Driven Modernization are made.

1 INTRODUCTION

Software organizations are continuously pressured

by their dynamic and highly competitive

environments to modernize. As rebuilding legacy

systems from scratch could require a huge

investment in time and efforts, new and more

lightweight modernization approaches are needed.

With the growing popularity of Service-Oriented

Architecture, the reuse of a legacy system by

exposing its functionality through services was

identified as a feasible and very promising

modernization approach. This resulted in various

service-oriented methodologies which were partially

or specifically focused on software reuse. Such

methodologies include the Service Migration and

Reuse Technique developed by Carnegie Mellon and

Software Engineering Institute (Lewis et al., 2005),

Service-Oriented Analysis and Design and Service-

Oriented Modeling and Architecture proposed by

IBM (Arsanjani, 2004); (Zimmermann et al., 2004),

Service Architecture Engineering (Butler, 2007),

Service Oriented Development of Applications

published by Gartner (Plummer, 2001) and the SOA

Migration Framework (Razavian and Lago, 2009).

Although Service-Oriented approaches were notable

improvement in terms of time and effort needed to

modernize, there were still many issues, mostly

concerned with the lack of in-depth knowledge on

the migrated system and its obsolete and

heterogeneous technologies and platforms. To

overcome these challenges, model-driven techniques

and tools were also incorporated. By turning models

into primary artefacts of the modernization process,

researchers and practitioners were expecting to

automate or semi-automate many of the

cumbersome activities, including the extraction of

knowledge from the legacy system, the development

of component architectures and detailed platform

specific design, and even the generation of specific

platform implementations. However, model-driven

methodologies for software modernization are still

scarce. They were mostly part of a small number of

industrial and research projects, such as MOMOCS

219

Stavru S., Krasteva I. and Ilieva S..

Challenges of Model-driven Modernization - An Agile Perspective.

DOI: 10.5220/0004317502190230

In Proceedings of the 1st International Conference on Model-Driven Engineering and Software Development (MODELSWARD-2013), pages 219-230

ISBN: 978-989-8565-42-6

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

(www.momocs.org), SOAMG (www.soamig.de),

MOOSE (www.moosetechnology.org), MoDisco

(www.eclipse.org/modisco), and various initiatives

of the Object Management Group, including

Architecture-Driven Modernization (ADM) and

Model Driven Architecture (MDA). However, they

provide only partial support for Model-Driven

Modernization (MDM) or are in their earliest stage.

REMICS (REuse and Migration of legacy

systems to Interoperable Cloud Services) is an EU

FP7 research project with the objective of supporting

the modernization of legacy systems to service

clouds by providing a model-driven methodology

and tools. REMICS proposes to improve existing

model-driven approaches (such as OMG’s MDA and

ADM) and extend them when needed to provide a

holistic view to migration that covers the whole

process with a methodology, tools, languages and

transformations (Mohagheghi et al. 2010).

Agile methods have been successfully applied in

software industry in the recent decade (Dyba and

Dingsoyr, 2009). During that period their adoption

has span from small development projects with low

risk and criticality to large distributed projects in

critical application domains such as banking and

automotive industry. Recently, a number of studies

on the applicability of agile methods and techniques

in the areas of Model-Driven Development,

Software Modernization, Service-Oriented

Architecture and Cloud Computing have been

published (Qumer and Henderson-Sellers, 2007);

(Abbattista et al., 2009); (Picek, 2009); (Prakash,

2010); (Zhang and Patel, 2011); (Matinnejad, 2011).

This paper further enlarges the existing body of

research by answering the following research

questions:

RQ1: Which agile techniques could add value to a

given MDM methodology on the Service Clouds?

RQ2: How do agile techniques address the

challenges of MDM on the Service Clouds?

In order to answer the above questions we propose a

systematic approach for reviewing the challenges for

MDM on the Service Clouds and an evaluation of

various agile techniques in terms of their potential to

address these challenges. The challenges that were

reviewed are extracted from four fields related to

MDM and Service Clouds, namely Model-Driven

Development, Software Modernization, Service-

Oriented Architecture and Cloud Computing. In

order to provide particular focus for this study, we

present only the first two fields in this paper, while

the challenges from the other two fields are

presented in (Stavru et al., 2012). The three main

contributions of this paper are: (1) the identification

and systematization of the challenges for MDM; (2)

the discussion on the possible implications of these

challenges on the incorporation of agile methods and

techniques into the MDM process; and (3) the

recommendation of agile techniques which could

address the identified challenges.

The paper is organised as follows: Section 2

describes the methodology used for conducting

literature review and evaluating agile techniques;

Section 3 presents the challenges from the fields of

Model-Driven Development and Software

Modernization, extracted by the review process and

relevant for the MDM on the Service Clouds;

Section 4 discusses the results of the evaluation of

agile techniques and their potential to address the

identified challenges; and Section 5 concludes the

paper and outlines directions for future research.

2 METHODOLOGY

The methodology used to assess Agile Software

Development in the context of MDM consists of two

consecutive phases. During the first phase, the

challenges of both fields of Model-Driven

Development and Software Modernization were

extracted, analyzed and synthesized through a

systematic literature review (Brereton et al., 2007).

Then, in the second phase, using the Delphi method

(Helmer and Helmer-Hirschberg, 1983), various

agile techniques (taken from XP and Scrum) were

evaluated by a panel of experts for their potential to

address the identified challenges. The methodology

and its phases are thoroughly described in the next

paragraphs.

2.1 Review

Systematic review provides an analytical review

scheme, which is necessary for evaluating the

contribution of a given body of literature. It employs

an objective, transparent and reproducible procedure

for the identification, appraisal, selection and

synthesis of studies highly relevant to specific

research questions and thus improves the quality of

the review process and its outcome (Brereton et al.,

2007).

The systematic review, presented in this paper,

was conducted following the approach proposed by

Kitchenham (Kitchenham, 2004), taking into

account also her guidelines on performing

systematic reviews in software engineering

(Kitchenham, 2007). Given the review objective for

providing a comprehensive overview and a

MODELSWARD2013-InternationalConferenceonModel-DrivenEngineeringandSoftwareDevelopment

220

conceptual, rather than an empirical, consolidation

of the literature in regard to the challenges of MDM,

the data analysis was limited to descriptive, rather

than statistical (meta-analysis) methods and data

synthesis was conducted using qualitative methods

(or meta-ethnographic methods in particular). The

report of the conducted review will be briefly

summarized as it involves an extensive research

which cannot be presented within the limits of this

paper.

Articles were eligible for inclusion in the review

based on their relevance to the review objectives,

which are: (1) they describe the current state of

research and practice in Model-Driven Development

and / or Software Modernization; and (2) they

identify and discuss different challenges these areas

poses to both academia and industry. The relevance

was evaluated by reviewing the abstracts of the

articles and grading them as either relevant or

irrelevant. The inclusion was also restricted by the

type of the study, including only review articles and

excluding theoretical (conceptual) or empirical

studies. No restrictions were made in regard to the

publication year of the articles thus covering all the

years available in the included electronic database at

the time of the review (1 January, 2012). Other

exclusion criteria used were: (1) the article does not

have an abstract or the abstract is not available from

the included electronic database; (2) the access to

the full text of the article is restricted; and (3) the

full text of the article is not available in English.

The search strategy included both journals and

conference papers, and was limited to the Scopus

electronic database. Scopus is the largest abstract

and citation database of research literature and

quality web sources, which ensured the coverage of

nearly 18,000 titles from more than 5,000

publishers. The titles of both journals and

conference papers were searched using the following

search terms:

(1) Model-Driven Development - (“Model-Driven”

AND (Challenges OR Review OR Landscape OR

Roadmap OR “State of”));

(2) Software Modernization - (“Software” AND

(Modernization OR Migration OR Legacy OR

Transformation) AND (Challenges OR Review OR

Landscape OR Roadmap OR “State of”).

Applying the search strategy resulted in an initial

pool of 43 articles, 35 articles for Model-Driven

Development and 9 for Software Modernization.

Some additional articles, not covered by the search

strategy, were also included as being recommended

by the research community. Thus, by using the

inclusion and exclusion criteria the initial pool of

articles was limited to 26 articles. Their full texts

were thoroughly examined in order to extract the

challenges of Model-Driven Development and

Software Modernization, which are presented in the

subsequent sections.

2.2 Evaluation

The methodology used to evaluate various agile

techniques in terms of their potential to address the

challenges of MDM was the Delphi technique. This

technique is frequently used for eliciting consensus

from within a group of experts and has many

advantages over other methods of using panel

decision making (Helmer and Helmer-Hirschberg,

1983). Various researchers have found that one of

the major advantages of using it as a group response

is that consensus will emerge with one

representative opinion from the experts (Linstone

and Turoff, 1975); (Helmer and Helmer-Hirschberg,

1983). Other advantages include its simplicity,

anonymity, controlled feedback from the interaction,

etc. (Yousuf, 2007). Some limitations include that

judgments are derived from the subjective opinions

of experts and may not be representative, it requires

adequate time and participant commitment, its

validity extremely depends on the expertise and

experience of the panellists, etc. (Yousuf, 2007).

However, Linstone (Linstone and Turoff, 1975)

recommends the Delphi technique when the

examined issue does not allow the use of analytical

techniques but can benefit from the subjective

judgments on a collective basis, which is our case.

The process followed was the one proposed by

Pfeiffer (Pfeiffer, 1968) and included three

subsequent phases. During the first phase

(recommendation phase), a questionnaire was sent to

a panel of experts (with an average of 9 years of

both academic and industrial experience in Agile

Software Development), asking them to review the

list of challenges extracted by the review process

and make subjective judgment and recommendations

on which agile techniques (from Scrum and XP)

could be used to address these challenges. From

each expert a list of agile techniques was obtained.

During the second phase (evaluation phase), a

consolidated list of agile techniques was created

based on the individual recommendations of the

experts. The list was then sent to each expert to

further specify their level of agreement (using

standard five-point Likert rating scale for

agreement) on the potential of each technique to

address each of the listed challenges. During the

third phase (consensus phase) the consolidated list,

ChallengesofModel-drivenModernization-AnAgilePerspective

221

together with experts’ ratings was sent once again in

order to discuss big differences in ratings. It was

decided that an agile technique would be considered

as having the potential to address a specific

challenge only if the final level of agreement from

each expert is either “Agree” or “Strongly Agree”.

After a number of iterations for clarifications and

argumentation, a consensus was gained, resulting in

a sorted list of agile techniques and the challenges

they could address.

3 CHALLENGES OF MDM

The challenges identified by the review process were

sorted into two categories:

(1) Organizational challenges – These are process-

and people-oriented challenges from all levels of the

organization, including: (1) strategic challenges (e.g.

organizational restructuring and evaluation of

business context); (2) managerial challenges (e.g.

competence acquisition and lack of commitment and

support); and (3) operational challenges (e.g. etc.

lack of process models, interoperable tools and

integrated development environments);

(2) Technical challenges – These are product- and

technology-oriented challenges related to the

specification, design, implementation and

verification of the modernized system.

As the focus of this study was on MDM, we

expected that not all of the challenges discussed by

the reviewed articles would be relevant. For that

reason, we limited the extraction of challenges to

only these challenges which are applicable either in

general or in the context of MDM, excluding

challenges which are applicable only in very specific

contexts (e.g. embedded and safety-critical systems).

3.1 Challenges of Model-Driven

Development

Total of 18 reviews were thoroughly examined in

order to extract the challenges relevant to Model-

Driven Development (MDD). As many challenges

were found, they were further consolidated into total

of 12 challenges, 7 of which were organizational and

5 were technical challenges. A summary of these

challenges, together with their references, is

presented in Table 1.

Table 1: Challenges of Model-Driven Development.

# Challenge

1. Organizational challenges

Lack of Process Models

Due to its early adoption stage, there is still scarce

availability of process models, methods and techniques

to guide the adoption and implementation of MDD

(Wagelaar, 2008, Teppola et al., 2009, Straeten et al.,

2009, Mohagheghi et al., 2009, Rivera et al., 2009).

Acquisition of Competencies and Expertise

For an organization adopting MDD, thorough

understanding of the underlying technologies remains

highly critical. Therefore the acquisition of

competencies and expertise is a major driver for the

successful implementation of MDD. However the

acquisition of competencies and expertise in the context

of MDD is a cumbersome process due to the significant

technological threshold and steep learning curve

involved, and the lack of expertise available on the

labour market (Rios et al. 2006, Hailpern and Tarr

2006, France and Rumpe 2007, Streitferdt et al. 2008,

Teppola et al. 2009, Straeten et al. 2009, Kolovos et al.

2009, Mohagheghi et al. 2009, Lauder et al. 2010).

Restructuring of Software Development Team

MDD requires redefining existing roles and

responsibilities (e.g. introducing roles as domain

experts, language and transformation specialists,

implementation / platform experts, etc.) and thus force

the restructuring of the traditional software

development team (Rios et al. 2006, Teppola et al.

2009, Lauder et al. 2010).

Restructuring of Software Development Lifecycle

MDD changes the importance (e.g. automates some

activities and tasks) and the scope (e.g. introduce new

activities and tasks) of many of the phases in the

traditional software development lifecycle and thus

requires a restructured lifecycle (Rios et al. 2006,

Teppola et al. 2009).

Reliance on High Level Models

In MDD high level models become the primary

artefacts as executable code and tests are automatically

(or semi-automatically) generated. This requires change

in the mindset of the traditional software engineers (e.g.

to think in terms of models, to be knowledgeable on the

problem domain, etc.) and the heavy reliance on

computer-based technologies to transform models into

running systems (Rios et al. 2006, France and Rumpe

2007, Chunying and Kang 2007, Zhu et al. 2008,

Streitferdt et al. 2008, Straeten et al. 2009, Teppola et

al. 2009, Vangheluwe 2011).

Emphasizing Technology rather than Humans

Development environments and tools (and their

capabilities) play a key role in the successful

implementation of MDD. People are still seen from a

technological perspective through roles in the

processes. Thus the social aspect in MDD is still

ignored (Streitferdt et al. 2008).

MODELSWARD2013-InternationalConferenceonModel-DrivenEngineeringandSoftwareDevelopment

222

Table 1: Challenges of Model-Driven Development.

(cont.)

Immature Tools, Lack of integrated Development

Environments and Off-the-Shelf Infrastructure

Organizations adopting MDD have to provide their own

infrastructure (such as meta-models, model

transformations), configuration tools, build processes or

to address incompatible tools and development

environments (France and Rumpe 2007, Chunying and

Kang 2007, Wagelaar 2008, Streitferdt et al. 2008,

Teppola et al. 2009, Kolovos et al. 2009, Mohagheghi

et al. 2009, Rivera et al. 2009, Hailpern and Tarr 2006,

Loniewski et al. 2010, Tajali et al. 2011).

Management of Models

While models at varying levels of abstractions are

created, evolved, analyzed and transformed, many

integration (e.g. versioning, merging, etc.), consistency

(between different models and levels of abstractions,

interrelations and dependencies, etc.) and scalability

(e.g. scaling beyond a few tens of thousands of model

elements per model) issues arise (Hailpern and Tarr

2006, France and Rumpe 2007, Streitferdt et al. 2008,

Teppola et al. 2009, Straeten et al. 2009, Kolovos et al.

2009, Tajali et al. 2011, Vangheluwe 2011).

Transformation of Models

Synchronization transformation technologies are

required to “ripple” the results of transformations to

related views or to address the round-trip problems

between the models (incl. generated code), together

with new procedures for verifying the correctness of

these model transformations, etc. (Hailpern and Tarr

2006, France and Rumpe 2007, Streitferdt et al. 2008,

Teppola et al. 2009, Straeten et al. 2009, Kolovos et al.

2009, Rivera et al. 2009, Tajali et al. 2011, Vangheluwe

2011).

Design of the Modeling Languages

The design of the modeling language is identified as

one of the major aspects related to modularity in

modeling. But how the modeling language should be

defined remains an open research topic, including

issues as how to provide support for creating and

manipulating problem-level abstractions as first-class

modeling elements in a language (the abstraction

challenge), what aspects of the semantics of the

modeling language need to be formalized and how this

should be done, etc. (Hailpern and Tarr 2006, France

and Rumpe 2007, Conmy and Paige 2007, Teppola et

al. 2009, Straeten et al. 2009, Kolovos et al. 2009,

Vangheluwe 2011).

Quality of Models

MDD poses many challenges to software quality in

terms of localizing issues and troubleshooting (incl.

model-level debugging), fixing bugs in running

systems, ensuring correctness and reliability of test

cases, conducting performance and reliability analysis,

simulation, validation, model checking, etc.

(Pfadenhauer et al. 2005, Chunying and Kang 2007,

Zhu et al. 2008, Teppola et al. 2009, Straeten et al.

2009, Rivera et al. 2009).

Table 1: Challenges of Model-Driven Development.

(cont.)

Integration Of Legacy / Handcrafted Code

In MDD there could be the case that software

engineers, after performing model-to-code

transformations, have to integrate generated code with

handcrafted or legacy code. This could results in

refactoring of the generated and foreign code, as well as

writing glue code (France and Rumpe 2007, Streitferdt

et al. 2008, Kolovos et al. 2009, Mohagheghi et al.

2009).

The descriptive analysis of the extracted

challenges revealed that organizational and technical

challenges were almost equality considered within

the reviewed literature. Organizational challenges

were examined by 89% of the reviewed articles with

an average of 5.4 articles per organizational

challenge, while the same numbers for technical

challenges were 75% and 7.4 respectively. The most

cited organizational challenge was the lack of

mature tools, integrated development environments

and off-the-shelf infrastructure (O7) with total of 11

citations (or 61% of the reviewed articles), followed

by competence acquisition (O2) and the reliance on

high level models (O5) with 10 (56%) and 8 (44%)

citations respectively. In terms of technical

challenges, model transformations (T2) have been

cited the most (by total of 11 articles or 61% of all

articles), followed by model management (T1) and

language challenges (T3) with 9 (50%) and 7 (39%)

citations respectively. Further analysis revealed

three reasons for observing the extracted

organizational challenges: (1) the early adoption

stage of Model-Driven Development (O1, O2, O7);

(2) its technology intensive nature (O2, O6); and (3)

the significant organizational change needed when

moving from traditional to model-driven software

development (O2, O3, O4, O5). The reasons for

observing the technical challenges were mostly

associated with the use of new and innovative

technologies, where high level abstractions are used

for specifying, designing, implementing and

verifying complex software systems.

The challenges in Table 1 have various

implications on the incorporation of agile methods

and techniques into the MDM process. Model-

Driven Development, by emphasizing technology

rather than humans (O6), shifts the focus on

integrated development environments, tools and

technologies and sees them as the primary factor for

success. This contradicts with the agile philosophy,

which postulates that people are the most valuable

asset of the organization and human/social aspects

are the key for the successful software development.

ChallengesofModel-drivenModernization-AnAgilePerspective

223

Another implication is that there are many

prerequisites before models can be turned into fully

operational (or working) software system, even if

the software system provides only limited (but still

valuable) functionality. Example of such

prerequisites, which are requiring considerable time

and effort, are: (1) the definition of the problem

domain (O5); (2) the specification of the domain

language, transformation language, etc. (T3); (3) the

provision of infrastructure (such as meta-models,

model transformations), configuration tools and

build processes (O7); (4) the integration of legacy

and / or handcrafted code (T5); and many others. All

these prerequisites pose some limitations on the

extent to which agile methods and techniques could

be incorporated. In Agile Software Development,

working software is the only recognized measure of

progress and the rapid delivery is the ultimate goal,

so not having working software in the early stage of

the development lifecycle could be problematic.

Also, having so many prerequisites could threaten

the effectiveness of using short increments (2 - 4

weeks) and the possibility of delivering potentially

shippable products. This could result in reduced

customer value (e.g. through delayed time to market)

and untimely customer feedback (e.g. receiving the

feedback too late in the development lifecycle). The

challenges related to the management and

transformation of models (T1, T2) could

significantly hinder organization's ability to respond

to change due to the extensive and time-consuming

efforts needed for securing model integration,

consistency, scalability, transformation, etc. T1 and

T2, together with ensuring model quality (T4), could

also result in redundant documentation and

architecture, which could further delay the delivery

of working software. Probably the biggest

implication for incorporating agile methods and

techniques is that Model-Driven Development

emphasize on models rather than on coding and

testing (O5), and requires restructuring of the

traditional software development teams and

lifecycles (O3, O4). This could further hamper the

agile implementation into MDM because many of

the existing agile techniques might need significant

modifications (e.g. pair programming to be adapted

as pair modeling). Such possible modifications were

already discussed in the work of Zhang and Patel

(Zhang and Patel, 2011).

Although there are many implications for

incorporating agile methods and techniques into

Model-Driven Development, they seem to share

some common values. For example, using models as

the primary artifacts in the development process is

promising to increase the customer value (trough

better understanding of the problem domain from all

parties, incl. engineers; closer customer

collaboration and effective requirements elicitation

and prioritization; etc.) and the organization's ability

to respond to change (by changing only the high

level models and automatically distributing the

changes to the implementation / testing code).

However, in Model-Driven Development there is

still no special attention on individuals and

interactions, customer collaboration and working

software – values central to Agile Software

Development.

3.2 Challenges of Software

Modernization

A total of 8 reviews in the field of Software

Modernization were examined. The extracted

challenges were further consolidated into 11

challenges, including 7 organizational challenges

and 4 technical. They are shown in Table 2.

Table 2: Challenges of Software Modernization.

# Challenge

Organizational challenges

Definition of Business Context

Software modernization (as a heavy initiative) to be

successful needs to be considered in regard to the

specific business / organizational context and aligned

with the existing business goals and strategies, project

constraints as time / budget, organizational

stakeholders, etc. Thus evaluating the feasibility of the

modernization initiative (e.g. through pilot

modernizations, prototypes, etc.) should be an

inevitable part of the modernization process (Lewis et

al., 2005, Mohagheghi and Sæther, 2011).

Lack of Business Commitment

Software modernization success also depends on how

well the modernization efforts are justified in terms of

business value and the extent to which these efforts are

supported by all organizational stakeholders, including

customers and management. This requires additional

efforts in order to motivate the various stakeholders and

gain their commitment (Lewis et al., 2005, Teppe,

2009).

Resistance to Change

Legacy systems are often critical for business (these

systems are matured, heavily used, and constitute

massive corporate assets), so stakeholders (incl.

business people, customers, etc.) could be sensitive

about the modernization process and might resist too

many changes due to higher risk (Chowdhury and

Iqbal, 2004, Lewis et al., 2005, Al-Azzoni et al., 2011).

MODELSWARD2013-InternationalConferenceonModel-DrivenEngineeringandSoftwareDevelopment

224

Table 2: Challenges of Software Modernization. (cont.)

Acquisition of Competencies and Expertise

The software users must be re-trained and equipped to

use and understand the new applications and platforms

effectively. The same holds for the whole software

development team, which has to be re-trained to use the

modernization tools as well as the new technologies,

languages, platforms, etc. that are involved (Teppe

2009).

Increased Risk Due to New Technologies

New technologies should be prior evaluated for both

business and technical feasibility as they might have

tremendous impact on the successful modernization of

the legacy systems (Lewis et al. 2005).

Lack of in-depth Knowledge

It might be the case that there's a lack of in-depth

knowledge regarding the functional / non-functional

aspects and requirements for a given legacy system

(due to incomplete, inadequate, out-of-date or missing

documentation, the people who developed the system

had left the organization, etc.), while the target system

is expected to reflect the source system as it is

(Chowdhury and Iqbal 2004, Kvam et al. 2005, Al-

Azzoni et al. 2011).

Lack of Support

The business people and customers might provide

limited or no assistance during the modernization

process. They might not have the time or possibility to

re-evaluate their business needs in order to re-evaluate

the source system and extend its functionality. Also

they might point the source systems as the ultimate

source for requirements (Lewis et al. 2005, Teppe

2009).

Technical challenges

Extracting Business and Technical Knowledge from

Legacy Systems

The need to extract business and technical knowledge

could be problematic due to incomplete, inadequate,

out-of-date architectural and design documentation, low

quality of source code, lack of unit / acceptance tests,

etc. This requires additional efforts (manual or semi-

automated) and could become a time consuming

activity (Chia-Chu and Bayrak 2006).

Ensuring Behavioural Equivalence between Source

and Target Systems

Additional efforts are also needed in order to secure the

behavioural equivalence (in terms of functionality)

between the source and target systems (Lewis et al.

2005, Chia-Chu and Bayrak 2006, Torchiano et al.

2008).

Co-existence of Source and Target Systems

Additional issues arise when the source and target

systems should co-exist not only during the

modernization process but also when it is finalized (e.g.

integration issues, replication of efforts, data, utilization

of resources, etc.)

Table 2: Challenges of Software Modernization. (cont.)

Overcome Obsolete and/or Heterogeneous

Technologies (both Software and Hardware)

It could be the case that the legacy system is based on

obsolete and heterogeneous technologies and platforms,

which makes harder the modernization process to new

technologies / platforms due to limited possibilities for

reuse (in terms of design, architecture, implementation

details, test suits and etc.). Example is migration from

procedural programming paradigm to object-oriented

programming paradigm, or migration from a mixture of

COBOL/Delphi/.NET/C# based system to pure Java

based system and etc.

The descriptive analysis of the extracted

challenges revealed that organizational challenges

are prevailing within the reviewed literature.

Organizational challenges were examined by 75% of

the reviewed articles with an average of 2 articles

per organizational challenge, while the same

numbers for technical challenges were 38% and 1

respectively. The most cited organizational

challenges were the resistance to change (O3) and

the lack of in-depth knowledge (O6) with total of 3

citations each (38%), followed by the definition of

business context (O1) and the lack of business

commitment (O2) with 2 citations (25%)

respectively. In terms of technical challenges,

ensuring behavioural equivalence (T2) have been

cited the most, by total of 3 articles (38%), followed

by extracting business and technical knowledge

from legacy systems (T1) with only one citation.

The co-existence of source and target systems (T3)

and the overcoming obsolete and/or heterogeneous

technologies (T4) were not cited in any of the

reviewed articles. They were additionally included

by the authors, based on their own experience with

software modernization in real industrial settings.

The dominance of organizational values within the

reviewed literature could be explained by the

significant organizational change, required by the

modernization process, which affects crucial

business assets of the organization. So how this

change will be introduced and managed within the

organization becomes an arduous task. The technical

challenges on the other hand are context specific

(depend on the specific technology / platform /

programming language / etc. of the source and target

systems), although there are some general technical

challenges relevant to any software modernization

initiative (Table 2).

Software Modernization and its challenges

further affect the way agile methods and techniques

could be incorporated into the MDM process.

Challenges as lack of business commitment (O2)

ChallengesofModel-drivenModernization-AnAgilePerspective

225

and support (O7) could negatively impact customer

collaboration, which is one of the key success

factors for the implementation of Agile Software

Development. The co-existence of source and target

systems (T3) could reduce the customer value (in

terms of new functionality, improved quality, etc.)

as it could shift the focus from enhancing the

modernized system to keeping both source and

target systems aligned and synchronized. The

increased risk (e.g. failure due to inappropriate

selection of technologies and process models) (O5)

and stakeholders’ sensitiveness to the modernization

process (e.g. crucial business assets are being

changed), could lead to significant change resistance

and organizational rigidness. This could limit

organization's ability to respond to change.

Although there are some implications for

incorporating agile methods and techniques in the

context of Software Modernization, our analysis

revealed that they are no significant obstacles for

scaling Agile Software Development for

modernizing complex software systems.

4 RESULTS

The present section discusses the results of the

evaluation of agile techniques based on the Delphi

method. The results are shown in Table 3, where the

techniques are sorted by the total number of

challenges they are expected to address (shown in

brackets next to the technique’s name).

The agile techniques with the highest potential to

address the challenges of MDM (total of 18

challenges) were Small Releases (from XP), Sprints

(from Scrum) and Cross-Functional Teams (Table

3). One of the arguments for Small Releases and

Sprints was (1) receiving rapid feedback, including

feedback from the process (e.g. the adequacy of

team roles and responsibilities, and the development

lifecycle), from the product (e.g. the effectiveness of

the problem domain, modeling languages, model

transformations, etc. and the quality of the models)

and from the people (e.g. lack of commitment and

support). Another argument was (2) increasing the

organizational responsiveness to change by allowing

changes to happen in each subsequent increment

(e.g. refinement of the problem domain, modeling

languages, model transformations, etc. and changes

in the infrastructure, build processes, tools and

integrated environments, etc.). Among the other

arguments for incorporating Small Releases and

Sprints were: (3) gaining commitment and support

through frequent communication, increased visibility

and traceability, etc.; (4) effective competency

acquisition through learning by doing; (5) reducing

risk through early detection of potential issues; (6)

early delivery of customer value; and etc.

Cross-Functional Teams (from Scrum) was also

highly recommended by the experts. Among the

arguments for using Cross-Functional Teams,

together with Whole Team and Pair Programming

(from XP), were: (1) the effective acquisition of

competencies and expertise (e.g. through daily

knowledge transfer and direct interaction); (2)

reduced risk (e.g. through homogeneous distribution

of knowledge and expertise); (3) emphasis on

human/social aspects (e.g. through empowering the

team, building trust and respect, and enhancing

collaboration and interaction between individuals);

(4) reducing complexity (e.g. all required knowledge

and expertise are within the boundaries of the team);

(5) increased responsiveness and support (e.g.

through flawless communication and collaboration,

and customer involvement); (6) securing non-

functional concerns (e.g. the quality of models and

the behavioural equivalence between the source and

target systems; etc.

Planning Game (from XP) and Sprint Planning

Meeting (from Scrum) also have strong potential for

addressing the challenges of MDM (total of 15

challenges). Experts motivated their

recommendations with: (1) active involvement of

customers or their representatives in the

development process; and (2) enhanced

collaboration between customers and the

development team. Bringing together the customer

(or customer’s representative) and the development

team before each iteration could also result in (3)

increased customer value (e.g. through effective

requirements elicitation and prioritization,

refinement of the problem domain and mutual

understanding of the business context); (4) reduced

risk for failure (e.g. due to collective estimations);

(5) gaining support and commitment from

stakeholders; (6) clarification of team roles and

responsibilities; (7) early detection and escalation of

concerns; etc. Other agile techniques, highly

recommended by the experts were Continuous

Integration and Test-Driven Development (from XP)

and Product Backlog, Spring Backlog and Daily

Scrum (from Scrum).

Based on the presented results and following the

Pareto principle (80% of the effects come from 20%

of the causes) (Pareto, 1971), we recommend that an

organization, undertaking MDM and interested in

Agile Software Development, should start with

small releases (or sprints), encourage cross-

MODELSWARD2013-InternationalConferenceonModel-DrivenEngineeringandSoftwareDevelopment

226

Table 3: Agile techniques and the challenges they are expected to address.

Agile Technique MDD Challenges SM Challenges

Extreme Programming (XP)

Small Releases (18) O2, O3, O4, O7, T1, T2, T3, T4, T5 O2, O3, O4, O5, O6, O7, T1, T2, T3

Whole Team (16) O2, O3, O4, O5, O6, T4, T5 O1, O2, O3, O4, O5, O6, O7, T1, T2

Planning Game (15) O3, O4, O5, T2, T3 O1, O2, O3, O5, O6, O7, T1, T2, T3, T4

Pair Programming (13) O2, O4, O5, O7, T2, T3, T4, T5 O4, O6, T1, T2, T4

Continuous Integration (11) O4, O5, O6, O7, T1, T2, T4, T5 O3, T3, T4

Test-Driven Development (10) O4, O5, O7, T4, T5 O3, O4, T1, T2, T3

Collective Code Ownership (7) O3, O4, O5, T1, T2, T3 O6

System Metaphor (4) O2, O4, O5 O4

Sustainable Pace (4) O2, O6, O7 O4

Refactoring (3) O4, O5 T4

Simple Design (2) O4, O5 -

Coding Standards (2) O4, O5 -

Scrum

Sprint (18) O2, O3, O4, O7, T1, T2, T3, T4, T5 O2, O3, O4, O5, O6, O7, T1, T2, T3

Cross-Functional Team (18) O2, O3, O4, O5, O6, T1, T2, T3, T4, T5 O4, O5, O6, O7, T1, T2, T3, T4

Sprint Planning Meeting (15) O3, O4, O5, T2, T3 O1, O2, O3, O5, O6, O7, T1, T2, T3, T4

Product Backlog (11) T2, T3 O1, O2, O3, O5, O6, O7, T1, T2, T3

Spring Backlog (11) T2, T3 O1, O2, O3, O5, O6, O7, T1, T2, T3

Product Owner (8) O3, O4 O1, O2, O3, O6, O7, T1

Sprint Review Meeting (6) - O2, O3, O6, O7, T2, T3

Daily Scrum (4) O4, T1, T5 T4

Scrum Master (4) O3, O4 O5, O7

Scrum of Scrums (2) O4, T1 -

Sprint Retrospective (2) O2 O4

Sprint Burn Down Chart (0) - -

functional teams and incorporate planning meetings

similar to either planning game or sprint planning

meeting. This would guarantee minimum efforts for

incorporating agile into the MDM process and

maxim efficiency in terms of addressed challenges.

Next, if the organization would like to further

increase its agility, it might continue with Product /

Sprint Backlogs, Continuous Integration and On-Site

Customer. These techniques also have high potential

to address the challenges of MDM. Finally, as

almost all of the examined agile techniques could be

beneficial for the MDM, an organization might also

consider full implementation of either XP or Scrum

(or a hybrid), as this will ensure cohesiveness and

will allow the organization to take full advantage of

these methods.

The results in Table 3 can be further used to sort

out the techniques which have the potential to

address a particular challenge. This might be useful

when one or more challenges of MDM have greater

impact on the project than others. Then, all the

techniques recommended for that particular

challenge might be considered for introduction in the

project.

5 LIMITATIONS

This study has its recognized limitations. Some of

these limitations are coming from the review

methodology used to extract the challenges of MDD

and Software Modernization. Narrowing the search

strategy to include only the titles of the published

articles and limiting the publication databases to a

single electronic database might have minimized the

likelihood of capturing all relevant data and thus

maximized the effects of publication bias. The risk

of publication bias was further increased by

excluding studies depending on their type of study,

unavailability and language. However, by taking

some additional actions (e.g. including studies

recommended by the research community) and by

rigorously following the procedure of the systematic

review, the probability that the omitted research

could have critically altered our findings and

ChallengesofModel-drivenModernization-AnAgilePerspective

227

threaten their generalizability (or external validity)

has been reduced.

The use of the Delphi method to evaluate agile

techniques in terms of MDM possesses some

limitations as well. Among the most critical

limitations are that the evaluation was derived from

the subjective opinions of experts, which may not be

representative, and that the validity of the evaluation

extremely depends on their expertise and experience.

In order to mitigate these threads, the selection of

the panellists was restricted to experts with more

than 5 years of both academic and industrial

experience in Agile Software Development, as well

as proved knowledge and experience in MDD and

Software Modernization.

6 CONCLUSIONS

This paper presented the challenges of Model-

Driven Development and Software Modernization,

which were extracted, analyzed and synthesized

through a systematic literature review. Then, using

these challenges, the paper: (1) discussed the

possible implications for incorporating agile

methods and techniques into the MDM process; (2)

evaluated various agile techniques (from XP and

Scrum) for their potential to overcome the

challenges of MDM; and (3) provided

recommendations on which agile techniques are

most applicable in the context of MDM and gave

suggestions (following the Pareto principle) on how

they should be incorporated into the MDM process.

Although there were many implications for

combining Agile Software Development and MDM,

our final conclusion is that Agile Software

Development and MDM are compatible and using

various agile techniques could be beneficial for

organizations that are approaching software

modernization through model-driven development.

Adding our previous results in the fields of

Service-Oriented Architecture and Cloud Computing

(Stavru et al. 2012), our future work is proposing a

comprehensive agile methodology for model-driven

modernization of software systems with deployment

in Service Cloud and the empirical evaluation of this

methodology using the REMICS’s case studies.

ACKNOWLEDGEMENTS

The research in this paper was partially supported by

FP7 project REMICS, contract No. 257793 and by

National Scientific Fund, Bulgarian Ministry of

Education and Science, Research Project agreement

n. DO-02-182.

REFERENCES

Abbattista, F., Bianchi, A. & Lanubile, F. 2009. 'A

Storytest-Driven Approach to the Migration of Legacy

Systems.' In P. Abrahamsson, M. Marchesi, F. Maurer,

W. Aalst, J. Mylopoulos, M. Rosemann, M. J. Shaw &

C. Szyperski (Eds.) Agile Processes in Software

Engineering and Extreme Programming: 149-54.

Springer Berlin Heidelberg.

Al-Azzoni, I., Zhang, L. & Down, D. G. 2011. 'Abstract

only: performance evaluation for software migration.'

SIGSOFT Softw. Eng. Notes, 36:5, 42-42.

Arsanjani, A. 2004. 'Service-oriented modeling and

architecture', IBM developerWorks.

Brereton, P., Kitchenham, B. A., Budgen, D., Turner, M.

& Khalil, M. 2007. 'Lessons from applying the

systematic literature review process within the

software engineering domain.' J. Syst. Softw., 80:4,

571-83.

Butler, J. 2007. 'The Architecture Component of the SAE

Reference Framework for SOA.' CBDI Journal, 11-23.

Chia-Chu, C. & Bayrak, C. 2006. 'Legacy Software

Modernization.' Paper presented at Systems, Man and

Cybernetics, 2006. SMC '06. IEEE International

Conference on. 8-11 Oct. 2006.

Chowdhury, M. W. & Iqbal, M. Z. 2004. 'Integration of

Legacy Systems in Software Architecture.' Paper

presented at Specification and Verification of

Component-Based Systems.

Chunying, Z. & Kang, Z. 2007. 'Transformational

Approaches to Model Driven Architecture - A

Review.' Paper presented at Software Engineering

Workshop, 2007. SEW 2007. 31st IEEE. March 6

2007-Feb. 8 2007.

Conmy, P. & Paige, R. F. 2007. 'Challenges when using

Model Driven Architecture in the development of

Safety Critical Software.' Paper presented at Model-

Based Methodologies for Pervasive and Embedded

Software, 2007. MOMPES '07. Fourth International

Workshop on. 31-31 March 2007.

Dyba, T. & Dingsoyr, T. 2009. 'What Do We Know about

Agile Software Development?' IEEE Softw., 26:5, 6-9.

France, R. & Rumpe, B. 2007. 'Model-driven

Development of Complex Software: A Research

Roadmap.' 2007 Future of Software Engineering: 37-

54. IEEE Computer Society.

Hailpern, B. & Tarr, P. 2006. 'Model-driven development:

The good, the bad, and the ugly.' IBM Systems

Journal, 45:3, 451-61.

Helmer, O. & Helmer-Hirschberg, O. 1983. Looking

forward: a guide to futures research. Sage

Publications.

Kitchenham, B. 2004. 'Procedures for performing

systematic reviews.' Keele University and NICTA.

MODELSWARD2013-InternationalConferenceonModel-DrivenEngineeringandSoftwareDevelopment

228

Kitchenham, B. A. 2007. 'Guidelines for performing

Systematic Literature Reviews in Software

Engineering.' Keele University and University of

Durham.

Kolovos, D. S., Paige, R. F. & Polack, F. A. 2009. 'The

Grand Challenge of Scalability for Model Driven

Engineering.' In R. C. Michel (Ed.) Models in

Software Engineering: 48-53. Springer-Verlag.

Kvam, K., Lie, R. & Bakkelund, D. 2005. 'Legacy system

exorcism by Pareto's principle.' Companion to the 20th

annual ACM SIGPLAN conference on Object-oriented

programming, systems, languages, and applications:

250-56. San Diego, CA, USA: ACM.

Lauder, M., Schlereth, M., Rose, S. & Schürr, A. 2010.

'Model-driven systems engineering: State-of-the-art

and research challenges.' Bulletin of the Polish

Academy of Sciences, Technical Sciences, 58:3, 409-

22.

Lewis, G., Morris, E., O’Brien, L., Smith, D. & Wrage, L.

2005. SMART: The Service-oriented Migration and

Reuse Technique. Carnegie Mellon University,

Software Engineering Institute.

Linstone, H. A. & Turoff, M. 1975. The Delphi method:

techniques and applications. Addison-Wesley Pub.

Co., Advanced Book Program.

Loniewski, G., Insfran, E. & Abrahão, S. 2010. 'A

Systematic Review of the Use of Requirements

Engineering Techniques in Model-Driven

Development.' In D. Petriu, N. Rouquette & Ø.

Haugen (Eds.) Model Driven Engineering Languages

and Systems: 213-27. Springer Berlin / Heidelberg.

Matinnejad, R. 2011. 'Agile Model Driven Development:

An Intelligent Compromise.' Paper presented at

Software Engineering Research, Management and

Applications (SERA), 2011 9th International

Conference on. 10-12 Aug. 2011.

Mohagheghi, P., Berre, A. J., Sadovykh, A., Barbie, F. &

Benguria, G. 2010. 'Reuse and Migration of Legacy

Systems to Interoperable Cloud Services- The

REMICS project.' Paper presented at

Mda4ServiceCloud'10 at ECMFA.

Mohagheghi, P., Fernandez, M. A., Martell, J. A.,

Fritzsche, M. & Gilani, W. 2009. 'MDE Adoption in

Industry: Challenges and Success Criteria.' In R. C.

Michel (Ed.) Models in Software Engineering: 54-59.

Springer-Verlag.

Mohagheghi, P. & Sæther, T. 2011. 'Software Engineering

Challenges for Migration to the Service Cloud

Paradigm: Ongoing Work in the REMICS Project.'

Paper presented at Services (SERVICES), 2011 IEEE

World Congress on. 4-9 July 2011.

Pareto, V. 1971. Manual of political economy. Scholars

Book Shelf.

Pfadenhauer, K., Dustdar, S. & Kittl, B. 2005. 'Challenges

and solutions for model driven Web service

composition.' Paper presented at Enabling

Technologies: Infrastructure for Collaborative

Enterprise, 2005. 14th IEEE International Workshops

on. 13-15 June 2005.

Pfeiffer, J. 1968. New look at education: systems analysis

in our schools and colleges. Odyssey Press.

Picek, R. 2009. 'Suitability of Modern Software

Development Methodologies for Model Driven

Development.' Journal of Information and

Organizational Sciences, 33:2, 285-95.

Plummer, D. C. 2001. 'Service-Oriented Development of

Applications: SODA Pops', [online at

http://www2.roguewave.com/support/docs/leif/leif/ht

ml/leifintroug/2-3.html].

Prakash, G. 2010. 'Achieving Agility in Adaptive and

Perfective Software Maintenance.' Paper presented at

14th European Conference on Software Maintenance

and Reengineering (CSMR '10).

Qumer, A. & Henderson-Sellers, B. 2007. 'ASOP: An

Agile Service-Oriented Process.' Proceedings of the

2007 conference on New Trends in Software

Methodologies, Tools and Techniques: Proceedings of

the sixth SoMeT_07: 83-92. IOS Press.

Razavian, M. & Lago, P. 2009. 'Towards a conceptual

framework for legacy to SOA migration.' Proceedings

of the 2009 International Conference on Service-

oriented Computing: 445-55. Stockholm, Sweden:

Springer-Verlag.

Rios, E., Bozheva, T., Bediaga, A. & Guilloreau, N. 2006.

'MDD Maturity Model: A Roadmap for Introducing

Model-Driven Development.' In A. Rensink & J.

Warmer (Eds.) Model Driven Architecture –

Foundations and Applications: 78-89. Springer Berlin

/ Heidelberg.

Rivera, J. E., Romero, R. & Vallecillo, A. 2009. 'Behavior,

Time and Viewpoint Consistency: Three Challenges

for MDE.' In R. C. Michel (Ed.) Models in Software

Engineering: 60-65. Springer-Verlag.

Stavru, S., Krasteva, I. & Ilieva, S. 2012. 'Challenges for

Migrating to the Service Cloud Paradigm: An Agile

Perspective.' Paper presented at 1st Workshop on

Cloud-Enabled Business Process Management.

Straeten, R., Mens, T. & Baelen, S. 2009. 'Challenges in

Model-Driven Software Engineering.' In R. C. Michel

(Ed.) Models in Software Engineering: 35-47.

Springer-Verlag.

Streitferdt, D., Wendt, G., Nenninger, P., Nyssen, A. &

Lichter, H. 2008. 'Model Driven Development

Challenges in the Automation Domain.' Paper

presented at Computer Software and Applications,

2008. COMPSAC '08. 32nd Annual IEEE

International. July 28 2008-Aug. 1 2008.

Tajali, S. B., Radonjic, V. D. & Corriveau, J. P. 2011.

'Challenges of Variability in Model-Driven and

Transformational Approaches: A Systematic Survey.'

Paper presented at Software Architecture (WICSA),

2011 9th Working IEEE/IFIP Conference on. 20-24

June 2011.

Teppe, W. 2009. 'The ARNO Project: Challenges and

Experiences in a Large-Scale Industrial Software

Migration Project.' Paper presented at Software

Maintenance and Reengineering, 2009. CSMR '09.

13th European Conference on. 24-27 March 2009.

Teppola, S., Parviainen, P. & Takalo, J. 2009. 'Challenges

in Deployment of Model Driven Development.' Paper

ChallengesofModel-drivenModernization-AnAgilePerspective

229

presented at Software Engineering Advances, 2009.

ICSEA '09. Fourth International Conference on. 20-25

Sept. 2009.

Torchiano, M., Di Penta, M., Ricca, F., De Lucia, A. &

Lanubile, F. 2008. 'Software migration projects in

Italian industry: Preliminary results from a state of the

practice survey.' Paper presented at Automated

Software Engineering - Workshops, 2008. ASE

Workshops 2008. 23rd IEEE/ACM International

Conference on. 15-16 Sept. 2008.

Vangheluwe, H. 2011. 'Invited Talk: Promises and

Challenges of Model-Driven Engineering.' Paper

presented at Software Maintenance and Reengineering

(CSMR), 2011 15th European Conference on. 1-4

March 2011.

Wagelaar, D. 2008. 'Challenges in bootstrapping a model-

driven way of software development.' Proceedings of

the First International Workshop on Challenges in

Model-Driven Software Engineering (ChaMDE 2008):

25–30. Toulouse, France.

Yousuf, M. I., 12(4). 2007. 'Using Experts’ Opinions

through Delphi Technique.' Practical Assessment

Research & Evaluation, 12:4.

Zhang, Y. & Patel, S. 2011. 'Agile Model-Driven

Development in Practice.' IEEE Software, 28:2, 84-91.

Zhu, H., Wong, W. E. & Belli, F. 2008. 'Advancing test

automation technology to meet the challenges of

model-driven software development: report on the 3rd

workshop on automation of software test.' Companion

of the 30th International Conference on Software

Engineering: 1049-50. Leipzig, Germany: ACM.

Zimmermann, O., Krogdahl, P. & Gee, C. 2004. 'Elements

of Service-Oriented Analysis and Design', IBM

developerWorks.

MODELSWARD2013-InternationalConferenceonModel-DrivenEngineeringandSoftwareDevelopment

230
