A Literature Evaluation of CUDA Compatible Sequence Aligners

Yang Liu, Jiang-Yu Li, Yi-Qing Mao, Xiao-Lei Wang and Dong-Sheng Zhao

Institute of Health Service and Medical Information, Academy of Military Medical Sciences, Taiping Road, Beijing, China

Keywords: CUDA, Sequence Aligner, Performance per Watt, Price-performance, Programming Complexity.

Abstract: The rapidly accumulating biological data generated by next-generation sequencer motivate the development

of improved tools for sequence alignment. Many technologies have been proposed for this purpose, and one

of them is GPU computing. Existing acceleration of sequence aligners using GPU computing

overemphasize speed. However, other factors such as accuracy, performance per watt, price-performance

and programming complexity are also important and need to be considered. Based on the existing literatures

of GPU-based sequence aligners, this paper gives a literature evaluation of these sequence aligners from the

above perspectives, in order to determine the usability of the tremendous GPU-based sequence aligners.

1 INTRODUCTION

With the coming of big data era, traditional widely

adopted sequence aligners such as BLAST can no

longer meet the need to analyse the rapidly

accumulating sequence data. In response to this

challenge, new algorithms have been proposed to

increase speed with no sacrifice in sensitivity or

accuracy. One example is USEARCH (Edgar, 2010).

Some new technologies such as GPU computing

have also been used to accelerate alignment. Several

traditional sequence aligners have been implemented

with CUDA. However, to highlight performance the

authors tend to overemphasize the gain of speed.

Besides speed, Accuracy, performance per watt,

price-performance and programming complexity are

also important factors that need to be concerned, yet

omitted by almost all of the authors. Should I move

my task to the GPU platform? This is the question

that this article will answer. This article aims to

systematically evaluate the usability of these

tremendous aligners from a comprehensive point of

view.

2 MATERIALS AND METHODS

2.1 Materials

Several sequence aligners have been migrated to

GPU. We investigate the widely-known CUDA

compatible sequence aligners that were developed in

recent years through the method of literature search.

The hardware and speedup information are listed in

Table 1. The speed performances of some aligners

vary with dataset, so we calculated the average

speedup if data is provided, otherwise the mentioned

speedup is used. Some aligners such as NCBI

BLAST and BWA can exploit the multicore feature

of CPU, so we use the speedup of the GPU-based

aligner compared with its multi-threaded counterpart

in later calculations under this situation. The number

of threads is equal to the number of CPU cores.

2.2 Methods

Most GPU-based sequence aligners achieve some

extent of speedup compared with the corresponding

aligners implemented on CPU. GPU computing is a

solution for high performance computing and has

much potential, but it is not a panacea. There are

some cases where GPU computing may not be

beneficial. In this section, we discuss four major

factors regarding the use of GPU: accuracy,

performance per watt, price-performance and

programming complexity.

Some of the CUDA compatible aligners don’t

discuss the accuracy in the papers. We can infer

from the implementation of algorithm.

Performance per watt of these aligners compared

with their corresponding CPU-based aligners is

evaluated by PPW

GPU+CPU

/PPW

CPU

. It is calculated

with the following formula.

268

Liu Y., Li J., Mao Y., Wang X. and Zhao D..

A Literature Evaluation of CUDA Compatible Sequence Aligners .

DOI: 10.5220/0004191202680271

In Proceedings of the International Conference on Bioinformatics Models, Methods and Algorithms (BIOINFORMATICS-2013), pages 268-271

ISBN: 978-989-8565-35-8

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

Table 1: Information about GPU-based sequence aligners and comparison against their CPU-based counterparts.

GPU-based

Aligner

GPU

CPU-based

Aligner

CPU Speedup

MUMmerGPU

(Schatz et al., 2007)

GeForce 8800 GTX MUMmer

Intel Xeon 5160

(dual-core)

3.47x-3.79x

GPU accelerated HMMER

(Walters et al., 2008)

GeForce 8800 GTX HMMER

2.0 GHz Intel Xeon

(quad-core)

18.30x

SW-CUDA

(Manavski and Valle, 2008)

GeForce 8800 GTX

SSEARCH

3 GHz Pentium 4

(single-core)

15.30x

NCBI BLAST 0.94x

GSW

(Striemer and Akoglu, 2009)

Tesla C870 SSEARCH

3.2 GHz Pentium 4

(single-core)

8.50x

CUDASW++

(Liu et al., 2009)

GeForce GTX 280

NCBI BLAST

Intel Xeon 3.0 GHz

(dual-core)

3.48x(BLOSUM50)

GeForce GTX 295 5.31x(BLOSUM50)

GPU-BLAST

(Vouzis and Sahinidis, 2011)

Tesla C2050 NCBI BLASTP

Intel Xeon 2.67GHz

(six-core)

1.59x

CUDA-BLASTP

(Liu et al., 2011)

GeForce GTX 280

NCBI BLASTP

Intel i7-920

(quad-core)

1.90x

GeForce GTX 295 2.82x

SOAP3

(Liu et al., 2012)

GeForce GTX 580

BWA

3.07 GHz

(quad-core)

2.84x

Bowtie 5.60x(3 mismatches)

BarraCUDA

(Klus et al., 2012)

Tesla M2090 BWA

Intel Xeon X5670

(six-core)

1.09x

PPW

GPU+CPU

/PPW

CPU

= S*P

CPU

/(P

GPU

CPU

) (1)

GPU

and P

CPU

stand for the power dissipation of

GPU and CPU respectively. S stands for speedup.

Note that PPW

GPU+CPU

/PPW

CPU

is used because GPU

computing is a heterogeneous architecture and the

GPU-based aligners cannot run without CPU.

Price-performance is evaluated by PPR

GPU+

Sys

/PPR

Sys

, where PPR stands for Price/Performance

Ratio. It is calculated with the following formula.

PPR

GPU+S

/PPR

= (Pr

GPU

+Pr

)/(Pr

S) (2)

GPU

and Pr

Sys

are the price of GPU and system

respectively. S stands for speedup. Since different

pcs and servers are used, to be even we use a range

(from $1000 to $3000) to denote the price of system.

The price of a PC and a server are about $1000 and

$3000 respectively.

There is no straightforward criterion to evaluate

programming complexity. But some factors such as

degree of popularization can be a point of view

which indicates the complexity.

3 RESULTS

3.1 Accuracy

In original literature, only three papers (CUDA-

BLASTP, SOAP3 and BarraCUDA) give detailed

discussion of accuracy. SOAP3 and BarraCUDA get

nearly the same accuracy with their corresponding

CPU-based aligners. Although CUDA-BLASTP gets

a little worse result when aligning sequences shorter

than 128, it is much faster (CUDA-BLASTP

achieves speedup of up to 10.0 compared with

sequential NCBI BLASTP). Other aligners get the

same accuracy with their corresponding CPU-based

aligners.

3.2 Performance per Watt

GPU computing is energy-effective for many

applications. We gather the power dissipation

information in Table 2 according to the hardware

information listed in Table 1.

Higher PPW

GPU+CPU

/PPW

CPU

value indicates

better performance per watt. If PPW

GPU+CPU

/PPW

CPU

is higher than 1, it means the GPU-based aligner is

more energy-effective.

Six out of nine get PPW

GPU+CPU

/PPW

CPU

value

higher than 1. These aligners can be divided into

different groups. SOAP3 and BarraCUDA are short-

read aligners. CPU is a better choice for

BarraCUDA. SW-CUDA, GSW and CUDASW++

are implementations of Smith-Waterman algorithm

on GPU. They generally get a higher PPW

GPU+CPU

PPW

CPU

compared with GPU-BLAST and CUDA-

BLASTP. This is because Smith-Waterman

algorithm can better utilize the parallelism of GPU

compared with NCBI BLAST. Sequence alignment

with a suffix tree such as MUMmer might be

expected to be a poor candidate for GPU, but

MUMmerGPU stills get a relative good result

because MUMmer cannot exploit the multicore

feature of modern CPU.

ALiteratureEvaluationofCUDACompatibleSequenceAligners

269

Table 2: Power dissipations of hardware used in the papers. The data are from (Intel, 2012), (AMD, 2012), (Nvidia Tesla,

2012) and (geeks3d, 2012). The asterisk indicates the range of power dissipation since the model of CPU is uncertain.

GPU-based

Aligner

Power dissipation

of GPU (watts)

CPU-based

Aligner

Power dissipation

of CPU (watts)

Speedup

PPW

GPU+CPU

/PPW

CPU

MUMmerGPU 145 MUMmer 80 3.47x-3.79x 1.23-1.35

GPU accelerated

HMMER

145 HMMER 80 18.30x 6.51

SW-CUDA 145

SSEARCH

81.9-89*

15.30x 5.52-5.82

NCBI-BLAST 0.94x 0.34-0.36

GSW 170.9 SSEARCH 82-86* 8.50x 2.76-2.85

CUDASW++

236

NCBI BLAST 80-95*

3.48x(BLOSUM50) 0.88-1.00

289 5.31x(BLOSUM50) 1.15-1.31

GPU-BLAST 238 NCBI BLASTP 130 1.59x 0.56

CUDA-BLASTP

236

NCBI BLASTP 130

1.90x 0.67

289 2.82x 0.87

SOAP3 244

BWA

95-130*

2.84x 2.1-2.6

Bowtie 5.60x (3 mismatches) 1.57-1.94

BarraCUDA 225 BWA 95 1.09x 0.32

Table 3: Prices of the hardware. The data are from the paper (Schatz et al., 2007), (Amazon, 2012) and (Tweakers, 2012).

M denotes the price of system and ranges from $1000 to $3000.

GPU-based

Aligner

Price of

GPU ($)

CPU-based

Aligner

Price of

System($)

Speedup

PPR

GPU+Sys

/PPR

MUMmerGPU 529 MUMmer 882+M 3.47x-3.79x 0.30-0.37

GPU accelerated

HMMER

699 HMMER 389+M 18.30x 0.07-0.08

SW-CUDA 681

SSEARCH

106+M

15.30x 0.08-0.11

NCBI BLAST 0.94x 1.30-1.72

GSW 1400 SSEARCH 93+M 8.50x 0.17-0.27

CUDASW++

426

NCBI BLAST 200+M

3.48x(BLOSUM50) 0.33-0.39

559 5.31x(BLOSUM50) 0.22-0.28

GPU-BLAST 2781 NCBI BLASTP 1252+M 1.59x 1.04-1.41

CUDA-BLASTP

439

NCBI BLASTP 343+M

1.90x 0.60-0.70

549 2.82x 0.41-0.50

SOAP3 648

BWA

259+M

2.84x 0.42-0.53

Bowtie 5.60x (3 mismatches) 0.21-0.27

BarraCUDA 2400 BWA 1684+M 1.09x 1.39-1.74

3.3 Price-performance

For large research institutes, cost is not the

bottleneck at most times, but it is still an important

factor. Table 3 lists the prices of the hardware. Some

GPUs are out of production now, and the price of

hardware changes with time. So we use the retail

prices when the paper is published.

If PPR

GPU+Sys

/PPR

Sys

value is lower than 1, it

means the GPU-based aligner is more economical

than the corresponding aligner based on CPU.

Seven out of nine get PPR

GPU+Sys

/PPR

Sys

value lower

than 1. The different groups of sequence aligners

give similar result to those of energy efficiency

performance. The GPU-based aligners are generally

more economical than CPU-based aligners except

GPU-BLAST and BarraCUDA.

3.4 Programming Complexity

We first consider the emerging time of some GPU-

based aligners and their corresponding aligners

based on CPU. SOAP3 and BarraCUDA are

released in 2012, and their corresponding CPU-

based aligners SOAP2 and BWA are released in

2009. The intervals are both three years which are

much longer compared with the transplant interval

of cloud-based applications. On the other hand,

Wikipedia (Sequence alignment software, 2012)

provides a list of sequence aligners, but only a small

portion of them are implemented with GPU.

BIOINFORMATICS2013-InternationalConferenceonBioinformaticsModels,MethodsandAlgorithms

270

4 DISCUSSIONS

From the user’s standpoint, to obtain optimal result

accuracy should always be preferred to speed. Most

of the sequence aligners mentioned above complies

with this principle.

From above result we can see that even though

some sequence alignment algorithms such as

BLAST and MUMmer are not intrinsically suitable

for parallelization, they still get considerable

speedup without loss of accuracy. At the same time,

the performance per watt and price-performance of

GPU is better for most of the sequence aligners.

GPU computing is still a low-cost and energy-

efficient solution for high performance computing.

The programming complexity of CUDA slows

down the popularization of GPU computing in some

extent. But with the release of new NVIDIA GPU

compute architecture and the spread of some parallel

computing standards such as OpenACC (OpenACC,

2012) and OpenHMPP (OpenHMPP, 2012), GPU

has arguably become as easy, if not easier, to

program than multicore CPUs.

From the four factors discussed above we can see

that GPU computing is a sound choice for sequence

alignment. But there are more issues you may care

about. First, we can see that the existing GPU-based

sequence aligners are far from exploiting the

computation capability of GPU, though accelerate

the alignment to some extent. Second, further

development is needed for the usability of GPU-

based aligners. In the result, CUDASW++ is faster

and more accurate than NCBI BLAST. So why not

to choose CUDASW++? Usability is an important

factor that influences the user’s choice. The GPU-

based aligners are mainly developed for academic

research, most of which lacks later maintenance and

upgrade. The features of these GPU-based aligners

are far less than that of CPU-based aligners. The

solution of usability calls for more professional

programmers and algorithm designers to help with

the research of bioinformatics.

REFERENCES

Amazon, [online], Available: http://www.amazon.com

Accessed 2012-07-12.

AMD official website, [online], Available: http://products.

amd.com/pages/opteroncpuresult.aspx?AspxAutoDete

ctCookieSupport=1 Accessed 2012-10-20.

Edgar, R. C., 2010. Search and clustering orders of

magnitude faster than BLAST. Bioinformatics, vol. 26,

no. 19, pp. 2460-2461.

Geeks3d, [online], Available: http://www.geeks3d.com/20

090618/graphics-cards-thermal-design-power-tdp-data

base Accessed 2012-07-12.

Intel official website, [online], Available: http://ark.intel.c

om Accessed 2012-10-20.

Klus, P., Lam, S., Lyberg, D., Cheung, M. S., Pullan, G.,

McFarlane, I., Yeo, G., Lam, B., 2012. BarraCUDA -

a fast short read sequence aligner using graphics

processing units. BMC Research Notes, vol. 5, no. 1,

pp. 27.

Liu, Y., Maskell, D. L., Schmidt, B., 2009. CUDASW++:

optimizing Smith-Waterman sequence database

searches for CUDA-enabled graphics processing units.

BMC Res Notes, vol. 2, pp. 73.

Liu, W., Schmidt, B., Muller-Wittig, W., 2011. CUDA-

BLASTP: accelerating BLASTP on CUDA-enabled

graphics hardware. IEEE/ACM Transactions on

Computational Biology and Bioinformatics (TCBB),

vol. 8, no. 6, pp. 1678-1684.

Liu, C. M., Wong, T., Wu, E., Luo, R., Yiu, S. M., Li, Y.,

Wang, B., Yu, C., Chu, X., Zhao, K., Li, R., Lam, T.

W., 2012. SOAP3: Ultra-fast GPU-based parallel

alignment tool for short reads. Bioinformatics, doi:

10.1093/bioinformatics/bts061.

Manavski, S. A., Valle, G., 2008. CUDA compatible GPU

cards as efficient hardware accelerators for Smith-

Waterman sequence alignment. BMC Bioinformatics,

vol. 9, no. Suppl 2, pp. S10.

Nvidia Tesla, [online], Available: http://en.wikipedia.org/

wiki/Nvidia_Tesla Accessed 2012-07-12.

OpenACC, [online], Available: http://www.openacc-stand

ard.org Accessed 2012-07-12.

OpenHMPP, [online], Available: http://www.openhmpp.or

g Accessed 2012-07-12.

Schatz, M. C., Trapnell, C., Delcher, A. L., Varshney, A.,

2007. High-throughput sequence alignment using

Graphics Processing Units. BMC Bioinformatics, vol.

8, pp. 474.

Sequence alignment software, [online], Available:

http://en.wikipedia.org/wiki/List_of_sequence_alignm

ent_software Accessed 2012-07-12.

Striemer, G. M., Akoglu, A., 2009. Sequence Alignment

with GPU: Performance and Design Challenges. In

IEEE International Symposium on Parallel and

Distributed Processing.

Vouzis, P. D., Sahinidis, N. V., 2011. GPU-BLAST: using

graphics processors to accelerate protein sequence

alignment. Bioinformatics, vol. 27, no. 2, pp. 182-188.

Walters, J. P., Balu, V., Kompalli, S., Chaudhary, V., 2008.

Evaluating the use of GPUs for life science

applications. Buffalo, NY: The State University of

New York, http://www.cse.buffalo.edu/tech-

reports/2008-10.pdf. Accessed 2012-03-19.

Tweakers, [online], Available: http://tweakers.net/pricewat

ch Accessed 2012-10-20.

ALiteratureEvaluationofCUDACompatibleSequenceAligners

271
