Modeling Genealogical Domain

An Open Problem

Joan Campanyà Artés

, Jordi Conesa Caralt

and Enric Mayol

Universitat Politècnica de Catalunya, Barcelona Tech, Barcelona, Spain

Estudis d'Informàtica, Multimèdia i Telecomunicació, Universitat Oberta de Catalunya, Barcelona, Spain

ESSI Department, Universitat Politècnica de Catalunya, Barcelona Tech, Barcelona, Spain

Keywords: Conceptual Modeling, Genealogy, Ontologies.

Abstract: The automated processing, storing and knowledge inference of genealogical data presents several

difficulties. Roughly eighteen years ago, the FamilySearch organization published GEDCOM, a new

standard file format to allow genealogy software and tools to exchange genealogical data. Five years later,

the GENTECH Data Modeling Project, proposed a new genealogical logic data model to support research in

genealogy and to allow data inter-exchange between genealogy software. Despite being initial reference

models, they still have some limitations to adapt to different cultural and social environments. Additionally,

sharing genealogical data between systems is difficult since, even though they are syntactical reference

models, they may have semantic mismatches. Today, we have not a common and unified proposal as a

standard recognized genealogical model. In this way, in this paper we propose to consider the ontology

paradigm to extend expressiveness of concepts and relationships in such standards.

1 INTRODUCTION

Genealogy, is a discipline of social sciences and

history that study family composition, origin and

evolution. In recent years we have seen an

increasing popularity of genealogical services and

specific software to build familiar pedigree.

However, the absence of an accepted reference

model as a universal standard to represent

genealogical information makes it difficult to share

and reuse such data between people.

Designed as local databases or websites, most of

these applications offer importing and exporting

functionalities using file formats widely accepted,

like the GEDCOM

specification. However, given

the extendability of this specification, some

applications add proprietary extensions to

GEDCOM to consider these cultural and historical

diversity, not always recognized by others.

Another difficulty appears trying to identify

equivalent, complementary or inconsistency records

that refer to the same ancestor. We know that

personal names and places can change over time,

even if at only syntactical level. Applications based

GEDCOM, http://homepages.rootsweb.ancestry.

com/%7Epmcbride/gedcom/

on the relational model lack of appropriate

mechanisms to recognize variations of nominal

attributes, making it difficult to merge equivalent

instances. This situation is aggravated when the

database is scarce or incomplete.

The integration between genealogical

information systems could be achieved by means of

schema mappings among their databases and a

common reference model. Unfortunately, this model

does not still exist today. So, in this paper we present

a preliminary proposal to address such unmet need.

The paper is structured as follows. Section 2

gives a short overview of the most well-known

genealogical reference models. In Section 3 we

introduce our reference model proposal, and Section

4 describes its main features and contributions. In

Section 5 we identify open problems and main

challenges.

2 GENEALOGICAL DATA

STANDARDS: STATE OF ART

The most emblematic compilation project of

genealogical data on a large scale and worldwide has

been and continues to be carried out by

202

Campanyà Artés J., Conesa Caralt J. and Mayol E..

Modeling Genealogical Domain - An Open Problem.

DOI: 10.5220/0004135002020207

In Proceedings of the International Conference on Knowledge Engineering and Ontology Development (KEOD-2012), pages 202-207

ISBN: 978-989-8565-30-3

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

FamilySearch

organization. We have identified

three groups of proposals, those based on

GEDCOM, those on GENTECH and those

following an Ontological approach.

The first version of GEDCOM appeared on

1984. GEDCOM was just a paper specification

designed to allow genealogy programs to exchange

genealogical data. Therefore, it is not a data model

nor a genealogical application, but it is a format to

support data interoperability. GEDCOM is basically

oriented to a lineage-linked data model based on

families and individuals. This contrasts with

evidence models, where data is structured to reflect

the discovered and supporting evidences. GEDCOM

files are plain text similar to of markup languages.

However, it has the following disadvantages:

difficult evolution (due to its proprietary format),

family-centered (as an individual is identified by

the family it belongs, and not by the identity of their

parents), ambiguity (since the current specification

does not set limits on its hierarchical structure and

its not clearly defined in which levels or identity tags

where to put some data), lack of source references

(even though sources may be informed, there is not

an specific tracking method for data connected to the

research process, and it is difficult to make source

verification or to reuse such sources easily) and

inconsistencies (due to data duplication).

Some extensions to the GEDCOM format had

been proposed. On 2010, the “Build a Better

GEDCOM Project”

was initiated to develop an

international standard to store and transfer

genealogical data. An adhoc committee of

BetterGEDCOM wiki members established in 2012

the Family History Information Standards

Organization (FHISO)

. The objective is to solve

interoperability issues independently of technology

platforms, genealogy products or services. At the

same year, FamilySearch organization outlined a

major new project called GEDCOM X. The proposal

was a new format based on a XML language. It

defines new data formats to permit traceability of

sources and genealogical records. It also offers

support for sharing and linking data online.

In 1995, a different genealogical model was

proposed: the GENTECH Data Modeling Project

(Mitchell 2003) by the Federation of Genealogical

Societies (FGS, USA). Its main objective was to

define a genealogical data model to model the

genealogy research process and to facilitate data

FamilySearch, http://www.familysearch.org/

BetterGEDCOM wiki, http://bettergedcom.wikispaces.

com/

FHISO, http://fhiso.org/

exchange among genealogists. Although it was just

a conceptual model, it became a reference for many

other implementations. This model was not so

worldwide accepted. Genealogical data is defined

using certain structured collections, roles and

attributes. Such attributes are hardly typed,

introducing some strictness and limiting its

adaptation to different contexts. Moreover, the

model assumes its implementation on relational

databases, an unnecessary limitation for other

information technologies or database models.

More recently, a new approach was initiated by

(Zandhuis 2005). He proposes to use ontologies in

the genealogical data treatment to take advantage of

the Semantic Web in the data distribution and

knowledge extraction. Genealogical data was

modeled with OWL/RDF, but did not develop much

beyond that the class structure and properties

necessary to complete a genealogical model.

In the same direction, (Campbell 2006) proposes

the creation of an open network data, scalable,

extensible, based on open standards and

understandable by machines. In essence it was a

network of servers updated and maintained by local

genealogical organizations. In order to enable

automated semantic interpretation, genealogical data

is fragmented in the form of subject-predicate-object

sentences, in OWL-RDF files. Interconnections

between nodes were fixed by equivalence relations

between entities, task in which collaborate

intelligent agents.

Another interesting contribution is (Woodbury

2010). Its purpose is to show the feasibility of an

information system, based on individual and event

information, to automatically load of unstructured

genealogical data and to infer new hidden

knowledge. Textual data is analyzed using

ontological patterns and regular expressions. Data is

stored using OWL/RDF files. This proposal use a set

of tags that define SWRL rules and integrity

constraints. However, this model reflects only a

fraction of the complexity of the domain.

3 OUR PROPOSAL

The main difficulties when sharing data between

genealogical applications can be grouped into four

types. (1) Syntactic variants: the frequent existence

of syntactic variations of names of individuals and

locations make it difficult their proper recognition

and management. (2) Structural heterogeneity: the

social structure and evolution of the family, roles of

its individuals depend on temporal and cultural

ModelingGenealogicalDomain-AnOpenProblem

203

Figure 1: Modeling genealogical assertions.

contexts, so they must he interpreted correctly. (3)

Semantic heterogeneity: merging and integrating

genealogical data from different sources require take

into account different concept interpretation and

their inference rules. (4) Data quality: genealogical

data may contain transcription errors,

incompleteness and/or not be proved. All this

characteristics are inherent to the genealogy domain

and they difficult genealogical data management and

sharing.

Ontology paradigm may be appropriate to solve

some of these problems, since it handles semantic

concepts rather than syntactic keywords in

information retrieval systems. Therefore, genealogy

data repositories content may be described

regardless of their syntactic representation, focusing

on its semantic integration.

Our proposal consists of two independent

models: the Projects and the Assertions models. The

first one focus on the genealogical research process.

It describes projects, goals, tasks, collaborators,

resources and it keep track of the document sources

of genealogical information. The second one, the

Assertions model, contains the proper genealogical

information extracted or inferred from these sources.

Due to space limitations, this paper only deals with

the second one.

The concepts of the assertion model (Figure 1)

refer to people, places, dates, events, characteristics

and groups. So its design should facilitate addressing

the aforesaid four groups of problems. The core is

the Assertion class. Assertions may be deduced from

other assertions, or may be provided by a

collaborator and linked to one source. In both cases,

they have a annotation of genealogical interest, and

refer to one or more statements. These statements

refer to entities as people, relationships among them,

events, groups, personal characteristics, etc., but in a

implicit way. In order to enable automation with

computers, we need to make explicit this knowledge,

as discussed in the next section.

Statement class records concepts and their

relationships as atomic triples, in the form of

<subject, predicate, object>, which is similar to the

structure formats used in the semantic web: basically

RDF, RDF Schema and OWL. In our model

Statement is a associative class of the ternary

relationship between two instances of Entity class

(subject and object), and a Predicate instance. An

Event usually occurs at known times and places. The

Place class do not specialize to specific categories to

permit the maximum adaptability to different

cultural and geographical contexts (Figure 2).

4 GOING FORWARD: OUR

CONTRIBUTIONS

Most part of commercial genealogical information

systems and applications implement data persistence

upon relational databases, following the closed

KEOD2012-InternationalConferenceonKnowledgeEngineeringandOntologyDevelopment

204

Figure 2: Relationships between Event, Place and Date.

world assumption (CWA). In this sense, only facts

or assertions stored in the database are true, and

therefore, any other fact not stored as a database

tuple is false or non-existent. This assumption

limits exploration of possible related data when

information is incomplete or imprecise, which is

quite common in genealogy. A similar situation

may appears when integrating repositories that

have data in common but without information that

allow to filter duplicates. Our conceptual model

releases entities and their attributes from restrictive

types, facilitating integration to diverse contexts

and casuistry. We are interested in the semantic

value of attributes and roles, not in the explicit

record syntax or types. Adopting the ontological

paradigm, we can transform from implicit to

explicit semantic knowledge, in a way to reaching

a open world assumption (OWA).

To permit interaction between different systems

requires explicit semantic interoperability. To

obtain a context independent model we need to

address two goals. (1) The adoption of a specific

vocabulary, identifiable by its IRI (International

Resource Identifier) and namespace, as

enumeration types. Importantly, these types could

be particularized on different implementations of

the model. (2) The use of ontologies (general or

specific) that cover this vocabularies, to enable a

constructive information merge process between

information systems.

To differentiate the Assertions conceptual

model of the ontology from where the facts come,

we preferred rename the latter as Facts ontology. A

second ontology, PersonaEvents, is automatically

populated using the information of the Facts

ontology that deals with a given person. This

describes the specific events and relationships

(property, on a ontology terms) of Persona, which

is particularly of interest in genealogy. To

illustrate this, we can materialize the implicit

Statement relationships in properties between

instances of Person and Entity, like hasParent,

hasWife, wasBorn, professedReligion, etc.

So between these two ontologies,

PersonaEvents and Facts, there is redundant

information. This implies that, to avoid

inconsistencies, all changes made in any of them

should be reflected in the other. Another

remarkable aspect is that instances are referenced

by its IRI, avoiding the disadvantages arising from

different contextual interpretation. However this

has a cost, losing in PersonaEvents ontology any

reference to information sources, and that's why it's

necessary to maintain their link with statements in

the Facts ontology.

5 NEW CHALLENGES

One of the reasons why we have chosen ontologies

to represent knowledge is because the amount of

data we have may evolve constantly and because

some inferences can be done even when not all the

data is known. The open world assumption allows

us to add new knowledge incrementally and

ModelingGenealogicalDomain-AnOpenProblem

205

dynamically. The only condition is that the new

information cannot contradict the information of

the existing knowledge base, assuring that all

inferences made previously are still valid.

The ability to share information is also our

objective. The current situation is characterized by

an increasing number of private applications and a

lack of open and recognized standards. In addition,

there are an increasing number of semantic web

services that provide access to data repositories. It

would be desirable to agree on some specifications

that provide unambiguous descriptions of their

services and their mappings in a common ontology

domain.

A second line of research is to consider issues

related to database distribution. In this context,

instances identification is a major challenge, as it is

to discover duplicates (when the same instance

appear in two places) or combining multiple

overlapping data that refers to the same instance.

To deduce equivalence between genealogical

instances we must consider not only lexical

coincidence or proximity of key attributes (name,

date and place of birth or death) but also known

kinship with others, as portions of their family tree

(parents, siblings, spouse,…). Furthermore, record

linkage still remains a complex problem. Different

methods for automation of data linkage and for

reducing manual processes have been proposed,

most based on techniques from artificial

intelligence. Research, despite being limited to

particular environments, are promising and

satisfactory enough in the validation tests

performed. Neural networks (Pixton 2006),

bayesian probability models (Larsen, 2005) and

metric-based machine learning algorithms (Ivie,

2007) can provide the tools we need to simplify the

task.

The third challenge should allow us to build the

knowledge base from basic statements. As we have

seen in Section 4, the base of our model lies in

elementary semantic units inspired by the first-

order logic, the triples <subject, predicate, object>.

These triples formalize the essence of what is

known and what can be said. Unfortunately, using

such elemental assertions to express knowledge

make undecidable the processes that would allow

to infer new knowledge. However, the

computational complexity problems that involve

the use of first-order logic are well known. With

our two related ontologies, Facts and

PersonaEvents, this drawback can be fixed, as the

inferences of interest would be over the second,

obtained as a reduction from Facts. However, with

this operation we can reduce to one direct Person-

Entity relationship which originally may have

required several statements.

To complete the challenges, we must mention

problems about decidability and computational

complexity. Regarding our proposal, we have

chosen to reconcile description logics (DLs),

which form the basis for OWL, and rule languages,

while maintaining decidability:

- Using Semantic Web Rule Language (SWRL)

rules (Horrocks 2004), but by taking certain

precautions, such as restricting its applicability to

certain subset of data. These rules, known as DL-

safe as combination with OWL-DL, leads to

decidable systems and, more importantly,

computable in polynomial time. We will make

reference to some published studies that propose

specific solutions (Hirankitti 2011, Mei 2005,

Motik 2004).

- The latest OWL 2 Web Ontology Language

Recommendation, informally OWL 2 (Motik

2009), expands the options for integrating certain

kind of rules in OWL, thereby maintaining

decidability. SROIQ rules can provide interesting

features.

6 CONCLUSIONS

For many years, genealogical data used by the vast

majority of computer applications has been shared

using the data transfer format created by

GEDCOM. The problem arises when we want to

integrate the information collected by different

users. Despite the availability of data exchange

formats widely accepted, recognition of family ties

between those resources are difficult and requires

some expert assistance.

In this paper we proposed a genealogical model

that aims to be flexible enough to adapt to social,

cultural, geographical or temporal variability. The

ontological paradigm and its deployment on last

years, offers a variety of experiences and practical

tools competent to represent semantic information

of concepts relevant to the genealogical model.

These ontological tools, together with the proposed

semantic definitions, can provide solutions about

real problems that appear when integrating

different resources, such as data inconsistencies or

recognition of equivalences.

Finally, the automatic processing of

information is possible only after transforming

implicit knowledge from source statements to

explicit semantic concepts In this way, ontologies,

KEOD2012-InternationalConferenceonKnowledgeEngineeringandOntologyDevelopment

206

OWL axioms and SWRL rules provide powerful

languages understandable by computers. Future

work must be done in order to achieve a reliable

data processing with minimal need from expert

supervision.

REFERENCES

Campbell, Hilton, 2006. Enabling the Distributed Family

Tree, in Department of Computer Science - Brigham

Young University.

Family History Department, The Church of Jesus Christ

of Latter-day Saints, 2000. GEDCOM XML

Specification - Release 6.0 (Draft)

Hirankitti, Visit and Xuan, Trang Mai, 2011. A Meta-

reasoning Approach for Reasoning with SWRL

Ontologies, in Proceedings of the International

MultiConference of Engineers and Computer

Scientists 2011 Vol I, IMECS 2011, March 16-18,

2011, Hong Kong

Horrocks, Ian et al., 2004. SWRL: A Semantic Web Rule

Language Combining OWL and RuleML, in W3C

Member Submission

Ivie, S. et al., 2007. A Metric-Based Machine Learning

Approach to Genealogical Record Linkage,

Department of Computer Science (Brigham Young

University)

Larsen, Michael, 2005. Advances in Record Linkage

Theory: Hierarchical Bayesian Record Linkage

Theory, Department of Statistics (Iowa State

Univeristy)

Mei, Jing (Peking University) and Paslaru Bontas, Elena

(Freie Universität Berlin), 2005. Reasoning

Paradigms for SWRL-enabled Ontologies

Mitchell, Stanley, 2003. Gentech-GDM Reference

Model

(http://freepages.history.rootsweb.com/~mitchellshar

p/gdmref/gdmref-01.pdf)

Motik, Boris et al., 2004. Query Answering for OWL-

DL with Rules

Motik, Boris et al., 2009. OWL 2 Web Ontology

Language – Profiles. W3C Recommendation 27

October 2009 (http://www.w3.org/TR/2009/REC-

owl2-profiles/)

Pixton, Burdette, 2006. Improving record linkage

through pedigrees, Department of Physical and

Mathematical Sciences (Brigham Young University)

Woodbury, Charla, 2010. Automatic extraction from and

reasoning about genealogical records. Brigham

Young University (BYU, Utah – EEUU).

Zandhuis, Ivo, 2005. Towards a Genealogical Ontology

for the Semantic Web, in Association for History and

Computing Conference, (Amsterdam, 14-17

September 2005)

ModelingGenealogicalDomain-AnOpenProblem

207
